MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

ALL

P0604, P0605

P0606 (INSTRUCTION CHECK) (CASE 1)

P0606 (INSTRUCTION CHECK) (CASE 2)

P0606 (SOFTWARE MONITOR CHECK)

P060A (DISABLE FUNCTION OF OBSERVATION IC)

P060A (MALFUNCTION OF OBSERVATION IC CALCULATION)

P060A (OBSERVATION IC RESISTER MONITORING)

P060B

TYPICAL MALFUNCTION THRESHOLDS

P0604

P0605

P0606 (INSTRUCTION CHECK) (CASE 1)

P0606 (INSTRUCTION CHECK) (CASE 2)

P0606 (SOFTWARE FLOW CHECK)

P0606 (SOFTWARE MONITOR CHECK)

P0606 (OUTPUT DRIVER COMMUNICATION CHECK)

P0606 (CAN RESISTER CHECK)

P060A (DISABLE FUNCTION OBSERVATION IC)

P060A (MALFUNCTION OF OBSERVATION IC CALCULATION)

P060A (OBSERVATION IC RESISTER MONITORING)

P060B

P062F (OBSERVATION IC RESISTER MONITORING)

CONFIRMATION DRIVING PATTERN

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) .
4. Turn the Techstream off.
5. Turn the ignition switch off.
6. Disconnect the Techstream.
7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
8. Connect the cable to the negative (-) battery terminal.
9. Connect the Techstream to the DLC3.
10. Turn the ignition switch to ON and turn the Techstream on.
11. Wait 16 seconds or more.
12. Enter the following menus: Powertrain / Engine / Trouble Codes.
13. Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Input the DTC: P0604, P0605, P0606, P060A, P060B or P062F.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

PROCEDURE

1. READ DTC OUTPUT (DTC P0604, P0605, P0606, P060A, P060B AND/OR P062F) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . Turn the ignition switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait for 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0604, P0605, P0606, P060A, P060B or P062F is output B B --> See step 3 A --> See step 2
2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
3. REPLACE ECM. Refer to «REMOVAL [07/2013 - 12/2013]»(ref-612354-S32372465292014042900000)

P0616

P0617

P0616

P0617

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Idle the engine for 1 second or more.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0616 or P0617.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. READ VALUE USING TECHSTREAM (STARTER SIGNAL, STARTER SWITCH) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Starter Signal and Starter Switch. Read the value displayed on the Techstream when the ignition switch is turned to ON and cranking. OK Techstream Display Condition Normal Condition Starter Signal Ignition switch ON OFF Cranking ON Starter Switch Ignition switch ON OFF Cranking ON RESULT Result Proceed to NG A OK B B --> See step 4 A: Go to next step
2. INSPECT RELAY (ST) Inspect the ST relay. Refer to «ON-VEHICLE INSPECTION [07/2013 - 12/2013] - Step 1»(ref-612370-S09423623702014042900000) . NG --> REPLACE RELAY (ST) OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (ST RELAY - ECM) Remove the ST relay from the engine room relay block assembly. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition ST relay terminal 3 - A33-17 (STSW2) Always Below 1 ohms ST relay terminal 1 - A35-26 (STA) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition ST relay terminal 3 or A33-17 (STSW2) - Body ground Always 10 kohms or higher ST relay terminal 1 or A35-26 (STA) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 7
4. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the tester on. Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to No DTC is output A P0616 or P0617 is output B HINT: If the engine does not start, replace the ECM. B --> See step 6 A --> See step 5
5. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
6. REPLACE ECM. Refer to «REMOVAL [07/2013 - 12/2013]»(ref-612354-S32372465292014042900000)
7. CHECK STARTER SIGNAL CIRCUIT. Refer to «Starter Signal Circuit»(ref-612367-S39752115532014042900000)

P062D

P1261, P1262, P1263, P1264

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Record the Freeze Frame Data.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) .
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Based on engine speed, engine load and other freeze frame data stored in the ECM, reproduce the conditions present when the DTC was stored.
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the DTC. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P062D, P1261, P1262, P1263 or P1264.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shown ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
13. If the test result is INCOMPLETE or N/A and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 184

Scheme 185

1. CHECK DTC OUTPUT (AUTOMATIC TRANSMISSION SYSTEM) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC is not output A DTC is output B B --> See step 5 A: Go to next step
2. READ OUTPUT DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC is not output A DTC P0700 is output B B --> See step 4 A --> See step 3
3. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
4. REPLACE ECM. Refer to «REMOVAL [07/2013 - 12/2013]»(ref-612354-S32372465292014042900000)
5. GO TO AUTOMATIC TRANSMISSION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - ]»(ref-612247-S26516156312014042900000)

FOR MANUAL TRANSMISSION

FOR AUTOMATIC TRANSMISSION

P0851 (FOR MANUAL TRANSMISSION)

P0852 (FOR MANUAL TRANSMISSION)

P0851 (FOR AUTOMATIC TRANSMISSION)

P0852 (FOR AUTOMATIC TRANSMISSION)

Scheme 186

Scheme 187

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher.
7. Change gear position 3 times or more during Accelerating vehicle to 64 km/h (40 mph) [A]. (for Manual Transmission) WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
8. Drive the vehicle at 10 km/h (6.25 mph) or more for 1 minute or more [B]. (for Automatic Transmission) WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
9. Enter the following menus: Powertrain / Engine / Trouble Codes.
10. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0851 or P0852.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
14. If the test result is INCOMPLETE or N/A and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 188

Scheme 189

CASE 1

CASE 2

Scheme 190

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher.
7. Depress the accelerator pedal fully and release the accelerator pedal.
8. Drive the vehicle at 10 km/h (6.25 mph) or more for 1 minute or more [A]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
9. Enter the following menus: Powertrain / Engine / Trouble Codes.
10. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P1109 or P2109.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
14. If the test result is INCOMPLETE or N/A and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P2109) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P1109 or P2109 is output A DTC P1109 or P2109 and other DTCs are output B HINT: If any DTCs other than P1109 or P2109 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
2. REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Replace the throttle with motor body assembly. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S00452226372014042900000) . NEXT: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC is not output A DTC P1109 or P2109 is output B B --> See step 5 A --> END
4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2013 - 12/2013]»(ref-612245-S04086921262014042900000)
5. REPLACE ECM. Refer to «REMOVAL [07/2013 - 12/2013]»(ref-612354-S32372465292014042900000)

CASE 1

CASE 2

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher.
7. Depress the accelerator pedal fully and release the accelerator pedal.
8. Drive the vehicle at 10 km/h (6.25 mph) or more for 1 minute or more [A]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
9. Enter the following menus: Powertrain / Engine / Trouble Codes.
10. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P1109 or P2109.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
14. If the test result is INCOMPLETE or N/A and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P2109) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P1109 or P2109 is output A DTC P1109 or P2109 and other DTCs are output B HINT: If any DTCs other than P1109 or P2109 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
2. REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Replace the throttle with motor body assembly. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S00452226372014042900000) . NEXT: Go to next step
3. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC is not output A DTC P1109 or P2109 is output B B --> See step 5 A --> END
4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-612245-S22758347072014042900000)
5. REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-612354-S32380777172014042900000)

P1160

P1160

P2119 (CASE 1)

P2119 (CASE 2)

P2119 (CASE 3)

P2119 (CASE 4)

P2119 (CASE 5)

P1160

P2119 (CASE 1 AND CASE 2)

P2119 (CASE 3, CASE 4 AND CASE 5)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher.
7. Depress the accelerator pedal fully and release the accelerator pedal.
8. Drive the vehicle at 10 km/h (6.25 mph) or more for 1 minute or more. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
9. Enter the following menus: Powertrain / Engine / Trouble Codes.
10. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P1160 or P2119.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
14. If the test result is INCOMPLETE or N/A and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

FAIL-SAFE

When this DTC or other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a fully closed throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P1160 OR P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P1160 and/or P2119 is output A DTC P1160 and/or P2119 and other DTCs are output B HINT: If any DTCs other than P1160 and/or P2119 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
2. READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Data List / Throttle Position No. 1 and Throttle Position Command. Read the values displayed on the Techstream while fully depressing and releasing the accelerator pedal quickly. RESULT Result Proceed to Throttle Position No. 1 does not change A Throttle Position No. 1 changes even a little B HINT: When a DTC is output, the system changes to fail-safe mode. Therefore, only use the data up until the time the DTC is stored for confirmation. B --> See step 4 A: Go to next step
3. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (RESISTANCE OF THROTTLE ACTUATOR) Inspect the throttle with motor body assembly. Refer to «INSPECTION [07/2013 - ]»(ref-612354-S06053469062014042900000) . NG --> See step 7 OK: Go to next step
4. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and housing. If necessary, clean the throttle with motor body assembly. Also, check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 7 OK: Go to next step
5. READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine / Data List / Throttle Position No. 1, Throttle Position No. 2 and Throttle Position Command. Read the values displayed on the Techstream while wiggling the ECM wire harness. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to Value in Data List changes when wire harness is wiggled, or DTC is output A Other than above B B --> See step 8 A: Go to next step
6. REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - THROTTLE WITH MOTOR BODY ASSEMBLY) As the DTC was stored due to a change in the contact resistance of the connector, repair or replace the wire harness or connector. NEXT --> END
7. REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Replace the throttle with motor body assembly. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S00452226372014042900000) . NEXT: Go to next step
8. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC is not output A DTC P1160 and/or P2119 is output B B --> See step 10 A --> END
9. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2013 - 12/2013]»(ref-612245-S04086921262014042900000)
10. REPLACE ECM. Refer to «REMOVAL [07/2013 - 12/2013]»(ref-612354-S32372465292014042900000)

ALL

P119E, P119F AND P219A (CRANKSHAFT POSITION SENSOR MONITORING METHOD)

P219A (AIR FUEL RATIO SENSOR MONITORING METHOD)

P119E AND P219A (CRANKSHAFT POSITION SENSOR MONITORING METHOD)

P119F AND P219A (CRANKSHAFT POSITION SENSOR MONITORING METHOD)

P219A (AIR FUEL RATIO SENSOR MONITORING METHOD)

