Washer System & Wiper System: Adjustments Subaru Forester SG

ADJUSTMENT

Operate the wiper once. Align the wiper blade to ceramic print point mark (A) of front window pane.

Scheme 5

Scheme 6

Scheme 7

1. Disconnect the ground cable from battery.
2. Remove the cowl panel. Refer to «REMOVAL»(ref-200811-S09801602192005102300000) , Cowl Panel.
3. Disconnect the connector of motor.
4. Loosen the bolts and nuts to remove wiper link.
5. Loosen the bolts and nuts to remove motor.

Scheme 8

1. Install the wiper link to the vehicle, and then connect the motor connector.
2. Connect the battery ground cable to battery.
3. To confirm that the motor is at auto stop position, turn the wiper switch ON/OFF once.
4. Disconnect the ground cable from battery.
5. Tighten the nut where rod (A) and link plate (B) is aligned in a straight line.
6. Install in the reverse order of removal. Tightening torque: Refer to «FRONT WIPER»(ref-200805-S16912044612005102300000) , COMPONENT, General Description.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. Connect the battery to wiper motor connectors and confirm that motor operates at low speed.
2. Connect the battery to terminal of connectors and confirm that motor operates at high speed.
3. Connect the battery to terminals of connector, and remove the terminal connection with motor rotated at low speed, and stop the wiper motor through operation.
4. Connect the battery and confirm that the motor stops at automatic stop position after the motor operates at low speed again.

Scheme 13

1. Remove the washer hose from the washer nozzle.
2. Open the clips on the underside of the hood with a thin screwdriver or other tool, and remove the washer nozzle.
