Continuously Variable Transmission (TR690) (Service Information): Overview Subaru Forester SJ

GENERAL DESCRIPTION

Perform Variator Chain Break-in when the following work has been performed.

1. Variator chain replacement
2. Primary pulley and secondary pulley replacement

1. Follow the messages displayed on the Subaru Select Monitor when working.
2. Perform as necessary in FWD mode.
3. When switched to FWD, AWD light illuminates.

ENGINE BRAKE OPERATION

In each mode of SI drive, check down shifting operation, engine braking, and indicators inside the meters.

P RANGE OPERATION

Stop the vehicle on an uphill grade of 5% or more and shift to the "P" range and apply the parking brake. Check that the vehicle does not move when the parking brake is released.

Before disassembling and assembling the transmission, follow the following procedures to prepare.

Scheme 512

1. Clean the transmission exterior.
2. Remove the torque converter assembly. < Ref. to «REMOVAL»(ref-662126-S33286336972014101300000) , Torque Converter Assembly. >
3. Attach the ST on the transmission. ST 18632AA000 STAND ASSY
4. Remove the transmission cover on the transmission upper side. NOTE: Install using the following tightening torque. Tightening torque: 8 N.m (0.8 kgf-m, 5.9 ft-lb)
5. Place the transmission assembly on end.

Scheme 513

1. Remove the transmission assembly from the vehicle. < Ref. to «REMOVAL»(ref-662126-S27261880402014101300000) , Automatic Transmission Assembly. >
2. Pull out the torque converter assembly horizontally. CAUTION: Do not scratch the inside of engaging parts.
3. Remove the O-ring from the front reduction drive gear.

Scheme 514

1. Install the O-ring to front reduction drive gear. NOTE: Use new O-rings. Apply CVTF to the O-ring.
2. While holding the torque converter assembly by hand, carefully install it into the torque converter case. NOTE: Apply CVTF to the oil seal lip. Do not damage the oil seal and O-ring.
3. Engage the splines while gently rotating the torque converter assembly by hand, and securely insert the assembly.
4. Measure depth "A", from converter case end surface to drive plate contacting surface. Standard (reference): 6.8 mm (0.268 in) or less
5. Install the transmission assembly to the vehicle. < Ref. to «INSTALLATION»(ref-662126-S03255485532014101300000) , Automatic Transmission Assembly. >
