Crimp J95, main harness
Location
4D/5D: Approx. 60 mm from branching point front left door towards engine bay
CV: Approx. 30 mm from branching point left front door to engine bay
Scheme 703
Crimp J290, engine harness ME9
Location: Approx. 50 mm from branching of cylinder 1 ignition coil toward grounding point G7R
Scheme 704
Crimp J291, engine harness ME9
Location: Approx. 30 mm from branching of cylinder 3 ignition coil toward grounding point G7R
Scheme 705
Crimp J292, engine harness ME9
Location: Approx. 30 mm from branching of cylinder 5 ignition coil toward grounding point G7R
Scheme 706
Crimp J293, engine harness ME9
Location: Approx. 110 mm from branching of engine control module toward front cylinder bank
Scheme 707
Crimp J294, engine harness ME9
Location: Approx. 70 mm from branching of engine control module toward engine control module
Scheme 708
Crimp J295, engine harness ME9
Location: Approx. 120 mm from branching of engine control module toward engine control module
Scheme 709
Crimp J297, engine harness ME9
Location: Approx. 70 mm from branching of fuel pressure sensor toward rear cylinder bank
Scheme 710
Crimp J298, engine harness ME9
Location: Approx. 110 from branching of cylinder 2 ignition coil toward rear cylinder bank
Scheme 711
Crimp J299, engine harness ME9
Location: Approx. 40 mm from branching of cylinder 2 ignition coil toward cylinder 4
Scheme 712
Crimp J300, engine harness ME9
Location: Approx. 60 mm from grounding point G7F
Scheme 713
Crimp J308, adapter harness ME9
Location: Approx. 50 mm from branching point battery towards engine control module
Scheme 714
Crimp J309, adapter harness ME9
Location: Approx. 240 mm from branching of battery toward engine control module
Scheme 715
Crimp J311, adapter harness ME9
Location: Approx. 290 mm from branching of battery toward engine control module
Scheme 716
Crimp J312, adapter harness ME9
Location: Approx. 150 mm from branching of battery toward engine control module
Scheme 717
Crimp J319, injector harness, ME9
Location: Approx. 30 mm from branching of cylinder 3 injector toward cylinder 1
Scheme 718
Crimp J320, injector harness, ME9
Location: Approx. 30 mm from branching of cylinder 5 injector toward cylinder 3
