OUTLINE OF DIAGNOSIS

Detect the AVCS system malfunction.

Judge NG when the amount of AVCS actual timing advance does not approach to the amount of AVCS target timing advance.

DIAGNOSTIC METHOD

When the differences of target timing advance amount and actual timing advance amount is calculated during AVCS control, and the difference per predetermined time is the specified value or larger.

  1. Abnormality Judgment

Judge as NG when the following conditions are established within the predetermined time.

Malfunction CriteriaThreshold Value
Sum(Target position - Actual position)> 4000 °CA (Bank 1)
> 4000 °CA (Bank 2)
Or
Sum(Target position - Actual position)< -4000 °CA (Bank 1)
< -4000 °CA (Bank 2)

JUDGMENT VALUE

Time Needed for Diagnosis: 25000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established within the predetermined time.

Malfunction CriteriaThreshold Value
Sum(Target position - Actual position)< or = 4000 °CA (Bank 1)
< or = 4000 °CA (Bank 2)
And
> or = -4000 °CA (Bank 1)
> or = -4000 °CA (Bank 2)

JUDGMENT VALUE

Time Needed for Diagnosis: 25000 ms

Note. For the detection standard, refer to P000A. < Ref. to DTC P000A A CAMSHAFT POSITION SLOW RESPONSE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect open or short circuit of the oil control solenoid.

Judge as NG when the current is small even though the duty signal is large.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9 V
Oil control solenoid control duty> or = 99.61 %
Oil control solenoid control present current< 0.306 A

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9 V
Target current value of the oil control solenoid> or = 0.14 A
Target current value of the oil control solenoid - oil control solenoid control current value< 0.08 A

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Detect the AVCS system malfunction.

Judge as NG when the conditions during which the differences of AVCS target timing advance amount and AVCS actual timing advance amount is large continues.

When the conditions during which the differences of AVCS target timing advance amount and AVCS actual timing advance amount is large continues for certain amount of time.

  1. Abnormality Judgment

Judge as NG when the following conditions are established within the predetermined time.

Malfunction CriteriaThreshold Value
(Target position - Actual position)> 10 °CA
Or
< -10 °CA

JUDGMENT VALUE

Time Needed for Diagnosis: 5000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established within the predetermined time.

Malfunction CriteriaThreshold Value
(Target position - Actual position)< or = 10 °CA
And
> or = -10 °CA

JUDGMENT VALUE

Time Needed for Diagnosis: 5000 ms

Detect the AVCS system malfunction.

Judge as NG when standard timing advance amount is far from learning angle.

Judge as NG when the absolute value of the difference between cam signal input position and learning value is out of specification.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Crankshaft position when camshaft position sensor signal is input - Learning value> 10 °CA

JUDGMENT VALUE

Time Needed for Diagnosis: 5000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

Note. Initial standard learning value is the value of crank angle initially input at the production plant. And then it will be updated every time normal judgment has been completed. Learning value will not be updated if NG judgment occurs because timing belt or chain derails suddenly in process or because wrong assembly occurs during servicing.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Crankshaft position when camshaft position sensor signal is input - Learning value< or = 10 °CA

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Note. For the detection standard, refer to DTC P0016. < Ref. to DTC P0016 CRANKSHAFT POSITION - CAMSHAFT POSITION CORRELATION (BANK1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0010. < Ref. to DTC P0010 "A" CAMSHAFT POSITION ACTUATOR CIRCUIT/OPEN (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0011. < Ref. to DTC P0011 INTAKE CAMSHAFT POSITION - TIMING OVER-ADVANCED OR SYSTEM PERFORMANCE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect functional errors of the front oxygen (A/F) sensor heater.

Judge as NG when it is determined that the front oxygen (A/F) sensor impedance is large when looking at engine status such as deceleration fuel cut.

Scheme 2

Scheme 2: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Front oxygen (A/F) sensor impedance> 87 ohms

JUDGMENT VALUE

Time Needed for Diagnosis: 10000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Front oxygen (A/F) sensor impedance< or = 87 ohms

JUDGMENT VALUE

Time Needed for Diagnosis: 10000 ms

Detect front oxygen (A/F) sensor heater open or short circuit.

The front oxygen (A/F) sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.

Judge as NG when the terminal voltage remains Low.

Scheme 3

Scheme 3: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage levelLow
Front oxygen (A/F) sensor heater control duty< 87.5 %

JUDGMENT VALUE

Time Needed for Diagnosis: 4 ms x 250 time(s)

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage levelHigh

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect front oxygen (A/F) sensor heater open or short circuit.

The front oxygen (A/F) sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.

Judge as NG when the terminal voltage remains High.

Scheme 4

Scheme 4: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage levelHigh
Front oxygen (A/F) sensor heater control duty> or = 12.5 %

JUDGMENT VALUE

Time Needed for Diagnosis: 4 ms x 500 time(s)

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage levelLow

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the rear oxygen sensor heater open or short circuit.

The rear oxygen sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.

Judge as NG when the terminal voltage remains Low.

Scheme 5

Scheme 5: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage levelLow
Rear oxygen sensor heater control duty< 75 %

JUDGMENT VALUE

Time Needed for Diagnosis: 8 ms x 1250 time(s)

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage levelHigh

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the rear oxygen sensor heater open or short circuit.

The rear oxygen sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.

Judge as NG when the terminal voltage remains High.

Scheme 6

Scheme 6: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage levelHigh
Rear oxygen sensor heater control duty> or = 20 %

JUDGMENT VALUE

Time Needed for Diagnosis: 8 ms x 1250 time(s)

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage levelLow

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect problems in the intake manifold pressure sensor output properties.

Judge as NG when the intake air pressure AD value is Low whereas it seemed to be High from the viewpoint of engine condition, or when it is High whereas it seemed to be Low from the engine condition.

Scheme 7

Scheme 7: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when Low side or High side becomes NG.

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Low
Engine speed< 2500 rpm
Throttle position> or = 12 °
Output voltage< 1.46 V
Engine load> 0.6 g/rev (0.02 oz/rev)
High
Engine speed525 rpm - 900 rpm
Throttle position< 5.7 °
Output voltage> or = 3.5 V
Engine load< 0.44 g/rev (0.02 oz/rev)

JUDGMENT VALUE

Time Needed for Diagnosis

Low side: 5000 ms

High side: 10000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG when both Low side and High side become OK.

If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.

Malfunction CriteriaThreshold Value
Low
Engine speed< 2500 rpm
Throttle position> or = 12 °
Output voltage> or = 1.46 V
Engine load> 0.6 g/rev (0.02 oz/rev)
High
Engine speed525 rpm - 900 rpm
Throttle position< 5.7 °
Output voltage< 3.5 V
Engine load< 0.44 g/rev (0.02 oz/rev)

JUDGMENT VALUE

Time Needed for Diagnosis

Low side: Less than 1 second

High side: Less than 1 second

Detect the malfunction of air flow sensor output properties.

Judge as a low side NG when the air flow voltage indicates a small value regardless of running in a state where the air flow voltage increases. Judge as a high side NG when the air flow voltage indicates a large value regardless of running in a state where the air flow voltage decreases. Judge air flow sensor property NG when the Low side or High side becomes NG.

Scheme 8

Scheme 8: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when Low side or High side becomes NG.

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Low
Output voltage< 1.22 V
Engine speed> or = 1500 rpm
Throttle opening angle> or = 12 °
Intake manifold pressure> or = 73.3 kPa (550 mmHg, 21.7 inHg)
High (1)
Output voltage> or = 2.1 V
Engine speed525 rpm - 900 rpm
Throttle opening angle< 5.7 °
Intake manifold pressure> or = 58.7 kPa (440 mmHg, 17.3 inHg)
High (2)
Output voltage> or = 2.1 V
Engine speed525 rpm - 900 rpm
Throttle opening angle< 5.7 °
Intake manifold pressure> or = 58.7 kPa (440 mmHg, 17.3 inHg)
Fuel system diagnosisRich side malfunction

JUDGMENT VALUE

Time Needed for Diagnosis

Low: 5000 ms

High: 10000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG when both Low side and High side become OK.

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Low
Output voltage> or = 1.22 V
Engine speed> or = 1500 rpm
Throttle opening angle> or = 12 °
Intake manifold pressure> or = 73.3 kPa (550 mmHg, 21.7 inHg)
High
Output voltage< 2.1 V
Engine speed525 rpm - 900 rpm
Throttle opening angle< 5.7 °
Intake manifold pressure< 58.7 kPa (440 mmHg, 17.3 inHg)
Fuel system diagnosisRich side normal

JUDGMENT VALUE

Time Needed for Diagnosis

Low: Less than 1 second

High: Less than 1 second

Detect open or short circuits of the air flow sensor.

Judge as NG if out of specification.

Scheme 9

Scheme 9: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< or = 0.127 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> 0.127 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open or short circuits of the air flow sensor.

Judge as NG if out of specification.

Scheme 10

Scheme 10: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> or = 4.43 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< 4.43 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of intake manifold pressure sensor.

Judge as NG if out of specification.

Scheme 11

Scheme 11: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< or = 0.608 V

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> 0.608 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of intake manifold pressure sensor.

Judge as NG if out of specification.

Scheme 12

Scheme 12: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> or = 3.906 V

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< 3.906 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of intake air temperature sensor output property.

Judge as NG when the intake air temperature is not varied whereas it seemed to be varied from the viewpoint of engine condition.

Scheme 13

Scheme 13: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage difference between Max. and Min.< 0.02 V(Equivalent to approximately 0.5°C (0.9°F) near 25°C)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage difference between Max. and Min.> or = 0.02 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open or short circuit of the intake air temperature sensor.

Judge as NG if out of specification.

Scheme 14

Scheme 14: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 0.4 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.4 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open or short circuit of the intake air temperature sensor.

Judge as NG if out of specification.

Scheme 15

Scheme 15: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> or = 4.707 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< 4.707 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of the engine coolant temperature sensor characteristics.

When the ignition is ON after the specified period of soaking time has elapsed, compare the engine coolant temperature with intake air temperature. Judge as NG if the difference between two temperatures is larger than the predetermined value and the engine coolant temperature becomes the specified value or more.

Scheme 16

Scheme 16: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
All of the following conditions are established.
Engine coolant temperature - intake air temperature> 15°C (27°F)
Engine coolant temperature> 45 °C (113 °F)

JUDGMENT VALUE

Time Needed for Diagnosis: 512 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
When any one of the followings is established.
Engine coolant temperature - intake air temperature< or = 15°C (27°F)
Engine coolant temperature< or = 45 °C (113 °F)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the engine coolant temperature sensor.

Judge as NG if out of specification.

Scheme 17

Scheme 17: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment
Malfunction CriteriaThreshold Value
Output voltage< 0.47 V

JUDGMENT VALUE

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.47 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the engine coolant temperature sensor.

Judge as NG if out of specification.

Scheme 18

Scheme 18: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> or = 4.698 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< 4.698 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of throttle position sensor 1.

Judge as NG if out of specification.

Scheme 19

Scheme 19: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage< or = 0.267 V

JUDGMENT VALUE

Time Needed for Diagnosis: 24 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage> 0.267 V

JUDGMENT VALUE

Time Needed for Diagnosis: 24 ms

Detect the open or short circuit of throttle position sensor 1.

Judge as NG if out of specification.

Scheme 20

Scheme 20: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage> or = 4.727 V

JUDGMENT VALUE

Time Needed for Diagnosis: 24 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage< 4.727 V

JUDGMENT VALUE

Time Needed for Diagnosis: 24 ms

Detect the malfunction of engine coolant temperature output property.

