PRECAUTION
Note. Perform the RESET MEMORY (AT initialization) when replacing the automatic transaxle assy, engine assy or ECM (See INITIALIZATION ).
Note. Initialization can not be completed by only removing the battery.
MECHANICAL SYSTEM TESTS
- PERFORM MECHANICAL SYSTEM TESTS Measure the stall speed. The object of this test is to check the overall performance of the transaxle and engine by measuring the stall speeds in the D and R positions. NOTE: Do the test at normal operating ATF temperature 50 to 80 °C (122 to 176 °F). Do not continuously run this test for longer than 5 seconds. To ensure safety, do this test in a wide, clear level area which provides good traction. The stall test should always be carried out in pairs. One technician should observe the conditions of wheels or wheel stoppers outside the vehicle while the other is doing the test. Chock the 4 wheels. Connect an OBD II scan tool or hand-held tester to the DLC3. Fully apply the parking brake. Keep your left foot pressed firmly on the brake pedal. Start the engine. Shift into the D position. Press all the way down on the accelerator pedal with your right foot. Quickly read the stall speed at this time. Stall speed: 2,300 +/- 250 rpm Do the same test in the R position. Stall speed: 2,300 +/- 250 rpm Evaluation: POSSIBLE CAUSE Problem Possible cause (A) Stall Speed Low In D And R Positions Engine Output May Be Insufficient Stator One-Way Clutch Not Operating Properly NOTE: If The Value Is Less Than The Specified Value By 600 RPM Or More, The Torque Converter Could Be Faulty. (B) Stall Speed High In D Position Line Pressure Too Low Forward Clutch Slipping One-Way Clutch No. 2 Not Operating Properly (C) Stall Speed High In R Position Line Pressure Too Low Reverse Clutch Slipping 1St And Reverse Brake Slipping (D) Stall Speed High In D And R Positions Line Pressure Too Low Improper Fluid Level Measure the time lag. When the shift lever is shifted while the engine is idling, there will be a certain time lapse or lag before the shock can be felt. This is used for checking the condition of the direct clutch, forward clutch, and 1st and reverse brake. NOTE: Do the test at normal operating ATF temperature 50 to 80 °C (122 to 176 °F). Be sure to allow 1 minute interval between tests. Take 3 measurements and take the average value. Connect an OBD II scan tool or hand-held tester to the DLC3. Fully apply the parking brake. Start the engine and check idle speed. Idle speed: 700 +/- 50 rpm (In N position and A/C OFF) Shift the lever from N to D position. Using a stop watch, measure the time from when the lever is shifted until the shock is felt. Time lag: N --> D less than 1.2 seconds In the same way, measure the time lag for N --> R. Time lag: N --> R less than 1.5 seconds Evaluation (If N --> D or N --> R time lag is longer than the specified): POSSIBLE CAUSE Problem Possible Cause N --> D Time Lag Is Longer Line Pressure Too Low Forward Clutch Worn One-Way Clutch No. 2 Not Operating Properly N --> R Time Lag Is Longer Line Pressure Too Low Reverse Clutch Worn 1St & Reverse Brake Worn
Scheme 225
- PERFORM HYDRAULIC TEST Measure the line pressure. NOTE: Do the test at normal operation ATF temperature 50 to 80 °C (122 to 176 °F). The line pressure test should always be carried out in pairs. One technician should observe the conditions of wheels or wheel stopper outside the vehicle while the other is doing the test. Be careful to prevent SST's hose from interfering with the exhaust pipe. Warm up the ATF. Remove the test plug on the left side of the transaxle case and connect SST. SST 09992-00095 (09992- 00231, 09992-00271) Fully apply the parking brake and chock the 4 wheels. Connect an OBD II scan tool or hand-held tester to the DLC3. Start the engine and check idling speed. Keep your left foot pressing firmly on the brake pedal and shift into D position. Measure the line pressure when the engine is idling. Depress the accelerator pedal all the way down. Quickly read the highest line pressure when engine speed reaches stall speed. In the same way, do the test in R position. Specified line pressure: SPECIFIED LINE PRESSURE Condition D position : kPa (kgf / cm 2 , psi) R position : kPa (kgf / cm 2 , psi) Idling 372 to 407 (3.8 to 4.2, 54 to 60) 541 to 636 (5.5 to 6.5, 78 to 92) Stall 1,107 to 1,225 (11.3 to 12.5, 161 to 178) 1,695 to 1,813 (17.3 to 18.5, 246 to 263) Evaluation: POSSIBLE CAUSE Problem Possible Cause If The Measured Values At All Positions Are Higher Line Pressure Control Solenoid (SLT) Defective Regulator Valve Detective If The Measured Values At All Positions Are Lower Line Pressure Control Solenoid (SLT) Defective Regulator Valve Detective Oil Pump Defective If Pressure Is Low In The D Position Only D Position Circuit Fluid Leak Forward Clutch Defective If Pressure Is Low In The R Position Only R Position Circuit Fluid Leak Reverse Clutch Defective 1St And Reverse Brake Defective
Scheme 226
- PERFORM MANUAL SHIFTING TEST NOTE: By this test, it can be determined whether the trouble is within the electrical circuit or is a mechanical problem in the transaxle. Disconnect the transmission wire connector. Inspect the manual driving operation. Check that the shift and gear positions correspond to the table below. While driving, shift through the L, 2 and D positions. Check that the gear change corresponds to the shift position. SHIFT AND GEAR POSITION Shift Position Gear Position D 3rd 2 3rd L 3rd R Reverse P Pawl Lock NOTE: If the gear positions of the L, 2 and D are difficult to distinguish, do the following road test. If any abnormality is found in the above test, the problem is in the transaxle itself. Connect the transmission wire connector. Clear the DTC (See «DTC CHECK/CLEAR»(ref-204126-S03114955872005110800000) ).
Scheme 227
| Symbols (Terminals No.) | Wiring Color | Terminal Description | Condition | Specified Condition |
|---|---|---|---|---|
| ODLP (E5-7) - E1 (E4-7) | G-O - BR | O/D OFF Indicator Light Circuit | IG Switch ON And O/D OFF Indicator Light Lights Up | Below 3 V |
| IG Switch ON And O/D OFF Indicator Light Goes Off | 10 to 14 V | |||
| L (E5-8) - E1 (E4-7) | G-W - BR | L Shift Position Switch Signal | IG Switch ON And Shift Lever L Position | 10 to 14 V |
| IG Switch ON And Shift Lever Except L Position | Below 1 V | |||
| 2 (E5-9) - E1 (E4-7) | G - BR | 2 Shift Position Switch Signal | IG Switch ON And Shift Lever 2 Position | 10 to 14 V |
| IG Switch ON And Shift Lever Except 2 Position | Below 1 V | |||
| D (E5-10) - E1 (E4-7) | R-Y - BR | D Shift Position Switch Signal | IG Switch ON And Shift Lever D Position | 10 to 14 V |
| IG Switch ON And Shift Lever Except D Position | Below 1 V | |||
| R (E5-11) - E1 (E4-7) | R-W - BR | R Shift Position Switch Signal | IG Switch ON And Shift Lever R Position | 10 to 14 V |
| IG Switch ON And Shift Lever Except R Position | Below 1 V | |||
| STP (E5-19) - E1 (E4-7) | G-W - BR | Stop Lamp Switch Signal | IG Switch ON And Brake Pedal Is Depressed | 7.5 to 14 V |
| IG Switch ON And Brake Pedal Is Released | Below 1.5 V | |||
| SPD (E5-17) - E1 (E4-7) | V-W - BR | Speed Signal | IG Switch ON And Rotate Driving Wheel Slowly | Pulse Generation |
| ODMS (E5-29) - E1 (E4-7) | G-B - BR | O/D Main Switch Signal | IG Switch ON | 10 to 14 V |
| IG Switch ON And Press Continuously O/D Main Switch | Below 1 V | |||
