SHIFT LOCK OPERATION
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK COMMUNICATION OF SUBARU SELECT MONITOR. Turn the ignition switch to ON. Using the Subaru Select Monitor, check whether communication to all systems can be executed normally. | Is the system name displayed? | Go to step 2. | Perform the inspection following the diagnostic procedure in the LAN article. Refer to BASIC DIAGNOSTIC PROCEDURE . |
| 2 CHECK SHIFT LOCK. Turn the ignition switch to ON. Shift the select lever to "P" range. | While brake pedal is not depressed, is it possible to move the select lever from the "P" range to other ranges? | Perform the inspection of "SELECT LEVER CANNOT BE LOCKED OR RELEASED". Refer to SELECT LEVER CANNOT BE LOCKED OR RELEASED , INSPECTION, AT Shift Lock Control System. | Go to step 3. |
| 3 CHECK SHIFT LOCK. | While brake pedal is depressed, is it possible to move the select lever from the "P" range to other ranges? | Go to step 4. | Perform the inspection of "SELECT LEVER CANNOT BE LOCKED OR RELEASED". Refer to SELECT LEVER CANNOT BE LOCKED OR RELEASED , INSPECTION, AT Shift Lock Control System. |
| 4 CHECK SHIFT LOCK. Shift the select lever to "N" range. | Is it possible to move the select lever from the "N" range to the "P" range? | Go to step 5. | Perform the inspection of "SELECT LEVER CANNOT BE LOCKED OR RELEASED". Refer to SELECT LEVER CANNOT BE LOCKED OR RELEASED , INSPECTION, AT Shift Lock Control System. |
| 5 CHECK SHIFT LOCK. Shift the select lever to "N" range. Turn the ignition switch to OFF. | While brake pedal is depressed, is it possible to move the select lever from the "N" range to the "P" range? | Go to step 6. | Perform the inspection of "SELECT LEVER CANNOT BE LOCKED OR RELEASED". Refer to SELECT LEVER CANNOT BE LOCKED OR RELEASED , INSPECTION, AT Shift Lock Control System. |
| 6 CHECK KEY INTERLOCK. Turn the ignition switch to OFF. Shift the select lever to other than "P" range. | Can the ignition key be removed? | Perform the inspection of "KEY INTERLOCK CANNOT BE LOCKED OR RELEASED". Refer to KEY INTERLOCK CANNOT BE LOCKED OR RELEASED , INSPECTION, AT Shift Lock Control System. | Go to step 7. |
| 7 CHECK KEY INTERLOCK. Shift the select lever to "P" range. | Can the ignition key be removed? | AT shift lock system is normal. | Perform the inspection of "KEY INTERLOCK CANNOT BE LOCKED OR RELEASED". Refer to KEY INTERLOCK CANNOT BE LOCKED OR RELEASED , INSPECTION, AT Shift Lock Control System. |
SHIFT LOCK OPERATION INSPECTION CHART
Scheme 66
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK DTC OF BODY INTEGRATED UNIT. Check DTC of body integrated unit. Refer to OPERATION , Subaru Select Monitor. | Is the DTC of power line displayed on body integrated unit? | Repair or replace it according to the DTC. | Go to step 2. |
| 2 CHECK HARNESS CONNECTOR BETWEEN BODY INTEGRATED UNIT AND CHASSIS GROUND. Turn the ignition switch to ON. Measure the voltage between body integrated unit and chassis ground. Connector & terminal (B280) No. 1 (+) - Chassis ground (-): (B280) No. 6 (+) - Chassis ground (-): (B280) No. 7 (+) - Chassis ground (-): (B279) No. 22 (+) - Chassis ground (-) | Is the voltage 9 - 16 V? | Go to step 3. | Check harness for open circuit between the body integrated unit and the battery or a blown fuse. |
| 3 CHECK HARNESS CONNECTOR BETWEEN BODY INTEGRATED UNIT AND CHASSIS GROUND. Turn the ignition switch to OFF. Measure the harness resistance between the body integrated unit and chassis ground. Connector & terminal (i84) No. 28 - Chassis ground: (B279) No. 27 - Chassis ground: (B280) No. 17 - Chassis ground: (B281) No. 20 - Chassis ground | Is the resistance less than 1 ohms? | Go to step 4. | Repair the open circuit of harness between the body integrated unit and chassis ground. |
