Engine Diagnostic Trouble Code (DTC) Detecting Criteria (H4DOTC): Diagnosis Subaru Forester SJ

Testing & Diagnostics 120 illustrations ~19434 words

OUTLINE OF DIAGNOSIS

Detect the AVCS system malfunction.

Judge NG when the amount of AVCS actual timing advance does not approach to the amount of AVCS target timing advance.

DIAGNOSTIC METHOD

When the differences of target timing advance amount and actual timing advance amount is calculated during AVCS control, and the difference per predetermined time is the specified value or larger.

  1. Abnormality Judgment

Judge as NG when the following conditions are established within the predetermined time.

Malfunction CriteriaThreshold Value
Sum(Target position - Actual position)> 4000°CA
Or
< -4000°CA

JUDGMENT VALUE

Time Needed for Diagnosis: 25 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established within the predetermined time.

Malfunction CriteriaThreshold Value
Sum(Target position - Actual position)< or = 4000°CA and > or = -4000°CA

JUDGMENT VALUE

Time Needed for Diagnosis: 25 seconds

Detect the exhaust AVCS system malfunction.

Judge NG when the amount of exhaust AVCS actual timing advance does not approach the amount of exhaust AVCS target timing advance.

When the differences of target timing advance amount and actual timing advance amount is calculated during exhaust AVCS control, and the difference per predetermined time is the specified value or larger.

  1. Abnormality Judgment

Judge as NG when the following conditions are established within the predetermined time.

Malfunction CriteriaThreshold Value
Sum(Target position - Actual position)> 4500°CA
Or
< -4500°CA

JUDGMENT VALUE

Time Needed for Diagnosis: 25 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established within the predetermined time.

Malfunction CriteriaThreshold Value
Sum(Target position - Actual position)< or = 4500°CA and > or = -4500°CA

JUDGMENT VALUE

Time Needed for Diagnosis: 25 seconds

Note. For the detection standard, refer to DTC P000A. < Ref. to DTC P000A A CAMSHAFT POSITION SLOW RESPONSE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P000B. < Ref. to DTC P000B B CAMSHAFT POSITION SLOW RESPONSE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the open/short circuit of oil control solenoid valve.

Judge as NG when the current is small even though the duty signal is large, or when the current is large even though the duty signal is small.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Diagnosis 1

Malfunction CriteriaThreshold Value
Oil control solenoid control duty> or = 99.6%
Oil control solenoid control present current< 0.306 A

JUDGMENT VALUE

Diagnosis 2

Malfunction CriteriaThreshold Value
Oil control solenoid control duty< 8%
Present current of the oil control solenoid> or = 0.306 A

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Diagnosis 1

Malfunction CriteriaThreshold Value
Target current value of the oil control solenoid> or = 0.14 A
Target current value of the oil control solenoid - oil control solenoid control current value< 0.08 A

JUDGMENT VALUE

Diagnosis 2

Malfunction CriteriaThreshold Value
Target current value of the oil control solenoid - oil control solenoid control current value< 0.08 A

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Detect the AVCS system malfunction.

Judge as NG when the conditions during which the differences of AVCS target timing advance amount and AVCS actual timing advance amount is large continues.

When the conditions during which the differences of AVCS target timing advance amount and AVCS actual timing advance amount is large continues for certain amount of time.

  1. Abnormality Judgment

Judge as NG when the following conditions are established within the predetermined time.

Malfunction CriteriaThreshold Value
Normal Vtd Vtd = VVT target position - VVT actual position> 10°CA
Intermediate lock Vtd> 10°CA

JUDGMENT VALUE

Time Needed for Diagnosis

  1. Normal: 10 seconds
  2. Intermediate lock: 2 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established within the predetermined time.

Malfunction CriteriaThreshold Value
Normal Vtd< or = 10°CA
Intermediate lock Vtd< or = 10°CA

JUDGMENT VALUE

Time Needed for Diagnosis

  1. Normal: 10 seconds
  2. Intermediate lock: 2 seconds

Detect the open/short circuit of oil control solenoid valve.

Judge as NG when the current is small even though the duty signal is large, or when the current is large even though the duty signal is small.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Diagnosis 1

Malfunction CriteriaThreshold Value
Oil control solenoid control duty> or = 99.6%
Oil control solenoid control present current< 0.306 A

JUDGMENT VALUE

Diagnosis 2

Malfunction CriteriaThreshold Value
Oil control solenoid control duty< 8%
Present current of the oil control solenoid> or = 0.306 A

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Diagnosis 1

Malfunction CriteriaThreshold Value
Target current value of the oil control solenoid> or = 0.14 A
Target current value of the oil control solenoid - oil control solenoid control current value< 0.08 A

JUDGMENT VALUE

Diagnosis 2

Malfunction CriteriaThreshold Value
Target current value of the oil control solenoid - oil control solenoid control current value< 0.08 A

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Detect the exhaust AVCS system malfunction.

Judge as NG when the conditions during which the differences of exhaust AVCS target timing advance amount and exhaust AVCS actual timing advance amount is large continues.

When the conditions during which the differences of exhaust AVCS target timing advance amount and exhaust AVCS actual timing advance amount is large continues for certain amount of time.

  1. Abnormality Judgment

Judge as NG when the following conditions are established within the predetermined time.

Malfunction CriteriaThreshold Value
Vtd Vtd = VVT target position - VVT actual position> 10°CA

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established within the predetermined time.

Malfunction CriteriaThreshold Value
Vtd< or = 10°CA

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Detect the AVCS system malfunction.

Judge as NG when standard timing advance amount is far from learning angle.

Judge as NG when the absolute value of the difference between cam signal input position and learning value is out of specification.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Crankshaft position when camshaft position sensor signal is input - Learning value> 10°CA
Camshaft position sensor signal input position< 53°CA
Or
> 112°CA

JUDGMENT VALUE

Time Needed for Diagnosis: 1 second

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

Note. Initial standard learning value is the value of crank angle initially input at the production plant. And then it will be updated every time normal judgment has been completed. Learning value will not be updated if NG judgment occurs because timing belt or chain derails suddenly in process or because wrong assembly occurs during servicing.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Crankshaft position when camshaft position sensor signal is input - Learning value< or = 10°CA
Camshaft position sensor signal input position> or = 53°CA
And
< or = 112°CA

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the exhaust AVCS system malfunction.

Judge as NG when standard timing advance amount is far from learning angle.

Judge as NG when the absolute value of the difference between cam signal input position and learning value is out of specification.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Crankshaft position when camshaft position sensor signal is input - Learning value> 10°CA
Camshaft position sensor signal input position< 78°CA
Or
> 137°CA

JUDGMENT VALUE

Time Needed for Diagnosis: 5 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

Note. Initial standard learning value is the value of crank angle initially input at the production plant. And then it will be updated every time normal judgment has been completed. Learning value will not be updated if NG judgment occurs because timing belt or chain derails suddenly in process or because wrong assembly occurs during servicing.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Crankshaft position when camshaft position sensor signal is input - Learning value< or = 10°CA
Camshaft position sensor signal input position> or = 78°CA
And
< or = 137°CA

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Note. For the detection standard, refer to DTC P0016. < Ref. to DTC P0016 CRANKSHAFT POSITION - CAMSHAFT POSITION CORRELATION (BANK1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0017. < Ref. to DTC P0017 CRANK AND CAM TIMING B SYSTEM FAILURE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0010. < Ref. to DTC P0010 "A" CAMSHAFT POSITION ACTUATOR CIRCUIT/OPEN (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0011. < Ref. to DTC P0011 INTAKE CAMSHAFT POSITION - TIMING OVER-ADVANCED OR SYSTEM PERFORMANCE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0013. < Ref. to DTC P0013 B CAMSHAFT POSITION ACTUATOR CIRCUIT/OPEN (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0014. < Ref. to DTC P0014 EXHAUST AVCS SYSTEM 1 (RANGE/PERFORMANCE) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect functional errors of the front oxygen (A/F) sensor heater.

Judge as NG when it is determined that the front oxygen (A/F) sensor impedance is large when looking at engine status such as deceleration fuel cut.

Scheme 130

Scheme 130: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Front oxygen (A/F) sensor impedance> 100 ohms

JUDGMENT VALUE

Time Needed for Diagnosis: 25 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Front oxygen (A/F) sensor impedance< or = 100 ohms

JUDGMENT VALUE

Time Needed for Diagnosis: 25 seconds

Detect front oxygen (A/F) sensor heater open or short circuit.

The front oxygen (A/F) sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.

Judge as NG when the terminal voltage remains Low.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage levelLow

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage levelHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Detect front oxygen (A/F) sensor heater open or short circuit.

The front oxygen (A/F) sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.

Judge as NG when the terminal voltage remains High.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage levelHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 2250 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage levelLow

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Detect the rear oxygen sensor heater open or short circuit.

The rear oxygen sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.

Judge as NG when the terminal voltage remains Low.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage levelLow

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage levelHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Detect the rear oxygen sensor heater open or short circuit.

The rear oxygen sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.

Judge as NG when overcurrent is detected.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output current levelHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 2250 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output current levelLow

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Detect problems in the manifold absolute pressure sensor output properties.

Judge as NG when the intake air pressure AD value is Low whereas it seemed to be High from the viewpoint of engine condition, or when it is High whereas it seemed to be Low from the engine condition.

Scheme 131

Scheme 131: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when Low side or High side becomes NG.

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Low
Intake manifold pressure (absolute pressure)< 30 kPa (225 mmHg, 8.9 inHg)
High
Intake manifold pressure (absolute pressure)> or = 100 kPa (750.1 mmHg, 29.5 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis

Low side: 5000 ms

High side: 5000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG when both Low side and High side become OK.

If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.

Malfunction CriteriaThreshold Value
Low
Intake manifold pressure (absolute pressure)> or = 30 kPa (225 mmHg, 8.9 inHg)
High
Intake manifold pressure (absolute pressure)< 100 kPa (750.1 mmHg, 29.5 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis

Low side: 5000 ms

High side: 5000 ms

Note. For the detection standard, refer to DTC P0088. < Ref. to DTC P0088 FUEL RAIL/SYSTEM PRESSURE - TOO HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the malfunction of high pressure fuel system function.

Judge as NG when actual pressure is not close to target pressure.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold ValueDTC
Target fuel pressure - Actual fuel pressure> 3300 kPa (24752.1 mmHg, 974.5 inHg)P0087
Actual fuel pressure - Target fuel pressure> 6000 kPa (45003.8 mmHg, 1771.8 inHg)P0088

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
Target fuel pressure - Actual fuel pressure< or = 3300 kPa (24752.1 mmHg, 974.5 inHg)P0087
Actual fuel pressure - Target fuel pressure< or = 6000 kPa (45003.8 mmHg, 1771.8 inHg)P0088

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Detect the malfunction of intake air temperature sensor output property.

Judge as NG when the intake air temperature is not varied whereas it seemed to be varied from the viewpoint of engine condition.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage difference between Max. and Min.< 0.02 V (Equivalent to approximately 0.5°C (0.9°F) near 25°C (77°F))

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage difference between Max. and Min.> or = 0.02 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open or short circuit of the intake air temperature sensor (integrated with manifold absolute pressure sensor).

Judge as NG if out of specification.

Scheme 132

Scheme 132: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 0.223 V

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.223 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open or short circuit of the intake air temperature sensor (integrated with manifold absolute pressure sensor).

