Intake (Induction), 2.5L: Removal & Installation Saab 9-2X I

Mechanical 10 illustrations ~314 words

Removal

Remove the clip (B) above air cleaner case.

Scheme 2

Scheme 2: Removal

Remove the air cleaner element.

Installation

Install in the reverse order of removal.

Note. Fasten it with a clip after inserting the lower tab of case.

Scheme 3

Scheme 3: Installation

Disconnect the ground cable from battery.

Scheme 4

Scheme 4: Removal

Loosen the clamp (A) which connects the air cleaner case and intake duct.

Remove the clips (B) of air cleaner case.

Disconnect the connector (C) of air flow sensor.

Scheme 5

Scheme 5

Remove the intake duct and upper cover from air cleaner case.

Remove the air cleaner element.

Remove the bolts which install the air cleaner case to body.

Scheme 6

Scheme 6

Remove the air cleaner case.

Install in the reverse order of removal.

Tightening torque

33 Nm (3.4 kgf-m, 24.6 ft -lb)

Scheme 7

Scheme 7: Installation

Loosen the clamp (A) which connects the air intake chamber and throttle body.

Loosen the clamp (B) which connects the air intake chamber and intake duct.

Remove the bolts (C) which connects the air intake chamber to the stay.

Scheme 8

Scheme 8: Removal

Disconnect the two blow-by hoses, and then remove the air intake chamber.

Install in the reverse order of removal.

Tightening torque

6.5 Nm (0.66 kgf-m, 4.8 ft-lb)

Remove the bolts which install the air intake duct on the front side of body.

Remove the air intake duct.

Scheme 9

Scheme 9: Removal

Install in the reverse order of removal.

Tightening torque

7.5 Nm (0.76 kgf-m, 5.5 ft-lb)

Set the vehicle on a lift.

Remove the air intake duct.

Remove the air cleaner lower case.

Remove the resonator chamber mounting nut on the right side of engine compartment.

Scheme 10

Scheme 10: Removal

Remove the front wheel RH, and then lift-up the vehicle.

Remove the front mudguard RH.

Remove the resonator chamber (A) from inside front fender.

Scheme 11

Scheme 11

Install in the reverse order of removal.

Tightening torque

7.5 Nm (0.76 kgf-m, 5.5 ft-lb)