| NSW (E4-8) - E1 (E4-7) | B- BR | Park Neutral Switch Signal | IG Switch ON And Shift Lever P And N Position | Below 1 V |
| IG Switch ON And Shift Lever Except P And N Position | 10 to 14 V | |||
| ST (E4-12) - E1 (E4-7) | B-R - BR | ST Solenoid Signal | IG Switch ON | Below 1 V |
| IG Switch ON And R Gear | 10 to 14 V | |||
| SL (E4-13) - E1 (E4-7) | G - BR | SL Solenoid Signal | IG Switch ON | Below 1 V |
| Vehicle Driving Under Lock-Up Range | 10 to 14 V | |||
| S1 (E4-15) - E1 (E4-7) | W-G - BR | S1 Solenoid Signal | IG Switch ON | 10 to 14 V |
| 1st Or 2nd Gear | 10 to 14 V | |||
| 3rd Or O/D Gear | Below 1 V | |||
| S2 (E4-14) - E1 (E4-7) | W-R - BR | S2 Solenoid Signal | IG Switch ON | Below 1 V |
| 1st or O/D Gear | 10 to 14 V | |||
| 2nd or 3rd Gear | Below 1 V | |||
| NT+ (E4-27) - NT- (E4-35) | R - B | Speed Sensor (NT) Signal | Engine Is Running | Below 1 V and 4 to 5 V |
| SLT+ (E3-17) - SLT- (E3-16) | W-L - W | SLT Solenoid Signal | IG Switch ON | 10 to 14 V |
| OIL (E3-30) - E2 (E3-28) | Y-G - BR | ATF Temperature Sensor Signal | ATF Temperature: 115 °C (239 °F) Or More | Below 1.5 V |
TERMINAL SPECIFIED CONDITION
DEFINITION OF TERMS
| Term | Definition |
|---|---|
| Monitor Description | Description Of What The ECM Monitors And How It Detects Malfunctions (Monitoring Purpose And Its Details). |
| Related DTCs | Diagnostic Code |
| Typical Enabling Condition | Preconditions That Allow The ECM To Detect Malfunctions. With All Preconditions Satisfied, The ECM Sets The DTC When The Monitored Value (S) Exceeds The Malfunction Threshold (S). |
| Sequence Of Operation | The Priority Order That Is Applied To Monitoring, If Multiple Sensors And Components Are Used To Detect The Malfunction. While Another Sensor Is Being Monitored, The Next Sensor Or Component Will Not Be Monitored Until The Previous Monitoring Has Concluded. |
| Required Sensor/Components | The Sensors And Components That Are Used By The ECM To Detect Malfunctions. |
| Frequency Of Operation | The Number Of Times That The ECM Checks For Malfunctions Per Driving Cycle. "Once Per Driving Cycle" Means That The ECM Detects Malfunction Only One Time During A Single Driving Cycle. "Continuous" Means That The ECM Detects Malfunction Every Time When Enabling Condition Is Met During A Single Driving Cycle. |
| Duration | The Minimum Time That The ECM Must Sense A Continuous Deviation In The Monitored Value (S) Before Setting A DTC. This Timing Begins After The "Typical Enabling Conditions" Are Met. |
| Malfunction Thresholds | Beyond This Value, The ECM Will Conclude That There Is A Malfunction And Set A DTC. |
| MIL Operation | MIL Illumination Timing After A Defect Is Detected. "Immediately" Means That The ECM Illuminates MIL The Instant The ECM Determines That There Is A Malfunction. "2 Driving Cycle" Means That The ECM Illuminates MIL If The Same Malfunction Is Detected Again In The 2nd Driving Cycle. |
DEFINITION OF TERMS
PART AND SYSTEM NAME LIST
This reference list indicates the part names used in this manual along with their definitions.
| Part And System Name | Definition |
|---|---|
| Toyota HVAC System, Hydrocarbon Adsorptive Catalyst (HCAC) System | HC Adsorptive Three-Way Catalyst HC Adsorptive Three-Way Catalytic Converter |
| Variable Valve Timing Sensor, VVT Sensor | Camshaft Position Sensor |
| Variable Valve Timing System, VVT System | Camshaft Timing Control System |
| Camshaft Timing Oil Control Valve, Oil Control Valve OCV, VVT, VSV | Camshaft Timing Oil Control Valve |
| Variable Timing And Lift, VVTL | Camshaft Timing And Lift Control |
| Crankshaft Position Sensor "A" | Crankshaft Position Sensor |
| Engine Speed Sensor | Crankshaft Position Sensor |
| THA | Intake Air Temperature |
| Knock Control Module | Engine Knock Control Module |
| Knock Sensor | Engine Knock Sensor |
| Mass Or Volume Air Flow Circuit | Mass Air Flow Sensor Circuit |
| Vacuum Sensor | Manifold Air Pressure Sensor |
| Internal Control Module, Control Module, Engine Control ECU, PCM | Power Train Control Module |
| FC idle | Deceleration Fuel Cut |
| Idle Air Control Valve | Idle Speed Control |
| VSV For CCV, Canister Close Valve VSV For Canister Control | Evaporative Emissions Canister Vent Valve |
| VSV For EVAP, Vacuum Switching Valve Assembly No. 1, EVAP VAV, Purge VSV | Evaporative Emissions Canister Purge Valve |
| VSV For Pressure Switching Valve, Bypass VSV | Evaporative Emission Pressure Switching Valve |
| Vapor Pressure Sensor, EVAP Pressure Sensor, Evaporative Emission Control System Pressure Sensor | Fuel Tank Pressure Sensor |
| Charcoal Canister | Evaporative Emissions Canister |
| ORVR System | On-Board Refueling Vapor Recovery System |
| Intake Manifold Runner Control | Intake Manifold Tuning System |
| Intake Manifold Runner Valve, IMRV, IACV (Runner Valve) | Intake Manifold Tuning Valve |
| Intake Control VSV | Intake Manifold Tuning Solenoid Valve |
| AFS | Air Fuel Ratio Sensor |
| O2 Sensor | Heater Oxygen Sensor |
| Oxygen Sensor Pumping Current Circuit | Oxygen Sensor Output Signal |
| Oxygen Sensor Reference Ground Circuit | Oxygen Sensor Signal Ground |
| Accel Position Sensor | Accelerator Pedal Position Sensor |
| Throttle Actuator Control Motor, Actuator Control Motor, Electronic Throttle Motor, Throttle Control Motor | Electronic Throttle Actuator |
| Electronic Throttle Control System, Throttle Actuator Control System | Electronic Throttle Control System |
| Throttle/Pedal Position Sensor, Throttle/Pedal Position Switch, Throttle Position Sensor/Switch | Throttle Position Sensor |
| Turbo Press Sensor | Turbocharger Pressure Sensor |
| Turbo VSV | Turbocharger Pressure Control Solenoid Valve |
| P/S Pressure Switch | Power-Steering Pressure Switch |
| VSV For ACM | Active Control Engine Mount |
| Speed Sensor, Vehicle Speed Sensor "A", Speed Sensor For Skid Control ECU | Vehicle Speed Sensor |
| ATF Temperature Sensor, Trans. Fluid Temp. Sensor, ATF Temperature Sensor "A" | Transmission Fluid Temperature Sensor |
| Electronic Controlled Automatic Transmission, ECT | Electronically Controlled Automatic |
| Intermediate Shaft Speed Sensor "A" | Counter Gear Speed Sensor |
| Output Speed Sensor | Output Shaft Speed Sensor |
| Input Speed Sensor, Input Turbine Speed Sensor "A", Speed Sensor (NT), Turbine Speed Sensor | Input Turbine Speed Sensor |
| PNP Switch, NSW | Park/Neutral Position Switch |
| Pressure Control Solenoid | Transmission Pressure Control Solenoid |
| Shift Solenoid | Transmission Shift Solenoid Valve |
| Transmission Control Switch, Shift Lock Control Unit | Shift Lock Control Module |
| Engine Immobilizer System, Immobilizer System | Vehicle Anti-Theft System |
PART AND SYSTEM NAME LIST
LIST OF DISABLE A MONITOR
Note. This table indicates ECM monitoring status for the items in the upper columns if the DTCs in each line on the left are being set.
Scheme 228
Scheme 229
Scheme 230
- RESET MEMORY CAUTION: Perform the RESET MEMORY (AT initialization) when replacing the automatic transaxle assy, engine assy or ECM. NOTE: Hand-held tester only Turn the ignition switch off. Connect the hand-held tester to the DLC3. Turn the ignition switch to the ON position. Perform the reset memory procedure from the ENGINE menu. CAUTION: After performing the RESET MEMORY, be sure to perform the ROAD TEST described earlier.
