Engine Cooling System: Removal & Installation Subaru Impreza GD/GC/GG рестайлинг

Cooling Fan 14 illustrations ~286 words

INSTALLATION

Install in the reverse order of removal.

Note. When the main fan motor assembly cannot be installed as is, loosen the sub fan motor assembly securing bolts to install it.

Scheme 95

Scheme 95: INSTALLATION
  1. Tightening torque: 4.9 N.m (0.50 kgf.m, 3.6 ft.lb)

Scheme 96

Scheme 96

Scheme 97

Scheme 97: DISASSEMBLY

Scheme 98

Scheme 98

Scheme 99

Scheme 99
  1. Remove the clip which holds motor connector onto the shroud.
  2. Remove the nut which holds fan itself onto the fan motor and shroud assembly.
  3. Remove the bolts which install fan motor onto the shroud.

Install in the reverse order of removal.

  1. Tightening torque: 4.9 N.m (0.50 kgf.m, 3.6 ft.lb)

Scheme 100

Scheme 100

Scheme 101

Scheme 101: DISASSEMBLY

Scheme 102

Scheme 102

Scheme 103

Scheme 103
  1. Remove the clip which holds motor harness onto the shroud.
  2. Remove the nut which holds fan itself onto the fan motor and shroud assembly.
  3. Remove the bolts which install fan motor onto the shroud.

Install in the reverse order of removal.

  1. Tightening torque: 4.9 N.m (0.50 kgf.m, 3.6 ft.lb)

Scheme 104

Scheme 104

REMOVAL

WARNINGThe radiator is pressurized. Wait until engine cools down before working on the radiator.

Scheme 105

Scheme 105

Scheme 106

Scheme 106
  1. Drain the coolant about 3.0 (3.2 US qt, 2.6 Imp qt). See «DRAINING OF ENGINE COOLANT»(ref-180110-S14725639022005072100000) , Replacement, Engine Coolant.
  2. Remove the air cleaner upper cover and air intake boot. See «REMOVAL»(ref-178630-S30191792662005061700000) , Air Cleaner.
  3. Remove the air cleaner element.
  4. Disconnect the engine coolant hoses from the coolant filler tank.
  5. Remove the bolts and nut which install coolant filler tank.
  6. Disconnect the engine coolant hose which connects the under side of coolant filler tank.
  7. Remove the coolant filler tank.

Scheme 107

Scheme 107: INSTALLATION
  1. Install in the reverse order of removal. Tightening torque: T1: 19 N.m (1.9 kgf.m, 13.7 ft.lb) T2: 21 N.m (2.1 kgf.m, 15.2 ft.lb)
  2. Fill engine coolant, see «FILLING OF ENGINE COOLANT»(ref-180110-S07004686282005072100000) , REPLACEMENT, Engine Coolant.

Scheme 108

Scheme 108: INSPECTION
