MONITOR STRATEGY
| Related DTC | P1607: Internal control module range check |
| Required sensors/Components (Main) | ECM |
| Required sensors /Components (Related) | Cruise control |
| Frequency of Operation | Continuous |
| Duration | 0.3 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever the following DTCs are not present | None |
| DMA communication error | Not detected |
TYPICAL MALFUNCTION THRESHOLDS
| Cruise control | Forbiddance |
| When either condition below is met | |
| Cruise control | Operating |
| Low speed control | Operating |
Scheme 348
Scheme 348: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the DTCs. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P1607.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
PROCEDURE
- READ OUTPUT DTC (DTC P1607) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTC. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . Turn the ignition switch to OFF and turn the tester OFF. Disconnect the tester. Disconnect the cable from the battery negative (-) terminal and wait for 1 minute. Connect the cable to the battery negative (-) terminal. Connect the tester to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to No output A P1607 B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-388734-S30722680022011031100000)
- REPLACE ECM. Refer to «REMOVAL»(ref-388735-S27161698942011031100000)
| Related DTCs | P2102: Throttle actuator current (low current) P2103: Throttle actuator current (high current) |
| Required Sensors/Components (Main) | Throttle actuator (throttle body) |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Continuous |
| Duration | P2102: 2 seconds P2103: 0.6 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Throttle actuator | ON |
| Duty-cycle ratio to open throttle actuator | 80% or more |
| Throttle actuator power supply | 8 V or more |
| Motor current change during latest 0.016 seconds | Less than 0.2 A |
| Throttle actuator | ON |
| Either of the following conditions 1 or 2 is met | |
| 1. Throttle actuator power supply | 8 V or more |
| 2. Throttle actuator power | ON |
| Battery voltage | 8 V or more |
| Starter | OFF |
| Throttle actuator current | Less than 0.5 A |
| Either of following conditions is met | A or B |
| A. Hybrid IC diagnosis signal | Fail |
| B. Hybrid IC current limiter port | Fail |
Scheme 349
Scheme 349: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- With the vehicle stationary, fully depress the accelerator pedal and quickly release it [B].
- Check that 16 seconds or more have elapsed from the instant when the accelerator pedal is first depressed.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the DTCs. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2102 or P2103.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
FAIL-SAFE
When either of these DTCs or other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions, is set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned OFF.
Scheme 350
Scheme 350: WIRING DIAGRAM
| Related DTCs | P2111: Throttle actuator stuck open P2112: Throttle actuator stuck closed |
| Required Sensors/Components (Main) | Throttle actuator (throttle body) |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| All of following conditions are met | |
| System guard* judge condition | ON |
| Throttle actuator current | 2 A or more |
| Duty cycle to close throttle | 80% or more |
P2111 (THROTTLE ACTUATOR STUCK OPEN)
| All of following conditions are met | |
| System guard* judge condition | ON |
| Throttle actuator current | 2 A or more |
| Duty cycle to open throttle | 80% or more |
P2112 (THROTTLE ACTUATOR STUCK CLOSED)
| *System guard set when following conditions are met | |
| Throttle actuator | ON |
| Throttle actuator duty calculation | Executing |
| Throttle position sensor fail | Not detected |
| Throttle actuator current-cut operation | Not executing |
| Throttle actuator power supply | 4 V or higher |
| Throttle actuator fail | Not detected |
| TP sensor voltage change for 0.016 seconds | Less than 0.1 V for 0.5 seconds or more |
P2111 (THROTTLE ACTUATOR STUCK OPEN)
| TP sensor voltage change for 0.016 seconds | Less than 0.1 V for 0.5 seconds or more |
P2112 (THROTTLE ACTUATOR STUCK CLOSED)
Scheme 351
Scheme 351: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and fully depress and release the accelerator pedal quickly (to fully open and close the throttle valve).
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the DTCs. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2111 or P2112.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When either of these DTCs or other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions, is set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned to OFF.