| 4 CHECK POOR CONTACT. | Is there poor contact of connector? | Repair the poor contact. | Check body integrated unit. |
DIAGNOSTIC PROCEDURE
Scheme 67
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK BODY INTEGRATED UNIT POWER SUPPLY AND GROUND CIRCUIT. Refer to BODY INTEGRATED UNIT POWER SUPPLY AND GROUND CIRCUIT , INSPECTION, AT Shift Lock Control System. | Is there an abnormal condition? | Follow the procedures to perform inspection and repair. | Go to step 2. |
| 2 CHECK CURRENT DATA. Connect the Subaru Select Monitor. Shift the select lever to "P" range. Turn the ignition switch to ON. Display the current data display and display "P SW". Refer to OPERATION , Subaru Select Monitor. | Is the display "ON" in the P range and "OFF" in ranges other than P? | Go to step 3. | Go to step 8. |
| 3 CHECK CURRENT DATA. Display the current data display and display "Stop Light Switch". Refer to OPERATION , Subaru Select Monitor. | Is "ON" displayed when the brake pedal is depressed and "OFF" displayed when the brake pedal is released? | Go to step 4. | Go to step 11. |
| 4 CHECK BODY INTEGRATED UNIT DTC. Check the DTC of the body integrated unit when the brake pedal is pressed and when it is released. (Hold each condition for 5 seconds or more.) | Is there a DTC of a current malfunction? | Follow the DTC to perform inspection and repair. | Go to step 5. |
| 5 CHECK CURRENT DATA. Select the current data display and display "Shift Lock Solenoid". Refer to OPERATION , Subaru Select Monitor. | Is "ON" displayed when the brake pedal is depressed and "OFF" displayed when the brake pedal is released? | Go to step 6. | Replace the body integrated unit. |
| 6 CHECK CURRENT DATA. Select the current data display and display "Shift Position". Refer to OPERATION , Subaru Select Monitor. | Is the display "7" in the P range and other than "7" in ranges other than P? | Go to step 7. | Check the following items. Inhibitor switch Harness between inhibitor switch and TCM TCM input signal TCM CAN communication Body integrated unit CAN receive |
| 7 CHECK CURRENT DATA. Select the current data display and display "Front Wheel Speed". Refer to OPERATION , Subaru Select Monitor. Start the engine. Raise vehicle speed gradually up to approximately 20 km/h. | Is a figure equivalent to the speedometer being indicated? | Go to step 12. | Check the following items. Wheel speed sensor VDC/ABS CAN communication Body integrated unit CAN receive Replace the wheel speed sensor, VDC/ABS, or body integrated unit, or both. |
| 8 CHECK HARNESS BETWEEN BODY INTEGRATED UNIT AND "P" RANGE SWITCH. Disconnect the connector from body integrated unit. Disconnect the connector of "P" range switch. Check for open circuit of harness, short circuit to battery or short circuit to ground between the body integrated unit and "P" range switch. Connector & terminal (B281) No. 4 - (B117) No. 1 | Is the harness normal? | Go to step 9. | Repair or replace the harness between the body integrated unit and the "P" range switch. |
| 9 CHECK HARNESS BETWEEN "P" RANGE SWITCH AND CHASSIS GROUND. Measure the resistance of harness between "P" range switch and chassis ground. Connector & terminal (B117) No. 2 - Chassis ground | Is it less than 10 ohms? | Go to step 10. | Repair the harness between the "P" range switch and chassis ground. |
