Diagnostic Trouble Code (DTC) Detecting Criteria (H6DO): Overview Subaru Outback BP

Testing & Diagnostics 26 illustrations ~1903 words

COMPONENT DESCRIPTION

Atmospheric pressure sensor is built in ECM.

Scheme 2054

Scheme 2054: ENABLE CONDITION

ECM OPERATION AT DTC SETTING

  1. Memorize the freeze frame data. (For test mode $02)
  2. Memorize the diagnosis value and trouble standard value. (For test mode $06)
  1. Memorize the freeze frame data. (For test mode $02)
  2. Memorize the diagnostic value and trouble standard value. (For test mode $06)
  1. Pressure Control Solenoid Valve

Pressure control solenoid valve maintains the fuel tank pressure equal to the atmospheric air pressure. Normally, the solenoid is set to OFF, and the valve mechanically opens and closes in accordance with the difference between the tank pressure and atmospheric air pressure, and the tank pressure and canister pressure.

During the diagnosis, the valve is forcibly opened by setting the solenoid to ON.

Scheme 2055

Scheme 2055
  1. Valve Operation and Air Flow

As in the X parts below, there are the area with atmospheric air pressure above the diaphragm and the area with tank pressure below the diaphragm. Also, as in the Y parts below, there are the area with tank pressure above the diaphragm and the area with canister pressure below the diaphragm. In the table below the air flow from each port in accordance with pressure difference is shown with the atmospheric air pressure port A, tank pressure port B and canister pressure port C.

Scheme 2056

Scheme 2056

Scheme 2057

Scheme 2057

Scheme 2058

Scheme 2058

Scheme 2059

Scheme 2059
  1. When A < B (Solenoid OFF)
  2. When B < C (Solenoid OFF)
  3. When solenoid is ON
  4. Drain valve

Drain valve controls the ambient air to be introduced to the canister. Normally the solenoid is set to OFF and the valve is open. The valve is closed when the solenoid is set to ON only at the time of diagnosis.

Scheme 2060

Scheme 2060
  1. Tank Pressure Switching Solenoid

Fuel tank sensor control valve is connected to fuel tank pressure sensor and opened to atmosphere. A normal condition, fuel tank sensor control valve is OFF, and circuit of fuel pressure sensor is open to atmosphere. If fuel tank sensor control valve is ON, then circuit is closed.

Scheme 2061

Scheme 2061

Purpose of this solenoid

Fuel tank pressure sensor detects the difference between the atmospheric air pressure and the tank pressure, and the ECM monitors the pressure difference.

Even if the tank pressure is constant, the atmospheric air pressure varies depending on the driving height and the pressure signal transmitted to ECM will change.

Scheme 2062

Scheme 2062

Especially, in the small leakage [0.5 mm (0.02 inch)], minute change in the tank pressure has to be detected. This diagnosis period is long (approx. 29 seconds). And if the driving height changes during the diagnosis, he atmospheric air pressure changes. In this case, it becomes difficult to precisely detect the tank pressure variation, causing erroneous diagnosis. Therefore, using the atmospheric pressure switching solenoid, atmospheric air is sealed between the fuel tank pressure sensor and atmospheric pressure switching solenoid, maintaining the air pressure constant and enabling the detection of minute variation of tank pressure.

Scheme 2063

Scheme 2063

Note. ECM also has the atmospheric air pressure sensor, and always monitors atmospheric air. However, as the monitoring range is large, that is, 53.3 to 107 kPa (400 to 800 mmHg, 15.7 to 31.6 inHg), it is not suitable for detection of minute pressure variation. In the case of small leakage diagnosis, the tank pressure variation is very small, that is, 0.13 to 0.26 kPa (1 to 2 mmHg, 0.04 to 0.08 inHg), and the fuel tank pressure sensor is equipped.

