PROCEDURE
| CAUTION | Subaru Select Monitor is required for reading DTC, performing diagnosis and reading current data. Remove foreign matter (dust, water, oil, etc.) from the body integrated unit connector during removal and installation. For model with immobilizer, registration of immobilizer may be needed after the replacement of controller etc. For details, refer to the "PC application help for Subaru Select Monitor". |
Note. To check harness for open or short circuits, shake the suspected trouble spot or connector. Check List for Interview Ref. to CHECK LIST FOR INTERVIEW .
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK PRE-INSPECTION. Ask the customer when and how the trouble occurred using the interview check list. Ref. to CHECK LIST FOR INTERVIEW . | Did you interview the customer? | Go to step 2. | Interview the customer. |
| 2 BASIC INSPECTION. Check the components which might affect body control. Ref. to INSPECTION , General Description. | Is the component that might influence the body control problem normal? | Go to step 3. | Repair or replace each component. |
| 3 CHECK DTC. Read the DTC. Ref. to READ DIAGNOSTIC TROUBLE CODE (DTC) , OPERATION, Subaru Select Monitor. NOTE: If the communication function of the Subaru Select Monitor cannot be executed properly, check the communication circuit. Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , INSPECTION, Subaru Select Monitor. Record all DTCs and freeze frame data. | Is DTC displayed on the Subaru Select Monitor? | Go to step 5. | Go to step 4. |
| 4 PERFORM GENERAL DIAGNOSTICS. Inspect using the "General Diagnostics Table". Ref. to GENERAL DIAGNOSTIC TABLE . | Is result of inspection OK? | LAN system is normal. | Go to step 5. |
| 5 PERFORM DIAGNOSIS. Correct the cause of trouble. Perform the Clear Memory Mode. Ref. to CLEAR MEMORY MODE , OPERATION, Subaru Select Monitor. Read the DTC. Ref. to READ DIAGNOSTIC TROUBLE CODE (DTC) , OPERATION, Subaru Select Monitor. | Is DTC displayed on the Subaru Select Monitor? | Repeat step 5 until DTC is not shown. | Finish the diagnosis. |
| NOTE |
|---|
| If the communication function of the Subaru Select Monitor cannot be executed properly, check the communication circuit. Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , INSPECTION, Subaru Select Monitor. |
DIAGNOSIS PROCEDURE
CHECK
Inspect the following item about the vehicle's state.
Scheme 18
Scheme 19
Scheme 20
SUPPLEMENTAL RESTRAINT SYSTEM "AIRBAG"
Airbag system wiring harness is routed near the body integrated unit and twisted pair line.
| CAUTION | Do not use electric test equipment on any wiring harnesses and connectors in the airbag system. Be careful not to damage the airbag system wiring harness when servicing the body integrated unit and LAN system. |
Scheme 21
Scheme 22
- Bus line of LAN system is twisted pair line. Be careful not to by-pass or partly unbind the twisted pair line.
- Do not make clearance between bus lines (CAN High, CAN Low).
- Difference of bus line length should be within 10 cm (3.94 in).
- Fray near the connector should be within 8 cm (3.14 in).
- If the characteristics of the twisted pair line are changed, it may extremely weaken against noise.
- When repairing the harness, connect the wires using soldering and protect it with insulating tape etc.
GENERAL TOOL
| TOOL NAME | REMARKS |
|---|---|
| Circuit tester | Used for measuring resistance, voltage and current. |
GENERAL TOOL CHART
Scheme 23
Scheme 24
Scheme 25
| Description | Terminal No. | Standard value | Measuring conditions |
|---|---|---|---|
| BAT (control) | B6 <----> chassis ground | 10 - 14V | Always |
| BAT (backup) | C2 <----> chassis ground | 10 - 14V | Always |
| BAT (door lock) | A34 <----> chassis ground | 10 - 14V | Always |
| ACC (rear wiper) | D21 <----> chassis ground | 10 - 15V | When ACC is ON |
| Ground | A28 <----> chassis ground | Less than 1.5 V | Always |
| Ground | B17 <----> chassis ground | Less than 1.5 V | Always |
| Ground | C20 <----> chassis ground | Less than 1.5 V | Always |
| Ground | D27 <----> chassis ground | Less than 1.5 V | Always |
| Key warning switch | D2 <----> chassis ground | Less than 1.5 V --> 10 - 15 V | With key removed --> inserted |
| ACC | B7 <----> chassis ground | Less than 1.5 V --> 10 - 15 V | ACC OFF --> ACC ON |
| IGN | B1 <----> chassis ground | Less than 1.5 V --> 10 - 15 V | IGN OFF --> IGN ON |
| Stop light switch | B2 <----> chassis ground | Less than 1.5 V --> 8 V or more | With brake pedal released --> depressed |
| Door switch, driver's seat | A19 <----> chassis ground | 8 V or more --> less than 1.5 V | With driver's door closed --> opened |
| Door switch, passenger's seat | A32 <----> chassis ground | 8 V or more --> less than 1.5 V | With passenger's door closed --> opened |
| Door switch, rear RH seat | A6 <----> chassis ground | 8 V or more --> less than 1.5 V | With rear RH seat door closed --> opened |
| Door switch, rear LH seat | A20 <----> chassis ground | 8 V or more --> less than 1.5 V | With rear LH seat door closed --> opened |
| Door switch, trunk/rear gate | A33 <----> chassis ground | 8 V or more --> less than 1.5 V | With trunk/rear gate closed --> opened |