Judge as NG if out of specification.

Scheme 133

Scheme 133: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 4.716 V

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 4.716 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of air flow sensor output properties.

Judge as a low side NG when the air flow voltage indicates a small value regardless of running in a state where the air flow voltage increases. Judge as a high side NG when the air flow voltage indicates a large value regardless of running in a state where the air flow voltage decreases. Judge air flow sensor property NG when the Low side or High side becomes NG.

Scheme 134

Scheme 134: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when Low side or High side becomes NG.

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Low
Output voltage< 1.13 V
High (1)
Output voltage> or = 1.75 V
High (2)
Fuel system diagnosisRich side malfunction
Output voltage> or = 1.55 V

JUDGMENT VALUE

Time Needed for Diagnosis

Low: 5 s

High: 10 s

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG when both Low side and High side become OK.

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Low
Output voltage> or = 1.13 V
High (1)
Output voltage< 1.75 V
High (2)
Fuel system diagnosisRich side malfunction
And
Output voltage< 1.55 V

JUDGMENT VALUE

Time Needed for Diagnosis

Low: 5 s

High: 10 s

Detect open or short circuits of the air flow sensor.

Judge as NG if out of specification.

Scheme 135

Scheme 135: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 121 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 121 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open or short circuits of the air flow sensor.

Judge as NG if out of specification.

Scheme 136

Scheme 136: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 4788 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 4788 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of manifold absolute pressure sensor.

Judge as NG if out of specification.

Scheme 137

Scheme 137: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 358 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 358 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of manifold absolute pressure sensor.

Judge as NG if out of specification.

Scheme 138

Scheme 138: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 4845 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 4845 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of intake air temperature sensor output property.

Judge as NG when the intake air temperature is not varied whereas it seemed to be varied from the viewpoint of engine condition.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage difference between Max. and Min.< 0.02 V (Equivalent to approximately 0.5°C (0.9°F) near 25°C (77°F))

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage difference between Max. and Min.> or = 0.02 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open or short circuit of the intake air temperature sensor (integrated with air flow sensor). Judge as NG if out of specification.

Scheme 139

Scheme 139: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 0.223 V

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.223 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open or short circuit of the intake air temperature sensor (integrated with air flow sensor). Judge as NG if out of specification.

Scheme 140

Scheme 140: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 4.716 V

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 4.716 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of the engine coolant temperature sensor characteristics.

When the ignition is ON after the specified period of soaking time has elapsed, compare the engine coolant temperature with intake air temperature. Judge as NG if the difference between two temperatures is larger than the predetermined value and the engine coolant temperature becomes the specified value or more.

Scheme 141

Scheme 141: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
All of the following conditions are established.
Engine coolant temperature - intake air temperature> 15°C (27°F)
Engine coolant temperature> 45°C (113°F)

JUDGMENT VALUE

Time Needed for Diagnosis: 2 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
When any one of the followings is established.
Engine coolant temperature - intake air temperature< or = 15°C (27°F)
Engine coolant temperature< or = 45°C (113°F)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the engine coolant temperature sensor.

Judge as NG if out of specification.

Scheme 142

Scheme 142: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 460 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 460 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the engine coolant temperature sensor.

Judge as NG if out of specification.

Scheme 143

Scheme 143: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 4713 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 4713 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of throttle position sensor 1.

Judge as NG if out of specification.

Scheme 144

Scheme 144: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage< 292 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage> or = 292 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of throttle position sensor 1.

Judge as NG if out of specification.

Scheme 145

Scheme 145: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage> 4693 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage< or = 4693 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of engine coolant temperature output property.

Judge as NG when the engine coolant temperature does not rise in driving conditions where it should.

Scheme 146

Scheme 146: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG if the criteria below are met.

Malfunction CriteriaThreshold Value
Engine coolant temperature< -15°C (5°F)
Timer for diagnosis after engine start> or = 300000 ms

JUDGMENT VALUE

Timer for diagnosis after engine start

40 ms + TWCNT ms (when at 40 ms)

TWCNT is shown in the following table.

Vehicle speed km/h (MPH)
0 (0)5 (3.1)10 (6.2)15 (9.3)20 (12.4)25 (15.5)30 (18.6)35 (21.7)
Lowest ECT °C (°F)35 (-31)00000000
23.5 (-10.3)00000000
23.4 (-10.1)6060606060606060
15 (5)6060606060606060

Time Needed for Diagnosis: 120 or 300 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG when the malfunction criteria below are met.

Malfunction CriteriaThreshold Value
Engine coolant temperature> or = -15°C (5°F)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect malfunctions of the thermostat function.

Judge as NG when any one of the following conditions is established.

  1. When the actual engine coolant temperature does not reach the maximum temperature necessary to perform other OBDII diagnosis and Sum (Estimated engine coolant temperature - actual engine coolant temperature) exceeded the predetermined value. (Judgment 1)
  2. When the actual engine coolant temperature does not reach the range within -11°C (-19.8°F) from the regulated temperature and Sum (Estimated engine coolant temperature - actual engine coolant temperature) exceeded the predetermined value. (Judgment 2)
  3. When the difference between the estimated coolant temperature and the actual engine coolant temperature exceeds the predetermined value, and Sum (Estimated engine coolant temperature - actual engine coolant temperature) exceeded the predetermined value. (Judgment 3)

Scheme 147

Scheme 147: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
When any one of the followings is established.
< Judgment 1 >
Actual engine coolant temperature< Value of Map 4
And
Sum (Estimated engine coolant temperature - actual engine coolant temperature)> Value of Map 5
< Judgment 2 >
Actual engine coolant temperature< Regulated temperature - Value of Map 6
And
Sum (Estimated engine coolant temperature - actual engine coolant temperature)> Value of Map 7
< Judgment 3 >
Estimated engine coolant temperature - actual engine coolant temperature> Value of Map 8
And
Sum (Estimated engine coolant temperature - actual engine coolant temperature)> Value of Map 9

JUDGMENT VALUE

Estimate ambient temperature °C (°F)7 (19.4)8 (46.4)10 (50)25 (77)
Threshold Value °C (°F)60 (140)60 (140)60 (140)60 (140)

MAP SPECIFICATION 4

Engine coolant temperature at engine starting °C (°F)7 (19.4)0 (32)10 (50)25 (77)30 (86)40 (104)
Threshold Value °C (°F)1387.5 (2497.5)1387.5 (2497.5)1387.5 (2497.5)1387.5 (2497.5)1387.5 (2497.5)961.5 (1730.7)

MAP SPECIFICATION 5

Estimate ambient temperature °C (°F)7 (19.4)8 (46.4)10 (50)25 (77)
Threshold Value °C (°F)18.6 (33.5)11.1 (20)11.1 (20)11.1 (20)

MAP SPECIFICATION 6

Engine coolant temperature at engine starting °C (°F)7 (19.4)0 (32)8 (46.4)10 (50)30 (86)35 (95)
Threshold Value °C (°F)1387.5 (2497.5)1387.5 (2497.5)1387.5 (2497.5)1387.5 (2497.5)1387.5 (2497.5)1201.9 (2163.4)

MAP SPECIFICATION 7

Estimate ambient temperature °C (°F)7 (19.4)8 (46.4)10 (50)25 (77)
Threshold Value °C (°F)11.1 (20)11.1 (20)11.1 (20)11.1 (20)

MAP SPECIFICATION 8

Engine coolant temperature at engine starting °C (°F)7 (19.4)8 (46.4)10 (50)25 (77)
Threshold Value °C (°F)1387.5 (2497.5)1387.5 (2497.5)1387.5 (2497.5)1387.5 (2497.5)

MAP SPECIFICATION 9

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
All of the following conditions are established.
< Judgment 1 >
Actual engine coolant temperature> or = Value of Map 4
And
Sum (Estimated engine coolant temperature - actual engine coolant temperature)< or = Value of Map 5
< Judgment 2 >
Actual engine coolant temperature> or = Regulated temperature - Value of Map 6
And
Sum (Estimated engine coolant temperature - actual engine coolant temperature)< or = Value of Map 7
< Judgment 3 >
Estimated engine coolant temperature - actual engine coolant temperature< or = Value of Map 8
And
Sum (Estimated engine coolant temperature - actual engine coolant temperature)< or = Value of Map 9
And
Actual engine coolant temperature> or = Regulated temperature - Value of Map 10

JUDGMENT VALUE

Estimate ambient temperature °C (°F)7 (19.4)8 (46.4)10 (50)25 (77)
Threshold Value °C (°F)18.6 (33.5)11.1 (20)11.1 (20)11.1 (20)

MAP SPECIFICATION 10

Time Needed for Diagnosis: Less than 1 second

Judge as NG, while the element impedance is low with the element current out of the range.

Scheme 148

Scheme 148: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Input current< -45 μA
Or
> 45 μA

JUDGMENT VALUE

Time Needed for Diagnosis: 3040 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Input current45 - 45 μA

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of sensor.

Judge as NG, when the element voltage is out of the specified range.

Scheme 149

Scheme 149: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Input voltage (+)< or = 1 V
Or
Input voltage (-)< or = 1 V
Or
Sensor reference voltage< or = 1 V

JUDGMENT VALUE

Time Needed for Diagnosis

Input voltage (+): 560 ms

Input voltage (-): 560 ms

Sensor reference voltage: 560 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.

Malfunction CriteriaThreshold Value
Input voltage (+)> 1 V
Input voltage (-)> 1 V
Sensor reference voltage> 1 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of sensor.

Judge as NG, when the element voltage is out of the specified range.

Scheme 150

Scheme 150: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Input voltage (+)> or = Battery voltage - 1 V
Or
Input voltage (-)> or = Battery voltage - 1 V
Or
Sensor reference voltage> or = 6.5 V

JUDGMENT VALUE

Time Needed for Diagnosis

Input voltage (+): 560 ms

Input voltage (-): 560 ms

Sensor reference voltage: 560 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.

Malfunction CriteriaThreshold Value
Input voltage (+)< Battery voltage - 1 V
Input voltage (-)< Battery voltage - 1 V
Sensor reference voltage< 6.5 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open circuits of the sensor.

Judge as NG when the element voltage is out of range, or when the malfunction signal is received from the front oxygen (A/F) sensor IC, or when the element current gets stuck.

Scheme 151

Scheme 151: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Input voltage (+)> 2.65 V
Or
Diagnostic signal of front oxygen (A/F) sensor ICMalfunction
Or
Input current45 μA - 45 μA

JUDGMENT VALUE

Time Needed for Diagnosis

Input voltage (+): 30000 ms

Diagnostic signal of front oxygen (A/F) sensor IC: 2000 ms

Input current: 2000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.

Malfunction CriteriaThreshold Value
Input voltage (+)< or = 2.65 V
Diagnostic signal of front oxygen (A/F) sensor ICNormal
Input current< -45 μA
Or
> 45 μA

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect continuity NG of the oxygen sensor. If the oxygen sensor voltage reading is not within the probable range considering the operating conditions, judge as NG.

