Sunroof: Removal & Installation Saab 9-7X I

Installation Procedure

1. Attach the mechanic's wire to the drain hose.
2. Route the end of the drain hose through side cowl panel until the paint mark is visible, right or left side, as needed.
3. Install the 2 hose clips securing the drain hose to the side door frame, right or left side, as needed.
4. Install the 2 hose clips securing the drain hose to the cowl panel, right or left side, as needed.
5. Connect the front sunroof drain hose to the sunroof module front spigot, right or left side, as needed.
6. Install the headliner. Refer to «Headlining Trim Panel Replacement»(ref-268079-S08507880722007101800000) .

Scheme 8

Scheme 9

1. Lower the headliner. Refer to «Headlining Trim Panel Replacement»(ref-268079-S08507880722007101800000) .
2. Disconnect the rear sunroof drain hose from the sunroof module rear spigot, right or left side, as needed.
3. Remove the hose clip securing the drain hose to the vehicle, right or left side, as needed.
4. Remove the drain hose from the vehicle, right or left side, as needed.

1. Route the end of the drain hose through the access hole and down the inner side panel, right or left side, as needed.
2. Install the hose clip to the door frame securing the drain hose to the vehicle, right or left side, as needed.
3. Connect the rear drain sunroof hose to the sunroof module rear spigot, right or left side, as needed.
4. Install the headliner. Refer to «Headlining Trim Panel Replacement»(ref-268079-S08507880722007101800000) .

Removal Procedure

Scheme 10

Scheme 11

1. Lower the headliner. Refer to «Headlining Trim Panel Replacement»(ref-268079-S08507880722007101800000) .
2. Disconnect the sunroof harness electrical connector. IMPORTANT: Do not remove the drain hoses.
3. Disconnect the drain hoses from the sunroof assembly. Refer to the following procedures: «Sunroof Housing Front Drain Hose Replacement»(ref-268099-S06694162012007101800000) «Sunroof Housing Rear Drain Hose Replacement»(ref-268099-S25285298142007101800000)
4. Support the sunroof with an assistant.
5. Remove the bolts that retain the sunroof module assembly to the roof panel
6. Remove the sunroof module assembly from the vehicle and place on a clean, prepared surface with an assistant.
7. Remove the sunroof motor/actuator from the sunroof module assembly. Refer to «Sunroof Motor/Actuator Replacement»(ref-268099-S34173610162007101800000) .
8. Remove the sunroof window from the sunroof module assembly. Refer to «Sunroof Window Replacement»(ref-268099-S08047863932007101800000) .
9. Remove the sunroof sunshade panel from the sunroof module assembly. Refer to «Sunroof Sunshade Replacement»(ref-268099-S34889047932007101800000) .

1. Install the sunroof sunshade panel to the sunroof module assembly. Refer to «Sunroof Sunshade Replacement»(ref-268099-S34889047932007101800000) .
2. Install the sunroof window to the sunroof module assembly. Refer to «Sunroof Window Replacement»(ref-268099-S08047863932007101800000) .
3. Install the sunroof motor/actuator to the sunroof module assembly. Refer to «Sunroof Motor/Actuator Replacement»(ref-268099-S34173610162007101800000) .
4. Position the sunroof module assembly to the vehicle with an assistant. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
5. Install the bolts that retain the sunroof module assembly to the roof panel. Tighten: Tighten the bolts to 10 N.m (7 lb ft).
6. Connect the drain hoses to the sunroof module assembly. Refer to the following procedures: «Sunroof Housing Front Drain Hose Replacement»(ref-268099-S06694162012007101800000) «Sunroof Housing Rear Drain Hose Replacement»(ref-268099-S25285298142007101800000)
7. Connect the sunroof harness electrical connector.
8. Install the headliner. Refer to «Headlining Trim Panel Replacement»(ref-268079-S08507880722007101800000) .

1. Align the splines on the sunroof motor/actuator shaft with the drive gear on the sunroof module assembly.
2. Install the sunroof motor/actuator (2) to the mounting bracket, ensuring that the sunroof motor/actuator is fully seated. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
3. Install the screws (1) that retain the sunroof motor/actuator (2) to the mounting bracket. Tighten: Tighten the sunroof motor/actuator screws to 3 N.m (27 lb in).
4. Connect the sunroof motor/actuator wiring harness electrical connector.
5. Install the tie strap retaining the sunroof motor/actuator wiring harness.
6. Install the headliner. Refer to «Headlining Trim Panel Replacement»(ref-268079-S08507880722007101800000) .
7. Press and hold the open switch until the glass panel stalls at the hard stop. The glass panel then moves forward several millimeters. This position is called the soft stop or full open position.
8. Release the switch.
9. Press and hold the open switch within six seconds of step 8, continue holding until the glass panel moves to the closed position and stops.
10. Release the switch.

Scheme 12

Scheme 13

1. Remove the sunroof window. Refer to «Sunroof Window Replacement»(ref-268099-S08047863932007101800000) .
2. Remove the screws (1) that retain the water trough to the sunroof assembly. IMPORTANT: The sunshade must be removed from the top of the vehicle.
3. Remove the water trough from the sunroof assembly from the top of the vehicle.
4. Slide the sunshade forward.
5. Flex the center of the sunshade (2) upward while simultaneously sliding the panel sideways to release the retaining tabs (3) from the track slot (1).
6. Remove the sunshade from the top of the vehicle.

