INSTALLATION
Note. Always fit the isolating ring (Scheme 1) before installing the sensor (Scheme 1)- The smooth surface of the isolating ring faces the sensor.
Scheme 1
- Fit isolating ring and push sensor into the sensor housing.
- Slide retaining spring over the sensor housing and press on until it meets the stop.
- Engage electrical plug connections and install fit rear spoiler.
Note. The electrical plug connection in the vehicle must always point to the center of the vehicle. Plug connection with marking (white adhesive tape) on the wiring harness always connected to outer left sensor.
- Engage the electrical plug connections and carefully lay the electrical leads (do not pinch).
- Clip in cover on the left and right and perform a function test.
- Engage electrical plug connection and route lead carefully.
- Install housing with GPS antenna and clip in cover. NOTE: The GPS antenna must not be covered by metallic or moist objects.