Scheme 152

Scheme 152: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold ValueDTC
HighP0138
Sensor output voltage> or = 1.2 V
LowP0137
Sensor output voltage< 0.03 V

JUDGMENT VALUE

Time Needed for Diagnosis

High: 2500 ms

Low (1): 20000 ms

Low (2): 40000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold ValueDTC
HighP0138
Sensor output voltage< 1.2 V
LowP0137
Sensor output voltage> or = 0.03 V

JUDGMENT VALUE

Time Needed for Diagnosis

High: 2500 ms

Low (1): 20000 ms

Low (2): 40000 ms

Note. For the detection standard, refer to DTC P0137. < Ref. to DTC P0137 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the slow response of rich --> lean for rear oxygen sensor output.

When the deceleration fuel cut has occurred, detect the trouble by calculating the time when the rear oxygen sensor output passes through the predetermined range of voltages.

Judge as NG when the response time is larger than the threshold value.

Scheme 153

Scheme 153: COMPONENT DESCRIPTION

Detect the trouble by calculating the response time of the rear oxygen sensor during fuel cut.

Scheme 154

Scheme 154: DIAGNOSTIC METHOD
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Time when rear oxygen sensor voltage changed from 0.5 V to 0.2 V> 837 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 837 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Time when rear oxygen sensor voltage changed from 0.5 V to 0.2 V< or = 837 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 837 ms

Detect the slow response of lean --> rich for rear oxygen sensor output.

After the deceleration fuel cut has occurred, detect the trouble by calculating the time when the rear oxygen sensor output passes through the predetermined range of voltages.

Judge as NG when the response time is larger than the threshold value.

Scheme 155

Scheme 155: COMPONENT DESCRIPTION

Detect the trouble by calculating the response time of the rear oxygen sensor after fuel cut.

Scheme 156

Scheme 156: DIAGNOSTIC METHOD
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Time when rear oxygen sensor voltage changed from 0.3 V to 0.5 V> 4000 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 4 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Time when rear oxygen sensor voltage changed from 0.3 V to 0.5 V< or = 4000 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 4 seconds

Detect the delayed response of rear oxygen sensor output for rich --> lean.

After the deceleration fuel cut has started, detect the trouble by calculating the time when the rear oxygen sensor output decreases to the predetermined voltages.

Judge as NG when the response time is larger than the threshold value.

Scheme 157

Scheme 157: COMPONENT DESCRIPTION

Detect the trouble by calculating the time from the beginning of the fuel cut to the beginning of the rear oxygen sensor voltage starting to drop.

Scheme 158

Scheme 158: DIAGNOSTIC METHOD
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Time when rear oxygen sensor voltage changed to 0.5 V after the fuel cut started> 4000 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 4 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Time when rear oxygen sensor voltage changed to 0.5 V after the fuel cut started< or = 4000 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 4 seconds

Detect the delayed response of rear oxygen sensor output for lean --> rich.

After the deceleration fuel cut has completed, detect the trouble by calculating the time when the rear oxygen sensor output increases to the predetermined voltages.

Judge as NG when the response time is larger than the threshold value.

Scheme 159

Scheme 159: COMPONENT DESCRIPTION

Detect the trouble by calculating the time from the completion of the fuel cut to the beginning of the rear oxygen sensor voltage starting to rise.

Scheme 160

Scheme 160: DIAGNOSTIC METHOD
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
The number of times that the rear oxygen sensor voltage changed to 0.3 V after the fuel cut has completed (time counter)> 40 ms x 3000 times

JUDGMENT VALUE

Time Needed for Diagnosis: 40 ms x 3000 times

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
The number of times that the rear oxygen sensor voltage changed to 0.3 V after the fuel cut has completed (time counter)< or = 40 ms x 3000 times

JUDGMENT VALUE

Time Needed for Diagnosis: 40 ms x 3000 times

Detect the rear oxygen sensor open or short circuit. Judge as NG when the rear oxygen sensor voltage can be determined to be abnormal while observing conditions such as intake air amount and deceleration fuel cut.

Scheme 161

Scheme 161: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Minimum output voltage> 0.15 V
Or
Maximum output voltage< 0.55 V

JUDGMENT VALUE

Time Needed for Diagnosis: 90 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Minimum output voltage< or = 0.15 V
Maximum output voltage> or = 0.55 V

JUDGMENT VALUE

Time Needed for Diagnosis: 90 seconds

Detect malfunction of the rear oxygen sensor heater.

Judge as NG if it is determined that the rear oxygen sensor impedance is large by observing the engine conditions.

Scheme 162

Scheme 162: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Rear oxygen sensor heater current< Value from Map

JUDGMENT VALUE

Battery voltage (V)10.91213141516
Threshold Value (mA)330357.5385412.5440467.5

MAP SPECIFICATION

Time Needed for Diagnosis: 10 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Rear oxygen sensor heater current> or = Value from Map

JUDGMENT VALUE

Time Needed for Diagnosis: 1.4 seconds

Detect the slow response of front oxygen (A/F) sensor.

For diagnosis, detect the trouble by processing the lambda waveform in normal driving without forcibly changing the target air fuel ratio.

Scheme 163

Scheme 163: COMPONENT DESCRIPTION

DIAGNOSTIC METHOD 1

Detect the malfunction by checking "Cumulative value of time when lambda changes from lean --> rich" in comparison to "Time during which diagnosis is in progress".

Scheme 164

Scheme 164: DIAGNOSTIC METHOD 1
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
(Cumulative value of time when lambda changes from lean --> rich)/(Time during which diagnosis is in progress)< 0.38P014C
> 0.61P014D

JUDGMENT VALUE

Time Needed for Diagnosis: 120 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
(Cumulative value of time when lambda changes from lean --> rich)/(Time during which diagnosis is in progress)> or = 0.38P014C
< or = 0.61P014D

JUDGMENT VALUE

Time Needed for Diagnosis: 120 seconds

DIAGNOSTIC METHOD 2

Detect the malfunction by the cumulative value obtained from the amount of variation in lambda change.

Scheme 165

Scheme 165: DIAGNOSTIC METHOD 2
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
Cumulative value obtained from the amount of variation in lambda change Sum (lambda(n) - lambda(n-1)) - (lambda(n-1) - lambda(n-2))< Value from MapP014C and P014D

JUDGMENT VALUE

Cumulative value obtained from the amount of variation in lambda Sum lambda(n) - lambda(n-1)0.003.00
Cumulative value obtained from the amount of variation in lambda change0.002.50

MAP SPECIFICATION

Time Needed for Diagnosis: 120 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
Cumulative value obtained from the amount of variation in lambda change Sum (lambda(n) - lambda(n-1)) - (lambda(n-1) - lambda(n-2))> or = Value from MapP014C and P014D

JUDGMENT VALUE

Time Needed for Diagnosis: 120 seconds

Note. For the detection standard, refer to DTC P014C. < Ref. to DTC P014C O2 SENSOR SLOW RESPONSE - RICH TO LEAN (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the slow response of front oxygen (A/F) sensor.

For diagnosis, detect the trouble by processing the lambda waveform in normal driving without forcibly changing the target air fuel ratio.

Scheme 166

Scheme 166: COMPONENT DESCRIPTION

Detect the malfunction depending on the average value of time necessary for lambda to inverse the air fuel ratio from "Lean --> Rich --> Lean" to "Rich --> Lean --> Rich".

Scheme 167

Scheme 167: DIAGNOSTIC METHOD 1
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
Average value of time necessary for lambda to inverse the air fuel ratio to Lean --> Rich --> Lean> 100 msP015A
Average value of time necessary for lambda to inverse the air fuel ratio to Rich --> Lean --> Rich> 110 msP015B

JUDGMENT VALUE

Time Needed for Diagnosis: 100 times of inversion

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
Average value of time necessary for lambda to inverse the air fuel ratio to Lean --> Rich --> Lean< or = 100 msP015A
Average value of time necessary for lambda to inverse the air fuel ratio to Rich --> Lean --> Rich< or = 110 msP015B

JUDGMENT VALUE

Time Needed for Diagnosis: 100 times of inversion

Detect the malfunction by calculating the average amplitude of lambda.

Scheme 168

Scheme 168: DIAGNOSTIC METHOD 2
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
Average value for lambda amplitude> 0.08P015A and P015B

JUDGMENT VALUE

Time Needed for Diagnosis: 90 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
Average value for lambda amplitude< or = 0.08P015A and P015B

JUDGMENT VALUE

Time Needed for Diagnosis: 90 seconds

Note. For the detection standard, refer to DTC P015A. < Ref. to DTC P015A O2 SENSOR DELAYED RESPONSE - RICH TO LEAN (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect fuel system malfunction by the amount of main feedback control.

Fuel system is diagnosed by comparing the target air fuel ratio calculated by ECM with the actual air fuel ratio measured by sensor.

  1. Abnormality Judgment

Compare the diagnostic value with the threshold value, and if a condition meeting the criteria continues for 10 s x 3 times or more, judge that there is a fault in the fuel system.

Malfunction CriteriaThreshold Value
Faf x (1+flaf)> or = 1.35
Faf = Main feedback compensation coefficient
Flaf = main feedback learning compensation coefficient

JUDGMENT VALUE

Time Needed for Diagnosis: 10 s x 3 times

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Faf x (1+flaf)< 1.35

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Detect fuel system malfunction by the amount of main feedback control.

Fuel system is diagnosed by comparing the target air fuel ratio calculated by ECM with the actual air fuel ratio measured by sensor.

  1. Abnormality Judgment

Compare the diagnostic value with the threshold value, and if a condition meeting the criteria continues for 10 s x 3 times or more, judge that there is a fault in the fuel system.

Malfunction CriteriaThreshold Value
Faf x (1+flaf)< 0.65
Faf = Main feedback compensation coefficient
Flaf = main feedback learning compensation coefficient

JUDGMENT VALUE

Time Needed for Diagnosis: 10 s x 3 times

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK if the status that the criteria below are met continues for 10 seconds.

Malfunction CriteriaThreshold Value
Faf x (1+flaf)> or = 0.65

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Detect the signal stuck of the fuel pressure sensor.

Judge as NG when the voltage change amount per unit time of the fuel pressure sensor does not exceed the threshold value.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Change amount per unit time of fuel pressure sensor voltage< or = 3.75 V/s

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Change amount per unit time of fuel pressure sensor voltage> 3.75 V/s

JUDGMENT VALUE

Time Needed for Diagnosis: 5 seconds

Detect the open or short circuit of the fuel pressure sensor.

Judge as NG if out of specification.

Scheme 169

Scheme 169: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 0.232 V

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.232 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the fuel pressure sensor.

Judge as NG if out of specification.

Scheme 170

Scheme 170: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 3.254 V

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 3.254 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect for abnormal values in the oil temperature sensor output properties.

Judge as NG when the oil temperature does not rise even though the engine is running under a condition where it should rise.

Scheme 171

Scheme 171: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Engine oil temperature< 50°C (122°F)
After engine start oil temperature sensor characteristic diagnosis timer> or = Judgment value for after engine start oil temperature sensor characteristic diagnosis timer

JUDGMENT VALUE

After engine start oil temperature sensor characteristic diagnosis timer (timer for diagnosis)

  1. Timer stop at fuel cut
  2. During the driving conditions except a) above, timer counts up as follows.

64 ms + TOILCNT ms (when at 64 ms)

Where, TOILCNT is determined as follows

TOILCNT = 0 at idle switch ON

For TOILCNT at Idle switch off, refer to the following table.

