Installing front lid
Installation Location
Scheme 100
1. Install front lid.
1.1. Position -1- front lid -Arrow A-. (Scheme 101), (Scheme 100).
1.2. Screw fastening nuts -2- onto studs and position carefully -Arrow B-. (Scheme 101)
Scheme 101
2. Install pneumatic spring on front lid > 553119 Removing and installing pneumatic spring on front lid - "Installing"
3. Adjust front lid > 552215 Adjusting front lid .
4. Tighten fastening nuts -2- --> Tightening torque: 15 ftlb. +/-2 ftlb.. (Scheme 101)
5. Install wire harness on front lid. Refer to 97 13 19 Removing and installing wiring harness in engine compartment - as of MY 2003 (All Models) .
6. Install insulation for front lid. Refer to 70 04 19 Removing and installing insulation for engine compartment lid - as of MY 2003 (All Models) .
7. Closing front lid