CHAPTER 1: ELECTRONIC CIRCUIT MATRIX CHART
| Symptom/Suspect Area | See | |
|---|---|---|
| No Up-Shift (A Particular Gear, From 1st to 3rd Gear, Is Not Upshifted) | ||
| ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| No up-shift (3rd --> O/D) | ||
| 1. O/D Main Switch Circuit | O/D MAIN SWITCH CIRCUIT | |
| 2. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| No Down-Shift (O/D --> 3rd) | ||
| 1. O/D Main Switch Circuit | O/D MAIN SWITCH CIRCUIT | |
| 2. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| No Down-Shift (A Particular Gear, From 3rd to 1st Gear, Is Not Down-Shifted) | ||
| 1. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| No Lock-Up Or No Lock-Up Off | ||
| 1. Stop light switch circuit (1) | DTC P0724 BRAKE SWITCH "B" CIRCUIT HIGH | |
| 2. Engine coolant temp. sensor circuit (1) | DIAGNOSTIC TROUBLE CODE CHART | |
| 3. Throttle position sensor circuit (1) | DIAGNOSTIC TROUBLE CODE CHART | |
| 4. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| Shift Point Too High Or Too Low | ||
| 1. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| Up Shift To 2nd While In L Position | ||
| 1. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| Up-Shift To 3rd While In 2 Position | ||
| 1. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| Up-Shift To O/D From 3rd While O/D Main Switch Is OFF | ||
| 1. O/D Main Switch Circuit | O/D MAIN SWITCH CIRCUIT | |
| 2. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| Up-Shift To O/D From 3rd While Engine Is Cold | ||
| 1. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| Harsh Engagement (N --> D) | ||
| 1. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| Harsh Engagement (Lock-Up) | ||
| 1. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| Harsh Engagement (Any Driving Position) | ||
| 1. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| Poor Acceleration | ||
| 1. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| Engine Stalls When Starting Off Or Stopping | ||
| 1. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| No Kick-Down | ||
| 1. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| Malfunction In Shifting | ||
| 1. Park/Neutral Position Switch Circuit (1) | DTC P0705 TRANSMISSION RANGE SENSOR CIRCUIT MALFUNCTION (PRNDL INPUT) | |
| 2. ECM | ELECTRONIC CIRCUIT INSPECTION PROCEDURE | |
| (1) When The Circuit On Which Mark *1 Is Attached Is A Malfunction, DTC Could Be Output (See DTC CHECK/CLEAR ). | ||
| (1) | When The Circuit On Which Mark *1 Is Attached Is A Malfunction, DTC Could Be Output (See DTC CHECK/CLEAR ). |
ELECTRONIC CIRCUIT MATRIX
Chapter 2: On-vehicle Repair
| Symptom/Suspect Area | See | |
|---|---|---|
| Vehicle Does Not Move In Any Forward Position And Reverse Position | ||
| 1. Manual Valve | (1) | |
| 2. Valve Body Assy (Primary Regulator Valve) | REPLACEMENT | |
| 3. Valve Body Assy (Secondary Regulator Valve) | REPLACEMENT | |
| 4. Off-Vehicle Repair Matrix Chart | — | |
| Vehicle Does Not Move In R Position | ||
| 1. Manual Valve | (1) | |
| 2. Off-Vehicle Repair Matrix Chart | — | |
| No Up-Shift (1st --> 2nd) | ||
| 1. Valve Body Assy (1-2 Shift Valve) | REPLACEMENT | |
| 2. Off-Vehicle Repair Matrix Chart | — | |
| No Up-Shift (2nd --> 3rd) | ||
| 1. Valve Body Assy (2-3 Shift Valve) | REPLACEMENT | |
| 2. Off-Vehicle Repair Matrix Chart | — | |
| No Up-Shift (3rd --> O/D) | ||
| 1. Valve Body Assy (3-4 Shift Valve) | REPLACEMENT | |
| 2. Off-Vehicle Repair Matrix Chart | — | |
| No Down-Shift (O/D --> 3rd) | ||
| Valve Body Assy (3-4 Shift Valve) | REPLACEMENT | |
| No Down-Shift (3rd --> 2nd) | ||
| Valve Body Assy (2-3 Shift Valve) | REPLACEMENT | |
| No Down-Shift (2nd --> 1st) | ||
| Valve Body Assy (1-2 Shift Valve) | REPLACEMENT | |
| No Lock-Up Or No Lock-Up Off | ||
| 1. Valve Body Assy (Lock-Up Relay Valve) | REPLACEMENT | |
| 2. Valve Body Assy (Lock-Up Control Valve) | REPLACEMENT | |
| 3. Valve Body Assy (Solenoid Relay Valve) | REPLACEMENT | |
| 4. Valve Body Assy (Solenoid Modulator Valve) | REPLACEMENT | |
| 5. Off-Vehicle Repair Matrix Chart | — | |
| Harsh Engagement (N --> D) | ||
| 1. Valve Body Assy (C1 Accumulator) | REPLACEMENT | |
| 2. Valve Body Assy (Accumulator Control Valve) | REPLACEMENT | |
| 3. Off-Vehicle Repair Matrix Chart | — | |
| Harsh Engagement (N --> R) | ||
| 1. C 3 Accumulator | (1) | |
| 2. Valve Body Assy (Accumulator Control Valve) | REPLACEMENT | |
| 3. Valve Body Assy (Reverse Control Valve) | REPLACEMENT | |
| 4. Off-Vehicle Repair Matrix Chart | — | |
| Harsh Engagement (Lock-Up) | ||
| 1. Valve Body Assy (Lock-Up Relay Valve) | REPLACEMENT | |
| 2.Valve Body Assy (Accumulator Control Valve) | REPLACEMENT | |
| 3. Valve Body Assy (Lock-Up Control Valve) | REPLACEMENT | |
| 4. Off-Vehicle Repair Matrix Chart | — | |
| Harsh Engagement (1st --> 2nd) | ||
| 1. B 2 Accumulator | (1) | |
| 2. Valve Body Assy (Accumulator Control Valve) | REPLACEMENT | |
| Harsh Engagement (2nd --> 3rd) | ||
| 1. C 2 Accumulator | (1) | |
| 2. Valve Body Assy (Accumulator Control Valve) | REPLACEMENT | |
| Harsh Engagement (3rd --> O/D) | ||
| 1. Valve Body Assy (B 1 Accumulator) | REPLACEMENT | |
| 2. Valve Body Assy (Accumulator Control Valve) | REPLACEMENT | |
| 3. Valve Body Assy (3-4 Shift Timing Valve) | REPLACEMENT | |
| Harsh Engagement (O/D --> 3) | ||
| 1. Valve Body Assy (3-4 Shift Timing Valve) | REPLACEMENT | |
| 2 Valve Body Assy (4-3 Shift Timing Valve) | REPLACEMENT | |
| Harsh Engagement (D, 2, L Position) | ||
| Valve Body Assy (Coast Relay Valve) | REPLACEMENT | |
| Slip Or Shudder (Forward And Reverse) | ||
| 1. Valve Body Assy (Oil Strainer) | REPLACEMENT | |
| 2. Off-Vehicle Repair Matrix Chart | — | |
| No Engine Braking (1St: L Position) | ||
| 1. Valve Body Assy (Reverse Control Valve) | REPLACEMENT | |
| 2. Off-Vehicle Repair Matrix Chart | — | |
| No Engine Braking (2nd: 2 Position) | ||
| Valve Body Assy (3-4 Shift Valve) | REPLACEMENT | |
| No Kick-Down | ||
| 1. Valve Body Assy (1-2 Shift Valve) | REPLACEMENT | |
| 2. Valve Body Assy (2-3 Shift Valve) | REPLACEMENT | |
| 3. Valve Body Assy (3-4 Shift Valve) | REPLACEMENT | |
| Poor Acceleration | ||
| Valve Body Assy (SLT Damper) | REPLACEMENT | |
| (1) See OVERHAUL - U340E & U341E article. | ||
| (1) | See OVERHAUL - U340E & U341E article. |
ON-VEHICLE REPAIR SYMPTOM
Chapter 3: Off-vehicle Repair
| Symptom/Suspect Area | See | |
|---|---|---|
| Vehicle Does Not Move In Any Forward Position And Reverse Position | ||
| 1. Planetary Gear Unit | (1) | |
| 2. Forward Clutch | (1) | |
| 3. One-Way Clutch No. 2 | (1) | |
| 4. Reverse Clutch | (1) | |
| 5. 1st And Reverse Brake | (1) | |
| Vehicle Does Not Move In R Position | ||
| 1. Planetary Gear Unit | (1) | |
| 2. Reverse Clutch | (1) | |
| 3. 1st And Reverse Brake | (1) | |
| No Up-Shift (1st --> 2nd) | ||
| 1. 2nd Brake | (1) | |
| 2. One-Way Clutch No. 1 | (1) | |
| No Up-Shift (2nd --> 3rd) | ||
| Direct Clutch | (1) | |
| No Up-Shift (3rd --> O/D) | ||
| O/D And 2nd Brake | (1) | |
| No Lock-Up Or No Lock-Up Off | ||
| Torque Converter Clutch | INSPECTION | |
| Harsh Engagement (N --> D) | ||
| 1. Forward Clutch | (1) | |
| 2. One-Way Clutch No. 2 | (1) | |
| Harsh Engagement (N --> R) | ||
| 1. Reverse Clutch | (1) | |
| 2. 1st And Reverse Brake | (1) | |
| Harsh Engagement (Lock-Up) | ||
| Torque Converter Clutch | INSPECTION | |
| Harsh Engagement (1st --> 2nd) | ||
| 1. 2nd Brake | (1) | |
| 2. One-Way Clutch No. 1 | (1) | |
| Harsh Engagement (2nd --> 3rd) | ||
| Direct Clutch | (1) | |
| Harsh Engagement (3rd --> O/D) | ||
| O/D And 2nd Brake | (1) | |
| Slip Or Shudder (Forward Position) | ||
| 1. Torque Converter Clutch | INSPECTION | |
| 2. Forward Clutch | (1) | |
| 3. Direct Clutch | (1) | |
