INSPECTION
Before performing diagnostics, check the following item which might affect body integrated unit malfunctions.
- Measure the battery voltage and check electrolyte. Standard voltage: 12 V or more Specific gravity: 1.260 or more
- Check the fuse condition. Make sure that ampere of the fuse is setting value, and it is not blown out. (Be sure to check the back-up fuse also.)
- Check the connecting condition of harness and harness connector.
- Confirm settings of body integrated unit are corresponded to vehicle equipment. REGISTRATION BODY INTEGRATED UNIT (FUNCTION SETTING), OPERATION, Subaru Select Monitor.>
- Make sure that the User Customizing of the body integrated unit matches the vehicle equipment. USER CUSTOMIZING, OPERATION, Subaru Select Monitor.>
- Confirm "Factory or Market setting" of body integrated unit registrations is "Market".
- Confirm key illumination does not blink with ignition switch turned to ON.
TROUBLE SYMPTOM
Not communicable with Subaru Select Monitor.
Scheme 31
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK IGNITION SWITCH. | Is the ignition switch ON? | Go to step 2. | Turn the ignition switch to ON, and select Integ. unit mode using Subaru Select Monitor. |
| 2 CHECK BATTERY. Turn the ignition switch to OFF. Measure the battery voltage. | Is the voltage 11 V or more? | Go to step 3. | Charge or replace the battery. |
| 3 CHECK BATTERY TERMINAL. | Is there poor contact at battery terminal? | Repair or tighten the battery terminal. | Go to step 4. |
| 4 CHECK COMMUNICATION OF SUBARU SELECT MONITOR. Turn the ignition switch to ON. Using the Subaru Select Monitor, check whether communication to other systems can be executed normally. | Is the system name displayed? | Go to step 7. | Go to step 5. |
| 5 CHECK COMMUNICATION OF SUBARU SELECT MONITOR. Turn the ignition switch to OFF. Disconnect the body integrated unit connector. Turn the ignition switch to ON. Check whether communication to other systems can be executed normally. | Is the system name displayed? | Go to step 7. | Go to step 6. |
| 6 CHECK HARNESS CONNECTOR BETWEEN EACH CONTROL MODULE AND SUBARU SELECT MONITOR. Turn the ignition switch to OFF. Disconnect the body integrated unit connector. Measure the resistance between data link connector and chassis ground. Connector & terminals (B40) No. 7 - Chassis ground | Is the resistance 1 Mohms or more? | Go to step 7. | Repair the harness and connector between each control module and Subaru Select Monitor. |
| 7 CHECK OUTPUT SIGNAL TO BODY INTEGRATED UNIT. Turn the ignition switch to ON. Measure the voltage between body integrated unit and chassis ground. Connector & terminal (B40) No. 7 (+) - Chassis ground (-) | Is the voltage less than 1 V? | Go to step 8. | Repair the harness and connector between each control module and Subaru Select Monitor. |
| 8 CHECK HARNESS CONNECTOR BETWEEN BODY INTEGRATED UNIT AND DATA LINK CONNECTOR. Measure the resistance between body integrated unit and data link connector. Connector & terminals (B40) No. 7 - (B280) No. 20 | Is the resistance less than 1 ohms? | Go to step 9. | Repair the harness and connector between body integrated unit and Subaru Select Monitor. |
| 9 CHECK BACK-UP FUSE. Check that back-up fuse is not blown out, or check that it is inserted. | Is back-up fuse OK? | Go to step 10. | Replace the backup fuse, or insert it into the fuse holder. |
| 10 CHECK POWER SUPPLY CIRCUIT. Measure the voltage between body integrated unit connector and chassis ground. Connector & terminals (B281) No. 2 (+) - Chassis ground (-) | Is the voltage 10 V or more? | Go to step 11. | Repair the open circuit of harness between body integrated unit and battery. |
| 11 CHECK HARNESS CONNECTOR BETWEEN BODY INTEGRATED UNIT AND CHASSIS GROUND. Turn the ignition switch to OFF. Disconnect the connector from body integrated unit. Measure the resistance of harness between the body integrated unit and chassis ground. Connector & terminals (B280) No. 20 - Chassis ground | Is the resistance 1 Mohms or more? | Go to step 12. | Repair the poor contact of harness between body integrated unit and ground. |
| 12 CHECK POOR CONTACT OF CONNECTOR. | Is there poor contact of the control unit ground and the Subaru Select Monitor? | Replace the body integrated unit. Ref. to REMOVAL , Body integrated Unit. | Repair the poor contact of connector. |
DIAGNOSTIC PROCEDURE
| CAUTION | For model with immobilizer, immobilizer registration work is necessary when the body integrated unit replaced. For details, refer to the "PC application help for Subaru Select Monitor". |
DTC TABLE
Note. When more than two DTC codes are recorded, referring to their combination will make it easy to identify the possible cause. Refer to the list for typical examples.