Judge as NG when the engine coolant temperature does not rise in driving conditions where it should.

Scheme 21

Scheme 21: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG if the criteria below are met.

Malfunction CriteriaThreshold Value
Engine coolant temperature< -15 °C (5 °F)
Timer for diagnosis after engine start> or = 299968 ms

JUDGMENT VALUE

Timer for diagnosis after engine start

64 ms + TWCNT ms (when at 64 ms)

TWCNT is shown in the following table.

Vehicle speed km/h (MPH)
0 (0)8 (5)16 (9.9)24 (14.9)32 (19.9)40 (24.9)48 (29.8)56 (34.8)
Lowest engine coolant temperature °C (°F)35 (-31)00000000
23.5 (-10.3)00000000
23.4 (-10.1)9696969696969696
15 (5)9696969696969696

Time Needed for Diagnosis: 120 or 300 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG when the malfunction criteria below are met.

Malfunction CriteriaThreshold Value
Engine coolant temperature> or = -15 °C (5 °F)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect malfunctions of the thermostat function.

Judge as NG when any one of the following conditions is established.

  1. When the actual engine coolant temperature does not reach the maximum temperature necessary to perform other OBDII diagnosis and Sum (Estimated engine coolant temperature - actual engine coolant temperature) exceeded the predetermined value. (Judgment 1)
  2. When the actual engine coolant temperature does not reach the range within -11°C (-19.8°F) from the regulated temperature and Sum (Estimated engine coolant temperature - actual engine coolant temperature) exceeded the predetermined value. (Judgment 2)
  3. When the difference between the estimated coolant temperature and the actual engine coolant temperature exceeds the predetermined value, and Sum (Estimated engine coolant temperature - actual engine coolant temperature) exceeded the predetermined value. (Judgment 3)

Scheme 22

Scheme 22: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
When any one of the followings is established.
< Judgment 1 >
Actual engine coolant temperature< Value of Map 4
And
Sum (Estimated engine coolant temperature - actual engine coolant temperature)> Value of Map 5
< Judgment 2 >
Actual engine coolant temperature< Regulated temperature - Value of Map 6
And
Sum (Estimated engine coolant temperature - actual engine coolant temperature)> Value of Map 7
< Judgment 3 >
Estimated engine coolant temperature - actual engine coolant temperature> Value of Map 8
And
Sum (Estimated engine coolant temperature - actual engine coolant temperature)> Value of Map 9

JUDGMENT VALUE

Estimate ambient temperature °C (°F)7 (19.4)8 (46.4)10 (50)25 (77)
Threshold Value °C (°F)70 (158)70 (158)70 (158)70 (158)

MAP SPECIFICATION 4

Engine coolant temperature at engine starting °C (°F)7 (19.4)0 (32)8 (46.4)10 (50)30 (86)40 (104)
Threshold Value °C (°F)1731.6 (3116.9)1731.6 (3116.9)1731.6 (3116.9)1731.6 (3116.9)1731.6 (3116.9)1200 (2160)

MAP SPECIFICATION 5

Estimate ambient temperature °C (°F)7 (19.4)8 (46.4)10 (50)25 (77)
Threshold Value °C (°F)17.9 (32.2)11.1 (20)11.1 (20)11.1 (20)

MAP SPECIFICATION 6

Engine coolant temperature at engine starting °C (°F)7 (19.4)0 (32)8 (46.4)10 (50)30 (86)35 (95)
Threshold Value °C (°F)1731.6 (3116.9)1731.6 (3116.9)1731.6 (3116.9)1731.6 (3116.9)1731.6 (3116.9)1500 (2700)

MAP SPECIFICATION 7

Estimate ambient temperature °C (°F)7 (19.4)8 (46.4)10 (50)25 (77)
Threshold Value °C (°F)11.1 (20)11.1 (20)11.1 (20)11.1 (20)

MAP SPECIFICATION 8

Engine coolant temperature at engine starting °C (°F)7 (19.4)8 (46.4)10 (50)25 (77)
Threshold Value °C (°F)1731.6 (3116.9)1731.6 (3116.9)1731.6 (3116.9)1731.6 (3116.9)

MAP SPECIFICATION 9

Time Needed for Diagnosis: 300 - 700 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
All of the following conditions are established.
< Judgment 1 >
Actual engine coolant temperature> or = Value of Map 4
And
Sum (Estimated engine coolant temperature - actual engine coolant temperature)< or = Value of Map 5
< Judgment 2 >
Actual engine coolant temperature> or = Regulated temperature - Value of Map 6
And
Sum (Estimated engine coolant temperature - actual engine coolant temperature)< or = Value of Map 7
< Judgment 3 >
Estimated engine coolant temperature - actual engine coolant temperature< or = Value of Map 8
And
Sum (Estimated engine coolant temperature - actual engine coolant temperature)< or = Value of Map 9
And
Actual engine coolant temperature> or = Regulated temperature - Value of Map 10

JUDGMENT VALUE

Estimate ambient temperature °C (°F)7 (19.4)8 (46.4)10 (50)25 (77)
Threshold Value °C (°F)20.3 (36.54)11.1 (20)11.1 (20)11.1 (20)

MAP SPECIFICATION 10

Time Needed for Diagnosis: 300 - 700 seconds

Detect the open or short circuit of sensor.

Judge as NG, when the element voltage is out of the specified range.

Scheme 23

Scheme 23: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Input voltage (+)< 0.4 V
Or
Input voltage (-)< 0.1 V
Or
Input voltage (+) - Input voltage (-)< 0.4 V

JUDGMENT VALUE

Time Needed for Diagnosis

Input voltage (+): 1000 ms

Input voltage (-): 1000 ms

Input voltage (+) - Input voltage (-): 1000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Input voltage (+)> or = 0.4 V
Input voltage (-)> or = 0.1 V
Input voltage (+) - Input voltage (-)> or = 0.4 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of sensor.

Judge as NG, when the element voltage is out of the specified range.

Scheme 24

Scheme 24: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Input voltage (+)> 4.7 V
Or
Input voltage (-)> 4.7 V

JUDGMENT VALUE

Time Needed for Diagnosis

Input voltage (+): 1000 ms

Input voltage (-): 1000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Input voltage (+)< or = 4.7 V
Input voltage (-)< or = 4.7 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open circuits of the sensor.

Judge as NG when the impedance of the element is large.

Scheme 25

Scheme 25: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9 V
Time of heater control duty at 70 % or more> or = 36000 ms
Front oxygen (A/F) sensor impedance.> 450 ohms

JUDGMENT VALUE

Time Needed for Diagnosis: 5000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9 V
Front oxygen (A/F) sensor impedance.< or = 450 ohms

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect continuity NG of the oxygen sensor. If the oxygen sensor voltage reading is not within the probable range considering the operating conditions, judge as NG.

Scheme 26

Scheme 26: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold ValueDTC
HighP0138
Sensor output voltage> 1.2 V
LowP0137
Sensor output voltage< 0.03 V

JUDGMENT VALUE

Time Needed for Diagnosis

High: 2500 ms

Low (1): 20000 ms

Low (2): 40000 ms

Low (3): Value from Map

Fuel cut time (ms)0200010000
Time Needed for Diagnosis (ms)400004000060000

MAP SPECIFICATION

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold ValueDTC
HighP0138
Sensor output voltage< or = 1.2 V
LowP0137
Sensor output voltage> or = 0.03 V

JUDGMENT VALUE

Time Needed for Diagnosis

High: Less than 1 second

Low (1): Less than 1 second

Low (2): Less than 1 second

Low (3): Less than 1 second

Note. For the detection standard, refer to DTC P0137. < Ref. to DTC P0137 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the slow response of rich --> lean for rear oxygen sensor output.

When the deceleration fuel cut has occurred, detect the trouble by calculating the time when the rear oxygen sensor output passes through the predetermined range of voltages.

Judge as NG when the response time is larger than the threshold value.

Scheme 27

Scheme 27: COMPONENT DESCRIPTION

Detect the trouble by calculating the response time of the rear oxygen sensor during fuel cut.

Scheme 28

Scheme 28: DIAGNOSTIC METHOD
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Time when rear oxygen sensor voltage changed from 0.5 V to 0.2 V.> 491 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Time when rear oxygen sensor voltage changed from 0.5 V to 0.2 V.< or = 491 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Detect the slow response of lean --> rich for rear oxygen sensor output.

After the deceleration fuel cut has occurred, detect the trouble by calculating the time when the rear oxygen sensor output passes through the predetermined range of voltages.

Judge as NG when the response time is larger than the threshold value.

Scheme 29

Scheme 29: COMPONENT DESCRIPTION

Detect the trouble by calculating the response time of the rear oxygen sensor after fuel cut.

Scheme 30

Scheme 30: DIAGNOSTIC METHOD
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Time when rear oxygen sensor voltage changed from 0.3 V to 0.5 V.> 4000 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Time when rear oxygen sensor voltage changed from 0.3 V to 0.5 V.< or = 4000 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Detect the delayed response of rear oxygen sensor output for rich --> lean.

After the deceleration fuel cut has started, detect the trouble by calculating the time when the rear oxygen sensor output decreases to the predetermined voltages.

Judge as NG when the response time is larger than the threshold value.

Scheme 31

Scheme 31: COMPONENT DESCRIPTION

Detect the trouble by calculating the time from the beginning of the fuel cut to the beginning of the rear oxygen sensor voltage starting to drop.

Scheme 32

Scheme 32: DIAGNOSTIC METHOD
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Time when rear oxygen sensor voltage changed to 0.5 V after the fuel cut started.> 4000 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Time when rear oxygen sensor voltage changed to 0.5 V after the fuel cut started.< or = 4000 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Detect the delayed response of rear oxygen sensor output for lean --> rich.

After the deceleration fuel cut has completed, detect the trouble by calculating the time when the rear oxygen sensor output increases to the predetermined voltages.

Judge as NG when the response time is larger than the threshold value.

Scheme 33

Scheme 33: COMPONENT DESCRIPTION

Detect the trouble by calculating the time from the completion of the fuel cut to the beginning of the rear oxygen sensor voltage starting to rise.

Scheme 34

Scheme 34: DIAGNOSTIC METHOD
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
The number of times that the rear oxygen sensor voltage changed to 0.3 V after the fuel cut has completed (time counter)> 3750 time(s)

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
The number of times that the rear oxygen sensor voltage changed to 0.3 V after the fuel cut has completed (time counter)< or = 3750 time(s)

JUDGMENT VALUE

Time Needed for Diagnosis: 10 seconds

Detect the rear oxygen sensor open or short circuit. Judge as NG when the rear oxygen sensor voltage can be determined to be abnormal considering conditions such as intake air amount, engine coolant temperature, main feedback control and deceleration fuel cut.

Scheme 35

Scheme 35: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Minimum output voltage> 0.15 V
Or
Maximum output voltage< 0.55 V

JUDGMENT VALUE

Time Needed for Diagnosis: 90000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Diagnosis of the rear oxygen sensor voltage low sideIncomplete
Minimum output voltage< or = 0.15 V
Maximum output voltage> or = 0.55 V

JUDGMENT VALUE

Detect the malfunction of rear oxygen sensor heater.

While observing the engine condition, judge as NG if the rear oxygen sensor impedance is great.

Scheme 36

Scheme 36: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output terminal for heater characteristics failure detectionLow

JUDGMENT VALUE

Time Needed for Diagnosis: 4 ms x 2500 time(s)

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output terminal for heater characteristics failure detectionHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 4 ms x 2500 time(s)

Detect the slow response of front oxygen (A/F) sensor.

For diagnosis, detect the trouble by processing the lambda waveform in normal driving without forcibly changing the target air fuel ratio.

