SPECIAL TOOL
| TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|
| ST18231AA010. (Scheme 162) | CAM SPROCKET WRENCH | Used for removing and installing cam sprocket. (LH side) |
| ST1111111111. (Scheme 163) | VEHICLE DIAGNOSTIC INTERFACE | Troubleshooting for electrical system. |
| ST-498267800. (Scheme 164) | CYLINDER HEAD TABLE | Used for replacing valve guides. Used for removing and installing valve spring. |
| ST-498277200. (Scheme 165) | STOPPER SET | Used for installing automatic transmission assembly to engine. |
| ST-498457000. (Scheme 166) | ENGINE STAND ADAPTER RH | Used with ENGINE STAND (32005156). |
| ST-498457100. (Scheme 167) | ENGINE STAND ADAPTER LH | Used with ENGINE STAND (32005156). |
| ST-498497100. (Scheme 168) | CRANKSHAFT STOPPER | Used for stopping rotation of flywheel when loosening/tightening crank pulley bolt. |
| ST-498747300. (Scheme 169) | PISTON GUIDE | Used for installing piston in cylinder. |
| ST-498857100. (Scheme 170) | VALVE OIL SEAL GUIDE | Used for press-fitting of intake and exhaust valve guide oil seals. |
| ST-499017100. (Scheme 171) | PISTON PIN GUIDE | Used for installing piston pin, piston and connecting rod. |
| ST-499037100. (Scheme 172) | CONNECTING ROD BUSHING REMOVER AND INSTALLER | Used for removing and installing connecting rod bushing. |
| ST-499587200. (Scheme 173) | CRANKSHAFT OIL SEAL INSTALLER | Used for installing crankshaft oil seal. Used with CRANKSHAFT OIL SEAL GUIDE (32005141). |
| ST-499587500. (Scheme 174) | OIL SEAL INSTALLER | Used for installing camshaft oil seal. Used with OIL SEAL GUIDE (32005140). |
| ST-499587700. (Scheme 175) | CAMSHAFT OIL SEAL INSTALLER | Used for installing cylinder head plug. |
| ST-499097700. (Scheme 176) | PISTON PIN REMOVER ASSY | Used for removing piston pin. |
| ST-499207400. (Scheme 177) | CAM SPROCKET WRENCH | Used for removing and installing cam sprocket. (RH side) |
| ST-499497000. (Scheme 178) | TORX(R) PLUS | Used for removing and installing camshaft cap. |
| ST-499587100. (Scheme 179) | OIL SEAL INSTALLER | Used for installing oil pump oil seal. |
| ST-499597000. (Scheme 180) | OIL SEAL GUIDE | Used for installing camshaft oil seal. Used with CAMSHAFT OIL SEAL INSTALLER (32005137). |
| ST-499597100. (Scheme 181) | CRANKSHAFT OIL SEAL GUIDE | Used for installing crankshaft oil seal. Used with CRANKSHAFT OIL SEAL INSTALLER (32005136). |
| ST-499718000. (Scheme 182) | VALVE SPRING REMOVER | Used for removing and installing valve spring. |
| ST-499767200. (Scheme 183) | VALVE GUIDE REMOVER | Used for removing valve guides. |
| ST-499767400. (Scheme 184) | VALVE GUIDE REAMER | Used for reaming valve guides. |
| ST-499767700. (Scheme 185) | VALVE GUIDE ADJUSTER | Used for installing valve guides. (Intake side) |
| ST-499767800. (Scheme 186) | VALVE GUIDE ADJUSTER | Used for installing valve guides. (Exhaust side) |
| ST-499817100. (Scheme 187) | ENGINE STAND | Stand used for engine disassembly and assembly. Used with ENGINE STAND ADAPTER RH (32005105) & LH (32005106). |
| ST-499977100. (Scheme 188) | CRANK PULLEY WRENCH | Used for stopping rotation of crank pulley when loosening/tightening crank pulley bolt. |
| ST18332AA000. (Scheme 189) | OIL FILTER WRENCH | Used for removing and installing oil filter. (Outer diameter: 68 mm (2.68 in)) |
| ST-499987500. (Scheme 190) | CRANKSHAFT SOCKET | Used for rotating crankshaft. |
| ST42099AE000. (Scheme 191) | CONNECTOR REMOVER | Used for removing quick connector. |
