Continuously Variable Transmission (Diagnostics): Other Subaru Forester SJ

PROCEDURE

CHECK

Check the following items when a problem has occurred.

Note. Use copies of this list for interviewing customers.

Scheme 941

SUPPLEMENTAL RESTRAINT SYSTEM "AIRBAG"

The airbag system wiring harness is routed near the TCM.

MEASUREMENT

When measuring the voltage and resistance of the ECM, TCM or each sensor, use a tapered pin with a diameter of less than 0.64 mm (0.025 in) in order to avoid poor contact. Do not insert a pin of more than 0.65 mm (0.026 in) diameter.

BATTERY

Measure the battery voltage and specific gravity of the electrolyte.

Standard voltage: 12 V or more

Specific gravity: 1.260 or more

TRANSMISSION GROUND

Make sure that the ground terminal bolt is tightened securely.

Tightening torque

Non-turbo model

14 N.m (1.4 kgf-m, 10.3 ft-lb)

Scheme 942

Turbo model

16 N.m (1.6 kgf-m, 11.8 ft-lb)

Scheme 943

GENERAL TOOL

Scheme 944

Scheme 945

Scheme 946

Scheme 947

1. Non-turbo model
2. Turbo model

Scheme 948

Scheme 949

1. Non-turbo model
2. Turbo model

Scheme 950

Note. Measure after warming up.

