Vehicle steering
The steering wheel is the first link between the driver and the vehicle. The steering wheel is fastened to a steering shaft within the column. At the lower end of the column, the intermediate shaft connects the column to the steering gear.
The steering column can be adjusted vertically and longitudinally
Vehicle security
Theft deterrent components are mounted and designed into the steering column. The following components allow the column to be locked in order to minimize theft
- The ignition switch
- The steering column lock
- "The ignition cylinder
- The theft deterrent immobilizer module, if equipped
Lock
In order to lock the steering column, the ignition must be in the OFF position. Vehicles with automatic transmission: the gear selector lever must be in the P position to be able to turn OFF the ignition. The Body Control Module (BCM) will then check that the vehicle is stationary and one of the front doors is open. Once these conditions have been met, BCM will send signal to the Steering Column Lock (SCL) to lock.
Unlock
When the ignition button is pressed, the steering column lock (SCL) unlocks if the transponder is approved. If the car has been parked so that the steering column is straining hard on the lock bolt, it may be that the SCL is unable to unlock. The SCL will then send a message on the bus and the Instrument Cluster will instruct the driver via its display to turn the steering wheel and try again.
Driver convenience
The steering wheel and column may also have driver controls attached for convenience and comfort. The following controls may be mounted on the steering wheel or column.
- The turn signal switch
- The headlamp dimmer switch
- The wiper/washer switch
- The horn pad
- The redundant radio/entertainment system controls
- The tilt functions
- The telephone system controls
- The DIC controls
- The cruise control functions
- The automatic transmission manual setting function
Driver safety
The steering wheel and column has safety features to protect the driver. The following components may be mounted on or near the steering column
Energy-Absorbing Steering Column
The energy-absorbing steering column compresses in the event of a front-end collision, which reduces the risk of injury to the driver. The energy-absorbing feature, collapsible steering shaft, and break away mounting features help reduce the injury in the event of an accident.
SIR Coil and Module
For additional information on the operation of the SIR coil and module, refer to SIR SYSTEM DESCRIPTION AND OPERATION .
Steering wheel angle sensor
The steering wheel angle sensor is located under the steering wheel on the contact roller for the airbag. The sensor measures the position of the steering wheel and the speed at which it is rotated. A signal representing this measurement is provided to the vehicle stability enhancement system (VSES) in the ABS module and to the variable effort steering (VES) system.
The theft deterrent immobilizer module
The immobilizer module is mounted in the steering column lock on cars without Passive Entry Passive Start system (PEPS). Refer to CONTENT THEFT DETERRENT (CTD) DESCRIPTION AND OPERATION .
| DTC | Description |
|---|---|
| DTC B1023 | Internal Switch Fault |
| DTC B144C | Inverted RUN/CRANK Relay Circuit |
| DTC B2515 | Steering Column Lock Motor, Feedback Circuit Not Reasonable |
| DTC B2897 | Steering Column Lock Motor, Locking Circuit |
| DTC B305A | Steering Column Lock, No Communication |
| DTC B2910 | Steering Column Lock, Incorrect Code |
STEERING COLUMN ASSEMBLY DTC INDEX
In order to lock the steering column, the ignition must be in the OFF position. Vehicles with automatic transmission: the gear selector lever must be in the P position to be able to turn OFF the ignition. The Body Control Module (BCM) will then check that the vehicle is stationary and one of the front doors is open. Once these conditions have been met, BCM will send signal to the Steering Column Lock (SCL) to lock.
When the ignition button is pressed, the steering column lock (SCL) unlocks if the transponder is approved. If the car has been parked so that the steering column is straining hard on the lock bolt, it may be that the SCL is unable to unlock. The SCL will then send a message on the bus and the Instrument Cluster will instruct the driver via its display to turn the steering wheel and try again.
Electrical Information Reference
- «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
- «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
- «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
- «WIRING REPAIRS»(ref-653659-S03227166852014090100000)
Circuit/System Verification
Perform the programming and setting procedure for the control module in question. Confirm that the DTC was not set again after programming.
==> If the DTC is set again, replace the control module in question.
Repair Instructions
Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.
- «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for steering column lock control module replacement, setup and programming.
- «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
- «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
- «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
- «WIRING REPAIRS»(ref-653659-S03227166852014090100000)
- Ignition OFF, remove the KR73 RUN/CRANK relay.
- Ignition ON, connect a test lamp between pin 4 (87A) and ground. Check that the test lamp does not illuminate. ==> If the test lamp illuminates, test the circuit for a short to battery. If the test values are normal, replace the K60 steering column lock control module.
- Connect the test lamp between pin 3 (30) and ground. Check that the test lamp illuminates. ==> If the lamp does not illuminate, check the circuit for an open circuit or high resistance.
- Ignition OFF, disconnect the connector to the K60 steering column lock control module.
- Connect a test lamp between pin 3 and ground.
- Ignition ON, bridge with a 5 A fuse between pins 3 (30) and 4 (87A). Check that the test lamp illuminates. ==> If the test lamp does not light and the fuse is intact, check the circuit for break/high resistance. ==> If the test lamp does not illuminate and the fuse has blown, test the circuit for a short to ground. If the test result is normal, replace the K60 steering column lock control module.
- If all the test results are normal, check or replace the RUN/CRANK relay KR73
Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.
- «RELAY REPLACEMENT (ATTACHED TO WIRE HARNESS)»(ref-653659-S31726074922014090100000) .
- «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for steering column lock control module replacement, setup and programming.
- «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
- «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
- «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
- «WIRING REPAIRS»(ref-653659-S03227166852014090100000)
Delete all DTCs and operate the steering column lock control module within the conditions indicated by the DTC. The DTC must not be set.
==> If the DTC is set, replace the steering column lock control module K60 or body control module K9.
Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.
- «STEERING COLUMN REPLACEMENT»(ref-653651-S05260936292014090100000)
- «BODY CONTROL MODULE REPLACEMENT (RIGHT HAND DRIVE)»(ref-653639-S28483150132014090100000) or «BODY CONTROL MODULE REPLACEMENT (LEFT HAND DRIVE)»(ref-653639-S00602260772014090100000)
- «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000)
In order to lock the steering column, the ignition must be in the OFF position. Vehicles with automatic transmission: the gear selector lever must be in the P position to be able to turn OFF the ignition. The Body Control Module (BCM) will then check that the vehicle is stationary and one of the front doors is open. Once these conditions have been met, BCM will send signal to the Steering Column Lock (SCL) to lock.
When the ignition button is pressed, the steering column lock (SCL) unlocks if the transponder is approved. If the car has been parked so that the steering column is straining hard on the lock bolt, it may be that the SCL is unable to unlock. The SCL will then send a message on the bus and the Instrument Cluster will instruct the driver via its display to turn the steering wheel and try again.
- «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
- «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
- «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
- «WIRING REPAIRS»(ref-653659-S03227166852014090100000)
- Ignition OFF, disconnect the connector on the K60 steering column lock control module.
- Measure the resistance between pins 6 and 7 in the female connector. The value should be less than 10 ohms. ==> If the resistance is higher than 10 ohms, check the circuit for an open circuit or high resistance.
- Connect the test lamp between pin 5 and ground. Check that the test lamp illuminates. ==> If the lamp does not illuminate, check the circuit for a short to battery or an open circuit/high resistance.
- Connect a test lamp between pin 3 in the female connector and ground, the lamp should illuminate. ==> If the lamp does not illuminate, check the circuit for a short to battery or an open circuit/high resistance.
- Measure the voltage between pin 4 and ground. The voltage should be less than 0.3 V. ==> If the voltage is higher than 0.3 V, check the circuit for a short to battery.
- Disconnect the connector on the K84 keyless entry control module.
- Measure the resistance between pin 4 on the K60 steering column lock control module and pin 1 on the K84 keyless entry control module. The resistance should not exceed 5 ohms. ==> If the resistance is higher than 5 ohms, check the circuit for an open circuit or high resistance.
- If all the test results are normal, test or replace the K60 steering column lock control module. If the DTC returns, replace the K84 keyless entry control module
Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.
- «CONTROL MODULE, REFERENCES»(ref-653639-S11210668452014090100000) for replacement, set-up and programming of the steering column lock control module or keyless entry control module.
In order to lock the steering column, the ignition must be in the OFF position. Vehicles with automatic transmission: the gear selector lever must be in the P position to be able to turn OFF the ignition. The Body Control Module (BCM) will then check that the vehicle is stationary and one of the front doors is open. Once these conditions have been met, BCM will send signal to the Steering Column Lock (SCL) to lock.
When the ignition button is pressed, the steering column lock (SCL) unlocks if the transponder is approved. If the car has been parked so that the steering column is straining hard on the lock bolt, it may be that the SCL is unable to unlock. The SCL will then send a message on the bus and the Instrument Cluster will instruct the driver via its display to turn the steering wheel and try again.
- «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
- «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
- «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
- «WIRING REPAIRS»(ref-653659-S03227166852014090100000)
Delete all DTCs and operate the steering column lock control module within the conditions indicated by the DTC. The DTC must not be set.
==> If the DTC is set, replace the steering column lock control module K60 or body control module K9.
Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.
- «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for steering column lock control module replacement, setup and programming.
In order to lock the steering column, the ignition must be in the OFF position. Vehicles with automatic transmission: the gear selector lever must be in the P position to be able to turn OFF the ignition. The Body Control Module (BCM) will then check that the vehicle is stationary and one of the front doors is open. Once these conditions have been met, BCM will send signal to the Steering Column Lock (SCL) to lock.
When the ignition button is pressed, the steering column lock (SCL) unlocks if the transponder is approved. If the car has been parked so that the steering column is straining hard on the lock bolt, it may be that the SCL is unable to unlock. The SCL will then send a message on the bus and the Instrument Cluster will instruct the driver via its display to turn the steering wheel and try again.
- «CIRCUIT TESTING»(ref-653659-S30091259062014090100000)
- «CONNECTOR REPAIRS»(ref-653659-S33681896522014090100000)
- «TESTING FOR INTERMITTENT CONDITIONS AND POOR CONNECTIONS»(ref-653659-S19761557662014090100000)
- «WIRING REPAIRS»(ref-653659-S03227166852014090100000)
Perform the programming and setting procedure for the control module in question. Confirm that the DTC was not set again after programming.
==> If the DTC is set again, replace the control module in question.
Perform the DIAGNOSTIC REPAIR VERIFICATION after completing the diagnostic procedure.
- «CONTROL MODULE REFERENCES»(ref-653639-S11210668452014090100000) for steering column lock control module replacement, setup and programming.
Symptoms - Steering Wheel and Column
Review the system description and operation in order to familiarize yourself with the system functions. See HYDRAULIC POWER STEERING SYSTEM, DESCRIPTION AND FUNCTION .
High Telescoping Effort
| Checks | Action |
|---|---|
| The steering shaft assembly is bent or damaged. | If necessary, replace the steering column. Refer to STEERING COLUMN REPLACEMENT . |
Looseness in Steering Column
| Step | Action | Yes | No |
|---|---|---|---|
| 1 | Did you review the Steering Wheel and Column Description and Operation and perform the necessary inspections? | Go to Step 2 | Go to STEERING WHEEL AND COLUMN DESCRIPTION AND OPERATION |
| 2 | Verify that the steering column is loose. Is the steering column loose? | Go to Step 3 | System OK |
| 3 | Inspect the steering column mounting features for the following conditions: Steering column mounting fasteners for looseness Steering column mounting features are sheared Are the steering column mounting features loose? | Go to Step 5 | Go to Step 4 |
| 4 | Inspect the upper and/or lower bearings for looseness. Are any of the bearings worn or loose? | Go to Step 6 | Go to Step 7 |
| 5 | NOTE: If the steering column mounting feature is damaged or sheared, the steering column will need to be replaced. Refer to STEERING COLUMN REPLACEMENT . Tighten the steering column mounting fastener to specifications. Refer to FASTENER TIGHTENING SPECIFICATIONS .Did you complete the repair? | Go to Step 7 | |
| 6 | NOTE: If the steering column upper and/or lower bearings are not serviceable, the steering column will need to be replaced. Refer to STEERING COLUMN REPLACEMENT . Replace the upper and/or lower bearings, if serviceable.Did you complete the repair? | Go to Step 7 | |
| 7 | Operate the steering column in order to verify the repair. Did you correct the condition? | System OK | Go to Step 3 |
| NOTE |
|---|
| If the steering column mounting feature is damaged or sheared, the steering column will need to be replaced. Refer to STEERING COLUMN REPLACEMENT . |
| NOTE |
|---|
| If the steering column upper and/or lower bearings are not serviceable, the steering column will need to be replaced. Refer to STEERING COLUMN REPLACEMENT . |
| Object code - ID | Description | Condition | Model year | Correction | Pos | Time (hrs) |
|---|---|---|---|---|---|---|
| 64110-01 | Steering wheel | 2010 | 01 | 0.2 | ||
| 64123-01 | Steering wheel member | 2010 | 01 | 3.9 | ||
| 64126-01 | Steering wheel bearing cover, lower part | 2010 | 01 | 0.2 | ||
| 64130-01 | Steering column assembly, comp. | Calibration not included | 2010 | 01 | 1.0 | |
| 64135-01 | Intermediate shaft, comp. | 2010 | 01 | 0.3 | ||
| 64139-01 | Lock housing, steering wheel lock | 2010 | 01 | 0.1 | ||
| 64199-01 | Bearing housing | 2010 | 01 | 0.4 | ||
| 64311-01 | Tie Rod | Measure wheel angles, 4-wheel measurement not included | 2010 | 01 | 0304 | 0.5 |
| 64311-02 | Tie Rod | Measure wheel angles, 4-wheel measurement not included | 2010 | 01 | 05 | 0.9 |
| 64312-01 | Rubber gaiter | Measure wheel angles, 4-wheel measurement not included | 2010 | 01 | 05 | 0.5 |
| 64312-02 | Rubber gaiter | Measure wheel angles, 4-wheel measurement not included | 2010 | 01 | 0304 | 0.3 |
| 64320-01 | Tie Rod End | Measure wheel angles, 4-wheel measurement not included | 2010 | 01 | 0304 | 0.2 |
| 64320-02 | Tie Rod End | Measure wheel angles, 4-wheel measurement not included | 2010 | 01 | 05 | 0.4 |
Correction
- 01 - Replacement
- 02 - Removal - Refit
- 03 - Renovate
- 04 - Paint
- 05 - Adjust
- 06 - Change comp. unit
- 07 - Lubricate - Clean - Polish
- 08 - Check/Fault search
- 09 - Expose
- 10 - Install new
- 11 - Transfer
Steering Column Lock Control Module Programming and Setup
The following service procedures require either a programming or a setup event performed for a complete repair.