| Rear gate opener button | C24 <----> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Manual switch (LOCK) | A15 <----> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Manual switch (UNLOCK) | A29 <----> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Delivery (test) mode connector | A17 <----> chassis ground | 8 V or more --> less than 1.5 V | When delivery (test) mode connector is connected |
| Front wiper input RTN | C5 <----> chassis ground | 8 V or more --> less than 1.5 V | When front wiper is reversed |
| Rear wiper switch ON | C18 <----> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Rear wiper switch (INT) | C27 <----> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Rear wiper switch, washer | C28 <----> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Lighting I switch | B11 <----> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Lighting II switch | C8 <----> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| D6 <----> chassis ground | 8 V or more --> less than 1.5 V | Key warning switch ON and lighting switch OFF --> ON | |
| Dimmer switch, Hi beam | B12 <----> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Dimmer switch, passing | B22 <----> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Front fog light switch | B24 <----> chassis ground | 8 V or more -? less than 1.5 V | Switch OFF --> ON |
| TPMS answer-back request input | B13 <----> chassis ground | 8 V or more --> less than 1.5 V | When TPMS transmitter registration answer-back is output |
| MT reverse switch | B18 <----> chassis ground | 8 V or more --> less than 1.5 V | Other than reverse --> reverse |
| Parking brake switch | C15 <----> chassis ground | 8 V or more --> less than 1.5 V | With parking brake not operated operated |
| Bright switch | A14 <----> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Illumination (Vi1) | A12 <----> chassis ground | Approx. 5 V | While clearance light illuminates |
| Illumination (Vi2) | A3 <----> chassis ground | 0.5 V - 4.5 V | While clearance light illuminates |
| Illumination (Vi3) | A26 <----> chassis ground | Less than 1.5 V | Always |
| Fuel level sensor | C7 <----> chassis ground | Approx. 2 - 96 ohms | Ignition ON |
| Wiper deicer & rear defogger switch | A16 <----> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Seat belt switch (driver's seat) | C16 <----> chassis ground | Less than 1.5 V --> 8 V or more | With seat belt unbuckled --> buckled |
| Seat belt switch (Passenger's seat) | C26 <----> chassis ground | Less than 1.5 V --> 8 V or more | With seat belt unbuckled --> buckled |
| Impact sensor | B8 <----> chassis ground | Less than 1.5 V <=> 8 V or more --> 8 V or more | When impact is applied |
| Rear wiper output ON | D9 <----> chassis ground | Less than 1.5 V --> 10 V or more | When rear wiper operates |
| Rear wiper output RTN | D8 <----> chassis ground | Less than 1.5 V --> 10 V or more | When rear wiper reversed |
| Door lock output | A7 <----> A8 | Less than 1.5 V --> 10 V or more | While lock output |
| Door unlock output | A8 --> A7 | Less than 1.5V --> 10 V or more | While unlock output |
| Driver's door unlock output | A23 <----> A7 | Less than 1.5 V --> 10 V or more | While unlock output |
| Trunk/rear gate UNLOCK output | A22 <----> chassis ground | Less than 1.5 V --> 10 V or more | Sedan: While trunk UNLOCK output Wagon: While rear gate UNLOCK output |
| Lighting power supply | C1 <----> chassis ground | Less than 1.5 V --> 10 V or more | With back-up fuse inserted, ACC ON or IGN ON |
| D1 <----> chassis ground | Less than 1.5 V --> 10 V or more | When key warning switch is ON | |
| Clearance light relay output | D19 <----> chassis ground | 8 V or more --> less than 1.5 V | Small light ON |
| Lo beam relay output | C3 <----> chassis ground | 8 V or more --> less than 1.5 V | Headlight switch ON |
| D7 <----> chassis ground | 8 V or more --> less than 1.5 V | Headlight switch ON | |
| Hi beam relay output | D20 <----> chassis ground | 8 V or more --> less than 1.5 V | Headlight switch ON and Hi beam ON Passing switch ON |
| Front fog light relay output | D17 <----> chassis ground | 8 V or more --> less than 1.5 V | Lo beam ON, Hi beam OFF, front fog light switch ON |
| DRL cancel output | D18 <----> chassis ground | 8 V or more --> less than 1.5 V | When Hi beam 100 % illuminates |
| Room light output | D5 | Pulse control | Illumination is adjusted through PWM control |
| Key ring illumination output | C23 | Pulse control | Illumination is adjusted through PWM control |
| Illumination output | A2 | Pulse control | Illumination is adjusted through PWM control |
| Map light output (model with sunroof) | D4 <----> chassis ground | Pulse control | Illumination is adjusted through PWM control |
| Rear defogger relay output | D16 <----> chassis ground | 8 V or more -? less than 1.5 V | While rear defogger output |
| Wiper deicer relay output | D15 <----> chassis ground | 8 V or more -? less than 1.5 V | While wiper deicer output |
| Seat belt warning light (passenger's seat) | A25 <----> chassis ground | 8 V or more --> less than 1.5 V | Indicator go off --> illuminate |
| Answer-back buzzer output | D24 <----> chassis ground | Can not be measured because of high speed ON/OFF | Door lock --> unlock with keyless entry system |
