U241E Automatic Transaxle: Removal & Installation Scion xB II

Automatic Trans 2 illustrations ~133 words

INSTALLATION

  1. INSTALL SPEED SENSOR NC Coat a new O-ring with ATF, and install it into the speed sensor NC. Install the speed sensor NC with the bolt. Torque: 8.8 N*m (90 kgf*cm, 78 in.*lbf) Connect the speed sensor NC connector.
  2. INSTALL SPEED SENSOR NT Coat a new O-ring with ATF, and install it into the speed sensor NT. Install the speed sensor NT with the bolt. Torque: 11 N*m (110 kgf*cm, 8 ft.*lbf) Connect the speed sensor NT connector.
  3. INSTALL AIR CLEANER CASE SUB-ASSEMBLY (See «INSTALLATION»(ref-289742-S29456220692008070700000) )
  4. INSTALL AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY (See «INSTALLATION»(ref-289742-S29456220692008070700000) )
  5. INSTALL AIR CLEANER CAP SUB-ASSEMBLY (See «INSTALLATION»(ref-289755-S15393896032008070700000) )
  6. INSTALL NO. 2 BATTERY CARRIER (See «INSTALLATION»(ref-289742-S29456220692008070700000) )
  7. INSTALL BATTERY (See «INSTALLATION»(ref-289752-S17907450142008070700000) )
  8. INSPECT FOR AUTOMATIC TRANSAXLE FLUID LEAK

Scheme 476

Scheme 476: COMPONENTS
Scheme 476: COMPONENTS

Scheme 477

Scheme 477
Scheme 477
