1. REPLACE AUTOMATIC TRANSMISSION FLUID Lift the vehicle. [*1] NOTE: Set the vehicle on a lift so that the vehicle is kept level when it is lifted up (make sure that the tilt angle from the front to rear of the vehicle is within +/- 1°). Remove the No. 2 engine under cover. Refer to «REMOVAL [07/2013 - ] - Step 2»(ref-612378-S00142194672014042900000). Remove the drain plug and gasket, and drain the ATF. [*2] Temporarily install the drain plug and gasket. [*3] HINT: Reuse the old gasket. The drain plug will be removed again to adjust the fluid level. Remove the refill plug with O-ring, overflow plug and gasket. [*4] TEXT IN ILLUSTRATION *1 Refill Plug *2 Overflow Plug *a Refill Hole Add fluid to the refill hole until it flows out of the overflow tube. [*5] TEXT IN ILLUSTRATION *1 Overflow Tube *a Specified Fluid Level NOTE: Use Toyota Genuine ATF WS. Wait until the fluid flow slows and only drops come out. [*6] Temporarily install the overflow plug and gasket. [*7] HINT: Reuse the old gasket. The overflow plug will be removed again to adjust the fluid level. Add fluid to the refill hole using the amount of fluid specified for removal and installation of the oil pan. [*8] HINT: Specified amount of fluid is 2.0 liters (2.1 US qts, 1.8 Imp. qts). Temporarily install the refill plug with O-ring. [*9] HINT: Reuse the old O-ring. The refill plug will be removed again to adjust the fluid level. Lower the vehicle. [*10] Start the engine. [*11] NOTE: Make sure that the A/C switch is off. Slowly move the shift lever from P to M. Then return the shift lever to P. [*12] HINT: Slowly move the shift lever to circulate the fluid through each part of the transmission. Allow the engine to idle for 30 seconds to warm it up. [*13] Turn the ignition switch off. [*14] Repeat steps [*1] to [*14]. Repeat steps [*1] to [*2]. Install the drain plug and a new gasket. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) Repeat steps [*4] to [*10]. Adjust the fluid level. Refer to «ADJUSTMENT [07/2013 - ]»(ref-612361-S07378094452014042900000). Install the No. 2 engine under cover. Refer to «INSTALLATION [07/2013 - ] - Step 9»(ref-612378-S21479833412014042900000). Lower the vehicle. Operation complete.

Scheme 52

Note. This transmission requires Toyota Genuine ATF WS. After servicing the transmission, you must follow the ATF adjustment procedure. Maintain the vehicle in a horizontal position while adjusting the fluid level.

