Diagnostic Trouble Code (DTC) Detecting Criteria (H4SO): Other Subaru Forester SH

Testing & Diagnostics 1 illustration ~1709 words

LIST

DTCItemIndex
P0026Intake Valve Control Solenoid Circuit Range/Performance (Bank 1)Refer to DTC P0026 INTAKE VALVE CONTROL SOLENOID CIRCUIT RANGE/PERFORMANCE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0028Intake Valve Control Solenoid Circuit Range/Performance (Bank 2)Refer to DTC P0028 INTAKE VALVE CONTROL SOLENOID CIRCUIT RANGE/PERFORMANCE (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0030HO2S Heater Control Circuit (Bank 1 Sensor 1)Refer to DTC P0030 HO2S HEATER CONTROL CIRCUIT (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0031HO2S Heater Control Circuit Low (Bank 1 Sensor 1)Refer to DTC P0031 HO2S HEATER CONTROL CIRCUIT LOW (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0032HO2S Heater Control Circuit High (Bank 1 Sensor 1)Refer to DTC P0032 HO2S HEATER CONTROL CIRCUIT HIGH (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0037HO2S Heater Control Circuit Low (Bank 1 Sensor 2)Refer to DTC P0037 HO2S HEATER CONTROL CIRCUIT LOW (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0038HO2S Heater Control Circuit High (Bank 1 Sensor 2)Refer to DTC P0038 HO2S HEATER CONTROL CIRCUIT HIGH (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0068MAP/MAF - Throttle Position CorrelationRefer to DTC P0068 MAP/MAF - THROTTLE POSITION CORRELATION , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0076Intake Valve Control Solenoid Circuit Low (Bank 1)Refer to DTC P0076 INTAKE VALVE CONTROL SOLENOID CIRCUIT LOW (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0077Intake Valve Control Solenoid Circuit High (Bank 1)Refer to DTC P0077 INTAKE VALVE CONTROL SOLENOID CIRCUIT HIGH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0082Intake Valve Control Solenoid Circuit Low (Bank 2)Refer to DTC P0082 INTAKE VALVE CONTROL SOLENOID CIRCUIT LOW (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0083Intake Valve Control Solenoid Circuit High (Bank 2)Refer to DTC P0083 INTAKE VALVE CONTROL SOLENOID CIRCUIT HIGH (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0101Mass or Volume Air Flow Circuit Range/PerformanceRefer to DTC P0101 MASS OR VOLUME AIR FLOW CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0102Mass or Volume Air Flow Circuit Low InputRefer to DTC P0102 MASS OR VOLUME AIR FLOW CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0103Mass or Volume Air Flow Circuit High InputRefer to DTC P0103 MASS OR VOLUME AIR FLOW CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0107Manifold Absolute Pressure/Barometric Pressure Circuit Low InputRefer to DTC P0107 MANIFOLD ABSOLUTE PRESSURE/BAROMETRIC PRESSURE CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0108Manifold Absolute Pressure/Barometric Pressure Circuit High InputRefer to DTC P0108 MANIFOLD ABSOLUTE PRESSURE/BAROMETRIC PRESSURE CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0111Intake Air Temperature Sensor 1 Circuit Range/PerformanceRefer to DTC P0111 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0112Intake Air Temperature Sensor 1 Circuit LowRefer to DTC P0112 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0113Intake Air Temperature Sensor 1 Circuit HighRefer to DTC P0113 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0117Engine Coolant Temperature Circuit LowRefer to DTC P0117 ENGINE COOLANT TEMPERATURE CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0118Engine Coolant Temperature Circuit HighRefer to DTC P0118 ENGINE COOLANT TEMPERATURE CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0122Throttle/Pedal Position Sensor/Switch "A" Circuit LowRefer to DTC P0122 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A" CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0123Throttle/Pedal Position Sensor/Switch "A" Circuit HighRefer to DTC P0123 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A" CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0125Insufficient Coolant Temperature for Closed Loop Fuel ControlRefer to DTC P0125 INSUFFICIENT COOLANT TEMPERATURE FOR CLOSED LOOP FUEL CONTROL , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0126Insufficient Engine Coolant Temperature for Stable OperationRefer to DTC P0126 INSUFFICIENT ENGINE COOLANT TEMPERATURE FOR STABLE OPERATION , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0128Coolant Thermostat (Engine Coolant Temperature Below Thermostat Regulating Temperature)Refer to DTC P0128 COOLANT THERMOSTAT (ENGINE COOLANT TEMPERATURE BELOW THERMOSTAT REGULATING TEMPERATURE) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0131O2 Sensor Circuit Low Voltage (Bank 1 Sensor 1)Refer to DTC P0131 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0132O2 Sensor Circuit High Voltage (Bank 1 Sensor 1)Refer to DTC P0132 O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0133O2 Sensor Circuit Slow Response (Bank 1 Sensor 1)Refer to DTC P0133 O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0134O2 Sensor Circuit No Activity Detected (Bank 1 Sensor 1)Refer to DTC P0134 O2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0137O2 Sensor Circuit Low Voltage (Bank 1 Sensor 2)Refer to DTC P0137 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0138O2 Sensor Circuit High Voltage (Bank 1 Sensor 2)Refer to DTC P0138 O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0139O2 Sensor Circuit Slow Response (Bank 1 Sensor 2)Refer to DTC P0139 O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0140O2 Sensor Circuit No Activity Detected (Bank 1 Sensor 2)Refer to DTC P0140 O2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0171System Too Lean (Bank 1)Refer to DTC P0171 SYSTEM TOO LEAN (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0172System Too Rich (Bank 1)Refer to DTC P0172 SYSTEM TOO RICH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0181Fuel Temperature Sensor "A" Circuit Range/PerformanceRefer to DTC P0181 FUEL TEMPERATURE SENSOR "A" CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0182Fuel Temperature Sensor "A" Circuit Low InputRefer to DTC P0182 FUEL TEMPERATURE SENSOR "A" CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0183Fuel Temperature Sensor "A" Circuit High InputRefer to DTC P0183 FUEL TEMPERATURE SENSOR "A" CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0196Engine Oil Temperature Sensor Circuit Range/PerformanceRefer to DTC P0196 ENGINE OIL TEMPERATURE SENSOR CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0197Engine