Dice: Overview Saab 9-5 I рестайлинг

Scheme 5

Scheme 6

1. Remove lower panel from driver's side.
2. Remove the fuse cover (To be better able to see what you're doing).
3. Unplug the connector from on the control module.
4. Remove 2 screws (Torx 25) holding DICE.
5. Pull the DICE control module straight out.

Scheme 7

Scheme 8

1. Fit the control module in place.
2. Screw tight with 2 screws.
3. Plug in the connector to the control module.
4. Refit the fuse cover.
5. Refit the lower panel.
6. After the DICE control module is replaced, it must be programmed into the car.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Location: In the engine bay on the side panel in front of the left-hand wheel housing

System Overview, Wiper Headlamp

1. Control module, DICE (628)
2. Wiper stalk switch (61)
3. Headlamp wiper relay (365)
4. Headlamp Wiper Motor (66Fl, 66Fr)

Scheme 21

1. Control module, DICE (628)
2. Stalk switch, windscreen wipers (61)
3. Headlamp wiper relay (365)
4. Headlamp wiper motor (66FL, 66FR)

Scheme 22

1. Control module, DICE (628)
2. Relay, electrically heated rear window (113)
3. Electrically heated rear window, element (115)
4. Electrically heated door mirrors, elements (207)
5. Control module, ACC (216)
6. Radio aerial amplifier (624)
7. Aerial ground filter (644)

Scheme 23

1. Control module, DICE (628)
2. Electrically heated rear window, switch (116)
3. Relay, electrically heated rear window (113)
4. Electrically heated rear window, element (115)
5. Electrically heated door mirrors, elements (207)
6. MCC control panel (504)
7. Radio aerial amplifier (624)
8. Aerial ground filter (644)

Scheme 24

1. Control module, DICE (628)
2. Electrically heated rear window, switch (116)
3. Relay, electrically heated rear window (113)
4. Electrically heated rear window, element (115)
5. Electrically heated door mirrors, elements (207)
6. Control module, ACC (216)
7. Radio aerial amplifier (624)
8. Aerial ground filter (644)

Scheme 25

1. Control module, DICE (628)
2. Relay, electrically heated rear window (113)
3. Electrically heated rear window, element (115)
4. Electrically heated door mirrors, elements (207)
5. Control module, ACC (216)

Scheme 26

1. Control module, DICE (628)
2. Electrically heated rear window, switch (116)
3. Relay, electrically heated rear window (113)
4. Electrically heated rear window, element (115)
5. Electrically heated door mirrors, elements (207)
6. MCC control panel (504)

Scheme 27

1. Control module, DICE (628)
2. Electrically heated rear window, switch (116)
3. Relay, electrically heated rear window (113)
4. Electrically heated rear window, element (115)
5. Electrically heated door mirrors, elements (207)
6. Control module, ACC (216)

Scheme 28

1. Control module, DICE (628)
2. Relay, 2-speed radiator fan, low speed (155)
3. Relay, 2-speed radiator fan, high-speed (81)
4. High speed RH radiator fan, relay (396)
5. Radiator fans, motor (37LH, 37RH)
6. Engine management system (430, 589, 600, 608)
7. Main instrument display (540)
8. Engine coolant temperature sensor, engine management system (202)
9. Pressure sensor, A/C (620)
10. SID (541)

Scheme 29

1. Control module, DICE (628)
2. Relay, 2-speed radiator fan, low speed (155)
3. Relay, 2-speed radiator fan, high-speed (81)
4. Resistor, 2-speed radiator fan (367)
5. Radiator fan motor (37LH)
6. Engine management system (430, 589, 600, 608)
7. Main instrument display (540)
8. Engine coolant temperature sensor, engine management system (202)
