Engine Control System (Diagnostic Codes (P0504-U0101) & Circuit Tests)): Other

MONITOR STRATEGY

Related DTCs	P0505: ISC function
Required Sensors/Components (Main)	ETCS
Required Sensors/Components (Related)	Crankshaft position sensor, Engine coolant temperature sensor, and Vehicle speed sensor
Frequency of Operation	Once per driving cycle
Duration	10 minutes
MIL Operation	2 driving cycles
Sequence of Operation	None

TYPICAL ENABLING CONDITIONS

Monitor runs whenever following DTCs not stored

P0010 (VVT oil control valve) P0011 (VVT system - Advance) P0012 (VVT system - Retard) P0013 (Exhaust VVT oil control valve) P0014 (Exhaust VVT system - Advance) P0015 (Exhaust VVT system - Retard) P0016 (VVT system - Misalignment) P0017 (Exhaust VVT system - Misalignment) P0031, P0032, P101D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340 (Camshaft position sensor) P0340, P0342, P0343 (VVT sensor) P0351 - P0354 (Igniter) P0365, P0367, P0368 (Exhaust VVT sensor) P0451, P0452, P0453 (EVAP system) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch) P0748, P0778, P0798 (Pressure control solenoid) P219A (Air fuel ratio imbalance)

Engine

Running

TYPICAL MALFUNCTION THRESHOLDS

Either condition is met	1 or 2
1. Both of following conditions A and B met
A. Engine speed - Target engine speed	Less than -100 rpm, or more than 150 rpm (A/C off and NSW off) Less than -100 rpm, or more than 200 rpm (A/C on or NSW on)
B. IAC flow rate learned value	0.9 L/sec. or less, or 6 L/sec. or more for 5 seconds or more
2. Both of following conditions C and D met
C. Frequency that both of following conditions (a) and (b) met	5 times or more
(a) Engine speed - Target engine speed	Less than -100 rpm, or more than 150 rpm (A/C off and NSW off) Less than -100 rpm, or more than 200 rpm (A/C on or NSW on)
(b) Vehicle condition	Stopped after being driven at 10 km/h (6.25 mph) or more
D. Either condition is met	(c) or (d)
(c) IAC flow rate learned value	0.9 L/sec. or less, or 6 L/sec. or more
(d) Amount of change of IAC flow rate learned value	+4.91 L/sec. or more, or -4.15 L/sec. or less

Scheme 152

Scheme 152: CONFIRMATION DRIVING PATTERN

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on [A].
Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off [B].
Idle the engine for 5 minutes or more [C]. HINT: In order to keep the idling stable, turn off the A/C and all other electric loads and do not perform any shift operations.
Enter the following menus: Powertrain / Engine / Trouble Codes [D].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P0505.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F].
Accelerate the vehicle to 10 km/h (6.25 mph) or more, and then idle the engine for 20 seconds or more [E].
Repeat step [E] 5 times.
Enter the following menus: Powertrain / Engine / Trouble Codes [F].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P0505.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

PROCEDURE

CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0505 is output A P0505 and other DTCs are output B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-451180-S40333274922012020700000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 7 OK: Go to next step
CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-451179-S04241581252012020700000) . OK No leaks in air induction system. NG --> See step 8 OK: Go to next step
INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for contamination between the throttle valve and housing, and check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 9 OK: Go to next step
CONFIRM WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read the DTCs. RESULT Result Proceed to P0505 is output A No DTC is output B B --> END A --> See step 10
GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-451061-S15337112142012020700000)
REPAIR OR REPLACE PCV HOSE. Refer to «REMOVAL»(ref-451182-S14434534672012020700000)
REPAIR OR REPLACE AIR INDUCTION SYSTEM. Refer to «REMOVAL»(ref-451183-S13826490012012020700000)
REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY. Refer to «REMOVAL»(ref-451166-S06090055942012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	P050A: Cold start idle air speed control system
Required sensors/Components (Main)	Throttle body assembly
Required sensors/Components (Related)	Mass air flow meter assembly Engine coolant temperature sensor
Frequency of operation	Once per driving cycle
Duration	10 seconds
MIL operation	2 driving cycles
Sequence of operation	None

Monitor runs whenever following DTCs not stored	P0010 (VVT oil control valve) P0011 (VVT system - Advance) P0012 (VVT system - Retard) P0013 (Exhaust VVT oil control valve) P0014 (Exhaust VVT system - Advance) P0015 (Exhaust VVT system - Retard) P0016 (VVT system - Misalignment) P0017 (Exhaust VVT system - Misalignment) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340 (Camshaft position sensor) P0340, P0342, P0343 (VVT sensor) P0351 - P0354 (Igniter) P0365, P0367, P0368 (Exhaust VVT sensor) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch) P219A (Air fuel ratio imbalance)
Battery voltage	8 V or higher
Time after engine start	3 seconds or more
Starter	OFF
Engine coolant temperature at engine start	10°C (14°F) or higher
Engine coolant temperature	10 to 50°C (14 to 122°F)
Engine idling	3 seconds or more
Fuel-cut	OFF
Vehicle speed	Less than 3 km/h (1.875 mph)
Time after shift position changed	1 second or more [AT]
Atmospheric pressure	76 kPa (570 mmHg) or higher

Accumulated mass air flow

Less than 25.625 g (varies with ECT) [AT] Less than 29.375 g (varies with ECT) [MT]

CONFIRMATION DRIVING PATTERN

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on [A].
Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
Idle the engine for 1 minute or more [B].
Enter the following menus: Powertrain / Engine / Trouble Codes [C].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P050A.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following the menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P050A is output A DTC P050A and other DTCs are output B HINT: If any DTCs other than P050A are output, troubleshoot those DTCs first. B --> See step 20 A: Go to next step
READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Short FT #1 and Long FT #1. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1 values to obtain the total fuel trim. Result Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for deposits around the throttle valve and check the throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. OK --> See step 14 NG --> See step 4
REPAIR OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Repair or replace the throttle with motor body assembly. Refer to «REMOVAL»(ref-451166-S06090055942012020700000) . NEXT --> See step 14
CHECK PCV SYSTEM Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-451180-S40333274922012020700000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 10 OK: Go to next step
CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-451179-S04241581252012020700000) . OK No leaks in air induction system. NG --> See step 11 OK: Go to next step
INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK Air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 12 OK: Go to next step
PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Turn the A/C on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1 and VVT Change Angle #1]. Refer to «DATA LIST / ACTIVE TEST»(ref-451061-S12130890322012020700000) . NG --> See step 13 OK: Go to next step
READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 8 g/sec. and 22 g/sec. (shift lever: N; A/C: Off). OK --> See step 14 NG --> See step 15
REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 14
REPAIR OR REPLACE AIR INDUCTION SYSTEM Repair or replace the air induction system. NEXT --> See step 14
REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 14
CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT: Go to next step
CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 15 A --> See step 22
CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-451050-S11678174372012020700000) . HINT: Repair any problems. NEXT: Go to next step
CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050A is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B2-5 (VG) - B30-94 (VG) Always Below 1 ohms B2-4 (E2G) - B30-117 (E2G) Always Below 1 ohms B2-5 (VG) or B30-94 (VG) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL»(ref-451166-S16902211522012020700000) . HINT: If the result of the inspection performed in step 9 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. NEXT: Go to next step
CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 21 A --> END
GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-451061-S15337112142012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)

Related DTCs	P050B: Cold start ignition timing performance
Required Sensors/Components (Main)	Throttle body assembly
Required Sensors/Components (Related)	Mass air flow meter assembly Engine coolant temperature sensor
Frequency of Operation	Once per driving cycle
Duration	10 seconds
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor runs whenever following DTCs not stored	P0010 (VVT oil control valve) P0011 (VVT system - Advance) P0012 (VVT system - Retard) P0013 (Exhaust VVT oil control valve) P0014 (Exhaust VVT system - Advance) P0015 (Exhaust VVT system - Retard) P0016 (VVT system - Misalignment) P0017 (Exhaust VVT system - Misalignment) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P015A, P015B, P2195, P2196, P2237, P2238, P2239, P2252, P2253 (Air fuel ratio sensor) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340 (Camshaft position sensor) P0340, P0342, P0343 (VVT sensor) P0351 - P0354 (Igniter) P0365, P0367, P0368 (Exhaust VVT sensor) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch) P219A (Air fuel ratio imbalance)
Battery voltage	8 V or higher
Time after engine start	3 seconds or more
Starter	OFF
Engine coolant temperature at engine start	10°C (14°F) or higher
Engine coolant temperature	10 to 50°C (14 to 122°F)
Engine idling time	3 seconds or more
Fuel-cut	OFF
Vehicle speed	Less than 3 km/h (1.875 mph)
Atmospheric pressure	76 kPa (570 mmHg) or higher

Accumulated time when ignition timing retard is cut off

5 seconds or more

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on [A].
Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
Idle the engine for 1 minute or more [B].
Enter the following menus: Powertrain / Engine / Trouble Codes [C].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P050B.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P050B is output A P050B and other DTCs are output B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. B --> See step 20 A: Go to next step
READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Short FT #1 and Long FT #1. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1 values to obtain the total fuel trim. OK Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for deposits around the throttle valve and check the throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. OK --> See step 14 NG --> See step 4
REPAIR OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Repair or replace the throttle with motor body assembly. Refer to «REMOVAL»(ref-451166-S06090055942012020700000) . NEXT --> See step 14
CHECK PCV HOSE Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-451180-S40333274922012020700000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 10 OK: Go to next step
CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-451179-S04241581252012020700000) . OK No leak in the air induction system. NG --> See step 11 OK: Go to next step
INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK The air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 12 OK: Go to next step
PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Turn the A/C on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1 and VVT Change Angle #1]. Refer to «DATA LIST / ACTIVE TEST»(ref-451061-S12130890322012020700000) . NG --> See step 13 OK: Go to next step
READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 8 g/sec. and 22 g/sec. (shift lever: N; A/C: Off). OK --> See step 14 NG --> See step 15
REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 14
REPAIR OR REPLACE AIR INDUCTION SYSTEM Repair or replace the air induction system. NEXT --> See step 14
REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 14
CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT: Go to next step
CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F) Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 15 A --> See step 22
CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-451050-S11678174372012020700000) . HINT: Repair any problems. NEXT: Go to next step
CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F) Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050B is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B2-5 (VG) - B30-94 (VG) Always Below 1 ohms B2-4 (E2G) - B30-117 (E2G) Always Below 1 ohms B2-5 (VG) or B30-94 (VG) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL»(ref-451166-S16902211522012020700000) . HINT: If the result of the inspection performed in step 9 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. NEXT: Go to next step
CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 21 A --> END
GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-451061-S15337112142012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)

Related DTCs	P0560: ECM system voltage
Required Sensors/Components (Main)	ECM
Required Sensors/Components (Related)
Frequency of Operation	Continuous
Duration	3 seconds
MIL Operation	Immediate (MIL illuminated after next engine start)
Sequence of Operation	None

Monitor runs whenever following DTCs not stored

None

Stand-by RAM	Initialized
ECM power source	Below 3.5 V

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on.
Wait 5 seconds or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P0560.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 153

Scheme 153: WIRING DIAGRAM

CHECK HARNESS AND CONNECTOR (ECM - BATTERY) Disconnect the ECM connector. Disconnect the cable from the positive (+) battery terminal. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A35-20 (BATT) - Battery positive (+) terminal Always Below 1 ohms A35-20 (BATT) or Battery positive (+) terminal - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
INSPECT BATTERY Check that the battery is not depleted. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-451174-S18929627622012020700000) . OK Battery is not depleted. NG --> REPLACE BATTERY OK: Go to next step
CHECK BATTERY TERMINAL Check that the battery terminals are not loose or corroded. OK Battery terminals are not loose or corroded. NG --> REPAIR BATTERY TERMINAL OK: Go to next step
CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0560 is output A No DTC is output B B --> See step 5 A --> See step 6
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	None
Required sensors/Components (Main)	ECM
Required sensors/Components (Related)	None
Frequency of operation	Continuous
Duration	16 seconds
MIL operation	Immediate
Sequence of operation	None