Vehicle speed km/h (MPH)
0 (0)5 (3.1)10 (6.2)15 (9.3)20 (12.4)25 (15.5)30 (18.6)35 (21.7)
Lowest EOT °C (°F)20 (-4)016.620.324.636.150.967.280.9
10 (14)01518.622.733476173.9
0 (32)013.5172129.942.254.566.1
10 (50)010.914.318.125.634.644.753.3
20 (68)02.45.28.412.417.623.629.2

After engine start oil temperature characteristic diagnosis timer judgment value (t)

t = 1829497 - 46830 x Ti (t > or = 284107)

Ti = The lowest coolant temperature after starting the engine

Time Needed for Diagnosis: 250 - 550 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Engine oil temperature> or = 50°C (122°F)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the oil temperature sensor.

Judge as NG when outside of the judgment value.

Scheme 172

Scheme 172: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 184 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 184 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the oil temperature sensor.

Judge as NG when outside of the judgment value.

Scheme 173

Scheme 173: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 4713 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 4713 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of throttle position sensor 2.

Judge as NG if out of specification.

Scheme 174

Scheme 174: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage< 440 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage> or = 440 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of throttle position sensor 2.

Judge as NG if out of specification.

Scheme 175

Scheme 175: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage> 4904 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage< or = 4904 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of fuel pump control unit.

Judge as NG when the NG signal is sent through a diagnostic line coming from the fuel pump control unit.

Fuel pump control unit detects the open or short circuit malfunction for each line, and then sends NG signals if one of them is found NG.

Scheme 176

Scheme 176: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Fuel pump control unit output diagnosis signalLow

JUDGMENT VALUE

Time Needed for Diagnosis: 2520 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Fuel pump control unit output diagnosis signalHigh

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of high pressure fuel pump circuit function.

Judge as NG when ECM detects any malfunction in the diagnostic items listed below.

Diagnostic itemMalfunction Criteria
Power supply shortECM low side terminal voltage of the high pressure fuel pump circuit is high.
Ground shortECM low side terminal voltage of the high pressure fuel pump circuit is low.
Open circuitHigh pressure fuel pump current is low.
OvercurrentHigh pressure fuel pump current is high.
Short circuitThe time when the high pressure fuel pump current reaches the target current is short.
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Result of high pressure fuel pump circuit diagnosisMalfunction

JUDGMENT VALUE

Time Needed for Diagnosis: TDC x 75 times

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Result of high pressure fuel pump circuit diagnosisNormal

JUDGMENT VALUE

Time Needed for Diagnosis: TDC x 75 times

Detect the malfunction of wastegate control solenoid valve function.

Judge as NG when becoming high wastegate pressure.

Scheme 177

Scheme 177: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Intake manifold pressure> Value from Map

JUDGMENT VALUE

Barometric pressure (kPa (mmHg, inHg))
64 (480, 18.9)70.6 (529.5, 20.8)77.3 (579.8, 22.8)84 (630.1, 24.8)90.6 (679.6, 26.8)93.3 (699.8, 27.6)96 (720.1, 28.3)97.3 (729.8, 28.7)
Engine speed (rpm)1600159.7 (1197.9, 47.2)159.7 (1197.9, 47.2)159.7 (1197.9, 47.2)159.7 (1197.9, 47.2)159.7 (1197.9, 47.2)159.7 (1197.9, 47.2)159.7 (1197.9, 47.2)159.7 (1197.9, 47.2)
2400223.7 (1677.9, 66.1)223.7 (1677.9, 66.1)223.7 (1677.9, 66.1)223.7 (1677.9, 66.1)223.7 (1677.9, 66.1)223.7 (1677.9, 66.1)223.7 (1677.9, 66.1)223.7 (1677.9, 66.1)
3200219.2 (1644.1, 64.7)223.3 (1674.9, 65.9)229.6 (1722.1, 67.8)233.7 (1752.9, 69)233.7 (1752.9, 69)233.7 (1752.9, 69)233.7 (1752.9, 69)233.7 (1752.9, 69)
4000204.3 (1532.4, 60.3)210.7 (1580.4, 62.2)220.4 (1653.1, 65.1)236.4 (1773.2, 69.8)240.7 (1805.4, 71.1)240.7 (1805.4, 71.1)240.7 (1805.4, 71.1)240.7 (1805.4, 71.1)
4800190.9 (1431.9, 56.4)201.9 (1514.4, 59.6)213.5 (1601.4, 63)234.7 (1760.4, 69.3)245.7 (1842.9, 72.6)245.7 (1842.9, 72.6)245.7 (1842.9, 72.6)245.7 (1842.9, 72.6)
5600155.1 (1163.3, 45.8)176.5 (1323.9, 52.1)187.2 (1404.1, 55.3)208.6 (1564.6, 61.6)219.3 (1644.9, 64.8)234.3 (1757.4, 69.2)240.7 (1805.4, 71.1)240.7 (1805.4, 71.1)
KPa (mmHg, inHg)

MAP SPECIFICATION

Time Needed for Diagnosis: 2000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Intake manifold pressure< or = Map value - 26.7 kPa (200.3 mmHg, 7.9 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open or short circuit of the wastegate control solenoid valve.

Judge as NG when the terminal output voltage remains Low during outputting the duty signal.

Scheme 178

Scheme 178: COMPONENT DESCRIPTION

Detect open or short circuit of the wastegate control solenoid valve.

Judge as NG when the terminal output voltage remains Low or High during outputting the duty signal.

Scheme 179

Scheme 179: COMPONENT DESCRIPTION

Note. For the detection standard, refer to DTC P0301. < Ref. to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the presence of misfire occurrence. (Revolution fluctuation method)

Monitoring Misfire which influences exhaust deterioration (1.5 times of FTP) and catalyst damage is made obligatory by the law. Misfire affecting these two has two patterns below

  1. Intermittent misfire (The same cylinder misfires in random, or different cylinders misfire in random.): FTP 1.5 times misfire
  2. Every time misfire (The same cylinder misfires every time.): FTP 1.5 times misfire, Catalyst damage misfire

The following detecting methods are adopted for these detection.

  1. Intermittent misfire: FTP 1.5 times misfire 180° Interval Difference Method 360° Interval Difference Method (whole range) 720° Interval Difference Method (3, 000 rpm or more)
  2. Misfire every time: FTP 1.5 times misfire, Catalyst damage misfire 360° Interval Difference Method

When a misfire occurs, the engine speed will decrease and the crankshaft position speed will change. Calculate the interval difference value (diagnostic value) from crankshaft position speed by the following formula, and judge whether a misfire is occurring or not comparing the calculated result with judgment value. Count the number of misfires, if the misfire ratio is higher during 1000 revs. or 200 revs., judge corresponding cylinders as NG.

Diagnostic value calculation (Calculate from angle speed) -->Misfire detection every single ignition (Compare diagnostic value with judgment value) -->NG judgment (Misfire occurrence judgment required by the law) (Compare number of misfire with judgment value)
180° Interval Difference Method 360° Interval Difference Method 720° Interval Difference MethodFTP 1.5 times misfire NG judgment Catalyst damage misfire NG judgment

As shown in the following figure, pick a cylinder as the standard and name it omg 0. And the former crankshaft position speed is named omg 1, the second former crankshaft position speed is named omg 2, the third is named omg 3, etc.

Scheme 180

Scheme 180

Note. For the detection standard, refer to DTC P0301. < Ref. to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0301. < Ref. to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0301. < Ref. to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the open or short circuit of knock sensor.

Judge as NG if out of specification.

Scheme 181

Scheme 181: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 219 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 219 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of knock sensor.

Judge as NG if out of specification.

Scheme 182

Scheme 182: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 4732 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 4732 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of knock sensor.

Judge as NG if out of specification.

Scheme 183

Scheme 183: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 219 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 219 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of knock sensor.

Judge as NG if out of specification.

Scheme 184

Scheme 184: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 4732 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 4732 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the crankshaft position sensor.

Judge as NG when the crank signal is not input even though the starter was rotated.

Scheme 185

Scheme 185: COMPONENT DESCRIPTION

Scheme 186

Scheme 186
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Crankshaft position sensor signalNot detected

JUDGMENT VALUE

Time Needed for Diagnosis: 3000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Crankshaft position sensor signalInput exists

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect for faults in crankshaft position sensor output properties.

Judge as NG when there is a problem in the number of crankshaft signals for every revolution of crankshaft.

Scheme 187

Scheme 187: COMPONENT DESCRIPTION

Scheme 188

Scheme 188
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Diagnosis 1

Malfunction CriteriaThreshold Value
Amount of crank sensor signal during 0.5 rev of crankshaft< 14
Or
> or = 20

JUDGMENT VALUE

Diagnosis 2

Malfunction CriteriaThreshold Value
(Present value of diagnosis 1) - (Previous value of diagnosis 1)1

JUDGMENT VALUE

Time Needed for Diagnosis: 10 engine revs.

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Diagnosis 1

Malfunction CriteriaThreshold Value
Amount of crank sensor signal during 0.5 rev of crankshaft14 - 20

JUDGMENT VALUE

Diagnosis 2

Malfunction CriteriaThreshold Value
(Present value of diagnosis 1) - (Previous value of diagnosis 1)= 1

JUDGMENT VALUE

Time Needed for Diagnosis: 10 engine revs.

Detect the open or short circuit of the camshaft position sensor.

When there is no camshaft position signal input continuously, judge as NG.

Scheme 189

Scheme 189: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Diagnosis 1

Judge as NG when no input of camshaft position sensor signal in TDC remains for 14 times.

Malfunction CriteriaThreshold Value
No camshaft position sensor signal input in TDC> or = 14 times

JUDGMENT VALUE

Time Needed for Diagnosis: TDC x 10 times

Diagnosis 2

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Camshaft position sensor signalNo input

JUDGMENT VALUE

Time Needed for Diagnosis: 3000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Diagnosis 1

Judge as OK and clear the NG when the malfunction criteria below are met.

Malfunction CriteriaThreshold Value
No camshaft position sensor signal input in TDC= 0 time(s)

JUDGMENT VALUE

Time Needed for Diagnosis: TDC x 10 times

Diagnosis 2

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Camshaft position sensor signalInput exists

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of camshaft position sensor property.

Judge as NG when the number of camshaft signals remains abnormal.

Scheme 190

Scheme 190: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when the condition where the number of camshaft position sensor signals are less than 3 times during 2 revs of crankshaft.

Malfunction CriteriaThreshold Value
Amount of camshaft sensor signal during 2 revs of crankshaft3 times

JUDGMENT VALUE

Time Needed for Diagnosis: Engine two revolutions x 4 times

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG when the malfunction criteria below are met.

Malfunction CriteriaThreshold Value
Camshaft position sensor signal= 3 times

JUDGMENT VALUE

Time Needed for Diagnosis: Engine two revolutions x 4 times

Note. For the detection standard, refer to DTC P0340. < Ref. to DTC P0340 CAMSHAFT POSITION SENSOR "A" CIRCUIT (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0341. < Ref. to DTC P0341 CAMSHAFT POSITION SENSOR "A" CIRCUIT RANGE/PERFORMANCE (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Based on the self-diagnostic result of the ignition coil driving IC, judge the ignition coil driving circuit as normal or abnormal.

