Entertainment System: Removal & Installation Subaru Forester SH рестайлинг

INSTALLATION

Install each part in the reverse order of removal.

Scheme 3

1. Disconnect the ground cable from battery.
2. Remove the front door trim. < Refer to «FRONT DOOR»(ref-465406-S24604543942012042000000) , REMOVAL.
3. Remove the mounting screw of the front speaker.
4. Disconnect the harness connector and remove the front speaker.

Install each part in the reverse order of removal.

Scheme 4

1. Disconnect the ground cable from the battery.
2. Disconnect the harness connector and remove the front door gusset cover.
3. Remove the claws and detach the tweeter.

Install each part in the reverse order of removal.

Scheme 5

1. Disconnect the ground cable from battery.
2. Remove the rear door trim. < Refer to «REAR DOOR»(ref-465406-S18467692322012042000000) , REMOVAL.
3. Remove the mounting screw of the rear speaker.
4. Disconnect the harness connector and remove the rear speaker.

Install each part in the reverse order of removal.

Scheme 6

Scheme 7

1. Remove the roof trim. < Refer to «REMOVAL»(ref-465406-S14178384052012042000000) .
2. Disconnect the harness connector and terminal, and remove the mounting nut (A).
3. Pull out the antenna from the roof top.

Install each part in the reverse order of removal.

Note. For how to attach the feeder cord, refer to the "Roof Trim" INSTALLATION .

REMOVAL

Scheme 8

Scheme 9

Scheme 10

1. Set the front wheels in straight ahead position.
2. Turn the ignition switch to OFF.
3. Disconnect the ground cable from battery and wait for at least 60 seconds before starting work.
4. Using TORX® bit T30 (1), loosen two TORX® bolts which secure the driver's airbag module.
5. Disconnect the airbag module connector on back of the airbag module. < Refer to «PROCEDURE»(ref-465432-S42329161922012042000000) .
6. Remove the steering wheel. < Refer to «REMOVAL»(ref-465415-S03651163672012042000000) .
7. Remove the screws to remove the lower cover from steering wheel.
8. Loosen the screws on the backside of the steering wheel and remove the satellite switch.

Install each part in the reverse order of removal.

Scheme 11

Scheme 12

1. Remove the airbag module from the steering wheel. < Refer to «REMOVAL»(ref-465432-S02801909522012042000000) .
2. Check the resistance between satellite switch connector terminals. Model with normal audio and navigation TERMINAL REFERENCE CHART Switch Position Terminal No. Standard Mute Volume (+) Volume (-) Mode SEEK (↑) SEEK (↓) All OFF 4 and 5 Approx. 4.7 kohms Mute ON 4 and 5 Approx. 22 ohms Volume (+) ON 4 and 5 Approx. 90 ohms Volume (-) ON 4 and 5 Approx. 200 ohms Mode ON 4 and 5 Approx. 360 ohms Preset CH UP/ SEEK (↑) ON 4 and 5 Approx. 690 ohms Preset CH DOWN/SEEK (↓) ON 4 and 5 Approx. 1.5 kohms Model with premium audio (Bluetooth applicable) TERMINAL REFERENCE CHART Switch Position Terminal No. Standard Volume (+) Volume (-) Mode SEEK (↑) SEEK (↓) All OFF 4 and 5 5 and 11 Approx. 100 kohms Volume (+) ON 4 and 5 Approx. 1010 ohms Volume (-) ON 4 and 5 Approx. 3.21 kohms Mode ON 5 and 11 Less than 1 ohms SEEK (↑) ON 4 and 5 Less than 1 ohms SEEK (↓) ON 4 and 5 Approx. 330 ohms
3. Replace the satellite switch if the inspection result is not within the standard value.

Scheme 13

Scheme 14

1. Set the front wheels in straight ahead position.
2. Turn the ignition switch to OFF.
3. Disconnect the ground cable from battery and wait for at least 60 seconds before starting work.
4. Using TORX® bit T30 (1), loosen two TORX® bolts which secure the driver's airbag module.
5. Disconnect the airbag module connector on back of the airbag module. < Refer to «PROCEDURE»(ref-465432-S42329161922012042000000) .
6. Remove the steering wheel.
7. Remove the screws, disconnect the steering switch connector, and remove the lower cover from steering wheel.
8. Remove the screws and remove the steering switch.

Install each part in the reverse order of removal.

Scheme 15

1. Remove the airbag module from the steering wheel. < Refer to «REMOVAL»(ref-465432-S02801909522012042000000) .
2. Connect the tester as shown in the figure, then check resistance between terminals when each switch is pressed. TERMINAL RESISTANCE REFERENCE CHART Switch Resistance No switch pressed 1 Mohms or more HOOK ON Approx. 330 ohms HOOK OFF Approx. 1010 ohms TALK Approx. 3.21 kohms
3. If internal resistance is out of specification shown in the above table, replace the steering switch.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Tightening torque

Rear gate garnish: 4.5 N.m (0.46 kgf-m, 3.3 ft-lb)

Rear wiper motor & wiper arm: < Refer to REAR WIPER , COMPONENT, General Description >