Steering Column Lock Control Module Reprogramming
If the steering column lock control module needs to be reprogrammed, the following procedures must be performed
Connect a scan tool to the vehicle and access SPS.
Perform the SPS function Steering Column Lock Control Module - Programming and follow the on-screen instructions.
Clear DTCs after completing the programming procedure.
Master Electrical Component List
Link to end views of connectors: COMPONENT CONNECTOR END VIEWS . Linear wiring stem, end view of connectors.
| Code | Name | Option | Location | Locator View |
|---|---|---|---|---|
| A10 | Inside Rearview Mirror | In the passenger compartment, mounted to top center of windshield | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| A11 | Radio | In the passenger compartment, on the center of the instrument panel, above the center console | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| A12 | Digital Radio Receiver Control Module | U2K or UBT | In the passenger compartment behind the center of the Instrument Panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| A13 | Rear Audio Control Module | ULD | In the passenger compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| A20 | Radio/HVAC Controls | In the passenger compartment, in the center console, below of the radio controls | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| A23D | Door Latch Assembly - Driver | In the passenger compartment, at the rear of the driver door | DOOR COMPONENT VIEWS | |
| A23LR | Door Latch Assembly - Left Rear | In the passenger compartment, at the rear of the left rear door | DOOR COMPONENT VIEWS | |
| A23P | Door Latch Assembly - Passenger | In the passenger compartment, at the rear of the passenger door | DOOR COMPONENT VIEWS | |
| A23RR | Door Latch Assembly - Right Rear | In the passenger compartment, at the rear of the right rear door | DOOR COMPONENT VIEWS | |
| A25A | Glow Plug/Pressure Sensor Cylinder 1 Assembly | LBS | In the engine compartment on top of the engine near the number 1 cylinder | POWERTRAIN COMPONENT VIEWS |
| A25B | Glow Plug/Pressure Sensor Cylinder 2 Assembly | LBS | In the engine compartment on top of the engine near the number 2 cylinder | POWERTRAIN COMPONENT VIEWS |
| A25C | Glow Plug/Pressure Sensor Cylinder 3 Assembly | LBS | In the engine compartment on top of the engine near the number 3 cylinder | POWERTRAIN COMPONENT VIEWS |
| A25D | Glow Plug/Pressure Sensor Cylinder 4 Assembly | LBS | In the engine compartment on top of the engine near the number 4 cylinder | POWERTRAIN COMPONENT VIEWS |
| A7 | Fuel Pump and Level Sensor Assembly | Under the vehicle, in the fuel tank | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| A9A | Outside Rearview Mirror - Driver | Left side of the vehicle, on the outside of the driver door | DOOR COMPONENT VIEWS | |
| A9B | Outside Rearview Mirror - Passenger | Right side of the vehicle, on the outside of the passenger door | DOOR COMPONENT VIEWS | |
| B1 | A/C Refrigerant Pressure Sensor | At front of vehicle, at right side of condenser | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B10B | Ambient Light/Sunload Sensor | In the passenger compartment, in the center instrument panel speaker grill | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| B107 | Accelerator Pedal Position Sensor | In the passenger compartment, below the instrument panel on the driver side, mounted to the top of the accelerator pedal assembly | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| B108 | Air Quality Sensor | At front of vehicle, under cowling | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B116 | Water in Fuel Sensor | LBS | Under the vehicle, in the fuel tank | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B117 | Rain Sensor | CE1 | Top center of the windshield | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| B119 | Multi-Axis Acceleration Sensor | In the passenger compartment, mounted to the floor, under floor console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B12A | Transmission Fluid Pressure Manual Valve Position Switch | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| B129 | Cruise Control Vehicle Distance Sensor Module | KSG | At front of vehicle, behind grille | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B13 | Transmission Fluid Temperature Sensor | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| B14A | Transmission Output Shaft Speed Sensor | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| B14C | Transmission Input Shaft Speed Sensor | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| B15 | Transmission Internal Mode Switch | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| B150 | Fuel Tank Pressure | NT7 | Under the rear of the vehicle, on top of the fuel tank, mounted to the fuel pump and sender assembly | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B150 | Fuel Tank Pressure | NU6 | Under the rear of the vehicle, on top of the fuel tank, mounted to the fuel pump and sender assembly | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B153D | Seat Belt Buckle - Driver | In the passenger compartment, mounted to the inboard side of seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B153P | Seat Belt Buckle - Passenger | In the passenger compartment, mounted to the inboard side of seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B16 | Backup Lamp Switch | MR6 or MK6 | Front of the transmission | POWERTRAIN COMPONENT VIEWS |
| B160 | Windscreen Temperature and Inside Moisture Sensor | ASV | Top center of the windshield | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| B161LF | Vertical Suspension Acceleration Sensor - Left Front | F45 | Near the top of the left front steering knuckle | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B161RF | Vertical Suspension Acceleration Sensor - Right Front | F45 | Near the top of the right front steering knuckle | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B162LF | Vertical Body Acceleration Sensor - Left Front | F45 | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B162R | Vertical Body Acceleration Sensor - Rear | F45 | In the rear compartment, rearward of left rear seat | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B162RF | Vertical Body Acceleration Sensor - Right Front | F45 | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B166LF | Parking Aid Side Sensor - Left Front | UD5 or UDP | At front of vehicle, mounted to front bumper cover, on left side | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B166RF | Parking Aid Side Sensor - Right Front | UD5 or UDP | At front of vehicle, mounted to front bumper cover, on right side | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B18 | Battery Current Sensor | At front of vehicle, mounted to battery (-) cable | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B19B | Brake Booster Vacuum Sensor | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B19C | Brake Booster Vacuum Switch | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B5LF | Wheel Speed Sensor - Left Front | Mounted to the left front steering knuckle assembly | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| B5LR | Wheel Speed Sensor - Left Rear | Mounted to the left rear upper control arm | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| B5RF | Wheel Speed Sensor - Right Front | Mounted to the right front steering knuckle assembly | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| B5RR | Wheel Speed Sensor - Right Rear | Mounted to the right rear upper control arm | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| B7B | Air Temperature Sensor - Duct Lower | In the passenger compartment, mounted to the HVAC module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| B7F | Air Temperature Sensor - Duct Upper | In the passenger compartment, mounted to the HVAC module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| B9 | Ambient Air Temperature Sensor | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B20 | Brake Fluid Level Switch | At front of vehicle, mounted to brake fluid reservoir | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B22 | Brake Pedal Position Sensor | In the passenger compartment, below the instrument panel, in the driver side footwell, near the top of the accelerator pedal assembly | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| B23A | Camshaft Position Sensor - Bank 1 Exhaust | LAU | Rear of the engine, left side of the engine block | POWERTRAIN COMPONENT VIEWS |
| B23B | Camshaft Position Sensor - Bank 1 Intake | LAU | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS |
| B23C | Camshaft Position Sensor - Bank 2 Exhaust | LAU | Rear of the engine, at the right side | POWERTRAIN COMPONENT VIEWS |
| B23D | Camshaft Position Sensor - Bank 2 Intake | LAU | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS |
| B23E | Camshaft Position Sensor - Exhaust | LDK | In the engine compartment, left side of engine | POWERTRAIN COMPONENT VIEWS |
| B23F | Camshaft Position Sensor - Intake | LDK | In the engine compartment, left side of engine | POWERTRAIN COMPONENT VIEWS |
| B23 | Camshaft Position Sensor | LBS | In the engine compartment, left side of engine | POWERTRAIN COMPONENT VIEWS |
| B24 | Cellular Phone Microphone | UE1 or UPH or UPJ | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B25B | Clutch Pedal Position Sensor | MR6 or MK6 | In the passenger compartment, below the instrument panel, in the driver side footwell, near the top of the clutch pedal assembly | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| B26 | Crankshaft Position Sensor | In the engine compartment, on the lower left front of the engine | POWERTRAIN COMPONENT VIEWS | |
| B27A | Door Handle Switch - Driver Exterior | ATH | In the passenger compartment, at the driver door handle | DOOR COMPONENT VIEWS |
| B27B | Door Handle Switch - Passenger Exterior | ATH | In the passenger compartment, at the passenger door handle | DOOR COMPONENT VIEWS |
| B27E | Door Handle Switch - Driver Interior | ATH | On the driver door, trim panel | DOOR COMPONENT VIEWS |
| B27F | Door Handle Switch - Passenger Interior | ATH | On the passenger door, trim panel | DOOR COMPONENT VIEWS |
| B27LR | Door Handle Switch - Left Rear Exterior | ATH | In the passenger compartment, at the left rear door handle | DOOR COMPONENT VIEWS |
| B27RR | Door Handle Switch - Right Rear Exterior | ATH | In the passenger compartment, at the right rear door handle | DOOR COMPONENT VIEWS |
| B34 | Engine Coolant Temperature Sensor | In the engine compartment, left side of engine | POWERTRAIN COMPONENT VIEWS | |
| B35B | Engine Oil Level Sensor | Bottom center of the engine oil pan | POWERTRAIN COMPONENT VIEWS | |
| B37B | Engine Oil Pressure Sensor | Front right side of the engine | POWERTRAIN COMPONENT VIEWS | |
| B46A | Fuel Level Sensor - Primary | LAU or LDK | Under the vehicle, on top of the fuel tank | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B46B | Fuel Level Sensor - Secondary | F46 | Under the vehicle, on top of the fuel tank | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B47B | Fuel Rail Pressure Sensor | LBS or LDK | Top of the engine | POWERTRAIN COMPONENT VIEWS |
| B47 | Fuel Pressure Sensor | LAU or LDK | Under the vehicle, on top of the fuel tank | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| B48 | Fuel Temperature Sensor | LBS | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| B51F | Headlamp Leveling Sensor - Front | TR7 | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B51R | Headlamp Leveling Sensor - Rear | TR7 | In the rear compartment, rearward of left rear seat | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B52A | Heated Oxygen Sensor 1 | LAU or LDK | In the engine compartment, left side of engine | POWERTRAIN COMPONENT VIEWS |
| B52B | Heated Oxygen Sensor 2 | LAU or LDK | Middle rear of the engine | POWERTRAIN COMPONENT VIEWS |
| B52 | Heated Oxygen Sensor | LBS | Center rear of the engine compartment, on the rear exhaust manifold | POWERTRAIN COMPONENT VIEWS |
| B55 | Bonnet Switch | UTJ | At front of vehicle, part of the hood latch | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B59L | Front Impact Sensor - Left | At front of vehicle, mounted to the radiator support, left of center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B59R | Front Impact Sensor - Right | At front of vehicle, mounted to the radiator support, right of center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B59 | Front Impact Sensor | At front of vehicle, mounted to the radiator support, near center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| B60 | Passenger Presence Detection Sensor | UH0 or UH1 | In the passenger compartment, part of the passenger presence detection module, in the passenger seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B63L | Side Impact Sensor - Left | In the passenger compartment, at base of left b-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B63LF | Side Impact Sensor - Left Front | In the passenger compartment, at base of left b-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B63LR | Side Impact Sensor - Left Rear | AW7 | In the passenger compartment, at base of left c-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B63R | Side Impact Sensor - Right | In the passenger compartment, at base of right b-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B63RF | Side Impact Sensor - Right Front | In the passenger compartment, at base of right b-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B63RR | Side Impact Sensor - Right Rear | AW7 | In the passenger compartment, at base of right c-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B65 | Intake Manifold Pressure and Air Temperature Sensor | Right front top side of the intake manifold | POWERTRAIN COMPONENT VIEWS | |
| B67 | Ultrasonic Intrusion Sensor | UTV | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B68A | Knock Sensor 1 | LAU or LDK | In the engine compartment, on the front middle of the engine block | POWERTRAIN COMPONENT VIEWS |
| B68B | Knock Sensor 2 | LAU or LDK | In the engine compartment, on the front middle of the engine block | POWERTRAIN COMPONENT VIEWS |
| B74 | Manifold Absolute Pressure Sensor | LDK | On the engine, at the top left front | POWERTRAIN COMPONENT VIEWS |
| B75B | Mass Air Flow/Intake Air Temperature Sensor | LBS or LDK | On the top right side of the engine, at the air cleaner | POWERTRAIN COMPONENT VIEWS |
| B75 | Mass Air Flow Sensor | LAU | On the top right side of the engine, at the air cleaner | POWERTRAIN COMPONENT VIEWS |