Oil Temperature Sensor LowRefer to DTC P0197 ENGINE OIL TEMPERATURE SENSOR LOW , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0198Engine Oil Temperature Sensor HighRefer to DTC P0198 ENGINE OIL TEMPERATURE SENSOR HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0222Throttle/Pedal Position Sensor/Switch "B" Circuit LowRefer to DTC P0222 THROTTLE/PEDAL POSITION SENSOR/SWITCH "B" CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0223Throttle/Pedal Position Sensor/Switch "B" Circuit HighRefer to DTC P0223 THROTTLE/PEDAL POSITION SENSOR/SWITCH "B" CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0301Cylinder 1 Misfire DetectedRefer to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0302Cylinder 2 Misfire DetectedRefer to DTC P0302 CYLINDER 2 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0303Cylinder 3 Misfire DetectedRefer to DTC P0303 CYLINDER 3 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0304Cylinder 4 Misfire DetectedRefer to DTC P0304 CYLINDER 4 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0327Knock Sensor 1 Circuit Low (Bank 1 or Single Sensor)Refer to DTC P0327 KNOCK SENSOR 1 CIRCUIT LOW (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0328Knock Sensor 1 Circuit High (Bank 1 or Single Sensor)Refer to DTC P0328 KNOCK SENSOR 1 CIRCUIT HIGH (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0335Crankshaft Position Sensor "A" CircuitRefer to DTC P0335 CRANKSHAFT POSITION SENSOR "A" CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0336Crankshaft Position Sensor "A" Circuit Range/PerformanceRefer to DTC P0336 CRANKSHAFT POSITION SENSOR "A" CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0340Camshaft Position Sensor "A" Circuit (Bank 1 or Single Sensor)Refer to DTC P0340 CAMSHAFT POSITION SENSOR "A" CIRCUIT (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0341Camshaft Position Sensor "A" Circuit Range/Performance (Bank 1 or Single Sensor)Refer to DTC P0341 CAMSHAFT POSITION SENSOR "A" CIRCUIT RANGE/PERFORMANCE (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0400Exhaust Gas Recirculation FlowRefer to DTC P0400 EXHAUST GAS RECIRCULATION FLOW , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0420Catalyst System Efficiency below Threshold (Bank 1)Refer to DTC P0420 CATALYST SYSTEM EFFICIENCY BELOW THRESHOLD (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0442Evaporative Emission Control System Leak Detected (Small Leak)Refer to DTC P0442 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (SMALL LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0447Evaporative Emission Control System Vent Control Circuit OpenRefer to DTC P0447 EVAPORATIVE EMISSION CONTROL SYSTEM VENT CONTROL CIRCUIT OPEN , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0448Evaporative Emission Control System Vent Control Circuit ShortedRefer to DTC P0448 EVAPORATIVE EMISSION CONTROL SYSTEM VENT CONTROL CIRCUIT SHORTED , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0451Evaporative Emission Control System Pressure SensorRefer to DTC P0451 EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0452Evaporative Emission Control System Pressure Sensor Low InputRefer to DTC P0452 EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0453Evaporative Emission Control System Pressure Sensor High InputRefer to DTC P0453 EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0456Evaporative Emission Control System Leak Detected (Very Small Leak)Refer to DTC P0456 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (VERY SMALL LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0457Evaporative Emission Control System Leak Detected (Fuel Cap Loose/Off)Refer to DTC P0457 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (FUEL CAP LOOSE/OFF) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0458Evaporative Emission System Purge Control Valve Circuit LowRefer to DTC P0458 EVAPORATIVE EMISSION SYSTEM PURGE CONTROL VALVE CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0459Evaporative Emission System Purge Control Valve Circuit HighRefer to DTC P0459 EVAPORATIVE EMISSION SYSTEM PURGE CONTROL VALVE CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0461Fuel Level Sensor "A" Circuit Range/PerformanceRefer to DTC P0461 FUEL LEVEL SENSOR "A" CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0462Fuel Level Sensor "A" Circuit LowRefer to DTC P0462 FUEL LEVEL SENSOR "A" CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0463Fuel Level Sensor "A" Circuit HighRefer to DTC P0463 FUEL LEVEL SENSOR "A" CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0464Fuel Level Sensor Circuit IntermittentRefer to DTC P0464 FUEL LEVEL SENSOR CIRCUIT INTERMITTENT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0500Vehicle Speed Sensor "A"Refer to DTC P0500 VEHICLE SPEED SENSOR "A" , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0506Idle Air Control System RPM Lower Than ExpectedRefer to DTC P0506 IDLE AIR CONTROL SYSTEM RPM LOWER THAN EXPECTED , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0507Idle Air Control System RPM Higher Than ExpectedRefer to DTC P0507 IDLE AIR CONTROL SYSTEM RPM HIGHER THAN EXPECTED , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0512Starter Request CircuitRefer to DTC P0512 STARTER REQUEST CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0513Incorrect Immobilizer KeyRefer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0600Serial Communication LinkRefer to DTC P0600 SERIAL COMMUNICATION LINK , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0604Internal Control Module Random Access Memory (RAM) ErrorRefer to DTC P0604 INTERNAL CONTROL MODULE RANDOM ACCESS MEMORY (RAM) ERROR , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0605Internal Control Module Read Only Memory (ROM) ErrorRefer to DTC P0605 INTERNAL CONTROL MODULE READ ONLY MEMORY (ROM) ERROR , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0607Throttle Control System Circuit Range/PerformanceRefer to DTC P0607 THROTTLE CONTROL SYSTEM CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0638Throttle Actuator Control Range/Performance (Bank 1)Refer to DTC P0638 THROTTLE ACTUATOR CONTROL RANGE/PERFORMANCE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0700Transmission Control System (MIL Request)Refer to DTC P0700 TRANSMISSION CONTROL SYSTEM (MIL REQUEST) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0851Park/Neutral Switch Input Circuit Low (AT Model)Refer to DTC P0851 PARK/NEUTRAL