Engine Mechanical (H6DO): Removal & Installation Subaru Outback BP

REMOVAL

1. Remove engine assembly. Refer to 7 «ENGINE ASSEMBLY»(ref-208385-S40718943072005120700000) .
2. Remove engine mounting from engine assembly.

INSTALLATION

Install in the reverse order of removal.

Tightening torque

1. Engine mounting; 34 N.m (3.5 kgf-m, 25.3 ft-lb)

Scheme 429

Scheme 430

Scheme 431

Scheme 432

Scheme 433

Scheme 434

Scheme 435

Scheme 436

Scheme 437

Scheme 438

Scheme 439

Scheme 440

Scheme 441

Scheme 442

Scheme 443

Scheme 444

Scheme 445

Scheme 446

1. Preparation for installation of chain tensioner. Put the screw, spring, pin and tension rod into the tensioner body. While pressing tensioner onto rubber mat, twist it left and right to shorten tension rod. Then set a thin pin into the holes between tension rod and tensioner body to hold it. NOTE: Carry out the work on rubber mat or other nonslip material.
2. Using ST, align "top mark" on crankshaft sprocket at 9 o'clock position as shown in the figure. ST 18252AA000 CRANKSHAFT SOCKET
3. Using ST, align four key grooves on camshaft sprocket at 12 o'clock position as shown in the figure. ST 18231AA000 CAMSHAFT SPROCKET WRENCH
4. Rotate crankshaft sprocket clockwise to align "top mark" at 12 o'clock position as shown in the figure. (Piston # 1 is at TDC.) CAUTION: Do not rotate crankshaft and camshaft sprockets until timing chain is completely routed.
5. Install the idler sprocket. (Lower) Tightening torque: 69 N.m (7.0 kgf-m, 50.6 ft-lb)
6. Install timing chain LH. Align the timing mark (B) on crankshaft sprocket with the matching mark (A) on timing chain LH. Route timing chain LH on idler sprocket (Lower), water pump, exhaust cam sprocket, and intake cam sprocket in order. CAUTION: Make sure that matching marks on the timing chain (A) and camshaft sprocket (B) are aligned the same way as the one on crankshaft sprocket. Install chain idler. (Upper) Tightening torque: 69 N.m (7.0 kgf-m, 50.6 ft-lb) Install chain guide. (Left-hand between cams) Tightening torque: 6.3 N.m (0.64 kgf-m, 4.6 ft-lb) NOTE: Replace mounting bolt with a new one. Install chain guide (LH). Tightening torque: 16 N.m (1.6 kgf-m, 11.6 ft-lb) Install chain tensioner lever LH. Tightening torque: 16 N.m (1.6 kgf-m, 11.6 ft-lb) Install chain tensioner LH. Tightening torque: 16 N.m (1.6 kgf-m, 11.6 ft-lb)
7. Install timing chain RH. On idler sprocket (Lower), align matching marks on timing chains LH and RH. Route timing chain RH on intake cam sprocket and then exhaust cam sprocket. CAUTION: Make sure that matching marks on the timing chain (A) and camshaft sprocket (B) are aligned the same way as the one on crankshaft sprocket. Install chain guide (RH). Install chain tensioner lever (RH). Tightening torque: 16 N.m (1.6 kgf-m, 11.6 ft-lb) Install timing chain guide RH No. 1. Tightening torque: 6.3 N.m (0.64 kgf-m, 4.6 ft-lb) NOTE: Replace mounting bolt with a new one. Install the chain tensioner (RH). Tightening torque: 16 N.m (1.6 kgf-m, 11.6 ft-lb) Adjust the clearance between chain guide (RH) and chain guide (Center) to the range between 8.4 mm (0.331 in) to 8.6 mm (0.339 in). And install chain guide (Center). Tightening torque: 7.8 N.m (0.8 kgf-m, 5.8 ft-lb) NOTE: Replace mounting bolt with a new one. After checking the matching marks on each sprocket and corresponding timing chain are aligned, pull stopper pin out of chain tensioner.

Scheme 447

1. Remove crankshaft pulley. Refer to «CRANKSHAFT PULLEY»(ref-208385-S05331601292005120700000) .
2. Remove front chain cover. Refer to «FRONT CHAIN COVER»(ref-208385-S10361917952005120700000) .
3. Remove timing chain assembly. Refer to «TIMING CHAIN ASSEMBLY»(ref-208385-S22290053572005120700000) .
4. Remove camshaft sprocket. To lock camshaft, use ST. ST 18231AA000 CAMSHAFT SPROCKET WRENCH

Scheme 448

1. Install camshaft sprocket. To lock camshaft, use ST. ST 18231AA000 CAMSHAFT SPROCKET WRENCH Tightening torque: 13 N.m (1.0 kgf-m, 7.2 ft-lb)
2. Install timing chain assembly. Refer to «INSTALLATION»(ref-208385-S24492764732005120700000) , Timing Chain Assembly.
3. Install front chain cover. Refer to «FRONT CHAIN COVER»(ref-208385-S10361917952005120700000) .
4. Install crankshaft pulley. Refer to «CRANKSHAFT PULLEY»(ref-208385-S05331601292005120700000) .
