Installing release for front lid
Installation Location
Scheme 9
1. Install actuating mechanism for front lid.
Scheme 10
1.1. Engage ball head -7- ( -arrow A- ) and clip in rear section of cable for front lid lock -3- at the actuating mechanism for the front lid -5- ( -arrow B- ). (Scheme 10)
Scheme 11
1.2. Insert actuating mechanism for front lid -5- into the body ( -arrow C- ). (Scheme 11)
Scheme 12
1.3. Screw in -6- fastening screws. (Scheme 12)
Scheme 13
2. Clip in rear section of cable for front lid lock.
2.1. Clip in rear section of cable for front lid lock -3- at the fastening clips -4- ( -arrows D- ). (Scheme 13)
Scheme 14
3. Secure insulating mat.
3.1. Swivel insulating mat -1- back ( -arrow E- ) and clip in fastening clips -2- ( -arrow F- ). (Scheme 14), (Scheme 15).
Scheme 15
4. Install front side section trim panel. Refer to 70 24 19 Removing and installing front side section trim - as of MY 2003 (All Models) .
Scheme 16
Scheme 17
Note. The lower part of the lock does not have to be removed from the lock support to facilitate the removal of the front section of the cable for the front lid lock.
1. Remove front lock lower part > 551719 Removing and installing front lock lower part - "Removing" .
Scheme 18
2. Unclip front section of cable for front lid lock.
2.1. Release front section of cable for front lid lock -1- ( -Arrow A- ) and swivel it out ( -Arrow B- ). (Scheme 18)
Scheme 19
3. Disengage ball head and remove front section of cable for front lid lock.
3.1. Disengage ball head -2- ( -Arrow C- ) and remove front section of cable for front lid lock -1- ( -Arrow D- ). (Scheme 19)
Scheme 20
Note. The lower part of the lock does not have to be removed from the lock support to facilitate the removal of the front section of the cable for the front lid lock.
1. Remove front lock lower part > 551719 Removing and installing front lock lower part - "Removing" .
Scheme 21
2. Unclip emergency release cable.
2.1. Release emergency release cable -1- ( -Arrow A- ) and swivel it out ( -Arrow B- ). (Scheme 21)
Scheme 22
3. Disengage ball head and remove emergency release cable.
3.1. Disengage ball head -2- ( -Arrow C- ) and remove emergency release cable -1- ( -Arrow D- ). (Scheme 22)