Monitor runs whenever following DTCs not stored

None

Main CPU and sub CPU mirroring

Fail

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the Techstream off.
Turn the ignition switch off.
Disconnect the Techstream.
Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
Connect the cable to the negative (-) battery terminal.
Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Wait 16 seconds or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P0604.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P0604 is not output. NG --> See step 3 OK --> See step 2
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTC	P0606: ECM range check
Required sensors/Components (Main)	ECM
Required sensors/Components (Related)
Frequency of Operation	Continuous
Duration	Within 1 second
MIL Operation	Immediate
Sequence of Operation	None

Monitor runs whenever the following DTCs are not stored

None

Either condition A or B is met
A. DMA communication	No response
B. Watchdog from monitoring processor	Not toggle

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the Techstream off.
Turn the ignition switch off.
Disconnect the Techstream.
Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
Connect the cable to the negative (-) battery terminal.
Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Wait 1 second or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P0606.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 1 second or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P0606 is not output. NG --> See step 3 OK --> See step 2
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	P0607: Control module performance
Required sensors/Components (Main)	ECM
Required sensors/Components (Related)	Heated oxygen sensor
Frequency of operation	Continuous
Duration	60 seconds
MIL operation	Immediate
Sequence of operation	None

Monitor runs whenever the following DTCs are not stored	None
Engine	Running
Estimated heated oxygen sensor temperature	450 to 750°C (842 to 1382°F)

Heated oxygen sensor transistors

Fail

Scheme 154

Scheme 154: CONFIRMATION DRIVING PATTERN

Stop the engine for 30 minutes or more [A].
Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on [B].
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on [C].
Start the engine and wait 2 minutes [D].
Warm up the engine until the engine coolant temperature is 75°C (167°F) or higher [E].
Idle the engine for 1 minute [F].
Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
Drive the vehicle at a speed between 56 and 80 km/h (35 and 50 mph) for 5 minutes or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
Enter the following menus: Powertrain / Engine / Trouble Codes [I].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P0607, P0136, P0137 or P0138.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [I] again.
If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 155

Scheme 155: PROCEDURE

CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . RESULT Result Proceed to P0607 and P0136, P0137 or P0138 are output A Only P0607 is output B B --> See step 3 A: Go to next step
INSPECT DTC (P0136, P0137 OR P0138) Refer to the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-451173-S26750703122012020700000) . Then proceed to "Inspect ECM". If P0137 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-451173-S26750703122012020700000) . Then proceed to "Inspect ECM". If P0138 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-451173-S26750703122012020700000) . Then proceed to "Inspect ECM". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). NEXT --> See step 6
CHECK FOR EXHAUST GAS LEAK Allow the engine to idle, and then rev the engine. Check for exhaust gas leaks around the heated oxygen sensor. If any exhaust gas leaks are present, repair them and proceed to "Perform Confirmation Driving Pattern". If no exhaust gas leaks are present, proceed to "Perform Confirmation Driving Pattern". HINT: If no exhaust gas leaks are present, there may be a malfunction in the heated oxygen sensor circuit. If any exhaust gas leaks are present around the heated oxygen sensor, noise appears in the output voltage of the heated oxygen sensor. NEXT: Go to next step
PERFORM CONFIRMATION DRIVING PATTERN Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Connect the Techstream to the DLC3. Start the engine. Warm up the engine until the engine coolant temperature becomes 75°C (167°F) or higher. Perform the driving pattern. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle. Drive the vehicle at a speed between 60 and 80 km/h (35 and 50 mph) for 5 minutes. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0607 and P0136, P0137 or P0138 are output A Only P0607 is output B No DTC is output C B --> See step 7 C --> See step 6 A: Go to next step
INSPECT DTC (P0136, P0137 OR P0138) Refer to the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-451173-S26750703122012020700000) . Then proceed to "Inspect ECM". If P0137 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-451173-S26750703122012020700000) . Then proceed to "Inspect ECM". If P0138 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-451173-S26750703122012020700000) . Then proceed to "Inspect ECM". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). NEXT: Go to next step
INSPECT ECM Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Stop the engine and wait for 30 minutes. Connect the Techstream to the DLC3. Start the engine and allow it to idle for 2 minutes. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Check the DTCs. RESULT Result Proceed to DTC is not output A P0607 is output B B --> See step 7 A --> END
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	None
Required sensors/Components (Main)	ECM
Required sensors/Components (Related)
Frequency of operation	Once per driving cycle
Duration	16 seconds
MIL operation	Immediate
Sequence of operation	None

CPU reset

Occurred

When either condition below is met	Condition 1 or 2
1. When all conditions below are met
CPU reset	1 time or more
Learned throttle position - Learned accelerator pedal position	0.4 V or higher
Electronic throttle actuator	OFF
2. CPU reset	2 times or more

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the Techstream off.
Turn the ignition switch off.
Disconnect the Techstream.
Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
Connect the cable to the negative (-) battery terminal.
Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Wait 16 seconds or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P060A.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P060A is not output. NG --> See step 3 OK --> See step 2
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	None
Required sensors/Components (Main)	ECM
Required sensors/Components (Related)
Frequency of operation	Once per driving cycle
Duration	16 seconds
MIL operation	Immediate
Sequence of operation	None

Monitor runs whenever following DTCs not stored

None

When one of following conditions is met	Condition 1, 2 or 3
1. Internal control module serial communication	Fail
2. AD converter	Fail
3. Knock sensor circuit	Fail

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the Techstream off.
Turn the ignition switch off.
Disconnect the Techstream.
Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
Connect the cable to the negative (-) battery terminal.
Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Wait 16 seconds or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P060B.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. RESULT Result Proceed to DTC is not output A DTC P060B is output B DTC P060B and P0327 or P0328 are output C B --> See step 3 C --> See step 4 A --> See step 2
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)
GO TO DTC P0327 OR P0328. Refer to «DTC P0327: Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor); DTC P0328: Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor)»(ref-451173-S07108844542012020700000)

Related DTCs	None
Required sensors/Components (Main)	ECM
Required sensors/Components (Related)
Frequency of operation	Once per driving cycle
Duration	1 second
MIL operation	Immediate
Sequence of operation	None

Monitor runs whenever following DTCs not stored

None

Difference of main accelerator pedal position and sub accelerator pedal position

0.3 V or more

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the Techstream off.
Turn the ignition switch off.
Disconnect the Techstream.
Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
Connect the cable to the negative (-) battery terminal.
Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Wait 16 seconds or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P060D.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P060D is not output. NG --> See step 3 OK --> See step 2
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	None
Required sensors/Components (Main)	ECM
Required sensors/Components (Related)
Frequency of operation	Once per driving cycle
Duration	1 second
MIL operation	Immediate
Sequence of operation	None

Monitor runs whenever following DTCs not stored	None
DMA communication error	Not detected

When one of following conditions is met	Condition 1 or 2
1. Difference of main throttle position and sub throttle position	0.3 V or more
2. Stop light switch signal (CPU) and stop light switch signal (Monitor IC)	Different

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the Techstream off.
Turn the ignition switch off.
Disconnect the Techstream.
Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
Connect the cable to the negative (-) battery terminal.
Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Wait 16 seconds or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P060E.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P060E is not output. NG --> See step 3 OK --> See step 2
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	P0617: Starter signal
Required Sensors/Components (Main)	Starter relay (ST), Park/neutral position switch assembly, Clutch pedal switch assembly (for clutch start system), Ignition switch assembly, Power management control ECU
Required Sensors/Components (Related)	Speed sensor, Crankshaft position sensor
Frequency of Operation	Continuous
Duration	20 seconds
MIL Operation	Immediate
Sequence of Operation	None

Monitor runs whenever following DTCs not stored	None
Battery voltage	10.5 V or higher
Vehicle speed	20 km/h (12.43 mph) or more
Engine speed	1000 rpm or more

Starter signal

Scheme 156

Scheme 156: CONFIRMATION DRIVING PATTERN

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on [A].
Idle the engine for 5 seconds or more [B].
Drive the vehicle at 24 km/h (15 mph) or more for 20 seconds or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
Enter the following menus: Powertrain / Engine / Trouble Codes [D].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P0617.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 157

Scheme 157: WIRING DIAGRAM

Scheme 158

READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Starter Signal. Check the value displayed on the Techstream when the ignition switch is turned to ON and when the engine is started. OK Condition Starter Signal Ignition switch turned to ON Close Engine started Open RESULT Result Proceed to OK A NG (for Automatic Transaxle) B NG (for Manual Transaxle) C B --> See step 2 C --> See step 5 A --> See step 10
INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Inspect the park/neutral position switch assembly. Refer to «INSPECTION»(ref-451170-S41582320372012020700000) . NG --> See step 8 OK: Go to next step
REPAIR OR REPLACE HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - ECM) NEXT: Go to next step
CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Drive the vehicle at more than 24 km/h (15 mph) for more than 20 seconds. Enter the following menus: Powertrain / Engine / Trouble Code. Read the DTCs. RESULT Result Proceed to P0617 is output A No DTC is output B B --> END A --> See step 11
INSPECT CLUTCH PEDAL SWITCH ASSEMBLY (FOR CLUTCH START SYSTEM) Inspect the clutch pedal switch assembly (for clutch start system). Refer to «INSPECTION»(ref-451176-S37533855712012020700000) . NG --> See step 9 OK: Go to next step
REPAIR OR REPLACE HARNESS AND CONNECTOR (CLUTCH PEDAL SWITCH - ECM) NEXT: Go to next step
CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Drive the vehicle at more than 24 km/h (15 mph) for more than 20 seconds. Enter the following menus: Powertrain / Engine / Trouble Code. Read the DTCs. RESULT Result Proceed to P0617 is output A No DTC is output B B --> END A --> See step 12
REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-451170-S34996445972012020700000)
REPLACE CLUTCH PEDAL SWITCH ASSEMBLY (FOR CLUTCH START SYSTEM). Refer to «REMOVAL»(ref-451176-S25457226082012020700000)
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	P062F: Internal control module EEPROM error
Required sensors/Components (Main)	ECM
Required sensors/Components (Related)
Frequency of operation	Once per driving cycle
Duration	11 seconds
MIL operation	Immediate
Sequence of operation	None

Monitor runs whenever following DTCs not stored	None
Time after engine start	10 seconds or more
Battery voltage	8 V or higher
Ignition switch	ON
Starter	OFF

Permanent fault code data

Mismatch (3 times or more)

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on.
Wait 30 seconds or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P062F.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 30 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to No DTC is output A DTC P062F is output B B --> See step 2 A --> See step 3
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)

Related DTCs	P0630: VIN not programmed
Required Sensors/Components (Main)	ECM
Required Sensors/Components (Related)
Frequency of Operation	Continuous
Duration	0.325 seconds
MIL Operation	Immediate
Sequence of Operation	None

Battery voltage	8 V or higher
Ignition switch	ON
Starter	OFF

VIN code

Not programmed

COMPONENT OPERATING RANGE

VIN code

Programmed

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on.
Wait 5 seconds or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P0630.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

READ CURRENT DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0630 is output A P0630 and other DTCs are output B HINT: If any DTCs other than P0630 are output, troubleshoot those DTCs first. NOTE: If P0630 is stored, the VIN must be input to the ECM using the Techstream. However, all DTCs are cleared automatically by the Techstream when the VIN is input. If DTCs other than P0630 are output, troubleshoot them first. B --> See step 3 A: Go to next step
INPUT VIN WITH TECHSTREAM Refer to Registration. Refer to «REGISTRATION»(ref-451061-S18147329012012020700000) . NEXT --> END
GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-451061-S15337112142012020700000)

Related DTCs	None
Required sensors/Components (Main)	ECM
Required sensors/Components (Related)
Frequency of operation	Once per driving cycle
Duration	Within 1 second
MIL operation	Immediate
Sequence of operation	None

Throttle actuator power supply voltage

7 V or higher

Ignition switch	From ON to off (Temporary Fail ON)
Throttle actuator power supply	ON

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the Techstream off.
Turn the ignition switch off.
Disconnect the Techstream.
Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
Connect the cable to the negative (-) battery terminal.
Turn the ignition switch to ON.
Wait 10 seconds or more.
Turn the ignition switch off.
Wait 15 seconds or more.
Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Wait 5 seconds or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P0657.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON. Wait 10 seconds or more. Turn the ignition switch off. Wait 15 seconds or more. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P0657 is not output. NG --> See step 3 OK --> See step 2
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	P0705: Park/neutral position switch/Verify switch input
Required sensors/Components	Park/neutral position switch assembly, Transmission control switch
Frequency of operation	Continuous
Duration	Condition (A) and (B) 2 sec. Condition (C) 60 sec.
MIL operation	2 driving cycles
Sequence of operation	None

Monitor runs whenever following DTCs not stored	None
Ignition switch	ON
Battery voltage	10.5 V or higher
Starter	OFF

ALL

One of the following conditions is met	Condition (a), (b), (c) or (d)
(a) NSW switch	ON
(b) P switch	ON
(c) N switch	ON
(d) R switch	ON

CONDITION (B)

One of the following conditions is met: Condition (A), (B) and (C) CONDITION (A) Any two of the following conditions are met: Conditions A, B and C A. One of the following conditions is met: Conditions (a), (b) or (c) (a) P switch ON (b) N switch ON (c) NSW switch ON B. R switch ON C. D switch ON CONDITION (B) M or S range position switch ON CONDITION (C) Park switch OFF N switch OFF NSW switch OFF R switch OFF D switch OFF

Park/neutral position switch

The park/neutral position switch sends only one signal to the ECM.