| Turn & hazard output | C22 <----> chassis ground | 8 V or more --> less than 1.5 V | Door lock or unlock with keyless entry system |
| Horn relay output | D29 <----> chassis ground | 8 V or more --> less than 1.5 V | While security alarm operates |
| Security indicator output | A10 <----> chassis ground | 8 V or more --> less than 1.5 V | While indicator in combination meter blinks |
| Immobilizer antenna 1 | B26 <----> B25 | 30 - +30 V | While key secret code is verified |
| Immobilizer antenna 2 | B25 <----> B26 | ||
| Immobilizer communication_1 | B4 | Can not be measured because of digital communication | Serial communication line |
| Immobilizer communication_2 | B15 | Can not be measured because of digital communication | Serial communication line |
| Keyless entry control module communication | A24 | Can not be measured because of digital communication | Serial communication line |
| SSM communication (K line) | B20 | Can not be measured because of digital communication | Serial communication line |
| Body system CAN_Hi | A1 <----> chassis ground | Can not be measured because of digital communication | Serial communication line |
| Body system CAN_Lo | A9 <----> chassis ground | Can not be measured because of digital communication | Serial communication line |
| Driving system CAN_Hi | B3 <----> chassis ground | Can not be measured because of digital communication | Serial communication line |
| Driving system CAN_Lo | B9 <----> chassis ground | Can not be measured because of digital communication | Serial communication line |
MEASURING CONDITIONS CHART
READ CURRENT DATA
- On the «Main Menu», select {Each System Check}.
- On the «System Selection Menu» display screen, select the {Integ. unit mode}.
- Select «Current Data Display & Save» screen.
- Using the scroll key, scroll the display screen up or down until the desired data is shown.
DISPLAY OF DATA
| Items to be displayed | Unit of measure | Remarks | Note |
|---|---|---|---|
| BATT voltage (control) | 10 - 15V | Body integrated unit input value | Always |
| BATT voltage (BACKUP) | 10 - 15V | Body integrated unit input value | Always |
| IG power supply voltage | 10 - 15V | Body integrated unit input value | Ignition switch ON |
| ACC voltage | 10 - 15V | Body integrated unit input value | Ignition switch ACC |
| Illumination VR Voltage | 0 - 5V | Body integrated unit input value | Input value from illumination volume |
| Illumi. output d-ratio | 0 - 100% | Body integrated unit output value | Small light ON Illumination volume is other than bright. |
| Ambient Temperature | 40 - 87.5°C | CAN data input value | Ignition switch ON |
| Fuel level voltage | 0 - 8 V | Body integrated unit input value | Ignition switch ON |
| Fuel level resistance | 0 - 102.3 ohms | Body integrated unit input value | Ignition switch ON |
| Key-lock solenoid V | 6 - 15V | Body integrated unit output value | Not applicable |
| Number of regist. | 0 - 4 | Number of keyless key registered | Number of transmitter registered is displayed |
| Front Wheel Speed | Km/h | CAN data input value | Reception from VDC module |
| VDC/ABS latest f-code | DTC display (Temporarily) | CAN data input value | It is normal when DTC is not been input even if this code is displayed. Received from VDC (Use after hexadecimal conversion) |
| Blower Fan Steps | 0 - 2 levels | CAN data input value | 0: OFF, 1: Low, 2:2 levels or more Reception from air conditioner ECM |
| Fuel level resistance 2 | 0 - 102.3 n | CAN data output value | Reception from body integrated unit |
| Fuel consumption | Cc/s | CAN data input value | Reception from ECM and transmission to center monitor |
| Coolant Temp. | 40 - 130°C | CAN data input value | Reception from ECM |
| Vehicle longitudinal G | M/s 2 | CAN data input value | Reception from VDC module |
| SPORT Shift Stages | 0 - 7 levels | CAN data input value | Not applicable |
| Shift Position | 0 - 7 levels | CAN data input value | Not applicable |
| VDC/ABS condition | 0 - 4 | CAN data input value | Reception from VDC module |
| Destination Code | 0 - 16 | CAN data input value | Reception from combination meter |
| Touch SW | 0 - 64 | CAN data input value | Reception from navigation module |
| Key-lock warning SW | ON/OFF | Body integrated unit input value | ON when ignition key inserted |
| Stop Light Switch | ON/OFF | Body integrated unit input value | ON when brake pedal is depressed |
| Front fog lamp SW input | ON/OFF | Body integrated unit input value | When front fog light switch is ON |
| TPMS input | ON/OFF | Body integrated unit input value | ON when tire pressure is low or malfunction occurs |
| Driver's door SW input | ON/OFF | Body integrated unit input value | ON when driver's door is open |
| P-door SW input | ON/OFF | Body integrated unit input value | ON when passenger's door is open |
| Rear right door SW input | ON/OFF | Body integrated unit input value | ON when rear right door is open |
| Rear left door SW input | ON/OFF | Body integrated unit input value | ON when rear left door is open |
| R Gate SW input | ON/OFF | Body integrated unit input value | ON when rear gate/trunk open |
| Manual lock SW input | ON/OFF | Body integrated unit input value | Manual lock switch ON |
