Engine (Diagnostics) (H4SO U5): Diagnosis Subaru Outback BP

Testing & Diagnostics 341 illustrations ~9180 words

INSPECTION

Before performing diagnostics, check the following items which might affect engine problems

MODE $01 (CURRENT POWERTRAIN DIAGNOSTIC DATA)

Refers to data denoting the current operating condition of analog input/output, digital input/output and/or the powertrain system.

A list of the support data and PID (Parameter Identification) codes are shown in the following table.

Scheme 796

Scheme 796: MODE $01 (CURRENT POWERTRAIN DIAGNOSTIC DATA)

Note. Refer to OBD-II general scan tool manufacturer's instruction manual to access generic OBD-II PIDs (MODE $01).

Refer to READ DIAGNOSTIC TROUBLE CODE (DTC) for information about data denoting emission-related powertrain DTC. .

Refers to the mode used to clear or reset emission-related diagnostic information (OBD-II trouble diagnostic information).

Note. Refer to OBD-II general scan tool manufacturer's instruction manual to clear or reset emission-related diagnostic information (MODE $04).

READ DIAGNOSTIC TROUBLE CODE (DTC) FOR ENGINE (NORMAL MODE)

Refer to READ DIAGNOSTIC TROUBLE CODE (DTC) for information about how to indicate DTC. .

READ DIAGNOSTIC TROUBLE CODE (DTC) FOR ENGINE (OBD MODE)

Refer to READ DIAGNOSTIC TROUBLE CODE (DTC) .

OBD-II GENERAL SCAN TOOL

Refers to data denoting emission-related powertrain DTC.

For details concerning DTC, refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) .

Note. Refer to OBD-II general scan tool manufacturer's instruction manual to access emission-related powertrain DTC (MODE $03) .

PREPARATION FOR THE INSPECTION MODE

  1. Make sure the fuel remains approx. half amount [20 - 40l (5.3 - 10.6 US gal, 4.4 - 8.8 lmp gal)] and the battery voltage is 12 V or more.
  2. Raise the vehicle using a garage jack and place on safety stands or drive the vehicle onto free rollers.

Scheme 797

Scheme 797

Scheme 798

Scheme 798: SUBARU SELECT MONITOR

Scheme 799

Scheme 799

Scheme 800

Scheme 800

Scheme 801

Scheme 801

Scheme 802

Scheme 802
  1. After clearing the memory, check for any remaining unresolved trouble data. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) .
  2. Warm up the engine.
  3. Prepare the Subaru Select Monitor kit. Refer to «PREPARATION TOOL»(ref-208370-S05181239172005120700000) , General Description.
  4. Connect the diagnosis cable to Subaru Select Monitor.
  5. Insert the cartridge into Subaru Select Monitor. Refer to «PREPARATION TOOL»(ref-208370-S05181239172005120700000) , General Description.
  6. Connect the test mode connector (A) at the lower portion of instrument panel (on driver's side).
  7. Connect the Subaru Select Monitor to data link connector. Data link connector is located in the lower portion of the instrument panel (on the driver's side). Connect the diagnosis cable to data link connector. CAUTION: Do not connect the scan tools except for Subaru Select Monitor and OBD-II general scan tool.
  8. Turn the ignition switch to ON (engine OFF) and Subaru Select Monitor switch to ON.
  9. On << Main Menu>> display screen, select the {2. Each System Check} and press the [YES] key.
  10. On << System Selection Menu>> display screen, select the {Engine Control System} and press the [YES] key.
  11. Press the [YES] key after the information of engine type is displayed.
  12. On << Engine Diagnosis>> display screen, select the {Dealer Check Mode Procedure} and press the [YES] key.
  13. When the "Perform Inspection (Dealer Check) Mode?" is shown on display screen, press the [YES] key.
  14. Perform subsequent procedures as instructed the display screen.

If trouble still remains in memory, the corresponding DTC appears on display screen.

Note. For detailed operation procedure, refer to the SUBARU SELECT MONITOR OPERATION MANUAL For details concerning the DTC, refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) Release the parking brake. The speed difference between front and rear wheels may light either the ABS warning light, but this indicates no malfunctions. When the engine control diagnosis is finished, perform the ABS memory clearance procedure of self-diagnosis system.

Scheme 803

Scheme 803: OBD-II GENERAL SCAN TOOL

Scheme 804

Scheme 804
  1. After clearing memory, check for any remaining unresolved trouble data: Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) .
  2. Warm up the engine.
  3. Connect the test mode connector (A) at the lower side of instrument panel (on the driver's side).
  4. Connect the OBD-II general scan tool to its data link connector. CAUTION: Do not connect the scan tools except for Subaru Select Monitor and OBD-II general scan tool.
  5. Start the engine. NOTE: Ensure the selector lever is placed in "P" position before starting. (AT models) Depress the clutch pedal when starting engine. (MT models)
  6. Using the selector lever or shift lever, turn the "P" position switch and "N" position switch to ON.
  7. Depress the brake pedal to turn brake switch ON. (AT models)
  8. Keep the engine speed in 2,500 - 3,000 rpm range for 40 seconds.
  9. Place the selector lever or shift lever in "D" position (AT models) or "1st" gear (MT models) and drive the vehicle at 5 to 10 km/h (3 to 6 MPH). NOTE: On AWD vehicles, release the parking brake. The speed difference between front and rear wheels may light ABS warning light, but this indicates no malfunctions. When the engine control diagnosis is finished, perform the ABS memory clearance procedure of self-diagnosis system.
  10. Using the OBD-II general scan tool, check for DTC and record the result(s).

Note. For detailed operation procedures, refer to the OBD-II General Scan Tool Instruction Manual For details concerning DTC, refer to the list of Diagnostic Trouble Code (DTC). See LIST OF DIAGNOSTIC TROUBLE CODE (DTC) .

For clear memory procedures using the OBD-II general scan tool, refer to OBD-II General Scan Tool Instruction Manual .

After the memory has been cleared, the idle air control solenoid valve must be initialized. To do this, turn the ignition switch to ON position. Wait 3 seconds before starting the engine.

