Cruise Control System (Diagnostics): Wiring Subaru Forester SH рестайлинг

WIRING DIAGRAM

Refer to CRUISE CONTROL SYSTEM in the Systems Wiring Diagram article. . >

Scheme 8

1. Prepare the Subaru Select Monitor kit.
2. Prepare PC with Subaru Select Monitor installed.
3. Connect the SDI (Subaru Diagnostic Interface) to the PC USB port (exclusively for Subaru Selector Monitor) using a USB cable. NOTE: Port exclusively for Subaru Select Monitor refers to the USB port used when installing Subaru Select Monitor.
4. Connect the diagnosis cable to the SDI.
5. Connect the SDI to data link connector located in the lower portion of the instrument panel (on the driver's side). CAUTION: Do not connect scan tools other than the Subaru Select Monitor.
6. Turn the ignition switch to ON.
7. Start the PC.
8. Run the "PC application for Subaru Select Monitor".