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) .
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on.
Wait 10 minutes or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P0705.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 159

Scheme 159: WIRING DIAGRAM

Related DTCs	P0724: Stop light switch/Range check/Rationality
Required sensors/Components	Stop light switch assembly, Vehicle speed sensor
Frequency of operation	Continuous
Duration	GO and STOP 5 times
MIL operation	2 driving cycles
Sequence of operation	None

Monitor runs whenever following DTCs not stored	None
Battery voltage	8 V or higher
Starter	OFF
Ignition switch	ON
GO (Vehicle speed is 30 km/h (18.65 mph) or more)	Once
STOP (Vehicle speed is less than 3 km/h (1.86 mph))	Once

Stop light switch

Stuck on

Scheme 160

Scheme 160: CONFIRMATION DRIVING PATTERN

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on [A].
Wait 5 seconds.
Enter the following menus: Powertrain / Engine / Trouble Codes [B].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P0724.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] through [E].
Start the engine [C].
Accelerate the vehicle to 30 km/h (19 mph) or more, and then depress the brake pedal and decelerate the vehicle to 3 km/h (1.8 mph) or less [D]. Repeat step [D] 5 times. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
Check the DTC judgment result [E].
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

CHECK STOP LIGHT SWITCH ASSEMBLY INSTALLATION Check the stop light switch assembly installation. OK Stop light switch assembly is installed correctly. NG --> See step 4 OK: Go to next step
INSPECT STOP LIGHT SWITCH ASSEMBLY Inspect the stop light switch assembly. Refer to «INSPECTION»(ref-451186-S31823982232012020700000) . NG --> See step 5 OK: Go to next step
CHECK HARNESS AND CONNECTOR (ECM - BATTERY) Disconnect the ECM connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A35-29 (STP) - Body ground Brake pedal is depressed 11 to 14 V A35-29 (STP) - Body ground Brake pedal is released Below 1 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
SECURELY REINSTALL STOP LIGHT SWITCH ASSEMBLY. Refer to «INSTALLATION»(ref-451186-S42844307762012020700000)
REPLACE STOP LIGHT SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-451186-S12977845582012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTC	P1607: Internal control module range check
Required sensors/Components (Main)	ECM
Required sensors/Components (Related)	Cruise control
Frequency of Operation	Continuous
Duration	0.3 seconds
MIL Operation	Immediate
Sequence of Operation	None

Monitor runs whenever the following DTCs are not stored	None
DMA communication error	Not detected

Cruise control	Prohibited
When either condition below is met
Cruise control	Operating
Low speed control	Operating

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the Techstream off.
Turn the ignition switch off.
Disconnect the Techstream.
Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
Connect the cable to the negative (-) battery terminal.
Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Wait 16 seconds or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P1607.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

CHECK FOR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. OK P1607 is not output. NG --> See step 3 OK --> See step 2
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	P2004: Tumble Control Valve (TCV) Stuck Open P2006: Tumble Control Valve (TCV) Stuck Closed
Required sensors/components (Main)	Tumble control valve
Required sensors/components (Related)	Intake air temperature sensor, Engine coolant temperature sensor
Frequency of operation	Once per driving cycle
Duration	Approximately 10 seconds
MIL operation	2 driving cycles
Sequence operation	None

The monitor will run whenever these DTCs are not stored	None
Engine coolant temperature	10°C (14°F) or higher
Intake air temperature	10°C (14°F) or higher
Ignition switch	ON
Battery voltage	8 V or higher

ALL

Control valve angle

17° or more

P2004

Control valve angle

Less than 35°

P2006

Control valve angle

0 to 70°

Scheme 161

Scheme 161: CONFIRMATION DRIVING PATTERN

Connect the Techstream to the DLC3.
Turn the ignition switch to ON.
Turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on [A].
Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. HINT: Check for DTC P2004 at a coolant temperature of 30°C or less. Check for DTC P2006 at a coolant temperature of 80°C or higher.
Turn the ignition switch off.
Turn the ignition switch to ON, wait approximately 10 seconds, and then turn the ignition switch off. Repeat this procedure 3 times [B].
Enter the following menus: Powertrain / Engine / Trouble Codes [C].
Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All readiness.
Input the DTC: P2004 or P2006.
Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 162

Scheme 162: WIRING DIAGRAM

CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2004 OR P2006) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P2004 or P2006 is output A P2004 or P2006 and other DTCs are output B HINT: If any DTCs other than P2004 or P2006 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
INSPECT INTAKE AIR CONTROL VALVE ACTUATOR (FOR TCV) Inspect the intake air control valve actuator (for TCV). Refer to «ON-VEHICLE INSPECTION - Step 3»(ref-451179-S04241581252012020700000) . NG --> See step 6 OK: Go to next step
CHECK HARNESS AND CONNECTOR (ECM - INTAKE AIR CONTROL VALVE ACTUATOR) Disconnect the ECM connector. Disconnect the intake air control valve actuator connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B30-3 (IA1-) - M2-4 (M-) Always Below 1 ohms B30-4 (IA1+) - M2-5 (M+) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B30-3 (IA1-) or M2-4 (M-) - Body ground Always 10 kohms or higher B30-4 (IA1+) or M2-5 (M+) - body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
CHECK WHETHER DTC OUTPUT RECURS (DTC P2004 OR P2006) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read the DTCs. RESULT Result Proceed to P2004 or P2006 is output A No DTC is output B B --> SYSTEM OK A --> See step 7
GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-451061-S15337112142012020700000)
REPLACE INTAKE MANIFOLD. Refer to «REMOVAL»(ref-451183-S13826490012012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	P2009: DC motor for intake air control valve actuator Range Check (Low Current) P2010: DC motor for intake air control valve actuator Range Check (High Current)
Required sensors/components (Main)	Intake air control valve actuator (for TCV)
Required sensors/components (Related)	None
Frequency of operation	Continuous
Duration	DC motor for intake air control valve actuator Range Check (Low Current): 1 second DC motor for intake air control valve actuator Range Check (High Current): 10 seconds
MIL operation	Immediate
Sequence operation	None

The monitor will run whenever these DTCs are not stored	None
Battery voltage	8 V or higher
Starter	OFF
Output signal duty	100%
Difference between motor current and previous motor current	Less than 0.2 A

P2009

The monitor will run whenever these DTCs are not stored	None
Battery voltage	8 V or higher
Starter	OFF

P2010

Current of DC motor for intake air control valve actuator

Below 0.35 A

P2009

Motor drive IC high current limiter monitor input

Fail

P2010

Current of DC motor for TCV

0.4 to 3 A

Connect the Techstream to the DLC3.
Turn the ignition switch to ON.
Turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on.
Enter the following menus: Powertrain / Engine / Data List / Coolant Temp.
Check that the coolant temperature is 60°C (140°F) or higher.
Wait approximately 10 seconds.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All readiness.
Input the DTC: P2009 or P2010.
Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

INSPECT INTAKE AIR CONTROL VALVE ACTUATOR (FOR TCV) Inspect the intake air control valve actuator (for TCV). Refer to «INSPECTION»(ref-451183-S03406544532012020700000) . NG --> See step 4 OK: Go to next step
CHECK HARNESS AND CONNECTOR (ECM - INTAKE AIR CONTROL VALVE ACTUATOR) Disconnect the ECM connector. Disconnect the intake air control valve actuator connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B30-3 (IA1-) - M2-4 (M-) Always Below 1 ohms B30-4 (IA1+) - M2-5 (M+) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B30-3 (IA1-) or M2-4 (M-) - Body ground Always 10 kohms or higher B30-4 (IA1+) or M2-5 (M+) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
CHECK WHETHER DTC OUTPUT RECURS (DTC P2009 OR P2010) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read the DTCs. RESULT Result Proceed to P2009 or P2010 is output A No DTC is output B B --> See step 5 A --> See step 6
REPLACE INTAKE AIR CONTROL VALVE ACTUATOR (FOR TCV). Refer to «REMOVAL»(ref-451183-S35750795822012020700000)
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	P2014: TCV Position Sensor Range Check (Chattering) P2016: TCV Position Sensor Range Check (Low Voltage) P2017: TCV Position Sensor Range Check (High Voltage)
Required sensors/components (Main)	Intake air control valve actuator (for TCV)
Required sensors/components (Related)	None
Frequency of operation	Continuous
Duration	0.5 seconds
MIL operation	Immediate
Sequence operation	None

The monitor will run whenever these DTCs are not stored

None

TCV position sensor voltage

Below 0.2 V or higher than 4.8 V

P2014

TCV position sensor voltage

Below 0.2 V

P2016

TCV position sensor voltage

Higher than 4.8 V

P2017

TCV position sensor voltage

0.2 to 4.8 V

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on.
Allow 0.5 seconds or more to elapse.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All readiness.
Input the DTC: P2014, P2016 or P2017.
Check the DTC judgment result. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Related DTCs	P2102: Throttle actuator current (low current) P2103: Throttle actuator current (high current)
Required Sensors/Components (Main)	Throttle actuator (throttle with motor body assembly)
Required Sensors/Components (Related)	None
Frequency of Operation	Continuous
Duration	2 seconds: P2102 Within 1 second: P2103
MIL Operation	Immediate
Sequence of Operation	None

Monitor runs whenever following DTCs not stored

None

Throttle actuator	Activated
Duty cycle to throttle actuator	80% or more
Throttle actuator power supply	8 V or higher

P2102

Throttle actuator	Activated
Throttle actuator power supply	8 V or higher
Battery voltage	8 V or higher
Starter	OFF

P2103

Throttle actuator current

Below 0.5 A

P2102

Either of the following conditions is met	Condition 1 or 2
1. Hybrid IC diagnosis signal	Fails 25 times
2. Hybrid IC current limiter monitor input	Fails for 0.6 seconds

P2103

Scheme 163

Scheme 163: CONFIRMATION DRIVING PATTERN

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on [A].
Start the engine.
With the vehicle stationary, fully depress the accelerator pedal and quickly release it [B].
Check that 16 seconds or more have elapsed from the instant when the accelerator pedal is first depressed.
Enter the following menus: Powertrain / Engine / Trouble Codes [C].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P2102 or P2103.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

FAIL-SAFE

When either of these DTCs, or other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing in accordance with the accelerator pedal position to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

The ECM continues operating in fail-safe mode until a pass condition is detected, and the ignition switch is then turned off.