1. Non-turbo model Item Connector No. Terminal No. Measuring condition Measurement value Resistance between terminal and chassis ground Remarks Backup power supply B55 1 - 10 - 13 V - Ignition power supply B55 21 - 10 - 13 V - Main power supply B55 11 - 10 - 13 V - Main power supply B55 2 - 10 - 13 V - Main power supply B55 22 - 10 - 13 V - Manual mode switch B55 4 Manual mode switch ON Less than 1 V - Manual mode switch OFF 8 V or more - Manual mode UP switch B55 5 Manual mode UP switch ON Less than 1 V - Manual mode UP switch OFF 8 V or more - Manual mode DOWN switch B55 16 Manual mode DOWN switch ON Less than 1 V - Manual mode DOWN switch OFF 8 V or more - Stop light switch B55 13 Stop light switch ON 8 V or more - Stop light switch OFF Less than 1 V - P range switch B54 5 P range Less than 1 V - Except for P range 8 V or more - R range switch B54 18 R range Less than 1 V - Except for R range 8 V or more - N range switch B54 9 N range Less than 1 V - Except for N range 8 V or more - D range switch B54 22 D range Less than 1 V - Except for D range 8 V or more - ATF temperature sensor B54 3 ATF temperature at 20°C (68°F) Approx. 2.5 V Approx. 2.5 kohms ATF temperature at 80°C (176°F) Approx. 0.7 V Approx. 330 ohms ATF temperature sensor GND B54 16 Always Approx. 0 V - Secondary pressure sensor power supply output B54 2 Ignition switch ON 5 V - Secondary pressure sensor B54 17 Ignition switch ON, engine OFF Approx. 0.5 V (0 MPa) - Value increases with increase of engine load. (0.5 - 4.5 V) Ignition switch ON, engine ON Approx. 1.0 V (1.0 MPa) - Secondary pressure sensor GND B54 15 Always Approx. 0 V - Primary speed sensor B54 6 While driving 0 or 5 V - Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (sensor) Secondary speed sensor B54 7 While driving 0 or 5 V - Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (sensor) Turbine speed sensor B54 20 Engine ON, "P" or "N" range 0 or 5 V - Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (sensor) Self shut output B55 20 For three seconds after ignition switch ON and OFF Less than 1 V - Ignition switch OFF 8 V or more F&R solenoid B54 11 Engine ON Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (1)) Approx. 4 - 6 ohms Resistance value at 20°C (68°F). Value is higher as the temperature increase. Secondary solenoid B54 12 Engine ON Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (2)) Approx. 5 - 7 ohms Resistance value at 20°C (68°F). Value is higher as the temperature increase. Primary UP solenoid B54 24 Engine ON, while UP shifting Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (3)) Approx. 10 -13.5 ohms Resistance value at 20°C (68°F). Value is higher as the temperature increase. Primary DOWN solenoid B54 25 Engine ON, while DOWN shifting Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (4)) Approx. 10 -13.5 ohms Resistance value at 20°C (68°F). Value is higher as the temperature increase. Lock-up duty solenoid B54 26 Lock-up ON Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (5)) Approx. 10 -13.5 ohms Resistance value at 20°C (68°F). Value is higher as the temperature increase. AWD solenoid B54 13 Engine ON, "P" or "N" range Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (6)) Approx. 2 -4.5 ohms Resistance value at 20°C (68°F). Value is higher as the temperature increase. Engine ON, "D" range, brake ON Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (7)) CAN communication line (+) B55 18 - - - CAN communication line (-) B55 17 - - - GND B54 1 Always Approx. 0 V - GND B54 14 Always Approx. 0 V
2. Turbo model Item Connector No. Terminal No. Measuring condition Measurement value Resistance between terminal and chassis ground Remarks Backup power supply B55 1 - 10 - 13 V - Ignition power supply B55 21 - 10 - 13 V - Main power supply B55 11 - 10 - 13 V - Main power supply B55 2 - 10 - 13 V - Main power supply B55 22 - 10 - 13 V - Manual mode switch B55 4 Manual mode switch ON Less than 1 V - Manual mode switch OFF 8 V or more - Manual mode UP switch B55 5 Manual mode UP switch ON Less than 1 V - Manual mode UP switch OFF 8 V or more - Manual mode DOWN switch B55 16 Manual mode DOWN switch ON Less than 1 V - Manual mode DOWN switch OFF 8 V or more - Stop light switch B55 13 Stop light switch ON 8 V or more - Stop light switch OFF Less than 1 V - P range switch B54 5 P range Less than 1 V - Except for P range 8 V or more - R range switch B54 18 R range Less than 1 V - Except for R range 8 V or more - N range switch B54 9 N range Less than 1 V - Except for N range 8 V or more - D range switch B54 22 D range Less than 1 V - Except for D range 8 V or more - ATF temperature sensor B54 3 ATF temperature at 20°C (68°F) Approx. 2.6 V Approx. 2.6 kohms ATF temperature at 80°C (176°F) Approx. 0.7 V Approx. 370 ohms ATF temperature sensor GND B54 16 Always Approx. 0 V - Secondary pressure sensor power supply output B54 2 Ignition switch ON 5 V - Secondary pressure sensor B54 17 Ignition switch ON, engine OFF Approx. 0.5 V (0 MPa) - Value increases with increase of engine load. (0.5 - 4.5 V) Ignition switch ON, engine ON Approx. 1.0 V (1.0 MPa) - Secondary pressure sensor GND B54 15 Always Approx. 0 V - Primary speed sensor B54 6 While driving 0 or 5 V - Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (sensor) Secondary speed sensor B54 7 While driving 0 or 5 V - Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (sensor) Front wheel speed sensor B54 20 While driving 0 or 5 V - Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (sensor) Self shut output B55 20 For three seconds after ignition switch ON and OFF Less than 1 V - Ignition switch OFF 8 V or more F&R solenoid B54 11 Engine ON Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (1)) Approx. 4 - 6 ohms Resistance value at 20°C (68°F). Value is higher as the temperature increase. Secondary solenoid B54 12 Engine ON Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (2)) Approx. 5 - 7 ohms Resistance value at 20°C (68°F). Value is higher as the temperature increase. Primary UP solenoid B54 24 Engine ON, while UP shifting Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (3)) Approx. 10 - 13.5 ohms Resistance value at 20°C (68°F). Value is higher as the temperature increase. Primary DOWN solenoid B54 25 Engine ON, while DOWN shifting Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (4)) Approx. 10 - 13.5 ohms Resistance value at 20°C (68°F). Value is higher as the temperature increase. Lock-up duty solenoid B54 26 Lock-up ON Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (5)) Approx. 10 - 13.5 ohms Resistance value at 20°C (68°F). Value is higher as the temperature increase. AWD solenoid B54 13 Engine ON, "P" or "N" range Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (6)) Approx. 2 - 4.5 ohms Resistance value at 20°C (68°F). Value is higher as the temperature increase. Engine ON, "D" range, brake ON Refer to the «WAVEFORM»(ref-662155-S38973575002014101300000) (solenoid (7)) Lock-up ON/OFF solenoid B54 23 Lock-up OFF Less than 1 V Approx. 13 - 18.5 ohms Resistance value at 20°C (68°F). Value is higher as the temperature increase. With lock-up ON and R range Battery voltage or higher CAN communication line (+) B55 18 - - - CAN communication line (-) B55 17 - - - GND B54 1 Always Approx. 0 V - GND B54 14 Always Approx. 0 V