The ignition coil driving IC detects "no ignition" status as a malfunction.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Ignition driving IC informationMalfunction

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Ignition driving IC informationNormal

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Note. For the detection standard, refer to DTC P0351. < Ref. to DTC P0351 IGNITION COIL A PRIMARY/SECONDARY CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0351. < Ref. to DTC P0351 IGNITION COIL A PRIMARY/SECONDARY CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0351. < Ref. to DTC P0351 IGNITION COIL A PRIMARY/SECONDARY CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the open or short circuit of the camshaft position sensor.

When there is no camshaft position signal input continuously, judge as NG.

Scheme 191

Scheme 191: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when no input of camshaft position sensor signal in TDC remains for 15 times.

Malfunction CriteriaThreshold Value
No camshaft position sensor signal input in TDC> or = 15 times

JUDGMENT VALUE

Time Needed for Diagnosis: TDC x 15 times

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG when the malfunction criteria below are met.

Malfunction CriteriaThreshold Value
No camshaft position sensor signal input in TDC= 0 time(s)

JUDGMENT VALUE

Time Needed for Diagnosis: TDC x 15 times

Detect the malfunction of camshaft position sensor property.

Judge as NG when the number of camshaft signals remains abnormal.

Scheme 192

Scheme 192: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when the condition where the number of camshaft position sensor signals are less than 2 times during 2 revs of crankshaft.

Malfunction CriteriaThreshold Value
Amount of camshaft sensor signal during 2 revs of crankshaft2 times

JUDGMENT VALUE

Time Needed for Diagnosis: Engine two revolutions x 4 times

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG when the malfunction criteria below are met.

Malfunction CriteriaThreshold Value
Camshaft position sensor signal= 2 times

JUDGMENT VALUE

Time Needed for Diagnosis: Engine two revolutions x 4 times

Note. For the detection standard, refer to DTC P0365. < Ref. to DTC P0365 CAMSHAFT POSITION SENSOR "B" CIRCUIT (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0390. < Ref. to DTC P0390 CAMSHAFT POSITION SENSOR "B" CIRCUIT (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

For the detection standard, refer to DTC P0366. < Ref. to DTC P0366 CAMSHAFT POSITION SENSOR B CIRCUIT RANGE/PERFORMANCE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect EGR system malfunction.

Intake manifold pressure (negative pressure) is constant because the throttle valve is fully closed during deceleration fuel cut. At this time, when the EGR valve is opened/closed, the intake manifold pressure will change. EGR System OK/NG is judged by the range of this change.

Scheme 193

Scheme 193: COMPONENT DESCRIPTION

Measure the pressure values when the enable conditions are established, and perform diagnosis by calculating those results.

  1. Label the intake manifold pressure value as PMOF1, which is observed when enable conditions are established, and set the EGR target step to 55 steps (nearly full open).
  2. Label the intake manifold pressure value as PMON, which is observed after one second has passed since EGR target step was set to 55 steps (when the enable conditions were established), and set the EGR target step to 0.
  3. Label the intake manifold pressure as PMOF2, which is observed after one second has passed since EGR target step was set to 0 (after two seconds have passed since the enable conditions were established).
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
PMON - (PMOF1 + PMOF2)/2< 2.48 kPa (18.6 mmHg, 0.7 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 2 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

Scheme 194

Scheme 194
  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
PMON - (PMOF1 + PMOF2)/2> or = 2.48 kPa (18.6 mmHg, 0.7 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 2 seconds

Detect the deterioration of the catalyst function.

Though the front oxygen sensor output would change slowly with a new catalyst, the sensor output with a deteriorated catalyst becomes high and the inversion time is shortened.

For this reason, the catalyst diagnosis is carried out by monitoring the front oxygen sensor output and comparing it with the front oxygen (A/F) sensor output.

Scheme 195

Scheme 195: COMPONENT DESCRIPTION

After the enable conditions have been established, calculate the front oxygen (A/F) sensor lambda value deviation sum value (Sum (sglmd n - sglmd n-1 )), and rear oxygen sensor output voltage deviation sum value (Sum (ro2sad n - ro2sad n-1 )) in every 32 ms x 4 times. If the front oxygen (A/F) sensor lambda value deviation sum value (Sum (sglmd n - sglmd n - 1 )) is the predetermined value or more, calculate the diagnostic value.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is within the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sum (ro2sad n - ro2sad n - 1 )/Sum (sglmd n - sglmd n - 1 )> 9

JUDGMENT VALUE

Time Needed for Diagnosis: 30 - 55 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is within the predetermined time.

Malfunction CriteriaThreshold Value
Sum (ro2sad n - ro2sad n - 1 )/Sum (sglmd n - sglmd n - 1 )< or = 9

JUDGMENT VALUE

Time Needed for Diagnosis: 30 - 55 seconds

Detect the malfunction of purge flow by the change of ELCM pressure sensor output value before/after purge introduction.

First diagnosis

Pressure decreases when the purge is introduced compared with when the purge is not performed. By using this, judge if the purge is correctly performed. If there is no pressure decrease, go to the SECOND DIAGNOSIS .

Scheme 196

Scheme 196: First diagnosis
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
ELCM pressure value when purge is not performed - ELCM pressure value when purge is performed< 75 Pa (0.6 mmHg, 0.02 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 41 seconds

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
ELCM pressure value when purge is not performed - ELCM pressure value when purge is performed> or = 75 Pa (0.6 mmHg, 0.02 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 41 seconds

Second diagnosis

Close the ELCM switching valve, and close the fuel tank completely, and perform the forced purging. If pressure change amount is 666.1 Pa (5 mmHg, 0.2 inHg) or less, judge as malfunction of purge flow.

Scheme 197

Scheme 197: Second diagnosis
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
ELCM pressure value when purge is not performed - ELCM pressure value when purge is performed< 666.1 Pa (5 mmHg, 0.2 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 26 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
ELCM pressure value when purge is not performed - ELCM pressure value when purge is performed> or = 666.1 Pa (5 mmHg, 0.2 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 26 seconds

Detect the malfunction of ELCM pressure sensor output properties.

Judge as NG when the ELCM pressure sensor output value is largely different from the intake manifold pressure when the ignition switch is ON.

Scheme 198

Scheme 198: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
ELCM pressure sensor output value when ignition switch is ON - intake manifold pressure (absolute pressure) when ignition switch is ON> 12.4 kPa (93 mmHg, 3.7 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 0.32 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
ELCM pressure sensor output value when ignition switch is ON - intake manifold pressure (absolute pressure) when ignition switch is ON< or = 12.4 kPa (93 mmHg, 3.7 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 0.32 seconds

Detect the open or short circuit of the ELCM pressure sensor.

Judge as NG if out of specification.

Scheme 199

Scheme 199: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 919 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 919 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Detect the open or short circuit of the ELCM pressure sensor.

Judge as NG if out of specification.

Scheme 200

Scheme 200: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 4252 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 4252 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

This diagnosis judges whether the ELCM operation is normal or not, and whether the evaporative emission system has leak and clogging or not.

To purge the canister, after driving, perform the five hours soaking after ignition switch OFF in order to stabilize the evaporative gas status.* After 5, 7 or 9.5 hours passed, ECM is activated by soaking timer, and the leak check is started.

Judges whether the ELCM operation is normal or not, by measuring the reference pressure status via reference orifice (0.02 inch orifice). Judge as malfunction if the reference pressure is out of specified range. Then, judge whether there is a leak or not, by comparing the pressure (leak pressure) when the reference pressure and the evaporative emission system are in negative pressure condition. Judge as system leak in the evaporative emission system if the leak pressure is higher than reference pressure. Judge as clogging of pipe if the leak pressure becomes lower than the reference pressure within the specified amount of time.

0.02 inch leak and 0.04 inch leak can be distinguished by measuring the leak pressure.

The diagnosis results are stored inside ECM until the engine is started again.

*: When the test conditions are not met in 5 hours, perform diagnosis at elapsed time of 7 hours. When the test conditions are not met in 7 hours, perform diagnosis at elapsed time of 9.5 hours.

Diagnostic item
ELCM system (ELCM body)Vacuum pump stuck Switching valve stuck to open Switching valve stuck to close Reference orifice flow large Reference orifice flow small
Leak checkLarge leak 0.04 inch leak Fuel cap loose Fuel cap off System malfunction
Very small leak 0.02 inch leak
Clogging of pipe

Scheme 201

Scheme 201: OUTLINE OF DIAGNOSIS

Mode D (Clogging of pipe diagnosis and leak pressure measurement)

  1. Clogging of pipe Purpose: Measure the time required for the evaporative emission system to reach the target negative pressure by the vacuum pump, and detect the clogging of pipe trouble. Judge as clogging of pipe malfunction if the evaporative emission system reaches to the target negative pressure within the specified time. JUDGMENT VALUE Malfunction Criteria Threshold Value DTC Time required to reach to the target negative pressure < or = 30 s P1451 When any one of the followings is established. Reference pressure for setting the target negative pressure - Pressure sensor output value > Value of Map 4 Pressure sensor output value < -5 kPa (-37.298 mmHg, -1.5 inHg) MAP SPECIFICATION 4 Time of negative pressure introduction ms 0 100000 200000 300000 400000 500000 600000 700000 800000 900000 1000000 1100000 1200000 Reference pressure for setting the target negative pressure - Pressure sensor output value kPa (mmHg, inHg) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3)
  2. Leak pressure measurement Purpose: Measure the pressure (leak pressure) when the evaporative emission system becomes the negative pressure by the vacuum pump. Store the pressure as a leak pressure while the following conditions are met.
Conditions for storing the leak pressureThreshold Value
When any one of the followings is established.
Reference pressure for setting the target negative pressure - Pressure sensor output value> or = Value of Map 4
Pressure sensor output value< -5 kPa (-37.298 mmHg, -1.5 inHg)
Time of negative pressure introduction> or = 900000 ms

JUDGMENT VALUE

Note. For the detection standard, refer to DTC P0455. < Ref. to DTC P0455 EVAPORATIVE EMISSION SYSTEM LEAK DETECTED (LARGE LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect open or short circuit of the purge control solenoid valve.

Judge as NG when the ECM output level differs from the actual terminal level.

Scheme 202

Scheme 202: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Terminal output voltageLow

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal output voltageHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Detect open or short circuit of the purge control solenoid valve.

Judge as NG when the ECM output level differs from the actual terminal level.

Scheme 203

Scheme 203: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Terminal output currentHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 2250 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal output currentLow

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Detect malfunctions of the fuel level sensor output property.

If the fuel level does not vary in a particular driving condition/engine condition where it should, judge as NG.

Scheme 204

Scheme 204: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Max. value - min. value of fuel level< 2.2 L (0.58 US gal, 0.48 Imp gal)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Max. value - min. value of fuel level> or = 2.2 L (0.58 US gal, 0.48 Imp gal)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of fuel level sensor. Judge as NG if out of specification.

Scheme 205

Scheme 205: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 2.21 V

JUDGMENT VALUE

Time Needed for Diagnosis: 2560 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 2.21 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of fuel level sensor. Judge as NG if out of specification.

Scheme 206

Scheme 206: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 12.175 V

JUDGMENT VALUE

Time Needed for Diagnosis: 1040 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 12.175 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Judge as NG when outside of the judgment value.