SWITCH INPUT CIRCUIT LOW (AT MODEL) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0851Neutral Switch Input Circuit Low (MT Model)Refer to DTC P0851 NEUTRAL SWITCH INPUT CIRCUIT LOW (MT MODEL) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0852Park/Neutral Switch Input Circuit High (AT Model)Refer to DTC P0852 PARK/NEUTRAL SWITCH INPUT CIRCUIT HIGH (AT MODEL) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P0852Neutral Switch Input Circuit High (MT Model)Refer to DTC P0852 NEUTRAL SWITCH INPUT CIRCUIT HIGH (MT MODEL) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1152O2 Sensor Circuit Range/Performance (Low) (Bank 1 Sensor 1)Refer to DTC P1152 O2 SENSOR CIRCUIT RANGE/PERFORMANCE (LOW) (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1153O2 Sensor Circuit Range/Performance (High) (Bank 1 Sensor 1)Refer to DTC P1153 O2 SENSOR CIRCUIT RANGE/PERFORMANCE (HIGH) (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1160Return Spring FailureRefer to DTC P1160 RETURN SPRING FAILURE , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1400Fuel Tank Pressure Control Solenoid Valve Circuit LowRefer to DTC P1400 FUEL TANK PRESSURE CONTROL SOLENOID VALVE CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1420Fuel Tank Pressure Control Sol. Valve Circuit HighRefer to DTC P1420 FUEL TANK PRESSURE CONTROL SOL. VALVE CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1443Vent Control Solenoid Valve Function ProblemRefer to DTC P1443 VENT CONTROL SOLENOID VALVE FUNCTION PROBLEM , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1491Positive Crankcase Ventilation (Blow-by) Function ProblemRefer to DTC P1491 POSITIVE CRANKCASE VENTILATION (BLOW-BY) FUNCTION PROBLEM , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1492EGR Solenoid Valve Signal #1 Circuit Malfunction (Low Input)Refer to DTC P1492 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1493EGR Solenoid Valve Signal #1 Circuit Malfunction (High Input)Refer to DTC P1493 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1494EGR Solenoid Valve Signal #2 Circuit Malfunction (Low Input)Refer to DTC P1494 EGR SOLENOID VALVE SIGNAL #2 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1495EGR Solenoid Valve Signal #2 Circuit Malfunction (High Input)Refer to DTC P1495 EGR SOLENOID VALVE SIGNAL #2 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1496EGR Solenoid Valve Signal #3 Circuit Malfunction (Low Input)Refer to DTC P1496 EGR SOLENOID VALVE SIGNAL #3 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1497EGR Solenoid Valve Signal #3 Circuit Malfunction (High Input)Refer to DTC P1497 EGR SOLENOID VALVE SIGNAL #3 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1498EGR Solenoid Valve Signal #4 Circuit Malfunction (Low Input)Refer to DTC P1498 EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1499EGR Solenoid Valve Signal #4 Circuit Malfunction (High Input)Refer to DTC P1499 EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1560Back-up Voltage Circuit MalfunctionRefer to DTC P1560 BACK-UP VOLTAGE CIRCUIT MALFUNCTION , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1570AntennaRefer to DTC P1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1571Reference Code IncompatibilityRefer to DTC P1571 REFERENCE CODE INCOMPATIBILITY , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1572IMM Circuit Failure (Except Antenna Circuit)Refer to DTC P1572 IMM CIRCUIT FAILURE (EXCEPT ANTENNA CIRCUIT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1574Key Communication FailureRefer to DTC P1574 KEY COMMUNICATION FAILURE , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1576EGI Control Module EEPROMRefer to DTC P1576 EGI CONTROL MODULE EEPROM , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1577IMM Control Module EEPROMRefer to DTC P1577 IMM CONTROL MODULE EEPROM , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1578Meter FailureRefer to DTC P1578 METER FAILURE , Diagnostic Trouble Code (DTC) Detecting Criteria.
P1602Control Module Programming ErrorRefer to DTC P1602 CONTROL MODULE PROGRAMMING ERROR , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2096Post Catalyst Fuel Trim System Too Lean (Bank 1)Refer to DTC P2096 POST CATALYST FUEL TRIM SYSTEM TOO LEAN (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2097Post Catalyst Fuel Trim System Too Rich (Bank 1)Refer to DTC P2097 POST CATALYST FUEL TRIM SYSTEM TOO RICH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2101Throttle Actuator Control Motor Circuit Range/PerformanceRefer to DTC P2101 THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2102Throttle Actuator Control Motor Circuit LowRefer to DTC P2102 THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2103Throttle Actuator Control Motor Circuit HighRefer to DTC P2103 THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2109Throttle/Pedal Position Sensor "A" Minimum Stop PerformanceRefer to DTC P2109 THROTTLE/PEDAL POSITION SENSOR "A" MINIMUM STOP PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2122Throttle/Pedal Position Sensor/Switch "D" Circuit Low InputRefer to DTC P2122 THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2123Throttle/Pedal Position Sensor/Switch "D" Circuit High InputRefer to DTC P2123 THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2127Throttle/Pedal Position Sensor/Switch "E" Circuit Low InputRefer to DTC P2127 THROTTLE/PEDAL POSITION SENSOR/SWITCH "E" CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2128Throttle/Pedal Position Sensor/Switch "E" Circuit High InputRefer to DTC P2128 THROTTLE/PEDAL POSITION SENSOR/SWITCH "E" CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2135Throttle/Pedal Position Sensor/Switch "A"/"B" Voltage CorrelationRefer to DTC P2135 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A"/"B" VOLTAGE CORRELATION , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2138Throttle/Pedal Position Sensor/Switch "D"/"E" Voltage CorrelationRefer to DTC P2138 THROTTLE/PEDAL POSITION SENSOR/SWITCH "D"/"E" VOLTAGE CORRELATION , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2227Barometric Pressure Circuit Range/PerformanceRefer to DTC P2227 BAROMETRIC PRESSURE CIRCUIT RANGE/PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2228Barometric Pressure Circuit LowRefer to DTC P2228 BAROMETRIC PRESSURE CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria.
P2229Barometric Pressure Circuit HighRefer to DTC P2229 BAROMETRIC PRESSURE CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria.