  1. Memorize the freeze frame data. (For test mode $02)
  2. Memorize the diagnostic value and trouble standard value. (For test mode $06)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Inhibitor switch ensures the safety at engine start. This switch is installed to the right side of transmission case, and operated by selector lever. When the selector lever is in the "P" or "N" range, the engine will start because the electric circuit in inhibitor switch is closed and the starter circuit is connected. When the selector lever is in the "R", "D", "3", "2" or "1" range, the electric circuit in inhibitor switch is open; therefore, the engine cannot be cranked. In the "R" range, the back-up light will illuminate because the back-up light circuit in the switch is connected. In addition to the functions above, the inhibitor switch has the circuit which detects the selected range position at the present and transmits the range signal to the TCM.

Scheme 2064

Scheme 2064: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

ATF temperature sensor is installed to the hydraulic control valve body of transmission as a unit with transmission harness. This sensor detects ATF temperature and outputs it as electric resistance signal.

Scheme 2065

Scheme 2065: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

Torque converter turbine speed sensor (output shaft speed sensor) is installed to the outside of transmission case. This sensor detects the turbine speed of torque converter by the peripheral speed of high clutch drum connected to input shaft. And then it transmits the sine wave signal (32 pulses per rev.) to TCM. TCM calculates the ratio of the input shaft speed to vehicle speed, and then makes a judgment whether to shift or not.

Scheme 2066

Scheme 2066: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

This vehicle speed sensor (output shaft speed sensor) is installed to the outside of transmission case. This sensor detects the front wheel speed, and transmits the sine wave signal (32 pulses per rev.) to TCM. TCM converts the signal to pulse signal, and transmits to both of the ECM and the combination meter.

Scheme 2067

Scheme 2067: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

Engine speed sensor is installed to the outside of engine body and crank part. This sensor detects the crank speed, and transmits the sine wave signal (2 pulses per rev.) to TCM.

Scheme 2068

Scheme 2068: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Lock-up duty solenoid is installed to the transmission hydraulic control valve body. The duty ratio is controlled by the signal from TCM. This allows the lock-up clutch to be connected or released smoothly by controlling the lock-up control valve.

Scheme 2069

Scheme 2069: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

Line pressure duty solenoid is installed to the transmission hydraulic control valve body. The duty ratio is controlled by the signal from TCM. This allows controlling the pressure modifier valve and accumulator control valve A, and allows the line pressure to be adjusted to the pressure appropriate for driving condition.

Scheme 2070

Scheme 2070: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

Shift solenoid 1 Shift solenoid is installed to the transmission hydraulic control valve body. This solenoid is switched on or off by the signal from TCM. Gear positions will change depending on the solenoid condition which is ON or OFF.

Scheme 2071

Scheme 2071: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

Shift solenoid 2 Shift solenoid is installed to the transmission hydraulic control valve body. This solenoid is switched on or off by the signal from TCM. Gear positions will change depending on the solenoid condition which is ON or OFF.

Scheme 2072

Scheme 2072: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

Low clutch timing solenoid Low clutch timing solenoid is installed to the transmission hydraulic control valve body. This solenoid is switched on or off by the signal from TCM. This allows controlling the low clutch timing valve B and reverse inhibitor valve.

Scheme 2073

Scheme 2073: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

2-4 brake duty solenoid is installed to the transmission hydraulic control valve body. The duty ratio is controlled by the signal from TCM. This solenoid decreases the change gear shock by adjusting the 2-4 brake pressure during 2-4 brake operation.

Scheme 2074

Scheme 2074: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

2-4 brake timing solenoid is installed to the transmission hydraulic control valve body. This solenoid is switched on or off by the signal from TCM. This allows controlling the 2-4 brake timing valve B and decreases the change gear shock.

Scheme 2075

Scheme 2075: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Data frame as "Start signal (Low_40 ms + High_20 ms) rightarrow Data rightarrow End signal" is transmitted every approx. 1 second.

Scheme 2076

Scheme 2076: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

Data frame as "Start signal (Low_40 ms + High_20 ms) rightarrow Data rightarrow End signal" is transmitted every approx. 1 second.

Scheme 2077

Scheme 2077: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

Atmospheric pressure sensor is built in ECM.

Scheme 2078

Scheme 2078: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

Atmospheric pressure sensor is built in ECM.

Scheme 2079

Scheme 2079: ENABLE CONDITION

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)

Memorize the freeze frame data. (For test mode $02)
