Eyesight System (Service Information): Other Subaru Forester SJ

Collision/avoidance 1 illustration ~596 words

CAUTION

  1. Before disassembling or reassembling parts, always disconnect the battery ground cable from battery. When replacing the audio, control module and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
  2. Reassemble the parts in the reverse order of disassembly procedure unless otherwise indicated.
  3. Adjust parts to the given specifications.
  4. Connect the connectors securely during reassembly.
  5. After reassembly, make sure that the functional parts operate normally.
  6. Yellow connectors and harnesses with yellow tapes around them are the connectors and harnesses for the airbag system. Using a tester above such circuits may cause malfunction of airbag system. Follow the cautions for the airbag system in this case. < Ref. to «CAUTION»(ref-662142-S33828179652014101300000) , General Description. >
  7. Be careful not to damage the airbag system wiring harness when servicing electrical parts and switches.
  8. If the steering wheel and steering angle sensor (steering roll connector) are removed, adjust the steering angle sensor. < Ref. to «ADJUSTMENT»(ref-662135-S18423196602014101300000) , VDC Control Module and Hydraulic Control Unit (VDCCM&H/U). >
  9. If the glass is damaged inside the glass repair prohibited area, always perform the glass replacement. < Ref. to «WINDSHIELD GLASS AND DASHBOARD»(ref-662112-S10786578482014101300000) , INSPECTION, General Description. >

Even if a scratch that occurs inside the prohibited area is repaired, this will affect the recognition of the stereo camera, which may cause the EyeSight function not to operate correctly.

GENERAL TOOL

TOOL NAMEREMARKS
Circuit testerUsed for measuring resistance and voltage.
Steering wheel pullerUsed for removing the steering wheel.
Protective tape (masking tape, etc.)Used for removing and installing stereo camera cover assembly.

Scheme 71

Scheme 71: LOCATION
Scheme 71: LOCATION
Relay & fuse boxFuse 15A (stop light and brake switch, brake light relay)(A)

Note. For other related fuses, refer to the wiring diagram. < Ref. to POWER SUPPLY CIRCUIT . >

CHECK FUSE

  1. Remove the fuse and inspect visually.
  2. If the fuse is blown out, replace the fuse. NOTE: If the fuse is blown again, check the system wiring harness.

NOTE

For procedure of each component in the EyeSight system, refer to the respective section.

  1. Control module: < Ref. to «CONTROL UNIT»(ref-662158-S22034091522014101300000) . >
  2. Stereo camera: < Ref. to «STEREO CAMERA»(ref-662158-S14124198682014101300000) . >
  3. Cruise control command switch: < Ref. to «CRUISE CONTROL COMMAND SWITCH»(ref-662158-S40131402352014101300000) . >
  4. Combination meter: < Ref. to «COMBINATION METER»(ref-662158-S00169400192014101300000) . >
  5. Transmission control module (TCM): < Ref. to «TRANSMISSION CONTROL MODULE (TCM)»(ref-662158-S37584467302014101300000) . >
  6. Stop light and brake switch: < Ref. to «STOP LIGHT & BRAKE SWITCH»(ref-662158-S09088904332014101300000) . >
  7. VDC control module & hydraulic control unit (VDCCM&H/U): < Ref. to «VDC CONTROL Module and Hydraulic Control Unit (VDCCM&H/U)»(ref-662158-S20165324362014101300000) . >
  8. Multi-function display (MFD): < Ref. to «MULTI-FUNCTION DISPLAY (MFD)»(ref-662158-S31151187872014101300000) . >
  9. Switches and harness: < Ref. to «SWITCHES AND HARNESS»(ref-662158-S39078763882014101300000) . >

System control of the EyeSight is performed by the following modules.

  1. Engine control module (ECM)
  2. Transmission control module (TCM)
  3. VDC control module (VDCCM)
  4. Stereo camera

P-CR OFF & LANE OFF SWITCH

The P-CR OFF & LANE OFF switch is integrated in the stereo camera cover assembly.

If the P-CR OFF & LANE OFF switch is faulty, replace the stereo camera cover assembly. < Ref. to STEREO CAMERA . >

For the combination meter, refer "INSTRUMENTATION/DRIVER INFO" section. < Ref. to COMBINATION METER . >

For transmission control module (TCM), refer to "CONTINUOUSLY VARIABLE TRANSMISSION" section.

  1. Non-turbo model: < Ref. to «TRANSMISSION CONTROL MODULE (TCM)»(ref-662125-S27199531162014101300000) . >
  2. Turbo model: < Ref. to «TRANSMISSION CONTROL MODULE (TCM)»(ref-662126-S27249512552014101300000) . >

For stop light and brake switch, refer to "BRAKE" section. < Ref. to STOP LIGHT SWITCH . >

For VDC control module & hydraulic control module (VDCCM&H/U), refer to "VEHICLE DYNAMICS CONTROL (VDC)" section. < Ref. to VDC CONTROL MODULE AND HYDRAULIC CONTROL UNIT (VDCCM&H/U) . >

For the multi-function display (MFD), refer to "INSTRUMENTATION/DRIVER INFO" section. < Ref. to MULTI-FUNCTION DISPLAY (MFD) . >