Judge NG when the received data from VDCCM&H/U is abnormal vehicle speed, and the vehicle speed data is impossible.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Front ABS wheel speed sensor statusMalfunction
Either of the following is established
Front left wheel speed> or = 300 km/h (186.4 MPH)
Front right wheel speed> or = 300 km/h (186.4 MPH)

JUDGMENT VALUE

Time Needed for Diagnosis: 2560 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Front left wheel speed> 0 km/h (0 MPH)
And
< 300 km/h (186.4 MPH)
Front right wheel speed> 0 km/h (0 MPH)
And
< 300 km/h (186.4 MPH)

JUDGMENT VALUE

Time Needed for Diagnosis: 2560 ms

Detect the malfunction that actual engine speed is not close to target engine speed during idling. Judge as NG when actual engine speed is not close to target engine speed during idling.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Actual engine speed - Target engine speed< - 100 rpm

JUDGMENT VALUE

Time Needed for Diagnosis: 15 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Actual engine speed - Target engine speed> or = - 100 rpm

JUDGMENT VALUE

Time Needed for Diagnosis: 15 seconds

Detect the malfunction that actual engine speed is not close to target engine speed during idling. Judge as NG when actual engine speed is not close to target engine speed during idling.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Actual engine speed - Target engine speed> 200 rpm

JUDGMENT VALUE

Time Needed for Diagnosis: 15 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Actual engine speed - Target engine speed< or = 200 rpm

JUDGMENT VALUE

Time Needed for Diagnosis: 15 seconds

  1. When cold, the abnormality in the control of target engine speed increase is detected. (P050A)

Judge as NG if the idle speed diagnosis is NG.

  1. Idle speed diagnosis

Judge as NG when actual engine speed is not close to target engine speed at cold start.

  1. Detect malfunctions of the catalyst advanced idling retard angle control. (P050B)

Judge as NG when ECM is not controlling the angle properly during catalyst advanced idling retard angle control.

  1. Final ignition timing diagnosis

Judge as NG when actual retard amount is under the specified value at cold start.

  1. Idle speed diagnosis

Note. For the detection standard, refer to DTC P050A. < Ref. to DTC P050A COLD START IDLE AIR CONTROL SYSTEM PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect abnormal continuity in the starter SW.

Judge as ON NG when the starter SW signal remains ON.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as ON NG.

Malfunction CriteriaThreshold Value
Starter SW 1 signalON

JUDGMENT VALUE

Time Needed for Diagnosis: 60000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OFF OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Starter SW 1 signalOFF

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of battery temperature sensor.

Judge as NG if out of specification.

Scheme 207

Scheme 207: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 0.203 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.203 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of battery temperature sensor.

Judge as NG if out of specification.

Scheme 208

Scheme 208: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> or = 4.816 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage< 4.816 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open/short circuit of back-up power supply circuit.

Judge as NG when the backup power voltage is low.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Voltage of back-up power supply< 6 V

JUDGMENT VALUE

Time Needed for Diagnosis: 2560 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Voltage of back-up power supply> or = 6 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of microcomputer (RAM).

When there is a problem in the CPU normal RAM, judge as NG.

If it is possible to write data to the whole area of RAM in the initial routine, and is possible to read the same data, it is judged as OK, and if not, NG.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Write the specified value into the RAM.The written value cannot be read.

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Write the specified value into the RAM.The written value can be read.

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Judge as NG when SUM value of ROM is outside the standard value.

Judge as NG when any one of the followings is established.

  1. When the input amplifier circuit operation of throttle position sensor 1 is abnormal.
  2. When SUM value of backup RAM is outside the standard value.
  3. When the communication between main CPU and sub CPU is abnormal.
  4. If the CPU operation is abnormal (flow check).
  5. When the learning value of backup RAM is incorrect.
  6. If the CPU operation is abnormal (instruction check).
  7. If the CPU operation is abnormal (FPU check).

Judge as NG if the criteria below are met.

Malfunction CriteriaThreshold Value
(1) Minimum throttle halt position> or = 13.183°
(2) SUM value of backup RAMStandard
(3) Communication status between main CPU and sub CPUMalfunction
(4) CPU calculation result (flow check) and expected valueUnmatch
(5) Learning value comparison result of backup RAMUnmatch
(6) CPU calculation result (instruction check) and expected valueUnmatch
(7) CPU calculation result (FPU check) and expected valueUnmatch

JUDGMENT VALUE

Time Needed for Diagnosis

  1. 10 ms
  2. 10 ms
  3. 10 ms
  4. 10 ms
  5. 10 ms
  6. 10 ms
  7. 200 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

Judge as NG when the monitoring IC operation is abnormal.

  1. Abnormality Judgment

Judge as NG when one of the following conditions is established.

Malfunction CriteriaThreshold Value
(1) Communication status between main CPU and sub CPUMalfunction
(2) Sub CPU power off function diagnostic resultMalfunction

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
(1) Communication status between main CPU and sub CPUNormal
(2) Sub CPU power off function diagnostic resultNormal

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Judge as NG when the AD converter operation is abnormal.

  1. Abnormality Judgment

Judge as NG when one of the following conditions is established.

Malfunction CriteriaThreshold Value
Change amount of A/D for control< or = 0.2 V
Change amount of A/D for monitoring< or = 0.2 V

JUDGMENT VALUE

Time Needed for Diagnosis: 200 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Change amount of A/D for control> 0.2 V
Change amount of A/D for monitoring> 0.2 V

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Detect abnormal continuity in the starter SW 2.

Judge as OFF NG when the starter SW 2 signal remains OFF.

  1. Abnormality Judgment

Judge as OFF NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Starter SW2 signalNo ON experience

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as ON OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Starter SW2 signalON Experience exists

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect abnormal continuity in the starter SW 2.

Judge as ON NG when the starter SW 2 signal remains ON.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Starter SW2 signalON

JUDGMENT VALUE

Time Needed for Diagnosis

  1. Model without push button start: 30000 ms
  2. Model with push button start: 2000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OFF OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Starter SW2 signalOFF

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of fuel injector circuit function.

Judge as NG when ECM with two fuel injectors or more detects any malfunction in the diagnostic items listed below.

Diagnostic itemMalfunction Criteria
OvercurrentFuel injector current is high.
Low currentFuel injector current is low.
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Fuel injector circuit diagnosis resultMalfunction

JUDGMENT VALUE

Time Needed for Diagnosis: TDC x 50 times

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Fuel injector circuit diagnosis resultNormal

JUDGMENT VALUE

Time Needed for Diagnosis: TDC x 50 times

Judge as NG when the EEPROM operation is abnormal.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Writing result to EEPROMMalfunction

JUDGMENT VALUE

Time Needed for Diagnosis: 2 times

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Writing result to EEPROMNormal

JUDGMENT VALUE

Time Needed for Diagnosis: None

Judge as NG when there is CAN communication with the TCM and there is a MIL lighting request.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
MIL lighting request from TCMYes

JUDGMENT VALUE

Time Needed for Diagnosis: 2560 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
MIL lighting request from TCMNone

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect abnormal continuity in the starter cut relay.

Judge as NG when the starter cut relay output line is open.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Starter cut relay terminal levelLow

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Starter cut relay terminal levelHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 10 ms

Detect the open or short circuit of neutral SW.

Judge as NG when the ECM neutral terminal input differs from the reception data from TCM.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Neutral switch signal in ECM when "P"/"N" range in TCM are "OFF" and when the other switches are "ON"LOW (ON)

JUDGMENT VALUE

Time Needed for Diagnosis: 80 times

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Neutral switch signal in ECM when "P"/"N" range in TCM are "OFF" and when the other switches are "ON"HIGH (OFF)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Judge the open or short circuit of the neutral SW.

Judge as NG when the ECM neutral terminal input differs from the reception data from TCM.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Neutral switch signal in ECM when "P"/"N" range in TCM are "ON" and when the other switches are "OFF"HIGH (OFF)

JUDGMENT VALUE

Time Needed for Diagnosis: 80 times

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Neutral switch signal in ECM when "P"/"N" range in TCM are "ON" and when the other switches are "OFF"LOW (ON)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Judge as NG when the A/F sensor microcomputer operation is abnormal.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Communication status between CPU and A/F sensor microcomputerMalfunction

JUDGMENT VALUE

Time Needed for Diagnosis: 80 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK when the following conditions are established.

Malfunction CriteriaThreshold Value
Communication status between CPU and A/F sensor microcomputerNormal

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open circuit of the rear oxygen sensor. Judge as NG when the rear oxygen sensor voltage can be determined to be abnormal while observing conditions such as engine coolant temperature and deceleration fuel cut.

Scheme 209

Scheme 209: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage240 - 360 mV
Continuous time of fuel cut> or = 5000 ms
Current existing time of the oxygen sensor heater> or = 5000 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 1040 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage< or = 240 mV
Or
> 360 mV

JUDGMENT VALUE

Judge as NG when the throttle opening angle is out of specified value with ignition switch OFF.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Throttle opening angle< 4.59°
Or
> 12.60°

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Throttle opening angle4.59 - 12.60°

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of fuel injector circuit function.

Judge as NG when ECM detects any malfunction in the diagnostic items listed below.

Diagnostic itemMalfunction Criteria
Power supply shortECM low side terminal voltage of the fuel injector circuit is high.
Ground shortECM low side terminal voltage of the fuel injector circuit is low.
Open circuitFuel injector current is high.
OvercurrentFuel injector current is high.
Short circuitThe time when the fuel injector current reaches the target current is short.
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Fuel injector circuit diagnosis resultMalfunction

JUDGMENT VALUE

Time Needed for Diagnosis: TDC x 50 times

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Fuel injector circuit diagnosis resultNormal

JUDGMENT VALUE

Time Needed for Diagnosis: TDC x 50 times

Note. For the detection standard, refer to DTC P1261. < Ref. to DTC P1261 DI INJECTOR CIRCUIT/OPEN - (CYLINDER 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P1261. < Ref. to DTC P1261 DI INJECTOR CIRCUIT/OPEN - (CYLINDER 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P1261. < Ref. to DTC P1261 DI INJECTOR CIRCUIT/OPEN - (CYLINDER 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the drain filter clogging by the pressure change during purge introduction.

Judge as drain filter clogging malfunction if the pressure in the evaporative emission system piping suddenly decreases by the purging.

Scheme 210

Scheme 210: COMPONENT DESCRIPTION

Note. For the detection standard, refer to DTC P0455. < Ref. to DTC P0455 EVAPORATIVE EMISSION SYSTEM LEAK DETECTED (LARGE LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect open or short circuit of the purge control solenoid valve 2.

Judge as NG when the ECM output level differs from the actual terminal level.

Scheme 211

Scheme 211: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Terminal output voltageLow

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal output voltageHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Detect open or short circuit of the purge control solenoid valve 2.

Judge as NG when the ECM output level differs from the actual terminal level.

Scheme 212

Scheme 212: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Terminal output currentHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 2250 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal output currentLow

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Note. For the detection standard, refer to DTC P1498. < Ref. to DTC P1498 EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P1499. < Ref. to DTC P1499 EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P1498. < Ref. to DTC P1498 EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P1499. < Ref. to DTC P1499 EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P1498. < Ref. to DTC P1498 EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P1499. < Ref. to DTC P1499 EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

  1. Detects open or short circuit of EGR.
  2. Judge as NG when the ECM output level differs from the actual terminal level.