| 10 CHECK P RANGE SWITCH. Measure the resistance between "P" range switch connector terminals. Terminals No. 2 - No.1 | Is it less than 10 ohms in the "P" range, and 1 Mohms or more in ranges other than "P"? | Replace the body integrated unit. | Replace the P range switch. |
| 11 CHECK STOP LIGHT SWITCH INPUT SIGNAL. Disconnect the connector from body integrated unit. Measure the voltage between the body integrated unit connector terminal and chassis ground. Connector & terminal (B280) No. 2 (+) - Chassis ground (-) | Is the voltage 9 V or more when the brake pedal is depressed, and less than approximately 1.5 V when not pressed? | Replace the body integrated unit. | Check the stop light system. |
| 12 CHECK SHIFT LOCK SOLENOID OPERATION. Connect the battery to the shift lock solenoid unit connector terminal, and operate the solenoid. Terminals No.3 (+) - No.4 (-) | Does the shift lock solenoid operate normally? | Check the lock mechanism of the select lever body. | Replace the shift lock solenoid. |
DIAGNOSTIC PROCEDURE
Scheme 68
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK DELIVERY (TEST) MODE CONNECTOR. Check that the delivery (test) mode connector is disconnected. | Is the delivery (test) mode connector disconnected? | Go to step 2. | Disconnect the delivery (test) mode connector. |
| 2 CHECK BODY INTEGRATED UNIT POWER SUPPLY AND GROUND CIRCUIT. Refer to BODY INTEGRATED UNIT POWER SUPPLY AND GROUND CIRCUIT , INSPECTION, AT Shift Lock Control System. | Is there an abnormal condition? | Follow the procedures to inspect and repair. | Go to step 3. |
| 3 CHECK CURRENT DATA. Connect the Subaru Select Monitor. Shift the select lever to "P" range. Turn the ignition switch to ON. Display the current data display and display "P SW". Refer to OPERATION , Subaru Select Monitor. | Is the display "ON" in the P range and "OFF" in ranges other than P? | Go to step 4. | Go to step 7. |
| 4 CHECK CURRENT DATA. Select the current data display and display the "Key-lock warning SW". Refer to OPERATION , Subaru Select Monitor. Turn the ignition switch to OFF. | Does the display change from "ON" to "OFF" when the key is inserted and removed? | Go to step 5. | Go to step 10. |
| 5 CHECK CURRENT DATA. Turn the ignition switch to ON. Select the current data display and display "Key locking output". Refer to OPERATION , Subaru Select Monitor. | Is the display "ON" in the P range and "OFF" in ranges other than P? | Go to step 12. | Go to step 6. |
| 6 CHECK DTC OF BODY INTEGRATED UNIT. Set the select lever to other than "P" range. Check DTC of body integrated unit. | Is B1105 (key interlock circuit malfunction) a current malfunction? | Follow the DTC to perform inspection and repair. | Go to step 12. |
| 7 CHECK HARNESS BETWEEN BODY INTEGRATED UNIT AND "P" RANGE SWITCH. Disconnect the connector from body integrated unit. Disconnect the connector of "P" range switch. Check for open circuit of harness, short circuit to battery or short circuit to ground between the body integrated unit and "P" range switch. Connector & terminal (B281) No. 4 - (B117) No. 1 | Is the harness normal? | Go to step 8. | Repair or replace the harness between the body integrated unit and the "P" range switch. |
| 8 CHECK HARNESS BETWEEN "P" RANGE SWITCH AND CHASSIS GROUND. Measure the resistance of harness between "P" range switch and chassis ground. Connector & terminal (B117) No. 2 - Chassis ground | Is it less than 10 ohms? | Go to step 9. | Repair the harness between the "P" range switch and chassis ground. |
| 9 CHECK P RANGE SWITCH. Measure the resistance between "P" range switch connector terminals. Terminals No. 2 - No. 1 | Is it less than 10 ohms in the "P" range, and 1 Mohms or more in ranges other than "P"? | Replace the body integrated unit. | Replace the P range switch. |