Scheme 805

Scheme 805: OPERATION

Scheme 806

Scheme 806

Scheme 807

Scheme 807

Scheme 808

Scheme 808

Scheme 809

Scheme 809
  1. Prepare the Subaru Select Monitor kit. Refer to «PREPARATION TOOL»(ref-208370-S05181239172005120700000) , General Description.
  2. Connect the diagnosis cable to Subaru Select Monitor.
  3. Insert the cartridge into Subaru Select Monitor. Refer to «PREPARATION TOOL»(ref-208370-S05181239172005120700000) , General Description.
  4. Connect the test mode connector (A) at the lower portion of instrument panel (on driver's side).
  5. Connect the Subaru Select Monitor to data link connector. Data link connector is located in the lower portion of instrument panel (on driver's side). Connect the diagnosis cable to data link connector. CAUTION: Do not connect scan tools except for Subaru Select Monitor and OBD-II general scan tool.
  6. Turn the ignition switch to ON (engine OFF) and Subaru Select Monitor switch to ON.
  7. On << Main Menu>> display screen, select the {2. Each System Check} and press the [YES] key.
  8. On << System Selection Menu>> display screen, select the {Engine Control System} and press the [YES] key.
  9. Press the [YES] key after the information of engine type is displayed.
  10. On << Engine Diagnosis>> display screen, select the {System Operation Check Mode} and press the [YES] key.
  11. On << System Operation Check Mode>> display screen, select the {Actuator ON/OFF Operation} and press the [YES] key.
  12. Select the desired compulsory actuator on the << Actuator ON/OFF Operation>> display screen and press the [YES] key.
  13. Pressing the [NO] key completes the compulsory operation check mode. The display will then return to the << Actuator ON/OFF Operation>> screen. A list of support data is shown in the following table.

Scheme 810

Scheme 810

Note. The following parts will be displayed but not functional. For detailed operation procedure, refer to SUBARU SELECT MONITOR OPERATION MANUAL .

Scheme 811

Scheme 811: PROCEDURE

Scheme 812

Scheme 812: ACTIVATION OF MALFUNCTION INDICATOR LIGHT

Scheme 813

Scheme 813

Scheme 814

Scheme 814

Scheme 815

Scheme 815
  1. When the ignition switch is turned to ON (engine off), the malfunction indicator light (A) in the combination meter illuminates. NOTE: If the malfunction indicator light does not illuminate, perform diagnostics of the malfunction indicator light circuit or the combination meter circuit. Refer to «CHECK ENGINE MALFUNCTION INDICATOR LAMP (MIL) DOES NOT COME ON»(ref-208370-S17027351312005120700000) , Malfunction Indicator Light.
  2. After starting the engine, the malfunction indicator light goes out. If it does not, either the engine or the emission control system is malfunctioning.
  3. If the diagnosis system senses a misfire which could damage the catalyzer, the malfunction indicator light will blink at a cycle of 1 Hz.
  4. When the ignition switch is turned to ON (engine off) or to "START" with test mode connector connected, the malfunction indicator light blinks at a cycle of 3 Hz.

DIAGNOSIS

  1. The CHECK ENGINE malfunction indicator lamp (MIL) circuit is open or shorted.

TROUBLE SYMPTOM

  1. When ignition switch is turned ON (engine OFF), MIL does not come on.

Scheme 816

Scheme 816: WIRING DIAGRAM

Scheme 817

Scheme 817

Scheme 818

Scheme 818
  1. The CHECK ENGINE malfunction indicator lamp (MIL) circuit is shorted.
  1. Although MIL comes on when engine runs, trouble code is not shown on Subaru select monitor or OBD-II general scan tool display.

Scheme 819

Scheme 819: WIRING DIAGRAM

Scheme 820

Scheme 820
  1. The CHECK ENGINE malfunction indicator lamp (MIL) circuit is open or shorted.
  2. Test mode connector circuit is in open.
  1. When inspection mode, MIL does not blink at a cycle of 3 Hz.

Scheme 821

Scheme 821: WIRING DIAGRAM

Scheme 822

Scheme 822
  1. Test mode connector circuit is shorted.
  1. MIL blinks at a cycle of 3 Hz when ignition switch is turned to ON.

Scheme 823

Scheme 823: WIRING DIAGRAM

Scheme 824

Scheme 824

Scheme 825

Scheme 825: PROCEDURE

DTC DETECTING CONDITION

  1. Two consecutive driving cycles with fault
  2. GENERAL DESCRIPTION < Refer to «DTC P0030: HO2S HEATER CONTROL CIRCUIT (BANK SENSOR 1)»(ref-208371-S19604533362005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 826

Scheme 826: WIRING DIAGRAM

Scheme 827

Scheme 827: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0031: HO2S HEATER CONTROL CIRCUIT LOW (BANK 1 SENSOR 1)»(ref-208371-S06399443522005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 828

Scheme 828: WIRING DIAGRAM

Scheme 829

Scheme 829: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0032: HO2S HEATER CONTROL CIRCUIT HIGH (BANK 1 SENSOR 1)»(ref-208371-S21970756142005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 830

Scheme 830: WIRING DIAGRAM

Scheme 831

Scheme 831: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0037: HO2S HEATER CONTROL CIRCUIT LOW (BANK 1 SENSOR 2)»(ref-208371-S20347598862005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 832

Scheme 832: WIRING DIAGRAM

Scheme 833

Scheme 833: DIAGNOSTIC PROCEDURE

Scheme 834

Scheme 834
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0038: HO2S HEATER CONTROL CIRCUIT HIGH (BANK 1 SENSOR 2)»(ref-208371-S30467780022005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 835

Scheme 835: WIRING DIAGRAM

Scheme 836

Scheme 836: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0043: HO2S HEATER CONTROL CIRCUIT LOW (BANK 1 SENSOR 3)»(ref-208371-S07656035902005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 837

Scheme 837: WIRING DIAGRAM

Scheme 838

Scheme 838: DIAGNOSTIC PROCEDURE

Scheme 839

Scheme 839
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0044: HO2S HEATER CONTROL CIRCUIT HIGH (BANK 1 SENSOR 3)»(ref-208371-S14369240342005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 840

Scheme 840: WIRING DIAGRAM

Scheme 841

Scheme 841: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0050: HO2S HEATER CONTROL CIRCUIT (BANK 2 SENSOR 1)»(ref-208371-S10402978782005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 842

Scheme 842: WIRING DIAGRAM

Scheme 843

Scheme 843: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0051: HO2S HEATER CONTROL CIRCUIT LOW (BANK 2 SENSOR 1)»(ref-208371-S06421318612005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 844

Scheme 844: WIRING DIAGRAM

Scheme 845

Scheme 845: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0052: HO2S HEATER CONTROL CIRCUIT HIGH (BANK 2 SENSOR 1)»(ref-208371-S21444600922005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.> CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 846

Scheme 846: WIRING DIAGRAM

Scheme 847

Scheme 847: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0057: HO2S HEATER CONTROL CIRCUIT LOW (BANK 2 SENSOR 2)»(ref-208371-S07523487822005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 848

Scheme 848: WIRING DIAGRAM

Scheme 849

Scheme 849: DIAGNOSTIC PROCEDURE

Scheme 850

Scheme 850
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0058: HO2S HEATER CONTROL CIRCUIT HIGH (BANK 2 SENSOR 2)»(ref-208371-S17078410142005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 851

Scheme 851: WIRING DIAGRAM

Scheme 852

Scheme 852: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0068: MANIFOLD PRESSURE SENSOR RANGE/PERFORMANCE»(ref-208371-S08418493312005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 853

