Engine Control System (Diagnostic Codes (P0010-P0351): Wiring Scion xD I

WIRING DIAGRAM

Refer to DTC P0010, Refer to WIRING DIAGRAM .

Refer to DTC P0013, Refer to WIRING DIAGRAM .

Refer to DTC P2195, Refer to WIRING DIAGRAM .

Refer to DTC P0136, Refer to WIRING DIAGRAM .

Refer to DTC P0102, Refer to WIRING DIAGRAM .

Scheme 197

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
8. Drive the vehicle at approximately 80 km/h (50 mph) to 112 km/h (70 mph) for 5 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive while keeping the engine load as stable as possible.
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
10. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0101.
13. Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTCs, Refer to «DTC CHECK / CLEAR»(ref-388734-S06424090862011031100000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Refer to DTC P0112, Refer to WIRING DIAGRAM .

Refer to DTC P0115, Refer to WIRING DIAGRAM .

Refer to DTC P2195, Refer to WIRING DIAGRAM .

Wiring diagram of the ignition system.

Scheme 198

Scheme 199

Refer to DTC P0335, Refer to WIRING DIAGRAM .
