M/t Control Systems (Sti): Other Subaru Impreza GH

CAUTION

1. Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust and dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
5. Use SUBARU genuine fluid, grease etc. or equivalent. Do not mix fluid, grease, etc. of different grades or manufacturers.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or rigid racks at the specified points.
8. Apply grease onto sliding or revolving surfaces before installation.
9. Before installing O-rings or snap rings, apply sufficient amount of fluid to avoid damage and deformation.
10. Before securing a part in a vise, place cushioning material such as wood blocks, aluminum plate or cloth between the part and the vise.
11. Before disconnecting electrical connectors, be sure to disconnect the negative terminal from battery.

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. Set the vehicle on a lift.
2. Disconnect the ground cable from battery.
3. Remove the gear shift knob.
4. Remove the console box front. Ref. to «REMOVAL»(ref-357087-S02254754982010030800000) , Console Box.
5. Remove the clamp.
6. Remove the boot and insulator assembly.
7. Remove the harness clamp from the plate assembly.
8. Remove the plate assembly from the body.
9. Lift up the vehicle.
10. Remove the under cover.
11. Remove the rear exhaust pipe and muffler. Ref. to «REMOVAL»(ref-357090-S25330699942010030800000) , Rear Exhaust Pipe, and ref. to «REMOVAL»(ref-357090-S08053303402010030800000) , Muffler.
12. Remove the heat shield cover.
13. Remove the crossmember. Ref. to «REMOVAL»(ref-357103-S27833106852010030800000) , Transmission Mounting System.
14. Remove the snap pin and washer, and remove the reverse check cable from the reverse check lever.
15. Move the transmission to the right side, and remove the joint COMPL, stay bolts and reverse check cable. NOTE: If the transmission is not moved aside, the joint COMPL and stay bolts may contact the body and cause damage.
16. Remove the cushion rubber from the body.
17. Lower the vehicle.
18. Remove the gear shift lever.

Scheme 46

Scheme 47

Scheme 48

1. Insert the gear shift lever from the vehicle interior. NOTE: Insert the rod and the stay, and position the lever on top of the transmission mount.
2. Mount the cushion rubber on the body. Tightening torque: 18 Mm (1.8 kgf-m, 13.3 ft-lb)
3. Move the transmission to the right side of the vehicle, and install the joint COMPL and stay. Tightening torque: T1: 12 N.m (1.2 kgf-m, 8.9 ft-lb) T2: 32 N.m (3.3 kgf-m, 23.6 ft-lb)
4. Install the crossmember. Ref. to «INSTALLATION»(ref-357103-S07067463952010030800000) , Transmission Mounting System.
5. Install the reverse check cable end, washer and snap pin to the reverse check lever. NOTE: Be careful to install the snap pin in the proper direction. Adjust the reverse check cable before installation. ADJUSTMENT, Reverse Check Cable.>
6. Install the heat shield cover.
7. Install the rear exhaust pipe and muffler. Ref. to «INSTALLATION»(ref-357090-S14422312462010030800000) , Rear Exhaust Pipe, and ref. to «INSTALLATION»(ref-357090-S04010400282010030800000) , Muffler.
8. Install the under cover.
9. Install the boot plate. NOTE: Be careful not to twist the inner boot when installing. Tightening torque: 18 N.m (1.8 kgf-m, 13.3 ft-lb) Set the plate assembly to the vehicle. Temporarily tighten the bolt (A). Tighten the bolt (B). Tighten the bolt (A). Tighten the bolts (C) and (D).
10. Install the harness clamp to the plate assembly.
11. Install the boot and insulator assembly, and secure with a clamp.
12. Install the console box front. Ref. to «INSTALLATION»(ref-357087-S02480014952010030800000) , Console Box.
13. Check whether the gear shift shifts into each gear position.

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

1. Remove the spring pin from the slider.
2. Remove the slider and spring.
3. Cut off the band clip.
4. Remove the reverse check cable from the cable plate.
5. Remove the reverse check cable from the gear shift assembly.
6. Remove the holder and spring.
7. Disassemble the lock wire. NOTE: Do not reuse the lock wire.
8. Remove the boss from the rod.
9. Remove the rod from lever.
10. Separate the rod and inner boot.
11. Remove the snap ring from the stay.
12. Separate the gear shift lever and the stay.
13. Remove the O-ring and bushing from the gear shift lever.
14. Remove the spring pin, and then remove the bushing and snap ring.
15. Remove the bushing and spacer from the boss.
16. Remove the bushing and cushion rubber from the stay.
