Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Accelerator Mounting Nut | 11 N.m | 98 lb in |
| Brake Pedal Pivot Bolt | 25 N.m | 19 lb ft |
| Brake Pedal Sensor Bolt | 9 N.m | 80 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Adjustable Pedal Schematics
Scheme 2
Scheme 2: Adjustable Pedal Component Views
| Callout | Component Name |
|---|
| 1 | Electronic Adjustable Pedals (EAP) Relay |
| 2 | C225 |
| 3 | Electronic Adjustable Pedals (EAP) Assembly Connector |
| 4 | Accelerator Pedal Position (APP) Sensor |
Scheme 3
Scheme 3: Electronic Adjustable Pedals (EAP) Assembly
| Connector Part Information OEM: 174923-1 Service: See Catalog Description: 6-Way F AMP Multilock 070 Series (BK) |
|---|
| Terminal Part Information Pins: 1-5 Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Electronic Adjustable Pedals (EAP) Assembly Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | WH | | 5-Volt Reference |
| 2 | PK | | Adjustable Pedals Position Sensor Signal |
| 3 | BN/WH | | Low Reference |
| 4 | D-BU | | Electronic Adjustable Pedals (EAP) Motor Rearward Control |
| 5 | RD | | Electronic Adjustable Pedals (EAP) Motor Forward Control |
| 6 | | | Not Used |
Electronic Adjustable Pedals (EAP) Assembly Connector Terminal Identification
Scheme 4
Scheme 4: Electronic Adjustable Pedals (EAP) Relay
| Connector Part Information OEM: 12059561 Service: 12101847 Description: 6-Way F Metri-Pack 280 480 Series Unsealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Electronic Adjustable Pedals (EAP) Relay Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | PU | | Adjustable Pedals Relay Forward Control |
| B | RD | | Electronic Adjustable Pedals (EAP) Motor Forward Control |
| C | OG | | Battery Positive Voltage |
| D | BK | | Ground |
| E | D-BU | | Electronic Adjustable Pedals (EAP) Motor Rearward Control |
| F | OG/BK | | Adjustable Pedals Relay Rearward Control |
Electronic Adjustable Pedals (EAP) Relay Connector Terminal identification
Scheme 5
Scheme 5: Electronic Adjustable Pedals (EAP) Switch
| Connector Part Information OEM: 12064759 Service: 12117322 Description: 3-Way M Metri-Pack 150 Series Unsealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Electronic Adjustable Pedals (EAP) Switch Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | OG | 5286 | Adjustable Pedals Relay Forward Control |
| B | PK | 5285 | Adjustable Pedals Relay Rearward Control |
| C | BK | 3240 | Battery Positive Voltage |
Electronic Adjustable Pedals (EAP) Switch Connector Terminal Identification