| Manual unlock SW input | ON/OFF | Body integrated unit input value | Manual unlock switch ON |
| Bright SW input | ON/OFF | Body integrated unit input value | ON when bright switch is ON (only for model with clock) |
| P SW | ON/OFF | Body integrated unit input value | Not applicable |
| MT Reverse Switch | ON/OFF | Body integrated unit input value | ON when shift lever is at reverse position |
| R wiper ON SW input | ON/OFF | Body integrated unit input value | Rear wiper switch ON |
| R wiper INT SW input | ON/OFF | Body integrated unit input value | Rear wiper switch (INT ON) |
| R washer SW input | ON/OFF | Body integrated unit input value | Rear washer switch ON |
| Wiper deicer SW input | ON/OFF | Body integrated unit input value | Defogger switch ON |
| Rear Defogger Switch Input | ON/OFF | Body integrated unit input value | |
| Driver's Seat SW input | ON/OFF | Body integrated unit input value | Driver's seat buckle switch ON |
| P seatbelt SW input | ON/OFF | Body integrated unit input value | Passenger's seat buckle switch ON |
| Fr wiper input | ON/OFF | Body integrated unit input value | ON when front wiper is operating |
| Parking Brake Switch Input | ON/OFF | Body integrated unit input value | ON when parking brake is locked |
| R gate lock status SW input | ON/OFF | Body integrated unit inner memory value | Displays door lock/unlock state, ON when locked |
| R Gate Release SW input | ON/OFF | Body integrated unit input value | When rear gate opener button is ON |
| Rr defogger output | ON/OFF | Body integrated unit output value | ON when rear defogger relay is operating |
| Lock actuat. LOCK output | ON/OFF | Body integrated unit output value | ON when LOCK signal is output |
| All seat UNLOCK output | ON/OFF | Body integrated unit output value | ON when unlock signal is output |
| D-seat UNLOCK output | ON/OFF | Body integrated unit output value | ON when unlock signal is output |
| R gate/trunk UNLK output | ON/OFF | Body integrated unit output value | ON when rear gate/trunk unlock signal is output |
| R wiper output | ON/OFF | Body integrated unit output value | ON when rear wiper motor is operating |
| Shift Lock Solenoid | ON/OFF | Body integrated unit output value | Not applicable |
| Key locking output | ON/OFF | Body integrated unit output value | Not applicable |
| Wiper deicer output | ON/OFF | Body integrated unit output value | ON when wiper deicer relay is operating |
| Hazard Output | ON/OFF | Body integrated unit output value | ON when answer-back signal is received or when hazard is operating |
| Keyless Buzzer Output | ON/OFF | Body integrated unit output value | ON when lock/unlock signal is received |
| Horn Output | ON/OFF | Body integrated unit output value | ON when security warning is operating |
| D-belt warning light O/P | ON/OFF | CAN data output value | ON when ignition switch is turned to ON, and buckle switch is turned off |
| P-belt warning light O/P | ON/OFF | Body integrated unit output value | ON when ignition switch is turned to ON, occupant is seated, and buckle switch is turned off |
| Illumination lamp O/P | ON/OFF | Body integrated unit output value | ON when illumination is illuminated |
| Room lamp output | ON/OFF | Body integrated unit output value | ON when any door is open |
| Key illumi. lamp o/p | ON/OFF | Body integrated unit output value | ON when driver's door is open |
| Immobilizer lamp output | ON/OFF | Body integrated unit output value | ON when immobilizer pilot light blinks |
| Keyless operation 1 | Regist./Normal | Body integrated unit input value | When keyless is registered |
| Keyless operation 2 | Deletion/Normal | Body integrated unit input value | When keyless registration is deleted |
| CC Main Lamp | ON/OFF | CAN data input value | Cruise control switch ON Reception from ECM and transmission to combination meter |
| CC Set Lamp | ON/OFF | CAN data input value | ON when cruise control vehicle speed is set Reception from ECM and transmission to combination meter |
| SPORT Lamp | ON/OFF | CAN data input value | Not applicable |
| SPORT Blink | Blink/OFF | CAN data input value | Not applicable |
| ATF Temperature Lamp | ON/OFF | CAN data input value | Not applicable |
| ATF Blink | Blink/OFF | CAN data input value | Not applicable |
| ECO Lamp (AT) | ON/OFF | CAN data input value | Not applicable |
| ECO Lamp (MT) | ON/OFF | CAN data input value | Not applicable |
| Tire diameter abnormal 1 | ON/OFF | CAN data input value | Not applicable |
| Tire diameter abnormal 2 | Blink/OFF | CAN data input value | Not applicable |
| Shift Up Indication | UP/OFF | CAN data input value | Not applicable |
| Shift Down Indication | DOWN/OFF | CAN data input value | Not applicable |
| SPORT Shift (buzzer 1) | ON/OFF | CAN data input value | Not applicable |
| SPORT Shift (buzzer 2) | ON/OFF | CAN data input value | Not applicable |
| ABS/VDC Judging | ABS/VDC | CAN data input value | Transmission from vehicle dynamic control (VDC) to high speed control module |
| Small Light SW | ON/OFF | CAN data output value | ON when small light is illuminated |
| Headlamp | ON/OFF | CAN data output value | When headlight LO is ON |
| High Beam | ON/OFF | CAN data output value | When headlight HI is ON |