Scheme 951

Scheme 952

Scheme 953

1. Non-turbo model
2. Turbo model

HOW TO USE SUBARU SELECT MONITOR

For detailed operation procedures, refer to "Subaru Select Monitor operation manual".

READ CURRENT DATA

For detailed operation procedures, refer to "Subaru Select Monitor operation manual".

1. Non-turbo model Item Display Unit of measure Engine speed signal Engine Speed rpm Turbine speed sensor signal Turbine Speed rpm Accelerator position sensor Accel opening angle % Vehicle speed converted from secondary speed sensor signal Front Wheel Speed km/h or MPH ATF temperature sensor signal A/T Oil Temperature °C or °F Lock-up duty solenoid set duty ratio Lock Up Duty Ratio % AWD solenoid set duty ratio Transfer Duty Ratio % Gear ratio Actual Gear Ratio - Primary speed sensor signal Primary Rev Speed rpm Secondary speed sensor signal Secondary Rev Speed rpm Stop light switch signal Stop Light Switch ON or OFF Secondary fluid pressure sensor signal Actual Secondary Pressure MPa Secondary solenoid indicator current Secondary Set Current mA Secondary solenoid actual current Secondary Actual Current mA F&R solenoid indicator current F&R Linear Solenoid Set Current mA F&R solenoid actual current F&R Linear Solenoid Actual Current mA Battery voltage ECU ACC V Primary UP solenoid set duty ratio Primary UP Duty % Primary DOWN solenoid set duty ratio Primary DOWN Duty % Parking range signal P Range ON or OFF Reverse range signal R Range Signal ON or OFF Neutral range signal N Range ON or OFF Drive range signal D Range Signal ON or OFF L range signal L-range ON or OFF X mode condition X Mode ON or OFF Shift step in manual mode Shift Step in Manual Mode - Manual mode switch signal Tiptronic Mode Switch ON or OFF Manual mode up switch signal Up Switch ON or OFF Manual mode down switch signal Down Switch ON or OFF Secondary fluid pressure A/D converted value secondary pressure sensor voltage. V ATF temperature sensor voltage ATF Temp sensor voltage. V AT OIL TEMP light 2 Hz blink condition Diagnosis Lamp ON or OFF AT OIL TEMP light ON condition ATF Temperature Lamp ON or OFF AT learning mode condition AT learning Completed or Not Completed
2. Turbo model Item Display Unit of measure Engine speed signal Engine Speed rpm Turbine speed signal converted from primary speed sensor signal Turbine Speed rpm Accelerator position sensor Accel opening angle % Vehicle speed converted from front wheel speed sensor signal Front Wheel Speed km/h or MPH ATF temperature sensor signal A/T Oil Temperature °C or °F Lock-up duty solenoid set duty ratio Lock Up Duty Ratio % Lock-up ON/OFF solenoid set Lock-Up ON/OFF Solenoid ON or OFF AWD solenoid set duty ratio Transfer Duty Ratio % Gear ratio Actual Gear Ratio - Primary speed sensor signal Primary Rev Speed rpm Secondary speed sensor signal Secondary Rev Speed rpm Front wheel speed sensor signal Front Wheel Speed rpm Stop light switch signal Stop Light Switch ON or OFF Secondary fluid pressure sensor signal Actual Secondary Pressure MPa Secondary solenoid indicator current Secondary Set Current mA Secondary solenoid actual current Secondary Actual Current mA F&R solenoid indicator current F&R Linear Solenoid Set Current mA F&R solenoid actual current F&R Linear Solenoid Actual Current mA Battery voltage ECU ACC V Primary UP solenoid set duty ratio Primary UP Duty % Primary DOWN solenoid set duty ratio Primary DOWN Duty % Parking range signal P Range ON or OFF Reverse range signal R Range Signal ON or OFF Neutral range signal N Range ON or OFF Drive range signal D Range Signal ON or OFF SI drive mode (control data) SI Drive mode (Control) I, S or S# X mode condition X Mode ON or OFF Shift step in manual mode Shift Step in Manual Mode - Manual mode switch signal Tiptronic Mode Switch ON or OFF Manual mode up switch signal Up Switch ON or OFF Manual mode down switch signal Down Switch ON or OFF AT OIL TEMP light 2 Hz blink condition Diagnosis Lamp ON or OFF AT OIL TEMP light ON condition ATF Temperature Lamp ON or OFF AT learning mode condition AT learning Completed or Not Completed AT ignition power supply relay AT Power Relay ON or OFF