Scheme 164

Scheme 164: WIRING DIAGRAM

INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (RESISTANCE OF THROTTLE ACTUATOR) Inspect the throttle with motor body assembly. Refer to «INSPECTION»(ref-451166-S15584028722012020700000) . NG --> See step 5 OK: Go to next step
CHECK HARNESS AND CONNECTOR (THROTTLE ACTUATOR - ECM) Disconnect the throttle with motor body connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B22-2 (M+) - B30-21 (M+) Always Below 1 ohms B22-1 (M-) - B30-20 (M-) Always Below 1 ohms B22-2 (M+) or B30-21 (M+) - Body ground Always 10 kohms or higher B22-1 (M-) or B30-20 (M-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for foreign objects between the throttle valve and the housing. OK No foreign objects between throttle valve and housing. NG --> REMOVE FOREIGN OBJECT AND CLEAN THROTTLE BODY OK: Go to next step
INSPECT THROTTLE VALVE Check if the throttle valve opens and closes smoothly. OK Throttle valve opens and closes smoothly. NG --> See step 6 OK --> See step 7
REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY. Refer to «REMOVAL»(ref-451166-S06090055942012020700000)
REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY. Refer to «REMOVAL»(ref-451166-S06090055942012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	P2111: Throttle actuator stuck open P2112: Throttle actuator stuck closed
Required Sensors/Components (Main)	Throttle actuator
Required Sensors/Components (Related)
Frequency of Operation	Continuous
Duration	0.5 seconds
MIL Operation	Immediate
Sequence of Operation	None

Monitor runs whenever following DTCs not stored	None
System guard judgment condition*	ON
*System guard is ON when the following conditions met
Throttle actuator	ON
Throttle actuator duty calculation	Executing
Throttle position sensor failure	Not detected
Throttle actuator current-cut operation	Not executing
Throttle actuator power supply	4 V or higher
Throttle actuator failure	Not detected

ALL

All of following conditions met
Throttle actuator current	2 A or higher
Duty cycle to close throttle	80% or more

P2111 (THROTTLE ACTUATOR STUCK OPEN)

All of following conditions met
Throttle actuator current	2 A or higher
Duty cycle to open throttle	80% or more

P2112 (THROTTLE ACTUATOR STUCK CLOSED)

Throttle position sensor voltage

No change

Scheme 165

Scheme 165: CONFIRMATION DRIVING PATTERN

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on [A].
Start the engine and fully depress and release the accelerator pedal quickly (to fully open and close the throttle valve).
Enter the following menus: Powertrain / Engine / Trouble Codes [B].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P2111 or P2112.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When either of these DTCs or other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing in accordance with the accelerator pedal position to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

The ECM continues operating in fail-safe mode until a pass condition is detected, and the ignition switch is then turned off.

CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P2111 or P2112 is output A P2111 or P2112 and other DTCs are output B HINT: If any DTCs other than P2111 or P2112 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and housing. If necessary, clean the throttle body. Also, check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 4 OK: Go to next step
READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Data List / All Data / Throttle Position No. 1, Throttle Position No. 2 and Throttle Position Command. Check the values displayed on the Techstream while wiggling the ECM wire harness. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. RESULT Result Proceed to Value in Data List changes when wire harness is wiggled, or DTC is output* A Other than above B *: As the DTC was stored due to a change in the contact resistance of the connector, repair or replace the wire harness or connector. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-451050-S11678174372012020700000) . B --> See step 5 A --> REPAIR OR REPLACE HARNESS OR CONNECTOR
REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Replace the throttle with motor body assembly. Refer to «REMOVAL»(ref-451166-S06090055942012020700000) . NEXT: Go to next step
CHECK WHETHER DTC OUTPUT RECURS (DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Start the engine, and then fully depress and release the accelerator pedal quickly to fully open and close the throttle valve. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to No DTC is output A P2111 or P2112 is output B B --> See step 7 A --> END
GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-451061-S15337112142012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	P2118: Throttle actuator power supply
Required Sensors/Components (Main)	Throttle actuator, Throttle with motor body assembly, ETCS fuse
Required Sensors/Components (Related)	None
Frequency of Operation	Continuous
Duration	0.8 seconds
MIL Operation	Immediate
Sequence of Operation	None

Monitor runs whenever following DTCs not stored	None
Battery voltage	8 V or higher
Electronic throttle actuator power	ON

Throttle actuator power supply voltage (+BM)

Below 4 V

Throttle actuator power supply voltage (+BM)

11 to 14 V

Scheme 166

Scheme 166: CONFIRMATION DRIVING PATTERN

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on [A].
Start the engine.
Slowly depress the accelerator pedal, raise the engine speed to approximately 3000 rpm over approximately 5 seconds, and then idle the engine [B].
Check that 16 seconds or more have elapsed since the engine was started.
Enter the following menus: Powertrain / Engine / Trouble Codes [C].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P2118.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When this DTC or other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing in accordance with the accelerator pedal position to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

The ECM continues operating in fail-safe mode until a pass condition is detected, and the ignition switch is then turned off.

Scheme 167

Scheme 167: WIRING DIAGRAM

READ VALUE USING TECHSTREAM (+BM VOLTAGE) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / +BM Voltage. Read the value displayed on the Techstream. RESULT Result Proceed to Below 11 V or higher than 14 V A 11 to 14 V B B --> See step 3 A: Go to next step
CHECK HARNESS AND CONNECTOR (ECM - BATTERY, BODY GROUND) Disconnect the ECM connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A35-3 (+BM) - Body ground Always 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B30-104 (E1) - Body ground Always Below 1 ohms B30-19 (ME01) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	P2119: ETCS malfunction
Required Sensors/Components (Main)	Throttle actuator
Required Sensors/Components (Related)
Frequency of Operation	Continuous
Duration	Within 1 second
MIL Operation	Immediate
Sequence of Operation	None

Monitor runs whenever following DTCs not stored	None
System guard judgment condition*	ON
*: System guard is ON when the following conditions are met
Throttle actuator	ON
Throttle actuator duty calculation	Executing
Throttle position sensor failure	Not detected
Throttle actuator current-cut operation	Not executing
Throttle actuator power supply	4 V or higher
Throttle actuator failure	Not detected

Either of following conditions A or B met
A. Difference between commanded closed throttle position and current closed throttle position	0.3 V or more for 1 second
B. Difference between commanded open throttle position and current open throttle position	0.3 V or more for 0.6 seconds

Scheme 168

Scheme 168: CONFIRMATION DRIVING PATTERN

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on [A].
Start the engine.
Idle the engine for 20 seconds.
Enter the following menus: Powertrain / Engine / Trouble Codes [B].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P2119.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, fully depress and release the accelerator pedal 3 times, and then check the DTC judgment result [C].
If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

The ECM continues operating in fail-safe mode until a pass condition is detected, and the ignition switch is then turned off.

CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P2119 is output A P2119 and other DTCs are output B HINT: If any DTCs other than P2119 are output, troubleshoot those DTCs first. B --> See step 8 A: Go to next step
READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Data List / All Data / Throttle Position No. 1 and Throttle Position Command. Check the values displayed on the Techstream while fully depressing and releasing the accelerator pedal quickly. RESULT Result Proceed to Throttle Position No. 1 does not change A Throttle Position No. 1 changes even a little B HINT: When a DTC is output, the system changes to fail-safe mode. Therefore, only use the data up until the time the DTC is stored for confirmation. B --> See step 4 A: Go to next step
INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (RESISTANCE OF THROTTLE ACTUATOR) Inspect the throttle with motor body assembly. Refer to «INSPECTION»(ref-451166-S15584028722012020700000) . NG --> See step 6 OK: Go to next step
INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and housing. If necessary, clean the throttle body. Also, check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 6 OK: Go to next step
READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Data List / All Data / Throttle Position No. 1, Throttle Position No. 2 and Throttle Position Command. Check the values displayed on the Techstream while wiggling the ECM wire harness. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. RESULT Result Proceed to Value in Data List changes when wire harness is wiggled, or DTC is output* A Other than above B *: As the DTC was stored due to a change in the contact resistance of the connector, repair or replace the wire harness or connector. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-451050-S11678174372012020700000) . B --> See step 7 A --> REPAIR OR REPLACE HARNESS OR CONNECTOR
REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Replace the throttle with motor body assembly. Refer to «REMOVAL»(ref-451166-S06090055942012020700000) . NEXT: Go to next step
CHECK WHETHER DTC OUTPUT RECURS (DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Allow the engine to idle for 15 seconds or more. Fully depress and release the accelerator pedal several times quickly. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to No DTC is output A P2119 is output B B --> See step 9 A --> END
GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-451061-S15337112142012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	P2120: Accelerator pedal position sensor 1 range check (fluctuating) P2122: Accelerator pedal position sensor 1 range check (low voltage) P2123: Accelerator pedal position sensor 1 range check (high voltage) P2125: Accelerator pedal position sensor 2 range check (fluctuating) P2127: Accelerator pedal position sensor 2 range check (low voltage) P2128: Accelerator pedal position sensor 2 range check (high voltage) P2138: Accelerator pedal position sensor range check (correlation)
Required Sensors/Components (Main)	Accelerator pedal position sensor assembly
Required Sensors/Components (Related)
Frequency of Operation	Continuous
Duration	0.5 seconds: P2120, P2122, P2125 and P2127 2.0 seconds: P2123, P2128 and P2138
MIL Operation	Immediate
Sequence of Operation	None

Monitor runs whenever following DTCs not stored	None
Either of following conditions 1 or 2 met
1. Ignition switch	ON
2. Throttle actuator power	ON

Either of following conditions 1 or 2 met
1. VPA voltage when VPA2 voltage 0.04 V or higher	0.4 V or less
2. VPA voltage	4.8 V or higher

P2120

VPA voltage when VPA2 voltage 0.04 V or higher

0.4 V or less

P2122

VPA voltage

4.8 V or higher

P2123

Either of following conditions 1 or 2 met
1. VPA2 voltage when VPA voltage 0.04 V or higher	1.2 V or less
2. VPA2 voltage when VPA voltage 0.4 to 3.45 V	4.8 V or higher

P2125

VPA2 voltage when VPA voltage 0.04 V or higher

1.2 V or less

P2127

VPA2 voltage when VPA voltage 0.4 to 3.45 V

4.8 V or higher

P2128

Either of following conditions A or B met
Condition A
Difference between VPA and VPA2 voltages	0.02 V or less
Condition B
VPA voltage	0.4 V or less
VPA2 voltage	1.2 V or less

P2138

VPA voltage	0.4 to 4.8 V
VPA2 voltage	1.2 to 4.8 V
Difference between VPA and VPA2 voltages	More than 0.02 V

Scheme 169

Scheme 169: CONFIRMATION DRIVING PATTERN

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on [A].
Fully depress and release the accelerator pedal [B].
Check that 5 seconds or more have elapsed since the ignition switch was turned to ON.
Enter the following menus: Powertrain / Engine / Trouble Codes [C].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P2120, P2122, P2123, P2125, P2127, P2128 or P2138.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

When DTC P2120, P2121, P2122, P2123, P2125, P2127, P2128 or P2138 is stored, the ECM enters fail-safe mode. If either of the 2 sensor circuits malfunctions, the ECM uses the remaining circuit to calculate the accelerator pedal position to allow the vehicle to continue driving. If both of the circuits malfunction, the ECM regards the accelerator pedal as being released. As a result, the throttle valve is closed and the engine idles.

The ECM continues operating in fail-safe mode until a pass condition is detected, and the ignition switch is then turned off.