| Large Diameter Tire | Large tire/Others | CAN data output value | Large tire when the standard tire is 18 in Reception from combination meter |
| Number of cylinders | 4 Cylinder/6 Cylinder | CAN data input value | Display engine equipped |
| Cam shaft specification | SOHC/DOHC | CAN data input value | Display engine equipped |
| Turbo | Turbo/Non-turbo | CAN data input value | Display engine equipped |
| E/G displacement (2.5L) | 2.517 OFF | CAN data input value | Display engine equipped |
| E/G displacement (3.0L) | 3.0 U OFF | CAN data input value | Display engine equipped |
| AT Vehicle ID Signal | ON/OFF | CAN data input value | Display transmission equipped |
| Blower fan information | ON/OFF | CAN data input value | ON when blower fan is operating (always OFF for auto A/C equipped models) |
| Center display failure | OK/NG | CAN data input value | NG when there is a center display failure Reception from center display (NAVI monitor) |
| NAVI Failure | OK/NG | CAN data input value | NG when there is a navigation system failure Reception from Center Display |
| IE Bus failure | Can not use | CAN data input value | Reception from Center Display |
| Auto A/C failure | OK/NG | CAN data input value | NG when there is a failure in auto air conditioning system Reception from auto A/C module |
| EBD Warning Light | ON/OFF | CAN data input value | OK when EBD warning light is illuminated Reception from VDC/ABS and transmission to combination meter |
| ABS Warning Light | ON/OFF | CAN data input value | OK when ABS warning light is illuminated Reception from VDC/ABS and transmission to combination meter |
| VDC OFF flag | ON/OFF | CAN data input value | Vehicle dynamics control OFF SW is ON Reception from VDC/ABS and transmission to combination meter |
| VDC/ABS OK B | OK/NG | CAN data input value | NG when there is an error in VDC/ABS system Reception from VDC/ABS |
| Lighting 1 Switch Input | ON/OFF | Body integrated unit input value | ON when lighting switch, illumination is ON |
| Lighting II Switch Input | ON/OFF | Body integrated unit input value | ON when lighting switch, headlight is ON |
| Dimmer Hi Switch Input | ON/OFF | Body integrated unit input value | ON when dimmer switch is Hi beam position |
| Dimmer Pass Switch Input | ON/OFF | Body integrated unit input value | ON when dimmer switch is passing position |
| Lighting 1 Lamp Output | ON/OFF | Body integrated unit output value | ON when small light is illuminated |
| Lighting II Lamp Output | ON/OFF | Body integrated unit output value | ON when headlight is illuminated |
| Lighting Hi Lamp Output | ON/OFF | Body integrated unit output value | ON when Hi beam is illuminated |
| Front Fog Lamp Output | ON/OFF | Body integrated unit output value | ON when front fog light is ON. |
| DRL Cancel Output | ON/OFF | Body integrated unit output value | ON when small light is illuminated |
| Power Supply Tr | ON/OFF | Body integrated unit output value | Headlight auxiliary power supply ON |
| Spot map lamp output | ON/OFF | Body integrated unit output value | ON when spot map light is illuminated |
| Echo switch information | ON/OFF | Body integrated unit input value | Not applicable |
| Off delay time | OFF, Short, Normal, Long | Body integrated unit setting items | Customize setting |
| Rr defogger op, mode | Continuous/Normal | Body integrated unit setting items | Customize setting |
| Security Alarm Setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Impact Sensor Setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Alarm delay setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Lockout prevention | ON/OFF | Body integrated unit setting items | Customize setting |
| Impact sensor | ON/OFF | Body integrated unit setting items | Customize setting |
| Answer-back buzzer setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Hazard answer-back setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Ans.-back Buzzer | ON/OFF | Body integrated unit setting items | Inside condition of unit |
| Auto locking | ON/OFF | Body integrated unit setting items | Customize setting |
| Passive Alarm | ON/OFF | Body integrated unit setting items | Customize setting |
| Door open warning | ON/OFF | Body integrated unit setting items | Customize setting |
| Dome Light Alarm Setting | ON/OFF | Body integrated unit setting items | Customize setting |
| Map Light Setting | ON/OFF | Body integrated unit setting items | Customize setting |
| Belt Warning Switch | ON/OFF | Body integrated unit setting items | Customize setting |
| A/C ECM setting | ON/OFF | Body integrated unit setting items | Equipment setting |
| Wiper deicer | ON/OFF | Body integrated unit setting items | Equipment setting |
| Sedan/Wagon Setting | Sedan/wagon | Body integrated unit setting items | Equipment setting |
| MT/AT Setting | MT/AT | Body integrated unit setting items | Equipment setting |
| 6MT Setting | 6MT/Other than 6MT | Body integrated unit setting items | Equipment setting |
| Destination Setting | Each destination | Body integrated unit setting items | |
| Factory or Market setting | Factory/Market | Body integrated unit setting items | Equipment setting |
DISPLAY OF DATA
Note. For details concerning the operation procedure, refer to "PC application help for Subaru Select Monitor".
