Intake (Induction), 2.5L: Overview Saab 9-2X I

Mechanical 1 illustration

Scheme 1

Scheme 1: Air Intake Chamber Components
Scheme 1: Air Intake Chamber Components
  1. Resonator chamber
  2. Cushion
  3. Air intake duct
  4. Cushion
  5. Clip
  6. Air cleaner lower case
  7. Cushion
  8. Spacer
  9. Air cleaner element
  10. Guide
  11. Air cleaner upper cover
  12. Air flow sensor
  13. Clamp
  14. Intake duct
  15. Cushion
  16. Spacer
  17. Bolt
  18. Clamp
  19. Air intake chamber
  20. Spacer
  21. Cushion
  22. Stay LH (MT model)
  23. Stay LH (AT model)
  24. Clamp
  25. Stay RH Tightening torque: Nm (kgf-m, ft-lb) T1: 33 (3.4, 24.6) T2: 6.5 (0.66, 4.8) T3: 7.5 (0.76, 5.5) T4: 16 (1.6, 11.6) T5: 1.0 (0.1, 0.7) T6: 3.0 (0.3, 2.1)