READ FREEZE FRAME DATA

For detailed operation procedures, refer to "Subaru Select Monitor operation manual".

1. Non-turbo model Item Display Unit of measure Relative time since detection Relative time since detection ms Engine speed signal Engine Speed rpm Turbine speed sensor signal Turbine Speed rpm Accelerator position sensor Accel opening angle % Vehicle speed converted from secondary speed sensor signal Front Wheel Speed km/h or MPH ATF temperature sensor signal A/T Oil Temperature °C or °F Lock-up duty solenoid set duty ratio Lock Up Duty Ratio % AWD solenoid set duty ratio Transfer Duty Ratio % Gear ratio Actual Gear Ratio - Primary speed sensor signal Primary Rev Speed rpm Secondary speed sensor signal Secondary Rev Speed rpm Stop light switch signal Stop Light Switch ON or OFF Secondary fluid pressure sensor signal Actual Secondary Pressure MPa Secondary solenoid indicator current Secondary Set Current mA Secondary solenoid actual current Secondary Actual Current mA F&R solenoid indicator current F&R Linear Solenoid Set Current mA F&R solenoid actual current F&R Linear Solenoid Actual Current mA Battery voltage ECU ACC V Primary UP solenoid set duty ratio Primary UP Duty % Primary DOWN solenoid set duty ratio Primary DOWN Duty % Parking range signal P Range ON or OFF Reverse range signal R Range Signal ON or OFF Neutral range signal N Range ON or OFF Drive range signal D Range Signal ON or OFF L range signal L-range ON or OFF X mode condition X Mode ON or OFF Shift step in manual mode Shift Step in Manual Mode - Manual mode switch signal Tiptronic Mode Switch ON or OFF Manual mode up switch signal Up Switch ON or OFF Manual mode down switch signal Down Switch ON or OFF Secondary fluid pressure A/D converted value secondary pressure sensor voltage. V ATF temperature sensor voltage ATF Temp sensor voltage. V AT OIL TEMP light 2 Hz blink condition Diagnosis Lamp ON or OFF AT OIL TEMP light ON condition ATF Temperature Lamp ON or OFF
2. Turbo model Item Display Unit of measure Relative time since detection Relative time since detection ms Engine speed signal Engine Speed rpm Turbine speed signal converted from primary speed sensor signal Turbine Speed rpm Accelerator position sensor Accel opening angle % Vehicle speed converted from front wheel speed sensor signal Front Wheel Speed km/h or MPH ATF temperature sensor signal A/T Oil Temperature °C or °F Lock-up duty solenoid set duty ratio Lock Up Duty Ratio % Lock-up ON/OFF solenoid set Lock-Up ON/OFF Solenoid ON or OFF AWD solenoid set duty ratio Transfer Duty Ratio % Gear ratio Actual Gear Ratio - Primary speed sensor signal Primary Rev Speed rpm Secondary speed sensor signal Secondary Rev Speed rpm Front wheel speed sensor signal Front Wheel Speed rpm Stop light switch signal Stop Light Switch ON or OFF Secondary fluid pressure sensor signal Actual Secondary Pressure MPa Secondary solenoid indicator current Secondary Set Current mA Secondary solenoid actual current Secondary Actual Current mA F&R solenoid indicator current F&R Linear Solenoid Set Current mA F&R solenoid actual current F&R Linear Solenoid Actual Current mA Battery voltage ECU ACC V Primary UP solenoid set duty ratio Primary UP Duty % Primary DOWN solenoid set duty ratio Primary DOWN Duty % Parking range signal P Range ON or OFF Reverse range signal R Range Signal ON or OFF Neutral range signal N Range ON or OFF Drive range signal D Range Signal ON or OFF SI drive mode (control data) SI Drive mode(Control) I, S or S# X mode condition X Mode ON or OFF Shift step in manual mode Shift Step in Manual Mode - Manual mode switch signal Tiptronic Mode Switch ON or OFF Manual mode up switch signal Up Switch ON or OFF Manual mode down switch signal Down Switch ON or OFF AT OIL TEMP light 2 Hz blink condition Diagnosis Lamp ON or OFF AT OIL TEMP light ON condition ATF Temperature Lamp ON or OFF AT learning mode condition AT learning Completed or Not Completed

