Engine Control System - Tests W/codes - Introduction: Diagnosis Saturn SL II

SCAN TOOL DISPLAY

Note. OBD II vehicles have options available in the scan tool DTC mode to display enhanced information available. However, to fully utilize information and procedures requires the use of a Tech 1 or Tech 2 scan tool. See scan tool operator's manual for additional information.

The following are Tech 1 or Tech 2 scan tool sub-menus in the DTC INFO and SPECIFIC DTC modes

1. DTC INFO MODE Used to search for specific type of stored DTC information. There are 7 choices in this mode. Technician may be instructed to test DTCs in a certain manner. Follow the affected DTC test procedures. To get complete description of any status, hit ENTER key before pressing the desired "F" key.
2. DTC STATUS This selection will display any DTCs that have not run during the current ignition cycle or have reported a test failure during this ignition up to a maximum of 33 DTCs. A DTC test that runs and passes will cause affected DTC to be removed from scan tool screen.
3. FAIL THIS IGN. This selection will display all DTCs that have failed during the present ignition cycle.
4. HISTORY This selection will display only DTCs that are stored in the control module's history memory. It will not display type "D" DTCs. It will display all type "A" and type "B" DTCs that have the MIL illuminated and have failed within the last 40 warm-up cycles. It will also display type "C" DTCs that have failed within the 40 warm-up cycles.
5. LAST TEST FAIL This selection will only display DTCs that have failed the last time the test ran. If type "A" or "B" DTCs are displayed, the last test may have ran during the previous ignition cycle. For type "C" DTCs, the last failure must have occurred during the current ignition cycle to be displayed as LAST TEST FAIL.
6. MIL REQUEST This selection will only display DTCs that are requesting MIL illumination. Type "C" DTCs cannot be displayed using this option. This selection will report type "B" DTCs only after MIL illumination has been requested.
7. NOT RUN SCC Not Run Since Code Clear option will display up to 33 DTCs that have not run since DTCs were last cleared. Since any displayed DTCs have not run, their condition (passing or failing) is unknown.
8. TEST FAIL SCC Test Fail Since Code Clear selection will display all active and history DTCs that have reported a test failure since the last time DTCs were cleared. DTCs that last failed over 40 warm-up cycles before this option is selected will not be displayed.
9. FAILED SINCE CLEAR This message indicates the DTC has failed at least once within the last 40 warm-up cycles since the last time DTCs were cleared.
10. NOT RUN SINCE CL. Not Run Since Cleared message indicates that the selected diagnostic test has not run since the last time DTCs were cleared. Therefore, the diagnostic test status (passed or failed) is unknown. After DTCs are cleared, this message will continue to be displayed until the diagnostic test runs.
11. NOT RUN THIS IGN. Not Run This Ignition message indicates the selected diagnostic test has not run this ignition cycle.
12. TEST RAN AND PASSED This message indicates the selected diagnostic test has: Passed the last test. Ran and passed during this ignition cycle. Ran and passed since DTCs were last cleared. Test has not failed since DTCs were last cleared. If this message is displayed, repair is complete. If FAILED THIS IGN. message is displayed, repair is incomplete and further diagnosis is required.

DIAGNOSTIC PROCEDURE

Diagnosis of computerized engine control system should be performed in the following order

1. Ensure all engine systems not related to computer system are operating properly. DO NOT proceed with testing unless all other problems have been repaired. On-Board Diagnostic (OBD) system check must be performed before using specific DTC testing procedure. See «ON-BOARD DIAGNOSTIC (OBD) SYSTEM CHECK»(ref-132811-S27457185922002013000000) .
2. If DTCs were displayed, determine whether codes are hard or intermittent. Hard codes will cause MIL to illuminate continuously while engine is running. See «HARD OR INTERMITTENT TROUBLE CODE DETERMINATION»(ref-132811-S37617504142002013000000) . For diagnosing hard codes, proceed to appropriate DTC test. See DIAGNOSTIC TESTS in appropriate TESTS W/CODES article. For diagnosing intermittent codes, see appropriate TROUBLE SHOOTING - NO CODES article.
3. If no DTCs are present and a driveability problem exists, refer to SYMPTOMS in appropriate TROUBLE SHOOTING - NO CODES article. Doing so will help identify proper system or component to check in appropriate SYSTEM & COMPONENT TESTING article.
4. After necessary repairs are made, clear DTCs, verify vehicle will enter "closed loop" operation and ensure DTC does not reset.

RETRIEVING DIAGNOSTIC TROUBLE CODES

DTCs are retrieved using a Tech 1 or Tech 2 scan tool, or other OBD-II compatible scan tool connected to OBD-II 16-pin Data Link Connector (DLC). See ON-BOARD DIAGNOSTIC (OBD) SYSTEM CHECK. (Scheme 8) DLC is located below left side of dash.

Scheme 8

ON-BOARD DIAGNOSTIC (OBD) SYSTEM CHECK

Note. Tech 1 or Tech 2 scan tool is required to perform OBD system check.