1. Position the sunshade to the vehicle from the top of the vehicle.
2. Install the retaining tabs on one side of the sunshade into the track slot of the sunroof.
3. Flex the center of the sunshade (2) upwards while simultaneously inserting the retaining tabs (3) into the track slot (1).
4. Ensure that the sunshade tabs are fully seated in the track slots, and the sunshade slides smoothly.
5. Install the water trough to the sunroof from the top of the vehicle. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
6. Install the screws (1) that retain the water trough to the sunroof. Tighten: Tighten the screws to 1 N.m (9 lb in).
7. Install the sunroof window. Refer to «Sunroof Window Replacement»(ref-268099-S08047863932007101800000) .

Scheme 14

Scheme 15

1. Remove the overhead console in order to access the sunroof switch. Refer to «Roof Console Replacement»(ref-268082-S40237450432007101800000) .
2. Disconnect the electrical connector from the sunroof switch.
3. With a flat-bladed tool carefully release the tabs that retain the sunroof switch to the overhead console.
4. Remove the sunroof switch from the overhead console.

1. Position the sunroof switch alignment tabs to the slots in the console.
2. Install the sunroof switch into the console, ensuring that the retaining tabs are fully seated.
3. Connect the electrical connector to the sunroof switch.
4. Install the overhead console to the roof. Refer to «Roof Console Replacement»(ref-268082-S40237450432007101800000) .

1. Place the module in the full open position.
2. Remove the headliner. Refer to «Headlining Trim Panel Replacement»(ref-268079-S08507880722007101800000) .
3. Disconnect the electrical connector from the motor/actuator.
4. Remove the motor. Refer to «Sunroof Motor/Actuator Replacement»(ref-268099-S34173610162007101800000) .
5. Push the window guides rearward on the track until the guides are positioned against the rear hard stop.

1. Install the motor. Refer to «Sunroof Motor/Actuator Replacement»(ref-268099-S34173610162007101800000) .
2. Connect the electrical connector to the motor/actuator.
3. Install the headliner. Refer to «Headlining Trim Panel Replacement»(ref-268079-S08507880722007101800000) .
4. Perform the Initialization/Teach Procedure. Refer to «Sunroof Motor/Actuator Initialization/Teach Process»(ref-268099-S41720431212007101800000) .
5. Verify the operation of the sunroof.

Scheme 16

1. Remove the sunroof window. Refer to «Sunroof Window Replacement»(ref-268099-S08047863932007101800000) .
2. Carefully remove the sunroof window weatherstrip from the perimeter of the sunroof window.

1. Carefully install the sunroof window weatherstrip to the perimeter of the sunroof window, ensuring that the weatherstrip is fully seated.
2. Install the sunroof window to the sunroof module assembly. Refer to «Sunroof Window Replacement»(ref-268099-S08047863932007101800000) .
3. Ensure that the sunroof does not have any air or waterleaks.

Scheme 17

1. Open the sunshade panel.
2. Remove the 4 screws (2) that retain the sunroof window (1) to the sunroof module assembly.
3. Remove the sunroof window from the top of the vehicle.

1. Position the sunroof window (1) to the vehicle.
2. Loosely insert the screws (2) that retain the sunroof window (1) to the sunroof module assembly. NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
3. Adjust the sunroof window height so that the window is flush with the roof panel. Tighten: Tighten the screws to 3 N.m (27 lb in).

The Power Sunroof System consists of the following components

1. Sunroof motor/module assembly
2. Sunroof switch
3. Sunroof glass, tilt/slide style, with glass sliding between the headliner and roof
4. Sunshade
5. Rail and track assembly upon which the sunroof glass rides
6. Power supply for the sunroof motor/module assembly: SUNROOF 20-amp fuse for motor operation Sunroof module logic circuitry: Short wheelbase and Envoy XUV-Retained accessory power (RAP) supply voltage is supplied and controlled directly from the body control module (BCM) for the RAP function. Long wheelbase-VENT WDO 20-amp fuse supplies the voltage through the RAP relay, that is controlled by the BCM, for the RAP function.
7. Ground from G306

The sunroof motor/module assembly has 2 power circuits battery positive voltage and the retained accessory power (RAP) supply voltage circuit. The Sunroof 20-amp fuse is hot at all times suppling the battery positive voltage circuit for the operation of the sunroof motor. The RAP supply voltage circuit is for the sunroof module logic circuitry and is controlled from, or by the body control module (BCM), depending on the wiring configuration. The power sunroof will operate with the ignition switch turned to Accessory or RUN suppling RAP supply voltage. Once the ignition switch is turned to OFF the sunroof will continue to operate until any door is open or when the RAP has timed out. For a description and operation of the RAP operation, refer to Retained Accessory Power (RAP) Description and Operation .

Use the rocker type sunroof switch to command the sunroof to

1. Express Open
2. Close
3. Vent

Pressing the sunroof switch rearward, the sunroof glass will slide from

1. Vent position to the closed position
2. Closed position to the open position

Pressing the sunroof switch forward, the sunroof glass will slide from

1. Open position to the closed position
2. Closed position to the vent position