DIAGNOSTIC TROUBLE CODE

ENABLE CONDITION

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
After engine starting> or = 6000 ms
Engine oil temperature> or = 15°C (59°F)
Variable valve lift controlOperation

ENABLE CONDITION

GENERAL DRIVING CYCLE

Perform the diagnosis continuously 6 seconds after engine start while variable valve lift is being controlled.

Secondary ParametersEnable Conditions
Condition established time> or = 42000 ms
Battery voltage> or = 10.9 V
Heater currentPermitted
Control duty > or = 35 %Experienced
After fuel cut> or = 20000 ms

ENABLE CONDITION

Perform the diagnosis continuously after 42000 ms seconds or more have passed since the engine started.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Elapsed time after engine starting> or = 1 second
Engine speed< 8000 RPM

ENABLE CONDITION

After starting the engine, perform the diagnosis continuously when engine speed is low.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Elapsed time after engine starting> or = 1 second
Engine speed< 8000 RPM

ENABLE CONDITION

After starting the engine, perform the diagnosis continuously when engine speed is low speed.

Secondary ParametersEnable Conditions
Engine coolant temperature> or = 75°C (167°F)

ENABLE CONDITION

Perform the diagnosis continuously after idling.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Engine coolant temperature> or = 75°C (167°F)

ENABLE CONDITION

Perform the diagnosis continuously after idling.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Engine coolant temperature at engine starting< 30 °C (86 °F)
Engine coolant temperature> or = 100°C (212°F)
Battery voltage> or = 10.9 V
Continuous time when the vehicle speed is less than 60 km/h (37.3 MPH)> or = 600 s

ENABLE CONDITION

Perform the diagnosis when the vehicle speed condition is met after warming up from a cold condition.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Engine speed> or = Value from Map
Battery voltage> or = 10.9 V

ENABLE CONDITION

Map

Engine coolant temperature °C (°F)40 (-40)30 (-22)20 (-4)10 (14)0 (32)10 (50)20 (68)30 (86)
Engine speed : RPM500500500500500500500500

ENGINE COOLANT TEMPERATURE SPECIFICATION

Engine coolant temperature °C (°F)40 (104)50 (122)60 (140)70 (158)80 (176)90 (194)100 (212)110 (230)
Engine speed : RPM500500500500500500500500

ENGINE COOLANT TEMPERATURE SPECIFICATION

Perform the diagnosis only once after engine start.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Refueling from the last engine stop till the current engine startNone
Fuel level> or = 15 l (3.96 US gal, 3.3 lmp gal)
Engine coolant temperature at the last engine stop> or = 75°C (167°F)

ENABLE CONDITION

Perform the diagnosis only once after starting the engine.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Time needed for all secondary parameters to be in enable conditions> or = 1024 ms
Battery voltage> or = 10.9 V
Barometric pressure75 kPa (563 mmHg, 22.2 inHg)
Closed loop control with main feedbackOperation
Front oxygen (A/F) sensor impedance0 ohms - 50 ohms
Elapsed time after starting the engine> or = 120000 ms
Engine coolant temperature> or = 75°C (167°F)
Engine speed1000 RPM - 3200 RPM
Vehicle speed10 km/h - 120 km/h (6.2 MPH - 74.6 MPH)
Amount of intake air10 g/s - 40 g/s (0.35 oz/s - 1.41 oz/s)
Engine load< 0.02 g/rev (0 oz/rev)
Learning value of EVAP cone, during purge< 0.2
Total time of operating canister purge> or = 19.9 s

ENABLE CONDITION

Perform diagnosis only once at a constant speed of 10 km/h - 120 km/h (6.2 MPH - 74.6 MPH) 120000 ms or more after starting the engine.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Used for abnormality judgement