- INSPECT THROTTLE BODY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and the housing. If necessary, clean the throttle body. And check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 3 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . Refer to the confirmation driving pattern for P2111 and P2112. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to No output A P2111 or P2112 B B --> See step 4 A --> See step 5
- REPAIR OR REPLACE THROTTLE BODY. Refer to «REMOVAL»(ref-388735-S12806086742011031100000)
- REPLACE ECM. Refer to «REMOVAL»(ref-388735-S27161698942011031100000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-388734-S30722680022011031100000)
| Related DTCs | P2118: Throttle actuator power supply |
| Required Sensors/Components (Main) | Throttle actuator, throttle valve (throttle body) ETCS fuse |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Continuous |
| Duration | 0.8 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Battery voltage | 8 V or more |
| Electronic throttle actuator power | ON |
| Throttle actuator power supply voltage (+BM) | Less than 4 V |
COMPONENT OPERATING RANGE
| Throttle actuator power supply voltage (+BM) | 11 to 14 V |
Scheme 352
Scheme 352: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Slowly depress the accelerator pedal, raise the engine speed to approximately 3000 rpm for approximately 5 seconds, and then idle the engine [B].
- Check that 16 seconds or more have elapsed since the engine was started.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the DTCs. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2118.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When this DTC, or other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions, are set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned to OFF.
Scheme 353
Scheme 353: WIRING DIAGRAM
| Related DTCs | P2119: ETCS malfunction |
| Required Sensors/Components (Main) | Throttle actuator (throttle body) |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | Closed: 1 second Open: 0.6 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| System guard* judge condition | ON |
| *System guard is ON when the following conditions met | |
| Throttle actuator | ON |
| Throttle actuator duty calculation | Executing |
| Throttle position sensor fail | Not detected |
| Throttle actuator current-cut operation | Not executing |
| Throttle actuator power supply | 4 V or higher |
| Throttle actuator fail | Not detected |
| Either of following conditions A or B is met | |
| A. Commanded closed TP - current closed TP | 0.3 V or more for 1 second |
| B. Commanded open TP - current open TP | 0.3 V or more for 0.6 seconds |
Scheme 354
Scheme 354: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 20 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the DTCs. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2119.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, fully depress and release the accelerator pedal 3 times, and then check the DTC judgment result [C].
- If no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When this DTC, as well as other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions, is set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned to OFF.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to P2119 A P2119 and other DTCs B HINT: If any DTCs other than P2119 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
- INSPECT THROTTLE BODY (RESISTANCE OF THROTTLE ACTUATOR) Disconnect the throttle body connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2(M+) - 1(M-) 20°C(68°F) 0.3 to 100 ohms Reconnect the throttle body connector. NG --> See step 6 OK: Go to next step
- REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-388735-S27161698942011031100000) NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . Allow the engine to idle for 15 seconds or more. Refer to the confirmation driving pattern for P2119. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. OK No DTC output. HINT: The output voltage of the throttle position sensor can be checked using the Techstream. Variations in the output voltage indicate that the throttle actuator is in operation. To check the output voltage using the Techstream, Enter the following menus: Powertrain / Engine and ECT / ETCS / Throttle Position No. 1. NG --> See step 6 OK --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-388734-S31814561492011031100000)
- REPLACE THROTTLE BODY. Refer to «REMOVAL»(ref-388735-S12806086742011031100000)
| Related DTCs | P2120: Accelerator Pedal Position (APP) sensor 1 range check (fluctuating) P2122: APP sensor 1 range check (low voltage) P2123: APP sensor 1 range check (high voltage) P2125: APP sensor 2 range check (fluctuating) P2127: APP sensor 2 range check (low voltage) P2128: APP sensor 2 range check (high voltage) P2138: APP sensor range check (correlation) |
| Required Sensors/Components (Main) | APP sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds: P2120, P2122, P2125 and P2127 2.0 seconds: P2123, P2128 and P2138 |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Either of following conditions 1 or 2 met | |
| 1. Ignition switch | ON |
| 2. Throttle actuator power | ON |
| Either of following conditions 1 or 2 met | |
| 1. VPA voltage when VPA2 voltage 0.04 V or more | 0.4 V or less |
| 2. VPA voltage | 4.8 V or more |
| VPA voltage when VPA2 voltage 0.04 V or more | 0.4 V or less |
| Either of following conditions 1 or 2 met | |
| 1. VPA2 voltage when VPA voltage 0.04 V or more | 1.2 V or less |
| 2. VPA2 voltage when VPA voltage 0.4 to 3.45 V | 4.8 V or more |
| VPA2 voltage when VPA voltage 0.04 V or more | 1.2 V or less |
| VPA2 voltage when VPA voltage 0.4 to 3.45 V | 4.8 V or more |
| Either of following conditions A or B met | |
| Condition A | |
| Difference between VPA and VPA 2 voltages | 0.02 V or less |
| Condition B | |
| VPA voltage | 0.4 V or less |
| VPA2 voltage | 1.2 V or less |
| VPA voltage | 0.4 to 4.8 V |
| VPA2 voltage | 1.2 to 4.8 V |
| Difference between VPA and VPA2 voltages | More than 0.02 V |
Scheme 355
Scheme 355: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Fully depress and release the accelerator pedal [B].