Scheme 853: WIRING DIAGRAM

Scheme 854

Scheme 854: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0101: MASS OR VOLUME AIR FLOW CIRCUIT RANGE/PERFORMANCE»(ref-208371-S34671300432005120700000) .
  1. Erroneous idling
  2. Engine stalls.
  3. Poor driving performance
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 855

Scheme 855: WIRING DIAGRAM

Scheme 856

Scheme 856: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0102: MASS OR VOLUME AIR FLOW CIRCUIT LOW INPUT»(ref-208371-S16577033372005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Engine stalls.
  3. Poor driving performance
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 857

Scheme 857: WIRING DIAGRAM

Scheme 858

Scheme 858: DIAGNOSTIC PROCEDURE

Scheme 859

Scheme 859
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0103: MASS OR VOLUME AIR FLOW CIRCUIT HIGH INPUT»(ref-208371-S38630907092005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Engine stalls.
  3. Poor driving performance
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 860

Scheme 860: WIRING DIAGRAM

Scheme 861

Scheme 861: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0107: MANIFOLD ABSOLUTE PRESSURE/BAROMETRIC PRESSURE CIRCUIT LOW INPUT»(ref-208371-S40119617382005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 862

Scheme 862: WIRING DIAGRAM

Scheme 863

Scheme 863: DIAGNOSTIC PROCEDURE

Scheme 864

Scheme 864
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0108: MANIFOLD ABSOLUTE PRESSURE/BAROMETRIC PRESSURE CIRCUIT HIGH INPUT»(ref-208371-S29834128392005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 865

Scheme 865: WIRING DIAGRAM

Scheme 866

Scheme 866: DIAGNOSTIC PROCEDURE

Scheme 867

Scheme 867
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0111: INTAKE AIR TEMPERATURE CIRCUIT RANGE/PERFORMANCE»(ref-208371-S33195374962005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 868

Scheme 868: WIRING DIAGRAM

Scheme 869

Scheme 869: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0112: INTAKE AIR TEMPERATURE CIRCUIT LOW INPUT»(ref-208371-S13894187182005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 870

Scheme 870: WIRING DIAGRAM

Scheme 871

Scheme 871: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0113: INTAKE AIR TEMPERATURE CIRCUIT HIGH INPUT»(ref-208371-S39470706892005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 872

Scheme 872: WIRING DIAGRAM

Scheme 873

Scheme 873: DIAGNOSTIC PROCEDURE

Scheme 874

Scheme 874
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0117: ENGINE COOLANT TEMPERATURE CIRCUIT LOW INPUT»(ref-208371-S13098470562005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Hard to start
  2. Erroneous idling
  3. Poor driving performance
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 875

Scheme 875: WIRING DIAGRAM

Scheme 876

Scheme 876: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0118: ENGINE COOLANT TEMPERATURE CIRCUIT HIGH INPUT»(ref-208371-S07230283192005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Hard to start
  2. Erroneous idling
  3. Poor driving performance
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 877

Scheme 877: WIRING DIAGRAM

Scheme 878

Scheme 878: DIAGNOSTIC PROCEDURE

Scheme 879

Scheme 879
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0122: THROTTLE/PEDAL POSITION SENSOR/SWITCH "A" CIRCUIT LOW INPUT»(ref-208371-S10223292102005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Engine stalls.
  3. Poor driving performance

Scheme 880

Scheme 880: WIRING DIAGRAM

Scheme 881

Scheme 881: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0123: THROTTLE/PEDAL POSITION SENSOR/SWITCH "A" CIRCUIT HIGH INPUT»(ref-208371-S31641950672005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Engine stalls.
  3. Poor driving performance

Scheme 882

Scheme 882: WIRING DIAGRAM

Scheme 883

Scheme 883: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0125: INSUFFICIENT COOLANT TEMPERATURE FOR CLOSED LOOP FUEL CONTROL»(ref-208371-S15150297032005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Engine would not return to idling.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 884

Scheme 884: WIRING DIAGRAM

Scheme 885

Scheme 885: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0128: COOLANT THERMOSTAT (COOLANT TEMPERATURE BELOW THERMOSTAT REGULATING TEMPERATURE)»(ref-208371-S40526827512005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Thermostat remains open.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 886

Scheme 886: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0129: BAROMETRIC PRESSURE TOO LOW»(ref-208371-S38120713102005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 887

Scheme 887: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0131: O 2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 1)»(ref-208371-S34381153542005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 888

Scheme 888: WIRING DIAGRAM

Scheme 889

Scheme 889: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0132: O 2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 1 SENSOR 1)»(ref-208371-S29432622512005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 890

Scheme 890: WIRING DIAGRAM

Scheme 891

Scheme 891: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0133: O 2 SENSOR CIRCUIT SLOW RESPONSE (BANK 1 SENSOR 1)»(ref-208371-S06467323822005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) .

Scheme 892

Scheme 892: WIRING DIAGRAM

Scheme 893

Scheme 893: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0134: O 2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 1 SENSOR 1)»(ref-208371-S04359777312005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 894

Scheme 894: WIRING DIAGRAM

Scheme 895

Scheme 895: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0137: O 2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 2)»(ref-208371-S02849760912005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 896

Scheme 896: WIRING DIAGRAM

Scheme 897

Scheme 897: DIAGNOSTIC PROCEDURE

Scheme 898

Scheme 898
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0138: O 2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 1 SENSOR 2)»(ref-208371-S14287571812005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 899

Scheme 899: WIRING DIAGRAM

Scheme 900

Scheme 900: DIAGNOSTIC PROCEDURE

Scheme 901

Scheme 901
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0139: O 2 SENSOR CIRCUIT SLOW RESPONSE (BANK 1 SENSOR 2)»(ref-208371-S01340033872005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 902

Scheme 902: WIRING DIAGRAM

Scheme 903

Scheme 903: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0143: O 2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 3)»(ref-208371-S39511380142005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 904

Scheme 904: WIRING DIAGRAM

Scheme 905

Scheme 905: DIAGNOSTIC PROCEDURE

Scheme 906

Scheme 906
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0144: O 2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 1 SENSOR 3)»(ref-208371-S20398485172005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 907

Scheme 907: WIRING DIAGRAM

Scheme 908

Scheme 908: DIAGNOSTIC PROCEDURE

Scheme 909

Scheme 909
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0151: O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 2 SENSOR 1)»(ref-208371-S16928857812005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 910

Scheme 910: WIRING DIAGRAM

Scheme 911

Scheme 911: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0152: O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 2 SENSOR 1)»(ref-208371-S15424229402005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 912

Scheme 912: WIRING DIAGRAM

Scheme 913

Scheme 913: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0153: O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 2 SENSOR 1)»(ref-208371-S42140031172005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 914