Scheme 213

Scheme 213: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Terminal voltage level when EGR operatesLow

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal voltage level when EGR operatesHigh
EGR actual step difference between Max. and Min.> or = 2 steps

JUDGMENT VALUE

Time Needed for Diagnosis: 40 ms

  1. Detects open or short circuit of EGR.
  2. Judge as NG when the ECM output level differs from the actual terminal level.

Scheme 214

Scheme 214: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Terminal current level when EGR operatesHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 2250 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal current level when EGR operatesLow
EGR actual step difference between Max. and Min.> or = 2 steps

JUDGMENT VALUE

Time Needed for Diagnosis: 40 ms

Detect the open or short circuit of battery current sensor.

Judge as NG if out of specification.

Scheme 215

Scheme 215: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 0.226 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.226 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of battery current sensor.

Judge as NG if out of specification.

Scheme 216

Scheme 216: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> or = 4.875 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage< 4.875 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the output property and malfunction of battery current sensor.

Judge as NG when there is no variation (stuck) under a condition where the battery current sensor output should have changed or when difference between output and battery current value is larger than expected (characteristics malfunction).

Scheme 217

Scheme 217: COMPONENT DESCRIPTION
  1. Abnormality Judgment
  2. Stuck

Judge as NG when the following conditions are repeated 10 times or more.

Malfunction CriteriaThreshold Value
Difference between maximum value and minimum value in output voltage< 0.07 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Characteristics malfunction (Charge side)

Within 30000 ms from "enable condition not met" to "enable condition met", judge as NG when the time required for meeting the following conditions exceeds the predetermined time.

(When NG judgment is performed, NG status is retained during that driving cycle.)

Malfunction CriteriaThreshold Value
Output voltage0 V < or = output voltage < 2.4 V
And
Battery voltage< 13.2 V

JUDGMENT VALUE

Time Needed for Diagnosis: 26000 ms

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Characteristics malfunction (Discharge side)

Within 30000 ms from "enable condition not met" to "enable condition met", judge as NG when the time required for meeting the following conditions exceeds the predetermined time.

(Within 30000 ms from "enable condition not met" to "enable condition met", the target duty > or = 60% has not been experienced.)

Malfunction CriteriaThreshold Value
Output voltage2.6 V < or = output voltage < 5 V
And
Battery voltage> or = 13.7 V

JUDGMENT VALUE

Time Needed for Diagnosis: 26000 ms

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Normality Judgment
  2. Stuck

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Difference between maximum value and minimum value in output voltage> or = 0.07 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

  1. Characteristics malfunction (Charge side)

Within 30000 ms from "enable condition not met" to "enable condition met", judge as OK and clear the NG when the time required for meeting the following conditions does not reach the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage0 V < or = output voltage < 2.4 V
And
Battery voltage< 13.2 V

JUDGMENT VALUE

Time Needed for Diagnosis: 26000 ms

  1. Characteristics malfunction (Discharge side)

Within 30000 ms from "enable condition not met" to "enable condition met", judge as OK and clear the NG when the time required for meeting the following conditions does not reach the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage2.6 V < or = output voltage < 5 V
And
Battery voltage> or = 13.7 V

JUDGMENT VALUE

Time Needed for Diagnosis: 26000 ms

DTCItemOUTLINE OF DIAGNOSIS
B1570AntennaFaulty antenna
B1571Reference Code IncompatibilityReference code incompatibility between body integrated unit and ECM
B1572IMM Circuit Failure (Except Antenna Circuit)Communication failure between body integrated unit and ECM
B1574Key Communication FailureThe body integrated unit to confirm the key (transponder) ID code has malfunction, of the transponder is faulty.
B1575Incorrect Immobilizer KeyIncorrect immobilizer key (Use of unregistered key in body integrated unit)
B1576EGI Control Module EEPROMECM malfunctioning
B1577IMM Control Module EEPROMBody integrated unit malfunctioning
B1578Meter FailureReference code incompatibility between combination meter and body integrated unit

Judge as NG when the conditions for the outline of the diagnosis of the top are established.

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the malfunction of tumble generator valve motor function.

Judge open fixing malfunction when the opening degree is large even after finishing the tumble generator valve closing driving.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Tumble generator valve opening> or = 57 deg

JUDGMENT VALUE

Time Needed for Diagnosis: 3000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Tumble generator valve opening< 57 deg

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of tumble generator valve motor function.

Judge open fixing malfunction when the opening degree is large even after finishing the tumble generator valve closing driving.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Tumble generator valve opening> or = 57 deg

JUDGMENT VALUE

Time Needed for Diagnosis: 3000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Tumble generator valve opening< 57 deg

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of tumble generator valve motor function.

Judge close fixing malfunction when the opening degree is small even after finishing the tumble generator valve open driving.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Tumble generator valve opening< 57 deg

JUDGMENT VALUE

Time Needed for Diagnosis: 3000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Tumble generator valve opening> or = 57 deg

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of tumble generator valve motor function.

Judge close fixing malfunction when the opening degree is small even after finishing the tumble generator valve open driving.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Tumble generator valve opening< 57 deg

JUDGMENT VALUE

Time Needed for Diagnosis: 3000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Tumble generator valve opening> or = 57 deg

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of tumble generator valve motor.

Judge as NG when the overcurrent signal is sent from IC after tumble generator valve driving IC diagnosis.

Scheme 218

Scheme 218: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output current levelHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 320 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output current levelLow
Tumble generator valve output duty> or = 5.2%

JUDGMENT VALUE

Time Needed for Diagnosis: 320 ms

Detect the open or short circuit of tumble generator valve motor.

Judge as NG when the overcurrent signal is sent from IC after tumble generator valve driving IC diagnosis.

Scheme 219

Scheme 219: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output current levelHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 320 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output current levelLow
Tumble generator valve output duty> or = 5.2%

JUDGMENT VALUE

Time Needed for Diagnosis: 320 ms

Detect open or short circuit of tumble generator valve position sensor.

Judge as NG if out of specification.

Scheme 220

Scheme 220: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 0.213 V

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.213 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open or short circuit of tumble generator valve position sensor.

Judge as NG if out of specification.

Scheme 221

Scheme 221: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 4.467 V

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 4.467 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open or short circuit of tumble generator valve position sensor.

Judge as NG if out of specification.

Scheme 222

Scheme 222: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 0.213 V

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.213 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open or short circuit of tumble generator valve position sensor.

Judge as NG if out of specification.

Scheme 223

Scheme 223: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 4.467 V

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 4.467 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of fuel system from the size of the sub feedback learning value.

Control the sub feedback learning and judge as NG when the learning value is in the lean zone.

Scheme 224

Scheme 224: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sub feedback learning value< -0.073

JUDGMENT VALUE

Time Needed for Diagnosis: 1 s x 1 time

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Sub feedback learning value> or = -0.073

JUDGMENT VALUE

Time Needed for Diagnosis: 1 second

Detect the malfunction of fuel system from the size of the sub feedback learning value.

Sub feedback learning is being performed. When the learning value goes to the rich side, judge as NG.

Scheme 225

Scheme 225: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sub feedback learning value> 0.024

JUDGMENT VALUE

Time Needed for Diagnosis: 1 s x 1 time

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Sub feedback learning value< or = 0.024

JUDGMENT VALUE

Time Needed for Diagnosis: 1 second

In the diagnosis with ignition switch ON, judge as NG when the opening angle with the throttle driven to close direction is out of the specified range.

Scheme 226

Scheme 226: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Throttle opening angle when driven to close direction> or = 29.9°

JUDGMENT VALUE

Time Needed for Diagnosis: 190 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Throttle opening angle when driven to close direction< 29.9°

JUDGMENT VALUE

Time Needed for Diagnosis: 190 ms

Judge as NG when the electronic throttle control power is not supplied even when ECM sets the electric control throttle relay to ON, or when the monitored electronic throttle control relay does not switch to OFF even when ECM sets the electronic throttle control relay to OFF.

Scheme 227

Scheme 227: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
< For electronic throttle control power supply >
Electronic throttle control power voltage< 6 V
< For electronic throttle control relay monitor >
Electronic throttle control relay monitor voltage< or = 1.5 V

JUDGMENT VALUE

Time Needed for Diagnosis: 510 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
< For electronic throttle control power supply >
Electronic throttle control power voltage> or = 6 V
< For electronic throttle control relay monitor >
Electronic throttle control relay monitor voltage> 1.5 V

JUDGMENT VALUE

Time Needed for Diagnosis: 510 ms

Judge as NG when the monitored electronic throttle control relay does not switch to ON even when ECM sets the electric control throttle relay to ON.

Scheme 228

Scheme 228: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Electronic throttle control relay monitor voltage> or = 6 V

JUDGMENT VALUE

Time Needed for Diagnosis: 510 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Electronic throttle control relay monitor voltage< 6 V

JUDGMENT VALUE

Time Needed for Diagnosis: 510 ms

Judge as NG when full close point learning cannot conducted or abnormal value is detected.

Scheme 229

Scheme 229: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Throttle opening angle when the ignition switch is ON - Throttle minimum stop position< 3.088° (sensor 1) < 3.090° (sensor 2)

JUDGMENT VALUE

Time Needed for Diagnosis: 200 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Throttle opening angle when the ignition switch is ON - Throttle minimum stop position> or = 3.088° (sensor 1) > or = 3.090° (sensor 2)

JUDGMENT VALUE

Time Needed for Diagnosis: 2 ms

Judge as NG when the throttle is open stuck, or when the difference between actual throttle opening angle and estimated opening angle is out of range. Judge as NG when any one of the six items for diagnosis is applied.

Throttle open stuck

  1. Throttle opening angle is out of range
  2. Intake air amount is out of range

When the difference between actual throttle opening angle and estimated opening angle is out of range

  1. All time monitoring
  2. Actual opening angle change amount is small
  3. Actual opening angle change amount is large
  4. Actual opening angle does not change

Judge as NG if the criteria below are met.

ItemMalfunction CriteriaThreshold Value
Throttle opening angle is out of rangeThrottle opening angle> or = 14.4°
Intake air amount is out of rangeAmount of intake air> 19.16 g/s (0.68 oz/s)
All time monitoringDifference between actual throttle opening angle and estimated opening angle> or = 5°
Actual opening angle change amount is smallDifference between actual throttle opening angle and estimated opening angle> or = 2°
Actual opening angle change amount is largeDifference between actual throttle opening angle and estimated opening angle> or = 5°
Actual opening angle does not changeDifference between actual throttle opening angle and estimated opening angle> or = 0.248°

JUDGMENT VALUE

ItemTime
Throttle opening angle is out of range200 ms
Intake air amount is out of range200 ms
All time monitoring2000 ms
Actual opening angle change amount is small1000 ms
Actual opening angle change amount is large500 ms
Actual opening angle does not change1000 ms

TIME NEEDED FOR DIAGNOSIS REFERENCE

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

Detect the open or short circuit of accelerator pedal position sensor 1.

Judge as NG if out of specification.

Scheme 230

Scheme 230: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage< 539 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage> or = 539 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of accelerator pedal position sensor 1.

Judge as NG if out of specification.

Scheme 231

Scheme 231: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage> 4768 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage< or = 4768 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of accelerator pedal position sensor 2.

Judge as NG if out of specification.

Scheme 232

Scheme 232: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage< 539 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage> or = 539 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of accelerator pedal position sensor 2.

Judge as NG if out of specification.