CONFIRMATION OF CURRENT SETTING
- On «Main Menu» display, select {Each System Check}.
- On «System Selection Menu» display, select {Integ. unit mode}.
- On «Integ. unit mode failure diag» display, select {Current Data Display & Save}.
- Using the scroll key, scroll the display screen up or down until the desired data is shown.
- Display the following item and record the settings.
Required items for new registration (Except for system not equipped)
| Contents | Item to confirm | Remarks | |||
|---|---|---|---|---|---|
| Registration number | 1 | 2 | 3 | 4 | Registered ID type |
| Off delay time | OFF | Long | Normal | Short | Setting for lighting off time |
| Rr defogger op. mode | Normal | Continuous | |||
| Security Alarm Setup | ON | OFF | |||
| Impact Sensor Setup | ON | OFF | Option setting | ||
| Alarm delay setup | ON | OFF | |||
| Lockout prevention | ON | OFF | |||
| Impact sensor | Support | No support | Option setting | ||
| Answer-back buzzer setup | ON | OFF | |||
| Hazard answer-back setup | ON | OFF | |||
| Ans.-back Buzzer | Support | No support | |||
| Passive Alarm | ON | OFF | |||
| Door open warning | Support | No support | |||
| Dome Light Alarm Setting | ON | OFF | |||
| Map Light Setting | ON | OFF | |||
| Belt Warning Switch | ON | OFF | |||
| A/C ECM setting | Support | No support | Model with auto A/C | ||
| Wiper deicer | Support | No support | Option setting | ||
| Sedan/Wagon Setting | Sedan | Wagon | |||
| MT/AT Setting | AT | MT | |||
| 6MT Setting | 6MT | Other than 6MT | |||
| Factory or Market setting | Factory | Market | Do not change to factory mode. | ||
REGISTRATION CHART
REGISTRATION BODY INTEGRATED UNIT (FUNCTION SETTING)
| CAUTION | Body integrated unit is core of LAN system, and also can select the function of all vehicle system control. It is possible to control the original functions of vehicle when registrations of body integrated unit, or User Customizing are corresponded to vehicle equipment. If registrations and function setting are different from vehicle equipment, vehicle system does not operate normally and diagnosis cannot be performed correctly. Pay attention to following item. Be sure to correspond registrations, or User Customizing settings to vehicle equipment. Do not change the settings of vehicle improperly. Confirm key illumination does not blink or "Factory or Market setting" of body integrated unit registrations is "Market". If "Factory or Market setting" is set to "Factory," key illumination blinks when ignition key is turned ON, to notify that the settings are unconfirmed. Key illumination does not blink with ignition switch turned to ON and go off with door closed. Be sure to register immobilizer if body integrated unit is replaced with a new part, (models with immobilizer) Make a registration of immobilizer when the parts related to immobilizer have been replaced. Refer to the "PC application help for Subaru Select Monitor". |
- Connect SDI to data link connector located in the lower portion of the instrument panel (on the driver's side). CAUTION: Do not connect the scan tools other than the Subaru Select Monitor.
- Start the PC.
- Turn the ignition switch to ON (engine OFF) and run the "PC application for Subaru Select Monitor".
- On «Main Menu» display, select {Each System Check}.
- On «System Selection Menu» display, select {Integ. unit mode}.
- Click the [OK] button after the control module name {Integrated unit} is displayed.
- On «Integ. unit mode failure diag» display, select {Unit customizing}.
- Change the setting with UP/DOWN key. List of body integrated unit registration item NOTE: Setting is different depending on the grade of vehicle. REGISTRATION CHART Data Initial setting Registration Remarks A/C ECM setting OFF ON Set to "ON" in case of model with auto A/C. Set to "OFF" in case of model without auto A/C. OFF wiper deicer (Manufacturer option) OFF ON Be sure to set exactly according to vehicle equipment. ON signal does not output even when the switch is operated, if "OFF" is set. OFF Sedan/Wagon Setting Wagon Sedan Be sure to set exactly according to vehicle model. This relates to door lock control. Wagon MT/AT Setting AT MT Be sure to set exactly according to vehicle model. This relates to key interlock control, shift lock control. AT 6MT Setting Other than 6MT 6MT Set "6MT" for 6MT model, and set "Other than 6MT" for AT/5AT model. Other than 6MT Factory or Market setting Factory Factory Be sure to set to "Market". After setting change, turn the ignition switch to OFF and settle the changed settings. Market CAUTION: To perform normal operation of vehicle and diagnosis, the above settings must match the actual vehicle equipment. When body integrated unit is a new part or "Factory" mode, key illumination blinks to show equipment settings have not been completed. Check the detailed procedures of User Customizing. Be sure not to change Factory or Market setting except when installing a new body integrated unit. NOTE: "Factory" mode: Body integrated unit has not been set yet. It can be recognized by key illumination blinking with ignition switch turned to ON. All replacement body integrated units are set to "Factory" mode. When replacing a body integrated unit, be sure to perform the registration operation. "Market" mode: Each settings have been set. It can be recognized by key ring illumination coming on in concocting with room light and going off with ignition switch turned to ON.