Scheme 170

Scheme 170: WIRING DIAGRAM

Related DTCs	P2121: Accelerator pedal position sensor rationality
Required Sensors/Components (Main)	Accelerator pedal position sensor assembly
Required Sensors/Components (Related)
Frequency of Operation	Continuous
Duration	0.5 seconds
MIL Operation	Immediate
Sequence of Operation	None

Monitor runs whenever following DTCs not stored	P2120, P2122, P2123, P2125, P2127, P2128, P2138 (Accelerator pedal position sensor)
Either of following conditions 1 or 2 met
1. Ignition switch	ON
2. Throttle actuator power	ON

Difference between VPA voltage (learned value) and VPA2 voltage (learned value)

Less than 0.4 V, or more than 1.2 V

Scheme 171

Scheme 171: CONFIRMATION DRIVING PATTERN

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on [A].
Fully depress and release the accelerator pedal [B].
Check that 20 seconds or more have elapsed since the ignition switch was turned to ON.
Enter the following menus: Powertrain / Engine / Trouble Codes [C].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P2121.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

The accelerator pedal position sensor has two (main and sub) sensor circuits. If a malfunction occurs in either of the sensor circuits, the ECM detects the abnormal signal voltage difference between the two sensor circuits and switches to limp mode. In limp mode, the functioning circuit is used to calculate the accelerator pedal position to allow the vehicle to continue driving. If both circuits malfunction, the ECM regards the accelerator pedal as being fully released. In this case, the throttle valve remains closed as if the engine were idling.

If a pass condition is detected and then the ignition switch is turned off, the fail-safe operation stops and the system returns to normal.

CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2121) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P2121 is output A P2121 and other DTCs are output B HINT: If any DTCs other than P2121 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
READ VALUE USING TECHSTREAM (ACCELERATOR PEDAL POSITION SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Accel Sensor Out No. 1 and Accel Sensor Out No. 2. Read the values displayed on the Techstream. Standard Voltage Accelerator Pedal Operation Accel Sensor Out No. 1 Accel Sensor Out No. 2 Difference between Accel Sensor Out No. 1 and Accel Sensor Out No. 2 Released 0.5 to 1.1 V 1.2 to 2.0 V 0.4 to 1.2 V Depressed 2.6 to 4.5 V 3.4 to 4.98 V TEXT IN ILLUSTRATION *a Depressed *b Released NG --> See step 3 OK --> See step 6
REPLACE ACCELERATOR PEDAL POSITION SENSOR ASSEMBLY Replace the accelerator pedal position sensor assembly. Refer to «REMOVAL»(ref-451166-S40840052852012020700000) . NEXT: Go to next step
CHECK WHETHER DTC OUTPUT RECURS (DTC P2121) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read the DTCs. RESULT Result Proceed to P2121 is output A No DTC is output B B --> END A --> See step 7
GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-451061-S15337112142012020700000)
CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-451061-S02913597072012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Related DTCs	P2195: Air fuel ratio sensor signal stuck lean P2196: Air fuel ratio sensor signal stuck rich
Required Sensors/Components (Main)	Air fuel ratio sensor
Required Sensors/Components (Related)	Heated oxygen sensor
Frequency of Operation	Continuous: Sensor voltage detection monitor Once per driving cycle: Sensor current detection monitor
Duration	20 to 30 seconds: Sensor voltage detection monitor 3 seconds: Sensor current detection monitor
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor runs whenever following DTCs not stored

P0016 (VVT system - Misalignment) P0017 (Exhaust VVT system - Misalignment) P0031, P0032, P101D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0128 (Thermostat) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340 (Camshaft position sensor) P0451, P0452, P0453 (EVAP system) P0500 (Vehicle speed sensor) P0505 (IAC valve) P219A (Air fuel ratio imbalance)

ALL

Time after engine start	30 seconds or more
Fuel system status	Closed loop
Air fuel ratio sensor status	Activated

SENSOR VOLTAGE DETECTION MONITOR

Battery voltage	11 V or higher
Atmospheric pressure	76 kPa (570 mmHg) or higher
Air fuel ratio sensor status	Activated
Continuous time of fuel cut	3 to 10 seconds
Engine coolant temperature	75°C (167°F) or higher

SENSOR CURRENT DETECTION MONITOR

Rear heated oxygen sensor voltage	0.21 V or higher
Air fuel ratio sensor voltage	Higher than 3.8 V

SENSOR VOLTAGE DETECTION MONITOR (LEAN SIDE MALFUNCTION P2195)

Rear heated oxygen sensor voltage	Below 0.59 V
Air fuel ratio sensor voltage	Below 2.8 V

SENSOR VOLTAGE DETECTION MONITOR (RICH SIDE MALFUNCTION P2196)

Air fuel ratio sensor current

2.2 mA or higher

SENSOR CURRENT DETECTION MONITOR (HIGH SIDE MALFUNCTION P2195)

Air fuel ratio sensor current

Below 0.7 mA

SENSOR CURRENT DETECTION MONITOR (RICH SIDE MALFUNCTION P2196)

MONITOR RESULT

Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Monitor ID	Test ID	Scaling	Unit	Description
$01	$91	Multiply by 0.004	MA	A/F sensor current

P2195, P2196: O2 SENSOR / RANGE B1S1

This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" step of the following diagnostic troubleshooting procedure.

Scheme 172

Scheme 172: CONFIRMATION DRIVING PATTERN

Scheme 173

Connect the Techstream to the DLC3.
Turn the ignition switch to ON.
Turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on.
Start the engine and warm it up until the ECT reaches 75°C (167°F) or higher [A].
On the Techstream, enter the following menus to check the fuel-cut status: Powertrain / Engine / Data List / Idle Fuel Cut.
Drive the vehicle at a speed between 60 and 120 km/h (38 and 75 mph) for at least 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
Shift the transmission to 2nd gear [C].
Accelerate the vehicle to 64 km/h (40 mph) or more by depressing the accelerator pedal for at least 10 seconds [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
Soon after performing step [D] above, release the accelerator pedal for at least 4 seconds without depressing the brake pedal in order to execute fuel-cut control [E]. HINT: Fuel-cut is performed when the following conditions are met: Accelerator pedal is fully released. Engine speed is 2800 rpm or more (fuel injection returns at 1000 rpm).
Allow the vehicle to decelerate until the vehicle speed decreases to less than 10 km/h (6 mph).
Repeat steps [C] through [E] above at least 3 times in one driving cycle.
Enter the following menus: Powertrain / Engine / Trouble Codes [F].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P2195 or P2196.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [F] again.
If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 174

Scheme 174: WIRING DIAGRAM

CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO P2195 OR P2196) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to P2195 or P2196 is output A P2195 or P2196 and P0136, P0137 or P0138 are output A P2195 or P2196 and other DTCs are output B HINT: If any DTCs relating to the air fuel ratio sensor (DTCs for the air fuel ratio sensor heater or air fuel ratio sensor admittance) are output, troubleshoot those DTCs first. B --> See step 17 A: Go to next step
CONFIRM IF VEHICLE HAS RUN OUT OF FUEL IN PAST Has the vehicle run out of fuel in the past? NO --> See step 4 YES: Go to next step
PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2195 or P2196 is output) B B --> See step 4 A --> DTC CAUSED BY RUNNING OUT OF FUEL
READ VALUE USING TECHSTREAM (TEST VALUE OF AIR FUEL RATIO SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor / O2 Sensor / Current. Check that the status of O2 Sensor is Complete. If the status is still Incomplete, drive the vehicle according to the driving pattern again. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor / O2 Sensor / Details / RANGE B1 S1. Check the test value of the air fuel ratio sensor output current during fuel-cut. RESULT Test Value Proceed to Within normal range (0.7 mA or higher, and below 2.2 mA) A Outside normal range (below 0.7 mA, or 2.2 mA or higher) B B --> See step 14 A: Go to next step
READ VALUE USING TECHSTREAM (OUTPUT VOLTAGE OF AIR FUEL RATIO SENSOR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the air fuel ratio sensor at an engine speed of 2500 rpm for 90 seconds. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume. Perform the Control the Injection Volume operation with the engine idling. Monitor the output voltages of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12.0% to +12.0%. The injection volume can be changed in fine gradations. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) +12.0% Rich Below 3.1 V AFS Voltage B1S1 (Air fuel ratio) -12.0% Lean Higher than 3.4 V O2S B1S2 (Heated oxygen) +12.0% Rich Higher than 0.55 V O2S B1S2 (Heated oxygen) -12.0% Lean Below 0.4 V RESULT Status of AFS Voltage B1S1 Status of O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Misfire Suspected Trouble Area Proceed to Lean Lean Actual air fuel ratio lean May occur PCV valve and hose PCV hose connections Fuel injector blockage Gas leaks from exhaust system Intake system Fuel pressure Mass air flow meter assembly Engine coolant temperature sensor A Rich Rich Actual air fuel ratio rich - Fuel injector leakage or blockage Gas leaks from exhaust system Ignition system Fuel pressure Mass air flow meter assembly Engine coolant temperature sensor A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Lean/Rich Lean/Rich Normal - - B Lean: During the Control the Injection Volume Active Test, the air fuel ratio sensor output voltage (AFS Voltage) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently below 0.4 V. Rich: During the Control the Injection Volume Active Test, the AFS Voltage is consistently below 3.1 V, and the O2S is consistently higher than 0.55 V. Lean/Rich: During the Control the Injection Volume Active Test, the output voltage of the heated oxygen sensor alternates correctly. HINT: Refer to "Data List / Active Test" [AFS Voltage B1S1 and O2S B1S2]. Refer to «DATA LIST / ACTIVE TEST»(ref-451061-S12130890322012020700000) . B --> See step 14 A: Go to next step
CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-451179-S04241581252012020700000) . OK No leaks in intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-451184-S36711061902012020700000) . NG --> See step 16 OK: Go to next step
INSPECT FUEL INJECTOR ASSEMBLY Check the fuel injector assembly (whether fuel volume is high or low, and whether injector pattern is poor). Refer to «INSPECTION»(ref-451178-S05227766732012020700000) . NG --> See step 18 OK: Go to next step
REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-451166-S28662501142012020700000) . NEXT: Go to next step
PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P2195 or P2196 is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000) . NEXT: Go to next step
CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit NEXT --> END
REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-451166-S28662501142012020700000) . NEXT: Go to next step
PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P2195 or P2196. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2195 or P2196 is output) B B --> See step 19 A --> END
CHECK FUEL LINE Check the fuel lines for leaks or blockage. NG --> REPAIR OR REPLACE FUEL LINE OK --> See step 20
GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-451061-S15337112142012020700000)
REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-451178-S20746300762012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)
REPLACE FUEL PUMP. Refer to «REMOVAL»(ref-451178-S42865735842012020700000)

Related DTCs	P219A: A/F Cylinder Imbalance Monitor
Required Sensors/Components (Main)	Air fuel ratio sensor, Crankshaft position sensor
Required Sensors/Components (Related)	Mass air flow meter assembly, Engine coolant temperature sensor, Vehicle speed sensor
Frequency of Operation	Once per driving cycle
Duration	10 seconds: A/F sensor monitoring method 30 seconds: Crankshaft position sensor monitoring method
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor runs whenever following DTCs not stored

P0010 (VVT oil control valve) P0011 (VVT system - Advance) P0012 (VVT system - Retard) P0013 (Exhaust VVT oil control valve) P0014 (Exhaust VVT system - Advance) P0015 (Exhaust VVT system - Retard) P0016 (VVT system - Misalignment) P0017 (Exhaust VVT system - Misalignment) P0031, P0032, P101D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0327, P0328 (Knock sensor) P0335 (Crankshaft position sensor) P0340 (Camshaft position sensor) P0340, P0342, P0343 (VVT sensor) P0351 - P0354 (Igniter) P0365, P0367, P0368 (Exhaust VVT sensor) P0500 (Vehicle speed sensor)

ALL

A/F sensor status	Activated
Engine speed	1600 to 2400 rpm
Engine coolant temperature	75°C (167°F) or higher
Mass air flow	20 to 40 g/sec.
Fuel system status	Closed loop
Atmospheric pressure	76 kPa (570 mmHg) or higher

A/F SENSOR MONITORING METHOD

Vehicle speed	Less than 3 km/h (1.875 mph)
Engine speed	450 to 1500 rpm
Engine coolant temperature	75°C (167°F) or higher
A/F sensor status	Activated
Battery voltage	11 V or higher
Fuel system status	Closed loop