Scheme 233

Scheme 233: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage> 4768 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage< or = 4768 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Judge as NG when the signal level of throttle position sensor 1 is different from the throttle position sensor 2.

Scheme 234

Scheme 234: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Signal difference between two sensors> 18.812°

JUDGMENT VALUE

Time Needed for Diagnosis: 120 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Signal difference between two sensors< or = 18.812°

JUDGMENT VALUE

Time Needed for Diagnosis: 10 ms

Judge as NG when the signal level of throttle position sensor 1 is different from the throttle position sensor 2.

Scheme 235

Scheme 235: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Signal difference between two sensorsWithin NG range of Details of Judgment value

JUDGMENT VALUE

Scheme 236

Scheme 236: Details of Judgment Value

Time Needed for Diagnosis: 120 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Signal difference between two sensorsWithin OK range of Details of Judgment value

JUDGMENT VALUE

Time Needed for Diagnosis: 120 ms

Detect the open/short circuit of injector power supply circuit and injector booster circuit.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Diagnosis 1

Malfunction CriteriaThreshold Value
Injector power supply voltage< 6 V or > 17.2 V

JUDGMENT VALUE

Diagnosis 2

Malfunction CriteriaThreshold Value
Injector booster power supply voltage< 6 V or > 70.72 V

JUDGMENT VALUE

Time Needed for Diagnosis

  1. Diagnosis 1: 1000 ms
  2. Diagnosis 2: 280 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Diagnosis 1

Malfunction CriteriaThreshold Value
Injector power supply voltage6 - 17.2 V

JUDGMENT VALUE

Diagnosis 2

Malfunction CriteriaThreshold Value
Injector booster power supply voltage6 - 70.72 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect that lambda value remains low.

Judge as NG when lambda value is determined as abnormal in accordance with driving conditions such as intake air amount, sub feedback control, and front oxygen (A/F) sensor lambda value and rear oxygen sensor voltage value.

lambda value = Actual air fuel ratio/Theoretical air fuel ratio

lambda > 1: Lean

lambda < 1: Rich

Scheme 237

Scheme 237: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Lambda value< 0.85
Rear oxygen sensor voltage value< or = 150 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 10000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Lambda value> or = 0.85
Rear oxygen sensor voltage value> 150 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 10000 ms

Detect that lambda value remains high.

Judge as NG when lambda value is determined as abnormal in accordance with driving conditions such as intake air amount, sub feedback control, and front oxygen (A/F) sensor lambda value and rear oxygen sensor voltage value.

lambda value = Actual air fuel ratio/Theoretical air fuel ratio

lambda > 1: Lean

lambda < 1: Rich

Scheme 238

Scheme 238: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Lambda value> 1.15
Rear oxygen sensor voltage value> or = 550 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 10000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Lambda value< or = 1.15
Rear oxygen sensor voltage value< 550 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 10000 ms

This diagnostic monitor performs a functional check of the fuel system to determine an air-fuel ratio cylinder imbalance.

This diagnosis is composed of two monitors.

The outline of "monitor A1" is as follows. When an air-fuel ratio cylinder imbalance occurs, the primary oxygen sensor output signal will oscillate with increased amplitude. This monitor utilizes this behavior to make a diagnosis. The monitor integrates the difference between the amplification value and the mean value of the first oxygen sensor output signal and compares it to a threshold to make a judgment.

The outline of "monitor B1" is as follows. Similarly, when an imbalance occurs, the engine speed also fluctuates with increased amplitude. This monitor utilizes this behavior to make a diagnosis. For reference, it should be noted that this imbalance monitor method is actually similar to the current misfire diagnostic monitor, and the parameter "domg360" (units: degrees CA) is shared between the imbalance and misfire monitors. The imbalance monitor is performed during idle condition when the engine is warm. The monitor integrates the count of "domg360" which exceeds a threshold in 1000 revolution.

When both the "monitor A1" value and the "monitor B1" value exceed a predetermined threshold, this monitor determines a malfunction and stores a fault code.

Judge as NG when Monitor A1 and Monitor B1 are both NG, and when either is OK, judge as OK.

  1. Abnormality Judgment

Detect the malfunction of barometric pressure sensor output property.

Judge as NG when the barometric pressure sensor output is largely different from the intake manifold pressure at engine start.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Barometric pressure - Intake manifold pressure> or = 12.815 kPa (96.12 mmHg, 3.78 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 3.2 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Barometric pressure - Intake manifold pressure< 12.815 kPa (96.12 mmHg, 3.78 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 3.2 seconds

Detect the open/short circuit of the barometric pressure sensor.

Judge as NG if out of specification.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 1952 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 1952 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open/short circuit of the barometric pressure sensor.

Judge as NG if out of specification.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> 4469 mV

JUDGMENT VALUE

Time Needed for Diagnosis: 520 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< or = 4469 mV

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the ELCM vacuum pump.

Judge as NG if out of specification.

Scheme 239

Scheme 239: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Terminal output voltage when ECM outputs OFF signalLow

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal output voltage when ECM outputs OFF signalHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Detect the open or short circuit of the ELCM vacuum pump.

Judge as NG if out of specification.

Scheme 240

Scheme 240: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Terminal output current when ECM outputs ON signalHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 2250 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal output current when ECM outputs ON signalLow

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Note. For the detection standard, refer to DTC P0455. < Ref. to DTC P0455 EVAPORATIVE EMISSION SYSTEM LEAK DETECTED (LARGE LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the open or short circuit of the ELCM switching valve.

Judge as NG if out of specification.

Scheme 241

Scheme 241: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Terminal output voltage when ECM outputs OFF signalLow

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal output voltage when ECM outputs OFF signalHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Detect the open or short circuit of the ELCM switching valve.

Judge as NG if out of specification.

Scheme 242

Scheme 242: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Terminal output current when ECM outputs ON signalHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 2250 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal output current when ECM outputs ON signalLow

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Confirm the engine off timer accuracy by comparing engine off timer and power supply IC timer after ignition switch is turned to OFF.

This diagnosis consists of the following six cases. Judge as NG when in any one of the following cases, abnormality is detected.

Case numberDiagnosis functionTime Needed for Diagnosis
Case #1Diagnose the difference between wake-up request time and power supply IC timer.Less than 1 second
Case #2Diagnose the time in power supply IC timer before wake up.Less than 1 second
Case #3Diagnose the communication error between main CPU and sub CPU.2 s
Case #4Diagnose the communication error between main CPU and power supply IC.2 s
Case #5Diagnose the operation status abnormality in main CPU and sub CPU.2 s
Case #6Diagnose the ignition switch status abnormality in main CPU and sub CPU.2 s

Scheme 243

Scheme 243

Note. Normal mode: Main relay and ignition switch is ON. Wake-up mode: In soaking

< Case #1 >

Judge as abnormal in engine off timer or power supply IC timer when the difference between wake-up request time and power supply IC timer exceeds the threshold value.

When the sub CPU is faulty, wake-up timing is either advancing or retarding compared with normal timing.

Scheme 244

Scheme 244: DIAGNOSTIC METHOD

Processed in order Step 1 through Step 3.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
(Power supply IC timer) - (Wake-up request time)/Wake-up request time> 0.24

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK when the following conditions are established.

Malfunction CriteriaThreshold Value
(Power supply IC timer) - (Wake-up request time)/Wake-up request time< or = 0.24

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

< Case #2 >

Judge as abnormal in engine off timer when the power supply IC timer exceeds the wake-up request time before wake up.

When case #1 is not performed, perform case #2.

Scheme 245

Scheme 245

Processed in order Step 1 through Step 3.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
{(Power supply IC timer) - (Wake-up request time)}/Wake-up request time> 0.24

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK when the following conditions are established.

Malfunction CriteriaThreshold Value
{(Power supply IC timer) - (Wake-up request time)}/Wake-up request time< or = 0.24

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

< Case #3 >

Diagnose the communication error between main CPU and sub CPU.

Judge as NG when the wake-up time required from main CPU and the wake-up time received from sub CPU are different.

Scheme 246

Scheme 246
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Wake-up time required by main CPUWake-up time sent back by sub CPU

JUDGMENT VALUE

Time Needed for Diagnosis: 2 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK when the following conditions are established.

Malfunction CriteriaThreshold Value
Wake-up time required by main CPU= Wake-up time sent back by sub CPU

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

< Case #4 >

Diagnose the communication error between main CPU and power supply IC.

Judge as NG when the signal required by main CPU and the signal received from power supply IC are different.

Scheme 247

Scheme 247
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Signal required by main CPUSignal received from power supply IC

JUDGMENT VALUE

Time Needed for Diagnosis: 2 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK when the following conditions are established.

Malfunction CriteriaThreshold Value
Signal required by main CPU= Signal received from power supply IC

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

< Case #5 >

On main CPU and sub CPU, there are two operation status: "normal mode" and "wake-up mode".

Perform diagnosis for CPU operation status abnormality by detecting the difference in operating status of main CPU and sub CPU.

Judge as NG when main CPU and sub CPU is different in operating status.

Scheme 248

Scheme 248
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Operating status of main CPUOperating status of sub CPU

JUDGMENT VALUE

Time Needed for Diagnosis: 2 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK when the following conditions are established.

Malfunction CriteriaThreshold Value
Operating status of main CPU= Operating status of sub CPU

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

< Case #6 >

Perform diagnosis for ignition switch status abnormality by detecting the difference in ignition switch status (ON or OFF) of main CPU and sub CPU.

Judge as NG when main CPU and sub CPU are different in ignition switch status.

Scheme 249

Scheme 249
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Ignition switch status of main CPUIgnition switch status of sub CPU

JUDGMENT VALUE

Time Needed for Diagnosis: 2 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK when the following conditions are established.

Malfunction CriteriaThreshold Value
Ignition switch status of main CPU= Ignition switch status of sub CPU

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect malfunction of CAN communication.

Judge as NG when CAN communication failure has occurred.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Bus off flag or error warning flagSet (error)

JUDGMENT VALUE

Time Needed for Diagnosis: 436 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Bus off flag or error warning flagClear (No error)

JUDGMENT VALUE

Time Needed for Diagnosis: 1040 ms

Detect malfunction of CAN communication.

Judge as NG when CAN communication failure between TCM, VDC CM and combination meter has occurred.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
ID received from control module connected to CANNone during 500 milliseconds

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
ID received from control module connected to CANYes

JUDGMENT VALUE

Time Needed for Diagnosis: 1040 ms

Note. For the detection standard, refer to DTC U0101. < Ref. to DTC U0101 LOST COMMUNICATION WITH TCM , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC U0101. < Ref. to DTC U0101 LOST COMMUNICATION WITH TCM , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect malfunction of CAN communication.

Judge as NG when data received from TCM, VDC CM and combination meter is not normal.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Data updated from control module connected to CANNone during 2000 milliseconds

JUDGMENT VALUE

Time Needed for Diagnosis: 2 seconds

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Data updated from control module connected to CANYes

JUDGMENT VALUE

Time Needed for Diagnosis: 1040 ms

Note. For the detection standard, refer to DTC U0402. < Ref. to DTC U0402 INVALID DATA RECEIVED FROM TCM , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC U0402. < Ref. to DTC U0402 INVALID DATA RECEIVED FROM TCM , Diagnostic Trouble Code (DTC) Detecting Criteria. >