| B78A | Front Object Sensor - Left Outer | UD5 or UDP | At front of vehicle, mounted to front bumper cover, at left corner | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B78B | Front Object Sensor - Right Outer | UD5 or UDP | At front of vehicle, mounted to front bumper cover, at right corner | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B78C | Front Object Sensor - Left Middle | UD5 or UDP | At front of vehicle, mounted to front bumper cover, left of center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B78D | Front Object Sensor - Right Middle | UD5 or UDP | At front of vehicle, mounted to front bumper cover, right of center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| B78E | Rear Object Sensor - Left Middle | UD5 or UDP | At the rear of vehicle, mounted to rear bumper cover, left of center | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B78F | Rear Object Sensor - Right Middle | UD5 or UDP | At the rear of vehicle, mounted to rear bumper cover, right of center | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B78G | Rear Object Sensor - Left Outer | UD5 or UDP | At the rear of vehicle, mounted to rear bumper cover, at left corner | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B78H | Rear Object Sensor - Right Outer | UD5 or UDP | At the rear of vehicle, mounted to rear bumper cover, at right corner | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B80 | Park Brake Switch | Under the center console | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| B87 | Rearview Camera | UVC | At the rear of vehicle | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B88D | Seat Belt Switch - Driver | In the passenger compartment, part of the seat belt buckle - driver, mounted to the inboard side of seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B88LR | Seat Belt Switch - Left Rear | UH5 | In the passenger compartment, part of the seat belt buckle - left rear, mounted to the inboard side of seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B88MR | Seat Belt Switch - Rear Middle | UH5 | In the passenger compartment, part of the seat belt buckle - rear middle, mounted to the seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B88P | Seat Belt Switch - Passenger | In the passenger compartment, part of the seat belt buckle - passenger, mounted to the inboard side of seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| B88RR | Seat Belt Switch - Right Rear | UH5 | In the passenger compartment, part of the seat belt buckle - right rear, mounted to the inboard side of seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| B94L | Side Object Sensor - Left | UFT | At the rear of vehicle, mounted behind left side of rear bumper cover | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B94R | Side Object Sensor - Right | UFT | At the rear of vehicle, mounted behind right side of rear bumper cover | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| B99 | Steering Wheel Angle Sensor | In the steering column, behind the inflatable restraint steering wheel module coil | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| C1 | Battery | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| C3 | Telematics Communication Interface Control Module Battery | UE1 | In the passenger compartment, rear of the vehicle, at the center of the rear window shelf | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| E1C | Accent Lamp - Driver Door Handle | In the passenger compartment, in the driver door trim panel, below the armrest | DOOR COMPONENT VIEWS | |
| E1D | Accent Lamp - Driver Door | TSQ | In the passenger compartment, in the driver door trim panel, near the inside door handle | DOOR COMPONENT VIEWS |
| E1E | Accent Lamp - Left Rear Door Handle | TSQ | In the passenger compartment, mounted to the left rear door panel, near the door handle | DOOR COMPONENT VIEWS |
| E1F | Accent Lamp - Right Rear Door Handle | TSQ | In the passenger compartment, mounted to the right rear door panel, near the door handle | DOOR COMPONENT VIEWS |
| E1J | Accent Lamp - Left Lower Instrument Panel | TSQ | In the passenger compartment, on the left side, below of the instrument panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| E1K | Accent Lamp - Right Lower Instrument Panel | TSQ | In the passenger compartment, on the right side, below of the instrument panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| E1LR | Accent Lamp - Left Rear Door | TSQ | In the passenger compartment, in the left rear door trim panel, below the armrest | DOOR COMPONENT VIEWS |
| E1M | Accent Lamp - Passenger Door Handle | In the passenger compartment, in the passenger door trim panel, below the armrest | DOOR COMPONENT VIEWS | |
| E1P | Accent Lamp - Passenger Door | TSQ | In the passenger compartment, in the passenger door trim panel, near the inside door handle | DOOR COMPONENT VIEWS |
| E1RR | Accent Lamp - Right Rear Door | TSQ | In the passenger compartment, in the right rear door trim panel, below the armrest | DOOR COMPONENT VIEWS |
| E13L | Headlamp - Left | At front of vehicle, at left corner | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E13R | Headlamp - Right | At front of vehicle, at right corner | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E14A | Seat Heating Element - Driver Back | KA1 | In the passenger compartment, driver seat back cover | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| E14B | Seat Heating Element - Driver Cushion | KA1 | In the passenger compartment, driver seat cushion cover | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| E14C | Seat Heating Element - Passenger Back | KA1 | In the passenger compartment, passenger seat back cover | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| E14D | Seat Heating Element - Passenger Cushion | KA1 | In the passenger compartment, passenger seat cushion cover | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| E18 | Rear Defogger Grid | At the rear of vehicle, part of rear window | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E19 | Coolant Heater | LBS | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| E2LF | Side Marker Lamp - Left Front | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E2LR | Side Marker Lamp - Left Rear | At the rear of vehicle, in the tail lamp assembly - left | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E2RF | Side Marker Lamp - Right Front | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E2RR | Side Marker Lamp - Right Rear | At the rear of vehicle, in the tail lamp assembly - right | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E27 | Instrument Panel Compartment Lamp | In the passenger compartment, inside the instrument panel compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| E28 | Centre Console Compartment Lamp | In the passenger compartment, inside the center console compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| E29LF | Fog Lamp - Left Front | T96 | At front of vehicle, below headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| E29R | Fog Lamp - Rear | T79 | At the rear of vehicle | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| E29RF | Fog Lamp - Right Front | T96 | At front of vehicle, below headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| E31LF | Sunshade Mirror Lamp - Left Front | In the passenger compartment, in the left front sunshade | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| E31RF | Sunshade Mirror Lamp - Right Front | In the passenger compartment, in the right front sunshade | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| E32 | Cigarette Lighter Receptacle | In the passenger compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| E37F | Dome/Reading Lamps - Front | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| E37M | Dome/Reading Lamps - Middle | In the passenger compartment, mounted to the headliner above rear seats | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| E4C | Daytime Running Lamp - Left | TR7 | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| E4D | Daytime Running Lamp - Right | TR7 | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| E4E | Headlamp - Left High Beam | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4F | Headlamp - Right High Beam | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4G | Headlamp - Left Low Beam | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4H | Headlamp - Right Low Beam | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4J | Park Lamp - Left Front | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4K | Park Lamp - Right Front | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4LF | Turn Signal Lamp - Left Front | At front of vehicle, below headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4LR | Turn Signal Lamp - Left Rear | At the rear of vehicle, in the tail lamp assembly - left | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E4N | Park/Turn Signal Lamp - Left | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4P | Park/Turn Signal Lamp - Right | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4RF | Turn Signal Lamp - Right Front | At front of vehicle, below headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| E4RR | Turn Signal Lamp - Right Rear | At the rear of vehicle, in the tail lamp assembly - right | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E40 | Electrical Auxiliary Heater | C32 | Part of HVAC module, behind I/P | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| E42L | Tail Lamp Assembly - Left | At the rear of vehicle, in the tail lamp assembly - left | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E42R | Tail Lamp Assembly - Right | At the rear of vehicle, in the tail lamp assembly - right | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E5A | Backup Lamp - Left | At the rear of vehicle, in the tail lamp assembly - left | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E5B | Backup Lamp - Right | At the rear of vehicle, in the tail lamp assembly - right | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E5L | Stop Lamp - Left | At the rear of vehicle, in the tail lamp assembly - left | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E5R | Stop Lamp - Right | At the rear of vehicle, in the tail lamp assembly - right | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E6 | Centre High Mounted Stop Lamp | At the rear of vehicle | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E7 | License Plate Lamp | At the rear of vehicle | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E8D | Door Courtesy Lamp - Driver | In the passenger compartment, bottom edge of the left front door trim panel | DOOR COMPONENT VIEWS | |
| E8E | Rear Compartment Courtesy Lamp - Left | In the rear compartment, on left side | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E8F | Rear Compartment Courtesy Lamp - Right | In the rear compartment, on right side | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| E8J | Instrument Panel Courtesy Lamp - Left | In the passenger compartment, in the left kick panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| E8K | Instrument Panel Courtesy Lamp - Right | In the passenger compartment, in the right kick panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| E8P | Door Courtesy Lamp - Passenger | In the passenger compartment, bottom edge of the right front door trim panel | DOOR COMPONENT VIEWS | |
| F105L | Roof Rail Air Bag - Left | In the passenger compartment, behind the headliner, mounted to the roof, at left side | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F105R | Roof Rail Air Bag - Right | In the passenger compartment, behind the headliner, mounted to the roof, at right side | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F105 | Passenger instrument panel airbag | In the passenger compartment, in the left side of the instrument panel, above the instrument panel compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| F106LF | Side Air Bag - Left Front | In the passenger compartment, mounted to the outboard side of the left front seat back frame | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F106LR | Side Air Bag - Left Rear | AW7 | In the passenger compartment, mounted to the outboard side of the left rear seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| F106RF | Side Air Bag - Right Front | In the passenger compartment, mounted to the outboard side of the right front seat back frame | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F106RR | Side Air Bag - Right Rear | AW7 | In the passenger compartment, mounted to the outboard side of the right rear seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| F107 | Steering wheel air bag | In the passenger compartment, mounted in the center of the steering wheel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| F109E | Seat Belt Buckle Pretensioner - 2nd Row Left | In the passenger compartment, part of the seat belt buckle - left rear, mounted to the inboard side of seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F109F | Seat Belt Buckle Pretensioner - 2nd Row Right | In the passenger compartment, part of the seat belt buckle - right rear, mounted to the inboard side of seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F112D | Seat Belt Retractor Pretensioner - Driver | In the passenger compartment, mounted to the base of the driver b-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F112P | Seat Belt Retractor Pretensioner - Passenger | In the passenger compartment, mounted to the base of the passenger b-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F113D | Seat Belt Anchor Pretensioner - Driver | In the passenger compartment, mounted to the outboard side of the driver seat cushion frame | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| F113P | Seat Belt Anchor Pretensioner - Passenger | In the passenger compartment, mounted to the outboard side of the passenger seat cushion frame | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| G10L | Cooling Fan Motor - Left | At front of vehicle, behind radiator, left of center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| G10R | Cooling Fan Motor - Right | At front of vehicle, behind radiator, right of center | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| G12 | Fuel Pump | LAU or LDK | Under the vehicle, in the fuel tank | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| G13 | Alternator | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS | |
| G16 | Headlamp Washer Fluid Pump | CE4 | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| G18 | High Pressure Fuel Pump | In the engine compartment, mounted to engine | POWERTRAIN COMPONENT VIEWS | |
| G21 | Secondary Air Injection Pump | LAU with NU6 | Lower left front of the engine | POWERTRAIN COMPONENT VIEWS |
| G24 | Windscreen Washer Pump | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| K17 | Electronic Brake Control Module | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| K19 | Suspension Control Module | F45 | In the rear compartment, on left side, behind trim | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| K20 | Engine Control Module | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| K26 | Headlamp Control Module | TR7 | In the passenger compartment, at the lower left of the instrument panel, behind the body control module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| K27 | Fuel Pump Control Module | LAU or LDK | In the rear compartment, on right side, behind trim | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| K29D | Seat Heating Control Module - Driver | KA1 without A45 | In the passenger compartment, mounted to the bottom of the driver seat cushion frame | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K33 | HVAC Control Module | In the passenger compartment, in the center of the instrument panel, behind the HVAC and radio controls | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| K34 | Glow Plug Control Module | LBS | Left side of the engine compartment, in front of the battery | POWERTRAIN COMPONENT VIEWS |
