Crimp J26, engine harness, Trionic
Location: Approx. 170 mm from branching connector H24-2 towards the engine control module
Scheme 126
Crimp J31, engine harness, Trionic
Location: Approx. 20 mm from branching of engine control module switch B towards its switch A
Scheme 127
Crimp J32, engine harness, Trionic
Location: Approx. 70 mm from branching of engine control module switch B towards its switch A
Scheme 128
Crimp J33, engine harness, Trionic
Location: Approx. 20 mm from branching of engine control module switch B towards its switch A
Scheme 129
Crimp J34, engine harness, Trionic
Location: Approx. 70 mm from branching of engine control module switch B towards its switch A
Scheme 130
Crimp J35, engine harness, Trionic
Location: Approx. 40 mm from branching of engine control module switch A towards the ignition coils
Scheme 131
Crimp J36, engine harness, Trionic
Location: Approx. 110 mm from branching of engine control module switch A towards the ignition coils
Scheme 132
Crimp J37, engine harness, Trionic
Location: Approx. 260 mm from branching of crankshaft sensor towards the engine control module
Scheme 133
Crimp J38, engine harness, Trionic
Location: Approx. 160 mm from branching of engine control module switch A towards the ignition coils
Scheme 134
Crimp J39, engine harness, Trionic
Location: Approx. 60 mm from the branching point to the ignition coil with integrated amplifier, cyl.4, towards the combustion sensor
Scheme 135
CRIMP J40, ENGINE HARNESS, TRIONIC
Crimp J40, engine harness, Trionic
Location: Approximately 190 mm from crankshaft position sensor branching point towards the engine control module
Scheme 136
Crimp J42, engine harness, Trionic
Location: Approx. 20 mm from branching point crankshaft sensor towards the engine oil pressure switch
Scheme 137
Crimp J43, engine harness, Trionic
Location: Approx. 30 mm from the branching point to the ignition coil with integrated amplifier, cyl.4, towards the combustion sensor
Scheme 138
Crimp J44, engine harness, Trionic
Location: Approx. 80 mm from the branching point to the ignition coil with integrated amplifier, cyl.4, towards the combustion sensor
Scheme 139
CRIMP J40, ENGINE HARNESS, TRIONIC
Crimp J45, engine harness, Trionic
Location: Approx. 250 mm from branching point connector H24-2 towards the engine control module
Scheme 140
Crimp J46, engine harness, Trionic
Location: Approx. 130 mm from connector H24-2
Scheme 141
Crimp J48, engine harness, Trionic
Location: Approx. 80 mm from branching point ignition coil with integrated power amplifier for cylinder 4 towards the engine control module
Scheme 142
Crimp J95, main harness
Location
4D/5D: Approx. 60 mm from branching point front left door towards engine bay
CV: Approx. 30 mm from branching point left front door to engine bay