Secondary ParametersEnable Conditions
High
Secondary air systemNot in operation
Closed loop control at the oxygen sensorIn operation
Misfire detection every 200 rotations< 5 time(s)
Front oxygen (A/F) sensor compensation coefficientNot in limit value
Battery voltage> or = 10.9 V
Engine coolant temperature> or = 75°C (167°F)
Low (1)
Secondary air systemNot in operation
Closed loop control at the oxygen sensorIn operation
Misfire detection every 200 rotations< 5 time(s)
Front oxygen (A/F) sensor compensation coefficientNot in limit value
Battery voltage> or = 10.9 V
Engine coolant temperature> or = 75°C (167°F)
Amount of intake air> or = 10g/s (0.35 oz/s)
Low (2)
Secondary air systemNot in operation
Closed loop control at the oxygen sensorIn operation
Misfire detection every 200 rotations< 5 time(s)
Front oxygen (A/F) sensor compensation coefficientNot in limit value
Battery voltage> or = 10.9 V
Engine coolant temperature> or = 75°C (167°F)
Amount of intake air< 10 g/s (0.35 oz/s)
Current continuation time of the rear oxygen sensor heater> or = 30000 ms
Low (3)
Secondary air systemNot in operation
Closed loop control at the oxygen sensorIn operation
Misfire detection every 200 rotations< 5 time(s)
Front oxygen (A/F) sensor compensation coefficientNot in limit value
Battery voltage> or = 10.9 V
Engine coolant temperature> or = 75°C (167°F)
Amount of intake air< 10 g/s (0.35 oz/s)
Current continuation time of the rear oxygen sensor heater> or = 30000 ms
Fuel cutExperienced

ENABLE CONDITION

Used for normality judgement

Secondary ParametersEnable Conditions
Secondary air systemNot in operation
Closed loop control at the oxygen sensorIn operation
Misfire detection every 200 rotations< 5 time(s)
Front oxygen (A/F) sensor compensation coefficientNot in limit value
Battery voltage> or = 10.9 V
Engine coolant temperature> or = 75°C (167°F)

ENABLE CONDITIONS

After starting the engine, continuously perform the diagnosis with the same engine condition.

Rich --> lean diagnosis response

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
A/F main feedback control conditionCompleted
Deceleration fuel cut time is 6000 ms or more.Experienced
After fuel cut> or = 2000 ms
Current calculation time of the rear oxygen sensor heater> or = 55000 ms
Current continuation time of the rear oxygen sensor heater> or = 29000 ms
Estimated catalyst temperature> or = 480 °C (896 °F)
Number of deceleration fuel cut> or = 1 time(s)

ENABLE CONDITION

Perform the diagnosis only once when deceleration fuel cut occurs after rapid acceleration. (Pay attention to the oxygen sensor voltage for the timing of the deceleration).

Lean --> rich response diagnosis

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
A/F main feedback control conditionCompleted
Deceleration fuel cut time is 6000 ms or more.Experienced
After fuel cut> or = 2000 ms
Current calculation time of the rear oxygen sensor heater> or = 55000 ms
Current continuation time of the rear oxygen sensor heater> or = 29000 ms
Estimated catalyst temperature> or = 450 °C (842 °F)
Number of deceleration fuel cut> or = 1 time(s)

ENABLE CONDITION

Perform the diagnosis only once when deceleration fuel cut occurs after rapid acceleration. (Pay attention to the oxygen sensor voltage for the timing of the deceleration).

ENABLE CONDITION (USED ONLY FOR MALFUNCTION JUDGEMENT)

Secondary ParametersEnable Conditions
Closed loop control at the rear oxygen sensorIn operation
Target output voltage of rear oxygen sensor> or = 0.55 V + 0.05 V
Amount of intake air> or = 10 g/s (0.35 oz/s)
Engine coolant temperature> or = 75°C (167°F)
Misfire detection every 200 rotations< 5 time(s)
Front oxygen (A/F) sensor compensation coefficientNot in limit value
Battery voltage> or = 10.9 V
Deceleration fuel cut of 6000 ms or more.Experienced

ENABLE CONDITION

Perform the diagnosis once after starting the engine.

Secondary ParametersEnable Conditions
A/F main learning systemIn operation
Engine coolant temperature> or = 75°C (167°F)
Engine load change< 0.02 g/rev (0 oz/rev)
Engine load> or = Value of Map 1

ENABLE CONDITION

Map 1

Engine speed (RPM)Idling65010001500200025003000350040004500
Measured value (g(oz)/rev)Na0.208 (0.01)0.201 (0.01)0.185 (0.01)0.183 (0.01)0.193 (0.01)0.206 (0.01)0.206 (0.01)0.225 (0.01)0.245 (0.01)

ENGINE SPEED REFERENCE

Perform the diagnosis continuously at idling or at a constant speed after warming up the engine.

Secondary ParametersEnable Conditions
A/F main learning systemIn operation
Engine coolant temperature> or = 75°C (167°F)
Engine load change< or = 0.02 g/rev (0 oz/rev)
Learning value of EVAP cone.< 0.15
Cumulative time of canister purge after engine start> or = 20 s
Continuous period after canister purge starting> or = 29884 ms
Engine load> or = Value of Map 1

ENABLE CONDITION

Map 1

Engine speed (RPM)Idling65010001500200025003000350040004500
Measured value (g(oz)/rev)Na0.208 (0.01)0.201 (0.01)0.185 (0.01)0.183 (0.01)0.193 (0.01)0.206 (0.01)0.206 (0.01)0.225 (0.01)0.245 (0.01)

DIAGNOSED VALUE - MAP 1

Perform the diagnosis continuously at idling or at a constant speed after warming up the engine.

Always perform the diagnosis continuously.