- Perform the Factory or Market setting. On the «ECM customizing» display screen of Subaru Select Monitor, select the {Factory or Market setting}.
- Change the mode from Factory to Market and then turn the ignition switch to OFF.
- Change the Subaru Select Monitor system selection to «Immobilizer» to register the immobilizer key. (models with immobilizer)
- Perform the operation according to the "PC application help for Subaru Select Monitor".
- When key registration is completed, "Do you want to register remote engine start?" is displayed. Perform registration only for equipped models.
- Perform the User Customizing. Ref. to «USER CUSTOMIZING»(ref-357102-S08765445172010030800000) , OPERATION, Subaru Select Monitor. NOTE: For details concerning the operation procedure, refer to "PC application help for Subaru Select Monitor".
CLEAR MEMORY MODE
- On «Main Menu» display, select {Each System Check}.
- On «System Selection Menu» display, select {Integ. unit mode}.
- Press the [OK] key after the information of body integrated unit type is displayed.
- On «Integ. unit mode failure diag» display, select {Clearing Memory} and press the [OK] key. CLEAR MEMORY MODE REFERENCE Display Contents to be monitored Clear Memory? Clear function of DTC and freeze frame data
- When "Done" is shown on the display screen, turn the ignition switch to OFF. NOTE: For details concerning the operation procedure, refer to "PC application help for Subaru Select Monitor".
FREEZE FRAME DATA
Note. Data stored at the time of trouble occurrence is shown on the display. Freeze frame data will be memorized maximum to 20. If freeze frame data is not stored in memory correctly (caused by low power supply of body integrated unit), DTC will be displayed with "?" on the head of it in the Subaru Select Monitor display. This shows it may be an unreliable reading.
USER CUSTOMIZING
- On «Main Menu» display, select {Each System Check}.
- On «System Selection Menu» display, select {Integ. unit mode}.
- On «Integ. unit mode failure diag» display, select {Unit Customizing}.
- Change the setting with UP/DOWN key and set with the [OK] key. List of User Customizing item LIST OF USER CUSTOMIZING ITEM Data Initial setting value Customize setting Remarks Off delay time Long Delay time below can be selected by setting. OFF 0 seconds Short 10 seconds Normal 20 seconds Long 30 seconds Rr defogger op. mode 15 minutes 15 minutes Automatically stops in 15 minutes after switch is turned to ON. Continuous Repeats active condition for 15 minutes and inactive condition for 2 minutes until switch is turned to OFF. Security Alarm Setup ON ON Security alarm (hazard, horn or siren) in active condition OFF Security alarm in inactive condition Impact Sensor Setup OFF ON Workable when Impact Sensor Setup is set to "ON". Impact sensor function becomes activated. OFF Impact sensor in inactive condition. (Set to "OFF" in models without sensors.) Alarm delay setup ON After the keyless lock operation, the alarm monitor starts after the following delay time has passed. ON Delay time is 30 seconds. OFF Delay time is 0 seconds. Lockout prevention ON ON Lockout prevention in active condition. (The function does not operate if safety knob is locked by hand.) OFF Lockout prevention in inactive condition Impact sensor (OP) OFF ON Workable when Impact Sensor Setup is set to "ON". Impact sensor function becomes activated. OFF Impact sensor in inactive condition (Set to "OFF" in models without sensors.) Answer-back buzzer setup ON ON Workable when answer-back buzzer setup is set to "ON". When lock/unlock is selected by keyless entry system operation, hazard answer-back buzzer operates. OFF When lock/unlock is selected by keyless entry system operation, answer-back buzzer does not sound. Hazard answer-back setup ON ON Workable when hazard answer-back setup is set to "ON" When lock/unlock is selected by keyless entry system operation, hazard answer-back buzzer operates. OFF When lock/unlock is selected by keyless entry system operation, answer-back buzzer does not sound. Ans.-back Buzzer ON ON Vehicle is controlled in answer-back buzzer equipped mode. OFF Vehicle is controlled in answer-back buzzer non-equipped mode. (Make sure to set to "OFF" in models without answer back buzzers.) Initial keyless setting - - Execution Initial button setting - - Execution Passive Alarm OFF ON Setting only for North American models OFF Door open warning ON ON If detecting door open for 30 minutes, room light, and key ring illumination that are related to doors are turned off to prevent battery run-out. OFF Room light, key illumination and door warning light is not turned off. Dome Light Alarm Setting OFF ON The room light lights by being interlocked with the activation of the alarm. OFF Map Light Setting ON ON Illuminates in accordance with the door interlocked room light. (model with sunroof) OFF Belt Warning Switch ON ON When using normally OFF Stop the belt warning buzzer beep and warning light illumination.