< Ref. to ROAD TEST . > < Ref. to ROAD TEST . >

PREPARATION FOR LEARNING

1. Warm up or cool down until the ATF temperature displayed on the Subaru Select Monitor is 40 - 65°C (104 - 149°F).
2. After stopping the vehicle, shift the select lever to "P" range.
3. Fully apply the parking brake.
4. Lift up the vehicle. CAUTION: While working, be sure to keep the lower edge of the tires 30 cm or more above the ground as vehicle will vibrate.
5. Connect the Subaru Select Monitor to data link connector.
6. Turn the ignition switch to ON.
7. Turn off all switches causing an electrical load, such as headlights, A/C, seat heater and rear defogger, etc.
8. Set SI-DRIVE to I mode. (Vehicles with SI drive)

SIMPLE LEARNING

Note. Simple learning is performed with the vehicle lifted, without actually running the vehicle.

1. Select {Work Support} in the «Transmission Diagnosis» display screen of the Subaru Select Monitor.
2. Select {Compulsory learning mode} in the «Work Support» display screen of the Subaru Select Monitor.
3. Follow the messages displayed on the Subaru Select Monitor screen when working. NOTE: During AT learning in progress, AT OIL TEMP light in the combination meter starts flashing at 2 Hz and the learning operation starts. The following message is displayed on the screen when the AT OIL TEMP light which was flashing at 2 Hz turns off.
4. When «AT learning normally ended.» is displayed, simple AT learning is completed. NOTE: If communication error occurs during learning, retry the "AT learning mode" from the beginning. If the message «Execute AT learning again after fixing troubles of the vehicle» appears during learning, select [OK] and display the DTC list. After repairing the locations indicated by the DTC, start the "AT learning mode" over from the beginning. When communication error occurs during learning, select lever does not shift occasionally. If select lever does not shift, turn the ignition switch to OFF before operating the select lever. If the message «AT learning ended abnormally.» is displayed, start the "AT learning mode" over from the beginning. Message Main causes for abnormal termination «AT learning ended abnormally.» Fault is detected during AT learning. The accelerator pedal is depressed during AT learning. An unspecified operation was performed during AT learning ATF temperature becomes out of specification during AT learning. Battery voltage is low. Malfunction indicator light illuminates. Parking brake not applied strongly enough. Brake pedal is not fully depressed. Abnormal idle speed increase, etc. For detailed operation procedures, refer to "Subaru Select Monitor operation manual".