Scheme 191

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher. HINT: Check the engine coolant temperature is 20°C (68°F) or less at engine started.
7. Perform the following the confirmation driving pattern. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. Drive the vehicle at 80 km/h (50 mph) or more for 20 minutes or more [A]. Stop the vehicle. Idle the engine for 1 minute or more [B].
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P119E, P119F or P219A.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
13. If the test result is INCOMPLETE or N/A and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P219A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P119E, P119F or P219A is output A DTC P119E, P119F, P219A and other DTCs are output B HINT: If any DTCs other than P219A are output, troubleshoot those DTCs first. B --> See step 14 A: Go to next step
2. READ VALUE USING TECHSTREAM (FREEZE FRAME DATA) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . Freeze Frame Data Items for DTC P119E, P119F and P219A Vehicle Speed Engine Speed Calculate Load Accelerator Idle Position Short FT #1 Long FT #1 Cylinder #1 Misfire Count to Cylinder #4 Misfire Count HINT: When the sum of Short FT and Long FT is positive, the engine is running lean, and when the sum is negative, the engine is running rich. DTC stored during idling It is possible to conclude that the problem was detected due to a "lean imbalance" (detected using crankshaft speed variation). DTC stored while vehicle being driven It is possible to conclude that the problem was detected due to a "rich imbalance" (detected using the air fuel ratio sensor). NEXT: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. HINT: The A/C switch and all accessory switches should be off and the shift lever should be in P, N or neutral position. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume / Cylinder #1 to #4 Misfire Count. HINT: When the "Control the Injection Volume" Active Test is selected (injection volume is 0%), if a misfire count increases, proceed to step 6 (Check Intake System). Perform the Control the Injection Volume operation with the engine idling. Check the misfire counts ("Cylinder #1 Misfire Count" to "Cylinder #4 Misfire Count") while decreasing the injection volume in 5% increments. NOTE: Do not decrease the injection volume by higher than 20%. Result The cylinder whose misfire count has not increased can be assumed to be running rich. Therefore, perform inspections while focusing on that cylinder. NEXT: Go to next step
4. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
5. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612373-S25356242002014042900000) . OK No leaks in the intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
6. INSPECT SPARK PLUG Inspect the spark plug of the cylinder causing the imbalance. Refer to «ON-VEHICLE INSPECTION [07/2013 - ] - Step 3»(ref-612369-S37616634002014042900000) . NG --> See step 15 OK: Go to next step
7. CHECK FOR SPARK (SPARK TEST) Perform a spark test. Refer to «ON-VEHICLE INSPECTION [07/2013 - ] - Step 1»(ref-612369-S37616634002014042900000) . HINT: If the result of the spark test is normal, proceed to the next step. NEXT: Go to next step
8. CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder. Refer to «ON-VEHICLE INSPECTION [07/2013 - ] - Step 9»(ref-612349-S19667946362014042900000) . NG --> CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION OK: Go to next step
9. CHECK HARNESS AND CONNECTOR (POWER SOURCE VOLTAGE) Disconnect the fuel injector assembly (for port injection) connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C8-1 - Body ground Ignition switch ON 11 to 14 V C30-1 - Body ground Ignition switch ON 11 to 14 V C9-1 - Body ground Ignition switch ON 11 to 14 V C31-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Injector Assembly) *b No. 1 cylinder *c No. 2 cylinder *d No. 3 cylinder *e No. 4 cylinder NG --> See step 16 OK: Go to next step
10. CHECK HARNESS AND CONNECTOR (FUEL INJECTOR ASSEMBLY - ECM) Check the harness and connector of fuel injector assembly (for port injection). Refer to «PROCEDURE - Step 3»(ref-612372-S35794914892014042900000) . Check the harness and connector of fuel injector assembly (for direct injection). Refer to «INSPECTION PROCEDURE»(ref-612377-S01404470492014042900000) . NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
11. CHECK FUEL INJECTOR ASSEMBLY OF CYLINDER CAUSING IMBALANCE Check the fuel injector assembly (for port injection) [whether fuel volume is high or low, and whether injection pattern is poor]. Refer to «INSPECTION [07/2013 - ]»(ref-612355-S11502663782014042900000) . Check the fuel injector assembly (for direct injection) [whether fuel volume is high or low, and whether injection pattern is poor]. Refer to «INSPECTION [07/2013 - ]»(ref-612355-S12904111072014042900000) . DTC Check the fuel injector P219A For port injection and direct injection P119E and P219A For port injection P119F and P219A For direct injection P119E, P119F and P219A For port injection and direct injection RESULT Result Proceed to OK A Fuel injector assembly (for port injection) is NG. B Fuel injector assembly (for direct injection) is NG. C B --> See step 17 C --> See step 18 A: Go to next step
12. CHECK FOR CAUSE OF FAILURE If the cause of the problem has not been found even after performing the troubleshooting procedure, perform the inspection below. Check the intake valve for deposits. HINT: As the DTC may have been stored due to deposits on the intake valve, remove the cylinder head and check the intake valve. NEXT: Go to next step
13. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. Result P219A is not output. NEXT --> END
14. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2013 - 12/2013]»(ref-612245-S04086921262014042900000)
15. REPLACE SPARK PLUG. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S20632081572014042900000)
16. GO TO FUEL INJECTOR CIRCUIT. Refer to «INSPECTION PROCEDURE»(ref-612372-S37134888492014042900000)
17. REPLACE FUEL INJECTOR ASSEMBLY (FOR PORT INJECTION). Refer to «REMOVAL [07/2013 - ]»(ref-612355-S38825859432014042900000)
18. REPLACE FUEL INJECTOR ASSEMBLY (FOR DIRECT INJECTION). Refer to «REMOVAL [07/2013 - ]»(ref-612355-S26558519832014042900000)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Record the Freeze Frame Data.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) .
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Based on engine speed, engine load and other freeze frame data stored in the ECM, reproduce the conditions present when the DTC was stored.
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the DTC. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P1235.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shown ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
13. If the test result is INCOMPLETE or N/A and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 192

1. INSPECT FUEL PUMP ASSEMBLY (FOR HIGH PRESSURE) Inspect the fuel pump assembly (for high pressure). Refer to «INSPECTION [07/2013 - ]»(ref-612355-S36223774022014042900000) . NG --> See step 7 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (INJECTOR DRIVER (EDU) - FUEL PUMP ASSEMBLY) Disconnect the injector driver (EDU) connector. Disconnect the fuel pump assembly (for high pressure) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition C2-3 (FP-) - C29-2 Always Below 1 ohms C2-4 (FP+) - C29-1 Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition C2-3 (FP-) or C29-2 - Body ground Always 10 kohms or higher C2-4 (FP+) or C29-1 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (ECM - INJECTOR DRIVER (EDU)) Disconnect the ECM connector. Disconnect the injector driver (EDU) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A34-32 (FPD) - C1-8 (FPD) Always Below 1 ohms A34-13 (FPF) - C1-7 (FPF) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A34-32 (FPD) or C1-8 (FPD) - Body ground Always 10 kohms or higher A34-13 (FPF) or C1-7 (FPF) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT ECM (FPD VOLTAGE) Turn the ignition switch to ON. Inspect the ECM using an oscilloscope. While idling the engine, check the waveform the terminals of the ECM connector. ECM Terminal Name A34-32 (FPD) - Body ground Tester Range 2 V/DIV., 20 ms./DIV. Condition Idling TEXT IN ILLUSTRATION *a Component with harness connected (ECM) *b FPD Terminal Waveform Normal Waveform Standard Signal waveform appears as shown in the illustration. HINT: The FPD terminal waveform is output only right after the engine starts. If this DTC is stored when the engine is started from ignition switch off, the system enters fail-safe mode and the waveform is not output. NG --> See step 6 OK: Go to next step
5. INSPECT ECM (FPF VOLTAGE) Turn the ignition switch to ON. Inspect the ECM using an oscilloscope. While idling the engine, check the waveform the terminals of the ECM connector. ECM Terminal Name CH1: A34-32 (FPD) - Body ground CH2: A34-13 (FPF) - Body ground Tester Range 2 V/DIV., 20 ms./DIV. Condition Idling TEXT IN ILLUSTRATION *a Component with harness connected (ECM) *b FPD Terminal and FPF Terminal Waveform Normal Waveform *c FPF Terminal Waveform NG Waveform 1 *d FPF Terminal Waveform NG Waveform 2 HINT: *: If the FPF terminal waveform is similar to the FPF terminal waveform NG waveform 1, stop the engine and disconnect injector driver (EDU) connector. Then, while cranking the engine, check to see if there is a difference between the FPF terminal waveform and the previous one. Result FPD Terminal Waveform FPF Terminal Waveform Proceed to OK OK A OK NG waveform 1* Does not change from NG waveform 1 (FPF terminal waveform remains at GND even after disconnecting the injector driver (EDU) connector and cranking the engine) A Changes to NG waveform 2 (FPF terminal waveform rises from GND after disconnecting the injector driver (EDU) connector and cranking the engine) B OK NG waveform 2 B B --> See step 9 A --> See step 8
6. INSPECT ECM (FPD VOLTAGE) Turn the ignition switch to ON. Disconnect the injector driver (EDU) connector. Inspect the ECM using an oscilloscope. While cranking the engine, check the waveform the terminals of the ECM connector. ECM Terminal Name A34-32 (FPD) - Body ground Tester Range 2 V/DIV., 20 ms./DIV. Condition Cranking TEXT IN ILLUSTRATION *a Component with harness connected (ECM) *b FPD Terminal Waveform Normal Waveform Standard Signal waveform appears as shown in the illustration. NG --> See step 8 OK --> See step 9
7. REPLACE FUEL PUMP ASSEMBLY (FOR HIGH PRESSURE). Refer to «REMOVAL [07/2013 - ]»(ref-612355-S39259682652014042900000)
8. REPLACE ECM. Refer to «REMOVAL [07/2013 - 12/2013]»(ref-612354-S32372465292014042900000)
9. REPLACE INJECTOR DRIVER (EDU). Refer to «REMOVAL [07/2013 - ]»(ref-612355-S33605946552014042900000)

Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F) and the coolant temperature below 45°C (113°F).

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure).
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
7. After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
8. Input the DTC: P1449.
9. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
10. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. INSPECT EVAP HOSE (DRAIN HOSE, PIPE AND TUBE) Check for filter blockage in the drain hose, pipe and tube. OK OK: No blockages in the drain hose, pipe and tube. NG --> See step 5 OK: Go to next step
2. INSPECT EVAP HOSE (CANISTER PUMP MODULE - DRAIN TUBE) Check for filter blockage in the EVAP purge line between the canister pump module and drain tube. OK No blockages in the EVAP purge line between the canister pump module and drain tube. NG --> See step 6 OK: Go to next step
3. INSPECT CANISTER PUMP MODULE (CANISTER FILTER) Check for filter blockage in the canister pump module (canister filter). OK No blockages in the canister filter. NG --> See step 7 OK: Go to next step
4. REPLACE CANISTER PUMP MODULE Replace the canister pump module. Refer to «REMOVAL [07/2013 - ]»(ref-612357-S03039446642014042900000) . NEXT --> See step 8
5. REPLACE EVAP HOSE (DRAIN HOSE, PIPE AND TUBE) NEXT --> See step 8
6. REPLACE EVAP HOSE (CANISTER PUMP MODULE - DRAIN TUBE) Replace the clogged EVAP purge line. NEXT --> See step 8
7. REPLACE CANISTER PUMP MODULE (CANISTER FILTER) Replace the canister pump module. Refer to «REMOVAL [07/2013 - ]»(ref-612357-S03039446642014042900000) . NEXT: Go to next step
8. PERFORM EVAP SYSTEM NOTE: The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine in this step. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F) and the coolant temperature below 45°C (113°F). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode. After the Evaporative System Check is completed, check for pending DTCs by entering the following menus: Powertrain / Engine / Trouble Codes. HINT: If no pending DTCs are found, the repair has been successfully completed. NEXT --> END

1. CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Read the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . RESULT Result Proceed to Only DTC P1603 is output A DTCs other than P1603 are output B HINT: If any DTCs other than P1603 are output, troubleshoot those DTCs first. B --> See step 102 A: Go to next step
2. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . OK Immobilizer Fuel Cut is OFF. RESULT Result Proceed to Abnormal A Normal B B --> See step 4 A: Go to next step
3. CHECK ENGINE IMMOBILIZER SYSTEM Connect the Techstream to the DLC3. Start the engine. Idle the engine Enter the following menus: Powertrain / Engine / Data List / Immobilizer Communication and Immobilizer Fuel Cut. Check the Data List indication. OK Data List Item Result Immobilizer Communication ON Immobilizer Fuel Cut OFF NG --> See step 108 OK: Go to next step
4. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Problem Symptom Freeze Frame Data Item Suspected Area Proceed to Closed Throttle Position SW Engine Speed Total of Short FT and Long FT When idling or decelerating, engine speed slowly decreases and engine stalls All 5 sets of freeze frame data are ON Decreases slowly*1 All 5 sets of freeze frame data are +15% or more*2 Air suction Sensor malfunction (value from sensor too lean) Fuel supply problem A At least 1 of the 5 sets of freeze frame data is -15% or less*3 Sensor malfunction (value from sensor too rich) B All 5 sets of freeze frame data are from -15% to +15% Intake air volume insufficient Ignition timing incorrect C When idling or decelerating, engine speed rapidly decreases and engine stalls Decreases rapidly*1 - Injection stoppage, ignition stoppage Load from external parts D When accelerating or driving at constant speed, engine stalls At least one is OFF - - Sensor malfunction Injection stoppage, ignition stoppage Fuel supply problem E HINT: *1: A rapid decrease in engine speed may be caused by an electrical fault in the shared wiring of all or a number of cylinders, an increase in load from external parts, etc. The engine speed is considered to have decreased rapidly if either of the following conditions applies. Otherwise, the engine speed is considered to have decreased slowly. In the freeze frame data, the decrease in engine speed from #3 to #5 is 400 rpm or more. In the freeze frame data, the engine speed at #5 is 120 rpm or less. If the vehicle speed is 30 km/h or less and the difference between Engine Speed and SPD (NT) is 100 rpm or less, inspect the automatic transmission. (Depending on the rate of vehicle deceleration, the engine speed may have decreased due to the A/T lock-up release being late.) *2: When a DTC is stored, feedback compensation increases because the air-fuel ratio is determined to be lean. *3: When a DTC is stored, feedback compensation decreases because the air-fuel ratio is determined to be rich. B --> See step 38 C --> See step 52 D --> See step 65 E --> See step 70 A: Go to next step
5. CHECK INTAKE SYSTEM Check for air leakage in the intake system [vacuum hose disconnection, cracks, damaged gaskets, etc.]. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612373-S25356242002014042900000) . HINT: If the accelerator pedal is released after racing the engine, the inspection is easier to perform because the vacuum inside the intake pipes increases and the air suction noise becomes louder. If Short FT and Long FT are largely different from the normal values when idling (the intake air volume is small) and almost the same as the normal values when racing the engine (the intake air volume is high), air leakage may be present. OK There is no air leakage. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
6. CHECK PURGE VALVE Disconnect the purge hose (on the canister side) of the purge valve. Start the engine. Idle the engine. Disconnect the connector of the purge valve. Check if air flows through the purge valve. OK Air does not flow. Connect the connector of the purge valve. Connect the purge hose of the purge valve. HINT: When this inspection is performed, the MIL may illuminate. After finishing the inspection, check and clear DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . NG --> See step 82 OK: Go to next step
7. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Stop Light Switch At least 1 of the 5 sets of freeze frame data is ON Air suction from brake booster A All 5 sets of freeze frame data are OFF - B B --> See step 10 A: Go to next step
8. READ VALUE USING TECHSTREAM (SHORT FT) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Short FT #1 in the Data List while depressing the brake pedal. Standard Short FT #1 changes by +10% or less. HINT: When air leakage from the brake booster is present, the feedback compensation increases because the air-fuel ratio becomes lean. NG --> See step 107 OK: Go to next step
9. PERFORM DRIVE TEST Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Short FT #1 in the Data List. Standard Data List Condition Specified Condition Short FT #1 + Long FT #1 The conditions of the vehicle are matched to those present when the problem occurs -15 to +15% NG --> See step 109 OK: Go to next step
10. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612369-S04420046822014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
11. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Calculate Load Below 90% of the current value of the vehicle*1 Mass air flow meter A AFS Voltage B1S1 2.2 V or higher*2 Air fuel ratio sensor Wire harness or connector B HINT: *1: If the mass air flow meter is malfunctioning and incorrectly measures the pressure to be less than the actual intake manifold pressure, the freeze frame data will show a low engine load value. *2: If the air fuel ratio sensor is malfunctioning and constantly outputs a value indicating the air-fuel ratio is lean, the actual air-fuel ratio will become rich and the engine may stall. B --> See step 15 A: Go to next step
12. CHECK MASS AIR FLOW METER Remove the mass air flow meter. Check for foreign matter in the airflow passage of the mass airflow meter. RESULT Result Proceed to Visible foreign matter is not present A Visible foreign matter is present B B --> See step 96 A: Go to next step
13. CHECK HARNESS AND CONNECTOR (ECM - MASS AIR FLOW METER) Disconnect the ECM. Disconnect the mass air flow meter connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A33-22 (VG) - C16-5 (VG) Always Below 1 ohms A33-29 (E2G) - C16-4 (E2G) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A33-22 (VG) or C16-5 (VG) - Body ground Always 10 kohms or higher A33-29 (E2G) or C16-4 (E2G) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
14. PERFORM DRIVE TEST Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Calculate Load in the Data List. Standard Data List Specified Condition Calculate Load 90 to 110% of the current value of the vehicle RESULT Result Proceed to Abnormal A Normal B B --> See step 18 A --> See step 118
15. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine, turn off all accessory switches and warm up the engine until the engine coolant temperature stabilizes. Idle the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor. Read the output voltage from the air fuel ratio sensor when increasing and decreasing the fuel injection volume. Standard Techstream Display Specified Condition Control the Injection Volume for A/F Sensor (+12%) Air fuel ratio sensor output voltage is below 2.0 V Control the Injection Volume for A/F Sensor (-12%) Air fuel ratio sensor output voltage is higher than 2.4 V RESULT Result Proceed to Abnormal A Normal B HINT: The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. B --> See step 18 A: Go to next step
16. CHECK TERMINAL VOLTAGE (AIR FUEL RATIO SENSOR POWER SOURCE) Disconnect the air fuel ratio sensor connector. Turn ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C14-2 (+B) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Air Fuel Ratio Sensor) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR AIR FUEL RATIO SENSOR POWER SOURCE CIRCUIT OK: Go to next step
17. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the ECM. Disconnect the air fuel ratio sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A34-18 (A1A-) - C14-4 (A1A-) Always Below 1 ohms A34-19 (A1A+) - C14-3 (A1A+) Always Below 1 ohms A34-5 (HA1A) - C14-2 (HA1A) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A34-18 (A1A-) or C14-4 (A1A-) - Body ground Always 10 kohms or higher A34-19 (A1A+) or C14-3 (A1A+) - Body ground Always 10 kohms or higher A34-5 (HA1A) or C14-2 (HA1A) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
18. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Proceed to Initial Engine Coolant Temp, Ambient Temp for A/C, Initial Intake Air Temp Difference in temperature between each item is less than 10°C*1 A Difference in temperature between each item is 10°C or more*2 B HINT: *1: A long time had elapsed after stopping the engine. *2: A long time had not elapsed after stopping the engine. B --> See step 21 A: Go to next step
19. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Initial Engine Coolant Temp, Coolant Temp, Engine Run Time Range A Engine coolant temperature sensor Thermostat A Range B Engine coolant temperature sensor B Range C - C HINT: This step is not directly related to engine stall. B --> See step 22 C --> See step 24 A: Go to next step
20. INSPECT THERMOSTAT HINT: For the thermostat inspection, refer to the following procedures. Refer to «INSPECTION [07/2013 - ]»(ref-612353-S37583208562014042900000) . RESULT Result Proceed to Abnormal A Normal B B --> See step 22 A --> See step 84
21. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Coolant Temp 120°C or higher Engine coolant temperature sensor A Coolant Temp, Ambient Temp for A/C Engine coolant temperature is lower than outside temperature by 15°C or more Engine coolant temperature sensor Both freeze frame data items listed above Values are other than above - B B --> See step 24 A: Go to next step
22. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «INSPECTION [07/2013 - ]»(ref-612354-S35982184052014042900000) . NG --> See step 94 OK: Go to next step
23. CHECK HARNESS AND CONNECTOR (ECM - ENGINE COOLANT TEMPERATURE SENSOR) Disconnect the ECM connector. Disconnect the engine coolant temperature sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A36-30 (THW) - C40-2 (THW) Always Below 1 ohms A36-29 (E1) - C40-1 (E2) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A36-30 (THW) or C40-2 (THW) - Body ground Always 10 kohms or higher A36-29 (E1) or C40-1 (E2) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
24. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to EVAP (Purge) VSV At least 1 of the 5 sets of freeze frame data is not 0% Purge valve A All 5 sets of freeze frame data are 0% - B HINT: If the purge valve is stuck closed, air-fuel ratio compensation by the purge valve is incorrectly adjusted, and then the air-fuel ratio becomes lean and the engine may stall. B --> See step 33 A: Go to next step
25. PERFORM ACTIVE TEST USING TECHSTREAM (ACTIVATE THE VSV FOR EVAP CONTROL) Disconnect the purge hose (on the canister side) of the purge valve. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine. Enter the following menus: Powertrain / Engine / Active Test / Activate the VSV for Evap Control. Operate the purge valve and check the airflow. OK Activate the VSV for Evap Control Specified Condition ON Air flows OFF Air does not flow RESULT Result Proceed to NG A OK B TEXT IN ILLUSTRATION *a Purge valve ON (Air flows) *b Purge valve OFF (Air does not flow) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. B --> See step 33 A: Go to next step
26. INSPECT PURGE VALVE Inspect the purge valve. Refer to «INSPECTION [07/2013 - ]»(ref-612357-S32320814572014042900000) . NG --> See step 86 OK: Go to next step
27. CHECK TERMINAL VOLTAGE (PURGE VALVE POWER SOURCE) Disconnect the purge valve connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition d1-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Purge Valve) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR PURGE VALVE POWER SOURCE CIRCUIT OK: Go to next step
28. CHECK HARNESS AND CONNECTOR (PURGE VALVE - ECM) Disconnect the purge valve connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A36-11 (PRG) - d1-2 Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A36-11 (PRG) or d1-2 - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
29. CLEAR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . NEXT: Go to next step
30. READ VALUE USING TECHSTREAM (EVAP (Purge) VSV) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine for 15 minutes or more. Using the Techstream, read the value of EVAP (Purge) VSV in the Data List. Standard Data List Specified Condition EVAP (Purge) VSV Value other than 0% is displayed RESULT Result Proceed to Abnormal A Normal B B --> See step 110 A: Go to next step
31. PERFORM ACTIVE TEST USING TECHSTREAM Disconnect the purge hose (on the canister side) of the purge valve. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine. Enter the following menus: Powertrain / Engine / Active Test / Activate the VSV for Evap Control. Operate the purge valve and check the airflow. OK Activate the VSV for Evap Control Specified Condition ON Air flows OFF Air does not flow RESULT Result Proceed to NG A OK B TEXT IN ILLUSTRATION *a VSV ON (Air flows) *b VSV OFF (Air does not flow) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. B --> See step 111 A: Go to next step