Scheme 914: WIRING DIAGRAM

Scheme 915

Scheme 915: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0154: O2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 2 SENSOR 1)»(ref-208371-S18453387482005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 916

Scheme 916: WIRING DIAGRAM

Scheme 917

Scheme 917: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0157: O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 2 SENSOR 2)»(ref-208371-S10036523722005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 918

Scheme 918: WIRING DIAGRAM

Scheme 919

Scheme 919: DIAGNOSTIC PROCEDURE

Scheme 920

Scheme 920
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0158: O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 2 SENSOR 2)»(ref-208371-S08886178462005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 921

Scheme 921: WIRING DIAGRAM

Scheme 922

Scheme 922: DIAGNOSTIC PROCEDURE

Scheme 923

Scheme 923
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0159: O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 2 SENSOR 2)»(ref-208371-S01062140862005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 924

Scheme 924: WIRING DIAGRAM

Scheme 925

Scheme 925: DIAGNOSTIC PROCEDURE

DIAGNOSTIC PROCEDURE

Refer to DTC P0175: SYSTEM TOO RICH (BANK 2) , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

Refer to DTC P0175: SYSTEM TOO RICH (BANK 2) , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

Refer to DTC P0175: SYSTEM TOO RICH (BANK 2) , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0171: SYSTEM TOO LEAN (BANK 1)»(ref-208371-S19017457432005120700000) and «DTC P0172: SYSTEM TOO RICH (BANK 1)»(ref-208371-S09242146602005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. Refer to «DTC P0174: SYSTEM TOO LEAN (BANK 2)»(ref-208371-S40124724292005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria and «DTC P0175: SYSTEM TOO RICH (BANK 2)»(ref-208371-S27502810892005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Engine stalls.
  3. Poor driving performance
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 926

Scheme 926: WIRING DIAGRAM

Scheme 927

Scheme 927: DIAGNOSTIC PROCEDURE

Scheme 928

Scheme 928
  1. DTC DETECTING CONDITION: Fault occurs in two consecutive driving cycles GENERAL DESCRIPTION < Refer to «DTC P0181: FUEL TEMPERATURE SENSOR "A" CIRCUIT RANGE/PERFORMANCE»(ref-208371-S35552735782005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 929

Scheme 929: WIRING DIAGRAM

Scheme 930

Scheme 930: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0182: FUEL TEMPERATURE SENSOR "A" CIRCUIT LOW INPUT»(ref-208371-S20866475812005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 931

Scheme 931: WIRING DIAGRAM

Scheme 932

Scheme 932: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0183: FUEL TEMPERATURE SENSOR "A" CIRCUIT HIGH INPUT»(ref-208371-S10867812352005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 933

Scheme 933: WIRING DIAGRAM

Scheme 934

Scheme 934: DIAGNOSTIC PROCEDURE

Scheme 935

Scheme 935
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0222: THROTTLE/PEDAL POSITION SENSOR/SWITCH "B" CIRCUIT LOW INPUT»(ref-208371-S12444205282005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance
  3. Engine stalls.

Scheme 936

Scheme 936: WIRING DIAGRAM

Scheme 937

Scheme 937: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0223: THROTTLE/PEDAL POSITION SENSOR/SWITCH "B" CIRCUIT HIGH INPUT»(ref-208371-S17453486782005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance
  3. Engine stalls.

Scheme 938

Scheme 938: WIRING DIAGRAM

Scheme 939

Scheme 939: DIAGNOSTIC PROCEDURE

Note. For the diagnostic procedure, refer to DTC P0304: CYLINDER 4 MISFIRE DETECTED , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

Note. For the diagnostic procedure, refer to DTC P0304: CYLINDER 4 MISFIRE DETECTED , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

Note. For the diagnostic procedure, refer to DTC P0304: CYLINDER 4 MISFIRE DETECTED , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault Immediately at fault recognition (A misfire which could damage catalyst occurs.) GENERAL DESCRIPTION < Refer to «DTC P0304: CYLINDER 4 MISFIRE DETECTED»(ref-208371-S11471628272005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Engine stalls.
  2. Erroneous idling
  3. Rough driving
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 940

Scheme 940: WIRING DIAGRAM

Scheme 941

Scheme 941: DIAGNOSTIC PROCEDURE

Scheme 942

Scheme 942

Scheme 943

Scheme 943

Scheme 944

Scheme 944

Scheme 945

Scheme 945

Scheme 946

Scheme 946
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0327: KNOCK SENSOR 1 CIRCUIT LOW INPUT (BANK 1 OR SINGLE SENSOR)»(ref-208371-S37151575752005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Poor driving performance
  2. Knocking occurs.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 947

Scheme 947: WIRING DIAGRAM

Scheme 948

Scheme 948: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0328: KNOCK SENSOR 1 CIRCUIT HIGH INPUT (BANK 1 OR SINGLE SENSOR)»(ref-208371-S26701696902005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Poor driving performance
  2. Knocking occurs.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 949

Scheme 949: WIRING DIAGRAM

Scheme 950

Scheme 950: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0335: CRANKSHAFT POSITION SENSOR "A" CIRCUIT»(ref-208371-S29706057782005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Engine stalls.
  2. Failure of engine to start
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to CLEAR MEMORY MODE .

Scheme 951

Scheme 951: WIRING DIAGRAM

Scheme 952

Scheme 952: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0336: CRANKSHAFT POSITION SENSOR "A" CIRCUIT RANGE/PERFORMANCE»(ref-208371-S41041432472005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.>
  1. Engine stalls.
  2. Failure of engine to start
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 953

Scheme 953: WIRING DIAGRAM

Scheme 954

Scheme 954: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0340: CAMSHAFT POSITION SENSOR "A" CIRCUIT (BANK 1 OR SINGLE SENSOR)»(ref-208371-S03424403492005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Engine stalls.
  2. Failure of engine to start
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 955

Scheme 955: WIRING DIAGRAM

Scheme 956

Scheme 956: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0341: CAMSHAFT POSITION SENSOR "A" CIRCUIT RANGE/PERFORMANCE (BANK 1 OR SINGLE SENSOR)»(ref-208371-S41239416092005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Engine stalls.
  2. Failure of engine to start
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 957

Scheme 957: WIRING DIAGRAM

Scheme 958

Scheme 958: DIAGNOSTIC PROCEDURE

Scheme 959

Scheme 959
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0400: EXHAUST GAS RECIRCULATION FLOW»(ref-208371-S09731970912005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Poor driving performance at low engine speed
  2. Faulty idling
  3. Poor driving performance
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 960

Scheme 960: WIRING DIAGRAM

Scheme 961

Scheme 961: DIAGNOSTIC PROCEDURE

Scheme 962

Scheme 962
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0420: CATALYST SYSTEM EFFICIENCY BELOW THRESHOLD (BANK 1)»(ref-208371-S42611623412005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Engine stalls.
  2. Idle mixture is out of specifications.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 963