| DTC to Check | Diagnostic Code that was displayed. | Probable cause | |||
|---|---|---|---|---|---|
| Body integrated unit | ECM | TCM | VDC/ABS CM | ||
| B1100 DTC B1100 INTEG. UNIT SYSTEM ERROR, Diagnostic Procedure with Diagnostic Trouble Code (DTC).> | B1100 | There could be a problem in the body integrated unit. | |||
| U1221 DTC U1221 CAN-HS ECM NO-RECEIVE DATA, Diagnostic Procedure with Diagnostic Trouble Code (DTC).> | U1221 | P1718 | C0057 | It is possible that the ECM is faulty. | |
| U1222 DTC U1222 CAN-HS TCM NO-RECEIVE DATA, Diagnostic Procedure with Diagnostic Trouble Code (DTC).> | U1222 | P0600 | C0057 | It is possible that the TCM is faulty. | |
| U1223 DTC U1223 CAN-HS VDC/ABS NO-RECEIVE DATA, Diagnostic Procedure with Diagnostic Trouble Code (DTC).> | U1223 | P0600 | P1718 | It is possible that the VDC/ABS CM is faulty. | |
| U1321 DTC U1321 CAN-LS METER NO-RECEIVE DATA, Diagnostic Procedure with Diagnostic Trouble Code (DTC).> | U1321 | It is possible that the combination meter is faulty. | |||
| B1500 DTC B1500 KEYLESS UART COM. MALFUNCTION, Diagnostic Procedure with Diagnostic Trouble Code (DTC).> | B1500 | It's possible that there is an internal problem in the keyless entry control module, or a open circuit in the communication line. | |||
DTC CHART
DTC DETECTING CONDITION
Memory read out error in body integrated unit
- Check light comes on in the combination meter.
- LAN communication immobilizer function may not be executed normally.
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK DTC. Check DTC indicated by body integrated unit. READ DIAGNOSTIC TROUBLE CODE (DTC), OPERATION, Subaru Select Monitor.> | Is the DTC B1100 displayed current malfunction? | Go to step 2. | Temporary EEPROM access error occurred. |
| 2 CHECK CONNECTOR. Turn the ignition switch to OFF. Disconnect the body integrated unit connector. Connect the disconnected connectors. Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is the DTC B1100 displayed current malfunction? | Replace the body integrated unit. Ref. to REMOVAL , Body Integrated Unit. | Temporary EEPROM access error occurred. |
DIAGNOSTIC PROCEDURE
- Open or short in battery power supply control circuit
- Voltage malfunction caused by poor contact
Each function stops operation.
Note. When B1102 BATT p/supply (backup) malfunction is output at the same time, all the function of body integrated unit may not operate. B1101 may input when the battery run-out occurs.
Scheme 32
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK DTC. Read the DTC of body integrated unit using Subaru Select Monitor. READ DIAGNOSTIC TROUBLE CODE (DTC), OPERATION, Subaru Select Monitor.> | Is B1101 current malfunction? | Go to step 2. | Go to step 5. |
| 2 CHECK DTC. Turn the ignition switch to OFF. Disconnect the connector from body integrated unit and reconnect. Wait approx. 2 minutes. Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is B1101 current malfunction? | Go to step 3. | Go to step 5. |
| 3 CHECK FUSE. Turn the ignition switch to OFF. Inspect the fuse. | Is the fuse OK? | Go to step 4. | Replace the defective fuse. |
| 4 CHECK HARNESS. Disconnect the body integrated unit connector (B280). Measure the voltage between body integrated unit connector and chassis ground using tester. Connector & terminals (B280) No. 6 (+) - Chassis ground (-) | Is the voltage 8.5 - 16.5 V? | Replace the body integrated unit. Ref. to REMOVAL , Body Integrated Unit. | Repair or replace the open or shorted circuit between body integrated unit and fuse. |
| 5 CHECK CONNECTOR. Turn the ignition switch to OFF. Disconnect the body integrated unit connector (B280). | Is there poor contact of connector? | Repair or replace the poor contact of connector. | A temporary change of voltage occurred. |
DIAGNOSTIC PROCEDURE
Voltage malfunction caused by poor contact of battery power supply backup circuits
No influence.
