Removing front pneumatic spring
Installation Location
Scheme 107
1. Open front lid.
Scheme 108
2. Unfasten the pneumatic spring from the lid and the body.
2.1. A second person should hold the lid to prevent it from accidentally falling.
2.2. Insert a screwdriver -2- between the head of the pneumatic spring and safety clip -3- -A-. (Scheme 108)
2.3. Release the safety clip -3- by levering the screwdriver -2- towards the pneumatic spring -B-. The safety clip remains in the head of the pneumatic spring. (Scheme 108)
2.4. Pull pneumatic spring -1- from ball heads -C-. (Scheme 109), (Scheme 108).
2.5. Withdraw the screwdriver.
Scheme 109
Scheme 110
3. Remove pneumatic spring -1- -arrow-. (Scheme 110)
3.1. The lid can be fixed in the service position by using special tool bonnet stay P 9704 for further service work > Removing and installing bonnet stay for service position .