Scheme 53

Scheme 54

1. BEFORE FILLING TRANSMISSION When you have replaced the entire automatic transmission, automatic transmission oil pan, drain plug, transmission valve body and/or torque converter, proceed to the "TRANSMISSION FILL" procedures. When you have replaced the automatic transmission extension housing oil seal and/or repaired a fluid leak, proceed to the "FLUID TEMPERATURE CHECK" procedures.
2. FILL TRANSMISSION PAN WITH FLUID Lift the vehicle. NOTE: Set the vehicle on a lift so that the vehicle is kept level when it is lifted up (make sure that the tilt angle from the front to rear of the vehicle is within +/- 1°). Remove the No. 2 engine under cover. Refer to «REMOVAL [07/2013 - ]»(ref-612378-S28868806042014042900000). Remove the refill plug with O-ring, overflow plug and gasket. TEXT IN ILLUSTRATION *1 Refill Plug *2 Overflow Plug *a Refill Hole Fill the transmission through the refill hole until fluid begins to trickle out of the overflow tube. TEXT IN ILLUSTRATION *1 Overflow Tube *a Specified Fluid Level Wait until the fluid flow slows and only drops come out. Temporarily install the overflow plug and gasket. HINT: Reuse the old gasket. The overflow plug will be removed again to adjust the fluid level. Fill the transmission with the amount of fluid listed in the table below. Reference Capacity Performed Repair Fill Amount Automatic transmission oil pan and drain plug removal/installation 2.0 liters (2.1 US qts, 1.8 Imp. qts) Transmission valve body removal/installation 3.0 liters (3.2 US qts, 2.6 Imp. qts) Torque converter removal/installation 4.5 liters (4.8 US qts, 4.0 Imp. qts) HINT: If you cannot fill the listed amount of fluid, perform the following: Temporarily install the refill plug with O-ring. HINT: Reuse the old O-ring. The refill plug will be removed again to adjust the fluid level. Start the engine and idle it. NOTE: Check that electrical systems such as the air conditioning system, audio system and lighting system are off. Slowly move the shift lever from P to M. Then return the shift lever to P. HINT: Slowly move the shift lever to circulate the fluid through each part of the transmission. Wait for 30 seconds with the engine idling. Stop the engine. Remove the refill plug with O-ring. Fill the transmission with the remaining fluid until the amount in the table has been filled. Temporarily install the refill plug with O-ring. HINT: Reuse the old O-ring. The refill plug will be removed again to adjust the fluid level. Lower the vehicle.
3. FLUID TEMPERATURE CHECK NOTE: The ATF temperature can be confirmed by using the Techstream. Turn the ignition switch OFF. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Enter the following menus: Powertrain / ECT / Data List / A/T Oil Temperature 1. Check the ATF temperature. NOTE: If the ATF temperature is higher than 42°C (108°F), turn the ignition switch OFF and wait until the fluid temperature drops to below 42°C (108°F).
4. FLUID LEVEL CHECK WARNING: It is necessary to change to temperature detection mode in order to idle the vehicle appropriately. The ATF temperature must be between 42 and 47°C (108 and 117°F) to accurately check the fluid level. When using the Techstream: Enter the following menus: Powertrain / ECT / Active Test / Connect the TC and TE1. When not using the Techstream: Using SST, connect terminals 13 (TC) and 4 (CG) of the DLC3. TEXT IN ILLUSTRATION *a Front view of DLC3 SST: 09843-18040 Start the engine and idle it. NOTE: Check that electrical systems such as the air conditioning system, audio system and lighting system are off. Slowly move the shift lever from P to M. Then return the shift lever to P. HINT: Slowly move the shift lever to circulate the fluid through each part of the transmission. Move the shift lever to D, and then quickly move it back and forth between N and D (once within 1.5 seconds) for at least 6 seconds. This will activate the fluid temperature detection mode. Standard condition When switching to the oil temperature detecting mode, regardless of the shift position, the indicator lights [<--] and [↓] turn on for 2 seconds, and then go off. When using the Techstream: Return the shift lever to P and terminate the Active Test on the Techstream. When not using the Techstream: Return the shift lever to P and disconnect SST from the DLC3. While watching the state of the indicator lights [<--] and [↓], idle the engine to rise the oil temperature. NOTE: If only the indicator light [<--] turns on or the indicator lights [<--] and [↓] turn on simultaneously, stop the operation. And then, wait until the fluid temperature is lowered and only the indicator light [↓] turns on in the oil temperature detecting mode. Allow the engine to idle until the fluid temperature reaches 42 to 47°C (108 to 117°F). Indicator [D] Indication of ATF Temperature Below Proper Temperature Proper Temperature Higher than Proper Temperature Below 42°C (108°F) 42 to 47°C (108 to 117°F) Higher than 48°C (118°F) Indicator lights [↓] turns on Indicator lights [<--] and [↓] turn on Indicator lights [<--] turns on Remove the overflow plug and gasket with the engine idling. TEXT IN ILLUSTRATION *1 Overflow Tube *a Specified Fluid Level Wait until the overflow slows to a trickle. NOTE: If the fluid does not overflow, perform the following: Remove the refill plug with O-ring. Refill the transmission through the refill hole until fluid begins to trickle out of the overflow tube. Wait until the overflow slows to a trickle. Install the overflow plug and a new gasket. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) Coat a new O-ring with ATF and install it to the refill plug. Install the refill plug with O-ring. Torque: 39 N*m (400 kgf*cm, 29 ft.*lbf) Install the No. 2 engine under cover. Refer to «INSTALLATION [07/2013 - ]»(ref-612378-S24898860662014042900000). Lower the vehicle.
5. COMPLETE Turn the ignition switch OFF. When using the Techstream: Disconnect the Techstream from the DLC3. Inspect for automatic transmission fluid leak.

Scheme 55

Scheme 56

Scheme 57

Scheme 58

1. REMOVE NO. 1 ENGINE UNDER COVER. Refer to «REMOVAL [07/2013 - ] - Step 1»(ref-612378-S00142194672014042900000)
2. REMOVE NO. 2 ENGINE UNDER COVER. Refer to «REMOVAL [07/2013 - ] - Step 2»(ref-612378-S00142194672014042900000)
3. REMOVE TRANSMISSION REVOLUTION SENSOR (NT) Disconnect the transmission revolution sensor connector. TEXT IN ILLUSTRATION *1 O-ring Remove the bolt and the transmission revolution sensor (NT). Remove the O-ring from the transmission revolution sensor (NT).
4. REMOVE FRONT EXHAUST PIPE ASSEMBLY Refer to «REMOVAL [07/2013 - ]»(ref-612378-S28868806042014042900000)
5. REMOVE FLOOR SHIFT GEAR SHIFTING ROD SUB-ASSEMBLY See step 18
6. REMOVE TRANSMISSION REVOLUTION SENSOR (SP2) Disconnect the transmission revolution sensor connector. TEXT IN ILLUSTRATION *1 O-ring Remove the bolt and the transmission revolution sensor (SP2). Remove the O-ring from the transmission revolution sensor (SP2).

Scheme 59

1. INSPECT TRANSMISSION REVOLUTION SENSOR (NT) Measure the resistance according to the value(s) in the table below. TEXT IN ILLUSTRATION *a Component without harness connected (Transmission Revolution Sensor (NT)) Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 560 to 680 ohms If the result is not as specified, replace the transmission revolution sensor (NT).
2. INSPECT TRANSMISSION REVOLUTION SENSOR (SP2) Measure the resistance according to the value(s) in the table below. TEXT IN ILLUSTRATION *a Component without harness connected (Transmission Revolution Sensor (SP2)) Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 560 to 680 ohms If the result is not as specified, replace the transmission revolution sensor (SP2).