Note. When B1101 BATT p/supply (cont.) malfunction are output at the same time, all function of body integrated unit may not operate. B1101 may input when the battery run-out occurs.
Voltage malfunction caused by poor contact of IGN power supply circuits
Error related to LAN system will not be detected.
Note. B1103 may output when the ignition switch turns to ON with the weak battery condition.
Scheme 33
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK DTC. Read the DTC of body integrated unit using Subaru Select Monitor. READ DIAGNOSTIC TROUBLE CODE (DTC), OPERATION, Subaru Select Monitor.> | Is B1103 current malfunction? | Go to step 2. | Go to step 5. |
| 2 CHECK DTC. Turn the ignition switch to OFF. Disconnect the connector from body integrated unit and reconnect. Turn the ignition switch to ON. Wait approx. 2 minutes. Read the DTC of body integrated unit using Subaru Select Monitor. | Is B1103 current malfunction? | Go to step 3. | Go to step 5. |
| 3 CHECK FUSE. Turn the ignition switch to OFF. Inspect the fuse. | Is the fuse OK? | Go to step 4. | Replace the defective fuse. |
| 4 CHECK HARNESS. Disconnect the body integrated unit connector (B280). Turn the ignition switch to ON. Measure the voltage between body integrated unit connector and chassis ground using tester. Connector & terminals (B280) No. 1 (+) - Chassis ground (-) | Is the voltage 8.5 - 16.5 V? | Replace the body integrated unit. Ref. to REMOVAL , Body Integrated Unit. | Repair or replace the open or shorted circuit between body integrated unit and fuse. |
| 5 CHECK CONNECTOR. Turn the ignition switch to OFF. Disconnect the body integrated unit connector (B280). | Is there poor contact of connector? | Repair or replace the poor contact of connector. | A temporary change of voltage occurred. |
DIAGNOSTIC PROCEDURE
Voltage malfunction caused by poor contact of ACC power supply circuits
Does not exist.
Note. B1104 may output when the ignition switch turns to ACC with the weak battery condition.
Ground short of key interlock circuit
Key interlock does not keep lock condition.
Scheme 34
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK DTC. Insert the ignition key. Shift to the Neutral range. Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is B1105 current malfunction? | Go to step 2. | Go to step 8. |
| 2 CHECK DTC. Remove the ignition key. Disconnect the key lock solenoid connector (B350) and body integrated unit connector (B279). Connect the disconnected connectors. Insert the key and shift into Neutral. Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is B1105 current malfunction? | Go to step 3. | Go to step 8. |
| 3 CHECK KEY LOCK SOLENOID. Turn the ignition switch to OFF. Disconnect the key lock solenoid connector (B350). Measure the resistance between the key lock solenoid connector. Connector & terminals (B350) No. 1 - No. 2 | Is the resistance 12 - 14.5 ohms? | Go to step 4. | Replace the key lock solenoid. |
| 4 CHECK KEY LOCK SOLENOID. Connect the battery terminal to key lock solenoid. Terminals (B350) No. 2 - positive terminal: (B350) No. 1 - ground terminal | Is the solenoid activated and then key locked? | Go to step 5. | Replace the key lock solenoid. |
| 5 CHECK HARNESS. Disconnect the body integrated unit connector (B279). Measure the resistance between body integrated unit and key lock solenoid using tester. Connector & terminals (B350) No. 2 - (B279) No. 11 | Is the resistance less than 10 ohms? | Go to step 6. | Repair or replace the open circuit of harness. |
| 6 CHECK HARNESS. Measure the resistance between body integrated unit and chassis ground using tester. Connector & terminals (B279) No. 11 - Chassis ground | Is the resistance 1 Mohms or more? | Go to step 7. | Repair or replace the short circuit of the harness. |
| 7 CHECK HARNESS. Turn the ignition switch to ON. Measure the voltage between body integrated unit and chassis ground using tester. Connector & terminals (B279) No. 11 (+) - Chassis ground (-) | Is the voltage 1.5 V or more Connector & terminals? | Repair or replace the short circuit of the harness. | Replace the body integrated unit. Ref. to REMOVAL , Body Integrated Unit. |
| 8 CHECK CONNECTOR. Turn the ignition switch to OFF. Disconnect the body integrated unit connector (B279) and key lock solenoid connector (B350). | Is there poor contact at disconnected connector terminal? | Repair the terminal where poor contact exists, or replace harness. | It is possible that temporary poor contact occurs. |
DIAGNOSTIC PROCEDURE
Shift lock circuit is open or shorted.