Scheme 37

Scheme 37: COMPONENT DESCRIPTION

DIAGNOSTIC METHOD 1

Detect the malfunction by checking "Cumulative value of time when lambda changes from lean --> rich" in comparison to "Time during which diagnosis is in progress".

Scheme 38

Scheme 38: DIAGNOSTIC METHOD 1
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
(Cumulative value of time when lambda changes from lean --> rich)/(Time during which diagnosis is in progress)< 0.35 (CVT model) < 0.39 (MT model)P014C
> 0.65 (CVT model) > 0.59 (MT model)P014D

JUDGMENT VALUE

Time Needed for Diagnosis: 90 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
(Cumulative value of time when lambda changes from lean --> rich)/(Time during which diagnosis is in progress)> or = 0.35 (CVT model) > or = 0.39 (MT model)P014C
< or = 0.65 (CVT model) < or = 0.59 (MT model)P014D

JUDGMENT VALUE

Time Needed for Diagnosis: 90 seconds

DIAGNOSTIC METHOD 2

Detect the malfunction by the cumulative value obtained from the amount of variation in lambda change.

Scheme 39

Scheme 39: DIAGNOSTIC METHOD 2
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
Cumulative value obtained from the amount of variation in lambda change Sum (lambda(n) - lambda(n-1)) - (lambda(n-1) - lambda(n-2))< Value from MapP014C and P014D

JUDGMENT VALUE

Cumulative value obtained from the amount of variation in lambda Sum lambda(n) - lambda(n-1)0.005.00
Cumulative value obtained from the amount of variation in lambda change0.003.00

MAP SPECIFICATION (CVT MODEL EXCEPT FOR PZEV)

Cumulative value obtained from the amount of variation in lambda Sum lambda(n) - lambda(n-1)0.003.00
Cumulative value obtained from the amount of variation in lambda change0.009.00

MAP SPECIFICATION (MT MODEL EXCEPT FOR PZEV)

Cumulative value obtained from the amount of variation in lambda Sum lambda(n) - lambda(n-1)0.003.50
Cumulative value obtained from the amount of variation in lambda change0.003.50

MAP SPECIFICATION (PZEV CVT MODEL)

Cumulative value obtained from the amount of variation in lambda Sum lambda(n) - lambda(n-1)0.002.004.00
Cumulative value obtained from the amount of variation in lambda change0.007.009.00

MAP SPECIFICATION (PZEV MT MODEL)

Time Needed for Diagnosis: 90 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
Cumulative value obtained from the amount of variation in lambda change Sum (lambda(n) - lambda(n-1)) - (lambda(n-1) - lambda(n-2))> or = Value from MapP014C and P014D

JUDGMENT VALUE

Time Needed for Diagnosis: 90 seconds

Note. For the detection standard, refer to DTC P014C. < Ref. to DTC P014C O2 SENSOR SLOW RESPONSE - RICH TO LEAN (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the slow response of front oxygen (A/F) sensor.

For diagnosis, detect the trouble by processing the lambda waveform in normal driving without forcibly changing the target air fuel ratio.

Scheme 40

Scheme 40: COMPONENT DESCRIPTION

Detect the malfunction depending on the average value of time necessary for lambda to inverse the air fuel ratio from "Lean --> Rich --> Lean" to "Rich --> Lean --> Rich".

Scheme 41

Scheme 41: DIAGNOSTIC METHOD 1
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
Average value of time necessary for lambda to inverse the air fuel ratio to Lean --> Rich --> Lean> 150 ms (CVT model except for PZEV) > 130 ms (MT model except for PZEV) > 150 ms (PZEV CVT model) > 170 ms (PZEV MT model)P015A
Average value of time necessary for lambda to inverse the air fuel ratio to Rich --> Lean --> Rich> 350 ms (CVT model except for PZEV) > 170 ms (MT model except for PZEV) > 200 ms (PZEV CVT model) > 150 ms (PZEV MT model)P015B

JUDGMENT VALUE

Time Needed for Diagnosis: 50 times of inversion

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
Average value of time necessary for lambda to inverse the air fuel ratio to Lean --> Rich --> Lean< or = 150 ms (CVT model except for PZEV) < or = 130 ms (MT model except for PZEV) < or = 150 ms (PZEV CVT model) < or = 170 ms (PZEV MT model)P015A
Average value of time necessary for lambda to inverse the air fuel ratio to Rich --> Lean --> Rich< or = 350 ms (CVT model except for PZEV) < or = 170 ms (MT model except for PZEV) < or = 200 ms (PZEV CVT model) < or = 150 ms (PZEV MT model)P015B

JUDGMENT VALUE

Time Needed for Diagnosis: 50 times of inversion

Detect the malfunction by calculating the average amplitude of lambda.

Scheme 42

Scheme 42: DIAGNOSTIC METHOD 2
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
Average value for lambda amplitude> 0.07 (CVT model) > 0.1 (MT model)P015A and P015B

JUDGMENT VALUE

Time Needed for Diagnosis: 11250 time(s) x 8 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
Average value for lambda amplitude< or = 0.07 (CVT model) < or = 0.1 (MT model)P015A and P015B

JUDGMENT VALUE

Time Needed for Diagnosis: 11250 time(s) x 8 ms

DIAGNOSIS METHOD 3 (MT MODEL ONLY)

Change STFT (A/F compensation value) by interruption, and measure the reaction time of lambda value. When A/F sensor malfunctions, the reaction time takes longer than at normal condition. In this case, judge as abnormal.

Scheme 43

Scheme 43: DIAGNOSIS METHOD 3 (MT MODEL ONLY)

Measure reaction time (t1, t2, t3) and reaction time (t4, t5, t6). Use the average value of the reaction time to obtain the diagnostic value.

Scheme 44

Scheme 44
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
(t1 + t2 + t3)/3> 820 ms (except for PZEV model) > 800 ms (PZEV model)P015A and P015B
And
(t4 + t5 + t6)/3> 820 ms (except for PZEV model) > 800 ms (PZEV model)

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms x [1 time(s)/2] + 1000 ms x 3 time(s) + 500 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold ValueDTC
(t1 + t2 + t3)/3< or = 820 ms (except for PZEV model) < or = 800 ms (PZEV model)P015A and P015B
Or
(t4 + t5 + t6)/3< or = 820 ms (except for PZEV model) < or = 800 ms (PZEV model)

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms x [1 time(s)/2] + 1000 ms x 3 time(s) + 500 ms

Note. For the detection standard, refer to DTC P015A. < Ref. to DTC P015A O2 SENSOR DELAYED RESPONSE - RICH TO LEAN (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect fuel system malfunction by the amount of main feedback control.

Fuel system is diagnosed by comparing the target air fuel ratio calculated by ECM with the actual air fuel ratio measured by sensor.

  1. Abnormality Judgment

Compare the diagnostic value (fsobd) with the threshold value, and if a condition meeting the malfunction criteria below continues for 10 s x 3 time(s) or more, judge that there is a fault in the fuel system.

Malfunction CriteriaThreshold Value
Fsobd = (sglmd - tglmda) + faf + flaf> or = Value from Map 2
In this case: sglmd = measured lambda
Tglmda = target lambda
Faf = main feedback compensation coefficient (every 64 milliseconds)
Flaf = main feedback learning compensation coefficient

JUDGMENT VALUE

Amount of air (g (oz)/s)0 (0)3.2 (0.11)6.4 (0.23)9.6 (0.34)12.8 (0.45)16 (0.56)19.2 (0.68)
FsobdL1 (%)1.41.41.3321.251.251.251.25

MAP SPECIFICATION 2

Time Needed for Diagnosis: 10 s x 3 time(s)

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Fsobd = (sglmd - tglmda) + faf + flaf< 1.15

JUDGMENT VALUE

Time Needed for Diagnosis: 10 s

Detect fuel system malfunction by the amount of main feedback control.

Diagnostic method

Fuel system is diagnosed by comparing the target air fuel ratio calculated by ECM with the actual air fuel ratio measured by sensor.

  1. Abnormality Judgment

Compare the diagnostic value (fsobd) with the threshold value, and if a condition meeting the malfunction criteria below continues for 10 s x 3 time(s) or more, judge that there is a fault in the fuel system.

Malfunction CriteriaThreshold Value
Fsobd = (sglmd - tglmda) + faf + flaf< Value of Map 2
In this case: sglmd = measured lambda
Tglmda = target lambda
Faf = main feedback compensation coefficient (every 64 milliseconds)
Flaf = main feedback learning compensation coefficient

JUDGMENT VALUE

Amount of air (g (oz)/s)0 (0)3.2 (0.11)6.4 (0.23)9.6 (0.34)12.8 (0.45)16 (0.56)19.2 (0.68)
FsobdL1 (%)0.60.60.6680.7350.7350.7350.735

MAP SPECIFICATION 2

Time Needed for Diagnosis: 10 s x 3 time(s)

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK if the status that the criteria below are met continues for 10 seconds.

Malfunction CriteriaThreshold Value
Fsobd = (sglmd - tglmda) + faf + flaf> or = 0.85

JUDGMENT VALUE

Time Needed for Diagnosis: 10 s

Detect for abnormal values in the oil temperature sensor output properties.

Judge as NG when the oil temperature does not rise even though the engine is running under a condition where it should rise.

Scheme 45

Scheme 45: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Engine oil temperature< 40 °C (104 °F)
After engine start oil temperature sensor characteristic diagnosis timer> or = Judgment value for after engine start oil temperature sensor characteristic diagnosis timer

JUDGMENT VALUE

After engine start oil temperature sensor characteristic diagnosis timer (timer for diagnosis)

  1. Timer stop at fuel cut
  2. During the driving conditions except a) above, timer counts up as follows.

64 ms + TOILCNT ms (when at 64 ms)

Where, TOILCNT is determined as follows

TOILCNT = 0 at idle switch ON

For TOILCNT at Idle switch off, refer to the following table.

Vehicle speed km/h (MPH)
0 (0)8 (5)16 (9.9)24 (14.9)32 (19.9)40 (24.9)48 (29.8)56 (34.8)
Lowest engine oil temperature °C (°F)20 (-4)026.54632.52539.35957.69681.469107.490129.459
10 (14)023.94529.75336.39052.76675.21197.658118.256
0 (32)021.56427.21533.67347.87267.55587.207105.833
10 (50)017.46422.84428.99240.99355.37971.44585.303
30 (86)03.8408.32013.44019.84028.16037.76046.720

After engine start oil temperature characteristic diagnosis timer judgment value (t)

t = 1631442 - 46424 x Ti (t > or = 238722)

Ti = The lowest engine oil temperature after starting the engine

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Engine oil temperature> or = 40 °C (104 °F)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the oil temperature sensor.

Judge as NG when outside of the judgment value.

Scheme 46

Scheme 46: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 0.203 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.203 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the oil temperature sensor.

Judge as NG when outside of the judgment value.

Scheme 47

Scheme 47: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> or = 4.698 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< 4.698 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Based on the self-diagnostic result of the injector driving IC, judge the injector driving circuit as normal or abnormal.

Injector driving IC detects the status of "fuel remains injected" or "fuel is not injected" as a malfunction.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Injector driving IC informationMalfunction

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Injector driving IC informationNormal

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Note. For the detection standard, refer to DTC P0201. < Ref. to DTC P0201 INJECTOR #1 , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0201. < Ref. to DTC P0201 INJECTOR #1 , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0201. < Ref. to DTC P0201 INJECTOR #1 , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the open or short circuit of throttle position sensor 2.

Judge as NG if out of specification.