32. CHECK CONNECTOR CONNECTION CONDITION (ECM) Check the ECM connector connection condition. HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> RECONNECT CONNECTOR CORRECTLY OK --> See step 87
33. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP DUTY) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump Duty. When performing the Active Test, check for an operating sound from the fuel pump. Standard Control the Fuel Pump Duty Specified Condition 25 or 80% Operating sound heard OFF Operating sound not heard RESULT Result Proceed to Abnormal A Normal B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. While performing the Active Test, make sure that there is no fuel leakage from the pipes, no signs that fuel has leaked, and no fuel smell. If the fuel pump operating noise is abnormal, proceed to step 34. B --> See step 35 A: Go to next step
34. INSPECT FUEL PUMP ASSEMBLY Inspect the fuel pump assembly. Refer to «INSPECTION [07/2013 - ]»(ref-612355-S19908381832014042900000) . NG --> See step 105 OK --> See step 88
35. CHECK FUEL SYSTEM Check the fuel system. Check the fuel pump operation. Check the fuel leaks. Check the fuel pressure (low pressure side). Check the fuel pressure (high pressure side). Perform the Active Test [D-4S (Fuel Cut)]. HINT: For the fuel system On-vehicle Inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612368-S09323837092014042900000) . RESULT Result Proceed to Abnormal A Normal B B --> See step 112 A: Go to next step
36. CHECK FUEL SYSTEM Check for foreign matter such as iron particles around the fuel pump assembly (fuel pump, fuel pump filter and inside the fuel tank), and for signs that the fuel pump was stuck. RESULT Result Proceed to There is foreign matter or signs that fuel pump was stuck A There is no foreign matter and no signs that fuel pump was stuck B HINT: If there is foreign matter such as iron particles on the fuel pump, fuel filter or fuel tank, remove the foreign matter. B --> REPAIR OR REPLACE FUEL SYSTEM A: Go to next step
37. CHECK FUEL SYSTEM Check the fuel system. Check the fuel pump operation. Check the fuel leaks. Check the fuel pressure (low pressure side). Check the fuel pressure (high pressure side). Perform the Active Test [D-4S (Fuel Cut)]. HINT: For the fuel system On-vehicle Inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612368-S09323837092014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK --> END
38. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612369-S04420046822014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
39. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Calculate Load 110% or more of the current value of the vehicle*1 Mass air flow meter A AFS Voltage B1S1 Below 2.4 V*2 Air fuel ratio sensor Harness and connector B Both freeze frame data items listed above Values are other than above - C HINT: *1: If the mass air flow meter is malfunctioning and incorrectly measures the intake air volume to be higher than the actual volume of air flowing through the intake manifold, the freeze frame data will show a high engine load value. *2: As the air fuel ratio sensor output is low before the sensor warms up, the value at that time cannot be used for diagnosis. If the air fuel ratio sensor is malfunctioning and constantly outputs a value indicating the air-fuel ratio is rich, the actual air-fuel ratio will become lean and the engine may stall. B --> See step 43 C --> See step 46 A: Go to next step
40. CHECK MASS AIR FLOW METER Remove the mass airflow meter. Check for foreign matter in the airflow passage of the mass air flow meter. RESULT Result Proceed to Visible foreign matter is not present A Visible foreign matter is present B B --> See step 83 A: Go to next step
41. CHECK HARNESS AND CONNECTOR (ECM - MASS AIR FLOW METER) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A33-22 (VG) - C16-5 (VG) Always Below 1 ohms A33-29 (E2G) - C16-4 (E2G) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A33-22 (VG) or C16-5 (VG) - Body ground Always 10 kohms or higher A33-29 (E2G) or C16-4 (E2G) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
42. PERFORM DRIVE TEST Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Calculate Load in the Data List. Standard Data List Specified Condition Calculate Load 90 to 110% of the current value of the vehicle NG --> See step 113 OK: Go to next step
43. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine, turn off all accessory switches and warm up the engine until the engine coolant temperature stabilizes. Idle the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor. Read the output voltage from the air fuel ratio sensor when increasing and decreasing the fuel injection volume. Standard Techstream Display Specified Condition Control the Injection Volume for A/F Sensor (+12%) Air fuel ratio sensor output voltage is below 2.0 V Control the Injection Volume for A/F Sensor (-12%) Air fuel ratio sensor output voltage is higher than 2.4 V RESULT Result Proceed to Abnormal A Normal B HINT: The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. B --> See step 46 A: Go to next step
44. CHECK TERMINAL VOLTAGE (AIR FUEL RATIO SENSOR POWER SOURCE) Disconnect the air fuel ratio sensor connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition C14-2 (+B) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Air Fuel Ratio Sensor) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR AIR FUEL RATIO SENSOR POWER SOURCE CIRCUIT OK: Go to next step
45. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A34-18 (A1A-) - C14-4 (A1A-) Always Below 1 ohms A34-19 (A1A+) - C14-3 (A1A+) Always Below 1 ohms A34-5 (HA1A) - C14-2 (HA1A) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A34-18 (A1A-) or C14-4 (A1A-) - Body ground Always 10 kohms or higher A34-19 (A1A+) or C14-3 (A1A+) - Body ground Always 10 kohms or higher A34-5 (HA1A) or C14-2 (HA1A) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
46. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Proceed to Initial Engine Coolant Temp, Ambient Temp for A/C, Initial Intake Air Temp Difference in temperature between each item is less than 10°C*1 A Difference in temperature between each item is 10°C or more*2 B HINT: *1: A long time had elapsed after stopping the engine. *2: A long time had not elapsed after stopping the engine. B --> See step 49 A: Go to next step
47. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Initial Engine Coolant Temp, Coolant Temp, Engine Run Time Range A Engine coolant temperature sensor Thermostat A Range B Engine coolant temperature B Range C - C HINT: This step is not directly related to engine stall. B --> See step 50 C --> See step 78 A: Go to next step
48. INSPECT THERMOSTAT HINT: For the thermostat inspection, refer to the following procedures. Refer to «INSPECTION [07/2013 - ]»(ref-612353-S37583208562014042900000) . RESULT Result Proceed to Abnormal A Normal B HINT: This step is not directly related to engine stall. B --> See step 50 A --> See step 91
49. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Coolant Temp 120°C or higher Engine coolant temperature sensor A Coolant Temp, Ambient Temp for A/C Engine coolant temperature is lower than outside temperature by 15°C or more Engine coolant temperature sensor Both freeze frame data items listed above Values are other than above - B B --> See step 81 A: Go to next step
50. INSPECT ENGINE COOLANT TEMPERATURE SENSOR HINT: For the engine coolant temperature sensor inspection, refer to the following procedures. Refer to «INSPECTION [07/2013 - ]»(ref-612354-S35982184052014042900000) . RESULT Result Proceed to Normal A Abnormal B B --> See step 92 A: Go to next step
51. CHECK HARNESS AND CONNECTOR (ECM - ENGINE COOLANT TEMPERATURE SENSOR) Disconnect the ECM connector. Disconnect the engine coolant temperature sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A36-30 (THW) - C40-2 (THW) Always Below 1 ohms A36-29 (E1) - C40-1 (E2) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A36-30 (THW) or C40-2 (THW) - Body ground Always 10 kohms or higher A36-29 (E1) or C40-1 (E2) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 119
52. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612369-S04420046822014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
53. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Total of ISC Learning Value and ISC Feedback Value Below 80% of the current value of the vehicle Intake air volume insufficient A 80% or more of the current value of the vehicle B B --> See step 56 A: Go to next step
54. CHECK INTAKE SYSTEM Check for air leakage in the intake system [vacuum hose disconnection, cracks, damaged gaskets, etc.]. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612373-S25356242002014042900000) . HINT: If the accelerator pedal is released after racing the engine, the inspection is easier to perform because the vacuum inside the intake pipes increases and the air suction noise becomes louder. If Short FT and Long FT are largely different from the normal values when idling (the intake air volume is small) and almost the same as the normal values when racing the engine (the intake air volume is high), air leakage may be present. OK There is no air leakage. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
55. CHECK INTAKE SYSTEM Check the intake system. Inspect the brake booster assembly. Refer to «INSPECTION [07/2013 - ]»(ref-612347-S10347311112014042900000) . Inspect the mass air flow meter. Refer to «INSPECTION [07/2013 - ]»(ref-612354-S42629000262014042900000) . Check the PCV hose. Refer to «ON-VEHICLE INSPECTION [07/2013 - ] - Step 4»(ref-612375-S38856074132014042900000) . Inspect the PCV valve. Refer to «INSPECTION [07/2013 - ]»(ref-612357-S21623918332014042900000) . Inspect the purge valve. Refer to «INSPECTION [07/2013 - ]»(ref-612357-S32320814572014042900000) . RESULT Result Proceed to Abnormal A Normal B B --> See step 60 A --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA
56. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Connect the Techstream to the DLC3. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank1) or Control the VVT Linear (Bank2). HINT: When performing the Active Test, make sure the A/C is on and the shift lever is in P, N or neutral. Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Specified Condition 0 deg (CA) Normal engine speed 36 deg (CA) Engine idles roughly or stalls HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When the results of the inspection using the Active Test are normal but the valve operating noise is abnormal, check the valve for any signs of problems. If the camshaft timing oil control valve is stuck on, the valve overlap increases and combustion worsens due to the internal EGR which may cause rough idle or cause the engine to stall. NG --> See step 93 OK: Go to next step
57. CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE - ECM) Disconnect the camshaft timing oil control valve connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C7-1 - Body ground Ignition switch ON 11 to 14 V C24-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *A Bank 1 *B Bank 2 *a Front view of wire harness connector (to Camshaft Timing Oil Control Valve for Intake Side) Disconnect the ECM connector. Measure the voltage according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A36-17 (OC1) - C7-2 Always Below 1 ohms A36-16 (OC2) - C24-2 Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A36-17 (OC1) or C7-2 - Body ground Always 10 kohms or higher A36-16 (OC2) or C24-2 - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
58. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR) Connect the Techstream to the DLC3. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank1) or Control the VVT Exhaust Linear (Bank2). HINT: When performing the Active Test, make sure the A/C is on and the shift lever is in P, N or neutral position. Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Specified Condition 0 deg (CA) Normal engine speed 51 deg (CA) Engine idles roughly or stalls HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When the results of the inspection using the Active Test are normal but the valve operating noise is abnormal, check the valve for any signs of problems. If the camshaft timing oil control valve is stuck on, the valve overlap increases and combustion worsens due to the internal EGR which may cause rough idle or cause the engine to stall. NG --> See step 106 OK: Go to next step
59. CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE - ECM) Disconnect the camshaft timing oil control valve connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C5-1 - Body ground Ignition switch ON 11 to 14 V C23-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *A Bank 1 *B Bank 2 *a Front view of wire harness connector (to Camshaft Timing Oil Control Valve for Exhaust Side) Disconnect the ECM connector. Measure the voltage according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A36-7 (OE1) - C5-2 Always Below 1 ohms A36-5 (OE2) - C23-2 Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A36-7 (OE1) or C5-2 - Body ground Always 10 kohms or higher A36-5 (OE2) or C23-2 - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
60. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Suspected Area Proceed to IGN Advance Knock Correct Learn Value Differs from the current value of the vehicle by 10° or more Less than 3° Engine coolant temperature sensor Mass air flow meter Knock sensor A 3° or more - B Differs from the current value of the vehicle by less than 10° - - B --> See step 114 A: Go to next step