Scheme 963: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0442: EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (SMALL LEAK)»(ref-208371-S27746572172005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Fuel odor
  2. There is a hole of more than 1.0 mm (0.04 in) dia. in evaporation system or fuel tank.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 964

Scheme 964: WIRING DIAGRAM

Scheme 965

Scheme 965: DIAGNOSTIC PROCEDURE

Scheme 966

Scheme 966
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0447: EVAPORATIVE EMISSION CONTROL SYSTEM VENT CONTROL CIRCUIT OPEN»(ref-208371-S09982751292005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 967

Scheme 967: WIRING DIAGRAM

Scheme 968

Scheme 968: DIAGNOSTIC PROCEDURE

Scheme 969

Scheme 969
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0448: EVAPORATIVE EMISSION CONTROL SYSTEM VENT CONTROL CIRCUIT SHORTED»(ref-208371-S23749134672005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 970

Scheme 970: WIRING DIAGRAM

Scheme 971

Scheme 971: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0451: EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR RANGE/PERFORMANCE»(ref-208371-S39238659612005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 972

Scheme 972: WIRING DIAGRAM

Scheme 973

Scheme 973: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0452: EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR LOW INPUT»(ref-208371-S11595871152005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 974

Scheme 974: WIRING DIAGRAM

Scheme 975

Scheme 975: DIAGNOSTIC PROCEDURE

Scheme 976

Scheme 976
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0453: EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR HIGH INPUT»(ref-208371-S31857898212005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 977

Scheme 977: WIRING DIAGRAM

Scheme 978

Scheme 978: DIAGNOSTIC PROCEDURE

Scheme 979

Scheme 979
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0456: EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (VERY SMALL LEAK)»(ref-208371-S24427448172005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Fuel odor
  2. There is a hole of more than 0.5 mm (0.020 in) dia. in evaporation system or fuel tank.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 980

Scheme 980: WIRING DIAGRAM

Scheme 981

Scheme 981: DIAGNOSTIC PROCEDURE

Scheme 982

Scheme 982
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0457: EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (FUEL CAP LOOSE/OFF)»(ref-208371-S00467922902005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Fuel odor
  2. Fuel filler cap is loose or not installed.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 983

Scheme 983: WIRING DIAGRAM

Scheme 984

Scheme 984: DIAGNOSTIC PROCEDURE

Scheme 985

Scheme 985
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0458: EVAPORATIVE EMISSION CONTROL SYSTEM PURGE CONTROL VALVE CIRCUIT LOW»(ref-208371-S38224587462005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 986

Scheme 986: WIRING DIAGRAM

Scheme 987

Scheme 987: DIAGNOSTIC PROCEDURE

Scheme 988

Scheme 988
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0459: EVAPORATIVE EMISSION CONTROL SYSTEM PURGE CONTROL VALVE CIRCUIT HIGH»(ref-208371-S28159742942005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 989

Scheme 989: WIRING DIAGRAM

Scheme 990

Scheme 990: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0461: FUEL LEVEL SENSOR CIRCUIT RANGE/PERFORMANCE»(ref-208371-S40084535642005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 991

Scheme 991: WIRING DIAGRAM

Scheme 992

Scheme 992: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0462: FUEL LEVEL SENSOR CIRCUIT LOW INPUT»(ref-208371-S09584580382005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 993

Scheme 993: WIRING DIAGRAM

Scheme 994

Scheme 994: DIAGNOSTIC PROCEDURE

Scheme 995

Scheme 995
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0463: FUEL LEVEL SENSOR CIRCUIT HIGH INPUT»(ref-208371-S10631110562005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 996

Scheme 996: WIRING DIAGRAM

Scheme 997

Scheme 997: DIAGNOSTIC PROCEDURE

Scheme 998

Scheme 998
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0464: FUEL LEVEL SENSOR CIRCUIT INTERMITTENT»(ref-208371-S28456774202005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 999

Scheme 999: WIRING DIAGRAM

Scheme 1000

Scheme 1000: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITON: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0483: COOLING FAN RATIONALITY CHECK»(ref-208371-S31745670352005120700000) .
  1. Occurrence of noise
  2. Overheating
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Note. If the vehicle, with the engine idling, is placed very close to a wall or another vehicle, preventing normal cooling function, the OBD system may detect malfunction.

Scheme 1001

Scheme 1001: WIRING DIAGRAM

Scheme 1002

Scheme 1002: DIAGNOSTIC PROCEDURE

Note. For the diagnostic procedure, refer to DTC P0503: VEHICLE SPEED SENSOR INTERMITTENT/ERRATIC/HIGH , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0502: VEHICLE SPEED SENSOR CIRCUIT LOW INPUT»(ref-208371-S31717383692005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria and «DTC P0503: VEHICLE SPEED SENSOR INTERMITTENT/ERRATIC/HIGH»(ref-208371-S41683843392005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1003

Scheme 1003: WIRING DIAGRAM

Scheme 1004

Scheme 1004: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0506: IDLE CONTROL SYSTEM RPM LOWER THAN EXPECTED»(ref-208371-S33228041262005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Engine is difficult to start.
  2. Engine does not start.
  3. Erroneous idling
  4. Engine stalls.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1005

Scheme 1005: WIRING DIAGRAM

Scheme 1006

Scheme 1006: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0507: IDLE CONTROL SYSTEM RPM HIGHER THAN EXPECTED»(ref-208371-S24420309212005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Engine keeps running at higher revolution than specified idling revolution.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1007

Scheme 1007: WIRING DIAGRAM

Scheme 1008

Scheme 1008: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0512: STARTER REQUEST CIRCUIT»(ref-208371-S10997960702005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Failure of engine to start
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1009

Scheme 1009: MT Model

Scheme 1010

Scheme 1010: AT Model

Scheme 1011

Scheme 1011: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0519: IDLE CONTROL SYSTEM MALFUNCTION (FAIL-SAFE)»(ref-208371-S36331110712005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Engine keeps running at higher revolution than specified idling revolution.
  2. Fuel is cut according to fail-safe function.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1012

Scheme 1012: WIRING DIAGRAM

Scheme 1013

Scheme 1013: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0600: CAN COMMUNICATION CIRCUIT»(ref-208371-S40839695942005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1014

Scheme 1014: WIRING DIAGRAM

Scheme 1015

Scheme 1015: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0604: INTERNAL CONTROL MODULE RANDOM ACCESS MEMORY (RAM) ERROR»(ref-208371-S28463491872005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Engine does not start.
  2. Engine stalls.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1016