| K36 | Inflatable Restraint Sensing and Diagnostic Module | In the passenger compartment, mounted to the floor, under floor console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| K40D | Seat Memory Control Module - Driver | A45 | In the passenger compartment, mounted to the bottom of the driver seat cushion frame | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K41 | Parking Assist Control Module | UD5 or UDP | In the rear compartment, on left side, behind trim | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| K43 | Power Steering Control Module | NXC or NV7 | In the passenger compartment, lower left side of the instrument panel, to the left of the steering column, behind the body control module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| K46 | Radio Antenna Module | In the passenger compartment, mounted to the right c-pillar | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| K47 | Rear Differential Clutch Control Module | Under rear of the vehicle, mounted to the rear differential | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| K60 | Steering Column Lock Control Module | ULS | In the steering column | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| K61 | Sunroof Control Module | C3U | In the passenger compartment, mounted to the roof | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K62 | Sunroof Sunshade Motor Module | C3U | In the passenger compartment, mounted to the roof | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K65 | Tyre Pressure Indicator Module | UJN | Left rear of the vehicle | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K71 | Transmission Control Module | M36 | At front of vehicle, mounted to the top of the transmission assembly | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| K73 | Telematics Communication Interface Control Module | UE1 | In the passenger compartment, rear of the vehicle, at the center of the rear window shelf, between speakers | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| K74 | Vehicle Direction Camera Control Module | UVL or UVT | Above the headliner | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K77 | Remote Control Door Lock Receiver | In the passenger compartment, above the inside rearview mirror, behind the outside moisture sensor cover | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| K8 | Blower Motor Control Module | In the passenger compartment, below the right side of the instrument panel, on the bottom of the blower unit | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| K8A | Blower Motor Control Module - Auxiliary | In the passenger compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| K82 | Mobile Telephone Control Module | UPH or UPJ | In the center of the instrument panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| K83 | Parking Brake Control Module | Outside left rear of the vehicle, behind left rear wheel liner | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| K84 | Keyless Entry Control Module | In the passenger compartment, below the right side of the instrument panel, behind the passenger kick panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| K85 | Passenger Presence Detection Module | AL0 | In the passenger compartment, in the passenger seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| K89 | Immobilizer Control Module | In the passenger compartment, in the center console, below the cup holders | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| K9 | Body Control Module | In the passenger compartment, at the lower left of the instrument panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| M27 | Fuel Door Unlatch Actuator | In the right side of the rear compartment | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS | |
| M29L | Headlamp Leveling Actuator - Left | TR7 | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| M29R | Headlamp Leveling Actuator - Right | TR7 | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| M40 | Rear Compartment Lid Latch | At the rear of vehicle, mounted to the rear compartment lid | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| M50D | Seat Front Vertical Motor - Driver | AG1 | In the passenger compartment, mounted to the bottom of the driver seat at front | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M50P | Seat Front Vertical Motor - Passenger | AG2 | In the passenger compartment, mounted to the bottom of the passenger seat at front | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M51D | Seat Horizontal Motor - Driver | AG1 | In the passenger compartment, mounted to the bottom of the driver seat at middle | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M51P | Seat Horizontal Motor - Passenger | AG2 | In the passenger compartment, mounted to the bottom of the passenger seat at middle | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M52D | Seat Lumbar Support Horizontal Motor - Driver | APG | In the passenger compartment, driver seat back | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M52P | Seat Lumbar Support Horizontal Motor - Passenger | APH | In the passenger compartment, passenger seat back | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M54D | Seat Lumbar Support Vertical Motor - Driver | APG | In the passenger compartment, driver seat back | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M54P | Seat Lumbar Support Vertical Motor - Passenger | APH | In the passenger compartment, passenger seat back | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M55D | Seat Rear Vertical Motor - Driver | In the passenger compartment, mounted to the bottom of the driver seat, forward of middle | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| M55P | Seat Rear Vertical Motor - Passenger | In the passenger compartment, mounted to the bottom of the passenger seat, forward of middle | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| M56D | Seat Recline Motor - Driver | AG1 | In the passenger compartment, mounted the driver seat back frame inboard side | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M56P | Seat Recline Motor - Passenger | AG2 | In the passenger compartment, mounted the passenger seat back frame inboard side | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M64 | Starter motor | In the engine compartment, on the left side of the engine | POWERTRAIN COMPONENT VIEWS | |
| M69 | Sunroof Motor | C3U | In the passenger compartment, mounted to the roof | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M7 | Transmission Shift Lock Control Solenoid Actuator | M36 | In the passenger compartment, part of the transmission shift lever | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| M72 | Variable Power Steering Solenoid Valve | NXC or NV7 | Lower rear of the engine compartment, behind the transmission, on the power steering rack at the column hook up | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| M73A | Seat Blower Motor - Driver Back | KU1 | In the passenger compartment, driver seat back | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M73B | Seat Blower Motor - Passenger Back | KU3 | In the passenger compartment, passenger seat back | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M73C | Seat Blower Motor - Driver Cushion | KU1 | In the passenger compartment, driver seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M73D | Seat Blower Motor - Passenger Cushion | KU3 | In the passenger compartment, passenger seat cushion | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| M74D | Window Motor - Driver | In the passenger compartment, in the driver door | DOOR COMPONENT VIEWS | |
| M74LR | Window Motor - Left Rear | In the passenger compartment, in the left rear door | DOOR COMPONENT VIEWS | |
| M74P | Window Motor - Passenger | In the passenger compartment, in the passenger door | DOOR COMPONENT VIEWS | |
| M74RR | Window Motor - Right Rear | In the passenger compartment, in the right rear door | DOOR COMPONENT VIEWS | |
| M75 | Windscreen Wiper Motor | At front of vehicle, under cowling | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| M8 | Blower Motor | In the passenger compartment, below the right side of the instrument panel, on the bottom of the HVAC module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| M9 | Brake Booster Pump Motor | LAU | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| P4 | Security Siren | UTR | At front of vehicle, under cowling | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| P9 | Driver Information Center Display | In the passenger compartment, part of the instrument cluster | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| P12 | Horn | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| P14 | Passenger Air Bag Disable Indicator | In the passenger compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| P16 | Instrument Panel Cluster | In the passenger compartment, driver side of the instrument panel, above the steering column | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| P17 | Info Display Module | In the passenger compartment, in the center console | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| P19A | Speaker - Centre Console | U63 | Center of instrument panel below upper dash pad | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| P19AA | Speaker - Right Subwoofer | UQS | In the passenger compartment, mounted to shelf rearward of rear seats on right side | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| P19AD | Speaker - Left Surround | UQS | In the passenger compartment, mounted to shelf rearward of rear seats on right of center | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| P19AE | Speaker - Right Surround | UQS | In the passenger compartment, mounted to shelf rearward of rear seats on left of center | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| P19B | Speaker - Centre Instrument Panel | UQS | In the center of the instrument panel cover | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| P19G | Speaker - Left Front | Behind the left front door trim panel | DOOR COMPONENT VIEWS | |
| P19H | Speaker - Left Front Tweeter | Behind the left A-pillar trim panel | DOOR COMPONENT VIEWS | |
| P19K | Speaker - Left Rear | Behind the left rear door trim panel | DOOR COMPONENT VIEWS | |
| P19N | Speaker - Left Subwoofer | UQS | In the passenger compartment, mounted to shelf rearward of rear seats on left side | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| P19U | Speaker - Right Front | Behind the right front door trim panel | DOOR COMPONENT VIEWS | |
| P19V | Speaker - Right Front Tweeter | Behind the left A-pillar trim panel | DOOR COMPONENT VIEWS | |
| P19X | Speaker - Right Rear | Behind the right rear door trim panel | DOOR COMPONENT VIEWS | |
| P2 | Transmission Shift Lever Position Indicator | M36 | In the passenger compartment, in the center console, below the automatic transmission shift lever | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| P22E | Video Display - Driver Seatback | UWG | In the passenger compartment, on rear side of driver seatback | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| P22F | Video Display - Passenger Seatback | UWG | In the passenger compartment, on rear side of driver seat headrest | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| P29 | Head Up Display | In the passenger compartment, left side of the instrument panel, to the rear of the instrument cluster | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| P4 | Security Siren | UTR | At front of vehicle, under cowling | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| P9 | Driver Information Center Display | In the passenger compartment, part of the instrument cluster | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| Q2 | A/C Compressor Clutch | LLU | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q12 | Evaporative Emission Purge Solenoid Valve | LAU or LDK | In the engine compartment, on the front middle of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q13 | Evaporative Emission Vent Solenoid Valve | NT7 | Under the vehicle, on the left side of the fuel tank, mounted to the evaporative emission canister | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| Q14 | Exhaust Gas Recirculation Valve | LBS | Middle rear of the engine | POWERTRAIN COMPONENT VIEWS |
| Q17A | Fuel Injector 1 | In the engine compartment near the number 1 cylinder | POWERTRAIN COMPONENT VIEWS | |
| Q17B | Fuel Injector 2 | In the engine compartment near the number 2 cylinder | POWERTRAIN COMPONENT VIEWS | |
| Q17C | Fuel Injector 3 | In the engine compartment near the number 3 cylinder | POWERTRAIN COMPONENT VIEWS | |
| Q17D | Fuel Injector 4 | In the engine compartment near the number 4 cylinder | POWERTRAIN COMPONENT VIEWS | |
| Q17E | Fuel Injector 5 | LAU | In the engine compartment near the number 5 cylinder | POWERTRAIN COMPONENT VIEWS |
| Q17F | Fuel Injector 6 | LAU | In the engine compartment near the number 6 cylinder | POWERTRAIN COMPONENT VIEWS |
| Q22 | Intake Manifold Tuning Solenoid Valve | LBS | Under the intake manifold on the left side of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q23 | Line Pressure Control Solenoid Valve | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| Q27A | Pressure Control Solenoid Valve 1 | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| Q27B | Pressure Control Solenoid Valve 2 | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| Q27C | Pressure Control Solenoid Valve 3 | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| Q27D | Pressure Control Solenoid Valve 4 | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| Q37LF | Shock Absorber Actuator - Left Front | F45 | Left front of the vehicle, in the front strut | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| Q37LR | Shock Absorber Actuator - Left Rear | F45 | Left rear of the vehicle, in the rear strut | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| Q37RF | Shock Absorber Actuator - Right Front | F45 | Right front of the vehicle, in the front strut | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| Q37RR | Shock Absorber Actuator - Right Rear | F45 | Right rear of the vehicle, in the rear strut | WHEELS/VEHICLE UNDERBODY COMPONENT VIEWS |
| Q38 | Throttle Body | Top left side of the engine, on the throttle body | POWERTRAIN COMPONENT VIEWS | |
| Q40 | Turbocharger Bypass Solenoid Valve | LAU or LDK | Top left front of engine | POWERTRAIN COMPONENT VIEWS |
| Q42 | Turbocharger Wastegate Solenoid Valve | LAU or LDK | Top right front side of the engine | POWERTRAIN COMPONENT VIEWS |
| Q46 | A/C Compressor Solenoid Valve | Without LLU | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q47 | Exhaust Gas Recirculation Cooling Bypass Valve | LBS | In the engine compartment, on the left side of the engine | POWERTRAIN COMPONENT VIEWS |