- Check that 5 seconds or more have elapsed since the DTCs were cleared.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the DTCs. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2120, P2122, P2123, P2125, P2127, P2128 or P2138.
- Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When any of DTCs P2120, P2121, P2122, P2123, P2125, P2127, P2128 and P2138 are set, the ECM enters fail-safe mode. If either of the 2 sensor circuits malfunctions, the ECM uses the remaining circuit to calculate the accelerator pedal position to allow the vehicle to continue driving. If both of the circuits malfunction, the ECM regards the accelerator pedal as being released. As a result, the throttle valve is closed and the engine idles.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is turned to OFF.
Scheme 356
Scheme 356: WIRING DIAGRAM
| Related DTCs | P2121: Accelerator pedal position (APP) sensor rationality |
| Required Sensors/Components (Main) | APP sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| APP sensor circuit (P2120, P2122, P2123, P2125, P2127, P2128 P2138) | Not detected |
| Either of following conditions 1 or 2 met | |
| 1. Ignition switch | ON |
| 2. Electronic throttle actuator power | ON |
| Difference between VPA voltage (learned value) and VPA2 voltage (learned value) | Less than 0.4 V, or more than 1.2 V |
Scheme 357
Scheme 357: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Fully depress and release the accelerator pedal [B].
- Check that 20 seconds or more have elapsed since the DTCs were cleared.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the DTCs. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2121.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
The accelerator pedal position sensor has two (main and sub) sensor circuits. If a malfunction occurs in either of the sensor circuits, the ECM detects the abnormal signal voltage difference between the two sensor circuits and switches to fail-safe mode. In fail-safe mode, the functioning circuit is used to calculate the accelerator pedal opening angle to allow the vehicle to continue driving. If both circuits malfunction, the ECM regards the opening angle of the accelerator pedal as being fully closed. In this case, the throttle valve remains closed as if the engine is idling.
If a pass condition is detected and then the ignition switch is turned to OFF, the fail-safe operation stops and the system returns to a normal condition.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2121) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to P2121 A P2121 and other DTCs B HINT: If any DTCs other than P2121 are output, troubleshoot those DTCs first. B --> See step 7 A: Go to next step
- READ VALUE USING TECHSTREAM (ACCELERATOR POSITION SENSOR) See step 1 NG --> See step 3 OK --> See step 6
- REPLACE ACCELERATOR PEDAL ROD ASSEMBLY Replace the accelerator pedal rod assembly. Refer to «REMOVAL»(ref-388735-S04914580752011031100000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (ACCELERATOR PEDAL POSITION SENSOR DTCS) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . Start the engine. Refer to the confirmation driving pattern for P2121. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to P2121 A No output B B --> END A --> See step 5
- REPLACE ECM. Refer to «REMOVAL»(ref-388735-S27161698942011031100000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-388734-S30722680022011031100000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-388734-S31814561492011031100000)
| Related DTCs | P2195: Air Fuel Ratio (A/F) sensor (Bank 1) signal stuck lean P2196: A/F sensor (Bank 1) signal stuck rich |
| Required Sensors/Components (Main) | A/F sensor |
| Required Sensors/Components (Related) | Heated Oxygen (HO2) sensor |
| Frequency of Operation | Continuous |
| Duration | 5 seconds: Sensor voltage detection monitor 3 seconds: Sensor current detection monitor |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0016 (VVT system - misalignment) P0017 (Exhaust VVT system - misalignment) P0031, P0032, P101D(Air fuel ratio sensor heater - sensor 1) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120 - P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop) P0128 (Thermostat) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340 (Camshaft position sensor) P0451, P0452, P0453 (EVAP system) P0500 (Vehicle speed sensor) P0505 (IAC valve) |
