Assembling rear lid
Installation Location
Scheme 203
1. Installing lateral adjusting buffer.
1.1. Screw in blind rivet nuts for the lateral adjusting buffer -6- on the rivet gun, insert on the rear lid and rivet using hand-held blind rivet nut device NR.125. see scheme 233
1.2. Place lateral adjusting buffer -3- on the rear lid and screw in fastening screws -1, 2- -Arrows C-. see scheme 233
Scheme 204
2. Installing blind rivet nuts for the number plate holder.
2.1. Screw in blind rivet nuts for the number plate holder -7- on the rivet gun, insert on the rear lid -Arrows D- and rivet using hand-held blind rivet nut device NR.125. (Scheme 203)
Scheme 205
3. Installing blind rivet nuts for the trim strip holder and the rear window buffer
3.1. Screw in blind rivet nuts for trim strip holder -8- and rear window buffer -9- on the rivet gun, insert on the rear lid and rivet using hand-held blind rivet nut device NR.125. (Scheme 204)
Scheme 206
4. Installing buffer for rear window
4.1. Screw in buffer for rear window -4, 5- -arrows E- and tighten to the specified tightening torque --> Tightening torque: 1.0 ftlb.. (Scheme 205)
Scheme 207
5. Installing mounting points for the side trim.
5.1. Insert plastic clips -10- from the outside -Arrows H- for the mounting points of the side trim. (Scheme 206)
1. Install rear window release. Refer to 64 66 19 Removing and installing bottom section for rear window release - as of MY 2003 (All Models) .
2. Install wiper motor for rear window wiper system. Refer to 92 34 19 Removing and installing wiper motor for rear window wiper system - as of MY 2003 (All Models) .
3. Install number plate light. Refer to 94 29 19 Removing and installing number plate light - as of MY 2003 (All Models) .
4. Install release for rear lid > 555719 Removing and installing release for rear lid - "Installing"
5. Install rear lock upper part > 558719 Removing and installing rear lock upper part - "Installing" .
6. Install wiring harness on rear lid. Refer to 97 27 19 Removing and installing wiring harness for rear panel flap - as of MY 2003 (All Models) .
7. Install trim strip for rear lid. Refer to 66 47 19 Removing and installing molding for rear lid - as of MY 2003 (All Models) .
8. Install rear window seal. Refer to 64 90 19 Removing and installing rear window seal - as of MY 2003 (All Models) .
9. Install rear window. Refer to 64 86 19 Removing and installing rear window - as of MY 2003 (All Models) .
10. Install rear spoiler.
11. Remove linings for rear lid. Refer to 70 87 19 Removing and installing lining for rear lid - as of MY 2003 (All Models) .
12. Install rear lid. > 559019 Removing and installing rear lid - "Installing".