| Q6A | Camshaft Position Actuator Solenoid Valve - Bank 1 Exhaust | LAU | Rear of the engine, left side of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q6B | Camshaft Position Actuator Solenoid Valve - Bank 1 Intake | LAU | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q6C | Camshaft Position Actuator Solenoid Valve - Bank 2 Exhaust | LAU | Rear of the engine, at the right side | POWERTRAIN COMPONENT VIEWS |
| Q6D | Camshaft Position Actuator Solenoid Valve - Bank 2 Intake | LAU | In the engine compartment, on the right side of the engine block | POWERTRAIN COMPONENT VIEWS |
| Q6E | Camshaft Position Actuator Solenoid Valve - Exhaust | LDK | Front right side of the engine | POWERTRAIN COMPONENT VIEWS |
| Q6F | Camshaft Position Actuator Solenoid Valve - Intake | LDK | Top right side, to the rear of the engine | POWERTRAIN COMPONENT VIEWS |
| Q8 | Control Solenoid Valve Assembly | M36 | Inside the automatic transmission | POWERTRAIN COMPONENT VIEWS |
| R6 | Data Link Resistor | Upper center of the instrument panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S109 | Sport Mode Switch | In the passenger compartment, in the center console, next to the shift lever | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S2 | Transmission Manual Shift Switch | M36 | In the passenger compartment, part of the transmission shift lever | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| S25 | Garage Door Opener | UG1 | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S27 | Head-Up Display Switch | In the passenger compartment, left side of the instrument panel, near the headlamp switch | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S3 | Transmission Shift Lever | M36 | In the passenger compartment, mounted to the floor under the center console | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| S30 | Headlamp Switch | In the passenger compartment, at the left side of the instrument panel, to the left of the steering column | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S33 | Horn Switch | In the passenger compartment, in the steering wheel behind the inflatable restraint steering wheel module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S38 | Ignition Mode Switch | In the passenger compartment, center of the instrument panel, to the right of the steering column | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S40 | Passenger Air Bag Disable Switch | C99 | Upper right side of the instrument panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| S43 | Ultrasonic Intrusion Sensor Disable Switch | UTV | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S47D | Seat Memory Switch - Driver | A45 | In the passenger compartment, on the outboard side of driver seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S48A | Multi-Function Switch - Instrument Panel | In the passenger compartment, in the center console, below radio/HVAC control | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S48B | Multi-Function Switch - Overhead Console | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| S48E | Multi-Function Switch - Center Console | In the passenger compartment, in the center console, next to the shift lever | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S51 | Telematics Button Assembly | UE1 | In the passenger compartment, part of the inside rearview mirror, mounted to top center of windshield | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S52 | Outside Rearview Mirror Switch | In the passenger compartment, on the driver door, in front of the window switch | DOOR COMPONENT VIEWS | |
| S64D | Seat Adjuster Switch - Driver | In the passenger compartment, on the outboard side of driver seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| S64P | Seat Adjuster Switch - Passenger | In the passenger compartment, on the outboard side of passenger seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| S65D | Seat Lumbar Support Switch - Driver | APG | In the passenger compartment, on the outboard side of driver seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S65P | Seat Lumbar Support Switch - Passenger | APH | In the passenger compartment, on the outboard side of passenger seat | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S70L | Steering Wheel Controls Switch - Left | Left center of the steering wheel to the left of the inflatable restraint steering wheel module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S70R | Steering Wheel Controls Switch - Right | Right center of the steering wheel to the left of the inflatable restraint steering wheel module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S72 | Sunroof Switch | C3U | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S78 | Turn Signal/Multi-Function Switch | On the left side of the steering column, to the rear of the inflatable restraint steering wheel module coil | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S79D | Window Switch - Driver | In the passenger compartment, in the driver door armrest | DOOR COMPONENT VIEWS | |
| S79LR | Window Switch - Left Rear | In the passenger compartment, in the left rear door armrest | DOOR COMPONENT VIEWS | |
| S79P | Window Switch - Passenger | In the passenger compartment, in the passenger door armrest | DOOR COMPONENT VIEWS | |
| S79RR | Window Switch - Right Rear | In the passenger compartment, in the right rear door armrest | DOOR COMPONENT VIEWS | |
| S82 | Windscreen Wiper/Washer Switch | Mounted to the steering column to the right of the steering wheel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| S88 | Sunroof Tilt Switch | C3U | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S90 | Sunroof Sunshade Switch | C3U | In the passenger compartment, in the overhead console | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| S111 | Night Panel Switch | In the passenger compartment, in the center console | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| T1 | Accessory DC/AC Power Inverter Module | KI6 | In the passenger compartment, below the center console, under the shift lever assembly | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| T3 | Audio Amplifier | UQS | In the rear compartment, on right side, behind trim | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| T4F | Cellular Phone Antenna | UPJ without UDT | Outside the vehicle, at the rear center of the roof | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| T4G | Cellular Phone, Navigation, and Digital Radio Antenna | U2K or UBT or UE1 with UDT | On the roof at rear center | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| T4H | Digital Radio Antenna | U2K or UBT | On the roof at rear center | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| T4K | Navigation and Traffic Data Antenna | UPJ with UDT | On the roof at rear center | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS |
| T4M | Radio Antenna | In the passenger compartment, part of the rear window | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| T4P | Navigation Antenna | UDT without UE1 or UPJ | Outside the vehicle, at the rear center of the roof | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| T4S | Wireless Communication Antenna - Bluetooth | UPF | Mounted to the right rear corner of the vehicle communication interface module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| T7L | Headlamp Ballast - Left | T4F | At front of vehicle, in the headlamp - left | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| T7R | Headlamp Ballast - Right | T4F | At front of vehicle, in the headlamp - right | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS |
| T8A | Ignition Coil 1 | LAU or LDK | In the engine compartment near the number 1 cylinder | POWERTRAIN COMPONENT VIEWS |
| T8B | Ignition Coil 2 | LAU or LDK | In the engine compartment near the number 2 cylinder | POWERTRAIN COMPONENT VIEWS |
| T8C | Ignition Coil 3 | LAU or LDK | In the engine compartment near the number 3 cylinder | POWERTRAIN COMPONENT VIEWS |
| T8D | Ignition Coil 4 | LAU or LDK | In the engine compartment near the number 4 cylinder | POWERTRAIN COMPONENT VIEWS |
| T8E | Ignition Coil 5 | LAU | In the engine compartment near the number 5 cylinder | POWERTRAIN COMPONENT VIEWS |
| T8F | Ignition Coil 6 | LAU | In the engine compartment near the number 6 cylinder | POWERTRAIN COMPONENT VIEWS |
| T10B | Keyless Entry Antenna - Instrument Panel Compartment | In the passenger compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| T10E | Keyless Entry Antenna - Rear Compartment | In the rear compartment | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| T10F | Keyless Entry Antenna - Rear Window | In the passenger compartment | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| T10G | Keyless Entry Antenna - Rear Fascia | ATH | At the rear of vehicle, behind rear bumper cover | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS |
| T10J | Keyless Entry Antenna - Centre Console Front | Mounted to the front of the center console, near the instrument panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| T10K | Keyless Entry Antenna - Centre Console Rear | Mounted in the lower rear of the center console, behind the console rear cover | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| T10R | Keyless Entry Antenna - Right Body | In the rear compartment | PASSENGER COMPARTMENT/ROOF COMPONENT VIEWS | |
| T11 | Multimedia Player Interface Module | KTA | In the passenger compartment, near the front of the center console | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| T15 | Navigation Antenna Signal Splitter | UYS with UE1 | In the passenger compartment, rear of the vehicle, at the center of the rear window shelf, on the vehicle communication interface module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| X50A | Fuse Block - Underhood | At front of vehicle | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| X50D | Fuse Block - Battery | At front of vehicle, mounted to top of battery | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| X51A | Fuse Block - Instrument Panel | In the passenger compartment, below lower left side of the instrument panel, behind the lower trim panel | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| X53A | Fuse Block - Rear Body | In the rear compartment, on left side, behind trim | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| X70A | Relay Block - Underhood | At front of vehicle, at left side of radiator | FRONT OF VEHICLE/ENGINE COMPARTMENT COMPONENT VIEWS | |
| X80C | Accessory Power Receptacle - Cargo | In the rear compartment | LUGGAGE COMPARTMENT/REAR OF VEHICLE COMPONENT VIEWS | |
| X80H | Accessory Power Receptacle - Center Console | KC8 | Under the center console | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| X81 | Accessory Power Receptacle - 110V AC | KI6 | In the passenger compartment, near the bottom of the center console rear cover | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS |
| X82 | Audio/Video Input Adapter | In the passenger compartment, mounted to the center console rear cover | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| X83 | Auxiliary Audio Input | In the passenger compartment, inside the center console compartment | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| X84 | Data Link Connector | In the passenger compartment, under the left instrument panel knee bolster | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| X85 | Steering Wheel Air Bag Coil | In the passenger compartment, on the steering column behind the steering wheel module | INSTRUMENT PANEL/CENTER CONSOLE COMPONENT VIEWS | |
| X101 | Body Harness to the Front Bumper Harness (16 Cavities) | LHD | At the front of the vehicle, behind the front bumper cover, at the upper left side of the grill | HARNESS ROUTING VIEWS |
| X101 | Forward Lamp Harness to the Front Bumper Harness (16 Cavities) | RHD | At the front of the vehicle, behind the front bumper cover, at the upper left side of the grill | HARNESS ROUTING VIEWS |
| X102 | Forward Lamp Harness to the Body Harness (40 Cavities) | RHD | At the front of the vehicle, behind the front bumper cover | HARNESS ROUTING VIEWS |
| X103 | Forward Lamp Harness to the Body Harness (40 Cavities) | RHD | At the front of the vehicle, behind the front bumper cover | HARNESS ROUTING VIEWS |
| X104 | Forward Lamp Harness to the Left Front Suspension Harness (10 Cavities) | RHD with F45 | Under the vehicle, at the left side of the engine cradle, forward of the lower control arm | HARNESS ROUTING VIEWS |
| X105 | Forward Lamp Harness to Right Front Suspension Harness (10 Cavities) | RHD with F45 | Under the vehicle, at the right side of the engine cradle, forward of the lower control arm | HARNESS ROUTING VIEWS |
| X106 | Body Harness to Left Front Suspension Harness (10 Cavities) | LHD with F45 | Under the vehicle, at the left side of the engine cradle, forward of the lower control arm | HARNESS ROUTING VIEWS |
| X107 | Forward Lamp Harness to Right Front Suspension Harness (10 Cavities) | LHD with F45 | Under the vehicle, at the right side of the engine cradle, forward of the lower control arm | HARNESS ROUTING VIEWS |
| X108 | Engine Harness to the Body Harness (40 Cavities) | In the engine compartment, at the left of the radiator core support | HARNESS ROUTING VIEWS | |
| X109 | Engine Harness to the Oil Level Jumper Harness (7 Cavities) | LBS | In the engine compartment, at the rear of the engine | HARNESS ROUTING VIEWS |
| X110 | Body Harness to Headlamp - Left Harness (10 Cavities) | At the front of the vehicle, at the back of the left headlamp assembly | HARNESS ROUTING VIEWS | |
| X113 | Left Front Wheel Speed Sensor Harness to the Left Front Suspension Harness (2 Cavities) | F45 | Under the vehicle, on the left subframe assembly, near the left front strut assembly | HARNESS ROUTING VIEWS |
| X114 | Right Front Wheel Speed Sensor Harness to the Right Front Suspension Harness (2 Cavities) | F45 | Under the vehicle, on the right subframe assembly near the right front strut assembly | HARNESS ROUTING VIEWS |
| X116 | Power Steering Harness to the Forward Lamp Harness (2 Cavities) | RHD with NV7 | Under the vehicle, at the left side of the lower radiator core support | HARNESS ROUTING VIEWS |
| X116 | Power Steering Harness to the Body Harness (2 Cavities) | LHD with NV7 | Under the vehicle, at the left side of the lower radiator core support | HARNESS ROUTING VIEWS |
| X117 | Cooling Fan Jumper Harness to the Forward Lamp Harness (4 Cavities) | RHD | Under the vehicle, at the left side of the lower radiator core support | HARNESS ROUTING VIEWS |
| X117 | Cooling Fan Jumper Harness to the Body Harness (4 Cavities) | LHD | Under the vehicle, at the left side of the lower radiator core support | HARNESS ROUTING VIEWS |
| X118 | Cooling Fan Jumper Harness to the Forward Lamp Harness (5 Cavities) | RHD | Under the vehicle, at the left side of the lower radiator core support | HARNESS ROUTING VIEWS |
| X118 | Cooling Fan Jumper Harness to the Forward Lamp Harness (5 Cavities) | LHD | Under the vehicle, at the left side of the lower radiator core support | HARNESS ROUTING VIEWS |
| X119 | Cooling Fan Jumper Harness to the Forward Lamp Harness (2 Cavities) | RHD | Under the vehicle, at the left side of the lower radiator core support | HARNESS ROUTING VIEWS |