| 10 CHECK HARNESS BETWEEN BATTERY AND KEY WARNING SWITCH AND BODY INTEGRATED UNIT. Disconnect the connector from body integrated unit. Measure the voltage between body integrated unit and chassis ground. Connector & terminal (B279) No. 2 - Chassis ground | Is the display 9 V or more when the key is inserted, and less than 1.5 V with the key removed? | Replace the body integrated unit. | Check the following items. Key warning switch Harness/fuse Ignition circuit |
| 11 CHECK DELIVERY (TEST) MODE CONNECTOR HARNESS. Disconnect the connector of body integrated unit. Measure the resistance between body integrated unit connector and the delivery (test) mode connector. Connector & terminal (i84) No. 17 - (i1) No. 1 | Is it less than 10 ohms? | Go to step 12. | Repair or replace the harness between the body integrated unit and delivery (test) mode connector. |
| 12 CHECK HARNESS BETWEEN BODY INTEGRATED UNIT AND KEY LOCK SOLENOID. Disconnect the connector from body integrated unit. Disconnect the connector of key lock solenoid. Check for open circuit of harness, short circuit to battery or short circuit to ground between the body integrated unit and key lock solenoid. Connector & terminal (B279) No. 11 - (B350) No. 2 | Is the harness normal? | Go to step 13. | Repair or replace the harness between the body integrated unit and the key lock solenoid. |
| 13 CHECK HARNESS BETWEEN KEY LOCK SOLENOID AND CHASSIS GROUND. Measure the resistance of harness between key lock solenoid and chassis ground. Connector & terminal (B350) No. 1 - Chassis ground | Is it less than 10 ohms? | Go to step 14. | Repair or replace the harness between the key lock solenoid and chassis ground. |
| 14 CHECK KEY LOCK SOLENOID OPERATION. Connect the battery to the key lock solenoid connector terminal, and operate the solenoid. Terminals No.2 (+) - No.1 (-) | Does the key lock solenoid operate normally? | Go to step 15. | Replace the key lock solenoid. |
| 15 CHECK OUTPUT OF BODY INTEGRATED UNIT. Connect all connectors. Insert the key. Measure the voltage between body integrated unit and chassis ground. Connector & terminal (B279) No. 11 - Chassis ground | Is it 5 V or more in ranges other than "P", and less than 1.5 V in the "P" range? | Check the lock mechanism of the steering lock body. | Replace the body integrated unit. |
DIAGNOSTIC PROCEDURE
Scheme 69
Scheme 70
Scheme 71
Scheme 72
Scheme 73
Scheme 74
Scheme 75
- Set the vehicle on a lift.
- Shift the select lever to "N" range.
- Disconnect the ground cable from battery.
- Lift up the vehicle.
- Remove the rear exhaust pipe and muffler. Non-turbo model Refer to «REMOVAL»(ref-357254-S32999093642010031100000) , Rear Exhaust Pipe. Refer to «REMOVAL»(ref-357254-S17169301122010031100000) , Muffler. Turbo model Refer to «REMOVAL»(ref-357260-S02665767832010031100000) , Rear Exhaust Pipe. Refer to «REMOVAL»(ref-357260-S20286020412010031100000) , Muffler.
- Remove the heat shield cover.
- Remove the cable from arm assembly.
- Raise the claw of clamp and remove the cable.
- Lower the vehicle.
- Remove the grip.
- Remove the hand brake boot cover.
- Remove the console front panel.
- Remove the console cover and console box. Refer to «REMOVAL»(ref-357250-S06797543912010031100000) , Console Box.
- Remove the indicator assembly.
- Remove the harness clips from the bracket.
- Remove the blind.
- Disconnect the connectors, and then remove the four bolts to take out the select lever assembly from vehicle body.
Scheme 76
- Set the select lever to vehicle body.