| Time after engine start | 30 seconds or more |
| Fuel system status | Closed-loop |
SENSOR VOLTAGE DETECTION MONITOR (LEAN SIDE MALFUNCTION P2195)
| Time after engine start | 30 seconds or more |
| Fuel system status | Closed-loop |
SENSOR VOLTAGE DETECTION MONITOR (RICH SIDE MALFUNCTION P2196)
| Battery voltage | 11 V or more |
| Atmospheric pressure | 76 kPa (570 mmHg) or higher |
| Air-fuel ratio sensor status | Activated |
| Engine coolant temperature | 75°C (167°F) or more |
| Continuous time of fuel cut | 3 to 10 seconds |
SENSOR CURRENT DETECTION MONITOR (P2195, P2196)
| Rear HO2 sensor output voltage | Rises from less than 0.21 V to 0.59 V or more |
| A/F sensor voltage | More than 3.8 V |
SENSOR VOLTAGE DETECTION MONITOR (LEAN SIDE MALFUNCTION P2195)
| Rear HO2 sensor output voltage | Falls from 0.59 V or more to less than 0.21 V |
| A/F sensor voltage | Less than 2.8 V |
SENSOR VOLTAGE DETECTION MONITOR (RICH SIDE MALFUNCTION P2196)
| Air-fuel ratio sensor current during fuel cut | 2.2 mA or more |
SENSOR CURRENT DETECTION MONITOR (HIGH SIDE MALFUNCTION P2195)
| Air-fuel ratio sensor current during fuel cut | Less than 0.7 mA |
SENSOR CURRENT DETECTION MONITOR (LOW SIDE MALFUNCTION P2196)
MONITOR RESULT
Refer to CHECKING MONITOR STATUS. Refer to CHECKING MONITOR STATUS .
CONFIRMATION DRIVING PATTERN
| WARNING | Strictly observe posted speed limits, traffic laws, and road conditions when performing these drive patterns. |
This confirmation driving pattern is used in the "PERFORM CONFIRMATION DRIVING PATTERN" procedure of the following diagnostic troubleshooting procedure.
Scheme 358
Scheme 359
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine, and warm it up until the ECT reaches 75°C (167°F) or higher [A].
- On the Techstream, enter the following menus to check the fuel-cut status: Powertrain / Engine and ECT / Data List / Idle Fuel Cut.
- Drive the vehicle at between 60 and 120 km/h (38 and 75 mph) for at least 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Shift the transmission to 2nd gear [C].
- Accelerate the vehicle to 64 km/h (40 mph) or more by depressing the accelerator pedal for at least 10 seconds [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Soon after performing step [D] above, release the accelerator pedal for at least 8 seconds without depressing the brake pedal in order to execute fuel-cut control [E]. HINT: Fuel-cut is performed when the following conditions are met: Accelerator pedal is fully released. Engine speed is 2500 rpm or more (fuel injection returns at 1000 rpm).
- Allow the vehicle to decelerate until the vehicle speed decreases to less than 10 km/h (6 mph).
- Repeat steps [C] through [E] above at least 3 times in one driving cycle.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [F].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2195 or P2196.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [F] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 360
Scheme 360: WIRING DIAGRAM
| Related DTCs | P2237: Air Fuel Ratio (A/F) sensor open circuit between A1A+ and A1A- P2238: A/F sensor short circuit between A1A+ and A1A- P2238: A/F sensor short circuit between A1A+ and GND P2238: A/F sensor low impedance P2239: A/F sensor short circuit between A1A+ and +B P2252: A/F sensor short circuit between A1A- and GND P2253: A/F sensor short circuit between A1A- and +B |
| Required Sensors/Components (Main) | A/F sensor |
| Required Sensors/Components (Related) | Engine Coolant Temperature (ECT) sensor Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 seconds: P2237 (Air fuel ratio sensor open circuit between A1A+ and A1A-), P2238 (Air fuel ratio sensor low impedance) 5 seconds: Others |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0016 (VVT system - misalignment) P0017 (Exhaust VVT system - misalignment) P0031, P0032, P101D (Air fuel ratio sensor heater - sensor 1) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120 - P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop) P0171, P0172 (Fuel system) P0128 (Thermostat) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340 (Camshaft position sensor) P0451, P0452, P0453 (EVAP system) P0500 (Vehicle speed sensor) P0505 (IAC valve) |