61. INSPECT ENGINE COOLANT TEMPERATURE SENSOR HINT: For the engine coolant temperature sensor inspection, refer to the following procedures. Refer to «INSPECTION [07/2013 - ]»(ref-612354-S35982184052014042900000) . NG --> See step 85 OK: Go to next step
62. CHECK HARNESS AND CONNECTOR (ECM - ENGINE COOLANT TEMPERATURE SENSOR) Disconnect the ECM connector. Disconnect the engine coolant temperature sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A36-30 (THW) - C40-2 (THW) Always Below 1 ohms A36-29 (E1) - C40-1 (E2) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A36-30 (THW) or C40-2 (THW) - Body ground Always 10 kohms or higher A36-29 (E1) or C40-1 (E2) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
63. INSPECT MASS AIR FLOW METER (INTAKE AIR TEMPERATURE SENSOR) Inspect the mass air flow meter. Refer to «INSPECTION [07/2013 - ]»(ref-612354-S42629000262014042900000) . HINT: If the intake air temperature sent to the ECM is higher than the standard due to the mass air flow meter (intake air temperature sensor) malfunctioning, the ignition timing may become delayed. NG --> See step 90 OK: Go to next step
64. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of IGN Advance and Knock Correct Learn Value in the Data List. RESULT Freeze Frame Data Item Proceed to IGN Advance Knock Correct Learn Value Differs from the current value of the vehicle by 10° or more Less than 3° A 3° or more B Differs from the current value of the vehicle by less than 10° - HINT: If the results of the checks performed in steps 56 to 64 were all normal and the sum of ISC Feedback Value and ISC Learning Value in the Data List is 120% of the normal value or more, check for carbon deposits in the throttle with motor body assembly. If there are carbon deposits, clean them off to finish the troubleshooting procedure. B --> END A --> See step 95
65. CHECK TERMINAL VOLTAGE (FUEL INJECTOR POWER SOURCE) Disconnect the fuel injector assembly connectors. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Cylinder Tester Connection Switch Condition Specified Condition No. 1 C8-1 - Body ground Ignition switch ON 11 to 14 V No. 2 C30-1 - Body ground Ignition switch ON 11 to 14 V No. 3 C9-1 - Body ground Ignition switch ON 11 to 14 V No. 4 C31-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Injector Assembly (for Port Injection)) *b No. 1 cylinder *c No. 2 cylinder *d No. 3 cylinder *e No. 4 cylinder HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. A rapid decrease in engine speed may have been caused by a malfunction in all or multiple cylinders. (There may be an electrical malfunction in the wiring shared by all the cylinders.) NG --> REPAIR FUEL INJECTOR POWER SOURCE CIRCUIT OK: Go to next step
66. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612369-S04420046822014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
67. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Suspected Area Proceed to A/C Signal Air Conditioner FB Val A/C Signal display does not change from OFF - Except for A/C system A A/C Signal display changes from OFF to ON*1 Value displayed for Air Conditioner FB Val does not increase Value displayed for Air Conditioner FB Val increases A/C system B HINT: *1: Check not only the on/off state of the air conditioner but also the change in air conditioner load. The normal value for the ISC learned value is engine displacement (liters) x 0.9. Even if the results are normal, the power steering system and/or A/C system may have been malfunctioning. If there are no problems with other parts, inspect the power steering system and/or A/C system. B --> See step 97 A: Go to next step
68. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Suspected Area Proceed to Electric Load Feedback Val Difference between Engine Speed and SPD (NT) Vehicle Speed Electrical Load Signal display changes from OFF to ON*3, or value displayed for Electric Load Feedback Val increases*1 Value displayed for Electric Load Val changes - - Electrical load signal circuit C Value displayed for Electric Load Val does not change At least 1 of the 5 sets of freeze frame data is less than 100 rpm Less than 30 km/h Automatic transmission system B 30 km/h or more - A All 5 sets of freeze frame data are 100 rpm or more - - A Electrical Load Signal display does not change from OFF, or value displayed for Electric Load Feedback Val does not increase - At least 1 of the 5 sets of freeze frame data is less than 100 rpm Less than 30 km/h Automatic transmission system B 30 km/h or more - A All 5 sets of freeze frame data are 100 rpm or more - - A HINT: *1: If the Electrical Load Signal display changes from OFF to ON, or the "Electric Load Feedback Val" increases, it probably is a malfunction due to a change in electrical load. Check the generator and the continuity and connections between the generator and ECM. The normal value for the ISC learned value is engine displacement (liters) x 0.9. Even if the results are normal, the electrical load signal system and/or Automatic transmission system may have been malfunctioning. If there are no problems with other parts, inspect the electrical load system and/or Automatic transmission system. B --> See step 103 C --> See step 104 A: Go to next step
69. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Suspected Area Proceed to Shift SW Status (P Range) Shift SW Status (N Range) Neutral Position SW Signal P and N position are both OFF in at least one data set In D or R, NSW is ON Park/neutral position switch assembly A In D or R, NSW is OFF Automatic transmission system B All 5 sets of freeze frame data are ON - - C HINT: Even if the results are normal, the park/neutral position switch assembly and/or Automatic transmission system may have been malfunctioning. If there are no problems with other parts, inspect the park/neutral position switch assembly and/or Automatic transmission system. B --> See step 98 C --> See step 115 A --> See step 99
70. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Throttle Sensor Position, Calculate Load Calculate Load decreases while Throttle Sensor Position increases Mass air flow meter A Calculate Load does not decrease while Throttle Sensor Position increases - B B --> See step 74 A: Go to next step
71. CHECK MASS AIR FLOW METER Remove the mass air flow meter. Check for foreign matter in the airflow passage of the mass airflow meter. RESULT Result Proceed to Visible foreign matter is not present A Visible foreign matter is present B B --> See step 100 A: Go to next step
72. CHECK HARNESS AND CONNECTOR (ECM - MASS AIR FLOW METER) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A33-22 (VG) - C16-5 (VG) Always Below 1 ohms A33-29 (E2G) - C16-4 (E2G) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A33-22 (VG) or C16-5 (VG) - Body ground Always 10 kohms or higher A33-29 (E2G) or C16-4 (E2G) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
73. PERFORM DRIVE TEST Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Calculate Load in the Data List. Standard Data List Specified Condition Calculate Load 90 to 110% of the current value of the vehicle NG --> See step 116 OK: Go to next step
74. CHECK TERMINAL VOLTAGE (FUEL INJECTOR POWER SOURCE) Disconnect the fuel injector assembly connectors. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Cylinder Tester Connection Switch Condition Specified Condition No. 1 C8-1 - Body ground Ignition switch ON 11 to 14 V No. 2 C30-1 - Body ground Ignition switch ON 11 to 14 V No. 3 C9-1 - Body ground Ignition switch ON 11 to 14 V No. 4 C31-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Injector Assembly (for Port Injection)) *b No. 1 cylinder *c No. 2 cylinder *d No. 3 cylinder *e No. 4 cylinder HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. A rapid decrease in engine speed may have been caused by a malfunction in all or multiple cylinders. (There may be an electrical malfunction in the wiring shared by all the cylinders.) NG --> REPAIR FUEL INJECTOR POWER SOURCE CIRCUIT OK: Go to next step
75. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612369-S04420046822014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
76. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP DUTY) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump Duty. When performing the Active Test, check for an operating sound from the fuel pump. Standard Control the Fuel Pump Duty Specified Condition 25 or 80% Operating sound heard OFF Operating sound not heard RESULT Result Proceed to Abnormal A Normal B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. While performing the Active Test, make sure that there is no fuel leakage from the pipes, no signs that fuel has leaked, and no fuel smell. If the fuel pump operating noise is abnormal, proceed to step 77. B --> See step 78 A: Go to next step
77. INSPECT FUEL PUMP ASSEMBLY Inspect the fuel pump assembly. Refer to «INSPECTION [07/2013 - ]»(ref-612355-S19908381832014042900000) . NG --> See step 89 OK --> See step 101
78. CHECK FUEL SYSTEM Check the fuel system. Check the fuel pump operation. Check the fuel leaks. Check the fuel pressure. Check the fuel pressure (for high pressure). Perform the Active Test [D-4S (Fuel Cut)]. HINT: For the fuel system On-vehicle Inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612368-S09323837092014042900000) . RESULT Result Proceed to Abnormal A Normal B B --> See step 117 A: Go to next step
79. CHECK FUEL SYSTEM Check for foreign matter such as iron particles around the fuel pump assembly (fuel pump, fuel pump filter and inside the fuel tank), and for signs that the fuel pump was stuck. RESULT Result Proceed to There is foreign matter or signs that fuel pump was stuck A There is no foreign matter and no signs that fuel pump was stuck B HINT: If there is foreign matter such as iron particles on the fuel pump, fuel filter or fuel tank, remove the foreign matter. B --> REPAIR OR REPLACE FUEL SYSTEM A: Go to next step
80. CHECK FUEL SYSTEM Check the fuel system. Check the fuel pump operation. Check the fuel leaks. Check the fuel pressure. Check the fuel pressure (for high pressure). Perform the Active Test [D-4S (Fuel Cut)]. HINT: For the fuel system On-vehicle Inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612368-S09323837092014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK --> END
81. CLEAR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . NEXT --> END
82. REPLACE PURGE VALVE. Refer to «REMOVAL [07/2013 - ]»(ref-612357-S21370998562014042900000)
83. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
84. REPLACE THERMOSTAT. Refer to «REMOVAL [07/2013 - ]»(ref-612353-S14266877022014042900000)
85. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S36080325202014042900000)
86. REPLACE PURGE VALVE. Refer to «REMOVAL [07/2013 - ]»(ref-612357-S21370998562014042900000)
87. REPLACE ECM. Refer to «REMOVAL [07/2013 - 12/2013]»(ref-612354-S32372465292014042900000)
88. CHECK FUEL PUMP CONTROL CIRCUIT (LOW PRESSURE SIDE). Refer to «Fuel Pump Control Circuit»(ref-612367-S30459002732014042900000)
89. REPLACE FUEL PUMP ASSEMBLY. Refer to «REMOVAL [07/2013 - ]»(ref-612355-S08227949432014042900000)
90. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
91. REPLACE THERMOSTAT. Refer to «REMOVAL [07/2013 - ]»(ref-612353-S14266877022014042900000)
92. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S36080325202014042900000)
93. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S07019103422014042900000)
94. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S36080325202014042900000)
95. CHECK KNOCK SENSOR CIRCUIT. Refer to «INSPECTION PROCEDURE»(ref-612372-S38808854782014042900000)
96. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
97. CHECK AIR CONDITIONING SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - ]»(ref-612374-S08209266482014042900000)
98. CHECK AUTOMATIC TRANSMISSION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - ]»(ref-612247-S26516156312014042900000)
99. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «INSPECTION [07/2013 - ]»(ref-612361-S22229953602014042900000)
100. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
101. CHECK FUEL PUMP CONTROL CIRCUIT (LOW PRESSURE SIDE). Refer to «Fuel Pump Control Circuit»(ref-612367-S30459002732014042900000)
102. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2013 - 12/2013]»(ref-612245-S04086921262014042900000)
103. CHECK AUTOMATIC TRANSMISSION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - ]»(ref-612247-S26516156312014042900000)
104. CHECK GENERATOR CIRCUIT. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - ]»(ref-612376-S18684528212014042900000)
105. REPLACE FUEL PUMP ASSEMBLY. Refer to «REMOVAL [07/2013 - ]»(ref-612355-S08227949432014042900000)
106. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S07019103422014042900000)
107. INSPECT BRAKE BOOSTER ASSEMBLY. Refer to «INSPECTION [07/2013 - ]»(ref-612347-S10347311112014042900000)
108. CHECK ENGINE IMMOBILIZER SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - ]»(ref-612246-S23448296122014042900000)
109. INSPECT BRAKE BOOSTER ASSEMBLY. Refer to «INSPECTION [07/2013 - ]»(ref-612347-S10347311112014042900000)
110. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
111. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
112. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
113. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
114. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
115. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
116. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
117. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
118. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
119. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)