- Tighten the four bolts to install the select lever to vehicle body, and then connect the connector. Temporarily tighten the bolt A. Tighten the bolt B. Tighten the bolt A. Tighten the bolts C and D. Tightening torque: 18 N.m (1.8 kgf-m, 13.3 ft-lb)
- Install the harness clips to the bracket.
- Install the console cover and console box. Refer to «INSTALLATION»(ref-357250-S40920619742010031100000) , Console Box.
- Shift the select lever to "N" range.
- Install the blind. CAUTION: The blind should be installed so that it is securely caught by tabs of the plate guide COM-PL.
- Install the indicator assembly.
- Install the console front panel.
- Install the hand brake boot cover.
- Install the grip.
- Lift up the vehicle.
- Shift the range select lever to "N" range.
- Secure the cable to the bracket. Refer to «INSTALLATION»(ref-357268-S30796603972010031100000) , Select Cable.
- Adjust the select cable position. Refer to «ADJUSTMENT»(ref-357268-S23525996392010031100000) , Select Cable.
- After the completion of adjustment, confirm that the select lever operates properly at all range positions.
- Install the heat shield cover.
- Install the rear exhaust pipe and muffler. Non-turbo model Refer to «INSTALLATION»(ref-357254-S01911806842010031100000) , Rear Exhaust Pipe. Refer to «INSTALLATION»(ref-357254-S26780140732010031100000) , Muffler. Turbo model Refer to «INSTALLATION»(ref-357260-S40085387742010031100000) , Rear Exhaust Pipe. Refer to «INSTALLATION»(ref-357260-S15991227992010031100000) , Muffler.
- Inspect the following items. When a malfunction is found in the inspection, adjust the select cable and inhibitor switch. Refer to «ADJUSTMENT»(ref-357268-S23525996392010031100000) , Select Cable. Refer to «ADJUSTMENT»(ref-357244-S24167512312010031100000) , Inhibitor Switch. Engine starts when the select lever is in "P" and "N" range, but not in other ranges. Back-up light illuminates when the select lever is in the "R" range, but not in other ranges. Select lever and indicator positions are matched.
Scheme 77
Scheme 78
Scheme 79
Scheme 80
Scheme 81
Scheme 82
Scheme 83
Scheme 84
Scheme 85
Scheme 86
Scheme 87
Scheme 88
Scheme 89
- Remove the gasket and plate COMPL.
- Insert a flat tip screwdriver with a thin tip under the connector and disconnect each connector from the plate COMPL.
- Remove the spacer bolt and remove the plate guide COMPL.
- Remove the shift lock clamp, spring A, select lever rod, lock plate cushion, and bushing.
- Remove the bracket.
- Remove the detent spring.
- Remove the shift lock solenoid unit.
- Raise the claw of connector.
- Disconnect the terminals of the SPORT mode switch, "P" range switch, and shift lock solenoid from the connector, using a flat tip screwdriver with a thin tip.
- Remove the grommet.
- Pull out the spring pin.
- Pull out the arm assembly, remove select lever COMPL, and remove bracket arm detent and bushing.
- Remove the rod detent and spring detent from the bracket arm detent.
Scheme 90
Scheme 91
- Clean all the parts before assembly.
- Apply NIGTIGHT LYW No. 2 grease or equivalent to each part. Refer to «AT SELECT LEVER»(ref-357268-S06799418112010031100000) , COMPONENT, General Description.
- Assemble in the reverse order of disassembly. NOTE: Set the select lever to "D" range (normal mode position) when installing the guide plate and be careful of the following. Insert the protrusion (B) of the guide plate into the hole on shift lock solenoid unit (A). Insert link (D) of the shift lock release into link (C) of the shift lock solenoid unit. Connect the switch and solenoid terminals to the connector.
- After completing installation, shift the select lever from "P" range to "D" range, then check whether the indicator and select lever matches, whether the pointer and position mark matches and whether the operating force occurs.