Scheme 48

Scheme 48: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage< or = 1.133 V

JUDGMENT VALUE

Time Needed for Diagnosis: 24 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage> 1.133 V

JUDGMENT VALUE

Time Needed for Diagnosis: 24 ms

Detect the open or short circuit of throttle position sensor 2.

Judge as NG if out of specification.

Scheme 49

Scheme 49: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage> or = 4.772 V

JUDGMENT VALUE

Time Needed for Diagnosis: 24 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage< 4.772 V

JUDGMENT VALUE

Time Needed for Diagnosis: 24 ms

Note. For the detection standard, refer to DTC P0301. < Ref. to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the presence of misfire occurrence. (Revolution fluctuation method)

Monitoring Misfire which influences exhaust deterioration (1.5 times of FTP) and catalyst damage is made obligatory by the law. Misfire affecting these two has two patterns below

  1. Intermittent misfire (The same cylinder misfires in random, or different cylinders misfire in random.): FTP 1.5 times misfire
  2. Every time misfire (The same cylinder misfires every time.): FTP 1.5 times misfire, Catalyst damage misfire

The following detecting methods are adopted for these detection.

  1. Intermittent misfire: FTP 1.5 times misfire 180° Interval Difference Method (MT: 1, 800 rpm or less; CVT: None) 360° Interval Difference Method (whole range) 720° Interval Difference Method (3, 000 rpm or more)
  2. Misfire every time: FTP 1.5 times misfire, Catalyst damage misfire
  1. 360° Interval Difference Method

When a misfire occurs, the engine speed will decrease and the crankshaft position speed will change. Calculate the interval difference value (diagnostic value) from crankshaft position speed by the following formula, and judge whether a misfire is occurring or not comparing the calculated result with judgment value. Count the number of misfires, if the misfire ratio is higher during 1000 revs. or 200 revs., judge corresponding cylinders as NG.

Diagnostic value calculation (Calculate from angle speed) -->Misfire detection every single ignition (Compare diagnostic value with judgment value) -->NG judgment (Misfire occurrence judgment required by the law) (Compare number of misfire with judgment value)
180° Interval Difference Method 360° Interval Difference Method 720° Interval Difference MethodFTP 1.5 times misfire NG judgment Catalyst damage misfire NG judgment

As shown in the following figure, pick a cylinder as the standard and name it omg 0. And the former crankshaft position speed is named omg 1, the second former crankshaft position speed is named omg 2, the third is named omg 3, etc.

Scheme 50

Scheme 50

Note. For the detection standard, refer to DTC P0301. < Ref. to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0301. < Ref. to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0301. < Ref. to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the open or short circuit of knock sensor.

Judge as NG if out of specification.

Scheme 51

Scheme 51: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 0.154 V

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.154 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of knock sensor.

Judge as NG if out of specification.

Scheme 52

Scheme 52: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> or = 4.838 V

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< 4.838 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the crankshaft position sensor.

Judge as NG when the crank signal is not input even though the starter was rotated.

Scheme 53

Scheme 53: COMPONENT DESCRIPTION

Scheme 54

Scheme 54
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Starter switchON
Crankshaft position sensor signalNot detected
Battery voltage> or = 8 V

JUDGMENT VALUE

Time Needed for Diagnosis: 3000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Crankshaft position sensor signalInput exists
Battery voltage> or = 8 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect for faults in crankshaft position sensor output properties.

Judge as NG when there is a problem in the number of crankshaft signals for every revolution of crankshaft.

Scheme 55

Scheme 55: COMPONENT DESCRIPTION

Scheme 56

Scheme 56
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Cylinder number identificationCompleted
Amount of crank sensor signal during 1 rev of crankshaft.Not = 30

JUDGMENT VALUE

Time Needed for Diagnosis: 10 engine revs. engine revs.

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Cylinder number identificationCompleted
Amount of crank sensor signal during 1 rev of crankshaft.= 30

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the camshaft position sensor.

When there is no camshaft position signal input continuously, judge as NG.

Scheme 57

Scheme 57: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Diagnosis 1

Judge as NG when no input of camshaft position sensor signal in TDC remains for 10 time(s).

Malfunction CriteriaThreshold Value
No camshaft position sensor signal input in TDC> or = 10 time(s)

JUDGMENT VALUE

Time Needed for Diagnosis: TDC x 10 time(s)

Diagnosis 2

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Camshaft position sensor signalNo input

JUDGMENT VALUE

Time Needed for Diagnosis: 3000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Diagnosis 1

Judge as OK and clear the NG when the malfunction criteria below are met.

Malfunction CriteriaThreshold Value
No camshaft position sensor signal input in TDC= 0 time(s)

JUDGMENT VALUE

Time Needed for Diagnosis: TDC x 10 time(s)

Diagnosis 2

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Camshaft position sensor signalInput exists

JUDGMENT VALUE

Time Needed for Diagnosis: 32 ms

Detect the malfunction of camshaft position sensor property.

Judge as NG when the number of camshaft signals remains abnormal.

Scheme 58

Scheme 58: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when the status where the number of camshaft position sensor signal in two crankshaft revolutions is other than 3 time(s).

Malfunction CriteriaThreshold Value
Amount of camshaft sensor signal during 2 revs of crankshaft.3 time(s)

JUDGMENT VALUE

Time Needed for Diagnosis: Engine two revolutions x 4 time(s)

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG when the malfunction criteria below are met.

Malfunction CriteriaThreshold Value
Camshaft position sensor signal= 3 time(s)

JUDGMENT VALUE

Time Needed for Diagnosis: Engine two revolutions

Note. For the detection standard, refer to DTC P0340. < Ref. to DTC P0340 CAMSHAFT POSITION SENSOR "A" CIRCUIT (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0341. < Ref. to DTC P0341 CAMSHAFT POSITION SENSOR "A" CIRCUIT RANGE/PERFORMANCE (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Based on the self-diagnostic result of the ignition coil driving IC, judge the ignition coil driving circuit as normal or abnormal.

The ignition coil driving IC detects "no ignition" status as a malfunction.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Ignition driving IC informationMalfunction

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Ignition driving IC informationNormal

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Note. For the detection standard, refer to DTC P0351. < Ref. to DTC P0351 IGNITION COIL A PRIMARY/SECONDARY CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0351. < Ref. to DTC P0351 IGNITION COIL A PRIMARY/SECONDARY CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P0351. < Ref. to DTC P0351 IGNITION COIL A PRIMARY/SECONDARY CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect EGR system malfunction.

Intake manifold pressure (negative pressure) is constant because the throttle valve is fully closed during deceleration fuel cut. At this time, when the EGR valve is opened/closed, the intake manifold pressure will change. EGR System OK/NG is judged by the range of this change.

Scheme 59

Scheme 59: COMPONENT DESCRIPTION

Measure the pressure values when the enable conditions are established, and perform diagnosis by calculating those results.

  1. Label the intake manifold pressure value as PMOF1, which is observed when enable conditions are established, and set the EGR target step to 45 step(s) (nearly full open).
  2. Label the intake manifold pressure value as PMON, which is observed after 1000 ms has passed since EGR target step was set to 45 step(s) (when the enable conditions were established), and set the EGR target step to 0.
  3. Label the intake manifold pressure as PMOF2, which is observed after 1000 ms has passed since EGR target step was set to 0 (after (1000 ms + 1000 ms) have passed since the enable conditions were established).
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
PMON - (PMOF1 + PMOF2)/2< 2.5 kPa (18.63 mmHg, 0.7 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 1 time

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

Scheme 60

Scheme 60
  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
PMON - (PMOF1 + PMOF2)/2> or = 2.5 kPa (18.63 mmHg, 0.7 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 1 time

Detect the deterioration of the catalyst function.

Though the front oxygen sensor output would change slowly with a new catalyst, the sensor output with a deteriorated catalyst becomes high and the inversion time is shortened.

For this reason, the catalyst diagnosis is carried out by monitoring the front oxygen sensor output and comparing it with the front oxygen (A/F) sensor output.

Scheme 61

Scheme 61: COMPONENT DESCRIPTION

After the enable conditions have been established, calculate the front oxygen (A/F) sensor lambda value deviation sum value (Sum (sglmd n - sglmd n-1 )), and rear oxygen sensor output voltage deviation sum value (Sum (ro2sad n - ro2sad n-1 )) in every 32 ms x 4 times. If the front oxygen (A/F) sensor lambda value deviation sum value (Sum (sglmd n - sglmd n-1 )) is the predetermined value or more, calculate the diagnostic value.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is within the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sum (ro2sad n - ro2sad n-1 )/Sum (sglmd n - sglmd n-1 )> 10 (except for PZEV model)
> 8 (PZEV model)

JUDGMENT VALUE

Time Needed for Diagnosis: 30 - 55 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is within the predetermined time.

Malfunction CriteriaThreshold Value
Sum (ro2sad n - ro2sad n-1 )/Sum (sglmd n - sglmd n-1 )< or = 10 (except for PZEV model)
< or = 8 (PZEV model)

JUDGMENT VALUE

Time Needed for Diagnosis: 30 - 55 seconds

Detect the malfunction of purge flow by the change of ELCM pressure sensor output value before/after purge introduction.

First diagnosis

Pressure decreases when the purge is introduced compared with when the purge is not performed. By using this, judge if the purge is correctly performed. If there is no pressure decrease, go to the SECOND DIAGNOSIS .

Scheme 62

Scheme 62: First diagnosis
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
ELCM pressure sensor output voltage when purge is not performed - ELCM pressure sensor output voltage when purge is performed> 0.004 V

JUDGMENT VALUE

Time Needed for Diagnosis: 26 seconds

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
ELCM pressure sensor output voltage when purge is not performed - ELCM pressure sensor output voltage when purge is performed> 0.004 V

JUDGMENT VALUE

Time Needed for Diagnosis: 26 seconds

Second diagnosis

Close the ELCM switching valve, and close the fuel tank completely, and perform the forced purging. If pressure change amount is 0.7 kPa (5 mmHg, 0.2 inHg) or less, judge as malfunction of purge flow.

Scheme 63

Scheme 63: Second diagnosis
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
ELCM pressure sensor output value when purge is not performed -- ELCM pressure sensor output value when purge is performed< 666.5 Pa (5 mmHg, 0.2 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 21 seconds

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
ELCM pressure sensor output value when purge is not performed -- ELCM pressure sensor output value when purge is performed> or = 666.5 Pa (5 mmHg, 0.2 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 21 second

Detect the malfunction of ELCM pressure sensor output properties.

Judge as NG when the ELCM pressure sensor output value is largely different from the intake manifold pressure when the ignition switch is ON.

Scheme 64

Scheme 64: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
ELCM pressure sensor output value - intake manifold pressure (absolute pressure) when ignition switch is ON> 4.226 kPa (31.7 mmHg, 1.25 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 328 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
ELCM pressure sensor output value - intake manifold pressure (absolute pressure) when ignition switch is ON< or = 4.226 kPa (31.7 mmHg, 1.25 inHg)

JUDGMENT VALUE

Time Needed for Diagnosis: 262 ms

Detect the open or short circuit of the ELCM pressure sensor.

Judge as NG if out of specification.

Scheme 65

Scheme 65: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 0.973 V

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.973 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the ELCM pressure sensor.

Judge as NG if out of specification.

Scheme 66

Scheme 66: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> or = 4.095 V

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage< 4.095 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

This diagnosis judges whether the ELCM operation is normal or not, and whether the evaporative emission system has leak and clogging or not.

To purge the canister, after driving, perform the five hours soaking after ignition switch OFF in order to stabilize the evaporative gas status. * After 5, 7 or 9.5 hours passed, ECM is activated by soaking timer, and the leak check is started.