Always perform diagnosis after 20 seconds have passed since the engine started.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Engine speed> or = Value from Map

ENABLE CONDITION

Map

Engine coolant temperature °C (°F)40 (-40)30 (-22)20 (-4)10 (14)0 (32)10 (50)20 (68)30 (86)
Engine speed : RPM500500500500500500500500

ENGINE COOLANT TEMPERATURE SPECIFICATION

Engine coolant temperature °C (°F)40 (104)50 (122)60 (140)70 (158)80 (176)90 (194)100 (212)110 (230)
Engine speed RPM500500500500500500500500

ENGINE COOLANT TEMPERATURE SPECIFICATION

Perform the diagnosis continuously after starting the engine.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
All secondary parameters enable conditions> or = 1024 ms
Intake manifold pressure change at 180°CA< Value of Map 1
Throttle position change during 16 milliseconds< 21 °
Fuel shut-off functionNot in operation
Fuel level> or = 9.6 l (2.54 US gal, 2.11 lmp gal)
Vehicle dynamic control or AT torque controlNot in operation
Evaporative system leak checkNot in operation
Engine speed460 RPM - 6300 RPM
Intake manifold pressure> or = Value of Map 2
Battery voltage> or = 8 V
Fuel parameter determinationNot extremely low volatility
Elapsed time after starting the engine> or = 0 ms
Engine load change during 32 milliseconds< 1000 RPM

ENABLE CONDITION

Map 1

  1. AT model VEHICLE SPEED REFERENCE - AT MODEL RPM 700 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6300 kPa (mmHg, inHg) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9)
  2. MT model VEHICLE SPEED REFERENCE - MT MODEL RPM 650 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6300 kPa (mmHg, inHg) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) 13.3 (100, 3.9) Map 2
  3. AT model VEHICLE SPEED REFERENCE - AT MODEL RPM 700 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6300 kPa (mmHg, inHg) 26 (195.0, 7.7) 23.9 (179.5, 7.1) 23.3 (174.7, 6.9) 23.1 (173.2, 6.8) 23.6 (176.8, 7) 25.1 (188.0, 7.4) 26.2 (196.9, 7.8) 26.6 (199.6, 7.9) 26.9 (201.5, 7.9) 30 (225.0, 8.9) 33.4 (250.4, 9.9) 37.8 (283.5, 11.2) 39.5 (296.0, 11.7)
  4. MT model Vehicle speed < 64 km/h (39.8 MPH) VEHICLE SPEED REFERENCE - MT MODEL RPM 650 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6300 kPa (mmHg, inHg) 24.5 (184, 7.2) 22.7 (170.3, 6.7) 21.4 (160.2, 6.3) 21.5 (161.6, 6.4) 21.5 (161.4, 6.4) 23.2 (174.4, 6.9) 24.7 (185.5, 7.3) 25.8 (193.3, 7.6) 27.1 (203.2, 8) 28.8 (216.3, 8.5) 32.3 (242.2, 9.5) 36.3 (272, 10.7) 37.9 (284.5, 11.2)

Vehicle speed > or = 68 km/h (42.3 MPH)

RPM650100015002000250030003500400045005000550060006300
KPa (mmHg, inHg)31.6 (237, 9.3)31.6 (237, 9.3)31.6 (237, 9.3)31.1 (233, 9.2)31.3 (235, 9.3)33.1 (248, 9.8)33.9 (254, 10)28.8 (216, 8.5)30.1 (226, 8.9)33.3 (250, 9.8)36.9 (277, 10.9)40.1 (301, 11.9)43.2 (324, 12.8)

VEHICLE SPEED REFERENCE - MT MODEL

  1. If conditions are met, it is possible to detect the misfires from idling to high engine speed. However, in case any engine load or breakage occurs, perform with the engine at idle.
  2. Perform the diagnosis continuously.
Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Battery voltage> or = 8 V
Engine speed< 4000 RPM

ENABLE CONDITION

Perform the diagnosis continuously under 3000 RPM engine revs.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Cylinder number identificationCompleted
Battery voltage> or = 8 V
Engine speed550 RPM - 1000 RPM
Engine operationIdling
MisfireNot detected
Engine load change during 4 milliseconds< or = 12799.8 RPM

ENABLE CONDITION

Always perform the diagnosis continuously at idle speed.

Secondary ParametersEnable Conditions
Elapsed time after starting the engine> or = 40 s
Engine coolant temperature> or = 75°C(167°F)
Engine speed1200 RPM - 2950 RPM
Intake manifold pressure (absolute pressure)< 44 kPa (330 mmHg, 13 inHg)
Ambient air temperature> or = 5 °C(41 °F)
Throttle position< 0.25 °
Battery voltage> or = 10.9 V
Barometric pressure> or = 75 kPa (563 mmHg, 22.2 inHg)
Vehicle speed> or =58 km/h (36 MPH)
Fuel shut-off functionIn operation
Neutral switchOFF
After neutral switch ON/OFF change> or = Value from Map
No load change (A/C, power steering, lighting, rear defogger, heater fan and radiator fan)> or = 5000 ms

ENABLE CONDITION

Map

Engine coolant temperature °C (°F)40 (-40)30 (-22)20 (-4)10 (14)0 (32)10 (50)20 (68)30 (86)
After neutral switch change msec00000000

ENGINE COOLANT TEMPERATURE SPECIFICATION

Engine coolant temperature °C (°F)40 (104)50 (122)60 (140)70 (158)80 (176)90 (194)100 (212)110 (230)
After neutral switch change msec00000000

ENGINE COOLANT TEMPERATURE SPECIFICATION

During deceleration fuel cut from 53 km/h (approx. 33 MPH) or more, perform diagnosis once. Be careful of vehicle speed and engine speed. (Diagnosis will not be completed if the vehicle speed and engine speed conditions become out of specification due to deceleration).