The OBD system check determines

1. If Service Engine Soon (SES), also called Malfunction Indicator Light (MIL) operates.
2. If PCM is operating and can recognize a fault.
3. If any DTCs are stored.

After performing procedures in PRELIMINARY INSPECTION & ADJUSTMENTS, BASIC FUEL SYSTEM CHECKS and BASIC IGNITION SYSTEM CHECKS in appropriate BASIC DIAGNOSTIC PROCEDURES article, this is the starting point for utilizing the self-diagnostic system for determining computer-related problems. After performing necessary tests as described in the OBD system check, if no codes are indicated and driveability problems still exist, see appropriate TROUBLE SHOOTING - NO CODES article and SCAN TOOL USAGE .

DIAGNOSTIC TROUBLE CODE (DTC) DEFINITION

Note. Use of Tech 1 or Tech 2 scan tool is required to retrieve DTCs. Refer to user reference manual supplied with scan tool.

HARD OR INTERMITTENT TROUBLE CODE DETERMINATION

During any diagnostic procedure, determine if DTC(s) are hard failure codes or intermittent failure codes. Diagnostic procedures will not always help analyze intermittent codes. To determine hard codes and intermittent codes

1. Enter diagnostic mode. Read and record all stored DTCs. Exit diagnostic mode and clear DTCs. See «CLEARING DIAGNOSTIC TROUBLE CODES (DTCS)»(ref-132811-S16173125722002013000000) .
2. Apply parking brake and place transmission in Neutral or Park. Block drive wheels and start engine. MIL should turn off. Allow engine to reach normal operating temperature and continue to run for 2 minutes and note MIL.
3. If MIL illuminates, enter diagnostic mode. Read and record DTCs. This will reveal hard failure codes. Oxygen sensor related DTCs may require a road test to reset hard failures after DTCs were cleared.
4. If MIL does not illuminate, all stored DTCs were intermittent failures.

Note. DTCs will be recorded at various operating times. Some DTCs require operation of that sensor or switch for 5 seconds; others require operation for 5 minutes or longer at normal operating temperature, vehicle speed and load. Therefore, some DTCs may not set in a service bay operational mode and may require road testing vehicle in order to duplicate conditions under which code will set.

CLEARING DIAGNOSTIC TROUBLE CODES (DTCS)

To clear DTCs from memory, use scan tool, following scan tool manufacturer's instructions. Codes may also be cleared by disconnecting power supply to ECM/PCM/VCM for at least 30 seconds.

Diagnostic Aids

Diagnostic aids are additional tips used to help diagnose trouble codes when inspected circuit is okay. Diagnostic aids may help lead to a definitive solution to trouble code problem.

SPECIAL TOOLS (DIAGNOSTIC)

Note. For scan data values, refer to scan tool manufacturer owner's manual or compare values with a known-good component or vehicle.

Note. A scan tool connected to DLC is used to read DTCs and check voltages in system on serial data line. A scan tool is required to retrieve vehicle information.

Computerized engine control system is most easily diagnosed using scan tool; however, other tools may aid in diagnosing problems. These tools are a tachometer, test light, ohmmeter, digital voltmeter with a 10-megohm input impedance (minimum), vacuum pump, vacuum gauge, fuel injector test light, and jumper wires with appropriate terminal ends and length. A test light, rather than a voltmeter, must be used when indicated by a diagnostic test. In addition, special jumper harnesses or testers may be required by manufacturer to facilitate diagnosis.

SCAN TOOL USAGE

Note. Before connecting scan tool to vehicle, diagnostic system should be checked to determine if system is operating properly and if information received will be accurate. See ON-BOARD DIAGNOSTIC (OBD) SYSTEM CHECK . If vehicle does not pass OBD system check, information received may be invalid.

Scan tool is a specialized tester which, when connected to DLC, can be used to diagnose on-board computer control systems by providing instant access to circuit voltage information without need to crawl under dash or hood to backprobe sensors and connectors.

Scan tool reduces diagnostic time dramatically by furnishing input data (voltage signals) which can be compared to specification parameters. They may also furnish information on output device (solenoids and motors) status. However, status parameters only indicate output signals have been sent to devices by ECM/PCM/VCM; they do not indicate whether devices have responded properly to signal. Verify proper response at output device using a voltmeter or test light.

A problem may exist even if DTCs are not present. About 80 percent of driveability problems occur without setting DTCs. Sensors that are out of calibration will not set a DTC but will cause driveability problems.

Using a scan tool is the easiest method of checking sensor specifications and other data parameters. Scan tool is also useful in finding intermittent wiring problems by wiggling wiring harnesses and connections (key on, engine off) while observing data parameters.

Note. If erroneous voltage signals are suspected, verify tester information using a digital voltmeter and wiring schematic. If non-existent codes are displayed, DO NOT use scan tool for diagnosis. Contact tester manufacturer for additional information.