Shift lock does not be released or remain locked.
Note. P0801 may input simultaneously.
Scheme 35
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK DTC. Turn the ignition switch to ON. Keep the Parking range for approx. 5 seconds. Read the DTC of body integrated unit using Subaru Select Monitor. | Is B1106 current malfunction? | Go to step 2. | Go to step 7. |
| 2 CHECK DTC. Turn the ignition switch to OFF. Disconnect the body integrated unit connector (B279) and shift lock solenoid connector (B117). Connect the disconnected connectors. Turn the ignition switch to ON, then keep the Parking range for approx. 5 seconds. Read the DTC of body integrated unit using Subaru Select Monitor. | Is B1106 current malfunction? | Go to step 3. | Go to step 7. |
| 0 Connector & terminals (B117) No. 4 - Chassis ground | Is the resistance less than 10 ohms? | Go to step 4. | Repair the open circuit of harness or replace harness. |
| 4 CHECK SHIFT LOCK SOLENOID. Measure the resistance between the shift lock solenoid connector. Connector & terminals (B117) No. 4 - No. 3 | Is the resistance 19 - 25 ohms? | Go to step 5. | Replace the shift lock solenoid. |
| 5 CHECK SHIFT LOCK SOLENOID. Connect the battery terminal to shift lock solenoid. Terminals (B117) No. 3 - positive terminal: (B117) No. 4 - ground terminal | Is the solenoid activated, and then the shift lock released? | Go to step 6. | Replace the shift lock solenoid. |
| 6 CHECK HARNESS. Disconnect the body integrated unit connector (B279). Measure the resistance between body integrated unit connector (B279) and chassis ground. Connector & terminals (B279) No. 12 - Chassis ground | Is the resistance 1 Mohms or more? | Replace the body integrated unit. Ref. to REMOVAL , Body Integrated Unit. | Repair the short circuit of harness or replace harness. |
| 7 CHECK DTC. Connect the disconnected connectors. Turn the ignition switch to ON. With Parking range, depress the brake pedal and keep it at depressed condition. Read the DTC of body integrated unit using Subaru Select Monitor. | Is B1106 current malfunction? | Go to step 8. | Go to step 9. |
| 8 CHECK DTC. Turn the ignition switch to OFF. Disconnect the body integrated unit connector (B279) and shift lock solenoid connector (B117). Connect the disconnected connectors. Turn the ignition switch to ON. Shift into Parking range, then depress the brake pedal. Read the DTC of body integrated unit using Subaru Select Monitor. | Is B1106 current malfunction? | Go to step 4. | Go to step 9. |
| 9 CHECK CONNECTOR. Turn the ignition switch to OFF. Disconnect the body integrated unit connector (B279) and shift lock solenoid connector (B117). | Is there poor contact of connector terminal? | Repair the poor contact of the terminal or replace the harness. | It is possible that temporary poor contact occurs. |
DIAGNOSTIC PROCEDURE
Communication is unstable because of high speed CAN communication error.
Malfunction indicator light illuminates.