Scheme 1016: WIRING DIAGRAM

Scheme 1017

Scheme 1017: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0605: INTERNAL CONTROL MODULE READ ONLY MEMORY (ROM) ERROR»(ref-208371-S42627133212005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria and «DTC P0607: CONTROL MODULE PERFORMANCE»(ref-208371-S07944684262005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1018

Scheme 1018: WIRING DIAGRAM

Scheme 1019

Scheme 1019: DIAGNOSTIC PROCEDURE

Note. For the diagnostic procedure, refer to DTC P2101: THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT RANGE/PERFORMANCE , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0691: COOLING FAN 1 CONTROL CIRCUIT LOW»(ref-208371-S35750535362005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Radiator fan does not operate properly.
  2. Overheating
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1020

Scheme 1020: WIRING DIAGRAM

Scheme 1021

Scheme 1021: DIAGNOSTIC PROCEDURE

Scheme 1022

Scheme 1022
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0692: COOLING FAN 1 CONTROL CIRCUIT HIGH»(ref-208371-S31381042912005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Radiator fan does not operate properly.
  2. Overheating
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1023

Scheme 1023: WIRING DIAGRAM

Scheme 1024

Scheme 1024: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0703: TORQUE CONVERTER/BRAKE SWITCH "B" CIRCUIT»(ref-208371-S15681848712005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1025

Scheme 1025: WIRING DIAGRAM

Scheme 1026

Scheme 1026: DIAGNOSTIC PROCEDURE
  1. GENERAL DESCRIPTION < Refer to «DTC P0705: TRANSMISSION RANGE SENSOR CIRCUIT (PRNDL INPUT)»(ref-208371-S20995482632005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. Refer to CHECK INHIBITOR SWITCH , Diagnostic Procedure without Diagnostic Trouble Code (DTC).

  1. GENERAL DESCRIPTION < Refer to «DTC P0710: TRANSMISSION FLUID TEMPERATURE SENSOR CIRCUIT»(ref-208371-S38288226872005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. Refer to DTC 27 ATF TEMPERATURE SENSOR , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. GENERAL DESCRIPTION < Refer to «DTC P0716: INPUT/TURBINE SPEED SENSOR CIRCUIT RANGE/PERFORMANCE»(ref-208371-S17118843062005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. Refer to DTC 36 TORQUE CONVERTER TURBINE SPEED SENSOR , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. GENERAL DESCRIPTION < Refer to «DTC P0720: OUTPUT SPEED SENSOR CIRCUIT»(ref-208371-S09767766672005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. Refer to DTC 33 FRONT VEHICLE SPEED SENSOR , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. GENERAL DESCRIPTION < Refer to «DTC P0726: ENGINE SPEED INPUT CIRCUIT RANGE/PERFORMANCE»(ref-208371-S18392617052005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. Refer to DTC 11 ENGINE SPEED SIGNAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. For the diagnostic procedure, refer to DTC P0734: GEAR 4 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

Note. For the diagnostic procedure, refer to DTC P0734: GEAR 4 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

Note. For the diagnostic procedure, refer to DTC P0734: GEAR 4 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0731: GEAR 1 INCORRECT RATIO»(ref-208371-S36524805962005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria and «DTC P0731: GEAR 1 INCORRECT RATIO»(ref-208371-S36524805962005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. Refer to «DTC P0732: GEAR 2 INCORRECT RATIO»(ref-208371-S19420765672005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria and «DTC P0733: GEAR 3 INCORRECT RATIO»(ref-208371-S16842955472005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Shift point too high or too low; engine brake not effected in "3" range; excessive shift shock; excessive tight corner "braking"
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1027

Scheme 1027: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0741: TORQUE CONVERTER CLUTCH CIRCUIT PERFORMANCE OR STUCK OFF»(ref-208371-S14065950662005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. No lock-up (after engine warm-up)
  2. No shift or excessive tight corner "braking"
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1028

Scheme 1028: DIAGNOSTIC PROCEDURE

Scheme 1029

Scheme 1029
  1. GENERAL DESCRIPTION < Refer to «DTC P0743: TORQUE CONVERTER CLUTCH CIRCUIT ELECTRICAL»(ref-208371-S14700738782005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. Refer to DTC 77 LOCK-UP DUTY SOLENOID , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. GENERAL DESCRIPTION < Refer to «DTC P0748: PRESSURE CONTROL SOLENOID "A" ELECTRICAL»(ref-208371-S13569088942005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. Refer to DTC 75 LINE PRESSURE DUTY SOLENOID , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. GENERAL DESCRIPTION < Refer to «DTC P0753: SHIFT SOLENOID "A" ELECTRICAL»(ref-208371-S08075513082005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. Refer to DTC 71 SHIFT SOLENOID 1 , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. GENERAL DESCRIPTION < Refer to «DTC P0771: SHIFT SOLENOID "E" PERFORMANCE OR STUCK OFF»(ref-208371-S38310562522005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. Refer to DTC 72 SHIFT SOLENOID 2 , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. GENERAL DESCRIPTION < Refer to «DTC P0771: SHIFT SOLENOID "E" PERFORMANCE OR STUCK OFF»(ref-208371-S38310562522005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. Refer to DTC 73 LOW CLUTCH TIMING SOLENOID , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. GENERAL DESCRIPTION < Refer to «DTC P0778: PRESSURE CONTROL SOLENOID "B" ELECTRICAL»(ref-208371-S40446176212005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. Refer to DTC 76 2-4 BRAKE DUTY SOLENOID , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. GENERAL DESCRIPTION < Refer to «DTC P0785: SHIFT/TIMING SOLENOID»(ref-208371-S37494209592005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. Refer to DTC 74 2-4 BRAKE TIMING SOLENOID , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0851: NEUTRAL SWITCH INPUT CIRCUIT LOW (AT MODEL)»(ref-208371-S32617989142005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1030

Scheme 1030: WIRING DIAGRAM

Scheme 1031

Scheme 1031: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0851: NEUTRAL SWITCH INPUT CIRCUIT LOW (MT MODEL)»(ref-208371-S08642547222005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1032

Scheme 1032: WIRING DIAGRAM

Scheme 1033

Scheme 1033: DIAGNOSTIC PROCEDURE

Scheme 1034

Scheme 1034
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0852: NEUTRAL SWITCH INPUT CIRCUIT HIGH (AT MODEL)»(ref-208371-S34010390982005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1035

Scheme 1035: WIRING DIAGRAM

Scheme 1036

Scheme 1036: DIAGNOSTIC PROCEDURE

Scheme 1037

Scheme 1037
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0852: NEUTRAL SWITCH INPUT CIRCUIT HIGH (MT MODEL)»(ref-208371-S26498272432005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1038

Scheme 1038: WIRING DIAGRAM

Scheme 1039

Scheme 1039: DIAGNOSTIC PROCEDURE

Scheme 1040

Scheme 1040
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0864: TCM COMMUNICATION CIRCUIT RANGE/PERFORMANCE»(ref-208371-S39534902332005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1041

