Ignition System - SOHC: Removal & Installation Subaru Impreza GD/GC/GG рестайлинг

Ignition System 8 illustrations ~149 words

REMOVAL

CAUTIONAll spark plugs installed on an engine, must be of the same heat range.
Spark plugRange
ChampionRC10YC4
NGK (Alternate)BKR5E-11
NGK (Alternate)BKR6E-11

SPARK PLUG

Scheme 11

Scheme 11: RH SIDE
Scheme 11: RH SIDE

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. Disconnect the ground cable from battery.
  2. Remove the resonator chamber, see «REMOVAL»(ref-178690-S01214950542005062000000) , Resonator Chamber.
  3. Remove the spark plug cords by pulling the boot. (Do not pull the cord itself)
  4. Remove the spark plugs with spark plug sockets.

Scheme 14

Scheme 14: LH SIDE
Scheme 14: LH SIDE

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Disconnect the ground cable from battery.
  2. Remove the two bolts which hold washer tank, and then disconnect the washer motor connector.
  3. Disconnect the rear window glass washer hose from washer motor, then plug connection with a suitable cap.
  4. Hang the washer tank away from working area.
  5. Remove the spark plug cords by pulling the boot. (Do not pull the cord itself)
  6. Remove spark plugs with spark plug sockets.

INSTALLATION

  1. Install in the reverse order of removal. For tightening torques see scheme 2, COMPONENTS, General Description.