| 4. O/D And 2nd Brake | (1) | |
| 5. 2nd Brake | (1) | |
| 6. One-Way Clutch No. 1 | (1) | |
| 7. One-Way Clutch No. 2 | (1) | |
| Slip Or Shudder (Reverse Position) | ||
| 1. Reverse Clutch | (1) | |
| 2. 1st And Reverse Brake | (1) | |
| Slip Or Shudder (1st) | ||
| One-Way Clutch No. 2 | (1) | |
| Slip Or Shudder (2nd) | ||
| 1. 2nd Brake | (1) | |
| 2. One-Way Clutch No. 1 | (1) | |
| Slip Or Shudder (3rd) | ||
| Direct Clutch | (1) | |
| Slip Or Shudder (O/D) | ||
| O/D And 2nd Brake | (1) | |
| No Engine Braking (1st: L Position) | ||
| 1st And Reverse Brake | (1) | |
| No Engine Braking (2nd: 2 Position) | ||
| O/D And 2nd Brake | (1) | |
| Poor Acceleration (All Position) | ||
| Torque Converter Clutch | INSPECTION | |
| Large Shift Shock Or Engine Stalls When Starting Off Or Stopping | ||
| Torque Converter Clutch | INSPECTION | |
| (1) See OVERHAUL - U340E & U341E article. | ||
| (1) | See OVERHAUL - U340E & U341E article. |
OFF-VEHICLE REPAIR SYMPTOM
MONITOR STRATEGY
| Related DTCs | P0705 | Shift Lever Position Select Switch/Verify Switch Input |
|---|---|---|
| Required Sensors/Components | Park/Neutral Position Switch | |
| Frequency Of Operation | Continuous | |
| Duration | 0.5 sec. | |
| MIL Operation | 2 Driving Cycles | |
| Sequence Of Operation | None | |
MONITOR STRATEGY
TYPICAL ENABLING CONDITIONS
| Item | Specification | |
|---|---|---|
| Minimum | Maximum | |
| The Monitor Will Run Whenever The Following DTCs Are Not Present. | See LIST OF DISABLE A MONITOR | |
| The Typical Enabling Condition Is Not Available. | ||
TYPICAL ENABLING CONDITIONS
TYPICAL MALFUNCTION THRESHOLDS
| Detection Criteria | Threshold |
|---|---|
| Number Of The Following Signal Input At The Same Time. | 2 Or More |
| Park/Neutral Position Switch | ON |
| L Shift Position Switch | ON |
| 2 Shift Position Switch | ON |
| D Shift Position Switch | ON |
| R Shift Position Switch | ON |
TYPICAL MALFUNCTION THRESHOLDS
COMPONENT OPERATING RANGE
| Parameter | Standard Value |
|---|---|
| Park/Neutral Position Switch | The Park/Neutral Position Switch Sends Only One Signal To The ECM. |
COMPONENT OPERATING RANGE
Scheme 231
Scheme 232
Scheme 233
- INSPECT PARK/NEUTRAL POSITION SWITCH ASSY Disconnect the park/neutral position switch connector. Measure resistance according to the value (s) in the table below when the shift lever is moved to each position. Standard: SPECIFIED CONDITION Shift Position Tester Connection Specified Condition P 1-3 and 6-9 Below 1 ohms Except P 10 kW Or Higher R 2-3 Below 1 ohms Except R 10 kohms Or Higher N 3-5 and 6-9 Below 1 ohms Except N 10 kohms Or Higher D 3-7 Below 1 ohms Except D 10 kohms Or Higher 2 3-4 Below 1 ohms Except 2 10 kohms Or Higher L 3-8 Below 1 W Except L 10 kohms Or Higher NG : REPLACE PARK/NEUTRAL POSITION SWITCH ASSY (See «REPLACEMENT»(ref-180037-S08945244822005072000000) ) OK : Go to next step.
- CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - ECM) Connect the park/neutral position switch connector. Turn the ignition switch to the ON position, and measure the voltage according to the value (s) in the table below when the shift lever is moved to each position. Standard: SPECIFIED CONDITION Shift Position Tester Connection Specified condition P and N E4 - 8 (NSW)- Body Ground Below 1 V Except P and N 10 to 14 V R E5 - 11 (R) - Body Ground 10 to 14 V (1) Except R Below 1 V D E5 - 10 (D) - Body Ground 10 to 14 V Except D Below 1 V 2 E5 - 9 (2)-Body Ground 10 to 14 V Except 2 Below 1 V L E5 - 8 (L) - Body Ground 10 to 14 V Except L Below 1 V (1) The Voltage Will Drop Slightly Due To Lighting Up Of The Back Up Light. NG : REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-203959-S10482953642005110700000) ) OK : REPLACE ECM (See «REPLACEMENT»(ref-179919-S40023297442005071800000) )
| Related DTCs | P0710 | ATF temperature sensor "A"/Range check (Chattering) |
|---|---|---|
| P0712 | ATF temperature sensor "A"/Range check (Low resistance) | |
| P0713 | ATF temperature sensor "A"/Range check (High resistance) | |
| Required sensors/Components | ATF temperature sensor | |
| Frequency of operation | Continuous | |
| Duration | 0.5 sec. | |
| MIL operation | Immediate | |
| Sequence of operation | None | |
MONITOR STRATEGY
| Item | Specification | |
|---|---|---|
| Minimum | Maximum | |
| The Monitor Will Run Whenever The Following DTCs Are Not Present. | See LIST OF DISABLE A MONITOR | |
| Range check (Chattering), (Low resistance) | ||
| The typical enabling condition is not available. | ||
| Range check (High resistance) | ||
| Time after engine start | 900 sec. or more | |
TYPICAL ENABLING CONDITIONS
| Detection criteria | Threshold |
|---|---|
| Range check (Chattering) | |
| ATF temperature sensor resistance | Less than 79 ohms or more than 156 kohms |
| Range check (Low resistance) | |
| ATF temperature sensor resistance | Less than 79 ohms |
| Range check (High resistance) | |
| ATF temperature sensor resistance | More than 156 kohms |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard value |
|---|---|
| ATF temperature sensor resistance | 79 ohms to 156 kohms |
COMPONENT OPERATING RANGE
Scheme 234
Scheme 235
Scheme 236
- INSPECT TRANSMISSION WIRE (ATF TEMPERATURE SENSOR) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 1 (OT) - 6 (E2) 79 ohms to 156 kohms Measure the resistance according to the value (s) in the table below. Standard (Check for short): SPECIFIED CONDITION Tester Connection Specified Condition 1 (OT) - Body ground 10 kohms or higher 6 (E2) - Body ground NG : REPAIR OR REPLACE TRANSMISSION WIRE (See «REPLACEMENT»(ref-180037-S32557356512005072000000) ) OK : Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transaxle. Disconnect the ECM connectors. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition E3 - 30 (OIL) - E3 - 28 (E2) 79 ohms to 156 kohms Measure the resistance according to the value (s) in the table below. Standard (Check for short): SPECIFIED CONDITION Tester Connection Specified Condition E3 - 30 (OIL) - Body ground 10 kohms or higher E3 - 28 (E2) - Body ground NG : REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-203959-S10482953642005110700000) ) OK : REPLACE ECM (See «REPLACEMENT»(ref-179919-S40023297442005071800000) )
| Related DTCs | P0711 | ATF temperature sensor "A"/Rationality check |
|---|---|---|
| Required sensors/Components | ATF temperature sensor | |
| Frequency of operation | Continuous | |
| Duration | 3 sec. | |
| MIL operation | 2 driving cycles | |
| Sequence of operation | None | |
MONITOR STRATEGY
| Item | Specification | |
|---|---|---|
| Minimum | Maximum | |
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR | |
| (A) | ||
| ECT | 15 °C (5 °F) or more | |
| Time after engine start up | 1,000 sec. or more | |
| ATF temperature sensor circuit | Not circuit malfunction | |
| ECT sensor circuit | Not circuit malfunction | |
| IAT sensor circuit | Not circuit malfunction | |
| Throttle position sensor circuit | Not circuit malfunction | |
| (B) | ||
| Time after engine start | 1,100 sec. | |
| Driving distance after engine start | 9 km (6 mile) or more | |
| IAT (12 sec. after engine start) | 10 °C (14 °F) or more | |
| ECT (12 sec. after engine start) | 10 °C (14 °F) or more | |
TYPICAL ENABLING CONDITIONS
| Detection criteria | Threshold |
|---|---|
| Under the following conditions (A) or (B) | |
| (A), (B) | |
| ATF temperature | Less than 10 °C (50 °F) |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard value |
|---|---|
| ATF temperature sensor resistance | 79 ohms to 156 kohms |
COMPONENT OPERATING RANGE
Scheme 237
Scheme 238
Scheme 239