Scheme 36
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK DTC. Read all DTCs using the Subaru Select Monitor. READ DIAGNOSTIC TROUBLE CODE (DTC), OPERATION, Subaru Select Monitor.> | Are there any DTC other than U1201 or DTC not related to body integrated unit? | Perform the diagnosis according to DTC. | Go to step 2. |
| 2 CHECK DTC. Check DTC indicated by body integrated unit. | Is U1201 a current malfunction? | Go to step 3. | Go to step 14. |
| 3 CHECK DTC. Turn the ignition switch to OFF. Disconnect all connectors (B280, B310 or B301, B55, B136, B230, B231) that are connected to high speed CAN communication line. Connect all the disconnected connectors. Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1201 a current malfunction? | Go to step 4. | Go to step 14. |
| 4 CHECK TCM. Turn the ignition switch to OFF. Disconnect the TCM connector (B55). Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1201 a current malfunction? | Go to step 5. | Go to step 16. |
| 5 CHECK STEERING ANGLE SENSOR. NOTE: For model without VDC, Go to step 7. Turn the ignition switch to OFF. Connect the TCM connector. Disconnect the steering angle sensor connector (B231). Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1201 a current malfunction? | Go to step 6. | Go to step 17. |
| 6 CHECK YAW RATE SENSOR. Turn the ignition switch to OFF. Connect the steering angle sensor connector. Disconnect the yaw rate sensor connector (B230). Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1201 a current malfunction? | Go to step 7. | Go to step 18. |
| 7 CHECK VDC/ABS CM HARNESS. Turn the ignition switch to OFF. Connect the yaw rate sensor connector. Disconnect the VDC/ABS CM (B301 or B310) connector. Install the 120 ohms resistance to VDC/ABS CM connector terminals. Terminals Models with VDC (B310) No. 10 - No. 35: Models without VDC (B301) No. 11 - No. 26: Using the tester, measure the resistance between terminals of data link connector. Terminals (B40) No. 6 - No. 14 | Is the resistance 60 ohms? | Go to step 8. | Go to step 10. |
| 8 CHECK DTC. Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1201 a current malfunction? | Go to step 16. | Go to step 9. |
| 9 CHECK DTC. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1202 a current malfunction? | Replace the VDC/ABS CM. Ref. to REMOVAL , ABS Control Module and Hydraulic Control Unit (ABSCM & H/U). Ref. to REMOVAL , VDC Control Module and Hydraulic Control Unit (VDCCM & H/U). | Go to step 10. |
| 10 CHECK ECM. Turn the ignition switch to OFF. Connect the VDC/ABS CM. Disconnect the ECM connector (B136). install the 120 ohms resistance to ECM connector. Terminals (B136) No. 27 - No. 35: Using the tester, measure the resistance between terminals of data link connector. Connector & terminals (B40) No. 6 - No. 14 | Is the resistance 60 ohms? | Go to step 11. | Repair or replace the open circuit of harness. |
| 11 CHECK DTC. Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1201 a current malfunction? | Go to step 12. | Repair or replace the open circuit of measured related harness. |
| 12 CHECK DTC. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1202 a current malfunction? | Replace the ECM. Ref. to REMOVAL , Engine Control Module (ECM). Ref. to REMOVAL , Engine Control Module (ECM). | Go to step 13. |
| 13 CHECK DTC. Reconnect all the disconnected connectors. Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1201 a current malfunction? | Replace the body integrated unit. Ref. to REMOVAL , Body Integrated Unit. | Go to step 14. |
| 14 CHECK HARNESS. Shake the instrument harness and bulkhead harness, rear harness. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1201 a current malfunction? | Repair or replace the harness. | Go to step 15. |
| 15 CHECK CONNECTOR. Disconnect the connector used for CAN circuit. Check the connector terminal. | Is there poor contact of connector terminal? | Repair the connector terminal where poor contact exists, or replace harness. | Replace the ECM. Ref. to REMOVAL , Engine Control Module (ECM). Ref. to ENGINE CONTROL MODULE (ECM) . |
| 16 CHECK HARNESS. Using the tester, inspect the open circuit of harness and short (power supply-output short, GND-output short) between terminals of data link connector and TCM. Connector & terminals (B40) No. 14 - (B55) No. 17: (B40) No. 6 - (B55) No. 18 | Is harness normal? | Go to step 17. | Repair or replace the harness. |
| 17 CHECK HARNESS. Using the tester, inspect the open circuit of harness and short (power supply-output short, GND-output short) between terminals of data link connector and steering angle sensor. Connector & terminals (B40) No. 14 - (B231) No. 1: (B40) No. 6 - (B231) No. 2 | Is harness normal? | Go to step 18. | Repair or replace the harness. |
| 18 CHECK HARNESS. Using the tester, inspect the open circuit of harness and short (power supply-output short, GND-output short) between terminals of data link connector and yaw rate sensor. Connector & terminals (B40) No. 14 - (B230) No. 3: (B40) No. 6 - (B230) No. 2 | Is harness normal? | Replace the yaw rate sensor. Ref. to REMOVAL , Yaw Rate and G Sensor. | Repair or replace the harness. |
| NOTE |
|---|
| For model without VDC, Go to step 7. |
DIAGNOSTIC PROCEDURE
Communication with body integrated unit is not possible because of the following reasons.