Scheme 1041: WIRING DIAGRAM

Scheme 1042

Scheme 1042: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0865: TCM COMMUNICATION CIRCUIT LOW»(ref-208371-S01490581862005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1043

Scheme 1043: WIRING DIAGRAM

Scheme 1044

Scheme 1044: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P0866: TCM COMMUNICATION CIRCUIT HIGH»(ref-208371-S27774714022005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1045

Scheme 1045: WIRING DIAGRAM

Scheme 1046

Scheme 1046: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P1088: TUMBLE GENERATED VALVE POSITION SENSOR 1 CIRCUIT LOW»(ref-208371-S08505630682005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Engine stalls.
  3. Poor driving performance
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1047

Scheme 1047: WIRING DIAGRAM

Scheme 1048

Scheme 1048: DIAGNOSTIC PROCEDURE

Scheme 1049

Scheme 1049
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P1089: TUMBLE GENERATED VALVE POSITION SENSOR 1 CIRCUIT HIGH»(ref-208371-S18819440732005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Engine stalls.
  3. Poor driving performance
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1050

Scheme 1050: WIRING DIAGRAM

Scheme 1051

Scheme 1051: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P1090: TUMBLE GENERATED VALVE SYSTEM 1 (VALVE OPEN)»(ref-208371-S37235320792005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1052

Scheme 1052: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P1091: TUMBLE GENERATED VALVE SYSTEM 1 (VALVE CLOSE)»(ref-208371-S41922999392005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1053

Scheme 1053: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P1094: TUMBLE GENERATED VALVE SIGNAL 1 CIRCUIT MALFUNCTION (OPEN)»(ref-208371-S34331221682005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1054

Scheme 1054: WIRING DIAGRAM

Scheme 1055

Scheme 1055: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P1095: TUMBLE GENERATED VALVE SIGNAL 1 CIRCUIT MALFUNCTION (SHORT)»(ref-208371-S40571409982005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1056

Scheme 1056: WIRING DIAGRAM

Scheme 1057

Scheme 1057: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P1110: ATMOSPHERIC PRESSURE SENSOR CIRCUIT MALFUNCTION (LOW INPUT)»(ref-208371-S23111289572005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1058

Scheme 1058: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P1111: ATMOSPHERIC PRESSURE SENSOR CIRCUIT MALFUNCTION (HIGH INPUT)»(ref-208371-S14059065532005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1059

Scheme 1059: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P1152: O 2 SENSOR CIRCUIT RANGE/PERFORMANCE (LOW) (BANK 1 SENSOR 1)»(ref-208371-S19146189032005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1060

Scheme 1060: WIRING DIAGRAM

Scheme 1061

Scheme 1061: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P1153: O 2 SENSOR CIRCUIT RANGE/PERFORMANCE (HIGH) (BANK 1 SENSOR 1)»(ref-208371-S16311438522005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1062

Scheme 1062: WIRING DIAGRAM

Scheme 1063

Scheme 1063: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P1154: O 2 SENSOR CIRCUIT RANGE/PERFORMANCE (LOW) (BANK 2 SENSOR 1)»(ref-208371-S06440574552005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1064

Scheme 1064: WIRING DIAGRAM

Scheme 1065

Scheme 1065: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P1155: O 2 SENSOR CIRCUIT RANGE/PERFORMANCE (HIGH) (BANK 2 SENSOR 1)»(ref-208371-S20105264592005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1066

Scheme 1066: WIRING DIAGRAM

Scheme 1067

Scheme 1067: DIAGNOSTIC PROCEDURE

Note. For the diagnostic procedure, refer to DTC P2101: THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT RANGE/PERFORMANCE , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P1400: FUEL TANK PRESSURE CONTROL SOLENOID VALVE CIRCUIT LOW»(ref-208371-S13386647372005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1068

Scheme 1068: WIRING DIAGRAM

Scheme 1069

Scheme 1069: DIAGNOSTIC PROCEDURE

Scheme 1070

Scheme 1070
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P1420: FUEL TANK PRESSURE CONTROL SOL. VALVE CIRCUIT HIGH»(ref-208371-S42370907962005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1071

Scheme 1071: WIRING DIAGRAM

Scheme 1072

Scheme 1072: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P1443: VENT CONTROL SOLENOID VALVE FUNCTION PROBLEM»(ref-208371-S41591781572005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Improper fuel supply
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1073

Scheme 1073: WIRING DIAGRAM

Scheme 1074

Scheme 1074: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P1446: FUEL TANK SENSOR CONTROL VALVE CIRCUIT LOW»(ref-208371-S36928357332005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1075

Scheme 1075: WIRING DIAGRAM

Scheme 1076

Scheme 1076: DIAGNOSTIC PROCEDURE

Scheme 1077

Scheme 1077
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P1447: FUEL TANK SENSOR CONTROL VALVE CIRCUIT HIGH»(ref-208371-S38660754052005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1078

Scheme 1078: WIRING DIAGRAM

Scheme 1079

Scheme 1079: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P1448: FUEL TANK SENSOR CONTROL VALVE RANGE PERFORMANCE»(ref-208371-S09025574472005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1080

Scheme 1080: WIRING DIAGRAM

Scheme 1081

Scheme 1081: DIAGNOSTIC PROCEDURE

Note. Refer to DTC P1498: EGR SOLENOID VALVE SIGNAL # 4 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

Note. Refer to DTC P1499: EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

Note. Refer to DTC P1498: EGR SOLENOID VALVE SIGNAL # 4 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

Note. Refer to DTC P1499: EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

Note. Refer to DTC P1498: EGR SOLENOID VALVE SIGNAL # 4 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

Note. Refer to DTC P1499: EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. DTC DETECTING CONDITION: Immediately at fault recognition. GENERAL DESCRIPTION < Refer to «DTC P1492: EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (LOW INPUT)»(ref-208371-S04052046052005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria and «DTC P1494: EGR SOLENOID VALVE SIGNAL #2 CIRCUIT MALFUNCTION (LOW INPUT)»(ref-208371-S07945889232005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. Refer to «DTC P1496: EGR SOLENOID VALVE SIGNAL #3 CIRCUIT MALFUNCTION (LOW INPUT)»(ref-208371-S09933047732005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. and «DTC P1498: EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (LOW INPUT)»(ref-208371-S17855960732005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance
  3. Engine breathing CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1082

Scheme 1082: WIRING DIAGRAM

Scheme 1083

Scheme 1083: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition. GENERAL DESCRIPTION < Refer to «DTC P1493: EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (HIGH INPUT)»(ref-208371-S38140736792005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria and «DTC P1495: EGR SOLENOID VALVE SIGNAL #2 CIRCUIT MALFUNCTION (HIGH INPUT)»(ref-208371-S38451255762005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. Refer to «DTC P1497: EGR SOLENOID VALVE SIGNAL #3 CIRCUIT MALFUNCTION (HIGH INPUT)»(ref-208371-S25099672912005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria and «DTC P1499: EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (HIGH INPUT)»(ref-208371-S01556304502005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance
  3. Engine breathing CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1084

Scheme 1084: WIRING DIAGRAM

Scheme 1085

Scheme 1085: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P1518: STARTER SWITCH CIRCUIT LOW INPUT»(ref-208371-S03463354832005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Failure of engine to start
CAUTIONAfter repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to CLEAR MEMORY MODE and Inspection Mode. Refer to INSPECTION MODE .