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Barometric pressure> or = 75 kPa (563 mmHg, 22.2 inHg)
Engine coolant temperature> or = 70°C (158°F)
Estimated catalyst temperature> or = 645°C (1193°F)
Misfire detection every 200 rotations< 5 time(s)
Learning value of evaporation gas density<0.2
Sub feedbackIn operation
Evaporative system diagnosisNot in operation
Time of difference (< 0.10) between actual lambda and target lambda> or = 1000 ms
Vehicle speed70 km/h (43.5 MPH)
Amount of intake air> or = 10g/s (0.35 oz/s) and < 40g/s (1.41 oz/s)
Engine load change every 0.5 engine revs.< 0.02 g/rev (0 oz/rev)
Rear oxygen output change from 660 mV or less to 660 mV or moreExperienced after fuel cut
Elapsed time after starting the engine> or = 205s
Purge execution calculated time> or = 0s

ENABLE CONDITION

Perform the diagnosis only once at a constant 70 km/h (43.5 MPH) or higher.

Pressure control solenoid valve

PCV controls the fuel tank pressure to be equal to the atmospheric air pressure. Normally, the solenoid is set to OFF. The valve opens and closes mechanically in accordance with the pressure difference between tank and atmospheric air, or tank and canister.

The valve is forcibly opened by setting the solenoid to ON at the time of diagnosis.

Scheme 173

Scheme 173: Pressure control solenoid valve

Purpose of Mode Z

When performing the leakage diagnosis of EVAP system, the purge control solenoid valve must operate normally. Therefore, mode Z is used to diagnose the purge control solenoid valve stuck open condition. Note that if a purge control solenoid valve stuck open fault is detected, the EVAP system leakage diagnosis is cancelled.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Elapsed time after starting the engine> or = 60s
Fuel level> or = 9.6 l (2.54 US gal, 2.11 lmp gal)
Fuel temperature< 35 °C (95 °F)
Battery voltage> or = 10.9 V
Barometric pressure> or = 75 kPa (563 mmHg, 22.2 inHg)

ENABLE CONDITION

  1. Perform the diagnosis continuously after 60 s have passed since the engine started.
  2. Pay attention to the fuel level and temperature.
Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Time needed for all secondary parameters to be in enable conditions> or = 5000 ms
Vehicle speed> or = 2 km/h (1.2 MPH)
All conditions of EVAP canister purgeCompleted
Learning value of evaporation gas concentration (left and right)< 0.08
Main feedback compensation coefficient (left and right)> or = 0.9
Battery voltage> or = 10.9 V

ENABLE CONDITION

Perform the diagnosis when purging enable conditions are met without idling.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Elapsed time after starting the engine> or = 1 second

ENABLE CONDITION

Always perform the diagnosis after starting the engine.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Elapsed time after starting the engine> or = 1 second

ENABLE CONDITION

Always perform the diagnosis after starting the engine.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Malfunction CriteriaThreshold Value
Engine speed> or = 500 RPM
Elapsed time after starting the engine> or = 1 second
Battery voltage> or = 10.9 V
Idle switchON
Fuel level> or = 9.6 l (2.54 US gal, 2.11 lmp gal) and < 54.4 l (14.37 US gal, 11.97 lmp gal)
Vehicle speed = 0 km/h (0 MPH)> or = 10000 ms

ENABLE CONDITION

  1. Always perform the diagnosis continuously at idle speed.
  2. Pay attention to the fuel level.
Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Elapsed time after engine starting> or = 2000 ms

ENABLE CONDITION

Always perform diagnosis more than 2000 ms after starting the engine.

Secondary ParametersEnable Conditions
Engine coolant temperature> or = 75°C (167°F)
Battery voltage> or = 10.9 V
Barometric pressure> or = 75 kPa (563 mmHg, 22.2 inHg)
Fuel level> or = 9.6 l (2.54 US gal, 2.11 lmp gal)
Elapsed time after starting the engine> or = 10.49 s
Feedback of ISCIn operation
Lambda value (left and right)> or = 0.81 and < 1.1
After switching air conditioner to ON/OFF> or = 5.1 s
After intake manifold pressure changes by 4 kPa (30 mmHg, 1.2 inHg) or more.5.1 s
Elapsed time after switching neutral position switch to ON/OFF5.1 s
Vehicle speed0 km/h (0 MPH)

ENABLE CONDITION

Perform the diagnosis continuously at idling after warming up engine.

Secondary ParametersEnable Conditions
Engine coolant temperature> or = 75°C (167°F)
Battery voltage> or = 10.9 V
Barometric pressure> or = 75 kPa (563 mmHg, 22.2 inHg)
Fuel level> or = 9.6 l (2.54 US gal, 2.11 lmp gal)
Elapsed time after starting the engine> or = 10.49 s
Feedback of ISCIn operation
Lambda value (left and right)> or = 0.81 and < 1.1
After switching air conditioner to ON/OFF> or = 5.1 s
After intake manifold pressure changes by 4 kPa (30 mmHg, 1.2 inHg) or more.5.1 s
Elapsed time after switching neutral position switch to ON/OFF5.1 s
Vehicle speed0 km/h (0 MPH)

ENABLE CONDITION

Perform the diagnosis continuously at idling after warming up engine.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

When starting the engine.

Perform the diagnosis only after starting the engine.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Perform the diagnosis continuously after starting the engine.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Diagnosis with the initial routine.

Perform the diagnosis as soon as the ignition switch is turned to ON.

Secondary ParametersEnable Conditions
Ignition switchON

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
(1) Ignition switchON
(2) Ignition switchON
(3) None
(4) None
(5) Throttle opening angle
(6) Brake switch (only with cruise control)ON
(7) None

ENABLE CONDITION

(1) - (4): Always perform the diagnosis continuously.

(5): Always perform the diagnosis continuously when idling.

(6): Perform the diagnosis when the brake pedal is depressed.

(7): Always perform the diagnosis continuously.

(8): Always perform the diagnosis continuously when the cruise control pedal is not operating.