- Open or power supply-output short, GND-output short occurs in CAN line.
- End resistance malfunction
- Internal error in each control module
Each warning light illuminates because the CAN communication (sending and receiving) is not normal.
Received error data from ECM.
It is possible that engine control error may occur.
Received error data from TCM.
It is possible that transmission control error may occur.
Received error data from VDC/ABS CM.
It is possible that brake control error may occur.
Not received data from ECM. (If error is in the main harness, DTC P0600 CAN communication link is input simultaneously.)
Malfunction indicator light illuminates.
Not received data from TCM.
Malfunction indicator light illuminates.
Not received data from VDC/ABS CM.
ABS warning light and VDC warning light illuminate.
Open or short in CAN-LS circuit, on ether side
No influence.
Scheme 37
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK DTC. Read the DTC of body integrated unit using Subaru Select Monitor. READ DIAGNOSTIC TROUBLE CODE (DTC), OPERATION, Subaru Select Monitor.> | Is U1300 a current malfunction? | Go to step 2. | Go to step 7. |
| 2 CHECK DTC. Disconnect all connectors (i84, i10, i88, i85 or i50) that are connected to low speed CAN communication line. Connect the disconnected connectors. Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1300 a current malfunction? | Go to step 3. | Go to step 7. |
| 3 CHECK HARNESS. Turn the ignition switch to OFF. Disconnect all connectors (i84, i10, i88, i85 or i50) that are connected to low speed CAN communication line. Using the tester, inspect the open circuit of harness and short (power supply-output short, GND-output short). Connector & terminal (i84) No. 1 - (i10) No. 27 (combination meter): (i84) No. 9 - (i10) No. 26 (combination meter): (i84) No. 1 - (i88) No. 20 (auto A/C): (i84) No. 9 - (i88) No. 19 (auto A/C): (i84) No. 1 - (i85) No. 12 (audio): (i84) No. 9 - (i85) No. 11 (audio): (i84) No. 1 - (i50) No. 18 (navigation): (i84) No. 9 - (i50) No. 6 (navigation) | Is harness normal? | Go to step 4. | Repair or replace the harness. |
| 4 CHECK AUDIO OR NAVIGATION. Connect the disconnected connectors. Disconnect the connector of navigation (i85) or audio (i50). Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1300 a current malfunction? | Go to step 5. | Repair the navigation or audio. Ref. to REMOVAL , Audio. |
| 5 CHECK AUTO A/C CONTROL MODULE. Turn the ignition switch to OFF. Connect the audio or navigation connectors. Disconnect the auto A/C control module connector (i88). Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1300 a current malfunction? | Go to step 6. | Replace the auto A/C control module. Ref. to REMOVAL , Control Unit (Auto A/C Model). |
| 6 CHECK BODY INTEGRATED UNIT. Turn the ignition switch to OFF. Connect the auto A/C control module. Replace the body integrated unit of your vehicle with the body integrated unit from other vehicle, which is working normally. Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1300 a current malfunction? | Replace the combination meter. Ref. to REMOVAL , Combination Meter. | Replace the body integrated unit. Ref. to REMOVAL , Body Integrated Unit. |
| 7 CHECK HARNESS. Turn the ignition switch to OFF. Shake the harness used for CAN communication circuit. Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1300 a current malfunction? | Repair or replace the harness. | Go to step 8. |
| 8 CHECK CONNECTOR. Turn the ignition switch to OFF. Disconnect the connector that is connected to low speed CAN circuit. | Is there poor contact at disconnected connector? | Repair the connector terminal, or replace harness. | Temporary poor contact occurs. |
DIAGNOSTIC PROCEDURE
Communication is unstable because of low speed CAN communication error.
Display error may occur in fuel gauge because the CAN communication is not transmitted (sending/receiving) normally.
Communication with body integrated unit is not possible because of the following reasons.
- Open or power supply-output short, GND-output short occurs in both CAN line.
- Internal error in each control module
Display error may occur in fuel gauge because the CAN communication is not transmitted (sending/receiving) normally.
Received error data from meter.
Defective data from combination meter occurs.
