Scheme 2
Brief Description
The sunroof consists of sunroof unit with a glass hatch fixed to two lifting units. The hatch is driven with wires from an electric motor.
There is a switch on the front roof console to operate the sunroof.
Besides sliding backwards-forwards, the rear of the glass hatch can also raised (tilted).
The sunroof can be operated when the ignition is in position ON (+15) and its electric motor is continuously supplied with +30 via fuse 23.
The electric motor is grounded through pin 6 to grounding point G33.
When the switch is pressed, the respective pins on the electric motor are grounded and the motor starts to operate.