Judges whether the ELCM operation is normal or not, by measuring the reference pressure status via reference orifice (0.02 inch orifice). Judge as malfunction if the reference pressure is out of specified range. Then, judge whether there is a leak or not, by comparing the pressure (leak pressure) when the reference pressure and the evaporative emission system are in negative pressure condition. Judge as system leak in the evaporative emission system if the leak pressure is higher than reference pressure. Judge as clogging of pipe if the leak pressure becomes lower than the reference pressure within the specified amount of time.

0.02 inch leak and 0.04 inch leak can be distinguished by measuring the leak pressure.

The diagnosis results are stored inside ECM until the engine is started again.

*: When the test conditions are not met in 5 hours, perform diagnosis at elapsed time of 7 hours. When the test conditions are not met in 7 hours, perform diagnosis at elapsed time of 9.5 hours.

Diagnostic item
ELCM system (ELCM body)Vacuum pump stuck
Switching valve stuck to open
Switching valve stuck to close
Reference orifice flow large
Reference orifice flow small
Leak checkLarge leak 0.04 inch leak Fuel cap loose Fuel cap off System malfunction
Very small leak 0.02 inch leak
Clogging of pipe

Scheme 67

Scheme 67: OUTLINE OF DIAGNOSIS

Mode D (Clogging of pipe diagnosis and leak pressure measurement)

  1. Clogging of pipe Purpose: Measure the time required for the evaporative emission system to reach the target negative pressure by the vacuum pump, and detect the clogging of pipe trouble. Judge as clogging of pipe malfunction if the evaporative emission system reaches to the target negative pressure within the specified time. JUDGMENT VALUE Malfunction Criteria Threshold Value DTC Time required to reach to the target negative pressure For target vacuum, use one of the followings. Reference pressure for target vacuum setting - value of Map 4 -5 kPa (-37.298 mmHg, -1.5 inHg) < or = 34000 ms P1451 MAP SPECIFICATION 4 Time of negative pressure introduction ms 0 100000 200000 300000 400000 500000 600000 700000 800000 900000 1000000 1100000 1200000 Reference pressure for setting the target negative pressure - Pressure sensor output value kPa (mmHg, inHg) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3) 0.9 (7.058, 0.3)
  2. Leak pressure measurement

Purpose: Measure the pressure (leak pressure) when the evaporative emission system becomes the negative pressure by the vacuum pump.

Store the pressure as a leak pressure while the following conditions are met.

Conditions for storing the leak pressureThreshold Value
When any one of the followings is established. Reference pressure for setting the target negative pressure - Pressure sensor output value> or = Value of Map 4
Pressure sensor output value< -5 kPa (-37.298 mmHg, -1.5 inHg)
Time of negative pressure introduction> or = 900000 ms

JUDGMENT VALUE

Note. For the detection standard, refer to DTC P0455. < Ref. to DTC P0455 EVAPORATIVE EMISSION SYSTEM LEAK DETECTED (LARGE LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect open or short circuit of the purge control solenoid valve.

Judge as NG when the ECM output level differs from the actual terminal level.

Scheme 68

Scheme 68: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Duty ratio of "ON"< 0.75
Terminal output voltageLow

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal output voltageHigh

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect open or short circuit of the purge control solenoid valve.

Judge as NG when the ECM output level differs from the actual terminal level.

Scheme 69

Scheme 69: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Duty ratio of "ON"> or = 0.25
Terminal output voltageHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal output voltageLow

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect malfunctions of the fuel level sensor output property.

If the fuel level does not vary in a particular driving condition/engine condition where it should, judge as NG.

Scheme 70

Scheme 70: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Accumulated amount of intake air> or = 165375 g (5832.78 oz)
Max. - min. values of fuel level output< 2.6 2 (0.69 US gal, 0.57 Imp gal)
Battery voltage> or = 10.9 V
Engine speed< 10000 rpm
Elapsed time after starting the engine> or = 5000 ms

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Accumulated amount of intake air> or = 165375 g (5832.78 oz)
Max. - min. values of fuel level output> or = 2.6 2 (0.69 US gal, 0.57 Imp gal)
Battery voltage> or = 10.9 V
Engine speed< 10000 rpm
Elapsed time after starting the engine> or = 5000 ms

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of fuel level sensor. Judge as NG if out of specification.

Scheme 71

Scheme 71: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9 V
Elapsed time after starting the engine> or = 3000 ms
Output voltage< 2.211 V

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9 V
Elapsed time after starting the engine> or = 3000 ms
Output voltage> or = 2.211 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of fuel level sensor. Judge as NG if out of specification.

Scheme 72

Scheme 72: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9 V
Elapsed time after starting the engine> or = 3000 ms
Output voltage> or = 12 V

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9 V
Elapsed time after starting the engine> or = 3000 ms
Output voltage< 12 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Judge as NG when outside of the judgment value.

Judge NG when the received data from VDCCM&H/U is abnormal vehicle speed, and the vehicle speed data is impossible.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Front ABS wheel speed sensor statusMalfunction
Either of the following is established
Front left wheel speed> or = 300 km/h (186.4 MPH)
Front right wheel speed> or = 300 km/h (186.4 MPH)

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Front left wheel speed> 0 km/h (0 MPH)
And
< 300 km/h (186.4 MPH)
Front right wheel speed> 0 km/h (0 MPH)
And
< 300 km/h (186.4 MPH)

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Detect the malfunction that actual engine speed is not close to target engine speed during idling. Judge as NG when actual engine speed is not close to target engine speed during idling.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Actual engine speed - Target engine speed< -100 rpm
Feedback compensation for ISCMax.

JUDGMENT VALUE

Time Needed for Diagnosis: 15 s x 1 time(s)

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Actual engine speed - Target engine speed> or = -100 rpm

JUDGMENT VALUE

Time Needed for Diagnosis: 15 s

Detect the malfunction that actual engine speed is not close to target engine speed during idling. Judge as NG when actual engine speed is not close to target engine speed during idling.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Actual engine speed - Target engine speed> or = 200 rpm
Feedback compensation for ISCMin.

JUDGMENT VALUE

Time Needed for Diagnosis: 15 s x 1 time(s)

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Actual engine speed - Target engine speed< 200 rpm

JUDGMENT VALUE

Time Needed for Diagnosis: 15 s

  1. When cold, the abnormality in the control of target engine speed increase is detected. (P050A)

Judge as NG if the exhaust gas temperature diagnosis or idle speed diagnosis is NG.

  1. Exhaust gas temperature diagnosis Judge as NG when the estimated exhausted gas temperature in 14 seconds after the cold start is below the specified value.
  2. Idle speed diagnosis

Judge as NG when actual engine speed is not close to target engine speed at cold start.

  1. Detect malfunctions of the catalyst advanced idling retard angle control. (P050B)

Judge as NG when ECM is not controlling the angle properly during catalyst advanced idling retard angle control.

  1. Final ignition timing diagnosis

Judge as NG when actual retard amount is under the specified value at cold start.

  1. Exhaust gas temperature diagnosis

Note. For the detection standard, refer to DTC P050A. < Ref. to DTC P050A COLD START IDLE AIR CONTROL SYSTEM PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect abnormal continuity in the starter SW1.

Judge as ON NG when the starter SW 1 signal remains ON.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Battery voltage> or = 8 V
Engine conditionAfter engine starting
Starter SW 1 signalON

JUDGMENT VALUE

Time Needed for Diagnosis: 30000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Battery voltage> or = 8 V
Starter SW 1 signalOFF

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of battery temperature sensor.

Judge as NG if out of specification.

Scheme 73

Scheme 73: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 0.1294 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.1294 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of battery temperature sensor.

Judge as NG if out of specification.

Scheme 74

Scheme 74: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> or = 4.787 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage< 4.787 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open/short circuit of back-up power supply circuit.

Judge as NG when the backup power voltage is low.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Voltage of back-up power supplyLow
Battery voltage> or = 10.9 V
Engine conditionAfter engine starting

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Voltage of back-up power supplyHigh
Battery voltage> or = 10.9 V
Engine conditionAfter engine starting

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of microcomputer (RAM).

When there is a problem in the CPU normal RAM, judge as NG.

If it is possible to write data to the whole area of RAM in the initial routine, and is possible to read the same data, it is judged as OK, and if not, NG.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Write the specified value to RAM and then read.The written value cannot be read.

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Write the specified value to RAM and then read.The written value can be read.

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Judge as NG when SUM value of ROM is outside the standard value.

Abnormality Judgment

Judge as NG if the criteria below are met.

Malfunction CriteriaThreshold Value
SUM value of ROMStandard

JUDGMENT VALUE

Time Needed for Diagnosis: Undetermined

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

Judge as NG when the CPU operation is abnormal.

  1. Instruction check initial
  2. Instruction check base
  3. Software flow check
  4. Software monitor check
  5. CAN register check
  6. If the output IC operation is abnormal

Scheme 75

Scheme 75: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
(1) Main CPU calculation resultThe result and expected value do not match.
(2) Main CPU calculation resultThe result and expected value do not match.
(3) Process flow resultThe result and expected value do not match.
(4) High integrated IC motor continuity cut demandNone
(5) Writing value to CAN registerRead out value
(6) Communication between output driver ICsNot possible to communicate

JUDGMENT VALUE

Time Needed for Diagnosis

  1. 2 time(s)
  2. 512 ms
  3. 504 ms
  4. 48 ms
  5. None
  6. 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
(1) Main CPU calculation resultThe result and expected value match.
(2) Main CPU calculation resultThe result and expected value match.
(3) Process flow resultThe result and expected value match.
(4) High integrated IC motor continuity cut demandExist
(5) Writing value to CAN register= Read out value
(6) Communication between output driver ICsPossible to communicate

JUDGMENT VALUE

Time Needed for Diagnosis

  1. None
  2. 2000 ms
  3. 2000 ms
  4. 2000 ms
  5. None
  6. None

Judge as NG when the monitoring IC operation is abnormal.

  1. Monitoring IC Disable (motor continuity cut demand) diagnosis
  2. Monitoring IC function diagnosis
  3. Monitoring IC register diagnosis

Scheme 76

Scheme 76: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when one of the following conditions is established.

Malfunction CriteriaThreshold Value
(1) Main throttle opening angle - Main throttle opening angle at monitoring start> or = 2 °
(2) Monitoring IC Disable statusOFF
(3) Monitoring IC register writing valueReading value

JUDGMENT VALUE

Time Needed for Diagnosis

  1. 24 ms
  2. 0.08 s x 2 time(s)
  3. 200 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
(1) Main throttle opening angle - Main throttle opening angle at monitoring start< 2 °
(2) Monitoring IC Disable statusON
(3) Monitoring IC register writing value= Reading value

JUDGMENT VALUE

Time Needed for Diagnosis

  1. 80 ms
  2. None
  3. 2000 ms

Judge as NG when the AD converter operation is abnormal.

Scheme 77

Scheme 77: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when one of the following conditions is established.

Malfunction CriteriaThreshold Value
Target voltage= 0 V
And
Actual voltage< 0 V
Or
Actual voltage> 0.01953125 V
Target voltage= 5 V
And
Actual voltage< 4.979248047 V
Or
Actual voltage> 5 V

JUDGMENT VALUE

Time Needed for Diagnosis: 200 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Target voltage= 0 V
And
Actual voltage> or = 0 V
And
Actual voltage< or = 0.01953125 V
Target voltage= 5 V
And
Actual voltage> or = 4.979248047 V
And
Actual voltage< or = 5 V

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

  1. Model without push button start

Detect abnormal continuity in the starter SW1.

