TROUBLE SHOOTING
- Turn ignition switch to ACC or IGN position. Check power mirror fuse. See «WIRING DIAGRAMS»(ref-121729-S36337952442001090500000). If fuse is okay, turn ignition switch off. Remove power window switch. See «POWER MIRROR SWITCH»(ref-121729-S24606054152001090500000) under REMOVAL & INSTALLATION. Disconnect switch harness connector. Turn ignition switch to ACC or RUN position. Check voltage at switch harness connector terminal No. 4. See «POWER MIRROR SWITCH CONNECTOR TERMINAL IDENTIFICATION»(ref-121729-S11625665912001090500000). (Scheme 1) If battery voltage exists, go to next step. If battery voltage does not exist, repair wiring as necessary.
- Turn ignition off. Check resistance between ground and switch harness connector terminal No. 2 (ground). See «POWER MIRROR SWITCH CONNECTOR TERMINAL IDENTIFICATION»(ref-121729-S11625665912001090500000). If resistance is 10 ohms or greater, repair open in Black wire. If resistance is not 10 ohms or greater, go to «COMPONENT TESTS»(ref-121729-S08388191502001090500000).
POWER MIRROR SWITCH TEST
Remove power mirror switch from center console. See POWER MIRROR SWITCH under REMOVAL & INSTALLATION. Disconnect mirror switch connector. Check continuity between specified terminals of switch connector, with switch button in specified position(s). (Scheme 1) See POWER MIRROR SWITCH CONTINUITY TEST table. Replace switch if continuity is not as specified.
| Switch Position | Terminal No. | ||
|---|---|---|---|
| Changeover Switch | (1) | ||
| Mirror Switch (2) | |||
| Left Mirror | |||
| Up | 1 & 2; 4 & 7 | ||
| Down | 1 & 4; 2 & 7 | ||
| Left | 1 & 2; 4 & 9 | ||
| Right | 1 & 4; 2 & 9 | ||
| Right Mirror | |||
| Up | 1 & 2; 4 & 6 | ||
| Down | 1 & 4; 2 & 6 | ||
| Left | 1 & 2; 4 & 8 | ||
| Right | 1 & 4; 2 & 8 | ||
| (1) Information is not available from the manufacturer. (2) Changeover switch controls which mirror is activated. Both mirrors use same terminals for similar operational functions. | |||
| (1) | Information is not available from the manufacturer. |
| (2) | Changeover switch controls which mirror is activated. Both mirrors use same terminals for similar operational functions. |
POWER MIRROR SWITCH CONTINUITY TEST
Scheme 1
POWER MIRROR MOTOR TEST
Remove door panel. Disconnect mirror motor harness connector. Using 12-volt power supply and 2 jumper wires, apply voltage and ground to specified terminal. See appropriate POWER MIRROR MOTOR TEST table. (Scheme 2)
| Application & Movement | Terminal No. (+) (Wire Color) | Terminal No. (-) (Wire Color) | |
|---|---|---|---|
| Left Mirror | |||
| Up | 1 (Red/Black) | 3 (Red) | |
| Down | 3 (Red) | 1 (Red/Black) | |
| Left | 2 (Blue/Red) | 3 (Red) | |
| Right | 3 (Red) | 2 (Blue/Red) | |
| Right Mirror | |||
| Up | 1 (Red/Blue) | 3 (Red) | |
| Down | 3 (Red) | 1 (Red/Blue) | |
| Left | 2 (Green/Red) | 3 (Red) | |
| Right | 3 (Red) | 2 (Green/Red) | |
POWER MIRROR MOTOR TEST (FORESTER)
| Application & Movement | Terminal No. (+) (Wire Color) | Terminal No. (-) (Wire Color) | |
|---|---|---|---|
| Left Mirror | |||
| Up | 3 (Red/Black | 1 (Red) | |
| Down | 1 (Red) | 3 (Red/Black) | |
| Left | 2 (Blue/Red) | 1 (Red) | |
| Right | 1 (Red) | 2 (Blue/Red) | |
| Right Mirror | |||
| Up | 3 (Red/Blue) | 1 (Red) | |
| Down | 1 (Red) | 3 (Red/Blue) | |
| Left | 2 (Blue/Red) | 1 (Red) | |
| Right | 1 (Red) | 2 (Blue/Red) | |
POWER MIRROR MOTOR TEST (IMPREZA)
| Application & Movement | Terminal No. (+) (Wire Color) | Terminal No. (-) (Wire Color) | |
|---|---|---|---|
| Left Mirror | |||
| Up | 1 (Red/Yellow | 3 (Red/Blue) | |
| Down | 3 (Red/Blue) | 1 (Red/Yellow) | |
| Left | 2 (Red/White) | 3 (Red/Blue) | |
| Right | 3 (Red/Blue) | 2 (Red/White) | |
| Right Mirror | |||
| Up | 1 (Blue/Green | 3 (Red/White) | |
| Down | 3 (Red/White) | 1 (Blue/Green) | |
| Left | 2 (Blue/White) | 3 (Red/White) | |
| Right | 3 (Red/White) | 2 (Blue/White) | |
POWER MIRROR MOTOR TEST (LEGACY & OUTBACK)
