Sunroof: Specifications Saab 9-7X I

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Sunroof Module Bolts	10 N.m	89 lb in
Sunroof Motor/Acturtor Screws	3 N.m	27 lb in
Sunroof Trough Screws	1 N.m	9 lb in
Sunroof Window Screws	3 N.m	27 lb in

Fastener Tightening Specifications

Scheme 1: Sunroof Schematics

Scheme 2: Sunroof Component Views

Scheme 4: Sunroof Motor

Connector Part Information OEM: 7283-5909-40 Service: 88988798 Description: 10-Way F 1.5 Series Unsealed (L-GY)
Terminal Part Information Pins: 1-3, 5-6, 10 Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Sunroof Motor Connector Parts Information

Pin	Wire Color	Circuit No.	Function
1	BK/PU	1150	Ground
2	BN	128	Sunroof Switch Low Reference
3	PU	1353	RAP Supply Voltage
4			Not Used
5	WH	100	Sunroof Switch Open Signal
6	YE/RD	1840	Battery Positive Voltage
7-9			Not Used
10	L-BU	110	Sunroof Switch Close Signal

Sunroof Motor Connector Terminal Identification

Scheme 5: Sunroof Switch

Connector Part Information OEM: 12191825 Service: 15306048 Description: 8-Way F GT 280 Series Unsealed (BN)
Terminal Part Information Pins: A-C, F-G Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Sunroof Switch Connector Parts Information

Pin	Wire Color	Circuit No.	Function
A	D-BU	128	Sunroof Switch Low Reference
B	BN/WH	230	Instrument Panel Lamps Dimming Control
C	BK	1350	Ground
D-E			Not Used
F	OG	110	Sunroof Switch Close Signal
G	BN	100	Sunroof Switch Open Signal
H			Not Used

Sunroof Switch Connector Terminal Identification