1. CHECK FOR ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Read the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . RESULT Result Proceed to Only DTC P1603 is output A DTCs other than P1603 are output B HINT: If any DTCs other than P1603 are output, troubleshoot those DTCs first. B --> See step 102 A: Go to next step
2. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . OK Immobilizer Fuel Cut is OFF. RESULT Result Proceed to Abnormal A Normal B B --> See step 4 A: Go to next step
3. CHECK ENGINE IMMOBILIZER SYSTEM Connect the Techstream to the DLC3. Start the engine. Idle the engine Enter the following menus: Powertrain / Engine / Data List / Immobilizer Communication and Immobilizer Fuel Cut. Check the Data List indication. OK Data List Item Result Immobilizer Communication ON Immobilizer Fuel Cut OFF RESULT Result Proceed to OK A NG (w/ Smart Key System) B NG (w/o Smart Key System) C B --> See step 108 C --> See step 120 A: Go to next step
4. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Problem Symptom Freeze Frame Data Item Suspected Area Proceed to Closed Throttle Position SW Engine Speed Total of Short FT and Long FT When idling or decelerating, engine speed slowly decreases and engine stalls All 5 sets of freeze frame data are ON Decreases slowly*1 All 5 sets of freeze frame data are +15% or more*2 Air suction Sensor malfunction (value from sensor too lean) Fuel supply problem A At least 1 of the 5 sets of freeze frame data is -15% or less*3 Sensor malfunction (value from sensor too rich) B All 5 sets of freeze frame data are from -15% to +15% Intake air volume insufficient Ignition timing incorrect C When idling or decelerating, engine speed rapidly decreases and engine stalls Decreases rapidly*1 - Injection stoppage, ignition stoppage Load from external parts D When accelerating or driving at constant speed, engine stalls At least one is OFF - - Sensor malfunction Injection stoppage, ignition stoppage Fuel supply problem E HINT: *1: A rapid decrease in engine speed may be caused by an electrical fault in the shared wiring of all or a number of cylinders, an increase in load from external parts, etc. The engine speed is considered to have decreased rapidly if either of the following conditions applies. Otherwise, the engine speed is considered to have decreased slowly. In the freeze frame data, the decrease in engine speed from #3 to #5 is 400 rpm or more. In the freeze frame data, the engine speed at #5 is 120 rpm or less. If the vehicle speed is 30 km/h or less and the difference between Engine Speed and SPD (NT) is 100 rpm or less, inspect the automatic transmission. (Depending on the rate of vehicle deceleration, the engine speed may have decreased due to the A/T lock-up release being late.) *2: When a DTC is stored, feedback compensation increases because the air-fuel ratio is determined to be lean. *3: When a DTC is stored, feedback compensation decreases because the air-fuel ratio is determined to be rich. B --> See step 38 C --> See step 52 D --> See step 65 E --> See step 70 A: Go to next step
5. CHECK INTAKE SYSTEM Check for air leakage in the intake system [vacuum hose disconnection, cracks, damaged gaskets, etc.]. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612373-S25356242002014042900000) . HINT: If the accelerator pedal is released after racing the engine, the inspection is easier to perform because the vacuum inside the intake pipes increases and the air suction noise becomes louder. If Short FT and Long FT are largely different from the normal values when idling (the intake air volume is small) and almost the same as the normal values when racing the engine (the intake air volume is high), air leakage may be present. OK There is no air leakage. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
6. CHECK PURGE VALVE Disconnect the purge hose (on the canister side) of the purge valve. Start the engine. Idle the engine. Disconnect the connector of the purge valve. Check if air flows through the purge valve. OK Air does not flow. Connect the connector of the purge valve. Connect the purge hose of the purge valve. HINT: When this inspection is performed, the MIL may illuminate. After finishing the inspection, check and clear DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . NG --> See step 82 OK: Go to next step
7. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Stop Light Switch At least 1 of the 5 sets of freeze frame data is ON Air suction from brake booster A All 5 sets of freeze frame data are OFF - B B --> See step 10 A: Go to next step
8. READ VALUE USING TECHSTREAM (SHORT FT) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Short FT #1 in the Data List while depressing the brake pedal. Standard Short FT #1 changes by +10% or less. HINT: When air leakage from the brake booster is present, the feedback compensation increases because the air-fuel ratio becomes lean. NG --> See step 107 OK: Go to next step
9. PERFORM DRIVE TEST Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Short FT #1 in the Data List. Standard Data List Condition Specified Condition Short FT #1 + Long FT #1 The conditions of the vehicle are matched to those present when the problem occurs -15 to +15% NG --> See step 109 OK: Go to next step
10. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612369-S04420046822014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
11. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Calculate Load Below 90% of the current value of the vehicle*1 Mass air flow meter A AFS Voltage B1S1 2.2 V or higher*2 Air fuel ratio sensor Wire harness or connector B HINT: *1: If the mass air flow meter is malfunctioning and incorrectly measures the pressure to be less than the actual intake manifold pressure, the freeze frame data will show a low engine load value. *2: If the air fuel ratio sensor is malfunctioning and constantly outputs a value indicating the air-fuel ratio is lean, the actual air-fuel ratio will become rich and the engine may stall. B --> See step 15 A: Go to next step
12. CHECK MASS AIR FLOW METER Remove the mass air flow meter. Check for foreign matter in the airflow passage of the mass airflow meter. RESULT Result Proceed to Visible foreign matter is not present A Visible foreign matter is present B B --> See step 96 A: Go to next step
13. CHECK HARNESS AND CONNECTOR (ECM - MASS AIR FLOW METER) Disconnect the ECM. Disconnect the mass air flow meter connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A33-22 (VG) - C16-5 (VG) Always Below 1 ohms A33-29 (E2G) - C16-4 (E2G) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A33-22 (VG) or C16-5 (VG) - Body ground Always 10 kohms or higher A33-29 (E2G) or C16-4 (E2G) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
14. PERFORM DRIVE TEST Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Calculate Load in the Data List. Standard Data List Specified Condition Calculate Load 90 to 110% of the current value of the vehicle RESULT Result Proceed to Abnormal A Normal B B --> See step 18 A --> See step 118
15. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine, turn off all accessory switches and warm up the engine until the engine coolant temperature stabilizes. Idle the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor. Read the output voltage from the air fuel ratio sensor when increasing and decreasing the fuel injection volume. Standard Techstream Display Specified Condition Control the Injection Volume for A/F Sensor (+12%) Air fuel ratio sensor output voltage is below 2.0 V Control the Injection Volume for A/F Sensor (-12%) Air fuel ratio sensor output voltage is higher than 2.4 V RESULT Result Proceed to Abnormal A Normal B HINT: The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. B --> See step 18 A: Go to next step
16. CHECK TERMINAL VOLTAGE (AIR FUEL RATIO SENSOR POWER SOURCE) Disconnect the air fuel ratio sensor connector. Turn ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C14-2 (+B) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Air Fuel Ratio Sensor) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR AIR FUEL RATIO SENSOR POWER SOURCE CIRCUIT OK: Go to next step
17. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the ECM. Disconnect the air fuel ratio sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A34-18 (A1A-) - C14-4 (A1A-) Always Below 1 ohms A34-19 (A1A+) - C14-3 (A1A+) Always Below 1 ohms A34-5 (HA1A) - C14-2 (HA1A) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A34-18 (A1A-) or C14-4 (A1A-) - Body ground Always 10 kohms or higher A34-19 (A1A+) or C14-3 (A1A+) - Body ground Always 10 kohms or higher A34-5 (HA1A) or C14-2 (HA1A) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
18. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Proceed to Initial Engine Coolant Temp, Ambient Temp for A/C, Initial Intake Air Temp Difference in temperature between each item is less than 10°C*1 A Difference in temperature between each item is 10°C or more*2 B HINT: *1: A long time had elapsed after stopping the engine. *2: A long time had not elapsed after stopping the engine. B --> See step 21 A: Go to next step
19. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Initial Engine Coolant Temp, Coolant Temp, Engine Run Time Range A Engine coolant temperature sensor Thermostat A Range B Engine coolant temperature sensor B Range C - C HINT: This step is not directly related to engine stall. B --> See step 22 C --> See step 24 A: Go to next step
20. INSPECT THERMOSTAT HINT: For the thermostat inspection, refer to the following procedures. Refer to «INSPECTION [07/2013 - ]»(ref-612353-S37583208562014042900000) . RESULT Result Proceed to Abnormal A Normal B B --> See step 22 A --> See step 84
21. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Coolant Temp 120°C or higher Engine coolant temperature sensor A Coolant Temp, Ambient Temp for A/C Engine coolant temperature is lower than outside temperature by 15°C or more Engine coolant temperature sensor Both freeze frame data items listed above Values are other than above - B B --> See step 24 A: Go to next step
22. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Inspect the engine coolant temperature sensor. Refer to «INSPECTION [07/2013 - ]»(ref-612354-S35982184052014042900000) . NG --> See step 94 OK: Go to next step
23. CHECK HARNESS AND CONNECTOR (ECM - ENGINE COOLANT TEMPERATURE SENSOR) Disconnect the ECM connector. Disconnect the engine coolant temperature sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A36-30 (THW) - C35-2 (THW) Always Below 1 ohms A36-29 (E1) - C35-1 (E2) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A36-30 (THW) or C35-2 (THW) - Body ground Always 10 kohms or higher A36-29 (E1) or C35-1 (E2) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
24. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to EVAP (Purge) VSV At least 1 of the 5 sets of freeze frame data is not 0% Purge valve A All 5 sets of freeze frame data are 0% - B HINT: If the purge valve is stuck closed, air-fuel ratio compensation by the purge valve is incorrectly adjusted, and then the air-fuel ratio becomes lean and the engine may stall. B --> See step 33 A: Go to next step
25. PERFORM ACTIVE TEST USING TECHSTREAM (ACTIVATE THE VSV FOR EVAP CONTROL) Disconnect the purge hose (on the canister side) of the purge valve. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine. Enter the following menus: Powertrain / Engine / Active Test / Activate the VSV for Evap Control. Operate the purge valve and check the airflow. OK Activate the VSV for Evap Control Specified Condition ON Air flows OFF Air does not flow RESULT Result Proceed to NG A OK B TEXT IN ILLUSTRATION *a Purge valve ON (Air flows) *b Purge valve OFF (Air does not flow) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. B --> See step 33 A: Go to next step
26. INSPECT PURGE VALVE Inspect the purge valve. Refer to «INSPECTION [07/2013 - ]»(ref-612357-S32320814572014042900000) . NG --> See step 86 OK: Go to next step
27. CHECK TERMINAL VOLTAGE (PURGE VALVE POWER SOURCE) Disconnect the purge valve connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition d1-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Purge Valve) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR PURGE VALVE POWER SOURCE CIRCUIT OK: Go to next step
28. CHECK HARNESS AND CONNECTOR (PURGE VALVE - ECM) Disconnect the purge valve connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A36-11 (PRG) - d1-2 Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A36-11 (PRG) or d1-2 - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
29. CLEAR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . NEXT: Go to next step
30. READ VALUE USING TECHSTREAM (EVAP (Purge) VSV) Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine for 15 minutes or more. Using the Techstream, read the value of EVAP (Purge) VSV in the Data List. Standard Data List Specified Condition EVAP (Purge) VSV Value other than 0% is displayed RESULT Result Proceed to Abnormal A Normal B B --> See step 110 A: Go to next step
31. PERFORM ACTIVE TEST USING TECHSTREAM Disconnect the purge hose (on the canister side) of the purge valve. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine. Enter the following menus: Powertrain / Engine / Active Test / Activate the VSV for Evap Control. Operate the purge valve and check the airflow. OK Activate the VSV for Evap Control Specified Condition ON Air flows OFF Air does not flow RESULT Result Proceed to NG A OK B TEXT IN ILLUSTRATION *a VSV ON (Air flows) *b VSV OFF (Air does not flow) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. B --> See step 111 A: Go to next step
32. CHECK CONNECTOR CONNECTION CONDITION (ECM) Check the ECM connector connection condition. HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> RECONNECT CONNECTOR CORRECTLY OK --> See step 87
33. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP DUTY) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump Duty. When performing the Active Test, check for an operating sound from the fuel pump. Standard Control the Fuel Pump Duty Specified Condition 25 or 80% Operating sound heard OFF Operating sound not heard RESULT Result Proceed to Abnormal A Normal B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. While performing the Active Test, make sure that there is no fuel leakage from the pipes, no signs that fuel has leaked, and no fuel smell. If the fuel pump operating noise is abnormal, proceed to step 34. B --> See step 35 A: Go to next step
34. INSPECT FUEL PUMP ASSEMBLY Inspect the fuel pump assembly. Refer to «INSPECTION [07/2013 - ]»(ref-612355-S19908381832014042900000) . NG --> See step 105 OK --> See step 88
35. CHECK FUEL SYSTEM Check the fuel system. Check the fuel pump operation. Check the fuel leaks. Check the fuel pressure (low pressure side). Check the fuel pressure (high pressure side). Perform the Active Test [D-4S (Fuel Cut)]. HINT: For the fuel system On-vehicle Inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612368-S09323837092014042900000) . RESULT Result Proceed to Abnormal A Normal B B --> See step 112 A: Go to next step
36. CHECK FUEL SYSTEM Check for foreign matter such as iron particles around the fuel pump assembly (fuel pump, fuel pump filter and inside the fuel tank), and for signs that the fuel pump was stuck. RESULT Result Proceed to There is foreign matter or signs that fuel pump was stuck A There is no foreign matter and no signs that fuel pump was stuck B HINT: If there is foreign matter such as iron particles on the fuel pump, fuel filter or fuel tank, remove the foreign matter. B --> REPAIR OR REPLACE FUEL SYSTEM A: Go to next step
37. CHECK FUEL SYSTEM Check the fuel system. Check the fuel pump operation. Check the fuel leaks. Check the fuel pressure (low pressure side). Check the fuel pressure (high pressure side). Perform the Active Test [D-4S (Fuel Cut)]. HINT: For the fuel system On-vehicle Inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612368-S09323837092014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK --> END
38. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612369-S04420046822014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
39. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Calculate Load 110% or more of the current value of the vehicle*1 Mass air flow meter A AFS Voltage B1S1 Below 2.4 V*2 Air fuel ratio sensor Harness and connector B Both freeze frame data items listed above Values are other than above - C HINT: *1: If the mass air flow meter is malfunctioning and incorrectly measures the intake air volume to be higher than the actual volume of air flowing through the intake manifold, the freeze frame data will show a high engine load value. *2: As the air fuel ratio sensor output is low before the sensor warms up, the value at that time cannot be used for diagnosis. If the air fuel ratio sensor is malfunctioning and constantly outputs a value indicating the air-fuel ratio is rich, the actual air-fuel ratio will become lean and the engine may stall. B --> See step 43 C --> See step 46 A: Go to next step
40. CHECK MASS AIR FLOW METER Remove the mass airflow meter. Check for foreign matter in the airflow passage of the mass air flow meter. RESULT Result Proceed to Visible foreign matter is not present A Visible foreign matter is present B B --> See step 83 A: Go to next step
41. CHECK HARNESS AND CONNECTOR (ECM - MASS AIR FLOW METER) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A33-22 (VG) - C16-5 (VG) Always Below 1 ohms A33-29 (E2G) - C16-4 (E2G) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A33-22 (VG) or C16-5 (VG) - Body ground Always 10 kohms or higher A33-29 (E2G) or C16-4 (E2G) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
42. PERFORM DRIVE TEST Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Calculate Load in the Data List. Standard Data List Specified Condition Calculate Load 90 to 110% of the current value of the vehicle NG --> See step 113 OK: Go to next step
43. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Start the engine, turn off all accessory switches and warm up the engine until the engine coolant temperature stabilizes. Idle the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor. Read the output voltage from the air fuel ratio sensor when increasing and decreasing the fuel injection volume. Standard Techstream Display Specified Condition Control the Injection Volume for A/F Sensor (+12%) Air fuel ratio sensor output voltage is below 2.0 V Control the Injection Volume for A/F Sensor (-12%) Air fuel ratio sensor output voltage is higher than 2.4 V RESULT Result Proceed to Abnormal A Normal B HINT: The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. B --> See step 46 A: Go to next step
44. CHECK TERMINAL VOLTAGE (AIR FUEL RATIO SENSOR POWER SOURCE) Disconnect the air fuel ratio sensor connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition C14-2 (+B) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Air Fuel Ratio Sensor) HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR AIR FUEL RATIO SENSOR POWER SOURCE CIRCUIT OK: Go to next step
45. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A34-18 (A1A-) - C14-4 (A1A-) Always Below 1 ohms A34-19 (A1A+) - C14-3 (A1A+) Always Below 1 ohms A34-5 (HA1A) - C14-2 (HA1A) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A34-18 (A1A-) or C14-4 (A1A-) - Body ground Always 10 kohms or higher A34-19 (A1A+) or C14-3 (A1A+) - Body ground Always 10 kohms or higher A34-5 (HA1A) or C14-2 (HA1A) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
46. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Proceed to Initial Engine Coolant Temp, Ambient Temp for A/C, Initial Intake Air Temp Difference in temperature between each item is less than 10°C*1 A Difference in temperature between each item is 10°C or more*2 B HINT: *1: A long time had elapsed after stopping the engine. *2: A long time had not elapsed after stopping the engine. B --> See step 49 A: Go to next step
47. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Initial Engine Coolant Temp, Coolant Temp, Engine Run Time Range A Engine coolant temperature sensor Thermostat A Range B Engine coolant temperature B Range C - C HINT: This step is not directly related to engine stall. B --> See step 50 C --> See step 78 A: Go to next step
48. INSPECT THERMOSTAT HINT: For the thermostat inspection, refer to the following procedures. Refer to «INSPECTION [07/2013 - ]»(ref-612353-S37583208562014042900000) . RESULT Result Proceed to Abnormal A Normal B HINT: This step is not directly related to engine stall. B --> See step 50 A --> See step 91
49. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Coolant Temp 120°C or higher Engine coolant temperature sensor A Coolant Temp, Ambient Temp for A/C Engine coolant temperature is lower than outside temperature by 15°C or more Engine coolant temperature sensor Both freeze frame data items listed above Values are other than above - B B --> See step 81 A: Go to next step
50. INSPECT ENGINE COOLANT TEMPERATURE SENSOR HINT: For the engine coolant temperature sensor inspection, refer to the following procedures. Refer to «INSPECTION [07/2013 - ]»(ref-612354-S35982184052014042900000) . RESULT Result Proceed to Normal A Abnormal B B --> See step 92 A: Go to next step
51. CHECK HARNESS AND CONNECTOR (ECM - ENGINE COOLANT TEMPERATURE SENSOR) Disconnect the ECM connector. Disconnect the engine coolant temperature sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A36-30 (THW) - C35-2 (THW) Always Below 1 ohms A36-29 (E1) - C35-1 (E2) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A36-30 (THW) or C35-2 (THW) - Body ground Always 10 kohms or higher A36-29 (E1) or C35-1 (E2) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 119
52. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612369-S04420046822014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
53. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Total of ISC Learning Value and ISC Feedback Value Below 80% of the current value of the vehicle Intake air volume insufficient A 80% or more of the current value of the vehicle B B --> See step 56 A: Go to next step
54. CHECK INTAKE SYSTEM Check for air leakage in the intake system [vacuum hose disconnection, cracks, damaged gaskets, etc.]. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612373-S25356242002014042900000) . HINT: If the accelerator pedal is released after racing the engine, the inspection is easier to perform because the vacuum inside the intake pipes increases and the air suction noise becomes louder. If Short FT and Long FT are largely different from the normal values when idling (the intake air volume is small) and almost the same as the normal values when racing the engine (the intake air volume is high), air leakage may be present. OK There is no air leakage. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
55. CHECK INTAKE SYSTEM Check the intake system. Inspect the brake booster assembly. Refer to «INSPECTION [07/2013 - ]»(ref-612347-S10347311112014042900000) . Inspect the mass air flow meter. Refer to «INSPECTION [07/2013 - ]»(ref-612354-S42629000262014042900000) . Check the PCV hose. Refer to «ON-VEHICLE INSPECTION [07/2013 - ] - Step 4»(ref-612375-S38856074132014042900000) . Inspect the PCV valve. Refer to «INSPECTION [07/2013 - ]»(ref-612357-S21623918332014042900000) . Inspect the purge valve. Refer to «INSPECTION [07/2013 - ]»(ref-612357-S32320814572014042900000) . RESULT Result Proceed to Abnormal A Normal B B --> See step 60 A --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA
56. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) Connect the Techstream to the DLC3. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank1) or Control the VVT Linear (Bank2). HINT: When performing the Active Test, make sure the A/C is on and the shift lever is in P, N or neutral. Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Specified Condition 0 deg (CA) Normal engine speed 36 deg (CA) Engine idles roughly or stalls HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When the results of the inspection using the Active Test are normal but the valve operating noise is abnormal, check the valve for any signs of problems. If the camshaft timing oil control valve is stuck on, the valve overlap increases and combustion worsens due to the internal EGR which may cause rough idle or cause the engine to stall. NG --> See step 93 OK: Go to next step
57. CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE - ECM) Disconnect the camshaft timing oil control valve connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C7-1 - Body ground Ignition switch ON 11 to 14 V C24-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *A Bank 1 *B Bank 2 *a Front view of wire harness connector (to Camshaft Timing Oil Control Valve for Intake Side) Disconnect the ECM connector. Measure the voltage according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A36-17 (OC1) - C7-2 Always Below 1 ohms A36-16 (OC2) - C24-2 Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A36-17 (OC1) or C7-2 - Body ground Always 10 kohms or higher A36-16 (OC2) or C24-2 - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
58. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR) Connect the Techstream to the DLC3. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank1) or Control the VVT Exhaust Linear (Bank2). HINT: When performing the Active Test, make sure the A/C is on and the shift lever is in P, N or neutral position. Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Specified Condition 0 deg (CA) Normal engine speed 51 deg (CA) Engine idles roughly or stalls HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. When the results of the inspection using the Active Test are normal but the valve operating noise is abnormal, check the valve for any signs of problems. If the camshaft timing oil control valve is stuck on, the valve overlap increases and combustion worsens due to the internal EGR which may cause rough idle or cause the engine to stall. NG --> See step 106 OK: Go to next step
59. CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE - ECM) Disconnect the camshaft timing oil control valve connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition C5-1 - Body ground Ignition switch ON 11 to 14 V C23-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *A Bank 1 *B Bank 2 *a Front view of wire harness connector (to Camshaft Timing Oil Control Valve for Exhaust Side) Disconnect the ECM connector. Measure the voltage according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A36-7 (OE1) - C5-2 Always Below 1 ohms A36-5 (OE2) - C23-2 Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A36-7 (OE1) or C5-2 - Body ground Always 10 kohms or higher A36-5 (OE2) or C23-2 - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
60. READ FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Suspected Area Proceed to IGN Advance Knock Correct Learn Value Differs from the current value of the vehicle by 10° or more Less than 3° Engine coolant temperature sensor Mass air flow meter Knock sensor A 3° or more - B Differs from the current value of the vehicle by less than 10° - - B --> See step 114 A: Go to next step
61. INSPECT ENGINE COOLANT TEMPERATURE SENSOR HINT: For the engine coolant temperature sensor inspection, refer to the following procedures. Refer to «INSPECTION [07/2013 - ]»(ref-612354-S35982184052014042900000) . NG --> See step 85 OK: Go to next step
62. CHECK HARNESS AND CONNECTOR (ECM - ENGINE COOLANT TEMPERATURE SENSOR) Disconnect the ECM connector. Disconnect the engine coolant temperature sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A36-30 (THW) - C35-2 (THW) Always Below 1 ohms A36-29 (E1) - C35-1 (E2) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A36-30 (THW) or C35-2 (THW) - Body ground Always 10 kohms or higher A36-29 (E1) or C35-1 (E2) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
63. INSPECT MASS AIR FLOW METER (INTAKE AIR TEMPERATURE SENSOR) Inspect the mass air flow meter. Refer to «INSPECTION [07/2013 - ]»(ref-612354-S42629000262014042900000) . HINT: If the intake air temperature sent to the ECM is higher than the standard due to the mass air flow meter (intake air temperature sensor) malfunctioning, the ignition timing may become delayed. NG --> See step 90 OK: Go to next step
