Automatic Transaxle (On-Vehcle Service): Removal & Installation Scion xA I

Automatic Trans 16 illustrations ~850 words

REPLACEMENT

HINT

COMPONENTS

  1. INSTRUMENT PANEL/METER (See REMOVAL )
  2. FLOOR SHIFT ASSY (See «FLOOR SHIFT ASSY (ATM)»(ref-180037-S13607868112005072000000) )

Scheme 57

Scheme 57

Scheme 58

Scheme 58

Scheme 59

Scheme 59

Scheme 60

Scheme 60

Scheme 61

Scheme 61

Scheme 62

Scheme 62

Scheme 63

Scheme 63

Scheme 64

Scheme 64
  1. REMOVE CONSOLE BOX REAR COVER
  2. REMOVE CONSOLE BOX CARPET
  3. REMOVE CONSOLE BOX ASSY REAR
  4. REMOVE EXHAUST PIPE ASSY FRONT (See REMOVAL )
  5. REMOVE FRONT FLOOR HEAT INSULATOR NO. 1
  6. REMOVE AIR CLEANER ASSY
  7. DISCONNECT TRANSMISSION CONTROL CABLE ASSY Remove the nut, disconnect the transmission control cable assy from the floor shift assy. Using a screwdriver, disconnect the transmission control cable assy from the shift lever plate. Remove the 3 bolts. Pull out the transmission control cable assy from the body. Remove the nut and disconnect the transmission control cable assy from the control shaft lever. Remove the clip and disconnect the transmission control cable assy from the control cable bracket. Disconnect the transmission control cable assy from the transmission control cable support.
  8. CONNECT TRANSMISSION CONTROL CABLE ASSY Temporarily install the transmission control cable assy on the control shaft lever with the nut. Connect the transmission control cable assy with a new clip on the bracket. Connect the transmission control cable assy to the transmission control cable support. Install the transmission control cable assy on the body with the 3 bolts. Torque: 5.0 N.m (51 kgf.cm, 44 in.lbf) Connect the transmission control cable assy on the shift lever plate. Temporarily install the transmission control cable assy on the floor shift assy. Torque: 12 N.m (122 kgf.cm, 9 ft.lbf)
  9. INSTALL AIR CLEANER ASSY
  10. INSTALL FRONT FLOOR HEAT INSULATOR NO. 1 Torque: 5.5 N.m (56 kgf.cm, 49 ft.lbf)
  11. INSTALL EXHAUST PIPE ASSY FRONT (See INSTALLATION )
  12. ADJUST SHIFT LEVER POSITION (see «ADJUSTMENT»(ref-180037-S41297120202005072000000) )
  13. INSPECT SHIFT LEVER POSITION (see «ADJUSTMENT»(ref-180037-S41297120202005072000000) )
  14. INSTALL CONSOLE BOX ASSY REAR
  15. INSTALL CONSOLE BOX CARPET
  16. INSTALL CONSOLE BOX REAR COVER

HINT

  1. COMPONENTS: INSTRUMENT PANEL/METER (See REMOVAL )
  2. SUPPLEMENTAL RESTRAINT SYSTEM (See AIR BAG RESTRAINT SYSTEM
  3. STEERING COLUMN (See STEERING COLUMN )

Scheme 65

Scheme 65

Scheme 66

Scheme 66

Scheme 67

Scheme 67

Scheme 68

Scheme 68

Scheme 69

Scheme 69

Scheme 70

Scheme 70

Scheme 71

Scheme 71

Scheme 72

Scheme 72
  1. PRECAUTION (See AIR BAG RESTRAINT SYSTEM )
  2. SEPARATE BATTERY NEGATIVE TERMINAL
  3. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
  4. REMOVE HORN BUTTON ASSY (See AIR BAG RESTRAINT SYSTEM )
  5. REMOVE STEERING WHEEL ASSY (See OVERHAUL )
  6. REMOVE STEERING COLUMN COVER (See OVERHAUL )
  7. REMOVE INSTRUMENT CLUSTER FINISH PANEL (See REMOVAL )
  8. REMOVE INSTRUMENT CLUSTER FINISH PANEL GARNISH NO. 2 (See REMOVAL )
  9. REMOVE INSTRUMENT CLUSTER FINISH PANEL GARNISH NO. 1 (See REMOVAL )
  10. REMOVE INSTRUMENT CLUSTER FINISH PANEL ASSY CENTER (See REMOVAL )
  11. REMOVE FRONT ASH RECEPTACLE ASSY (See REMOVAL )
  12. REMOVE INSTRUMENT COVER LOWER CENTER (See REMOVAL )
  13. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER CENTER (See REMOVAL )
  14. REMOVE CONSOLE BOX REAR COVER
  15. REMOVE CONSOLE BOX CARPET
  16. REMOVE CONSOLE BOX ASSY REAR (See «OVERHAUL»(ref-180037-S42243399162005072000000) )
  17. DISCONNECT FLOOR SHIFT PARKING LOCK CABLE ASSY Rotate the adjust lock cap clockwise 90° facing the front of the vehicle, and release it. Push the claw and disconnect the floor shift parking lock cable assy from the shift lock release link. Using a screwdriver, disconnect the floor shift parking lock cable assy from the shift lever plate. Disconnect the cable clamp. Adjust the shift lever to the N position. Disconnect the floor shift parking lock cable assy from the upper bracket.
  18. CONNECT FLOOR SHIFT PARKING LOCK CABLE ASSY Turn the ignition switch to the ACC or ON position. Connect the cable to the upper bracket. HINT: After installation, make sure that the lever pin is pulled by the cable and is stopped with the stopper. Connect the cable clamp. Shift the shift lever to N position. Insert the floor shift parking lock cable assy of the shift lever plate. Insert the casing cap of the cable into the shift lever plate through-hole. HINT: Check that it is inserted securely. Insert the lever pin into the hole in the floor shift parking lock cable end. HINT: At this time, ensure that the shift lever is in the N position. After installation, make sure that the lever pin is pulled by the floor shift parking lock cable and is stopped with the stopper. To check that the spring for automatic adjustment works properly, hold the slide cap and move it back and forth. Rotate adjust lock cap shown in the illustration counterclockwise by 90° facing the front of the vehicle. HINT: Install the floor shift parking lock cable on the shift lever side with the key in the ACC position. Make sure the slide amount of the spring for automatic adjustment is 8 mm (0.31 in.).
  19. INSTALL CONSOLE BOX ASSY REAR (See «OVERHAUL»(ref-180037-S42243399162005072000000) )
  20. INSTALL CONSOLE BOX CARPET
  21. INSTALL CONSOLE BOX REAR COVER
  22. INSTALL INSTRUMENT CLUSTER FINISH PANEL (See INSTALLATION )
  23. INSTALL STEERING COLUMN COVER (See OVERHAUL )
  24. INSTALL STEERING WHEEL ASSY (See OVERHAUL )
  25. STEERING WHEEL CENTER POINT
  26. INSTALL HORN BUTTON ASSY (See INSTALLATION )
  27. CONNECT BATTERY NEGATIVE TERMINAL
  28. INSPECT HORN BUTTON ASSY (See AIR BAG RESTRAINT SYSTEM )
  29. INSPECT SRS WARNING LIGHT (See AIR BAG RESTRAINT SYSTEM )
  30. CHECK KEY INTERLOCK OPERATION (See «SHIFT LOCK SYSTEM (ATM)»(ref-180037-S42633690282005072000000) )