Scheme 16

1. Park the vehicle at the level place where there are enough area at the rear of the vehicle.
2. Attache the tape as the target point for standard at the floor rearward of the vehicle as shown in the figure below. NOTE: Standard tape width is about 30 - 50 mm (1.18 - 1.97 in) and brilliant color shall be used.
3. Confirm the following before checking the corresponding items. If the display is blank. Rearview camera image is not displayed. (Navigation screen or display audio screen is displayed normally.) Check the condition of back sensor connection. < Refer to «CHECK EACH VEHICLE SIGNAL»(ref-465439-S28624999202012042000000) , INSPECTION, Navigation System > Check the condition of rearview camera connection. < Refer to «CHECK EACH CONNECTION»(ref-465439-S29259730082012042000000) , INSPECTION, Navigation System > If the marker is not displayed. Check the condition of vehicle selection. < Refer to «VEHICLE SELECTION MODE»(ref-465439-S06195117782012042000000) , ADJUSTMENT, Rearview Camera System > If the marker position is not aligned. Adjust the marker position according to the MARKER ADJUSTMENT MODE. < Refer to «MARKER ADJUSTMENT MODE»(ref-465439-S13047648892012042000000) , ADJUSTMENT, Rearview Camera System >

Scheme 17

Scheme 18

1. Navigation system CAUTION: When replacing the navigation unit, be sure to replace with specified navigation unit. The marker adjustment can not be performed correctly if replacing with unspecified navigation unit. When the map screen is displayed, press the (b) key for one second while pressing the (a) key + (c) key. When the Maker Line Diag menu screen is displayed, confirm the < P > key is selected. If the < P > key is not selected, select the < P > key. (Press) Turn the ignition switch to OFF and wait for 60 seconds or more before finishing the procedures. CAUTION: Do not turn the ignition switch to ON or disconnect the ground cable from battery within 60 seconds after turning the ignition switch to OFF. The navigation unit data updating can not be performed correctly.

Scheme 19

Scheme 20

Scheme 21

Scheme 22

1. Navigation system CAUTION: When replacing the navigation unit, be sure to replace with specified navigation unit. The marker adjustment can not be performed correctly if replacing with unspecified navigation unit. Prepare the target point. < Refer to «INSPECTION»(ref-465439-S07029469832012042000000) , Rearview Camera System > Display the audio OFF screen by turning the ignition switch to ON, then touch the screen in the order of (1) - (6). When the Dealer Diag menu screen is displayed, touch the "Rear Camera Setup" from the items. CAUTION: Do not select the item other than "Rear Camera Setup". The navigation system can not operate normally. Shift the select lever to the "R" position to display the image of the rearview camera. Touch the adjustment keys on the display screen to adjust the marker line. Confirm that the target point position in the display screen is identified. Adjust by touching the adjustment keys so that the cross line (E) and target point join together. NOTE: Hide OSD key: Touching the Hide OSD key hides the operation keys. When the operation keys are not displayed, touching the display screen displays the operation keys again. Menu key: Touching this key shifts to the Dealer Diag Menu screen. Default key: Touching this key resets the adjustment values to the default condition. Turn the ignition switch to OFF and wait for 60 seconds or more before turning the ignition switch to ON again. CAUTION: If the ignition switch is turned to OFF, be sure to wait for 60 seconds or more before turning the ignition switch to ON again. If turning the ignition switch to ON again or disconnecting the ground cable from battery within 60 seconds after turning the ignition switch to OFF, the navigation unit data updating can not be performed correctly. Shift the select lever to the "R" position to display the image of the rearview camera. Confirm that the marker line position is correctly adjusted before turning the ignition switch to OFF, then finish the procedures.
2. Display audio CAUTION: When replacing the audio unit, be sure to replace with specified audio unit. The marker adjustment can not be performed correctly if replacing with unspecified audio unit. With the main power OFF, turn the TUNE/TRACK/CH dial (b) by 30 clicks while pressing the preset 6 key (a). When the version information screen is displayed, press the MENU/ENTER key (c). When the uploader screen is displayed, press the MENU/ENTER key (c). When the rearview camera marker adjust screen is displayed, press and hold the MENU/ENTER key (c). NOTE: When the ENTER key (c) is tapped, the version information screen is displayed again. With the image of the rearview camera displayed, adjust the rearview camera marker. CAUTION: Operate the keys shown in the table only. KEY OPERATION CHART Key operation Contents TUNE/TRACK/CH dial CCW Line marker moves upward. TUNE/TRACK/CH dial CW Line marker moves downward. >> key Line marker moves to the right. >> key Line marker moves to the left. MENU/ENTER key Modified line marker position is determined, and then rearview camera marker screen is displayed. Turn the ignition switch to OFF and wait for 60 seconds or more before finishing the procedures. CAUTION: Do not turn the ignition switch to ON or disconnect the ground cable from battery within 60 seconds after turning the ignition switch to OFF. The audio unit data updating can not be performed correctly.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Scheme 23

Scheme 24

1. Disconnect the ground cable from battery.
2. Remove the console box. < Refer to «REMOVAL»(ref-465406-S31630772932012042000000) , Console Box >
3. Disconnect the harness connector.
4. Remove the four claws to remove the AUX input terminal by pushing it into the console box.

Install each part in the reverse order of removal.