- After setting, make sure that the setting changed in the {Current Data Display & Save} is same as vehicle equipment. CAUTION: The above settings must match the actual vehicle equipment. Do not change settings except for above setting while performing the User Customizing. Be sure not to change Factory or Market setting except when installing a new body integrated unit. NOTE: For details concerning the operation procedure, refer to "PC application help for Subaru Select Monitor".
FUNCTION CHECK
In order to check the body integrated unit function, inspect the body integrated unit and actuator using Subaru Select Monitor without operating switches.
Scheme 26
- On «Main Menu» display, select {Each System Check}.
- On «System Selection Menu» display, select {Integ. unit mode}.
- On «Integ. unit mode failure diag» display, select {Function check}.
- Select the item to be operated on the «Function check» display screen with "UP/Down key" and press the [Next] button.
- Pressing [Next] starts, [End] cancels the operation and [OK] returns to the System Operation Check Mode display screen. NOTE: If not equipped (based on area or condition), process will not go on.
DETECTING CONDITION
Faulty harness connectors
LIST
| DTC | Item | Diagnosis content | Reference |
|---|---|---|---|
| B1100 | Integ. Unit System Error | Memory read out error in body integrated unit | Ref. to DTC B1100 INTEG. UNIT SYSTEM ERROR , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| B1101 | BATT p/supply malfunction cont. | Open or short in battery power supply control circuit Voltage malfunction caused by poor contact | Ref. to DTC B1101 BATT P/SUPPLY MALFUNCTION CONT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| B1102 | BATT p/supply malfunction backup | Voltage malfunction caused by poor contact of battery power supply backup circuits | Ref. to DTC B1102 BATT P/SUPPLY MALFUNCTION BACKUP , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| B1103 | Ignition power failure | Voltage malfunction caused by poor contact of IGN power supply circuits | Ref. to DTC B1103 IGNITION POWER FAILURE , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| B1104 | ACC power failure | Voltage malfunction caused by poor contact of ACC power supply circuits | Ref. to DTC B1104 ACC POWER FAILURE , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| U1201 | CAN-HS counter abnormal | Communication is unstable because of high speed CAN communication error. | Ref. to DTC U1201 CAN-HS COUNTER ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| U1202 | CAN-HS bus off | Open or power supply-output short, GND-output short occurs in CAN line. End resistance malfunction Internal error in each control module | Ref. to DTC U1202 CAN-HS BUS OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| U1211 | CAN-HS ECM data abnormal | Received error data from ECM. | Ref. to DTC U1211 CAN-HS ECM DATA ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| U1213 | CAN-HS VDC/ABS data abnormal | Received error data from VDC/ABS module. | Ref. to DTC U1213 CAN-HS VDC/ABS DATA ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| U1216 | High-Speed CAN (DCCD) Data Error | Received error data from DCCD CM. | Ref. to DTC U1216 HIGH-SPEED CAN (DCCD) DATA ERROR , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| U1221 | CAN-HS ECM no-receive data | Not received data from ECM. | Ref. to DTC U1221 CAN-HS ECM NO-RECEIVE DATA , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| U1223 | CAN-HS VDC/ABS no-receive data | Not received data from VDC/ABS CM. | Ref. to DTC U1223 CAN-HS VDC/ABS NO-RECEIVE DATA , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| U1226 | High-Speed CAN (DCCD) Data is Not Received | Not received data from DCCD CM. | Ref. to DTC U1226 HIGH-SPEED CAN (DCCD) DATA IS NOT RECEIVED , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| U1300 | CAN-LS malfunction | Open or short in CAN-LS circuit, on ether side | Ref. to DTC U1300 CAN-LS MALFUNCTION , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| U1301 | CAN-LS counter abnormal | Communication is unstable because of low speed CAN communication error. | Ref. to DTC U1301 CAN-LS COUNTER ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| U1302 | CAN-LS bus off | Open or power supply-output short, GND-output short occurs in both CAN line. Internal error in each control module | Ref. to DTC U1302 CAN-LS BUS OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| U1311 | CAN-LS meter unit data abnormal | Received error data from meter. | Ref. to DTC U1311 CAN-LS METER UNIT DATA ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| U1321 | CAN-LS meter no-receive data | Not received data from meter. | Ref. to DTC U1321 CAN-LS METER NO-RECEIVE DATA , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| B1401 | M Collation NG | Malfunction related immobilizer | Ref. to DTC B1401 M COLLATION NG , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| B1402 | Immobilizer Key Collation NG | Malfunction related immobilizer | Ref. to DTC B1402 IMMOBILIZER KEY COLLATION NG , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| B1403 | E/G request NG | Malfunction related immobilizer | Ref. to DTC B1403 E/G REQUEST NG , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| B1500 | Keyless UART com. Malfunction | Open or short circuit in keyless UART circuit | Ref. to DTC B1500 KEYLESS UART COM. MALFUNCTION , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
LIST OF DIAGNOSTIC TROUBLE CODE