| Estimated sensor temperature | 450 to 550°C (842 to 1022°F) |
| Engine | Running |
| Battery voltage | 11 V or more |
P2237 (A/F SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A-)
| Estimated sensor temperature | 700 to 800°C (1292 to 1472°F) |
| Engine coolant temperature | 10°C (50°F) or higher |
| Fuel cut | No executed |
P2238 (A/F SENSOR LOW IMPEDANCE)
| Battery voltage | 11 V or more |
| Ignition switch | ON |
| Time after ignition switch is OFF to ON | 5 seconds or more |
| A/F sensor admittance | Below 0.002 1/ohms |
P2237 (A/F SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A-)
| A/F sensor admittance | Below 0.0091 1/ohms |
P2238 (A/F SENSOR LOW IMPEDANCE)
| A/F+ terminal voltage | 0.5 V or less |
P2238 (A/F SENSOR SHORT CIRCUIT BETWEEN A1A+ AND GND)
| Difference between A/F+ terminal and A/F- terminal voltage | 0.1 V or less |
P2238 (A/F SENSOR SHORT CIRCUIT BETWEEN A1A+ AND A1A-)
| A/F+ terminal voltage | More than 4.5 V |
P2239 (A/F SENSOR SHORT CIRCUIT BETWEEN A1A+ AND +B)
| A/F- terminal voltage | 0.5 V or less |
P2252 (A/F SENSOR SHORT CIRCUIT BETWEEN A1A- AND GND)
| A/F- terminal voltage | More than 4.5 V |
P2253 (A/F SENSOR SHORT CIRCUIT BETWEEN A1A- AND +B)
| A/F sensor admittance | 0.0091 1/ohms or more |
| A1A+ terminal voltage | 0.6 to 4.5 V |
| A1A- terminal voltage | 0.6 to 4.5 V |
| Difference between A1A+ and A1A- terminal voltages | 0.1 to 0.8 V |
Scheme 361
Scheme 361: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and wait 2 minutes.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2237, P2238, P2239, P2252 or P2253.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes and check the DTC judgment result again [C].
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition C21-1 (HA1A) - C19-109 (HA1A) Always Below 1 ohms C21-3 (A1A+) - C19-112 (A1A+) C21-4 (A1A-) - C19-113 (A1A-) Standard Resistance (Check for Short) Tester Connection Condition Specified Condition C21-1 (HA1A) or C19-109 (HA1A) - Body ground Always 10 kohms or higher C21-3 (A1A+) or C19-112 (A1A+) - Body ground C21-4 (A1A-) or C19-113 (A1A-) - Body ground Reconnect the air fuel ratio sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-388735-S05886652062011031100000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle to Confirmation Driving Pattern on DTC P2195. Refer to «CONFIRMATION DRIVING PATTERN»(ref-388739-S18777418492011031100000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Refer to the confirmation driving pattern for P2237, P2238, P2239, P2252 and P2253. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to No output A P2237, P2238, P2239, P2252 or P2253 B B --> See step 5 A --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-388735-S27161698942011031100000)
| Required Sensors/Components | Purge VSV and canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 2 minutes (varies with amount of fuel in tank) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| EVAP key-off monitor runs when all of following conditions met | |
| Atmospheric pressure | 70 to 110 kPa-a (525 to 825 mmHg-a) |
| Battery voltage | 10.5 V or more |
| Vehicle speed | Below 4 km/h (2.5 mph) |
| Ignition switch | OFF |
| Time after key off | 5 or 7 or 9.5 hours |
| Canister pressure sensor malfunction (P0451, P0452 and P0453) | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of following conditions met before key off | Conditions 1 and 2 |
| 1. Duration that vehicle driven | 5 minutes or more |
| 2. EVAP purge operation | Performed |
| ECT | 4.4 to 35°C (40 to 95°F) |
| IAT | 4.4 to 35°C (40 to 95°F) |
| EVAP pressure change after EVAP canister vent valve ON | Less than 0.3 kPa-g (2.25 mmHg-g) |
Refer to CHECKING MONITOR STATUS. Refer to CHECKING MONITOR STATUS .