- INSPECT TRANSMISSION WIRE (ATF TEMPERATURE SENSOR) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Temperature: °C (°F) Tester Connection Specified Condition 10 (50) 1 (OT)- 6 (E2) 6.4 kohms 110 (230) 0.2 kohms Measure the resistance according to the value (s) in the table below. Standard (Check for short): SPECIFIED CONDITION Tester Connection Specified Condition 1 (OT) - Body ground 10 kohms or higher 6 (E2) - Body ground NG : REPAIR OR REPLACE TRANSMISSION WIRE (See «REPLACEMENT»(ref-180037-S32557356512005072000000) ) OK : Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transaxle. Disconnect the ECM connectors. Measure the resistance according to the value (s) in the table below. Standard: TEMPERATURE AND RESISTANCE Temperature: °C (°F) Resistance: kohms 10 (50) 6.4 110 (230) 0.2 Measure the resistance according to the value (s) in the table below. OK: Standard (Check for short): SPECIFIED CONDITION Tester Connection Specified Condition E3 - 30 (OIL) - Body ground 10 kohms or higher E3 - 28 (E2) - Body ground NG : REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-203959-S10482953642005110700000) ) OK : REPLACE ECM (See «REPLACEMENT»(ref-179919-S40023297442005071800000) )
| Related DTCs | P0717 | Turbine speed sensor/Verify pulse input |
|---|---|---|
| Required sensors/Components | Speed sensor (NT) | |
| Frequency of operation | Continuous | |
| Duration | 5 sec. | |
| MIL operation | Immediate | |
| Sequence of operation | None | |
MONITOR STRATEGY
| Item | Specification | |
|---|---|---|
| Minimum | Maximum | |
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR | |
| Shift change is completed and before starting next shift change operation. | ||
| Shift position | 3rd or 4th | |
| Output shaft rpm | 1,000 rpm or more | |
| Park/neutral position switch | OFF | |
| Shift lever "R" position switch | OFF | |
| Shift lever "L" position switch | OFF | |
| Engine | Running | |
TYPICAL ENABLING CONDITIONS
| Detection criteria | Threshold |
|---|---|
| Sensor signal rpm | Less than 300 rpm |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard value |
|---|---|
| Speed sensor (NT) resistance | 560 to 680 ohms |
COMPONENT OPERATING RANGE
Scheme 240
Scheme 241
Scheme 242
- INSPECT SPEED SENSOR (NT) Disconnect the speed sensor connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) 1 - 2 560 to 680 ohms NG : REPLACE SPEED SENSOR (NT) OK : Go to next step.
- CHECK HARNESS AND CONNECTOR (SPEED SENSOR - ECM) Connect the speed sensor connector. Disconnect the ECM connector. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) E4 - 27 (NT+) - E4 - 35 (NT-) 560 to 680 ohms Measure the resistance according to the value (s) in the table below. Standard (Check for short): SPECIFIED CONDITION Tester Connection Specified Condition E4 - 27 (NT+) - Body ground 10 kohms or higher E4 - 35 (NT-) - Body ground NG : REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-203959-S10482953642005110700000) ) OK : REPLACE ECM (See «REPLACEMENT»(ref-179919-S40023297442005071800000) )
| Related DTCs | P0724 | Stop light switch/Range check |
|---|---|---|
| Stop light switch/Rationality | ||
| Required sensors/Components | Stop light switch | |
| Frequency of operation | Continuous | |
| Duration | Go and stop 10 times or more | |
| MIL operation | 2 driving cycles | |
| Sequence of operation | None | |
MONITOR STRATEGY
| Item | Specification | |
|---|---|---|
| Minimum | Maximum | |
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR | |
| Number of "Go" and "Stop" defined as follows | 10 times | |
| "Go" | 30 km/h (19 mph) or more | |
| "Stop" | Less than 3 km/h (2 mph) | |
TYPICAL ENABLING CONDITIONS
| Detection criteria | Threshold |
|---|---|
| Switch status | ON stuck |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 243
Scheme 244
- INSPECT STOP LAMP SWITCH ASSY (See «INSPECTION»(ref-204018-S08859008582005110800000) ) NG : REPLACE STOP LAMP SWITCH ASSY OK : Go to next step.
- CHECK HARNESS AND CONNECTOR (STOP LAMP SWITCH ASSY - ECM) Install the stop lamp switch assy. Disconnect the ECM connector. Measure the voltage according to the value (s) in the table below when the brake pedal is depressed and released. Standard: SPECIFIED CONDITION Condition Tester Connection Specified Condition Brake pedal is depressed E5 - 19 (STP) - Body ground 10 to 14 V Brake pedal is released Below 1 V NG : REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-203959-S10482953642005110700000) ) OK : REPLACE ECM (See «REPLACEMENT»(ref-179919-S40023297442005071800000) )
| Related DTCs | P0741 | Torque converter clutch solenoid (SL)/Rationality check |
|---|---|---|
| Torque converter clutch solenoid (SL)/OFF malfunction | ||
| Torque converter clutch solenoid (SL)/ON malfunction | ||
| Required sensors/Components | Torque converter clutch solenoid (SL) | |
| Frequency of operation | Continuous | |
| Duration | OFF malfunction | 3.5 sec. |
| ON malfunction | 1.8 sec. | |
| MIL operation | 2 driving cycles | |
| Sequence of operation | None | |
MONITOR STRATEGY
| Item | Specification | |
|---|---|---|
| Minimum | Maximum | |
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR | |
| OFF malfunction | ||
| ECT | 60 °C (140 °F) or more | |
| Vehicle speed range | 25 km/h (16 mph) or more | |
| Transmission shift position | "D" | |
| ECM selected gear | 3rd or 4th | |
| Shift solenoid "A" (S1) circuit | Not circuit malfunction | |
| Shift solenoid "B" (S2) circuit | Not circuit malfunction | |
| Torque converter clutch solenoid (SL) circuit | Not circuit malfunction | |
| ECT sensor circuit | Not circuit malfunction | |
| Input (turbine) speed sensor circuit | Not circuit malfunction | |
| Internal counter shaft speed sensor circuit | Not circuit malfunction | |
| Throttle sensor circuit | Not circuit malfunction | |
| ECM lock up command | ON | |
| ON malfunction | ||
| ECT | 60 °C (140 °F) or more | |
| Vehicle speed | 25 km/h (16 mph) or more | |
| Transmission shift position | "D" | |
| ECM selected gear | 3rd or 4th | |
| Shift solenoid "A" (S1) circuit | Not circuit malfunction | |
| Shift solenoid "B" (S2) circuit | Not circuit malfunction | |
| Torque converter clutch solenoid (SL) circuit | Not circuit malfunction | |
| ECT sensor circuit | Not circuit malfunction | |
| Input (turbine) speed sensor circuit | Not circuit malfunction | |
| Internal counter shaft speed sensor circuit | Not circuit malfunction | |
| Throttle sensor circuit | Not circuit malfunction | |
| ECM lock up command | OFF | |
| Throttle valve opening angle | 8 % or more | |
| Vehicle speed | Less than 60 km/h (37 mph) | |
TYPICAL ENABLING CONDITIONS
| Detection criteria | Threshold |
|---|---|
| OFF malfunction | |
| Engine speed - Input shaft speed (NE - NT) NE: Engine speed NT: Input (turbine) speed | 100 rpm or more |
| ON malfunction | |
| It is necessary 2 judgments/driving cycle 1st judgment: Temporary flag ON 2nd judgment: Pending fault code ON Vehicle speed must be under 10 km/h (6 mph) once before | |
| Engine speed - Input shaft speed (NE - NT) NE: Engine speed NT: Input (turbine) speed | Less than 35 rpm |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 245
- INSPECT SHIFT SOLENOID VALVE (SL) Remove the shift solenoid valve SL. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) Solenoid Connector (SL) - Solenoid Body (SL) 11 to 15 ohms Connect the positive (+) battery lead to the solenoid connector terminal, and the negative (-) battery lead to the solenoid body for checking the solenoid valve operation. Standard: The solenoid valve makes an operating noise. NG : REPLACE SHIFT SOLENOID VALVE (SL) OK : Go to next step.
- INSPECT TRANSMISSION VALVE BODY ASSY (See «PROBLEM SYMPTOMS TABLE»(ref-204126-S35877874562005110800000) ) NG : REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSY (See «REPLACEMENT»(ref-180037-S37457792492005072000000) ) OK : Go to next step.
