Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Inside Rearview Mirror Set Screw | 2 N.m | 18 lb in |
| Power Mirror Motor Screws | 2 N.m | 18 lb in |
| Outside Rearview Mirror Nuts | 10 N.m | 89 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 2
| Callout | Component Name |
|---|---|
| 1 | Door Lock Actuator - Driver |
| 2 | Window Switch - Driver (A31) |
| 3 | Outside Rearview Mirror - Driver (D48) |
| 4 | Outside Rearview Mirror Switch (D48) |
| 5 | Speaker - LF Door |
| 6 | C166 |
| 7 | C165 |
| 8 | Window Motor - Driver (A31) |
Callouts For (Scheme 2)
Scheme 3
| Callout | Component Name |
|---|---|
| 1 | Outside Rearview Mirror Switch |
| 2 | Outside Rearview Mirror - Driver |
| 3 | Outside Rearview Mirror Connector - Driver |
| 4 | C166 |
| 5 | C165 |
| 6 | S501 |
| 7 | Speaker Connector - LF Door |
| 8 | S500 |
| 9 | Window Motor - Driver |
| 10 | Window Switch - Driver |
| 11 | Door Lock Actuator - Driver |
Callouts For (Scheme 3)
Scheme 4
| Callout | Component Name |
|---|---|
| 1 | Speaker - RF Door |
| 2 | Outside Rearview Mirror - Passenger (D48) |
| 3 | Door Lock Actuator - Passenger |
| 4 | Window Switch - Passenger (A31) |
| 5 | Window Motor - Passenger (A31) |
| 6 | C167 |
Callouts For (Scheme 4)
Scheme 5
| Callout | Component Name |
|---|---|
| 1 | C167 |
| 2 | Outside Rearview Mirror Connector - Passenger |
| 3 | Outside Rearview Mirror - Passenger |
| 4 | Window Motor - Passenger |
| 5 | Door Lock Actuator - Passenger |
| 6 | Window Switch - Passenger |
| 7 | Speaker Connector - RF Door |
| 8 | S600 |
Callouts For (Scheme 5)
Scheme 6
| Connector Part Information OEM: 917981-2 Service: See Catalog Description: 16-Way F 0.040/0.070 Hybrid I/O (BK) |
|---|
| Terminal Part Information Terminal/Tray: 175266-5/15 Core/Insulation Crimp: Pins: 1, 6, 8 K/K Core/Insulation Crimp: Pins: 11, 12, 14, 15 J/J Release Tool/Test Probe: 15315247/J-35616-16 (L-GN) |
Inside Rearview Mirror Connector Part Information (w/UE1)
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | GY | 157 | Courtesy Lamp Control |
| 2-5 | Not Used | ||
| 6 | D-BU/WH | 149 | Courtesy Lamp Supply Voltage |
| 7 | Not Used | ||
| 8 | BK | 550 | Ground |
| 9-10 | Not Used | ||
| 11 | D-GN/WH | 2514 | Keypad Signal |
| 12 | L-GN/BK | 2515 | Keypad Supply Voltage (UE1) |
| 13 | Not Used | ||
| 14 | YE/BK | 2516 | Keypad Green LED (UE1) |
| 15 | BN/WH | 2517 | Keypad Red LED (UE1) |
| 16 | Not Used |
Inside Rearview Mirror Connector Terminal Identification (w/UE1)
Scheme 7
| Connector Part Information OEM: 12124782 Service: 15306078 Description: 7-Way F VH Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: SVH-21T-P1.1/20 Core/Insulation Crimp: E/2 Release Tool/Test Probe: 12094429/J-35616-18 (BK) |
Inside Rearview Mirror Connector Part Information (w/o UE1)
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | Not Used | ||
| 2 | BK | 550 | Ground |
| 3-5 | Not Used | ||
| 6 | GY | 157 | Courtesy Lamp Control |
| 7 | D-BU/WH | 149 | Courtesy Lamp Supply Voltage |
Inside Rearview Mirror Connector Terminal Identification (w/o UE1)
Scheme 8
| Connector Part Information OEM: E-5965-003 Service: 88988356 Description: 3-Way M 1.5 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 7114-4102-08/9 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094430/J-35616-3 (GY) |
Outside Rearview Mirror (Driver) Connector Part Information (D48)
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | L-BU | 82 | Driver Mirror Motor Left Control |
| 2 | TN | 329 | Driver Mirror Motor Supply Voltage |
| 3 | YE | 88 | Driver Mirror Motor Up Control |
Outside Rearview Mirror (Driver) Connector Terminal Identification (D48)