| X119 | Cooling Fan Jumper Harness to the Forward Lamp Harness (2 Cavities) | LHD | Under the vehicle, at the left side of the lower radiator core support | HARNESS ROUTING VIEWS |
| X120 | Body Harness to Headlamp - Right Harness (10 Cavities) | At the front of the vehicle, at the back of left headlamp assembly | HARNESS ROUTING VIEWS | |
| X122 | Engine Harness to the Body Harness (2 Cavities) | LAU with NE9 | In the engine compartment, forward of the underhood fuse block | HARNESS ROUTING VIEWS |
| X124 | Engine Harness to Glow Plug Jumper Harness (16 Cavities) | LBS | In the engine compartment, at the top left rear of the engine | HARNESS ROUTING VIEWS |
| X125 | Engine Harness to Glow Plug Jumper Harness (4 Cavities) | LBS | In the engine compartment, at the top left rear of the engine | HARNESS ROUTING VIEWS |
| X160 | Engine Harness to the Fuel Injector Harness (10 Cavities) | LAU | In the engine compartment, top right of the engine | HARNESS ROUTING VIEWS |
| X160 | Engine Harness to the Fuel Injector Harness (8 Cavities) | LBS | In the engine compartment, top of the engine | HARNESS ROUTING VIEWS |
| X200 | Instrument Panel Harness to the Body Harness - Left (100 Cavities) | LHD | In the passenger compartment, at the base of the left a-pillar. | HARNESS ROUTING VIEWS |
| X200 | Instrument Panel Harness to the Body Harness - Right (100 Cavities) | RHD | In the passenger compartment, at the base of the right a-pillar. | HARNESS ROUTING VIEWS |
| X204 | Instrument Panel Harness to the Body Harness - Right (100 Cavities) | LHD with UQS or UWG | In the passenger compartment, at the base of the right a-pillar. | HARNESS ROUTING VIEWS |
| X204 | Instrument Panel Harness to the Body Harness - Left (100 Cavities) | RHD with UQS or UWG | In the passenger compartment, at the base of the left a-pillar. | HARNESS ROUTING VIEWS |
| X207 | Instrument Panel Harness to Lamps Jumper Harness (2 Cavities) | In the passenger compartment, behind the instrument panel | HARNESS ROUTING VIEWS | |
| X210 | Console Harness to the Instrument Panel Harness (52 Cavities) | In the passenger compartment, at the front of the center console | HARNESS ROUTING VIEWS | |
| X211 | Instrument Panel Harness to Body Harness (2 Cavities - Coax) | In the passenger compartment, behind the radio | HARNESS ROUTING VIEWS | |
| X212 | Instrument Panel Harness to Body Harness (2 Cavities - Coax) | In the passenger compartment, behind the radio | HARNESS ROUTING VIEWS | |
| X216 | Instrument Panel Harness to the Console Harness (4 Cavities - USB) | USR | In the passenger compartment, at the front of the center console | HARNESS ROUTING VIEWS |
| X300 | Body Harness to the Console Harness (30 Cavities) | In the passenger compartment, under the center console | HARNESS ROUTING VIEWS | |
| X301 | Body Harness to Driver Seat Harness (48 Cavities) | In the passenger compartment, on floor below driver seat. | HARNESS ROUTING VIEWS | |
| X307 | Body Harness to the Passenger Seat Harness (48 Cavities) | In the passenger compartment, on floor below passenger seat. | HARNESS ROUTING VIEWS | |
| X397 | Headliner Harness to Body Harness (18 Cavities) | In the passenger compartment, behind the left C-Pillar trim | HARNESS ROUTING VIEWS | |
| X398 | Headliner Harness to Body Harness (9 Cavities) | C3U | In the passenger compartment, behind the left A-Pillar trim | HARNESS ROUTING VIEWS |
| X401 | Left Rear Axle Harness to the Body Harness (2 Cavities) | F45 | Under the vehicle, behind the left rear wheel liner | HARNESS ROUTING VIEWS |
| X402 | Right Rear Axle Harness to the Body Harness (2 Cavities) | F45 | Under the vehicle, behind the right rear wheel liner | HARNESS ROUTING VIEWS |
| X403 | Fuel Tank Harness to the Body Harness (16 Cavities) | Under the vehicle, forward of the fuel tank | HARNESS ROUTING VIEWS | |
| X406 | Rear Bumper Harness to Body Harness (16 Cavities) | At the rear of the vehicle, behind the rear bumper cover | HARNESS ROUTING VIEWS | |
| X407 | Body Harness to the Rear Body Harness (8 Cavities) | In the luggage compartment, behind the left side trim panel | HARNESS ROUTING VIEWS | |
| X408 | AWD Jumper Harness to the Body Harness (12 Cavities) | F46 | Under the vehicle, behind the left rear wheel liner | HARNESS ROUTING VIEWS |
| X409 | Body Harness to the Tail Lamp Assembly - Left Harness (6 Cavities) | At the rear of the vehicle, between the left tail lamp assembly and the body | HARNESS ROUTING VIEWS | |
| X410 | Body Harness to the Tail Lamp Assembly - Right Harness (6 Cavities) | At the rear of the vehicle, between the right tail lamp assembly and the body | HARNESS ROUTING VIEWS | |
| X411 | License Lamp Harness to Body Harness (8 Cavities) | In the luggage compartment, at the center of the decklid, above the license plate | HARNESS ROUTING VIEWS | |
| X420 | Wiring harness, rear left wheel speed sensor to body wiring harness (2 holes) | Under the rear left side of the vehicle, by the rear left wheel housing | HARNESS ROUTING VIEWS | |
| X425 | Wiring harness, rear right wheel speed sensor to body wiring harness (2 holes) | Under the rear right side of the vehicle, by the rear right wheel housing | HARNESS ROUTING VIEWS | |
| X500 | Driver Door Harness to Body Harness (41 Cavities) | In the passenger compartment, at the base of the driver side A-Pillar | HARNESS ROUTING VIEWS | |
| X510 | Driver Door Harness to the Outside Rearview Mirror - Driver Harness (16 Cavities) | At the side of the vehicle, front of the driver door, between the outside rearview mirror and the door frame | HARNESS ROUTING VIEWS | |
| X600 | Passenger Door Harness to Body Harness (41 Cavities) | In the passenger compartment, at the base of the passenger side A-Pillar | HARNESS ROUTING VIEWS | |
| X610 | Passenger Door Harness to the Outside Rearview Mirror - Passenger Harness (16 Cavities) | At the side of the vehicle, front of the passenger door, between the outside rearview mirror and the door frame | HARNESS ROUTING VIEWS | |
| X700 | Left Rear Door Harness to the Body Harness (20 Cavities) | In the passenger compartment, at the base of the left B-Pillar | HARNESS ROUTING VIEWS | |
| X800 | Right Rear Door Harness to the Body Harness (20 Cavities) | In the passenger compartment, at the base of the right B-Pillar | HARNESS ROUTING VIEWS | |
| G102 | Body harness | LHD | In the engine compartment, on the right strut tower | GROUND VIEWS |
| G102 | Forward lamp harness | RHD | In the engine compartment, on the right strut tower | GROUND VIEWS |
| G103 | Battery (-) harness | In the engine compartment, on the body forward of the battery | GROUND VIEWS | |
| G105 | Body harness | LHD with TT2 or TT6 | In the engine compartment, on left strut tower | GROUND VIEWS |
| G105 | Forward lamp harness | RHD with TT2 or TT6 | In the engine compartment, on left strut tower | GROUND VIEWS |
| G106 | Cooling fan harness | In the engine compartment, on the radiator support left of center | GROUND VIEWS | |
| G107 | Battery harness and body harness | In the engine compartment, on the body forward of the battery | GROUND VIEWS | |
| G108 | Body harness | LHD with TT2 or TT6 | In the engine compartment, on the radiator support right of center | GROUND VIEWS |
| G108 | Forward lamp harness | RHD with TT2 or TT6 | In the engine compartment, on the radiator support right of center | GROUND VIEWS |
| G109 | Body harness | LHD | In the engine compartment, on the left strut tower | GROUND VIEWS |
| G109 | Forward lamp harness | RHD | In the engine compartment, on the left strut tower | GROUND VIEWS |
| G110 | Body harness | In the engine compartment, on the radiator support left of center | GROUND VIEWS | |
| G111 | Body harness | C32 or LAU | In the engine compartment, on the body rearward of the battery, near fuse block - underhood | GROUND VIEWS |
| G120 | Engine harness | LAU | In the engine compartment, on body below engine control module | GROUND VIEWS |
| G120 | Engine harness | LDK | In the engine compartment, between fuse block underhood and inline the body harness | GROUND VIEWS |
| G121 | Engine harness | LAU | In the engine compartment, on right rear of rearward cylinder head below camshaft cover | GROUND VIEWS |
| G121 | Engine harness | LDK | In the engine compartment, on front of engine block, lower middle near engine oil level switch | GROUND VIEWS |
| G122 | Engine harness | LAU | In the engine compartment, on left rear of rearward cylinder head below camshaft cover | GROUND VIEWS |
| G122 | Engine harness | LDK | In the engine compartment, on right side of cylinder head, near camshaft position sensor - exhaust | GROUND VIEWS |
| G123 | Engine harness | LAU | In the engine compartment, on front of forward cylinder head below camshaft cover | GROUND VIEWS |
| G124 | Engine harness | LBS | In the engine compartment, on the radiator support left of center | GROUND VIEWS |
| G201 | Body harness and instrument panel harness | In the passenger compartment, at base of left a-pillar | GROUND VIEWS | |
| G203 | Instrument panel harness | In the passenger compartment, on instrument panel support, near left a-pillar | GROUND VIEWS | |
| G205 | Body harness and instrument panel harness | In the passenger compartment, at base of right a-pillar | GROUND VIEWS | |
| G206 | Instrument panel harness | In the passenger compartment, on instrument panel support, left of center, near instrument cluster | GROUND VIEWS | |
| G302 | Body harness | In the passenger compartment, at base of right a-pillar | GROUND VIEWS | |
| G303 | Body harness and instrument panel harness | In the passenger compartment, on floor on forward side of left front seat brace | GROUND VIEWS | |
| G304 | Body harness | In the passenger compartment, at base of left a-pillar | GROUND VIEWS | |
| G305 | Body harness and instrument panel harness | In the passenger compartment, on floor on forward side of left front seat brace | GROUND VIEWS | |
| G306 | Body harness | In the rear compartment, right side below lid opening | GROUND VIEWS | |
| G401 | Body harness | In the rear compartment, left side on left rear wheel tub | GROUND VIEWS | |
| G404 | Defogger ground harness | In the passenger compartment, on right c-pillar | GROUND VIEWS | |
| J100 | Front bumper harness | T96 | At front of vehicle, between fog lamp - left front and ambient temperature sensor | HARNESS ROUTING VIEWS |
| J101 | Front bumper harness | T96 | At front of vehicle, between fog lamp - left front and ambient temperature sensor | HARNESS ROUTING VIEWS |
| J102 | Front bumper harness | UD5 or UDP | At front of vehicle, on branch, between main bundle and X101 | HARNESS ROUTING VIEWS |
| J103 | Front bumper harness | UD5 or UDP | At front of vehicle, on branch, between main bundle and X101 | HARNESS ROUTING VIEWS |
| J104 | Front bumper harness | At front of vehicle, in main bundle, right of breakout to X101 | HARNESS ROUTING VIEWS | |
| J105 | Engine cooling harness | At front of vehicle, on branch, between main bundle and relay block - underhood | HARNESS ROUTING VIEWS | |
| J106 | Engine cooling harness | At front of vehicle, on branch, between main bundle and relay block - underhood | HARNESS ROUTING VIEWS | |
| J107 | Engine cooling harness | At front of vehicle, on branch, between main bundle and relay block - underhood | HARNESS ROUTING VIEWS | |
| J108 | Engine cooling harness | At front of vehicle, on branch, between main bundle and cooling fan motor - left | HARNESS ROUTING VIEWS | |
| J109 | Engine harness | LAU | In the engine compartment, 50 mm from the breakout to the branch to bank 2 components | HARNESS ROUTING VIEWS |
| LDK | In the engine compartment, in main bundle, near breakout to high pressure fuel pump | HARNESS ROUTING VIEWS | ||
| J110 | Engine harness | LAU | In the engine compartment, on breakout to engine control module X2 | HARNESS ROUTING VIEWS |
| J110 | Engine harness | LDK | In the engine compartment, in branch between fuse block - underhood and G120 | HARNESS ROUTING VIEWS |
| J110 | Engine harness | LBS | In the engine compartment, between G124 and breakout to fuse block - underhood | HARNESS ROUTING VIEWS |
| J111 | Engine harness | LAU | In the engine compartment, in the formed conduit by throttle body | HARNESS ROUTING VIEWS |
| J111 | Engine harness | LDK | In the engine compartment, in branch between engine control module x2 and main bundle | HARNESS ROUTING VIEWS |
| J112 | Engine harness | LAU | In the engine compartment, in the branch to turbo charger wastegate solenoid | HARNESS ROUTING VIEWS |
| J112 | Engine harness | LBS | In the engine compartment, between G124 and breakout to engine control module X1 | HARNESS ROUTING VIEWS |
| J112 | Engine harness | LDK | In the engine compartment, in branch between fuse block - underhood and G120 | HARNESS ROUTING VIEWS |
| J113 | Engine harness | LAU | In the engine compartment, on breakout to x108 | HARNESS ROUTING VIEWS |
| J113 | Engine harness | LBS | In the engine compartment, between G124 and breakout to engine control module X1 | HARNESS ROUTING VIEWS |
| J113 | Engine harness | LDK | In the engine compartment, in branch between engine control module x2 and main bundle | HARNESS ROUTING VIEWS |
| J114 | Engine harness | LBS | In the engine compartment, between G124 and breakout to fuse block - underhood | HARNESS ROUTING VIEWS |
| J114 | Engine harness | LAU | In the engine compartment, between fuse block - underhood and G120 | HARNESS ROUTING VIEWS |
| J115 | Engine harness | LAU | In the engine compartment, between fuse block - underhood and G120 | HARNESS ROUTING VIEWS |
| J115 | Engine harness | LDK | In the engine compartment, in branch between fuse block - underhood and G120 | HARNESS ROUTING VIEWS |
| J116 | Engine harness | LAU | 90 mm from the breakout to the camshaft position sensors, toward those sensors | HARNESS ROUTING VIEWS |
| LDK | Near breakout to high pressure fuel pump, toward breakout to throttle body | HARNESS ROUTING VIEWS | ||
| J117 | Engine harness | LAU | In the engine compartment, between fuse block - underhood and G120 | HARNESS ROUTING VIEWS |
| J117 | Engine harness | LBS | In the engine compartment, between G124 and breakout to fuse block - underhood | HARNESS ROUTING VIEWS |
| J117 | Engine harness | LDK | In the engine compartment, in branch between fuse block - underhood and G120 | HARNESS ROUTING VIEWS |
| J119 | Engine harness | LAU | In the engine compartment, in the formed conduit by throttle body | HARNESS ROUTING VIEWS |
| J120 | Engine harness | LDK | In the engine compartment, in branch between ignition coil 4 and breakout to heated oxygen sensor 1 | HARNESS ROUTING VIEWS |
| J120 | Engine harness | LAU | In the engine compartment, in the formed conduit by throttle body | HARNESS ROUTING VIEWS |
| J121 | Engine harness | LAU | In the engine compartment, in the formed conduit near G123 | HARNESS ROUTING VIEWS |
| J122 | Engine harness | LAU | In the engine compartment, in the breakout to G122 | HARNESS ROUTING VIEWS |
| J122 | Engine harness | LDK | In the engine compartment, in branch between ignition coil 4 and breakout to heated oxygen sensor 1 | HARNESS ROUTING VIEWS |
