Intake (Induction) (H6DO): Other Subaru Outback BP

CAUTION

1. Wear working clothing, including a cap, protective goggles, and protective shoes during operation.
2. Remove contamination including dirt and corrosion before removal, installation or diassembly.
3. Keep the disassembled parts in order and protect them from dust or dirt.
4. Before removal, installation or diassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly, and replacement.
5. Be careful not to burn your hands, because each part on the vehicle is hot after running.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or safety stands at the specified points.
8. Before disconnecting electrical connectors of sensor or units, be sure to disconnect ground cable from battery.

Scheme 288

Scheme 289

1. Loosen clamp (A), and separate air cleaner upper cover from air intake boot.
2. Remove the clip (B) above the air cleaner upper cover.
3. Remove air cleaner element.
4. Remove air cleaner lower case.

Scheme 290

Scheme 291

Scheme 292

1. Install the air cleaner lower case. Tightening torque: 33 N.m (3.4 kgf-m, 24.6 ft-lb)
2. Set the air cleaner element.
3. Install the air cleaner upper cover. NOTE: Before installing air cleaner upper cover, align holes with protruding portions of air cleaner lower case, then secure upper cover to lower case.
4. Install the clip (B) above the air cleaner upper cover.
5. Tighten clamp (A), and connect air intake boot and air cleaner upper cover.