64. READ VALUE USING TECHSTREAM Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of IGN Advance and Knock Correct Learn Value in the Data List. RESULT Freeze Frame Data Item Proceed to IGN Advance Knock Correct Learn Value Differs from the current value of the vehicle by 10° or more Less than 3° A 3° or more B Differs from the current value of the vehicle by less than 10° - HINT: If the results of the checks performed in steps 56 to 64 were all normal and the sum of ISC Feedback Value and ISC Learning Value in the Data List is 120% of the normal value or more, check for carbon deposits in the throttle with motor body assembly. If there are carbon deposits, clean them off to finish the troubleshooting procedure. B --> END A --> See step 95
65. CHECK TERMINAL VOLTAGE (FUEL INJECTOR POWER SOURCE) Disconnect the fuel injector assembly connectors. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Cylinder Tester Connection Switch Condition Specified Condition No. 1 C8-1 - Body ground Ignition switch ON 11 to 14 V No. 2 C30-1 - Body ground Ignition switch ON 11 to 14 V No. 3 C9-1 - Body ground Ignition switch ON 11 to 14 V No. 4 C31-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Injector Assembly (for Port Injection)) *b No. 1 cylinder *c No. 2 cylinder *d No. 3 cylinder *e No. 4 cylinder HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. A rapid decrease in engine speed may have been caused by a malfunction in all or multiple cylinders. (There may be an electrical malfunction in the wiring shared by all the cylinders.) NG --> REPAIR FUEL INJECTOR POWER SOURCE CIRCUIT OK: Go to next step
66. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612369-S04420046822014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
67. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Suspected Area Proceed to A/C Signal Air Conditioner FB Val A/C Signal display does not change from OFF - Except for A/C system A A/C Signal display changes from OFF to ON*1 Value displayed for Air Conditioner FB Val does not increase Value displayed for Air Conditioner FB Val increases A/C system (Automatic A/C system) B A/C system (Manual A/C system) C HINT: *1: Check not only the on/off state of the air conditioner but also the change in air conditioner load. The normal value for the ISC learned value is engine displacement (liters) x 0.9. Even if the results are normal, the power steering system and/or A/C system may have been malfunctioning. If there are no problems with other parts, inspect the power steering system and/or A/C system. B --> See step 97 C --> See step 121 A: Go to next step
68. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Suspected Area Proceed to Electric Load Feedback Val Difference between Engine Speed and SPD (NT) Vehicle Speed Electrical Load Signal display changes from OFF to ON*3, or value displayed for Electric Load Feedback Val increases*1 Value displayed for Electric Load Val changes - - Electrical load signal circuit C Value displayed for Electric Load Val does not change At least 1 of the 5 sets of freeze frame data is less than 100 rpm Less than 30 km/h Automatic transmission system B 30 km/h or more - A All 5 sets of freeze frame data are 100 rpm or more - - A Electrical Load Signal display does not change from OFF, or value displayed for Electric Load Feedback Val does not increase - At least 1 of the 5 sets of freeze frame data is less than 100 rpm Less than 30 km/h Automatic transmission system B 30 km/h or more - A All 5 sets of freeze frame data are 100 rpm or more - - A HINT: *1: If the Electrical Load Signal display changes from OFF to ON, or the "Electric Load Feedback Val" increases, it probably is a malfunction due to a change in electrical load. Check the generator and the continuity and connections between the generator and ECM. The normal value for the ISC learned value is engine displacement (liters) x 0.9. Even if the results are normal, the electrical load signal system and/or Automatic transmission system may have been malfunctioning. If there are no problems with other parts, inspect the electrical load system and/or Automatic transmission system. B --> See step 103 C --> See step 104 A: Go to next step
69. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Suspected Area Proceed to Shift SW Status (P Range) Shift SW Status (N Range) Neutral Position SW Signal P and N position are both OFF in at least one data set In D or R, NSW is ON Park/neutral position switch assembly A In D or R, NSW is OFF Automatic transmission system B All 5 sets of freeze frame data are ON - - C HINT: Even if the results are normal, the park/neutral position switch assembly and/or Automatic transmission system may have been malfunctioning. If there are no problems with other parts, inspect the park/neutral position switch assembly and/or Automatic transmission system. B --> See step 98 C --> See step 115 A --> See step 99
70. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the ignition switch to ON. Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored. Refer to «FREEZE FRAME DATA [07/2013 - ]»(ref-612245-S16816801152014042900000) . RESULT Freeze Frame Data Item Result Suspected Area Proceed to Throttle Sensor Position, Calculate Load Calculate Load decreases while Throttle Sensor Position increases Mass air flow meter A Calculate Load does not decrease while Throttle Sensor Position increases - B B --> See step 74 A: Go to next step
71. CHECK MASS AIR FLOW METER Remove the mass air flow meter. Check for foreign matter in the airflow passage of the mass airflow meter. RESULT Result Proceed to Visible foreign matter is not present A Visible foreign matter is present B B --> See step 100 A: Go to next step
72. CHECK HARNESS AND CONNECTOR (ECM - MASS AIR FLOW METER) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for open) Tester Connection Condition Specified Condition A33-22 (VG) - C16-5 (VG) Always Below 1 ohms A33-29 (E2G) - C16-4 (E2G) Always Below 1 ohms Standard Resistance (Check for short) Tester Connection Condition Specified Condition A33-22 (VG) or C16-5 (VG) - Body ground Always 10 kohms or higher A33-29 (E2G) or C16-4 (E2G) - Body ground Always 10 kohms or higher HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
73. PERFORM DRIVE TEST Connect the Techstream to the DLC3. Start the engine and warm it up until the engine coolant temperature stabilizes. HINT: The A/C switch and all accessory switches should be off. Idle the engine. Using the Techstream, read the value of Calculate Load in the Data List. Standard Data List Specified Condition Calculate Load 90 to 110% of the current value of the vehicle NG --> See step 116 OK: Go to next step
74. CHECK TERMINAL VOLTAGE (FUEL INJECTOR POWER SOURCE) Disconnect the fuel injector assembly connectors. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Cylinder Tester Connection Switch Condition Specified Condition No. 1 C8-1 - Body ground Ignition switch ON 11 to 14 V No. 2 C30-1 - Body ground Ignition switch ON 11 to 14 V No. 3 C9-1 - Body ground Ignition switch ON 11 to 14 V No. 4 C31-1 - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Fuel Injector Assembly (for Port Injection)) *b No. 1 cylinder *c No. 2 cylinder *d No. 3 cylinder *e No. 4 cylinder HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. Make sure there is not an excessive amount of force applied to the wire harness. A rapid decrease in engine speed may have been caused by a malfunction in all or multiple cylinders. (There may be an electrical malfunction in the wiring shared by all the cylinders.) NG --> REPAIR FUEL INJECTOR POWER SOURCE CIRCUIT OK: Go to next step
75. CHECK IGNITION SYSTEM Perform ignition system On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612369-S04420046822014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK: Go to next step
76. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE FUEL PUMP DUTY) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump Duty. When performing the Active Test, check for an operating sound from the fuel pump. Standard Control the Fuel Pump Duty Specified Condition 25 or 80% Operating sound heard OFF Operating sound not heard RESULT Result Proceed to Abnormal A Normal B HINT: Jiggle the wire harness and connector to increase the likelihood of detecting malfunctions that do not always occur. While performing the Active Test, make sure that there is no fuel leakage from the pipes, no signs that fuel has leaked, and no fuel smell. If the fuel pump operating noise is abnormal, proceed to step 77. B --> See step 78 A: Go to next step
77. INSPECT FUEL PUMP ASSEMBLY Inspect the fuel pump assembly. Refer to «INSPECTION [07/2013 - ]»(ref-612355-S19908381832014042900000) . NG --> See step 89 OK --> See step 101
78. CHECK FUEL SYSTEM Check the fuel system. Check the fuel pump operation. Check the fuel leaks. Check the fuel pressure. Check the fuel pressure (for high pressure). Perform the Active Test [D-4S (Fuel Cut)]. HINT: For the fuel system On-vehicle Inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612368-S09323837092014042900000) . RESULT Result Proceed to Abnormal A Normal B B --> See step 117 A: Go to next step
79. CHECK FUEL SYSTEM Check for foreign matter such as iron particles around the fuel pump assembly (fuel pump, fuel pump filter and inside the fuel tank), and for signs that the fuel pump was stuck. RESULT Result Proceed to There is foreign matter or signs that fuel pump was stuck A There is no foreign matter and no signs that fuel pump was stuck B HINT: If there is foreign matter such as iron particles on the fuel pump, fuel filter or fuel tank, remove the foreign matter. B --> REPAIR OR REPLACE FUEL SYSTEM A: Go to next step
80. CHECK FUEL SYSTEM Check the fuel system. Check the fuel pump operation. Check the fuel leaks. Check the fuel pressure. Check the fuel pressure (for high pressure). Perform the Active Test [D-4S (Fuel Cut)]. HINT: For the fuel system On-vehicle Inspection, refer to the following procedures. Refer to «ON-VEHICLE INSPECTION [07/2013 - ]»(ref-612368-S09323837092014042900000) . NG --> REPAIR OR REPLACE MALFUNCTIONING PARTS, COMPONENT AND AREA OK --> END
81. CLEAR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612245-S39444024262014042900000) . NEXT --> END
82. REPLACE PURGE VALVE. Refer to «REMOVAL [07/2013 - ]»(ref-612357-S21370998562014042900000)
83. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
84. REPLACE THERMOSTAT. Refer to «REMOVAL [07/2013 - ]»(ref-612353-S14266877022014042900000)
85. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S36080325202014042900000)
86. REPLACE PURGE VALVE. Refer to «REMOVAL [07/2013 - ]»(ref-612357-S21370998562014042900000)
87. REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-612354-S32380777172014042900000)
88. CHECK FUEL PUMP CONTROL CIRCUIT (LOW PRESSURE SIDE). Refer to «Fuel Pump Control Circuit»(ref-612367-S30459002732014042900000)
89. REPLACE FUEL PUMP ASSEMBLY. Refer to «REMOVAL [07/2013 - ]»(ref-612355-S08227949432014042900000)
90. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
91. REPLACE THERMOSTAT. Refer to «REMOVAL [07/2013 - ]»(ref-612353-S14266877022014042900000)
92. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S36080325202014042900000)
93. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S07019103422014042900000)
94. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S36080325202014042900000)
95. CHECK KNOCK SENSOR CIRCUIT. Refer to «INSPECTION PROCEDURE»(ref-612372-S38808854782014042900000)
96. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
97. CHECK AIR CONDITIONING SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - ]»(ref-612374-S08209266482014042900000)
98. CHECK AUTOMATIC TRANSMISSION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - ]»(ref-612247-S26516156312014042900000)
99. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY. Refer to «INSPECTION [07/2013 - ]»(ref-612361-S22229953602014042900000)
100. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
101. CHECK FUEL PUMP CONTROL CIRCUIT (LOW PRESSURE SIDE). Refer to «Fuel Pump Control Circuit»(ref-612367-S30459002732014042900000)
102. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [12/2013 - ]»(ref-612245-S22758347072014042900000)
103. CHECK AUTOMATIC TRANSMISSION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - ]»(ref-612247-S26516156312014042900000)
104. CHECK GENERATOR CIRCUIT. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - ]»(ref-612376-S18684528212014042900000)
105. REPLACE FUEL PUMP ASSEMBLY. Refer to «REMOVAL [07/2013 - ]»(ref-612355-S08227949432014042900000)
106. REPLACE CAMSHAFT TIMING OIL CONTROL VALVE. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S07019103422014042900000)
107. INSPECT BRAKE BOOSTER ASSEMBLY. Refer to «INSPECTION [07/2013 - ]»(ref-612347-S10347311112014042900000)
108. CHECK ENGINE IMMOBILIZER SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [12/2013 - ]»(ref-612251-S15996370102014042900000)
109. INSPECT BRAKE BOOSTER ASSEMBLY. Refer to «INSPECTION [07/2013 - ]»(ref-612347-S10347311112014042900000)
110. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
111. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
112. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
113. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
114. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
115. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
116. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
117. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
118. REPLACE MASS AIR FLOW METER. Refer to «REMOVAL [07/2013 - ]»(ref-612354-S22820667092014042900000)
119. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS [07/2013 - ]»(ref-612245-S25693203212014042900000)
120. CHECK ENGINE IMMOBILIZER SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - ]»(ref-612246-S23448296122014042900000)
121. CHECK AIR CONDITIONING SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [12/2013 - ]»(ref-612244-S02173192122014042900000)