| J123 | Engine harness | LAU | In the engine compartment, in the breakout to G123 | HARNESS ROUTING VIEWS |
| J124 | Engine harness | LAU | In the engine compartment, in the formed conduit by throttle body | HARNESS ROUTING VIEWS |
| J124 | Engine harness | LDK | In the engine compartment, in branch between | HARNESS ROUTING VIEWS |
| J125 | Engine harness | LAU | In the engine compartment, in the breakout to ignition coils - 2, 4, and 6 | HARNESS ROUTING VIEWS |
| J125 | Engine harness | LDK | In the engine compartment, in branch between ignition coil 4 and breakout to heated oxygen sensor 1 | HARNESS ROUTING VIEWS |
| J126 | Engine harness | LAU | In the engine compartment, in the formed conduit by throttle body | HARNESS ROUTING VIEWS |
| J127 | Engine harness | LAU | In the engine compartment, in the formed conduit near G123 | HARNESS ROUTING VIEWS |
| J127 | Engine harness | LDK | In the engine compartment, in branch between fuse block - underhood and G120 | HARNESS ROUTING VIEWS |
| J128 | Engine harness | LAU | In the engine compartment, in the formed conduit near G123 | HARNESS ROUTING VIEWS |
| J128 | Engine harness | LDK | In the engine compartment, in branch between engine control module x2 and main bundle | HARNESS ROUTING VIEWS |
| J129 | Engine harness | LAU | In the engine compartment, in the branch between G120 and main bundle | HARNESS ROUTING VIEWS |
| J129 | Engine harness | LDK | In the engine compartment, in main bundle, near breakout to high pressure fuel pump | HARNESS ROUTING VIEWS |
| J130 | Engine harness | LBS | In the engine compartment, between G124 and breakout to fuse block - underhood | HARNESS ROUTING VIEWS |
| J131 | Body harness | LHD | In the engine compartment, under cowling, between windshield wiper motor and air quality sensor | HARNESS ROUTING VIEWS |
| J131 | Forward lamp harness | RHD | In the engine compartment, under cowling, between security siren and air quality sensor | HARNESS ROUTING VIEWS |
| J132 | Body harness | LHD | In the engine compartment, under cowling, between windshield wiper motor and air quality sensor | HARNESS ROUTING VIEWS |
| J132 | Forward lamp harness | RHD with TR7 | In the engine compartment, under cowling, between windshield wiper motor and air quality sensor | HARNESS ROUTING VIEWS |
| J133 | Forward lamp harness | RHD | In the engine compartment, under cowling, between windshield wiper motor and G102 | HARNESS ROUTING VIEWS |
| J134 | Forward lamp harness | RHD | In the engine compartment, under cowling, between windshield wiper motor and G102 | HARNESS ROUTING VIEWS |
| J135 | Body harness | LHD | In the engine compartment, under cowling, between security siren and G102 | HARNESS ROUTING VIEWS |
| J135 | Forward lamp harness | RHD | In the engine compartment, under cowling, between windshield wiper motor and G102 | HARNESS ROUTING VIEWS |
| J136 | Body harness | LHD | In the engine compartment, in the main bundle between, G109 and fuse block - underhood | HARNESS ROUTING VIEWS |
| J136 | Forward lamp harness | RHD | In the engine compartment, in the main bundle between, G109 and fuse block - underhood | HARNESS ROUTING VIEWS |
| J137 | Body harness | LHD | In the engine compartment, in the main bundle between, G109 and fuse block - underhood | HARNESS ROUTING VIEWS |
| J137 | Forward lamp harness | RHD | In the engine compartment, in the main bundle between, G109 and fuse block - underhood | HARNESS ROUTING VIEWS |
| J138 | Body harness | LHD | In the engine compartment, in the main bundle between, X109 and horn | HARNESS ROUTING VIEWS |
| J138 | Forward lamp harness | RHD | In the engine compartment, in the main bundle between, X109 and horn | HARNESS ROUTING VIEWS |
| J139 | Body harness | In the engine compartment, in the main bundle, between breakout to electronic brake control module and left bulkhead grommet | HARNESS ROUTING VIEWS | |
| J140 | Body harness | In the engine compartment, in the main bundle, between breakout to electronic brake control module and left bulkhead grommet | HARNESS ROUTING VIEWS | |
| J141 | Body harness | In the engine compartment, in the main bundle, between breakout to electronic brake control module and left bulkhead grommet | HARNESS ROUTING VIEWS | |
| J142 | Body harness | In the engine compartment, in the main bundle, between breakout to electronic brake control module and left bulkhead grommet | HARNESS ROUTING VIEWS | |
| J143 | Oil level jumper harness | LBS | In the engine compartment, in main bundle, between crankshaft position sensor and X109 | HARNESS ROUTING VIEWS |
| J144 | Fuel injector odd harness | LAU | In the engine compartment, at top of engine, below intake manifold, in the main bundle | HARNESS ROUTING VIEWS |
| J145 | Fuel injector even harness | LAU | In the engine compartment, at top of engine, below intake manifold, in the main bundle | HARNESS ROUTING VIEWS |
| J150 | Engine harness | LAU | In the engine compartment, in the formed conduit near G123 | HARNESS ROUTING VIEWS |
| J201 | Instrument panel harness | In the passenger compartment, in the main bundle, near data link resistor | HARNESS ROUTING VIEWS | |
| J202 | Instrument panel harness | In the passenger compartment, in the main bundle, near data link resistor | HARNESS ROUTING VIEWS | |
| J203 | Instrument panel harness | In the passenger compartment, in the main bundle, near data link resistor | HARNESS ROUTING VIEWS | |
| J204 | Instrument panel harness | ASV | In the passenger compartment, on the branch leading to remote control door lock receiver | HARNESS ROUTING VIEWS |
| J205 | Instrument panel harness | UDT | In the passenger compartment, on the branch leading to info display module | HARNESS ROUTING VIEWS |
| J206 | Instrument panel harness | CJ4 | In the passenger compartment, in branch between G305 and X210 | HARNESS ROUTING VIEWS |
| J207 | Instrument panel harness | In the passenger compartment, in branch between G305 and X210 | HARNESS ROUTING VIEWS | |
| J208 | Instrument panel harness | M36 | In the passenger compartment, in branch between breakout to HVAC control module and steering column | HARNESS ROUTING VIEWS |
| J209 | Instrument panel harness | In the passenger compartment, in branch between breakout to HVAC control module and steering column | HARNESS ROUTING VIEWS | |
| J210 | Instrument panel harness | In the passenger compartment, in branch between breakout to HVAC control module and steering column | HARNESS ROUTING VIEWS | |
| J211 | Instrument panel harness | K34, UVT, or W1Y | In the passenger compartment, in branch leading to steering column | HARNESS ROUTING VIEWS |
| J212 | Instrument panel harness | TSQ | In the passenger compartment, in the main bundle near instrument cluster | HARNESS ROUTING VIEWS |
| J213 | Instrument panel harness | In the passenger compartment, in the main bundle near instrument cluster | HARNESS ROUTING VIEWS | |
| J214 | Instrument panel harness | In the passenger compartment, in the main bundle near instrument cluster | HARNESS ROUTING VIEWS | |
| J215 | Instrument panel harness | In the passenger compartment, in the main bundle near instrument cluster | HARNESS ROUTING VIEWS | |
| J216 | Instrument panel harness | In the passenger compartment, in the main bundle near instrument cluster | HARNESS ROUTING VIEWS | |
| J217 | Instrument panel harness | In the passenger compartment, in the main bundle near instrument cluster | HARNESS ROUTING VIEWS | |
| J218 | Instrument panel harness | In the passenger compartment, in the main bundle, in formed conduit, near center of instrument panel | HARNESS ROUTING VIEWS | |
| J219 | Instrument panel harness | In the passenger compartment, in the main bundle, in formed conduit, near center of instrument panel | HARNESS ROUTING VIEWS | |
| J220 | Instrument panel harness | In the passenger compartment, in the main bundle, in formed conduit, near center of instrument panel | HARNESS ROUTING VIEWS | |
| J221 | Instrument panel harness | In the passenger compartment, in the main bundle, in formed conduit, near center of instrument panel | HARNESS ROUTING VIEWS | |
| J222 | Instrument panel harness | UBT, ULD, or UWG | In the passenger compartment, in the main bundle, near data link resistor | HARNESS ROUTING VIEWS |
| J223 | Instrument panel harness | In the passenger compartment, in the main bundle near fuse block - instrument panel | HARNESS ROUTING VIEWS | |
| J224 | Instrument panel harness | In the passenger compartment, in the main bundle near fuse block - instrument panel | HARNESS ROUTING VIEWS | |
| J225 | Instrument panel harness | In the passenger compartment, in the main bundle, between G201 and data link connector | HARNESS ROUTING VIEWS | |
| J226 | Instrument panel harness | In the passenger compartment, in the main bundle, between G201 and data link connector | HARNESS ROUTING VIEWS | |
| J227 | Body harness | In the engine compartment, in the main bundle, between breakout to left front door inline and left bulkhead grommet | HARNESS ROUTING VIEWS | |
| J228 | Body harness | F45 | In the engine compartment, in the main bundle, between breakout to left front door inline and left bulkhead grommet | HARNESS ROUTING VIEWS |
| J229 | Body harness | F45 | In the engine compartment, in the main bundle, between breakout to left front door inline and left bulkhead grommet | HARNESS ROUTING VIEWS |
| J230 | Body harness | In the engine compartment, in the main bundle, between breakout to left front door inline and left bulkhead grommet | HARNESS ROUTING VIEWS | |
| J231 | Body harness | In the engine compartment, in the main bundle, between breakout to left front door inline and G201 | HARNESS ROUTING VIEWS | |
| J232 | Body harness | In the engine compartment, in the branch to body control module, near breakout to left front door inline | HARNESS ROUTING VIEWS | |
| J233 | Body harness | In the engine compartment, in the main bundle, between breakout to left front door inline and G201 | HARNESS ROUTING VIEWS | |
| J234 | Body harness | In the engine compartment, in the branch to body control module, near breakout to left front door inline | HARNESS ROUTING VIEWS | |
| J235 | Body harness | In the engine compartment, in the branch to body control module, near breakout to left front door inline | HARNESS ROUTING VIEWS | |
| J236 | Body harness | M36, UJN, or UTR | In the engine compartment, in the main bundle, between breakout to left front door inline and G201 | HARNESS ROUTING VIEWS |
| J237 | Body harness | In the engine compartment, in the main bundle, between breakout to left front door inline and G201 | HARNESS ROUTING VIEWS | |
| J238 | Body harness | In the engine compartment, in the main bundle, between breakout to left front door inline and G201 | HARNESS ROUTING VIEWS | |
| J239 | Body harness | DWD or DWJ | In the engine compartment, in the main bundle, between breakout to left front door inline and G201 | HARNESS ROUTING VIEWS |
| J240 | Body harness | DWD or DWJ | In the engine compartment, in the main bundle, between breakout to left front door inline and G201 | HARNESS ROUTING VIEWS |
| J241 | Body harness | DD8 | In the engine compartment, in the main bundle, between breakout to left front door inline and G201 | HARNESS ROUTING VIEWS |
| J242 | Body harness | TR6 | In the engine compartment, in the main bundle, between breakout to left front door inline and G201 | HARNESS ROUTING VIEWS |
| J243 | Body harness | In the engine compartment, in the main bundle, between breakout to left front door inline and G201 | HARNESS ROUTING VIEWS | |
| J244 | Body harness | CE1 with TTW, or UVL or UVT | In the passenger compartment, on branch to inside rearview mirror, before breakout | HARNESS ROUTING VIEWS |
| J245 | Instrument panel harness | U63 or U65 | In the passenger compartment, on the branch leading to radio x1 | HARNESS ROUTING VIEWS |
| J246 | Instrument panel harness | U63 or U65 | In the passenger compartment, on the branch leading to radio x1 | HARNESS ROUTING VIEWS |
| J247 | Steering Wheel harness | K34, UVT, or W1Y | In the passenger compartment, in the steering wheel, in the main bundle | HARNESS ROUTING VIEWS |
| J248 | Instrument panel harness | In the passenger compartment, in the main bundle near fuse block - instrument panel | HARNESS ROUTING VIEWS | |
| J249 | Instrument panel harness | TR6 with C32 | In the passenger compartment, in the main bundle, between G203 and data link connector | HARNESS ROUTING VIEWS |
| J301 | Console harness | In the passenger compartment, in the main bundle, between ignition mode switch and multifunction switch - center console | HARNESS ROUTING VIEWS | |
| J302 | Console harness | URC with UD5, UDP, UVL, or UVT | In the passenger compartment, in the main bundle, between ignition mode switch and multifunction switch - center console | HARNESS ROUTING VIEWS |
| J302 | Console harness | In the passenger compartment, in the main bundle, between ignition mode switch and multifunction switch - center console | HARNESS ROUTING VIEWS | |
| J304 | Console harness | In the passenger compartment, in the main bundle, between ignition mode switch and multifunction switch - center console | HARNESS ROUTING VIEWS | |
| J305 | Body harness | In the passenger compartment, in the main bundle, between G201 and formed conduit near left front seat | HARNESS ROUTING VIEWS | |
| J306 | Body harness | In the passenger compartment, in the main bundle, between G201 and formed conduit near left front seat | HARNESS ROUTING VIEWS | |
| J307 | Body harness | In the passenger compartment, in the main bundle, between G201 and formed conduit near left front seat | HARNESS ROUTING VIEWS | |
| J308 | Body harness | In the passenger compartment, in the main bundle, between G201 and formed conduit near left front seat | HARNESS ROUTING VIEWS | |
| J309 | Body harness | In the passenger compartment, in the main bundle, between G201 and formed conduit near left front seat | HARNESS ROUTING VIEWS | |
| J310 | Body harness | DWD or DWJ | In the passenger compartment, in the main bundle, between G201 and formed conduit near left front seat | HARNESS ROUTING VIEWS |
| J311 | Body harness | In the passenger compartment, in the main bundle, between G201 and formed conduit near left front seat | HARNESS ROUTING VIEWS | |
| J312 | Body harness | UTT | In the passenger compartment, in the main bundle, between G201 and formed conduit near left front seat | HARNESS ROUTING VIEWS |
| J313 | Body harness | A45 | In the passenger compartment, in the main bundle, between G305 and formed conduit near left front seat | HARNESS ROUTING VIEWS |
| J314 | Body harness | In the passenger compartment, in the main bundle, between breakout to side impact sensor - left front and formed conduit near left front seat | HARNESS ROUTING VIEWS | |
| J315 | Body harness | In the passenger compartment, in the main bundle, between breakout to side impact sensor - left front and formed conduit near left front seat | HARNESS ROUTING VIEWS | |
| J316 | Body harness | KU1 with KU3 | In the passenger compartment, in the main bundle, between breakout to side impact sensor - left front and formed conduit near left front seat | HARNESS ROUTING VIEWS |
| J317 | Body harness | In the passenger compartment, in the main bundle, between breakout to side impact sensor - left front and formed conduit near left front seat | HARNESS ROUTING VIEWS | |