Scheme 38
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK DTC. Read the DTC of body integrated unit using Subaru Select Monitor. READ DIAGNOSTIC TROUBLE CODE (DTC), OPERATION, Subaru Select Monitor.> | Is DTC U1300 or U1302 displayed? | Perform the diagnosis according to DTC. | Go to step 2. |
| 2 CHECK DTC. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1311 a current malfunction? | Go to step 3. | Go to step 4. |
| 3 CHECK DTC. Turn the ignition switch to OFF. Disconnect the combination meter connector (i10). Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1311 a current malfunction? | Replace the combination meter. Ref. to REMOVAL , Combination Meter. | Go to step 4. |
| 4 CHECK HARNESS. Shake the harness used for low speed CAN communication circuit. Read the DTC of body integrated unit using Subaru Select Monitor. | Is U1311 a current malfunction? | Repair or replace the harness. | Go to step 5. |
| 5 CHECK CONNECTOR. Turn the ignition switch to OFF. Disconnect all connectors (i84, i10, i88, i85 or i50) that are connected to low speed CAN communication line. | Is there poor contact of connector terminal? | Repair the connector terminal, or replace harness. | Temporary poor contact occurs. |
DIAGNOSTIC PROCEDURE
Not received data from meter.
Engine may not be started.
Open or short circuit in keyless UART circuit
Door lock does not operate with keyless.
Scheme 39
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK DTC. Read the DTC of body integrated unit using Subaru Select Monitor. READ DIAGNOSTIC TROUBLE CODE (DTC), OPERATION, Subaru Select Monitor.> | Is B1500 current malfunction? | Go to step 2. | Go to step 6. |
| 2 CHECK DTC. Turn the ignition switch to OFF. Disconnect the connectors from body integrated unit and keyless entry control module. Connect the disconnected connectors. Turn the ignition switch to ON. Read the DTC of body integrated unit using Subaru Select Monitor. | Is B1500 current malfunction? | Go to step 3. | Go to step 6. |
| 3 CHECK HARNESS. Turn the ignition switch to OFF. Disconnect the connectors from body integrated unit and keyless entry control module. Using the tester, inspect the open circuit of harness and short (power supply-output short, GND-output short). Connector & terminal (i84) No. 24 - (R80) No. 3 | Is harness normal? | Go to step 4. | Repair or replace the harness. |
| 4 CHECK HARNESS. Using the tester, measure the voltage between keyless entry control module and chassis ground. Connector & terminal (R80) No. 4 (+) - Chassis ground (-) | Is the voltage battery voltage? | Go to step 5. | Check the power supply circuit for keyless entry control module. |
| 5 CHECK OPERATION. Install the keyless entry control module from other vehicle, which is working normally. Register the keyless key which is working normally. Operate the keyless key. | Is the door locking operate? | Replace the keyless entry control module. Ref. to REMOVAL , Keyless Entry Control Module. | Replace the body integrated unit. Ref. to REMOVAL , Body Integrated Unit. |
| 6 CHECK CONNECTOR. Disconnect the connectors from body integrated unit and keyless entry control module. | Is there poor contact of connector? | Repair the connector, or replace harness. | Temporary poor contact occurs. |
DIAGNOSTIC PROCEDURE
| Item | Operation | Specifications | Index | |
|---|---|---|---|---|
| YES | NO | |||
| Diagnostic code | DTC is not displayed when inspecting all DTCs. | System is normal. | Perform the diagnosis according to DTC. | |
| Engine coolant temperature | Engine coolant temperature gauge displays correctly without engine coolant temperature warning light illuminating/blinking. | System is normal. | Refer to the following to check. Engine cooling system LAN system | If three data values are different when display the current data of ECM, TCM and body integrated unit, it is possible that driving system CAN is malfunction. |
| Remaining fuel level | Fuel gauge displays correctly without low fuel warning light remaining illuminated. | System is normal. | Refer to the following to check. Combination meter system LAN system | If the values of "Fuel level resistance" and "Fuel level resistance 2" are different when display the current data of body integrated unit, it is possible that body integrated unit is malfunction. |
| ATF temperature warning light | ATF temperature warning is free from illuminating/blinking. | System is normal. | Refer to the following to check. Automatic transmission Shift lock control system LAN system | Warning light also blinks when DTC: B1106 occurs. |
| EBD warning light ABS warning light VDC warning light Hill start assist warning light | EBD warning Light/ABS warning light/VDC warning light/Hill start assist warning light are free from ON/OFF ail the time. | System is normal. | Refer to the following to check. ABS (diagnostics) VDC (diagnostics) Parking brake Combination meter system LAN system | |