Secondary ParametersEnable Conditions
Ignition switchON
Normal operation of electronic throttle controlON

ENABLE CONDITION

Always perform the diagnosis continuously when the electronic throttle control is operating.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Starter relayOFF

ENABLE CONDITION

Perform the diagnosis continuously in 2 seconds after starting the engine.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Starter relayOFF

ENABLE CONDITION

Perform the diagnosis continuously in 2 seconds after starting the engine.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Starter relayOFF

ENABLE CONDITION

Perform the diagnosis continuously in 2 seconds after starting the engine.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Starter relayOFF

ENABLE CONDITION

Perform the diagnosis continuously in 2 seconds after starting the engine.

Secondary ParametersEnable Conditions
Time needed for all secondary parameters to be in enable conditions> or = 4096 ms
Battery voltage> or = 10.9 V
Barometric pressure> or = 75 kPa (563 mmHg, 22.2 inHg)
Rear oxygen sensor sub feedbackExecution
Rear oxygen sensor output voltage - Feedback target voltage0.2 V - 0.1 V
Or
Rear oxygen sensor sub feedback compensation coefficientOn Min.
Or
UI Rear oxygen sensor sub feedback compensation coefficientOn Max.
Elapsed time after starting the engine> or = 60000 ms
Engine coolant temperature> or = 75°C (167°F)
Vehicle speed> or = 20 km/h (12.4 MPH)
Amount of intake air> or = 6 g/s (0.21 oz/s)
Load change at 180°CA< 0.02 g/rev (0 oz/rev)
Front oxygen (A/F) sensor impedance0 ohms - 50 ohms
Learning value of evaporation gas density<0.2
Total time of operating canister purge> or = 19.9 s
Targeted lambda value load compensation coefficient0.03 - 0.000

ENABLE CONDITION

Perform diagnosis continuously at a constant speed of 20 km/h (12.4 MPH) or more after 60000 ms have passed since the engine started.

Secondary ParametersEnable Conditions
Time needed for all secondary parameters to be in enable conditions> or = 4096 ms
Battery voltage> or = 10.9 V
Barometric pressure> or = 75 kPa (563 mmHg, 22.2 inHg)
Rear oxygen sensor sub feedbackExecution
Rear oxygen sensor output voltage - Feedback target voltage0.2 V - 0.1 V
Or
Rear oxygen sensor sub feedback compensation coefficientOn Min.
Or
Rear oxygen sensor sub feedback compensation coefficientOn Max.
Elapsed time after starting the engine> or = 60000 ms
Engine coolant temperature> or = 75°C (167°F)
Vehicle speed> or = 20 km/h (12.4 MPH)
Amount of intake air> or = 6 g/s (0.21 oz/s)
Load change at 180°CA< 0.02 g/rev (0 oz/rev)
Front oxygen (A/F) sensor impedance0 ohms - 50 ohms
Learning value of evaporation gas density< 0.2
Total time of operating canister purge> or = 19.9 s
Targeted lambda value load compensation coefficient0.03 - 0.000

ENABLE CONDITION

Perform diagnosis continuously at a constant speed of 20 km/h (12.4 MPH) or more after 60000 ms have passed since the engine started.

Secondary ParametersEnable Conditions
Battery voltage> or = 6V
Throttle position sensorNormal

ENABLE CONDITION

  1. Ignition switch ON --> OFF
  2. Ignition switch OFF --> ON (Only after clearing memory)
Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis after starting the engine.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis after starting the engine.

Secondary ParametersEnable Conditions
Drain valveOpen
Battery voltage> or = 10.9 V
Barometric pressure> or = 75 kPa (563 mmHg, 22.2 inHg)
Tank pressure when starter is OFF --> ON0.4 kPa (-3.2 mmHg, -0.1 inHg) and 1.4 kPa (10.7 mmHg, 0.4 inHg)

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Elapsed time after starting the engine> or = 1 second
EGR valve target position0 step
Battery voltage> or = 10.9 V

ENABLE CONDITION

Perform diagnosis continuously during EGR operation.

Secondary ParametersEnable Conditions
Elapsed time after starting the engine> or = 1 second
EGR valve target position0 step
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Barometric pressure> or = 75 kPa (563 mmHg, 22.2 inHg)
Battery voltage> or = 10.9 V
Cold start diagnosisIncomplete
Vehicle speed< 2 km/h (1.2 MPH)
Misfire within 200 engine revs.< 5
Time after starting= 14 seconds

ENABLE CONDITION

Perform the diagnosis at cold start.

Secondary ParametersEnable Conditions
Conditions for carrying out the sub feedback learningCompleted
Continuous time when all conditions are established.> or = 1 s

ENABLE CONDITION

Perform the diagnosis continuously when the vehicle is idling or running at a constant speed of 80 km/h (50 MPH) or more.

Secondary ParametersEnable Conditions
Conditions for carrying out the sub feedback learningCompleted
Continuous time when all conditions are established.> or = 1 s

ENABLE CONDITION

Perform the diagnosis continuously when the vehicle is idling or running at a constant speed of 80 km/h (50 MPH) or more.

Secondary ParametersEnable Conditions
Under control of electronic throttle controlON

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Electronic throttle control relay outputON

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Electronic throttle control relay outputOFF

ENABLE CONDITION

  1. When ignition switch ON --> OFF
  2. Ignition switch OFF --> ON (Only after clearing memory)
Secondary ParametersEnable Conditions
Ignition switchON --> OFF
Ignition switch (only after clear memory)OFF --> ON

ENABLE CONDITION

Perform the diagnosis at full closed point learning.

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6V

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
Engine speed< 300 RPM
Vehicle speed< 1 km/h (0.6 MPH)

ENABLE CONDITION

Perform the diagnosis once at ignition switch ON.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.
