INSTALLATION
Install in the reverse order of removal.
Scheme 31
Scheme 32
- Inspect the continuity between each connector terminal. If continuity is not as specified, replace the switch.
- Intermittent operation inspection
- Turn the wiper switch to INT.
- Adjust the intermittent control switch to MAX.
- Apply battery voltage to switch terminals 16 and 2, and inspect the voltage of terminals 7 and 2. (Measure the voltage from after the second time the wiper stops.)
Scheme 33
If operation is not as specified, replace the switch.
REMOVAL
While pushing the locking clip (A) up, pull out the blade from arm to arrow direction.
Scheme 34
- Install in the reverse order of removal.
- Confirm that the clip is locked securely.
Install in the reverse order of removal.
- Tightening torque: 6.0 N.m (0.61 kgf-m, 4.4 ft-lb)
- Install in the reverse order of removal.
- Adjust the position of the washer liquid sprayer. Refer to «ADJUSTMENT»(ref-200805-S12597151182005102300000) , Front Washer Nozzle.
- Install in the reverse order of removal.
- Adjust the position of the washer liquid sprayer. Refer to «ADJUSTMENT»(ref-200805-S04601009672005102300000) , Rear Washer.
Install in the reverse order of removal.
Scheme 35
Scheme 36
- Disconnect the connector from the wiper control relay.
- Connect the positive (+) lead from the battery to terminal 8 and the negative (-) lead to terminal 6. Connect the positive (+) lead from the voltmeter to terminal 3 and the negative (-) lead to ground.
- Measure the voltage when the wiper relay is operated. If operation is not as specified, replace the switch.