| J318 | Body harness | In the passenger compartment, in the main bundle, between breakout to side impact sensor - left front and formed conduit near left b-pillar | HARNESS ROUTING VIEWS | |
| J319 | Body harness | In the passenger compartment, in the main bundle, between breakout to side impact sensor - left front and formed conduit near left b-pillar | HARNESS ROUTING VIEWS | |
| J320 | Body harness | In the passenger compartment, in the main bundle, between breakout to side impact sensor - left front and formed conduit near left b-pillar | HARNESS ROUTING VIEWS | |
| J321 | Body harness | C3U | In the passenger compartment, in the main bundle, between breakout to side impact sensor - left front and formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J322 | Body harness | UWG | In the passenger compartment, in the main bundle, between breakout to side impact sensor - left front and formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J323 | Body harness | UWG | In the passenger compartment, in the main bundle, rearward of the formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J324 | Body harness | UH5 | In the passenger compartment, in the main bundle, rearward of the formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J325 | Body harness | C3U | In the passenger compartment, in the main bundle, in the formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J326 | Body harness | C3U | In the passenger compartment, in the main bundle, in the formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J327 | Body harness | LHD with UD5 or UDP | In the passenger compartment, in the main bundle, in the formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J328 | Body harness | LHD with UD5 or UDP | In the passenger compartment, in the main bundle, in the formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J329 | Body harness | LHD with UDP | In the passenger compartment, in the main bundle, in the formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J330 | Body harness | LHD with UDP | In the passenger compartment, in the main bundle, in the formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J331 | Body harness | LHD with UD5 or UDP | In the passenger compartment, in the main bundle, in the formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J332 | Body harness | LHD with UD5 or UDP | In the passenger compartment, in the main bundle, in the formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J333 | Body harness | LHD with UD5 or UDP | In the passenger compartment, in the main bundle, in the formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J334 | Body harness | LHD with UD5 or UDP | In the passenger compartment, in the main bundle, in the formed conduit near left b-pillar | HARNESS ROUTING VIEWS |
| J335 | Body harness | In the passenger compartment, in the main bundle, rearward of the formed conduit near left b-pillar | HARNESS ROUTING VIEWS | |
| J336 | Body harness | In the passenger compartment, in the main bundle, rearward of the formed conduit near left b-pillar, near c-pillar | HARNESS ROUTING VIEWS | |
| J337 | Body harness | In the passenger compartment, in the main bundle, rearward of the formed conduit near left b-pillar, near c-pillar | HARNESS ROUTING VIEWS | |
| J338 | Body harness | UD5, UDP, or UTR | In the passenger compartment, in the main bundle, rearward of the formed conduit near left b-pillar, near c-pillar | HARNESS ROUTING VIEWS |
| J339 | Body harness | In the passenger compartment, in the main bundle, rearward of the formed conduit near left b-pillar, near c-pillar | HARNESS ROUTING VIEWS | |
| J340 | Body harness | F45 or UG1 | In the passenger compartment, in the main bundle, rearward of the formed conduit near left b-pillar, near c-pillar | HARNESS ROUTING VIEWS |
| J341 | Body harness | In the passenger compartment, in the main bundle, between G302 and formed conduit near right front seat | HARNESS ROUTING VIEWS | |
| J342 | Body harness | UWG | In the passenger compartment, in the main bundle, between G302 and formed conduit near right front seat | HARNESS ROUTING VIEWS |
| J343 | Body harness | UWG | In the passenger compartment, in the main bundle, between G302 and formed conduit near right front seat | HARNESS ROUTING VIEWS |
| J344 | Body harness | In the passenger compartment, in the branch, between formed conduit at center floor and formed conduit near right front seat | HARNESS ROUTING VIEWS | |
| J345 | Body harness | In the passenger compartment, in the branch, between formed conduit at center floor and formed conduit near right front seat | HARNESS ROUTING VIEWS | |
| J346 | Headliner harness | In the passenger compartment, in the main bundle, between dome/reading lamp - front and sunshade - right | HARNESS ROUTING VIEWS | |
| J347 | Headliner harness | In the passenger compartment, in the main bundle, between dome/reading lamp - front and sunshade - left | HARNESS ROUTING VIEWS | |
| J348 | Headliner harness | In the passenger compartment, in the main bundle, between dome/reading lamp - middle and sunshade - left | HARNESS ROUTING VIEWS | |
| J349 | Headliner harness | In the passenger compartment, in the main bundle, between dome/reading lamp - middle and X397 | HARNESS ROUTING VIEWS | |
| J350 | Driver seat harness | KU1 | In the passenger compartment, in the main bundle near breakout to seat horizontal motor | HARNESS ROUTING VIEWS |
| J351 | Driver seat harness | A45 | In the passenger compartment, in breakout to Memory seat Control Module | HARNESS ROUTING VIEWS |
| J352 | Driver seat harness | In the passenger compartment, in the main bundle past breakout to anchor pretensioner | HARNESS ROUTING VIEWS | |
| J353 | Driver seat harness | A6B | In the passenger compartment, in breakout to seat adjuster switch - driver | HARNESS ROUTING VIEWS |
| J354 | Driver seat harness | A45, APG, KA1, or KU1 | In the passenger compartment, in the main bundle near breakout to recline motor | HARNESS ROUTING VIEWS |
| J355 | Driver seat harness | KU1 | In the passenger compartment, in the main bundle near breakout to recline motor | HARNESS ROUTING VIEWS |
| J356 | Driver seat harness | UWG | In the passenger compartment, between X301 and video display - driver seat headrest | HARNESS ROUTING VIEWS |
| J360 | Passenger seat harness | KU3 | In the passenger compartment, in the main bundle past breakout to anchor pretensioner | HARNESS ROUTING VIEWS |
| J362 | Passenger seat harness | In the passenger compartment, in the main bundle past breakout to anchor pretensioner | HARNESS ROUTING VIEWS | |
| J363 | Passenger seat harness | A6D | In the passenger compartment, in breakout to seat adjuster switch - passenger | HARNESS ROUTING VIEWS |
| J364 | Passenger seat harness | APH or KU3 | In the passenger compartment, in the main bundle near breakout to recline motor | HARNESS ROUTING VIEWS |
| J365 | Passenger seat harness | KU3 | In the passenger compartment, in the main bundle near breakout to recline motor | HARNESS ROUTING VIEWS |
| J366 | Passenger seat harness | UWG | In the passenger compartment, between X302 and video display - passenger seat headrest | HARNESS ROUTING VIEWS |
| J400 | Body harness | In the rear compartment, in the main bundle, rearward of the breakout to right rear wheel well | HARNESS ROUTING VIEWS | |
| J401 | Body harness | LAU or LDK | In the rear compartment, in the main bundle, forward of the breakout to right rear wheel well | HARNESS ROUTING VIEWS |
| J402 | Body harness | LBS | In the rear compartment, in the main bundle, forward of the breakout to right rear wheel well | HARNESS ROUTING VIEWS |
| J403 | Body harness | In the rear compartment, near grommet at rear of body | HARNESS ROUTING VIEWS | |
| J404 | Body harness | In the left rear wheel well, between grommet and parking brake control module | HARNESS ROUTING VIEWS | |
| J405 | Body harness | F45 or F46 | In the rear compartment, in the branch to left rear wheel well, between breakout to keyless entry antenna and grommet | HARNESS ROUTING VIEWS |
| J406 | Body harness | F46 | In the rear compartment, in the branch to left rear wheel well, between breakout to keyless entry antenna and main bundle | HARNESS ROUTING VIEWS |
| J407 | Body harness | F45 or F46 | In the rear compartment, in the branch to left rear wheel well, between breakout to keyless entry antenna and grommet | HARNESS ROUTING VIEWS |
| J408 | Body harness | F46 | In the rear compartment, in the branch to left rear wheel well, between breakout to keyless entry antenna and main bundle | HARNESS ROUTING VIEWS |
| J409 | Body harness | In the rear compartment, in the main bundle, between G401 and breakout to left rear wheel well | HARNESS ROUTING VIEWS | |
| J410 | Body harness | In the rear compartment, in the main bundle, between G401 and breakout to left rear wheel well | HARNESS ROUTING VIEWS | |
| J411 | Body harness | In the rear compartment, in the main bundle, between G401 and breakout to left rear wheel well | HARNESS ROUTING VIEWS | |
| J412 | Body harness | V9B | In the rear compartment, in the main bundle, between G401 and breakout to left rear wheel well | HARNESS ROUTING VIEWS |
| J413 | Body harness | F45 | In the rear compartment, in the main bundle, between G401 and breakout to left rear wheel well | HARNESS ROUTING VIEWS |
| J414 | Body harness | F45 | In the rear compartment, in the main bundle, between G401 and breakout to left rear wheel well | HARNESS ROUTING VIEWS |
| J415 | Body harness | V9B | In the rear compartment, in the main bundle, between G401 and breakout to left rear wheel well | HARNESS ROUTING VIEWS |
| J416 | Body harness | In the rear compartment, in the main bundle, between G401 and breakout to left rear wheel well | HARNESS ROUTING VIEWS | |
| J479 | Rear Bumper harness | UD5 or UDP | At rear of vehicle, in main bundle between, rear object sensor - left middle and rear object sensor - right middle | HARNESS ROUTING VIEWS |
| J480 | Rear Bumper harness | UD5 or UDP | At rear of vehicle, in main bundle between, rear object sensor - left middle and rear object sensor - right middle | HARNESS ROUTING VIEWS |
| J501 | Driver door harness | In the driver door, in branch, between speaker and lower door grommet | HARNESS ROUTING VIEWS | |
| J502 | Driver door harness | TSQ | In the driver door, in branch, between speaker and lower door grommet | HARNESS ROUTING VIEWS |
| J503 | Driver door harness | In the driver door, in branch, between speaker and lower door grommet | HARNESS ROUTING VIEWS | |
| J504 | Driver door harness | In the driver door, in branch, between speaker and lower door grommet | HARNESS ROUTING VIEWS | |
| J505 | Driver door harness | In the driver door, in branch, between outside rearview mirror switch and lower door grommet | HARNESS ROUTING VIEWS | |
| J506 | Driver door harness | Without A45 | In the driver door, in branch, between outside rearview mirror switch and lower door grommet | HARNESS ROUTING VIEWS |
| J507 | Driver door harness | Without A45 | In the driver door, in branch, between outside rearview mirror switch and lower door grommet | HARNESS ROUTING VIEWS |
| J508 | Driver door harness | In the driver door, in branch, between window switch - driver and lower door grommet | HARNESS ROUTING VIEWS | |
| J509 | Driver door harness | In the driver door, in branch, between outside rearview mirror switch and lower door grommet | HARNESS ROUTING VIEWS | |
| J515 | Outside rearview mirror - driver harness | In the driver door, in the outside rearview mirror - driver | HARNESS ROUTING VIEWS | |
| J602 | Passenger door harness | TSQ | In the passenger door, in branch, between speaker and lower door grommet | HARNESS ROUTING VIEWS |
| J603 | Passenger door harness | In the passenger door, in branch, between speaker and lower door grommet | HARNESS ROUTING VIEWS | |
| J604 | Passenger door harness | In the passenger door, in branch, between speaker and lower door grommet | HARNESS ROUTING VIEWS | |
| J605 | Passenger door harness | In the passenger door, in branch, between outside rearview mirror switch and lower door grommet | HARNESS ROUTING VIEWS | |
| J609 | Passenger door harness | In the passenger door, in branch, between outside rearview mirror switch and lower door grommet | HARNESS ROUTING VIEWS | |
| J615 | Outside rearview mirror - passenger harness | In the passenger door, in the outside rearview mirror - passenger | HARNESS ROUTING VIEWS | |
| J701 | Left rear door harness | In the left rear door, in main bundle, between lower grommet and breakout to window motor | HARNESS ROUTING VIEWS | |
| J702 | Left rear door harness | TSQ | In the left rear door, in main bundle, between lower grommet and breakout to speaker | HARNESS ROUTING VIEWS |
| J703 | Left rear door harness | In the left rear door, in main bundle, between door latch assembly and breakout to window motor | HARNESS ROUTING VIEWS | |
| J801 | Right rear door harness | In the right rear door, in main bundle, between lower grommet and breakout to window motor | HARNESS ROUTING VIEWS | |
| J802 | Right rear door harness | TSQ | In the right rear door, in main bundle, between lower grommet and breakout to speaker | HARNESS ROUTING VIEWS |
| J803 | Right rear door harness | In the right rear door, in main bundle, between door latch assembly and breakout to window motor | HARNESS ROUTING VIEWS |
Steering column lock, diagram
COLUMN LOCK (ULS)
Scheme 10
List of components
| No | Name Location |
|---|---|
| Components | |
| X51A | Instrument Panel Electrical Centre |
| X50A | Underhood Electrical Centre |
| KR73 | Ignition Main Relay |
| K9 | Body Control Module |
| K60 | Control unit, steering column lock |
| A90 | Logic |
| K84 | Keyless Entry Control Module |
VEHICLES CONCERNED
Saab 9-5 (650) MY10 - MY11.
BACKGROUND
A number of various issues can cause similar symptoms and failure message "Service Steering Column Lock" and the car will not start. Diagnostic Trouble Codes, (DTCs), must be checked before any rectification is done. Depending on which trouble codes are set, specific measures need to be carried out. This is important so the car does not return to with the same issue. See details below.
CONDITIONS
Message "Service Steering Column Lock" in the Driver Information Center (DIC).
Scheme 11
ACTION
DTC B305A 00 (MY11 s/w)
Download new Body Control Module (BCM) software, part number 13582397 and reconfigure BCM.
DTC U0236
No communication with Steering Column Lock (SCL). This DTC can be set when outside air temperature is below 0° C. This is due to a faulty capacitor in the SCL. Replace the SCL
DTC B297E 5A/B297C 5A
Update Passive Entry Passive Start (PEPS), with new software part number 13578648.
DTC B144C 06
No action. Analysis is ongoing. Please contact ASAC for latest information.
DTC U1534/U1538 (can also be other DTCs referring to door module)
This is fixed in production from VIN B4001033. No communication with Door Module (left front door/right front door). Remove door panels on respective door and check/repair cables that have been damaged due to contact with the sheet metal glass guide. Below is an example of a damaged wiring and how to repair this.