Judge as OFF NG when the starter SW 1 signal remains OFF.

  1. Model with push button start

Detect abnormal continuity in the starter SW 2.

Judge as OFF NG when the starter SW 2 signal remains OFF.

  1. Abnormality Judgment

Judge as OFF NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Battery voltage> or = 8 V
Vehicle speed< 1 km/h (0.6 MPH)
Engine conditionChange from pre-start to post-start
Starter SW 1 signal (model without push button start)No ON experience
Starter SW 2 signal (model with push button start)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OFF OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Battery voltage> or = 8 V
Vehicle speed< 1 km/h (0.6 MPH)
Engine conditionChange from pre-start to post-start
Starter SW 1 signal (model without push button start)ON Experience exists
Starter SW 2 signal (model with push button start)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

  1. Model without push button start

Detect abnormal continuity in the starter SW1.

Judge as ON NG when the starter SW 1 signal remains ON.

  1. Model with push button start

Detect abnormal continuity in the starter SW 2.

Judge as ON NG when the starter SW 2 signal remains ON.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Battery voltage> or = 8 V
Engine conditionAfter engine starting
Starter relay (model with push button start)OFF
Starter SW 1 signal (model without push button start)ON
Starter SW 2 signal (model with push button start)

JUDGMENT VALUE

Time Needed for Diagnosis

  1. Model without push button start: 30000 ms
  2. Model with push button start: 2000 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OFF OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Battery voltage> or = 8 V
Starter SW 1 signal (model without push button start)OFF
Starter SW 2 signal (model with push button start)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Judge as NG when the EEPROM operation is abnormal.

Scheme 78

Scheme 78: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Writing result to EEPROMMalfunction

JUDGMENT VALUE

Time Needed for Diagnosis: 2 times

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Writing result to EEPROMNormal

JUDGMENT VALUE

Time Needed for Diagnosis: None

Judge as NG when there is CAN communication with the TCM and there is a MIL lighting request.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9 V
MIL lighting request from TCMYes

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9 V
MIL lighting request from TCMNone

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect abnormal continuity in the starter cut relay.

Judge as NG when the starter cut relay output line is open.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Battery voltage> or = 8 V
Vehicle speed< 1 km/h (0.6 MPH)
Engine conditionChange from pre-start to post-start
Starter cut relay terminal levelNo High level experience

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Battery voltage> or = 8 V
Vehicle speed< 1 km/h (0.6 MPH)
Engine conditionChange from pre-start to post-start
Starter cut relay terminal levelHigh level experience exists

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of neutral SW.

Judge as NG when the ECM neutral terminal input differs from the reception data from TCM.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Neutral switch signal in ECM when "P"/"N" range in TCM are "OFF" and when the other switches are "ON"LOW (ON)

JUDGMENT VALUE

Time Needed for Diagnosis: 64 ms x 100 time(s)

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Neutral switch signal in ECM when "P"/"N" range in TCM are "OFF" and when the other switches are "ON"HIGH (OFF)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of neutral SW.

Judge as NG when there is no change in the neutral SW even if the driving shift was applied. (There is neutral SW ON/OFF inversion from the vehicle speed and engine speed.)

  1. Abnormality Judgment

Judge NG when the malfunction criteria below are completed determined times or more after the neutral SW change.

Malfunction CriteriaThreshold Value
Neutral switch signal (while changing from a to b below)LOW (ON) continues.
Driving condition changeFrom a) to b)
Engine speed 550 rpm - 900 rpm & Vehicle speed = 0 km/h (0 MPH) Engine speed 1500 rpm - 2150 rpm & Vehicle speed > or = 64 km/h (39.8 MPH)

JUDGMENT VALUE

Time Needed for Diagnosis: 3 time(s)

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear NG when there is change in the neutral SW.

Malfunction CriteriaThreshold Value
Neutral switch signal (while changing from a to b below)Changes to HIGH (OFF).
Driving condition changeFrom a) to b)
Engine speed 550 rpm - 900 rpm & Vehicle speed = 0 km/h (0 MPH) Engine speed 1500 rpm - 2150 rpm & Vehicle speed > or = 64 km/h (39.8 MPH)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of neutral SW.

Judge as NG when the ECM neutral terminal input differs from the reception data from TCM.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Neutral switch signal in ECM when "P"/"N" range in TCM are "ON" and when the other switches are "OFF"HIGH (OFF)

JUDGMENT VALUE

Time Needed for Diagnosis: 64 ms x 100 time(s)

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Neutral switch signal in ECM when "P"/"N" range in TCM are "ON" and when the other switches are "OFF"LOW (ON)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of neutral SW.

Judge as NG when there is no change in the neutral SW even if the driving shift was applied. (There is neutral SW ON/OFF inversion from the vehicle speed and engine speed.)

  1. Abnormality Judgment

Judge NG when the malfunction criteria below are completed determined times or more after the neutral SW change.

Malfunction CriteriaThreshold Value
Neutral switch signal (while changing from a to b below)HIGH (OFF) continues.
Driving condition changeFrom a) to b)
Engine speed 550 rpm - 900 rpm & Vehicle speed = 0 km/h (0 MPH) Engine speed 1500 rpm - 2150 rpm & Vehicle speed > or = 64 km/h (39.8 MPH)

JUDGMENT VALUE

Time Needed for Diagnosis: 3 time(s)

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear NG when there is change in the neutral SW.

Malfunction CriteriaThreshold Value
Neutral switch signal (while changing from a to b below)Changes to LOW (ON).
Driving condition changeFrom a) to b)
Engine speed 550 rpm - 900 rpm & Vehicle speed = 0 km/h (0 MPH) Engine speed 1500 rpm - 2150 rpm & Vehicle speed > or = 64 km/h (39.8 MPH)

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Judge as NG when the valve is opened more than the default opening angle, but does not move to the close direction with the motor power stopped.

Scheme 79

Scheme 79: COMPONENT DESCRIPTION
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Opening variation after continuity is set to OFF< 2 °

JUDGMENT VALUE

Time Needed for Diagnosis: 24 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Opening variation after continuity is set to OFF> or = 2 °

JUDGMENT VALUE

Time Needed for Diagnosis: 3400 ms

Detect the drain filter clogging by the pressure change during purge introduction.

Judge as drain filter clogging malfunction if the pressure in the evaporative emission system piping suddenly decreases by the purging.

Scheme 80

Scheme 80: COMPONENT DESCRIPTION

Note. For the detection standard, refer to DTC P0455. < Ref. to DTC P0455 EVAPORATIVE EMISSION SYSTEM LEAK DETECTED (LARGE LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

  1. Detects open or short circuit of EGR.
  2. Judge as NG when the ECM output level differs from the actual terminal level.

Scheme 81

Scheme 81: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Terminal voltage level when ECM outputs OFF signalLow level
Or
Terminal voltage level when EGR operatesLow level

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal voltage level when ECM outputs OFF signalHigh level
Terminal voltage level when EGR operatesHigh level

JUDGMENT VALUE

Time Needed for Diagnosis: 256 ms

  1. Detects open or short circuit of EGR.
  2. Judge as NG when the ECM output level differs from the actual terminal level.

Scheme 82

Scheme 82: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Terminal voltage level when ECM outputs ON signalHigh level
Or
Terminal voltage level when EGR operatesHigh level

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Terminal voltage level when ECM outputs ON signalLow level
Terminal voltage level when EGR operatesLow level

JUDGMENT VALUE

Time Needed for Diagnosis: 256 ms

Note. For the detection standard, refer to DTC P1492. < Ref. to DTC P1492 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P1493. < Ref. to DTC P1493 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P1492. < Ref. to DTC P1492 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P1493. < Ref. to DTC P1493 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P1492. < Ref. to DTC P1492 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC P1493. < Ref. to DTC P1493 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the open or short circuit of battery current sensor.

Judge as NG if out of specification.

Scheme 83

Scheme 83: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage< 0.2148 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage> or = 0.2148 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of battery current sensor.

Judge as NG if out of specification.

Scheme 84

Scheme 84: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Output voltage> or = 4.832 V

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Output voltage< 4.832 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the output property and malfunction of battery current sensor.

Judge as NG when there is no variation (stuck) under a condition where the battery current sensor output should have changed or when difference between output and battery current value is larger than expected (characteristics malfunction).

Scheme 85

Scheme 85: COMPONENT DESCRIPTION
  1. Abnormality Judgment
  2. Stuck

Judge as NG when the following conditions are repeated 10 time(s) or more.

Malfunction CriteriaThreshold Value
Difference between maximum value and minimum value in output voltage< 0.07 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Characteristics malfunction (Charge side)

Within 30000 ms from "enable condition not met" to "enable condition met", judge as NG when the time required for meeting the following conditions exceeds the predetermined time.

(When NG judgment is performed, NG status is retained during that driving cycle.)

Malfunction CriteriaThreshold Value
Output voltage 0 V< or = Output voltage < 2.4 V
And
Battery voltage< 13.2 V

JUDGMENT VALUE

Time Needed for Diagnosis: 26000 ms

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Characteristics malfunction (Discharge side)

Within 30000 ms from "enable condition not met" to "enable condition met", judge as NG when the time required for meeting the following conditions exceeds the predetermined time.

(Within 30000 ms from "enable condition not met" to "enable condition met", the target duty > or = 60 % has not been experienced.)

Malfunction CriteriaThreshold Value
Output voltage2.6 V < or = Output voltage < 5 V
And
Battery voltage> or = 13.7 V

JUDGMENT VALUE

Time Needed for Diagnosis: 26000 ms

Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.

  1. Normality Judgment
  2. Stuck

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Difference between maximum value and minimum value in output voltage> or = 0.07 V

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

  1. Characteristics malfunction (Charge side)

Within 30000 ms from "enable condition not met" to "enable condition met", judge as OK and clear the NG when the time required for meeting the following conditions does not reach the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage0 V < or = Output voltage < 2.4 V
And
Battery voltage< 13.2 V

JUDGMENT VALUE

Time Needed for Diagnosis: 26000 ms

  1. Characteristics malfunction (Discharge side)

Within 30000 ms from "enable condition not met" to "enable condition met", judge as OK and clear the NG when the time required for meeting the following conditions does not reach the predetermined time.

Malfunction CriteriaThreshold Value
Output voltage2.6 V < or = Output voltage < 5 V
And
Battery voltage> or = 13.7 V

JUDGMENT VALUE

Time Needed for Diagnosis: 26000 ms

DTCItemOUTLINE OF DIAGNOSIS
B1570AntennaFaulty antenna
B1571Reference Code IncompatibilityReference code incompatibility between body integrated unit and ECM
B1572IMM Circuit Failure (Except Antenna Circuit)Communication failure between body integrated unit and ECM
B1574Key Communication FailureThe body integrated unit to confirm the key (transponder) ID code has malfunction, of the transponder is faulty.
B1575Incorrect Immobilizer KeyIncorrect immobilizer key (Use of unregistered key in body integrated unit)
B1576EGI Control Module EEPROMECM malfunctioning
B1577IMM Control Module EEPROMBody integrated unit malfunctioning
B1578Meter FailureReference code incompatibility between combination meter and body integrated unit

Judge as NG when the conditions for the outline of the diagnosis of the top are established.

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC B1570. < Ref. to DTC B1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the malfunction of tumble generator valve motor function.

Judge open fixing malfunction when the opening degree is large even after finishing the tumble generator valve closing driving.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Tumble generator valve opening switch= High
Tumble generator valve "close" signal output time> or = 1600 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 4600 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Tumble generator valve opening switch= Low
Tumble generator valve "close" signal output time> or = 1600 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 1600 ms

Detect the malfunction of tumble generator valve motor function.