| Shift position | Meter display of shift position is correct. Shift position changes when switch the shift (up/down) on manual mode. | System is normal. | Refer to the following to check. Automatic transmission Combination meter system | |
| Clearance light Low beam High beam | Clearance light/low beam/high beam illuminate correctly by switch operation. Indicator in the meter illuminates when clearance light/high beam are illuminating. | System is normal. | Refer to the following to check. Lighting system Combination meter system LAN system | |
| Fog light | Fog light illuminate correctly by operating the switch. Indicator in the meter illuminates when each fog light is illuminating. | System is normal. | Refer to the following to check. Lighting system Combination meter system LAN system | |
| DRL | DRL operates correctly. | System is normal. | Refer to the following to check. Lighting system LAN system | |
| Key interlock | Key cannot be removed in other than P range. Key can be removed in P range. | System is normal. | Refer to the following to check. Shift lock control system LAN system | |
| Shift Lock | Shift operation is normal. | System is normal. | Refer to the following to check. Shift lock control system Combination meter system LAN system | |
| Key warning switch alarm | Alarm sounds when driver's door is open with the key removed. | System is normal. | Refer to the following to check. Combination meter system LAN system | |
| Seat belt warning alarm | Indicator in the meter illuminate and alarm sounds when driver's seat belt is not worn. Indicator in the clock illuminates. When passenger's seat is occupied without passenger's seat belt worn. Alarm sounds when vehicle speed is approx. 15 km/h without seat belt fastened. | System is normal. | Refer to the following to check. Seat belt warning system Combination meter system LAN system | |
| Rear window defogger | Rear window defogger operates by operating the switch. Indicator in the switch illuminates when rear window defogger is operating. | System is normal. | Refer to the following to check. Rear window defogger A/C control module | |
| Wiper deicer | Wiper deicer operates by operating the switch. | System is normal. | Refer to the following to check. Wiper deicer system A/C control module | |
| Rear wiper | Rear wiper operates by operating the switch. | System is normal. | Refer to the following to check. Wiper and washer system | Vehicle speed response time varies depending on the condition of customization of the body integrated unit "Sedan/Wagon Setting". |
| Door lock | Lock/unlock operates by operating the central door lock switch. Rear gate opens by operating the rear gate release switch. | System is normal. | Refer to the following to check. Security and locks LAN system | Rear gate cannot open by operating the rear gate release switch when customization of the body integrated unit "Sedan/Wagon Setting" is set to "Sedan". |
| Keyless Entry | Lock/unlock operates by operating the keyless transmitter. Trunk/rear gate unlock by operating the trunk/rear gate unlock button. | System is normal. | Refer to the following to check. Security and locks LAN system | Rear gate opens up by operating the trunk/rear gate unlock button when customization of the body integrated unit "Sedan/Wagon Setting" is set to "Sedan". |
| Answer back | Answer back operates by operating lock/unlock with the keyless entry. | System is normal. | Refer to the following to check. Security and locks LAN system | |
| Room light | ON/OFF according to the operation of the door open/close, lock/unlock with the keyless entry, and ignition. | System is normal. | Refer to the following to check. Room light system Security and locks LAN system | |
| Map light | ON/OFF according to the operation of the door open/close other than rear gate, lock/unlock with the keyless entry, and ignition. | System is normal. | Refer to the following to check. Spot map light Security and locks LAN system | |
| Key illumination | ON/OFF according to the operation of the driver's side door open/close and ignition. | System is normal. | Refer to the following to check. Ignition switch illumination Security and locks LAN system | Key illumination blinks when customization of the body integrated unit "Factory or Market setting" is set to "Factory" for models with keyless entry. |
| Illumination control | Illumination volume control is available. | System is normal. | Refer to the following to check. Combination meter system LAN system | Lighting adjustment is not possible when customization of the body integrated unit "Illumination Control On/Off" is set to "Off". |
| Engine start | Engine starts normally. | System is normal. | Refer to the following to check. Engine (diagnostics) Immobilizer LAN system | |
| Vehicle security | When locked by the keyless entry, security monitor condition starts. When unlocked by the keyless entry, security is released. | System is normal. | Refer to the following to check. Security and locks LAN system | |
INSPECTION CHART
