Ignition System - Dohc/tc: Removal & Installation Subaru Impreza GD/GC/GG рестайлинг

REMOVAL

1. Spark plug: NGK-PFR6G

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. Disconnect the ground terminal from battery.
2. Remove the air cleaner lower case, see «REMOVAL»(ref-178630-S30191792662005061700000) , Air Cleaner.
3. Disconnect the connector from ignition coil.
4. Remove the ignition coil.
5. Remove the spark plugs with the spark plug sockets.

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. Disconnect the battery terminals, and then remove the battery and battery carrier.
2. Disconnect the washer motor connector.
3. Disconnect the rear window glass washer hose from washer motor, then plug connection with a suitable cap.
4. Remove the two bolts which hold the washer tank, then take the tank away from the working area.
5. Disconnect the connector from ignition coil.
6. Remove the ignition coil.
7. Remove the spark plugs with the spark plug sockets.

Direct ignition type has been adopted.

For removal procedure. See REMOVAL , Spark Plug.

INSTALLATION

Install in the reverse order of removal.

1. Tightening torque: 16 N.m (1.63 kgf-m, 11.8 ft-lb)