Judge open fixing malfunction when the opening degree is large even after finishing the tumble generator valve closing driving.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Tumble generator valve opening switch= High
Tumble generator valve "close" signal output time> or = 1600 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 4600 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Tumble generator valve opening switch= Low
Tumble generator valve "close" signal output time> or = 1600 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 1600 ms

Detect the malfunction of tumble generator valve motor function.

Judge close fixing malfunction when the opening degree is small even after finishing the tumble generator valve open driving.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Tumble generator valve opening switch= Low
Tumble generator valve "open" signal output time> or = 1600 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 4600 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Tumble generator valve opening switch= High
Tumble generator valve "open" signal output time> or = 1600 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 1600 ms

Detect the malfunction of tumble generator valve motor function.

Judge close fixing malfunction when the opening degree is small even after finishing the tumble generator valve open driving.

  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Tumble generator valve opening switch= Low
Tumble generator valve "open" signal output time> or = 1600 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 4600 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Tumble generator valve opening switch= High
Tumble generator valve "open" signal output time> or = 1600 ms

JUDGMENT VALUE

Time Needed for Diagnosis: 1600 ms

Detect the open or short circuit of tumble generator valve motor.

Judge as NG when the overcurrent signal is sent from IC after tumble generator valve driving IC diagnosis.

Scheme 86

Scheme 86: COMPONENT DESCRIPTION
  1. Abnormality Judgment

At the main IC, check the sent signal at each timing which occurs just before the tumble generator valve output is set to ON --> OFF, and judge open NG when the open NG signal is sent 96 ms x 10 time(s) in a row.

Malfunction CriteriaThreshold Value
Overcurrent NG signal inputLow

JUDGMENT VALUE

Time Needed for Diagnosis: 96 ms x 10 time(s)

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG when the OK signal is sent.

Malfunction CriteriaThreshold Value
Overcurrent NG signal inputHigh

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of tumble generator valve motor.

Judge as NG when the overcurrent signal is sent from IC after tumble generator valve driving IC diagnosis.

Scheme 87

Scheme 87: COMPONENT DESCRIPTION
  1. Abnormality Judgment

At the main IC, check the sent signal at each timing which occurs just before the tumble generator valve output is set to ON --> OFF, and judge open NG when the open NG signal is sent 96 ms x 10 time(s) in a row.

Malfunction CriteriaThreshold Value
Overcurrent NG signal inputLow

JUDGMENT VALUE

Time Needed for Diagnosis: 96 ms x 10 time(s)

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG when the OK signal is sent.

Malfunction CriteriaThreshold Value
Overcurrent NG signal inputHigh

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the malfunction of fuel system from the size of the sub feedback learning value.

Control the sub feedback learning and judge as NG when the learning value is in the lean zone.

Scheme 88

Scheme 88: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sub feedback learning value< -0.042 (CVT model except for PZEV)
< -0.044 (MT model except for PZEV)
< -0.035 (PZEV CVT model)
< -0.037 (PZEV MT model)

JUDGMENT VALUE

Time Needed for Diagnosis: 1 s x 1 time(s)

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Sub feedback learning value> or = -0.042 + 0 (CVT model except for PZEV)
> or = -0.044 + 0 (MT model except for PZEV)
> or = -0.035 + 0 (PZEV CVT model)
> or = -0.037 + 0 (PZEV MT model)

JUDGMENT VALUE

Time Needed for Diagnosis: 1 s

Detect the malfunction of fuel system from the size of the sub feedback learning value.

Sub feedback learning is being performed. When the learning value goes to the rich side, judge as NG.

Scheme 89

Scheme 89: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sub feedback learning value> or = 0.013 (CVT model except for PZEV)
> or = 0.017 (MT model except for PZEV)
> or = 0.024 (PZEV CVT model)
> or = 0.023 (PZEV MT model)

JUDGMENT VALUE

Time Needed for Diagnosis: 1 s x 1 time(s)

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Sub feedback learning value< 0.013 + 0 (CVT model except for PZEV)
< 0.017 + 0 (MT model except for PZEV)
< 0.024 + 0 (PZEV CVT model)
< 0.023 + 0 (PZEV MT model)

JUDGMENT VALUE

Time Needed for Diagnosis: 1 s

Judge as NG when the motor current becomes large or drive circuit is heated.

Scheme 90

Scheme 90: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Motor current> 8 A
Or
Drive circuit inner temperature> 175°C (347°F)

JUDGMENT VALUE

Time Needed for Diagnosis: 512 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Motor current< or = 8 A
Drive circuit inner temperature< or = 175°C (347°F)

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Judge as NG when the electronic throttle control power is not supplied even when ECM sets the electronic throttle control relay to ON.

Scheme 91

Scheme 91: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Motor power voltage< or = 5 V

JUDGMENT VALUE

Time Needed for Diagnosis: 352 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Motor power voltage> 5 V

JUDGMENT VALUE

Time Needed for Diagnosis: 2000 ms

Judge as NG when the electronic throttle control power is supplied even when ECM sets the electronic throttle control relay to OFF.

Scheme 92

Scheme 92: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Motor power voltage> or = 5 V

JUDGMENT VALUE

Time Needed for Diagnosis: 600 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Motor power voltage< 5 V

JUDGMENT VALUE

Time Needed for Diagnosis: 400 ms

Judge as NG when full close point learning cannot conducted or abnormal value is detected.

Scheme 93

Scheme 93: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Throttle sensor opening angle at full close point learning< 9.975 °
Or
> 20.025 °
Or
Throttle opening angle when the ignition switch is ON - Throttle minimum stop position< 1.162 °

JUDGMENT VALUE

Time Needed for Diagnosis: 8 ms - 80 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Throttle sensor opening angle at full close point learning> or = 9.975 °
And
< or = 20.025 °
Throttle opening angle when the ignition switch is ON - Throttle minimum stop position> or = 1.162 °

JUDGMENT VALUE

Time Needed for Diagnosis: 8 ms

Judge as NG when the target opening angle and actual opening angle is mismatched or the current to motor is the specified duty or more for specified time continuously.

Scheme 94

Scheme 94: COMPONENT DESCRIPTION

Judge as OK and clear the NG when the malfunction criteria below are met.

Malfunction CriteriaThreshold Value
Difference between target opening angle and actual opening angleWithin OK range of Details of Judgment value
Output duty to drive circuit< 95 %

JUDGMENT VALUE

Time Needed for Diagnosis

  1. Difference between target opening angle and actual opening angle: NG judgment: See «DETAILS OF JUDGMENT TIME»(ref-662154-S17561103642014101300000) OK judgment: 2000 ms
  2. Output duty to driving circuit: 2000 ms

Scheme 95

Scheme 95: Details of Judgment Value

Scheme 96

Scheme 96: Details of Judgment time

Note. Judgment time when actual opening angle < or = target opening angle is always 1000 milliseconds.

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

Detect the open or short circuit of accelerator pedal position sensor 1.

Judge as NG if out of specification.

Scheme 97

Scheme 97: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage< 0.298 V

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage> or = 0.298 V

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Detect the open or short circuit of accelerator pedal position sensor 1.

Judge as NG if out of specification.

Scheme 98

Scheme 98: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage> or = 4.737 V

JUDGMENT VALUE

Time Needed for Diagnosis: 32 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Sensor 1 input voltage< 4.737 V

JUDGMENT VALUE

Time Needed for Diagnosis: 32 ms

Detect the open or short circuit of accelerator pedal position sensor 2.

Judge as NG if out of specification.

Scheme 99

Scheme 99: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage< 0.298 V

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage> or = 0.298 V

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Detect the open or short circuit of accelerator pedal position sensor 2.

Judge as NG if out of specification.

Scheme 100

Scheme 100: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage> or = 4.737 V

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Sensor 2 input voltage< 4.737 V

JUDGMENT VALUE

Time Needed for Diagnosis: 100 ms

Judge as NG when the signal level of throttle position sensor 1 is different from the throttle position sensor 2.

Scheme 101

Scheme 101: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Signal difference between two sensorsWithin the NG range of judgment value detail

JUDGMENT VALUE

Details of Judgment Value

Scheme 102

Scheme 102

Time Needed for Diagnosis: 212 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Signal difference between two sensorsWithin the OK range of judgment value detail

JUDGMENT VALUE

Time Needed for Diagnosis: 24 ms

Judge as NG when the signal level of throttle position sensor 1 is different from the throttle position sensor 2.

Scheme 103

Scheme 103: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Signal difference between two sensorsWithin the NG range of judgment value detail

JUDGMENT VALUE

Details of Judgment Value

Scheme 104

Scheme 104

Time Needed for Diagnosis: 116 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Signal difference between two sensorsWithin the OK range of judgment value detail

JUDGMENT VALUE

Time Needed for Diagnosis: 116 ms

Detect that lambda value remains low.

Judge as NG when lambda value is abnormal in accordance with lambda value of front oxygen (A/F) sensor and running conditions such as vehicle speed, amount of intake air, engine coolant temperature, sub feedback control, etc.

lambda value = Actual air fuel ratio/Theoretical air fuel ratio

lambda > 1: Lean

lambda < 1: Rich

Scheme 105

Scheme 105: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Lambda value< 0.85

JUDGMENT VALUE

Time Needed for Diagnosis: 10000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Lambda value> or = 0.85

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect that lambda value remains high.

Judge as NG when lambda value is abnormal in accordance with lambda value of front oxygen (A/F) sensor and running conditions such as vehicle speed, amount of intake air, engine coolant temperature, sub feedback control, etc.

lambda value = Actual air fuel ratio/Theoretical air fuel ratio

lambda > 1: Lean

lambda < 1: Rich

Scheme 106

Scheme 106: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Lambda value> 1.15

JUDGMENT VALUE

Time Needed for Diagnosis: 10000 ms

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Lambda value< or = 1.15

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

This diagnostic monitor performs a functional check of the fuel system to determine an air-fuel ratio cylinder imbalance.

This diagnosis is composed of two monitors.

The outline of "monitor A1" is as follows. When an air-fuel ratio cylinder imbalance occurs, the primary oxygen sensor output signal will oscillate with increased amplitude. This monitor utilizes this behavior to make a diagnosis. The monitor integrates the difference between the amplification value and the mean value of the first oxygen sensor output signal and compares it to a threshold to make a judgment.

The outline of "monitor B1" is as follows. Similarly, when an imbalance occurs, the engine speed also fluctuates with increased amplitude. This monitor utilizes this behavior to make a diagnosis. For reference, it should be noted that this imbalance monitor method is actually similar to the current misfire diagnostic monitor, and the parameter "domg360" (units: degrees CA) is shared between the imbalance and misfire monitors. The imbalance monitor is performed during idle condition when the engine is warm. The monitor integrates the count of "domg360" which exceeds a threshold in 1000 revolution.

When both the "monitor A1" value and the "monitor B1" value exceed a predetermined threshold, this monitor determines a malfunction and stores a fault code.

Judge as NG when Monitor A1 and Monitor B1 are both NG, and when either is OK, judge as OK.

