Test Description
The numbers below refer to the step numbers on the diagnostic table.
- 3: This step is used to determine the correct diagnostic path. The path depends on if the sunroof is inoperative and in the open position, or if the sunroof is inoperative and in the closed position.
- 4: This step tests the sunroof switch open switch.
- 7: This step tests the sunroof switch close switch.
| Step | Action | Value(s) | Yes | No |
|---|---|---|---|---|
| Schematic Reference: Sunroof Schematics Connector End View Reference: Sunroof Connector End Views | ||||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle | |
| 2 | Attempt to operate the sunroof through its full range of functions in order to verify that the power sunroof inoperative fault is present. Does the power sunroof system operate normally? | Go to Testing for Intermittent Conditions and Poor Connections | Go to Step 3 | |
| 3 | Is the sunroof in the fully closed position? | Go to Step 4 | Go to Step 7 | |
| 4 | Disconnect the sunroof switch. Turn ON the ignition, with the engine OFF. Connect a 3-amp fused jumper wire to the low reference circuit of the sunroof switch harness connector. Connect the other end of the 3-amp fused jumper wire to the sunroof switch open signal circuit of the sunroof switch harness connector, for 3 seconds. Did the sunroof open? | Go to Step 17 | Go to Step 5 | |
| 5 | Disconnect the 3-amp fused jumper wire. Measure the voltage from the sunroof switch open signal circuit of the sunroof switch harness connector to the low reference circuit of the sunroof switch harness connector. Does the voltage measure near the specified value? | B+ | Go to Step 13 | Go to Step 6 |
| 6 | Measure the voltage from the sunroof switch open signal circuit of the sunroof switch harness connector to a good ground. Does the voltage measure near the specified value? | B+ | Go to Step 14 | Go to Step 10 |
| 7 | Disconnect the sunroof switch. Turn ON the ignition, with the engine OFF. Connect a 3-amp fused jumper wire to the low reference circuit of the sunroof switch harness connector. Connect the other end of the 3-amp fused jumper wire to the sunroof switch close signal circuit of the sunroof switch harness connector, for 3 seconds. Did the sunroof close? | Go to Step 17 | Go to Step 8 | |
| 8 | Disconnect the 3-amp fused jumper wire. Measure the voltage from the sunroof switch close signal circuit of the sunroof switch harness connector to the low reference circuit of the sunroof switch harness connector. Does the voltage measure near the specified value? | B+ | Go to Step 15 | Go to Step 9 |
| 9 | Measure the voltage from the sunroof switch close signal circuit of the sunroof switch harness connector to a good ground. Does the voltage measure near the specified value? | B+ | Go to Step 14 | Go to Step 10 |
| 10 | Disconnect the sunroof motor harness connector. Measure the voltage from the battery positive voltage circuit of the sunroof motor harness connector to a good ground. Does the voltage measure near the specified value? | B+ | Go to Step 11 | Go to Step 19 |
| 11 | Measure the voltage from the retained accessory power (RAP) supply voltage circuit of the sunroof motor harness connector to a good ground. Does the voltage measure near the specified value? | B+ | Go to Step 12 | Go to Retained Accessory Power (RAP) Inoperative |
| 12 | Turn OFF the ignition. Measure the resistance from the ground circuit of the sunroof motor harness connector to a good ground. Does the resistance measure less than or equal to the specified value? | 5 ohms | Go to Step 16 | Go to Step 20 |
| 13 | Test the sunroof switch close signal circuit for a short to ground. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 23 | Go to Step 18 | |
| 14 | Test the sunroof switch low reference circuit for an open. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 23 | Go to Step 18 | |
| 15 | Test the sunroof switch open signal circuit for a short to ground. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 23 | Go to Step 18 | |
| 16 | Test the appropriate sunroof switch signal circuit for an open. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 23 | Go to Step 18 | |
| 17 | Inspect for poor connections at the harness connector of the sunroof switch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 23 | Go to Step 21 | |
| 18 | Inspect for poor connections at the harness connectors of the sunroof motor. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 23 | Go to Step 22 | |
| 19 | Repair the short to ground or open in the sunroof motor battery positive voltage circuit. Refer to Wiring Repairs and Connector Repairs . Did you complete the repair? | Go to Step 23 | ||
| 20 | Repair the open in the sunroof motor ground circuit. Refer to Wiring Repairs and Connector Repairs . Did you complete the repair? | Go to Step 23 | ||
| 21 | Replace the sunroof switch. Refer to Sunroof Switch Replacement . Did you complete the replacement? | Go to Step 23 | ||
| 22 | Replace the sunroof motor. Refer to Control Module References for replacement, setup, and programming. Did you complete the replacement? | Go to Step 23 | ||
| 23 | Operate the system in order to verify the repair. Did you find and correct the condition? | System OK | Go to Step 2 | |
Power Sunroof Inoperative
Perform the Initialization/Teach Process any time a new sunroof motor actuator is installed in the vehicle or any time an existing sunroof motor actuator is removed from the vehicle. Refer to Sunroof Motor/Actuator Initialization/Teach Process .
Parallel positioning of the window track guides or lift mechanism and cable is crucial to the proper function of the system. If the guides are misaligned, refer to Sunroof Track Timing/Synchronization .
Parallel positioning of the window track guides or lift mechanism and cable is crucial to the proper function of the system. If the guides are misaligned, refer to Sunroof Track Timing/Synchronization .
Perform the Initialization/Teach Process any time a new sunroof motor actuator is installed in the vehicle or any time an existing sunroof motor actuator is removed from the vehicle. Refer to Sunroof Motor/Actuator Initialization/Teach Process .
Perform the Initialization/Teach Process any time a new sunroof motor actuator is installed in the vehicle or any time an existing sunroof motor actuator is removed from the vehicle. Refer to Sunroof Motor/Actuator Initialization/Teach Process .
Perform the Initialization/Teach Process any time a new sunroof motor actuator is installed in the vehicle or any time an existing sunroof motor actuator is removed from the vehicle. Refer to Sunroof Motor/Actuator Initialization/Teach Process .
Perform the Initialization/Teach Process any time a new sunroof motor actuator is installed in the vehicle or any time an existing sunroof motor actuator is removed from the vehicle. Refer to Sunroof Motor/Actuator Initialization/Teach Process .
Scheme 6
Scheme 7
- Lower the headliner. Refer to «Headlining Trim Panel Replacement»(ref-268079-S08507880722007101800000) .
- Disconnect the front sunroof drain hose from the sunroof module front spigot, right or left side, as needed.
- Remove the 2 hose clips securing the drain hose to the cowl panel, right or left side, as needed.
- Remove the 2 hose clips securing the drain hose to the side door frame, right or left side, as needed. IMPORTANT: In order to aid in installation, attach a mechanic's wire to the end of the hose.
- Remove the drain hose from the vehicle, right or left side, as needed. Leave the mechanic's wire behind the instrument panel.