Scheme 1086

Scheme 1086: MT Model

Scheme 1087

Scheme 1087: AT Model

Scheme 1088

Scheme 1088: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P1560: BACK-UP VOLTAGE CIRCUIT MALFUNCTION»(ref-208371-S42464312522005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1089

Scheme 1089: WIRING DIAGRAM

Scheme 1090

Scheme 1090: DIAGNOSTIC PROCEDURE
  1. GENERAL DESCRIPTION < Refer to «DTC P1700: THROTTLE POSITION SENSOR CIRCUIT MALFUNCTION FOR AT»(ref-208371-S04022131622005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Note. Refer to DTC 31 THROTTLE POSITION SENSOR , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P2096: POST CATALYST FUEL TRIM SYSTEM TOO LEAN BANK 1»(ref-208371-S29206372442005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1091

Scheme 1091: WIRING DIAGRAM

Scheme 1092

Scheme 1092: DIAGNOSTIC PROCEDURE

Scheme 1093

Scheme 1093

Scheme 1094

Scheme 1094

Scheme 1095

Scheme 1095
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P2097: POST CATALYST FUEL TRIM SYSTEM TOO RICH BANK 1»(ref-208371-S33443382012005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1096

Scheme 1096: WIRING DIAGRAM

Scheme 1097

Scheme 1097: DIAGNOSTIC PROCEDURE

Scheme 1098

Scheme 1098

Scheme 1099

Scheme 1099

Scheme 1100

Scheme 1100
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P2098: POST CATALYST FUEL TRIM SYSTEM TOO LEAN BANK 2»(ref-208371-S23167221442005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1101

Scheme 1101: WIRING DIAGRAM

Scheme 1102

Scheme 1102: DIAGNOSTIC PROCEDURE

Scheme 1103

Scheme 1103

Scheme 1104

Scheme 1104

Scheme 1105

Scheme 1105
  1. DTC DETECTING CONDITION: Two consecutive driving cycles with fault GENERAL DESCRIPTION < Refer to «DTC P2099: POST CATALYST FUEL TRIM SYSTEM TOO RICH BANK 2»(ref-208371-S30706585732005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «INSPECTION MODE»(ref-208370-S02823930812005120700000) .

Scheme 1106

Scheme 1106: WIRING DIAGRAM

Scheme 1107

Scheme 1107: DIAGNOSTIC PROCEDURE

Scheme 1108

Scheme 1108

Scheme 1109

Scheme 1109

Scheme 1110

Scheme 1110
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P0638: THROTTLE ACTUATOR CONTROL RANGE/PERFORMANCE (BANK 1)»(ref-208371-S41327501462005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria. Refer to «DTC P1160: RETURN SPRING FAILURE»(ref-208371-S41221279382005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria and «DTC P2109: THROTTLE/PEDAL POSITION SENSOR A MINIMUM STOP PERFORMANCE»(ref-208371-S13738862832005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance
  3. Engine stalls.

Scheme 1111

Scheme 1111: WIRING DIAGRAM

Scheme 1112

Scheme 1112: DIAGNOSTIC PROCEDURE

Scheme 1113

Scheme 1113

Scheme 1114

Scheme 1114

Scheme 1115

Scheme 1115
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P2102: THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT LOW»(ref-208371-S07152862912005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance
  3. Engine stalls.

Scheme 1116

Scheme 1116: WIRING DIAGRAM

Scheme 1117

Scheme 1117: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P2103: THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT HIGH»(ref-208371-S40750963412005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.

Scheme 1118

Scheme 1118: WIRING DIAGRAM

Scheme 1119

Scheme 1119: DIAGNOSTIC PROCEDURE

Note. For the diagnostic procedure, refer to DTC P2101: THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT RANGE/PERFORMANCE , Diagnostic Procedure with Diagnostic Trouble Code (DTC).

  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P2122: THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT LOW INPUT»(ref-208371-S29772920302005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance

Scheme 1120

Scheme 1120: WIRING DIAGRAM

Scheme 1121

Scheme 1121: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P2123: THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT HIGH INPUT»(ref-208371-S28855043542005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance

Scheme 1122

Scheme 1122: WIRING DIAGRAM

Scheme 1123

Scheme 1123: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P2127: THROTTLE/PEDAL POSITION SENSOR/SWITCH "E" CIRCUIT LOW INPUT»(ref-208371-S31250682212005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance

Scheme 1124

Scheme 1124: WIRING DIAGRAM

Scheme 1125

Scheme 1125: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P2128: THROTTLE/PEDAL POSITION SENSOR/SWITCH "E" CIRCUIT HIGH INPUT»(ref-208371-S14630100912005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance

Scheme 1126

Scheme 1126: WIRING DIAGRAM

Scheme 1127

Scheme 1127: DIAGNOSTIC PROCEDURE
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P2135: THROTTLE/PEDAL POSITION SENSOR/SWITCH "A" / "B" VOLTAGE RATIONALITY»(ref-208371-S31817797592005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance CAUTION: After repair or replacement of faulty parts, conduct Clear Memory Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) and Inspection Mode. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) .

Scheme 1128

Scheme 1128: WIRING DIAGRAM

Scheme 1129

Scheme 1129: DIAGNOSTIC PROCEDURE

Scheme 1130

Scheme 1130
  1. DTC DETECTING CONDITION: Immediately at fault recognition GENERAL DESCRIPTION < Refer to «DTC P2138: THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" / "E" VOLTAGE RATIONALITY»(ref-208371-S16392744902005120700000) , Diagnostic Trouble Code (DTC) Detecting Criteria.
  1. Erroneous idling
  2. Poor driving performance

Scheme 1131

Scheme 1131: WIRING DIAGRAM

Scheme 1132

Scheme 1132: DIAGNOSTIC PROCEDURE

Scheme 1133

Scheme 1133

Scheme 1134

Scheme 1134

Note. Malfunction of parts other than those listed is also possible. Refer to ENGINE TROUBLE IN GENERAL .

Scheme 1135

Scheme 1135: ENGINE

Scheme 1136

Scheme 1136