CRANKSHAFT POSITION SENSOR MONITORING METHOD

A/F sensor monitoring method criteria

0.036926 or more

A/F SENSOR MONITORING METHOD

Crankshaft position sensor monitoring method criteria

1.0 or more

CRANKSHAFT POSITION SENSOR MONITORING METHOD

Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Monitor ID	Test ID	Scaling	Unit	Description
$81	$81	Multiply by 0.00003	No dimension	Monitoring method using A/F sensor

P219A: FUEL SYSTEM / A/F SENSOR DETERMINATION B1

Monitor ID	Test ID	Scaling	Unit	Description
$81	$82	Multiply by 0.001	No dimension	Monitoring method using crank angle sensor

P219A: FUEL SYSTEM / ENGINE SPEED FLUCTUATION AVERAGE B1

Scheme 175

Scheme 175: CONFIRMATION DRIVING PATTERN

Connect the Techstream to the DLC3.
Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [A]. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N.
Turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Drive the vehicle at 60 km/h (37 mph) or higher for 2 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: It is acceptable to turn electrical loads on while driving.
Idle the engine for 2 minutes or more [C]. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N.
Enter the following menus: Powertrain / Engine / Trouble Codes [D].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Drive the vehicle at less than 30 km/h (19 mph) for 5 seconds or more [E].
Accelerate the vehicle from 30 to 60 km/h (19 to 38 mph) over a period of approximately 10 to 20 seconds. HINT: Refer to the values of mass air flow and engine speed in Typical Enabling Conditions before accelerating the vehicle from 30 to 60 km/h (19 to 38 mph).
Drive the vehicle at 60 km/h (37 mph) or more for 5 seconds or more [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
Drive the vehicle at less than 30 km/h (19 mph) for 5 seconds or more [G].
Accelerate the vehicle from 30 to 60 km/h (19 to 38 mph) over a period of approximately 10 to 20 seconds. HINT: Refer to the values of mass air flow and engine speed in Typical Enabling Conditions before accelerating the vehicle from 30 to 60 km/h (19 to 38 mph).
Drive the vehicle at 60 km/h (37 mph) or more for 5 seconds or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
Repeat steps [G] through [H] above at least 2 times [I].
Idle the engine for 1 minute or more [J]. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N.
Enter the following menus: Powertrain / Engine / Trouble Codes [K].
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P219A.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform the following procedure.
If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P219A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to Only P219A is output A P219A and other DTCs are output B HINT: If any DTCs other than P219A are output, troubleshoot those DTCs first. B --> See step 17 A: Go to next step
READ VALUE USING TECHSTREAM (FREEZE FRAME DATA) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA»(ref-451061-S23860434312012020700000) . Freeze Frame Data Items for DTC P219A Vehicle Speed Engine Speed Calculate Load Accelerator Idle Position Short FT #1 Long FT #1 Cylinder #1 Misfire Count to Cylinder #4 Misfire Count A/F Sensor Determination (worst value) #1 Engine Speed Fluctuation Avg (worst value) #1 to #4 HINT: When the sum of Short FT and Long FT is positive, the engine is running lean, and when the sum is negative, the engine is running rich. DTC stored during idling It is possible to conclude that the problem was detected due to a "lean imbalance" (detected using crankshaft speed variation). DTC stored while vehicle being driven It is possible to conclude that the problem was detected due to a "rich imbalance" (detected using the air fuel ratio sensor). NEXT: Go to next step
READ VALUE USING TECHSTREAM (MONITOR RESULT) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. HINT: If any misfire count ("Cylinder #1 Misfire Count" to "Cylinder #4 Misfire Count) increases while idling or driving the vehicle, proceed to step 6. Perform inspections while focusing on the cylinder whose misfire count has increased. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor / Fuel System / Details / A/F SENSOR DETERMINATION B1 and ENGINE SPEED FLUCTUATION AVERAGE B1. Check the Test Result (A/F SENSOR DETERMINATION B1 and ENGINE SPEED FLUCTUATION AVERAGE B1). RESULT Result Proceed to A/F SENSOR DETERMINATION is Fail A A/F SENSOR DETERMINATION and ENGINE SPEED FLUCTUATION AVERAGE are Fail B ENGINE SPEED FLUCTUATION AVERAGE is Fail B* HINT: When the results of A/F SENSOR DETERMINATION and ENGINE SPEED FLUCTUATION AVERAGE are both Pass, drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern again. If both results are still Pass, proceed to step 4. Perform inspections while focusing on the cylinder whose engine speed fluctuation value ("Engine Speed Fluctuation Avg (worst value) #1" to "Engine Speed Fluctuation Avg (worst value) #4") was the largest. B --> See step 6 A: Go to next step
PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P or N. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume / Data List / Cylinder #1 to #4 Misfire Count. HINT: When the "Control the Injection Volume" Active Test is selected (injection volume is 0%), if a misfire count increases, proceed to step 6 (Check Air Induction System). Perform the Control the Injection Volume operation with the engine idling. Check the misfire counts ("Cylinder #1 Misfire Count" to "Cylinder #4 Misfire Count") while decreasing the injection volume in 5% increments. NOTE: Do not decrease the injection volume by more than 20%. Result The cylinder whose misfire count has not increased can be assumed to be running rich. Therefore, perform inspections while focusing on that cylinder. NEXT: Go to next step
CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leakage. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-451179-S04241581252012020700000) . OK No leakage in air induction system. NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
INSPECT SPARK PLUG Inspect the spark plug of the cylinder causing the imbalance. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-451177-S21303759642012020700000) . NG --> See step 18 OK: Go to next step
CHECK FOR SPARKS AND IGNITION Perform a spark test. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-451177-S21303759642012020700000) . WARNING: Always disconnect all injector connectors. NOTE: Do not crank the engine for more than 2 seconds. OK Sparks jump across electrode gap. NG --> See step 15 OK: Go to next step
CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder. Refer to «ON-VEHICLE INSPECTION - Step 4»(ref-451161-S38605424312012020700000) . NG --> CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION OK: Go to next step
CHECK FUEL INJECTOR ASSEMBLY (POWER SOURCE) See step 1 NG --> See step 19 OK: Go to next step
CHECK HARNESS AND CONNECTOR (FUEL INJECTOR - ECM) See step 3 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
CHECK FUEL INJECTOR ASSEMBLY OF CYLINDER CAUSING IMBALANCE Check the fuel injector injection [whether fuel volume is high or low, and whether injection pattern is poor]. Refer to «INSPECTION»(ref-451178-S05227766732012020700000) . NG --> See step 20 OK: Go to next step
CHECK FOR CAUSE OF FAILURE If the cause of the problem has not been found even after performing the troubleshooting procedure, perform the inspection below. Check the intake valve for deposits. HINT: As the DTC may have been stored due to deposits on the intake valve, remove the cylinder head and check the intake valve. NEXT: Go to next step
CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Check for DTCs. Result P219A is not output. NEXT --> END
CHANGE TO NORMAL SPARK PLUG AND CHECK SPARK OF CYLINDER CAUSING IMBALANCE Change the installed spark plug to a spark plug that functions normally. Perform a spark test. WARNING: Always disconnect all injector connectors. NOTE: Do not crank the engine for more than 2 seconds. Install the spark plug to the ignition coil and connect the ignition coil connector. Disconnect the injector connectors. Ground the spark plug. Check if sparks occur while the engine is being cranked. OK Sparks jump across electrode gap. NG --> See step 16 OK --> See step 22
CHANGE TO NORMAL IGNITION COIL ASSEMBLY AND CHECK SPARK OF CYLINDER CAUSING IMBALANCE Change the ignition coil assembly to an ignition coil assembly that functions normally. Perform a spark test. WARNING: Always disconnect all fuel injector connectors. NOTE: Do not crank the engine for more than 2 seconds. Install the spark plug to the ignition coil and connect the ignition coil connector. Disconnect the fuel injector connectors. Ground the spark plug. Check if sparks occur while the engine is being cranked. OK Sparks jump across electrode gap. NG --> See step 21 OK --> See step 23
GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-451061-S15337112142012020700000)
REPLACE SPARK PLUG. Refer to «REMOVAL»(ref-451166-S42926346012012020700000)
GO TO FUEL INJECTOR CIRCUIT. Refer to «Fuel Injector Circuit»(ref-451172-S00209579932012020700000)
REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-451178-S20746300762012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)
REPLACE SPARK PLUG. Refer to «REMOVAL»(ref-451166-S42926346012012020700000)
REPLACE IGNITION COIL ASSEMBLY. Refer to «REMOVAL»(ref-451166-S42926346012012020700000)

Related DTCs	P2237: Air fuel ratio sensor open circuit between AF+ and AF- P2238: Air fuel ratio sensor short circuit between AF+ and AF- P2238: Air fuel ratio sensor short circuit between AF+ and GND P2238: Air fuel ratio sensor low impedance P2239: Air fuel ratio sensor short circuit between AF+ and +B P2252: Air fuel ratio sensor short circuit between AF- and GND P2253: Air fuel ratio sensor short circuit between AF- and +B
Required Sensors/Components (Main)	Air fuel ratio sensor
Required Sensors/Components (Related)	Engine coolant temperature sensor, Crankshaft position sensor
Frequency of Operation	Continuous
Duration	10 seconds: Air fuel ratio sensor open circuit between AF+ and AF- and low impedance 5 seconds: Other
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor runs whenever following DTCs not stored

P0016 (VVT system - Misalignment) P0017 (Exhaust VVT system - Misalignment) P0031, P0032, P101D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0128 (Thermostat) P0171, P0172 (Fuel system) P0301 - P0304 (Misfire) P0335 (Crankshaft position sensor) P0340 (Camshaft position sensor) P0451, P0452. P0453 (EVAP system) P0500 (Vehicle speed sensor) P0505 (IAC valve) P219A (Air fuel ratio imbalance)

P2237 AND P2238

Monitor runs whenever following DTCs not stored

None

P2239, P2252 AND P2253

Battery voltage	11 V or higher
Engine	Running
Estimated sensor temperature	450 to 550°C (842 to 1022°F) for P2237 and P2240

AIR FUEL RATIO SENSOR - OPEN CIRCUIT BETWEEN AF+ AND AF

Engine coolant temperature	10°C (50°F) or higher
Estimated sensor temperature	700 to 800°C (1292 to 1472°F) for P2238 and P2241
Fuel cut	Not executed

AIR FUEL RATIO SENSOR - LOW IMPEDANCE

Battery voltage	11 V or higher
Ignition switch	ON
Timing after ignition switch off to ON	5 seconds or more

OTHER

Air fuel ratio sensor admittance

Below 0.002 1/ohms

P2237

When one of following conditions is met	Condition 1, 2 or 3
1. Air fuel ratio sensor admittance	Below 0.0074 1/ohms
2. AF+ voltage	0.5 V or less
3. Difference of AF+ and AF- voltage	0.1 V or less

P2238

AF+ voltage

Higher than 4.5 V

P2239

AF- voltage

0.5 V or less

P2252

AF- voltage

Higher than 4.5 V

P2253

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on.
Start the engine and wait 5 minutes.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P2237, P2238, P2239, P2252 or P2253.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 5 minutes and check the DTC judgment result again.
If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B17-1 (HA1A) - B30-18 (HA1A) Always Below 1 ohms B17-3 (A1A+) - B30-103 (A1A+) Always Below 1 ohms B17-4 (A1A-) - B30-126 (A1A-) Always Below 1 ohms B17-1 (HA1A) or B30-18 (HA1A) - Body ground Always 10 kohms or higher B17-3 (A1A+) or B30-103 (A1A+) - Body ground Always 10 kohms or higher B17-4 (A1A-) or B30-126 (A1A-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-451166-S28662501142012020700000) . NEXT: Go to next step
CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Start the engine. Allow the engine to idle for 5 minutes or more. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. RESULT Result Proceed to No DTC is output A P2237, P2238, P2239, P2252 or P2253 is output B B --> See step 4 A --> END
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)

Required Sensors/Components	Purge VSV and canister pump module
Frequency of Operation	Once per driving cycle
Duration	Within 3 minutes (varies with amount of fuel in tank)
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor runs whenever following DTCs not stored	P0452, P0453 (EVAP system)
EVAP key-off monitor runs when all of following conditions met
Atmospheric pressure	70 to 110 kPa-a (525 to 825 mmHg-a)
Battery voltage	10.5 V or higher
Vehicle speed	Less than 4 km/h (2.5 mph)
Ignition switch	Off
Time after key off	5, 7 or 9.5 hours
Purge VSV	Not operated by scan tool
Vent valve	Not operated by scan tool
Leak detection pump	Not operated by scan tool
Both of following conditions met before key off	Conditions 1 and 2
1. Duration that vehicle driven	5 minutes or more
2. EVAP purge operation	Performed
Engine coolant temperature	4.4 to 35°C (40 to 95°F)
Intake air temperature	4.4 to 35°C (40 to 95°F)

EVAP pressure change after EVAP canister vent valve ON

Less than 0.3 kPa-g (2.25 mmHg-g)

Refer to EVAP System. Refer to MONITOR RESULT .

Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 23 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on.
Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
After "Evaporative System Check" is completed, check All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P2420.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Required Sensors/Components	ECM
Frequency of Operation	Once per driving cycle
Duration	10 minutes: Timer malfunction Within 9.5 hours: Timer start-up malfunction
MIL Operation	2 driving cycles
Sequence of Operation	None

Monitor runs whenever following DTC not stored	None
Ignition switch	ON
Engine	Running
Battery voltage	8 V or higher
Starter	OFF

TIMER MALFUNCTION

Monitor runs whenever following DTC not stored	None
Elapsed time from engine stop	Less than 1800 seconds
Ignition switch	ON
Battery voltage	8 V or higher
Starter	OFF

TIMER START-UP MALFUNCTION (CASE 1)

Monitor runs whenever following DTC not stored	None
Elapsed time from engine stop	2400 seconds or more
Ignition switch	ON
Battery voltage	8 V or higher
Starter	OFF

TIMER START-UP MALFUNCTION (CASE 2)

Soak timer measurement when ECM CPU clock counts 10 minutes

Less than 7 minutes, or more than 13 minutes

TIMER MALFUNCTION

ECM has a record of being started by soak timer

Yes

TIMER START-UP MALFUNCTION (CASE 1)

ECM has a record of being started by soak timer

TIMER START-UP MALFUNCTION (CASE 2)

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on.
Start the engine.
Idle the engine for 10 minutes or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: P2610.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000) . NEXT: Go to next step
CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Start the engine and wait for 10 minutes or more. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. If no pending DTC is output, the repair has been successfully completed. NEXT --> END

Related DTCs	U0101: Verify communication
Required Sensors/Components (Main)	ECM
Required Sensors/Components (Related)
Frequency of Operation	Continuous
Duration	1.25 seconds
MIL Operation	Immediate
Sequence of Operation	None

Monitor runs whenever following DTCs are not stored	None
Battery Voltage	10.5 V or higher (0.5 seconds or more)
Ignition switch	ON
Starter	OFF

Communication signal

Lost communication with TCM

Connect the Techstream to the DLC3.
Turn the ignition switch to ON and turn the Techstream on.
Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) .
Turn the ignition switch off and wait for at least 30 seconds.
Turn the ignition switch to ON and turn the Techstream on.
Wait 5 seconds or more.
Enter the following menus: Powertrain / Engine / Trouble Codes.
Read the DTCs. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
Enter the following menus: Powertrain / Engine / Utility / All Readiness.
Input the DTC: U0101.
Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
If the judgment result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 176

Scheme 176: WIRING DIAGRAM

Scheme 177

Scheme 177: PROCEDURE

CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC U0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to U0101 is output A U0101 and other DTCs are output B HINT: If any DTCs other than U0101 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
INSPECT TCM (POWER SOURCE) Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B31-8 (E1) - Body ground Always Below 1 ohms Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B31-18 (+B) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) NG --> See step 7 OK: Go to next step
CHECK HARNESS AND CONNECTOR (ECM - TCM) Disconnect the ECM connector. Disconnect the TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B31-7 (CAN-) - B30-1 (CAN-) Always Below 1 ohms B31-6 (CAN+) - B30-24 (CAN+) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B31-7 (CAN-) or B30-1 (CAN-) - Body ground Always 10 kohms or higher B31-6 (CAN+) - B30-24 (CAN+) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000) . NEXT: Go to next step
CHECK WHETHER DTC OUTPUT RECURS (DTC U0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read the DTCs. RESULT Result Proceed to No DTC is output A U0101 is output B B --> See step 8 A --> END
GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-451061-S15337112142012020700000)
GO TO TCM POWER SOURCE CIRCUIT. Refer to «ECU Power Source Circuit»(ref-451187-S07699278022012020700000)
REPLACE TCM. Refer to «REMOVAL»(ref-451170-S32416003882012020700000)

RELATED DTCS

DTC No.	Monitoring Item	Refer To
P043E	Reference orifice (built into canister pump module) clogged	Refer to DTC P043E: Evaporative Emission System Leak Detection Reference Orifice Low Flow; DTC P043F: Evaporative Emission System Reference Orifice High Flow; DTC P2401: Evaporative Emission Leak Detection Pump Stuck OFF; DTC P2402: Evaporative Emission Leak Detection Pump Stuck ON; DTC P2419: Evaporative Emission System Switching Valve Control Circuit Low
P043F	Reference orifice (built into canister pump module) high flow
P0441	Purge VSV (Vacuum Switching Valve) stuck closed Purge VSV stuck open Purge flow	Refer to DTC P0441: Evaporative Emission Control System Incorrect Purge Flow
P0451	Canister pressure sensor (built into canister pump module) noise Canister pressure sensor (built into canister pump module) signal becomes fixed/flat	Refer to DTC P0451: Evaporative Emission Control System Pressure Sensor Range / Performance; DTC P0452: Evaporative Emission Control System Pressure Sensor / Switch Low Input; DTC P0453: Evaporative Emission Control System Pressure Sensor / Switch High Input
P0452	Canister pressure sensor (built into canister pump module) voltage low
P0453	Canister pressure sensor (built into canister pump module) voltage high
P0455	EVAP gross leak	Refer to DTC P0455: Evaporative Emission Control System Leak Detected (Gross Leak); DTC P0456: Evaporative Emission Control System Leak Detected (Very Small Leak)
P0456	EVAP small leak
P2401	Leak detection pump (built into canister pump module) stuck OFF	Refer to DTC P043E: Evaporative Emission System Leak Detection Reference Orifice Low Flow; DTC P043F: Evaporative Emission System Reference Orifice High Flow; DTC P2401: Evaporative Emission Leak Detection Pump Stuck OFF; DTC P2402: Evaporative Emission Leak Detection Pump Stuck ON; DTC P2419: Evaporative Emission System Switching Valve Control Circuit Low
P2402	Leak detection pump (built into canister pump module) stuck ON
P2419	Vent valve (built into canister pump module) stuck closed	Refer to DTC P043E: Evaporative Emission System Leak Detection Reference Orifice Low Flow; DTC P043F: Evaporative Emission System Reference Orifice High Flow; DTC P2401: Evaporative Emission Leak Detection Pump Stuck OFF; DTC P2402: Evaporative Emission Leak Detection Pump Stuck ON; DTC P2419: Evaporative Emission System Switching Valve Control Circuit Low
P2420	Vent valve (built into canister pump module) stuck open (vent)	Refer to DTC P2420: Evaporative Emission System Switching Valve Control Circuit High
P2610	Soak timer (built into ECM)	Refer to DTC P2610: ECM / PCM Internal Engine Off Timer Performance

If any EVAP system DTCs are output, the malfunctioning area can be determined using the table below.

Scheme 178

Note. If the reference pressure difference between the first and second checks is more than the specification, all the DTCs relating to the reference pressure (P043E, P043F, P2401, P2402 and P2419) are stored.

Scheme 179

Scheme 179: DESCRIPTION

*1	Purge VSV	*2	EVAP Hose (to Intake Manifold)
*3	EVAP Hose (from Canister)	*4	Purge Line
*5	Fuel Tank	*6	Canister
*7	Canister Pump Module - Canister Pressure Sensor - Leak Detection Pump - Vent Valve	*8	Air Filter
*9	Air Inlet Port	*10	Fuel Tank Cap Assembly
*a	Location of EVAP (Evaporative Emission) System

Scheme 180

*1	Canister Pump Module	*2	Intake Manifold
*3	Purge VSV	*4	Throttle Valve
*5	Canister	*6	Cut-off Valve
*7	Fuel Tank	*8	Air Cleaner
*9	ECM	*10	Canister Filter
*11	Soak Timer	*12	Roll-over Valve
*13	Fuel Tank Cap Assembly
*a	EVAP System Circuit

TEXT IN ILLUSTRATION

Note. In this vehicle's EVAP system, turning ON the vent valve does not seal off the EVAP system. To check for leaks in the EVAP system, disconnect the air inlet vent hose and apply pressure from the side of the canister exposed to the atmosphere.

While the engine is running, if a predetermined condition (closed loop, etc.) is met, the purge VSV is opened by the ECM and stored fuel vapors in the canister are purged into the intake manifold. The ECM changes the duty cycle ratio of the purge VSV to control purge flow volume.

The purge flow volume is also determined by the intake manifold pressure. Air at atmospheric pressure is allowed into the canister through the vent valve to ensure that the purge flow is maintained when negative pressure (vacuum) is applied to the canister.

The following two monitors run to confirm appropriate EVAP system operation.

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Key-off monitor This monitor checks for EVAP (Evaporative Emission) system leaks and canister pump module malfunctions. The monitor starts 5 hours* after the ignition switch is turned off. At least 5 hours are required for the fuel to cool down which stabilizes the EVAP pressure, thus making the EVAP system monitor more accurate. The leak detection pump creates negative pressure (vacuum) in the EVAP system and the pressure is measured. Finally, the ECM monitors for leaks from the EVAP system, and malfunctions in both the canister pump module and purge VSV based on the EVAP pressure. HINT: *: If the engine coolant temperature is not below 35°C (95°F) 5 hours after the ignition switch is turned off, the monitor check starts 2 hours later. If it is still not below 35°C (95°F) 7 hours after the ignition switch is turned off, the monitor check starts 2.5 hours later.
Purge flow monitor The purge flow monitor consists of 2 monitors. The 1st monitor is conducted every time and the 2nd monitor is activated if necessary. The 1st monitor While the engine is running and the purge VSV (Vacuum Switching Valve) is ON (open), the ECM monitors the purge flow by measuring the EVAP pressure change. If negative pressure is not created, the ECM begins the 2nd monitor. The 2nd monitor The vent valve is turned ON (closed) and the EVAP pressure is measured. If the variation in the pressure is less than 0.15 kPa-g (1.12 mmHg-g), the ECM interprets this as the purge VSV being stuck closed, illuminates the MIL and stores DTC P0441 (2 trip detection logic). Atmospheric pressure check: In order to ensure reliable malfunction detection, the variation between the atmospheric pressure before and after conduction of the purge flow monitor is measured by the ECM. TEXT IN ILLUSTRATION *1 Canister *2 to Intake Manifold *3 ECM *4 Soak Timer *5 Purge VSV (On) *6 Fuel Tank Cap Assembly *7 Canister Filter *8 Fuel Tank *9 Leak Detection Pump (Off) *10 Canister Pressure Sensor *11 Reference Orifice (0.02 Inches) *12 Vent Valve (Off) *13 Canister Pump Module - - *a EVAP Purge Flow - - Component Operation Canister Contains activated charcoal to absorb EVAP (Evaporative Emissions) generated in fuel tank. Cut-off valve Located in fuel tank. Valve floats and closes when fuel tank 100% full. Purge VSV (Vacuum Switching Valve) Opens or closes line between canister and intake manifold. ECM uses purge VSV to control EVAP purge flow. In order to discharge EVAP absorbed by canister to intake manifold, ECM opens purge VSV. EVAP discharge volume to intake manifold controlled by purge VSV duty cycle ratio (current flow time) (Open: ON; Closed: OFF). Roll-over valve Located in fuel tank. Valve closed by its own weight when vehicle overturns to prevent fuel from spilling out. Soak timer Built into ECM. To ensure accurate EVAP monitor, measures 5 hours (+/-15 min) after ignition switch turned off. This allows fuel to cool down, stabilizing EVAP pressure. When approximately 5 hours have elapsed, ECM activates see scheme 3 Canister pump module Consists of (a) to (d) below. Canister pump module cannot be disassembled. (a) Vent valve Vents and closes EVAP system. When ECM turns valve ON, EVAP system closed. When ECM turns valve OFF, EVAP system vented. Negative pressure (vacuum) created in EVAP system to check for EVAP leaks by closing purge VSV, turning on vent valve (closed) and operating leak detection pump see scheme 1 (b) Canister pressure sensor Indicates pressure as voltages. ECM supplies regulated 5 V to canister pressure sensor and uses feedback from sensor to monitor EVAP system pressure see scheme 2 (c) Leak detection pump Creates negative pressure (vacuum) in EVAP system for leak check. (d) Reference orifice Opening with 0.02-inch diameter. Vacuum produced through orifice by closing purge VSV, turning off vent valve and operating leak detection pump to monitor reference pressure. Reference pressure used to detect small leak of EVAP. TEXT IN ILLUSTRATION *1 Airflow *2 Leak Detection Pump: Off *3 Condition: Purge Flow *4 Condition: Leak Check *5 Vent Valve: Off (Vent) *6 to Canister Filter (Atmosphere) *7 Canister *8 Reference Orifice (0.02 Inches) *9 Canister Pressure Sensor *10 Leak Detection Pump: On *11 Vent Valve: On (Closed) - - *a Canister Pump Module see scheme 1

Scheme 185

Scheme 185: WIRING DIAGRAM

HINT

After a repair, check Monitor Status by performing the Key-off Monitor Confirmation and Purge Flow Monitor Confirmation described below.