- INSPECT TORQUE CONVERTER CLUTCH ASSY (See «INSPECTION»(ref-180037-S35488363542005072000000) ) NG : REPLACE TORQUE CONVERTER CLUTCH ASSY OK : REPAIR AUTOMATIC TRANSAXLE ASSY (See «COMPONENTS»(ref-180037-S14361214942005072000000) )
| Related DTCs | P0751 | Shift solenoid "A" (S1)/Rationality check |
|---|---|---|
| Shift solenoid "A" (S1)/OFF malfunction | ||
| Shift solenoid "A" (S1)/ON malfunction | ||
| Required sensors/Components | Shift solenoid valve S1 | |
| Frequency of operation | Continuous | |
| Duration | OFF malfunction (A) | 0.85 sec. |
| OFF malfunction (B) ON malfunction (A), (B) | 0.8 sec. | |
| MIL operation | 2 driving cycles | |
| Sequence of operation | None | |
MONITOR STRATEGY
| Item | Specification | |
|---|---|---|
| Minimum | Maximum | |
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR | |
| OFF malfunction (A) | ||
| ECT | 60 °C (140 °F) or more | |
| Transmission shift position | D" | |
| Shift solenoid "A" (S1) circuit | Not circuit malfunction | |
| Shift solenoid "B" (S2) circuit | Not circuit malfunction | |
| ECT sensor circuit | Not circuit malfunction | |
| Input (turbine) speed sensor circuit | Not circuit malfunction | |
| Internal counter shaft speed sensor circuit | Not circuit malfunction | |
| Throttle position sensor circuit | Not circuit malfunction | |
| ECM selected gear | 1st | |
| Duration time from shift command of ECM | 1 sec. or more | |
| Vehicle speed | 9 km/h (6 mph) or more | Less than 40 km/h (25 mph) |
| Throttle valve opening angle | 25 % or more 7 % or more at engine speed 1,900 rpm (Condition vary with engine speed) | |
| OFF malfunction (B) | ||
| ECT | 60 °C (140 °F) or more | |
| Transmission shift position | "D" | |
| Shift solenoid "A" (S1) circuit | Not circuit malfunction | |
| Shift solenoid "B" (S2) circuit | Not circuit malfunction | |
| ECT sensor circuit | Not circuit malfunction | |
| Input (turbine) speed sensor circuit | Not circuit malfunction | |
| Internal counter shaft speed sensor circuit | Not circuit malfunction | |
| Throttle position sensor circuit | Not circuit malfunction | |
| Current ECM selected gear | 4th | |
| Last ECM selected gear | 3rd | |
| ON malfunction (A) | ||
| ECT | 60 °C (140 °F) or more | |
| Transmission shift position | "D" | |
| Shift solenoid "A" (S1) circuit | Not circuit malfunction | |
| Shift solenoid "B" (S2) circuit | Not circuit malfunction | |
| ECT sensor circuit | Not circuit malfunction | |
| Input (turbine) speed sensor circuit | Not circuit malfunction | |
| Internal counter shaft speed sensor circuit | Not circuit malfunction | |
| Throttle position sensor circuit | Not circuit malfunction | |
| Current ECM selected gear | 4th | |
| Last ECM selected gear | 3rd | |
| ON malfunction (B) | ||
| ECT | 60 °C (140 °F) or more | |
| Transmission shift position | "D" | |
| Shift solenoid "A" (S1) circuit | Not circuit malfunction | |
| Shift solenoid "B" (S2) circuit | Not circuit malfunction | |
| ECT sensor circuit | Not circuit malfunction | |
| Input (turbine) speed sensor circuit | Not circuit malfunction | |
| Internal counter shaft speed sensor circuit | Not circuit malfunction | |
| Throttle position sensor circuit | Not circuit malfunction | |
| ECM selected gear | 4th | |
| Current - last current: Vehicle speed at current ECM selected gear last: Vehicle speed at last ECM selected gear | Less than 15 km/h (9 mph) | |
| Current - last current: Throttle valve opening angle at current ECM selected gear last: Throttle valve opening angle at last ECM selected gear | Less than 30 % | |
| Vehicle speed (current) | Less than 85 km/h (53 mph) | |
| Throttle valve opening angle (current) | Less than 45 % | |
| Engine speed (current) | 3,200 rpm or more | |
TYPICAL ENABLING CONDITIONS
| Detection criteria | Threshold |
|---|---|
| OFF malfunction | |
| Following conditions met OFF malfunction (A) and (B) It is necessary 2 judgments/driving cycle 1st judgment: temporary flag ON 2nd judgment: pending fault code ON | |
| OFF malfunction (A) | |
| Input speed/Output speed (NT/NO) NT: Input (turbine) speed NO: Internal counter shaft speed | 0.64 "GREATER THAN EQUAL TO" NT/NO < 0.78 |
| OFF malfunction (B) | |
| Input speed/Output speed (NT/NO) NT: Input (turbine) speed NO: Internal counter shaft speed | Changed as follows 0.95 "GREATER THAN EQUAL TO" NT/NO < 1.09 (Last) to 0.64 "GREATER THAN EQUAL TO" NT/NO < 0.78 (Current) |
| ON malfunction | |
| Following Conditions met ON malfunction (A) and (B). | |
| ON malfunction (A) | |
| Input speed/Output speed (NT/NO) NT: Input (turbine) speed NO: Internal counter shaft speed | Not changed as follows 0.95 "GREATER THAN EQUAL TO" NT/NO < 1.09 (Last) to 0.64 "GREATER THAN EQUAL TO" NT/NO < 0.78 (Current) |
| ON malfunction (B) | |
| Current - last current: Engine speed at current ECM selected gear last: Engine speed at last ECM last selected gear | 1,100 rpm or more |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 246
- INSPECT SHIFT SOLENOID VALVE (S1) Remove the shift solenoid valve S1. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) Solenoid Connector (S1) - Solenoid Body (S1) 11 to 15 ohms Connect the positive (+) battery lead to the solenoid connector terminal, and the negative (-) battery lead to the solenoid body for checking the solenoid valve operation. Standard: The solenoid makes an operating noise. NG : REPLACE SHIFT SOLENOID VALVE (S1) OK : Go to next step.
- INSPECT TRANSMISSION VALVE BODY ASSY (See «PROBLEM SYMPTOMS TABLE»(ref-204126-S35877874562005110800000) ) NG : REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSY (See «REPLACEMENT»(ref-180037-S37457792492005072000000) ) OK : REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSY (See «COMPONENTS»(ref-180037-S14361214942005072000000) )
| Related DTCs | P0756 | Shift solenoid "B" (S2)/Rationality check |
|---|---|---|
| Shift solenoid "B" (S2)/OFF malfunction | ||
| Shift solenoid "B" (S2)/ON malfunction | ||
| Required sensors/Components | Shift solenoid valve S2 | |
| Frequency of operation | Continuous | |
| Duration | 0.85 sec. | |
| MIL operation | 2 driving cycles | |
| Sequence of operation | None | |
MONITOR STRATEGY
| Item | Specification | |
|---|---|---|
| Minimum | Maximum | |
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR | |
| OFF malfunction (A) | ||
| ECT | 60 °C (140 °F) or more | |
| Transmission shift position | "D" | |
| Shift solenoid "A" (S1) circuit | Not circuit malfunction | |
| Shift solenoid "B" (S2) circuit | Not circuit malfunction | |
| ECT sensor circuit | Not circuit malfunction | |
| Input (turbine) speed sensor circuit | Not circuit malfunction | |
| Internal counter shaft speed sensor circuit | Not circuit malfunction | |
| Throttle position sensor circuit | Not circuit malfunction | |
| ECM selected gear | 1st | |
| Vehicle speed | 9 km/h (6 mph) or more | Less than 40 km/h (25 mph) |
| Throttle valve opening angle | 7 % or more at engine speed 1,900 rpm (Condition vary with engine speed) | |
| OFF malfunction (B) | ||
| ECT | 60 °C (140 °F) or more | |
| Transmission shift position | "D" | |
| Shift solenoid "A" (S1) circuit | Not circuit malfunction | |
| Shift solenoid "B" (S2) circuit | Not circuit malfunction | |
| ECT sensor circuit | Not circuit malfunction | |
| Input (turbine) speed sensor circuit | Not circuit malfunction | |
| Internal counter shaft speed sensor circuit | Not circuit malfunction | |
| Throttle position sensor circuit | Not circuit malfunction | |
| ECM selected gear | 3rd | |
| Throttle valve opening angle | 7 % or more at engine speed 1,900 rpm (Condition vary with engine speed) | |
| OFF malfunction (C) | ||
| ECT | 60 °C (140 °F) or more | |
| Transmission shift position | "D" | |
| Shift solenoid "A" (S1) circuit | Not circuit malfunction | |
| Shift solenoid "B" (S2) circuit | Not circuit malfunction | |
| ECT sensor circuit | Not circuit malfunction | |
| Input (turbine) speed sensor circuit | Not circuit malfunction | |
| Internal counter shaft speed sensor circuit | Not circuit malfunction | |
| Throttle position sensor circuit | Not circuit malfunction | |
| ECM selected gear | 4th | |