  1. Abnormality Judgment

Monitor A1

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Diagnostic value 1 (DV1)> Threshold value 1 (TV1)

JUDGMENT VALUE

Scheme 107

Scheme 107
Engine load (g/rev (oz/rev))
0.8 (0.03)0.9 (0.03)1 (0.04)1.1 (0.04)1.2 (0.04)
Engine speed (rpm)14000.0152240.0219000.0279640.0361840.033342
16000.0198310.03220.0308190.0377360.034578
18000.0162290.02310.0230190.0285720.032015
20000.0144160.0174760.0219860.0251520.031138
22000.0149700.02050.02440.03420.038278
24000.0165960.0210580.0275740.0353200.040443
26000.0177770.0237600.0280240.0334700.037612
28000.0168370.0206330.0244280.0334700.037612

MAP SPECIFICATION (CVT MODEL EXCEPT FOR PZEV)

Engine load (g/rev (oz/rev))
0.8 (0.03)0.9 (0.03)1 (0.04)1.1 (0.04)1.2 (0.04)
Engine speed (rpm)14000.0152240.0219000.0279640.0361840.033342
16000.0198310.0256230.0308190.0377360.034578
18000.0162290.0213910.0230190.0285720.032015
20000.0144160.0174760.0219860.0251520.031138
22000.0149700.0205200.0271910.0317330.038278
24000.0165960.0210580.0275740.0353200.040443
26000.0177770.0237600.0280240.0334700.037612
28000.0168370.0206330.0244280.0334700.037612

MAP SPECIFICATION (MT MODEL EXCEPT FOR PZEV)

Engine load (g/rev (oz/rev))
0.8 (0.03)0.9 (0.03)1 (0.04)1.1 (0.04)1.2 (0.04)
Engine speed (rpm)14000.00870.00970.01460.01360.0136
16000.01210.03220.03010.02020.0202
18000.01600.02310.01960.02140.0202
20000.01030.01060.01140.01800.0180
22000.01450.02050.02440.03420.0272
24000.01440.01930.02160.02430.0243
26000.01460.01780.02140.02540.0259
28000.01110.01430.01750.02420.0242

MAP SPECIFICATION (PZEV CVT MODEL)

Engine load (g/rev (oz/rev))
0.8 (0.03)0.9 (0.03)1 (0.04)1.1 (0.04)1.2 (0.04)
Engine speed (rpm)14000.0087310.0169300.0187280.0173590.013645
16000.0120820.0252840.0252840.0201750.020175
18000.0159950.0213910.0213910.0201600.020160
20000.0103160.0106230.0113730.0180470.018047
22000.0144550.0205200.0271910.0271910.027191
24000.0144240.0183770.0271910.0183770.018377
26000.0145550.0178380.0178380.0178380.017838
28000.0110690.0142610.0142610.0142610.014261

MAP SPECIFICATION (PZEV MT MODEL)

Time Needed for Diagnosis

  1. 4 ms x 2500 time(s) (CVT model)
  2. 4 ms x 2500 time(s) (MT model)

Monitor B1

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Diagnostic Value2 (DV2)> 45 time(s) (CVT model except for PZEV)
> 30 time(s) (MT model except for PZEV)
> 17 time(s) (PZEV CVT model)
> 17 time(s) (PZEV MT model)

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 engine revs.

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Monitor A1

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Diagnostic value 1 (DV1)< or = Threshold value 1 (TV1)

JUDGMENT VALUE

Time Needed for Diagnosis

  1. 4 ms x 2500 time(s) (CVT model)
  2. 4 ms x 2500 time(s) (MT model)

Detect the open or short circuit of the ELCM vacuum pump.

Judge as NG if out of specification.

Scheme 108

Scheme 108: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9
Terminal output voltage when ECM outputs OFF signalLow

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9
Terminal output voltage when ECM outputs OFF signalHigh

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the ELCM vacuum pump.

Judge as NG if out of specification.

Scheme 109

Scheme 109: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9
Terminal output voltage when ECM outputs ON signalHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9
Terminal output voltage when ECM outputs ON signalLow

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Note. For the detection standard, refer to DTC P0455. < Ref. to DTC P0455 EVAPORATIVE EMISSION SYSTEM LEAK DETECTED (LARGE LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect the open or short circuit of the ELCM switching valve.

Judge as NG if out of specification.

Scheme 110

Scheme 110: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9
Terminal output voltage when ECM outputs OFF signalLow

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9
Terminal output voltage when ECM outputs OFF signalHigh

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect the open or short circuit of the ELCM switching valve.

Judge as NG if out of specification.

Scheme 111

Scheme 111: COMPONENT DESCRIPTION
  1. Abnormality Judgment

If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9
Terminal output voltage when ECM outputs ON signalHigh

JUDGMENT VALUE

Time Needed for Diagnosis: 2500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
Battery voltage> or = 10.9
Terminal output voltage when ECM outputs ON signalLow

JUDGMENT VALUE

Time Needed for Diagnosis: Less than 1 second

Detect malfunction of soaking timer IC by the five diagnoses below.

Monitor NumberExplanationTime required for diagnosis
Monitor #1 < Timer diagnosis >Perform diagnosis of the soaking timer IC accuracy196 ms
Monitor #2 < Full count diagnosis >Perform diagnosis of the soaking timer IC counter function4000 ms
Monitor #3 < Soaking timer IC setting diagnosis >Perform diagnosis of communication between ECM and soaking timer IC196 ms
Monitor #4 < Timer diagnosis (during soaking) >Perform diagnosis of the soaking timer IC accuracy during soaking3000 ms
Monitor #5 < Wake-up diagnosis >Perform diagnosis of wake-up function64 ms

Scheme 112

Scheme 112

< Timer diagnosis >

Start the count up operation of counters in ECM and in soaking timer IC when the engine is started. Judge as timer malfunction if the difference between the counter in ECM and counter in soaking timer IC exceeds the allowable limit when the ignition switch is OFF.

Scheme 113

Scheme 113: < Timer diagnosis >
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Osoaktimcpu - osoaktimic/osoaktimcpu> 0.24
Osoaktimcpu = Counter in ECM osoaktimic = Counter in soaking timer IC

JUDGMENT VALUE

  1. Normality Judgment

Judge as OK when the following conditions are established.

Malfunction CriteriaThreshold Value
Osoaktimcpu - osoaktimic/osoaktimcpu< or = 0.24

JUDGMENT VALUE

< Full count diagnosis >

Reset the counter in soaking timer IC and start the count up operation.

Judge as full count diagnosis malfunction if counter in soaking timer IC is not $3FF (1023 count) after 4 seconds.

Scheme 114

Scheme 114: < Full count diagnosis >
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Osoakfcntic$3FF (1023 count)
Osoakfcntic = Counter in soaking timer IC

JUDGMENT VALUE

  1. Normality Judgment

Judge as OK when the following conditions are established.

Malfunction CriteriaThreshold Value
Osoakfcntic= $3FF (1023 count)

JUDGMENT VALUE

< Soaking timer IC setting diagnosis >

When setting the activation setting time to soaking timer IC, compare the writing value to soaking timer IC with read out value. Judge as malfunction if the values do not match 3 times in a row.

Scheme 115

Scheme 115: < Soaking timer IC setting diagnosis >
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Writing value and read out value when setting the soaking timerUnmatch
Number of retrying the soaking timer setting> or = 3 times

JUDGMENT VALUE

  1. Normality Judgment

Judge as OK when the following conditions are established.

Malfunction CriteriaThreshold Value
Writing value and read out value when setting the soaking timerMatch

JUDGMENT VALUE

< Timer diagnosis (during soaking) >

Wake-up at the predetermined interval until 5, 7 or 9.5 hours have passed after the ignition switch is OFF, and compare the counter in soaking timer IC with the counter in ECM.

Judge as malfunction if the counter in soaking timer IC is counted up to maximum value (1023 count) when the counter in ECM is 1637 ms, or if the counter in soaking timer IC is not counted up to maximum value (1023 count) when the counter in ECM is 2455 ms.

Scheme 116

Scheme 116: < Timer diagnosis (during soaking) >
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
When any one of the followings is established.
All of the following conditions are established.
Counter in ECM< or = 1637 ms
Counter in soaking timer IC= $3FF (1023 count)
All of the following conditions are established.
Counter in ECM> or = 2455 ms
Counter in soaking timer IC$3FF (1023 count)

JUDGMENT VALUE

  1. Normality Judgment

Judge as OK when the following conditions are established.

Malfunction CriteriaThreshold Value
Following conditions are established.
All of the following conditions are established.
Counter in ECM< or = 1637 ms
Counter in soaking timer IC$3FF (1023 count)
All of the following conditions are established.
Counter in ECM> or = 2455 ms
Counter in soaking timer IC= $3FF (1023 count)

JUDGMENT VALUE

< Wake-up diagnosis >

Store the number of wake-up activation when the ECM wakes up by the soaking timer IC.

Next time when the ignition switch is ON, if the number of wake-up activation does not reach the predetermined value even though the counter in soaking timer IC operates 1 hour or more, judge as wake-up malfunction.

Scheme 117

Scheme 117: < Wake-up diagnosis >
  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Number of wake-up< Wake-up indication count

JUDGMENT VALUE

  1. Normality Judgment

Judge as OK when the following conditions are established.

Malfunction CriteriaThreshold Value
Number of wake-up> or = Wake-up indication count

JUDGMENT VALUE

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Ignition switchON
Driving cycleCompleted
When any one of the followings is established.
Timer diagnosisNG
Full count diagnosisNG
Soaking timer IC setting diagnosisNG
Timer diagnosis (during soaking)NG
Wake-up diagnosisNG

JUDGMENT VALUE

Time Needed for Diagnosis: Approx. 5 to 9.5 hours

Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.

  1. Normality Judgment

Judge as OK and clear the NG if the following conditions are established.

Malfunction CriteriaThreshold Value
Ignition switchON
Driving cycleCompleted
All of the following conditions are established.
Timer diagnosisOK
Full count diagnosisOK
Soaking timer IC setting diagnosisOK
Timer diagnosis (during soaking)OK
Wake-up diagnosisOK

JUDGMENT VALUE

Time Needed for Diagnosis: Approx. 5 to 9.5 hours

Detect malfunction of CAN communication.

Judge as NG when CAN communication failure has occurred.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Battery voltage> 10.9 V
Starter switchOFF
EngineRun
Bus off flag or error warning flagSet (error)

JUDGMENT VALUE

Time Needed for Diagnosis: 436 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
EngineRun
Bus off flag or error warning flagClear (No error)

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Detect malfunction of CAN communication.

Judge as NG when CAN communication failure has occurred between TCM, VDC CM and body integrated unit.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Battery voltage> 10.9 V
Starter switchOFF
EngineRun
ID received from control module connected to CANNone during 500 milliseconds

JUDGMENT VALUE

Time Needed for Diagnosis: 500 ms

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
EngineRun
ID received from control module connected to CANYes

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Note. For the detection standard, refer to DTC U0101. < Ref. to DTC U0101 LOST COMMUNICATION WITH TCM , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC U0101. < Ref. to DTC U0101 LOST COMMUNICATION WITH TCM , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Detect malfunction of CAN communication.

Judge as NG when data received from TCM, VDC CM and body integrated unit is not normal.

  1. Abnormality Judgment

Judge as NG when the following conditions are established.

Malfunction CriteriaThreshold Value
Battery voltage> 10.9 V
Starter switchOFF
EngineRun
Data updated from control module connected to CANNone during 2000 milliseconds

JUDGMENT VALUE

Time Needed for Diagnosis: 2 seconds

Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.

  1. Normality Judgment

Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.

Malfunction CriteriaThreshold Value
EngineRun
Data updated from control module connected to CANYes

JUDGMENT VALUE

Time Needed for Diagnosis: 1000 ms

Note. For the detection standard, refer to DTC U0402. < Ref. to DTC U0402 INVALID DATA RECEIVED FROM TCM , Diagnostic Trouble Code (DTC) Detecting Criteria. >

Note. For the detection standard, refer to DTC U0402. < Ref. to DTC U0402 INVALID DATA RECEIVED FROM TCM , Diagnostic Trouble Code (DTC) Detecting Criteria. >