KEY-OFF MONITOR CONFIRMATION Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway) The fuel tank is less than 90% full The elevation is less than 2438 m (8000 ft.) The engine coolant temperature is between 4.4°C and 35°C (40°F and 95°F) The intake air temperature is between 4.4°C and 35°C (40°F and 95°F) The vehicle remains stationary (the vehicle speed is 0 km/h [0 mph]) Monitor Conditions Allow the engine to idle for at least 5 minutes. Turn the ignition switch off and wait for 6 hours (or 8 or 10.5 hours). HINT: Do not start the engine until checking Monitor Status. If the engine is started, the steps described above must be repeated. Monitor Status Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor / Evaporative System. Check Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor is not complete. Make sure that the preconditions have been met, and then perform the operations listed under Monitor Conditions again.
PURGE FLOW MONITOR CONFIRMATION (P0441) HINT: Perform this monitor confirmation after the Key-off Monitor Confirmation shows Complete. Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway) The engine coolant temperature is between 4.4 and 35°C (40 and 95°F) The intake air temperature is between 4.4 and 35°C (40 and 95°F) Monitor Conditions Release the pressure from the fuel tank by removing and reinstalling the fuel cap. Warm the engine up until the engine coolant temperature reaches a temperature higher than 75°C (167°F). Increase the engine speed to 3000 rpm once. Allow the engine to idle and turn the A/C on for 1 minute. Monitor Status Turn the ignition switch off (if ON or if the engine is running). Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor. Check Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor is not complete. Make sure that the preconditions have been met, and then perform the operations listed under Monitor Conditions again.

Refer to detailed information in Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Monitor ID	Test ID	Scaling	Unit	Description
$3D	$C9	Multiply by 0.001	KPa	Test value for small leak

P0456: EVAPORATIVE SYSTEM / SMALL LEAK

Monitor ID	Test ID	Scaling	Unit	Description
$3D	$CA	Multiply by 0.001	KPa	Test value for gross leak

P0455: EVAPORATIVE SYSTEM / GROSS LEAK

Monitor ID	Test ID	Scaling	Unit	Description
$3D	$CB	Multiply by 0.001	KPa	Test value for leak detection pump stuck OFF

P2401: EVAPORATIVE SYSTEM / VACUUM PMP OFF

Monitor ID	Test ID	Scaling	Unit	Description
$3D	$CD	Multiply by 0.001	KPa	Test value for leak detection pump stuck ON

P2402: EVAPORATIVE SYSTEM / VACUUM PMP ON

Monitor ID	Test ID	Scaling	Unit	Description
$3D	$CE	Multiply by 0.001	KPa	Test value for vent valve stuck OFF

P2420: EVAPORATIVE SYSTEM / VENT VALVE OFF

Monitor ID	Test ID	Scaling	Unit	Description
$3D	$CF	Multiply by 0.001	KPa	Test value for vent valve stuck ON

P2419: EVAPORATIVE SYSTEM / VENT VALVE ON

Monitor ID	Test ID	Scaling	Unit	Description
$3D	$D0	Multiply by 0.001	KPa	Test value for reference orifice low flow

P043E: EVAPORATIVE SYSTEM / ORIFICE CLOGGED

Monitor ID	Test ID	Scaling	Unit	Description
$3D	$D1	Multiply by 0.001	KPa	Test value for reference orifice high flow

P043F: EVAPORATIVE SYSTEM / ORIFICE HI-FLW

Monitor ID	Test ID	Scaling	Unit	Description
$3D	$D4	Multiply by 0.001	KPa	Test value for purge VSV stuck closed

P0441: EVAPORATIVE SYSTEM / PURGE VSV CLOSED

Monitor ID	Test ID	Scaling	Unit	Description
$3D	$D5	Multiply by 0.001	KPa	Test value for purge VSV stuck open

P0441: EVAPORATIVE SYSTEM / PURGE VSV OPENED

Monitor ID	Test ID	Scaling	Unit	Description
$3D	$D7	Multiply by 0.001	KPa	Test value for purge flow insufficient

P0441: EVAPORATIVE SYSTEM / PURGE FLOW

CHECK DTC OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: System Select / Health Check. Check DTCs. RESULT Result Proceed to No DTC is output A DTC is output B B --> GO TO DTC CHART A: Go to next step
READ VALUE USING TECHSTREAM (STOP LIGHT SWITCH AND ST1) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Stop Light Switch and ST1. Check the Data List indication when the brake pedal is depressed and released. OK Techstream Display Condition Specified Condition Stop Light Switch Brake pedal released OFF Brake pedal depressed ON ST1 Brake pedal released OFF Brake pedal depressed ON NG --> See step 10 OK: Go to next step
INSPECT BRAKE PEDAL Inspect and adjust the brake pedal. Refer to «ADJUSTMENT»(ref-451188-S40929547402012020700000) . HINT: If the stop light switch turns on too late, the start of brake override system control may be delayed; if it turns on too soon, brake override system control may begin too early. Therefore, it is necessary to conduct inspection of the brake pedal and stop light switch assembly. NG --> See step 9 OK: Go to next step
READ VALUE USING TECHSTREAM (ACCELERATOR PEDAL POSITION SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Accel Sens. No. 1 Volt % and Accel Sens. No. 2 Volt %. Read the value displayed on the Techstream. OK Techstream Display Condition Specified Condition Accel Sens. No. 1 Volt % Accelerator Pedal Released --> Depressed --> Released Values smoothly change following accelerator pedal operation Accel Sens. No. 2 Volt % HINT: For numerical values of Accel Sens. No. 1 Volt % and Accel Sens. No. 2 Volt %, refer to the Data List. Refer to «DATA LIST / ACTIVE TEST»(ref-451061-S12130890322012020700000) . NG --> See step 8 OK: Go to next step
READ VALUE USING TECHSTREAM (VEHICLE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Start the engine. Enter the following menus: Powertrain / Engine / Data List / Vehicle Speed. Read the value displayed on the Techstream. Standard Techstream Display Condition Specified Condition Vehicle Speed Vehicle stopped, engine running 0 km/h (0 mph) Vehicle driven at constant speed between 16.1 and 64.4 km/h (10 and 40 mph) No large fluctuations when driving at a constant speed WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Confirm the data after performing the driving test. NG --> See step 7 OK: Go to next step
READ VALUE USING TECHSTREAM (FR, FL, RR, RL WHEEL SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Start the engine. Enter the following menus: Chassis / ABS/VSC/TRAC / Data List / FR Wheel Speed, FL Wheel Speed, RR Wheel Speed and RL Wheel Speed. Read the value displayed on the Techstream. Standard Techstream Display Condition Specified Condition FR Wheel Speed FL Wheel Speed RR Wheel Speed RL Wheel Speed Vehicle stopped, engine running 0 km/h (0 mph) Vehicle driven at constant speed between 16.1 and 64.4 km/h (10 and 40 mph) No large fluctuations when driving at a constant speed WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Confirm the data after performing the driving test. NG --> INSPECT FRONT OR REAR SPEED SENSOR OK --> END
GO TO METER / GAUGE SYSTEM (SPEED SIGNAL CIRCUIT). Refer to «Speed Signal Circuit»(ref-451185-S18478867742012020700000)
REPLACE ACCELERATOR PEDAL POSITION SENSOR ASSEMBLY. Refer to «REMOVAL»(ref-451166-S40840052852012020700000)
REPAIR OR REPLACE BRAKE PEDAL. Refer to «REMOVAL»(ref-451188-S42639929802012020700000)
INSPECT STOP LIGHT SWITCH ASSEMBLY. Refer to «INSPECTION»(ref-451186-S31823982232012020700000)

CHECK THAT MIL IS ILLUMINATED Perform troubleshooting in accordance with the table below. RESULT Result Proceed to MIL remains on A MIL does not illuminate B B --> See step 5 A: Go to next step
CHECK WHETHER MIL TURNS OFF Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Check if any DTCs have been stored. Note down any DTCs. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-451061-S23674878372012020700000) . Check if the MIL goes off. OK MIL goes off. NG --> See step 3 OK --> See step 8
CHECK HARNESS AND CONNECTOR (CHECK FOR SHORT IN WIRE HARNESS) Disconnect the ECM connector. Turn the ignition switch to ON. Check that the MIL is not illuminated. OK MIL is not illuminated. NG --> See step 4 OK --> See step 9
CHECK HARNESS AND CONNECTOR (COMBINATION METER - ECM) Disconnect the ECM connector. Disconnect the combination meter connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A35-36 (W) or C50-20 (CHK) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 10
CHECK THAT MIL IS ILLUMINATED Check if the MIL is illuminated when the ignition switch is turned to ON. OK MIL is illuminated. NG --> See step 6 OK --> END
CHECK THAT ENGINE STARTS Turn the ignition switch to ON. Start the engine. RESULT Result Proceed to Engine starts A Engine does not start* B HINT: *: The Techstream cannot communicate with the ECM. B --> See step 11 A: Go to next step
CHECK HARNESS AND CONNECTOR (COMBINATION METER - ECM) Disconnect the ECM connector. Disconnect the combination meter connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A35-36 (W) - C50-20 (CHK) Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 12
REPAIR CIRCUITS INDICATED BY OUTPUT DTCS. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-451061-S15337112142012020700000)
REPLACE ECM. Refer to «REMOVAL»(ref-451166-S22630148492012020700000)
REPLACE COMBINATION METER ASSEMBLY. Refer to «REMOVAL»(ref-451189-S19812075632012020700000)
GO TO VC OUTPUT CIRCUIT. Refer to «VC Output Circuit»(ref-451172-S08987395552012020700000)
REPLACE COMBINATION METER ASSEMBLY. Refer to «REMOVAL»(ref-451189-S19812075632012020700000)

Engine Control System (Diagnostic Codes (P0504-U0101) & Circuit Tests)): Other Scion tC II

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

TYPICAL MALFUNCTION THRESHOLDS

Scheme 152

PROCEDURE

CONFIRMATION DRIVING PATTERN

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

COMPONENT OPERATING RANGE

Scheme 159

Scheme 160

Scheme 161

Scheme 162

Scheme 163

FAIL-SAFE

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

MONITOR RESULT

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

RELATED DTCS

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

More articles — Engine Control System (Diagnostic Codes (P0504-U0101) & Circuit Tests))

Login / Signup

Enter the code

You have successfully logged in!