| Throttle valve opening angle | 7 % or more at engine speed 1,900 rpm (Condition vary with engine speed) | |
| ON malfunction (A) | ||
| ECT | 60 °C (140 °F) or more | |
| Transmission shift position | "D" | |
| Shift solenoid "A" (S1) circuit | Not circuit malfunction | |
| Shift solenoid "B" (S2) circuit | Not circuit malfunction | |
| ECT sensor circuit | Not circuit malfunction | |
| Input (turbine) speed sensor circuit | Not circuit malfunction | |
| Internal counter shaft speed sensor circuit | Not circuit malfunction | |
| Throttle position sensor circuit | Not circuit malfunction | |
| ECM selected gear | 2nd | |
| Throttle valve opening angle | 7 % or more at engine speed 1,900 rpm (Condition vary with engine speed) | |
| ON malfunction (B) | ||
| ECT | 60 °C (140 °F) or more | |
| Transmission shift position | "D" | |
| Shift solenoid "A" (S1) circuit | Not circuit malfunction | |
| Shift solenoid "B" (S2) circuit | Not circuit malfunction | |
| ECT sensor circuit | Not circuit malfunction | |
| Input (turbine) speed sensor circuit | Not circuit malfunction | |
| Internal counter shaft speed sensor circuit | Not circuit malfunction | |
| Throttle position sensor circuit | Not circuit malfunction | |
| ECM selected gear | 3rd | |
| Throttle valve opening angle | 7 % or more at engine speed 1,900 rpm (Condition vary with engine speed) | |
| ON malfunction (C) | ||
| ECT | 60 °C (140 °F) or more | |
| Transmission shift position | "D" | |
| Shift solenoid "A" (S1) circuit | Not circuit malfunction | |
| Shift solenoid "B" (S2) circuit | Not circuit malfunction | |
| ECT sensor circuit | Not circuit malfunction | |
| Input (turbine) speed sensor circuit | Not circuit malfunction | |
| Internal counter shaft speed sensor circuit | Not circuit malfunction | |
| Throttle position sensor circuit | Not circuit malfunction | |
| ECM selected gear | 4th | |
| Throttle valve opening angle | 7 % or more at engine speed 1,900 rpm (Condition vary with engine speed) | |
TYPICAL ENABLING CONDITIONS
| Detection criteria | Threshold |
|---|---|
| OFF malfunction | |
| Following conditions met OFF malfunction (A), (B) and (C). | |
| It is necessary 2 judgments/driving cycle 1st judgment: temporary flag ON 2nd judgment: pending fault code ON | |
| OFF malfunction (A) | |
| Input speed/Output speed (NT/NO) NT: Input (turbine) speed NO: Internal counter shaft speed | 1.50 "GREATER THAN EQUAL TO" NT/NO < 1.80 |
| OFF malfunction (B) | |
| Input speed/Output speed (NT/NO) NT: Input (turbine) speed NO: Internal counter shaft speed | 0.95 "GREATER THAN EQUAL TO" NT/NO < 1.09 |
| OFF malfunction (C) | |
| Input speed/Output speed (NT/NO) NT: Input (turbine) speed NO: Internal counter shaft speed | 0.95 "GREATER THAN EQUAL TO" NT/NO < 1.09 |
| ON malfunction | |
| Following conditions met ON malfunction (A), (B) and (C). | |
| ON malfunction (A) | |
| Input speed/Output speed (NT/NO) NT: Input (turbine) speed NO: Internal counter shaft speed | 2.75 "GREATER THAN EQUAL TO" NT/NO < 3.35 |
| ON malfunction (B) | |
| Input speed/Output speed (NT/NO) NT: Input (turbine) speed NO: Internal counter shaft speed | 0.64 "GREATER THAN EQUAL TO" NT/NO < 0.78 |
| ON malfunction (C) | |
| Input speed/Output speed (NT/NO) NT: Input (turbine) speed NO: Internal counter shaft speed | 0.64 "GREATER THAN EQUAL TO" NT/NO < 0.78 |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 247
- INSPECT SHIFT SOLENOID VALVE (S2) Remove the shift solenoid valve S2. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) Solenoid Connector (S2) - Solenoid Body (S2) 11 to 15 ohms Connect the positive (+) battery lead to the solenoid connector terminal, and the negative (-) battery lead to the solenoid body for checking the solenoid valve operation. Standard: The solenoid makes an operating noise. NG : REPLACE SHIFT SOLENOID VALVE (S2) OK : Go to next step.
- INSPECT TRANSMISSION VALVE BODY ASSY (See «PROBLEM SYMPTOMS TABLE»(ref-204126-S35877874562005110800000) ) NG : REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSY (See «REPLACEMENT»(ref-180037-S37457792492005072000000) ) OK : REPAIR OR REPLACE AUTOMATIC TRANSAXLE ASSY (See «COMPONENTS»(ref-180037-S14361214942005072000000) )
| Related DTCs | P0787 | Shift timing solenoid/Range check (Low resistance) |
|---|---|---|
| P0788 | Shift timing solenoid/Range check (High resistance) | |
| Required sensors/Components | Shift solenoid valve ST | |
| Frequency of operation | Continuous | |
| Duration | 2 times or more | |
| MIL operation | Immediate | |
| Sequence of operation | None | |
MONITOR STRATEGY
| Item | Specification | |
|---|---|---|
| Minimum | Maximum | |
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR | |
| Range check (Low resistance) | ||
| Solenoid | ON | |
| Time after solenoid OFF to ON | More than 0.008 sec. | |
| Range check (High resistance) | ||
| Solenoid | OFF | |
| Time after solenoid ON to OFF | More than 0.008 sec. | |
TYPICAL ENABLING CONDITIONS
| Detection criteria | Threshold |
|---|---|
| Range check (Low resistance) | |
| Number of solenoid ON/OFF change with intelligent power MOS diagnosis signal failure (Fail at solenoid resistance "GREATER THAN EQUAL TO" 8 ohms) | 4 times (0.064 sec.) |
| Range check (High resistance) | |
| Number of solenoid ON/OFF change with intelligent power MOS diagnosis signal failure (Fail at solenoid resistance "LESS THAN EQUAL TO" 100 kohms) | 4 times (0.064 sec.) |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard value |
|---|---|
| Shift solenoid valve ST resistance | 11 to 15 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 248
Scheme 249
Scheme 250
Scheme 251
- INSPECT TRANSMISSION WIRE (ST) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) 2 - Body ground 11 to 15 ohms NG : Go to step 3 OK : Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) E4 - 12 (ST) - Body ground 11 to 15 ohms NG : REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-203959-S10482953642005110700000) ) OK : REPLACE ECM (See «REPLACEMENT»(ref-179919-S40023297442005071800000) )
- INSPECT SHIFT SOLENOID VALVE (ST) Remove the shift solenoid valve ST. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) Solenoid Connector (ST) - Solenoid Body (ST) 11 to 15 ohms Connect the positive (+) battery lead to the solenoid connector terminal, and the negative (-) battery lead to the solenoid body for checking the solenoid valve operation. Standard: The solenoid makes an operating noise. NG : REPLACE SHIFT SOLENOID VALVE (ST) OK : REPAIR OR REPLACE TRANSMISSION WIRE (See «REPLACEMENT»(ref-180037-S32557356512005072000000) )
| Related DTCs | P0973 | Shift solenoid "A"/Range check (Low resistance) |
|---|---|---|
| P0974 | Shift solenoid "A"/Range check (High resistance) | |
| Required sensors/Components | Shift solenoid valve S1 | |
| Frequency of operation | Continuous | |
| Duration | 2 times or more | |
| MIL operation | Immediate | |
| Sequence of operation | None | |
MONITOR STRATEGY
| Item | Specification | |
|---|---|---|
| Minimum | Maximum | |
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR | |
| Range check (Low resistance) | ||
| Solenoid | ON | |
| Time after solenoid OFF to ON | More than 0.008 sec. | |
| Range check (High resistance) | ||
| Solenoid | OFF | |
| Time after solenoid ON to OFF | More than 0.008 sec. | |
TYPICAL ENABLING CONDITIONS
| Detection criteria | Threshold |
|---|---|
| Range check (Low resistance) | |
| Number of solenoid ON/OFF change with intelligent power MOS diagnosis signal failure (Fail at solenoid resistance "GREATER THAN EQUAL TO" 8 W) | 4 times (0.064 sec.) |
| Range check (High resistance) | |
| Number of solenoid ON/OFF change with intelligent power MOS diagnosis signal failure (Fail at solenoid resistance "LESS THAN EQUAL TO" 100 kohms) | 4 times (0.064 sec.) |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard value |
|---|---|
| Shift solenoid valve S1 resistance | 11 to 15 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 252
Scheme 253
Scheme 254
Scheme 255
- INSPECT TRANSMISSION WIRE (S1) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) 5 - Body ground 11 to 15 ohms NG : Go to step 3 OK : To next step
