WIRING DIAGRAM

Refer to SYSTEM WIRING DIAGRAMS article . >

Refer to "Rearview Camera System" in the SYSTEM WIRING DIAGRAMS article . >

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. Disconnect the ground cable from battery.
2. Remove the rear gate trim. < Refer to «REMOVAL»(ref-465406-S04663519642012042000000) , Rear Gate Trim >
3. Remove the rear wiper motor. < Refer to «REMOVAL»(ref-465442-S31868070472012042000000) , Rear Wiper Motor >
4. Remove the rear gate garnish. < Refer to «REMOVAL»(ref-465406-S21487919852012042000000) , Rear Gate Garnish >
5. Remove the rearview camera assembly. Disconnect the connector. Pull out the harness, and then remove the screws. Rotate the camera harness to remove the rearview camera.

Refer to "Front Accessory Power Supply Socket System" in the SYSTEM WIRING DIAGRAMS article . >

Scheme 29

1. Disconnect the ground cable from the battery.
2. Remove the instrument panel lower cover. < Refer to «INSTRUMENT PANEL LOWER»(ref-465406-S06650894442012042000000) , REMOVAL, Center Console >
3. Disconnect the harness connectors and remove the front accessory power supply socket.

Refer to "Rear Accessory Power Supply Socket System" in the SYSTEM WIRING DIAGRAMS article . >

Scheme 30

1. Disconnect the ground cable from battery.
2. Remove the console box. < Refer to «REMOVAL»(ref-465406-S31630772932012042000000) , Console Box >
3. Disconnect the harness connector, and remove the claws (two) in accessory power supply socket.
4. Pull the accessory power supply socket out to remove.