Scheme 362
Scheme 362: CONFIRMATION DRIVING PATTERN
Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 19 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menu items: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
- After the "Evaporative System Check" is completed, check All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2420.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Required Sensors/Components | ECM |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 minutes: Timer malfunction Within 9.5 hours: Timer start-up malfunction |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTC not present | None |
| Ignition switch | ON |
| Engine | Running |
| Battery voltage | 8 V or more |
| Starter | OFF |
| Monitor runs whenever following DTC not present | None |
| Elapsed time from engine stop | Less than 1800 seconds |
| Ignition switch | ON |
| Battery voltage | 8 V or more |
| Starter | OFF |
TIMER START-UP MALFUNCTION (CASE 1)
| Monitor runs whenever following DTC not present | None |
| Elapsed time from engine stop | 2400 seconds or more |
| Ignition switch | ON |
| Battery voltage | 8 V or more |
| Starter | OFF |
TIMER START-UP MALFUNCTION (CASE 2)
| Soak timer measurement when ECM CPU clock counts 10 minutes | Less than 7 minutes, or more than 13 minutes |
Scheme 363
Scheme 363: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 10 minutes or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2610.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-388735-S27161698942011031100000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2610) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . Refer to the confirmation driving pattern for P2610. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. If no pending DTC is displayed, the repair has been successfully completed. NEXT --> END
| Related DTCs | P2A00: Air Fuel Ratio (A/F) sensor (bank 1) slow response |
| Required Sensors/Components (Main) | A/F sensor |
| Required Sensors/Components (Related) | Vehicle speed sensor, Crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 to 15 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0016 (VVT system - misalignment) P0017 (Exhaust VVT system - misalignment) P0031, P0032, P101D (Air fuel ratio sensor heater - sensor 1) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120 - P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop) P0128 (Thermostat) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340 (Camshaft position sensor) P0451, P0452, P0453 (EVAP system) P0500 (Vehicle speed sensor) P0505 (IAC valve) |
| Active A/F control | Performing |
| Active A/F control performed when following conditions met | |
| Battery voltage | 11 V or more |
| Engine coolant temperature | 75°C (167°F) or more |
| Idling | OFF |
| Engine RPM | Less than 4000 rpm |
| A/F sensor status | Activated |
| Fuel-cut | OFF |
| Engine load | 10 to 70% |
| Shift position | 2 or more |
| Catalyst monitor | Not yet |
| Intake air amount | 7 to 16 g/sec. |
| Response rate deterioration level | Less than 0.14V |
Refer to CHECKING MONITOR STATUS. Refer to CHECKING MONITOR STATUS .
This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" procedure of the following diagnostic troubleshooting procedure.
Scheme 364
Scheme 364: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream ON.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / O2 Sensor / Details.
- Check that RES RATE B1S1 is Incomplete.
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
- Drive the vehicle at a constant speed between 40 and 120 km/h (25 and 75 mph) for 3 minutes [B]. NOTE: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Check the monitor result values on the Techstream by entering the following menus: Powertrain / Engine and ECT / Monitor / O2 Sensor / Details / RES RATE B1S1.
- If the values indicated on the Techstream do not change, perform READINESS MONITOR DRIVE PATTERN for the A/F sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-388734-S30606484762011031100000) .
- Note the value of the Monitor Result.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2A00.
- Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2A00) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to P2A00 A P2A00 and other DTCs B HINT: If any DTCs other than P2A00 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE). Refer to «PROCEDURE - Step 1»(ref-388738-S38655170662011031100000) NG --> See step 10 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) See step 1 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle to Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2A00) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Refer to the confirmation driving pattern for P2A00. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to P2A00 A No output B B --> See step 11 A: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-388735-S05886652062011031100000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle to Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2A00) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Refer to the confirmation driving pattern for P2A00. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to No output A P2A00 B B --> See step 12 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-388734-S31814561492011031100000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-388735-S05886652062011031100000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-388734-S30722680022011031100000)
- CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «INSPECTION PROCEDURE»(ref-388738-S05948496422011031100000)
RELATED DTCS
| DTC | Monitoring Item | See |
| P043E | Reference orifice clogged (built into canister pump module) | Refer to DTC P043E: Evaporative Emission System Reference Orifice Clog Up; DTC P043F: Evaporative Emission System Reference Orifice High Flow; DTC P2401: Evaporative Emission Leak Detection Pump Stuck OFF; DTC P2402: Evaporative Emission Leak Detection Pump Stuck ON; DTC P2419: Evaporative Emission System Switching Valve Control Circuit Low |
| P043F | Reference orifice high-flow (built into canister pump module) |
| P0441 | Purge VSV (Vacuum Switching Valve) stuck closed Purge VSV stuck open Purge flow | Refer to DTC P0441: Evaporative Emission Control System Incorrect Purge Flow |
| P0451 | Canister pressure sensor (built into canister pump module) noise Canister pressure sensor (built into canister pump module) signal becomes fixed/flat | Refer to DTC P0451: Evaporative Emission Control System Pressure Sensor Range / Performance; DTC P0452: Evaporative Emission Control System Pressure Sensor / Switch Low Input; DTC P0453: Evaporative Emission Control System Pressure Sensor / Switch High Input |
| P0452 | Canister pressure sensor (built into canister pump module) voltage low |
| P0453 | Canister pressure sensor (built into canister pump module) voltage high |
| P0455 | EVAP gross leak | Refer to DTC P0455: Evaporative Emission Control System Leak Detected (Gross Leak); DTC P0456: Evaporative Emission Control System Leak Detected (Very Small Leak) |
| P0456 | EVAP small leak |
| P2401 | Leak detection pump stuck OFF (built into canister pump module) | Refer to DTC P043E: Evaporative Emission System Reference Orifice Clog Up; DTC P043F: Evaporative Emission System Reference Orifice High Flow; DTC P2401: Evaporative Emission Leak Detection Pump Stuck OFF; DTC P2402: Evaporative Emission Leak Detection Pump Stuck ON; DTC P2419: Evaporative Emission System Switching Valve Control Circuit Low |
| P2402 | Leak detection pump stuck ON (built into canister pump module) |
| P2419 | Vent valve stuck closed (built into canister pump module) | Refer to DTC P043E: Evaporative Emission System Reference Orifice Clog Up; DTC P043F: Evaporative Emission System Reference Orifice High Flow; DTC P2401: Evaporative Emission Leak Detection Pump Stuck OFF; DTC P2402: Evaporative Emission Leak Detection Pump Stuck ON; DTC P2419: Evaporative Emission System Switching Valve Control Circuit Low |
| P2420 | Vent valve stuck open (vent) (built into canister pump module) | Refer to DTC P2420: Evaporative Emission System Switching Valve Control Circuit High |
| P2610 | Soak timer (built into ECM) | Refer to DTC P2610: ECM / PCM Internal Engine Off Timer Performance |
If any EVAP system DTCs are set, the malfunctioning area can be determined using the table below.
Scheme 365
Note. If the reference pressure difference between the first and second checks is greater than the specification, all the DTCs relating to the reference pressure (P043E, P043F, P2401, P2402 and P2419) are stored.
After a repair, check Monitor Status by performing the Key-Off Monitor Confirmation and Purge Flow Monitor Confirmation described below.
- Key-off monitor confirmation Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway) The fuel tank is less than 90% full The altitude is less than 8000 ft (2432 m) The Engine Coolant Temperature (ECT) is between 4.4°C and 35°C (40°F and 95°F) The Intake Air Temperature (IAT) is between 4.4°C and 35°C (40°F and 95°F) The vehicle remains stationary (the vehicle speed is 0 km/h [0 mph]) Monitor Conditions Allow the engine to idle for at least 5 minutes. Turn the ignition switch to OFF and wait for 5 to 10 hours. HINT: Do not start the engine until checking Monitor Status. If the engine is started, the steps described above must be repeated. Monitor Status Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Monitor / Evaporative System. Check the Monitor Status displayed on the tester. HINT: If Incomplete is displayed, the monitor is not completed. Make sure that the preconditions have been met, and perform the Monitor Conditions again.
- Purge flow monitor confirmation (P0441) HINT: Perform this monitor confirmation after the Key-Off Monitor Confirmation shows Complete. Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway) The ECT is between 4.4°C and 35°C (40°F and 95°F) The IAT is between 4.4°C and 35°C (40°F and 95°F) Monitor Conditions Release the pressure from the fuel tank by removing and reinstalling the fuel cap. Warm the engine up until the ECT reaches more than 75°C (167°F). Increase the engine speed to 3000 rpm once. Allow the engine to idle and the ON for 1 minute. Monitor Status Turn the ignition switch to OFF (if ON or the engine is running). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Monitor. Check the Monitor Status displayed on the tester. HINT: If Incomplete is displayed, the monitor is not completed. Make sure that the preconditions have been met, and perform the Monitor Conditions again.
Refer to CHECKING MONITOR STATUS. Refer to CHECKING MONITOR STATUS .