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) E4 - 15 (S1) - Body ground 11 to 15 ohms NG : REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-203959-S10482953642005110700000) ) OK : REPLACE ECM (See «REPLACEMENT»(ref-179919-S40023297442005071800000) )
- INSPECT SHIFT SOLENOID VALVE (S1) Remove the shift solenoid valve S1. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) Solenoid Connector (S1) - Solenoid Body (S1) 11 to 15 ohms Connect the positive (+) battery lead to the solenoid connector terminal, and the negative (-) battery lead to the solenoid body for checking the solenoid valve operation. Standard: The solenoid makes an operating noise. NG : REPLACE SHIFT SOLENOID VALVE (S1) OK : REPAIR OR REPLACE TRANSMISSION WIRE (See «REPLACEMENT»(ref-180037-S32557356512005072000000) )
| Related DTCs | P0976 | Shift solenoid "B"/Range check (Low resistance) |
|---|---|---|
| P0977 | Shift solenoid "B"/Range check (High resistance) | |
| Required sensors/Components | Shift solenoid valve S2 | |
| Frequency of operation | Continuous | |
| Duration | 2 times or more | |
| MIL operation | Immediate | |
| Sequence of operation | None | |
MONITOR STRATEGY
| Item | Specification | |
|---|---|---|
| Minimum | Maximum | |
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR | |
| Range check (Low resistance) | ||
| Solenoid | ON | |
| Time after solenoid OFF to ON | More than 0.008 sec. | |
| Range check (High resistance) | ||
| Solenoid | OFF | |
| Time after solenoid ON to OFF | More than 0.008 sec. | |
TYPICAL ENABLING CONDITIONS
| Detection criteria | Threshold |
|---|---|
| Range check (Low resistance) | |
| Number of solenoid ON/OFF change with intelligent power MOS diagnosis signal failure (Fail at solenoid resistance "GREATER THAN EQUAL TO" 8 ohms) | 4 times (0.064 sec.) |
| Range check (High resistance) | |
| Number of solenoid ON/OFF change with intelligent power MOS diagnosis signal failure (Fail at solenoid resistance "LESS THAN EQUAL TO" 100 kohms) | 4 times (0.064 sec.) |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard value |
|---|---|
| Shift solenoid valve S2 resistance | 11 to 15 W at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 256
Scheme 257
Scheme 258
Scheme 259
- INSPECT TRANSMISSION WIRE (S2) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) 10 - Body ground 11 to 15 ohms NG : Go to step 3 OK : Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) E4 - 14 (S2) - Body ground 11 to 15 ohms NG : REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-203959-S10482953642005110700000) ) OK : REPLACE ECM (See «REPLACEMENT»(ref-179919-S40023297442005071800000) )
- INSPECT SHIFT SOLENOID VALVE (S2) Remove the shift solenoid valve S2. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) Solenoid Connector (S2) - Solenoid Body (S2) 11 to 15 ohms Connect the positive (+) battery lead to the solenoid connector terminal, and the negative (-) battery lead to the solenoid body for checking the solenoid valve operation. Standard: The solenoid makes an operating noise. NG : REPLACE SHIFT SOLENOID VALVE (S2) OK : REPAIR OR REPLACE TRANSMISSION WIRE (See «REPLACEMENT»(ref-180037-S32557356512005072000000) )
| Related DTCs | P2716 | Pressure control solenoid "D"/Range check |
|---|---|---|
| Required sensors/Components | Shift solenoid valve SLT | |
| Frequency of operation | Continuous | |
| Duration | 1 sec. | |
| MIL operation | Immediate | |
| Sequence of operation | None | |
MONITOR STRATEGY
| Item | Specification | |
|---|---|---|
| Minimum | Maximum | |
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR | |
| Solenoid current shout OFF | Not shut OFF | |
| Battery voltage | 11 V or more | |
| CPU commanded duty ratio | 19 % or more | |
TYPICAL ENABLING CONDITIONS
| Detection criteria | Threshold |
|---|---|
| Diagnostic signal from MIC | Fail |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard value |
|---|---|
| Shift solenoid valve SLT resistance | 5.0 to 5.6 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 260
Scheme 261
Scheme 262
Scheme 263
- INSPECT TRANSMISSION WIRE (SLT) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) 3 (SLT+) - 8 (SLT-) 5.0 to 5.6 ohms Measure the resistance according to the value (s) in the table below. Standard (Check for short): SPECIFIED CONDITION Tester Connection Specified Condition 3 (SLT+) - Body ground 10 kohms or higher 8 (SLT-) - Body ground NG : Go to step 3 OK : Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transaxle. Disconnect the ECM connector. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) E3 - 17 (SLT+) - E3 - 16 (SLT-) 5.0 to 5.6 ohms Measure the resistance according to the value (s) in the table below. Standard (Check for short): SPECIFIED CONDITION Tester Connection Specified Condition E3 - 17 (SLT+) - Body ground 10 kohms or higher E3 - 16 (SLT-) - Body ground NG : REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-203959-S10482953642005110700000) ) OK : REPLACE ECM (See «REPLACEMENT»(ref-179919-S40023297442005071800000) )
- INSPECT SHIFT SOLENOID VALVE (SLT) Remove the shift solenoid valve (SLT). Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) 1 - 2 5.0 to 5.6 ohms Connect the positive (+) battery lead with a 21 W bulb to the terminal 2 of the solenoid valve connector and the negative (-) battery lead to the terminal 1 of the solenoid valve connector for checking the solenoid valve operation. Standard: The solenoid makes an operating noise. NG : REPLACE SHIFT SOLENOID VALVE (SLT) OK : REPAIR OR REPLACE TRANSMISSION WIRE (See «REPLACEMENT»(ref-180037-S32557356512005072000000) )
| Related DTCs | P2769 | Torque converter clutch solenoid/Range check (Low resistance) |
|---|---|---|
| P2770 | Torque converter clutch solenoid/Range check (High resistance) | |
| Required sensors/Components | Shift solenoid valve SL | |
| Frequency of operation | Continuous | |
| Duration | 0.064 sec. | |
| MIL operation | 2 driving cycles | |
| Sequence of operation | None | |
MONITOR STRATEGY
| Item | Specification | |
|---|---|---|
| Minimum | Maximum | |
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR | |
| Range check (Low resistance) | ||
| Solenoid | ON | |
| Time after solenoid OFF to ON | More than 0.008 sec. | |
| Range check (High resistance) | ||
| Solenoid | OFF | |
| Time after solenoid ON to OFF | More than 0.008 sec. | |
TYPICAL ENABLING CONDITIONS
| Detection criteria | Threshold |
|---|---|
| Range check (Low resistance) | |
| Number of solenoid ON/OFF change with intelligent power MOS diagnosis signal failure (Fail at solenoid resistance "GREATER THAN EQUAL TO" 8 W) | 4 times (0.064 sec.) |
| Range check (High resistance) | |
| Number of solenoid ON/OFF change with intelligent power MOS diagnosis signal failure (Fail at solenoid resistance "LESS THAN EQUAL TO" 100 kW) | 4 times (0.064 sec.) |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard value |
|---|---|
| Shift solenoid valve SL resistance | 11 to 15 ohms at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 264
Scheme 265
Scheme 266
Scheme 267
- INSPECT TRANSMISSION WIRE (SL) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) 4 - Body ground 11 to 15 ohms NG : Go to step 3 OK : Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector. Disconnect the ECM connector. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) E4 - 13 (SL) - Body ground 11 to 15 ohms NG : REPAIR OR REPLACE HARNESS OR CONNECTOR (See «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-203959-S10482953642005110700000) ) OK : REPLACE ECM (See «REPLACEMENT»(ref-179919-S40023297442005071800000) )
- INSPECT SHIFT SOLENOID VALVE (SL) Remove the shift solenoid valve SL. Measure the resistance according to the value (s) in the table below. Standard: SPECIFIED CONDITION Tester Connection Specified Condition 20 °C (68 °F) Solenoid Connector (SL) - Solenoid Body (SL) 11 to 15 ohms Connect the positive (+) battery lead to the solenoid connector terminal, and the negative (-) battery lead to the solenoid body for checking the solenoid valve operation. Standard: The solenoid valve makes an operating noise. NG : REPLACE SHIFT SOLENOID VALVE (SL) OK : REPAIR OR REPLACE TRANSMISSION WIRE (See «REPLACEMENT»(ref-180037-S32557356512005072000000) )
